Key data: 5005 mm, 3586 mm, 1106 mm
year of production: 2007 automatic tool change Work spaces [mm]: 5000x2500 Groove distance [mm]: 200 Travel ranges [mm]: 5005x3586x1106 Work feed [m/min]: 35m/min Rapid feed [m/min]: 40 Spindle speed [rpm]: 35 - 6000 Spindle torque [kW]: 37kW Max. torque [Nm/rpm]: 670/525 Tool clamping: HSK-A 100 Tool magazine [pcs.]: 100ks Machine control system: iTNC 530 2x univerzální úhlová hlava 45° Direct outlet head Power supply
Manufacturer ZAYER Model 30 KMU-5000 Year 1999 CNC HEIDENHAIN TNC-430PA Table surface 4,700 x 1,200 mm. Strokes (X/Y/Z) 3,400/1,250/2,000 mm. Shaft Outlet (W Axis) 500 mm. ISO-50 Head Cone Main Motor Power 37 kW 45º Automatic Head INCLUDED Head Rotation 45º Automatic Rotation 0.001º/0.001º Head revolutions 45º 3,000 rpm 45º ISO-50 Head Cone Continuous Twist Head INCLUDED Twist head revolutions 3,000 rpm Twist Head Cone ISO-50 Ram with cane INCLUDED Shank diameter 150 mm. ISO-50 Rod Cone Internal and external cooling head 45º and rod INCLUDED External cooling twist head INCLUDED Semi-automatic head pickup INCLUDED Automatic Loading Tools INCLUDED Loader Positions Htas 60 AITEK Pickup Station for 45º head storage and Twist Head INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel RENISHAW MP 16+SP2/1 Piece Measurement Probe Motors + ...
Zayer 30KCU700AR (2003) with Heidenhain iTNC 530. - x, y, z = 7000, 2000, 1250 - CTS 15 bar - Controlled milling head (position accuracy 0.001) - 60 tools - 37 kW spindle motor - Rapid traverse 20/10 m/min - 4500 rpm - ISO50 - Renishaw RPM60 -Conveyor - Additional milling head (replacement)
Key data: 6000 mm, 2000 mm, 3000 mm
Machine Type: CNC Travelling Column Milling Machine Make ZAYER Type KCU6000 Year of construction 1992 Control type Heidenhain TNC 415 X-way (mm) 6,000 Y-off (mