cnc lathe machine used for sale

HAISHU CNC550T 4-axis CNC Lathe Producer- Taian HAISHU Machinery Co. Ltd YOM 2015 Condition- Never used Equipped with two spindle and an additional lower turret with 12 tools, providing automatic two-way processing of the workpiece in the achievement of maximum processing speed. Control CNC GSK988TD Additional Y axis Max. working length 750 mm Maximum turning diameter over bed 550 mm Maximum turning diameter pallet 500 mm Spindle type А12 Hydraulic Jaws: 2x 300 mm Front spindle bore taper 1:20 Spindle pass 75 mm Speed of Servo spindled 0-4000 mm/min Axis X/Z/B Quick moves 40 000 mm/min CS1, CS2 power of main motors: 15 kW Engine motor on axle C- 5.5 kW Moment by Axis X/Z: 15 Nm Movement on Y axis: + 55/-55 mm; Moment on axis B: 20 N. m; Time to change tool 1.6 sec Positioning accuracy 0.005 mm Moves on axes X1/X2- 350 mm Moves on axes Z1/Z2- 1100/1350/1850 mm ...

Calpe (5) station CNC lathe

AUTOMATIC SPINNING LATHE DENN RPE-290 Denn Mod.RPE-290 Automatic Spinning Lathe- Spindle Speeds 615/1060/1825 RPM. More information on request.

3-points Steady Ø 350 mm for SCULFORT Lathe Centre height: 550 mm Maxi diameter: Ø 350 mm Distance between fixing V: 350 mm Width: 1200 mm Thickness: 300 mm Total height: 1300 mm Weight: approx 250 kg

Touches 3-points Steady Ø 800 mm for SCULFORT Lathe Centre height: 550 mm Maxi diameter: Ø 800 mm Base dimensions: L 635 x W 300 mm Distance between fixing V: 480 mm Width: 1600 mm Thickness: 350 mm Total height : 1500 mm Weight: approx 250 kg

Polish Lathe / Polishing Machine Between points: 1500 mm Centre height: 180 mm Spindle CM3 Spindle speed driven by speed variator Pneumatic tailstock Equipped with a vaccum system (only air hose to plug in) Machine was used to polish axes Voltage: 220 V mono Dimensions (L x W x H): 3200 x 1000 x 1900 mm Weight: 1,2 T

This 600 Lathes Multiturn 2000 was manufactured in 2004. A robust horizontal turning machine featuring a turning diameter above bed of 400 mm, and a length of 1250 mm. It operates at a spindle speed of 2700 rpm with an 8-position turret. Tailstock taper is Morse 5. If you are looking to get high quality turning capabilities consider the 600 Lathes Multiturn 2000 machine we have for sale. Contact us for more information.

Type: SBS-1851 Gebruiksvriendelijke draaibank voor het draaien van de binnenzijde van trommelremmen. 380 volt Long: 1900 mm Depth: 800 mm Height: 900 mm Weight: 275 kg

ZUCKERMAN CHALLENGER- auto copy lathe and sander, capacity - ( mills 10" dia.by a max. of 120" long) hopper feed mills using cup cutters- followed by (1) sanding station, unit has hopper feeder, mills & sands one part at a time, does parts like: boat oars, shovel handles, gunstocks, chair legs, ect. Price-$10,900

Reichenbacker copy lathe mills/ turns (6) concentric or non concentric pieces at a time (1) station for your model/sample (models may be wood or metal) complete set up for duck decoys various sizes - items like Queen Ann legs, ect (photos available) (6) milling /working stations

Lmacchia Barley twist lathe- model012/FE Spiral/rope turning lathe Barley twist with automatic indexing 67" max. length 8" max. working diameter as new condition...$9,500 obo Contact Fred (716) 433 4224 (12:00 noon is best time to call)

Hemco hydraulic tracing lathe Hopper feed very good condition...$7,900 obo Contact Fred (716) 433 4224 (12:00 noon is best time to call)

Rotary Lathe with Staylog Bar and Longitudinal Cutting System

Reinbacker- rope turning lathe chuck up your part- twin routers transverse your material as lathe slowly rotates your material several passes give you a straight or tapered spiral like a rope turning or straight or spiral flutes

Universal lathe Harrison M250 - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Universal lathe Harrison M250 Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers Laminators Offset printing machinery Others Paper drills Perfect binders Pile turners Spare parts Stitching machines Universal lathe Harrison M250 Price: 6000 EUR Download PDF Universal lathe Harrison M250 The machine is in very good condition, not used in production. It served as an auxiliary machine in the maintenance department of the printing house. Technical data: Turning diameter over the bed: 280 mm Turning diameter over the slide: 170 mm Turning Length: 680MM Rotation speed: 40 – 1500/9 step U / min Spindle bore: 35 mm Tailstock taper MK: 3 ...

3D CNC Router T-Rex 1215 / Technical Data : Equipment / product data CNC-milling machine type High-Z/TRex series: Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all exis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 1860 x 1340 mm Travels: X=1500mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions wi ...

Manufacturer: Richpeace Machine Type: Flat Plate CNC Cutting Machine (3-in-1) Model: RPFP-NM-1D-FD-CKC-1-2000X2000-DGSF-QC-P-CK-EVK-PG-AF+AR-SP380 Year of Manufacture: 2020 (July 27, 2020) Technical Specifications - Working Mode: Camera + double bridge cutting - Cutting Area: 2000 mm (X) x 2000 mm (Y) - Camera Recognition Area: 1500 mm (X) x 2000 mm (Y) - Maximum Cutting Speed: 60 m/min - Maximum Cutting Thickness: 5 mm - Locating System: Vision localization - Loading, Orientation and Recognition Time: 10 seconds - Cutting Tools: Ink jet (optional) + round knife + vibrating knife (optional) + mark pen - Knife Replacement Cycle: Every 5 days x 8 hours of operation - Control System: Full servo system - Feeding System: Automatic transfer feed Transmission and Drive - X-axis: High-precision timing belt + linear guide - Y-axis: High-precision timing belt + linear guide Physical and El ...

Met RoboHelix-machines kunnen spiraalvormige schoepen worden gevormd uit standaard ronde of van een patroon voorziene werkstukken. RoboHelix-machines vereisen uiterst nauwkeurige synchrone bewegingsbesturing. Door de gebruiker gegenereerde gegevens worden vanuit cloudgebaseerde software, HelixNinja, naar het apparaat gedownload. Deze informatie wordt vervolgens verder verwerkt om coördinaten in het 3D-vlak te genereren, waarmee het proces van het creëren van een vliegtuig vanuit een blanco basis wordt nagebootst. De motoren volgen synchroon deze coördinaten om het vliegtuig te produceren. Met de elektronische nokkenplaatfunctie in TwinCAT NC Camming (TF5050) is relatieve synchrone beweging overal en altijd mogelijk. Afmetingen en toleranties zijn geen probleem meer zodra de motoren en aandrijvingen zijn gekalibreerd. De tweede generatie RX250 uit de machinelijn van RoboHelix heeft een ...

This 2019 CMA Machine Tools 3RD CNC 4506 is a high-performance machining center featuring an OMRON industrial 15.4 touchscreen Controller. With 3 (X/Y/Z) controlled axes and 3 (X/Y/Z helical interpolation) simultaneous axes, it offers a generous X-axis travel of 4500 mm, Y-axis travel of 600 mm, and Z-axis travel of 450 mm. The BT40 (MAS 403 BT) spindle delivers up to 4000 rpm, 13.1 kW power, and 125 Nm torque. Equipped with a 10-position rotary tool magazine and 4 bar coolant through spindle, this machine is optimized for structural parts. With only 692 spindle working hours, this CE-compliant unit includes an emulsion coolant system, chip conveyor, and advanced programming capabilities for efficient production.

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1215 Drive: 3 busiest brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse play maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 1860 x 1340 mm travel distances: X=1500mm; Y=1200mm; Z= 130 mm contact contactno-point sensors / reference switches / limit switches on all axes Double-secured emergency trigger energy chains for clean cable Total mass with motors : LxWxH approx. 2180 x 1800 x 1420 mm Fra- Sc ...

Equiptment / product data CNC-milling machine type High-Z/TRex series / 1224 Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all axis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 2800 x 1340 mm Travels: X=2400mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions with engines : LxBxH ca. 3070 x 1800 x  ...

Specifications / Technical Data S-1000 CNC-Fraese and Engraving Machine The almost largest CNC machine in the High-Z series. With an external dimension of approx. 1350 x 800mm still handy enough and extremely powerful. With the High-Z CNC unit, they acquire an all-round talent in TUeV-certified quality (EMC). Whether you want to clamp complex parts on a groove table or, or to clamp factory tins into a high vice (the machine is on a frame construction, is driven in X via 2 motors and thus allows to be placed completely over a part to be machined). or simply want to do engraving or drilling then they simply work on a flat base, on which they then attach e.g. an MDF plate, which they once overfrave plan and are then able to work up to approx. +-0.02mm exactly in depth. All CNC portal fraes machines are supplied with coloured energy chains on all axes due to the improved cable guid ...

machine has live spindle for drilling and grinding face plate diameter mm 800 max. workpiece diameter mm 1000 max. workpiece height mm 750 max. diameter of external working mm 1000 Z axe mm 630 face plate revolutions 1 5 – 500 rpm main motor output kW 30 (40) machine dimensions length mm 4900 height mm 3830 width mm 4485 machine weight kg 16000 machine had DRO Tesla NS 642

Table diameter 2,000 mm Max. Turning diameter 2,150 mm Turning height 1450 mm Table speed 3-140 rpm Max. weight of the workpiece 12000 kg Milling spindle: Maximum speed 2,000 rpm Milling spindle Motor power 22 kW Total weight of the machine approx. 34,000 kg Machine complete with: C-axis: 360,000° Milling spindle 22 KW Tool changer 16 positions Tool changer for milling tools ISO 50 16 positions Complete cladding Conveyor Complete cooling system with filtration

faceplate diameter: 1000 mm swing diameter: 1400 mm turning height: 1400 mm control: SIEMENS 850M total power requirement: 125 kW weight of the machine ca.: 38 t dimensions of the machine ca.: m Stocknumber 1020042 Type of machine CNC VTL Make PIETRO CARNAGHI Type AC 10 CNC Build in 1987 Type of control Siemens 850 M/E Faceplate diameter 1000 mm Max. Swing diameter 1400 mm Turning height max. 1400 mm Total Power (KW) totaal 125 Lenght (mm) 11000 Width (mm) 8000 Height (mm) 6000 Weight 38000 kg Additional information with driven tools with pallet changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: ca. 500 mm swing diameter: ca. 600 mm travel -x axis: ca. 400 mm travel -z axis: ca. 600 mm spindle turning speed range: 2000 U/min spindle drive: 63 kW control: SIEMENS control: SINUMERIK System 3 tool turret: 1 x 12 Pos total power requirement: kW weight of the machine ca.: 9,3 t dimensions of the machine ca.: m - R-version, turret right hand side of 3-jaw chuck - Accessories: hydr. 3-jaw chuck 400 mmø, various toolholders for turret, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Vertical turning lathe SEDIN 1512 CNC CNC control- Eastern origin Table diameter: 1120 mm Max work-piece: -Diameter: 1250 mm -Height: 1000 mm -Weight: 3200 kg Table speeds range per 1 min: 5-250 Tool dimensions: 25×40 Max horizontal travel of the vertical ram: 775 mm Max vertical travel of the vertical ram: 700 mm Max horizontal travel of the horizontal ram: 630 mm Max vertical travel of the horizontal ram: 1000 mm Max turning angle of the vertical ram: 45 degree Cross rail: -Travel: 660 mm -Speed: 400 mm/min Main motor power: 30 kW Overall dimensions: 2750×2975×4100 mm Machine weight: 15700 kg

SEDIN 1516 CNC Vertical Turret Lathe CNC control- Eastern origin Turning diameter: 1600 mm Table diameter: 1400 mm Max workpiece height: 1000 mm Max table loading: 5000 kg Max horizontal ram travel: 630 mm Max horizontal carriage travel: 975 mm Max vertical ram travel: 700 mm Max vertical carriage travel: 1000 mm No of feed carriages: 16 Carriages feed range: 0,07-12,5 mm/rev Distance between table and ram: 0-1225mm Fast stroke: 2000 mm/min Main motor power: 30 kW Speeds range: 4 - 200 rpm Dimensions: 3190x3360x4100 mm Weight: 18200 kg

Key data: 5000 mm, 8000 mm, 4000 mm

Berthiez Vertical Turning Lathe • Year of manufacture: 1982 • CNC type: older system (CNC axes) Dimensions and Working Parameters • Table diameter: 5000 mm • Maximum turning diameter: 8000 mm • Maximum turning diameter at center: 5000 mm • Maximum workpiece height: 4000 mm • Ram travel (T): 3600 mm • Saddle travel (TA): 650 mm Speed and Power • Table rotation range: 0.6 – 60 rpm • Table motor power: 140 kW • Maximum load on hydraulic support: 160 t • Ram feed speed: 400 mm/min • Saddle feed speed: 2500 mm/min • Spindle rotation for milling: 0.01 – 0.50 rpm • Positioning speed: 0.001 – 0.50 rpm Tool Carriages 1. Hand-Operated (Primary) Carriage • Kulannum section size: 360 × 360 mm • Axial travel (CA): 2500 mm • Horizontal travel (CB): 3400 mm • Tilt range (E-F): 15° – 45° 2. Side Tool C ...

Inv. Num. : 9058 Type: SPV 40 CNC Producer: CZ. TECH Created: 2008 Parameters: Control system: SIEMENS Table diameter: 533 mm Feed length X-axis: 550 mm Feed length Z-axis: 850 mm Max. turning diameter: 850 mm Max. workpiece height: 800 mm Max. workpiece weight: 800 kg Weight: 12500 kg

Key data: 1000 mm, 450 mm

Inv. Num. : 9150 Type: CNC 10 A/B Producer: DÖRRIES Created: GO 2015 Parameters: Control system: Siemens Sinumerik SL Table diameter: 1000 mm Engine power: 69 kW Max. workpiece diameter: 1500 mm Max. workpiece height: 450 mm Max. workpiece weight: 5000 kg Maximum table speed: 2-120/ 20-400 1/min Equipment: Chip conveyor 4-position turret Hydraulic/Manual 3-Jaw Chuck

Description WE OFFER AN HIGH TECH CNC LATHE TURNING AND MILLING CENTRE MACHINE IS COMMING OUT FROM FORMULA 1 - MERCEDES WORKSHOP MACHINE WAS FROM NEW HIGEST POSSIBLLE MAINTAINED WITH OFFICAL MORI SEIKI TECHNICAL DATA: Mori Seiki MT2000 CNC Lathe Description: Swing over bed - 700mm, Distance between centres - 1080mm, Max turning dia meter - 550mm, Max turning length - 1020mm, Bar capacity - 65mm, X Travel - 565mm, Y Travel - +/-80mm, Z Travel - 1077mm, B Indexing - +/-120deg, X Travel Turret 2 - 155mm, Z Travel Turret 2 - 1067mm, Spindle Speed - 4500rpm, Spindle nose - JIS A2-6, Tool Spindle Speed - 6000rpm, Tool Spindle type - Capto C6, ATC - 40 Tools, Max tool length - 280mm, Max tool weight - 7kg, Turret 2 Tools - 12, Square shank - 25mm, Boring bar shank diameter - 40mm, ...

faceplate diameter: 1200 mm swing diameter: 1400 mm turning height: 1190 mm Control: Siemens type: 840C max. ram stroke: 1250 mm Tool changer: 12 Pos Table load: 9000 kg cross rail - adjustment: 800 mm turning speeds: 2,5-250 U/min rapid traverse: 4 m/min total power requirement: 55 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 3,95x3,6x5,56 m No. 1096/97 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look  ...

Main Technical Specifications: Machine Type: Heavy-Duty CNC Vertical Turning Lathe Chuck / Table Diameter: 4,500 mm Maximum Machining Height: 3,150 mm Maximum Workpiece Load Capacity: 80 metric tons CNC Control System: Siemens The machine is suitable for heavy machining applications in the power generation, metallurgy, heavy engineering, and other industrial sectors. Price, technical documentation, photographs, and further details regarding the machine’s condition and configuration are available upon request.

Model : VTS-1620 CNC Vertical Lathe Year : 2013 Table : 1600mm manual chuck/10,000 kg load Table speed : 250 rpm Max swing : 2000mm Max cutting height : 1556mm X/Z : -127~1600mm/960mm Ram size : 308x250mm 37.5/45 kW motor 18 position ATC 8 tool holders Tool presetter Manual guide i Chip conveyor Fanuc control

Model : V550 CNC Vertical Lathe Year : 2012 Max cutting dia : 730mm Max cutting height : 730mm Table speed : 2000rpm 21" hyd. Chuck 10 Position Turret Gearbox Chip conveyor Fanuc control

Important and outstanding design features of the RaptorX-SL with steel substructure / The range of applications of a RaptorX-SL CNC Machine is variable due to the high-adjustable working area (read-through under bridge variable : 150mm, 300mm or 400mm ) and the 300mm travel height in the Z-axis (no extra charge) extremely large. special groesmes up to 17,500 mm (at one scale) x 3000 mm x 600 mm are possible ! If you are interested, please ask ! So you are able to process plate materials with the greatest stability of the Z-axis just as precisely as 200mm high 3D-parts. Use the system as a plasma cutting system or water jet cutting system, corresponding extensions are available. In the middle range of the machine (between the foottubes ) you can even process parts up to a height of 850mm (beam shrare etc. ) or 3D body up to about 400mm height ( at 400mm long Fraeser ) ...

Important and outstanding design features of the RaptorX-SL with steel substructure / gantry design RaptorX-SL1200/S20 The range of applications of a RaptorX-SL CNC Fraesmaschine is variable due to the adjustable working area (through-lasshoehe under Bruecke: 150mm, 300mm or 400mm ) and the travel height of 300mm in the Z-axis (at no extra charge) extremely large. special size (on one piece) x 3000 mm x 600 mm are feasible ! If you are interested please ask ! To such a way that you are able to process plate materials with the greatest stability of the Z-axis exactly as accurately as 200mm high 3D-Koerper. Use the system as a plasma cutting system or water jet cutting system, are available In the middle range of the machine (between the foottubes) you can even process parts up to a height of 850mm (beam rail etc. ) or 3D body up to about 400mm height ( at 400mm long F ...

Important and outstanding design features of the RaptorX-SL with steel substructure in gantry design RaptorX-SL1200/S15 The range of applications of a RaptorX-SL CNC Fraesmaschine is variable due to the adjustable working area (through-lasshoehe under Bruecke: 150mm, 300mm or 400mm ) and the traversing height of 300mm in the Z-axis (at no extra charge) extremely large. Special size up to 17,500 mm (on one piece) x 3000 mm x 600 mm are feasible ! If you are interested please ask ! This way you are able to process plate materials with the greatest stability of the Z-axis just as accurately as 200mm high 3D-Koerper. Use the system as a plasma cutting system or waterjet cutting system, appropriate extensions are available. In the middle range of the machine (between the foot tubes) you can even process parts up to a height of 850mm (beam rail etc. ) or 3D body up to about 400mm h ...

Important and outstanding design features of the RaptorX-SL with steel substructure /RaptorX-SL3200/S15 The application variety of a RaptorX-SL CNC Fraes machine is variable due to the high-adjustable working area (read-through he under bridge variable : 150mm, 300mm or 400mm ) and the travel height of 300mm in the Z-axis (without extra charge) extremely large. special coarseness up to 17,500 mm (on one scale) x 3000 mm x 600 mm are possible ! If you are interested, please ask ! So you are able to process plate materials with the greatest stability of the Z-axis just as precisely as 200mm high 3D-coerpers. Use the system as a plasma cutting system or waterjet cutting system, corresponding extensions are available. In the middle range of the machine (between the footpipes ) you can even process parts up to a height of 850mm (beam shroughl, etc. ) or 3D body up to about 400mm hei ...

Specifications / Technical Data S-720 CNC-Fraesmaschine With the High-Z CNC-Fraes.- and Engraving Machine you acquire an all-round talent in TUeV-certified Quality (EMV). Whether you want to clamp complex parts on a groove table or, or put factory tins in a high vice (the machine is on a frame construction, is driven in X via 2 motors and thus allows to be placed completely over a part to be machined). or simply want to do engraving or drilling then they simply work on a flat base, on which they then attach e.g. an MDF plate, which they once overfrave plan and are then able to work up to approx. +-0.02mm exactly in depth. All machines are supplied with coloured energy chains on all axes due to improved cable guidance. Furthermore, all machines are protected with a double-secured emergency exit button. Another is located directly at the controller. Basic equipment of all high- ...

Specifications / Technical Data S-720 CNC-Router / CNC-Engraver / Milling machine With the High-Z cnc router and engraving machine you purchase an allround talent in TÜV-certified quality. If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc milling machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc routers / milling machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc milling machines are equipped with an emergency stop button. An additional emerge ...

Important and outstanding design features of the RaptorX-SL with steel substructure / RaptorX-SL2200/S20 The application variety of a RaptorX-SL CNC Fraes machine is variable due to the adjustable working area (read-through shoe under bridge: 150mm, 300mm or 400mm ) and the travel height of 300mm in the Z-axis (at no extra charge) extremely large. special groesmes up to 17,500 mm (at one scale ) x 3000 mm x 600 mm are possible ! If you are interested, please ask ! So you are able to process plate materials with the greatest stability of the Z-axis just as precisely as 200mm high 3D-plates. Use the system as a plasma cutting system or waterjet cutting system, corresponding extensions are available. In the middle range of the machine (between the footpipes ) you can even process parts up to a height of 850mm (beam shroughl, etc. ) or 3D body up to about 400mm height (at 400mm ...

Important and distinguishing design features of the RaptorX SL CNC Router steel base machine RaptorX-SL2200/S15 The application range of the RaptorX- SL CNC milling machine is extremely wide due to the adjustable work surface height (variable bridge clearance: 150mm, 300mm or 400mm) plus the travel range of the Z axis of 300mm (at no extra cost). The Z axis stability is excellent, allowing you to work as accurately on large 3D objects as one can on flat sheet materials. Use the system as a plasma cutting system or a water jet cutting system, appropriate accessories are available. It is possible to work on work-pieces up to a height of 850mm (steel cabinets etc.) or three-dimensional objects up to a height of approx. 400mm (with 400m long milling cutter). This capability is unusual for machines of this size and mold makers usually use a layered construction metho ...

Specifications / Technical data S-1400/T 3-axis CNC-portal-machine and engraving machine (Attention: Pictures show the High-Z S-1400 with trapezoidal thread spindles, this differs exclusively by the spindles . With the T-variant of the high-Z CNC fraes machine, you acquire old-fashioned technology with the certain I-meat in TUeV-certified quality (EMC). The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circulation spindles used, the High-Z/T portalfraes machine achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This means engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can s ...

Specifications / Technical Data S-1400/T CNC-Router and CNC-Engraver / Engraving Machine (Attention: Pictures are showing the type with trapezium spindles, thats the only different to the t-series ) With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers are conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T cnc-machines achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this 3D-cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on ...

Specifications / Technical data S-1000/T Portalfraesmaschine / Engraving machine With the T-variant of the High-Z CNC-Fraese you acquire old-fashioned technology with the certain i-tuepfelchen in TUeV-certified quality (Emc). The High-Z/T Fraese is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circuit spindles used, the High-Z/T achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This is how engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can see a video about empty runs with the new high-Z/T 3D CNC machine. This makes this machine series in the industrial sector just as applicable for work ...

Specifications / Technical Data S-1000/T CNC-Router / CNC-Engraver With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T CNC-engraver achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This cnc-router series is usable in the industrial field as well as for works like engraving, milling, dr ...

Specifications / Technical Data S-720/T CNC-Fraesmaschine und Graviermaschine / Fraese With the T-variant of the High-Z CNC Fraes.-and engraving machine you acquire old-fashioned technology with the certain i-Tpuelchen in TUeV-certified quality (EMC). The High-Z/T CNC-Fraese is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. The high-Z/T CNC-Fraese achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm due to the ball's circulation spindles. At the same time, high travel speeds of up to 108mm/second ( 6500mm/ minute) can be achieved. This allows engraving and feeding speeds of up to approx. 4500mm/min and express ingesses up to approx. 7000mm/min. Here you can watch a video of empty journeys with the new High-Z/T. This series of mechanical engineering is just as applicable in the industrial sec ...
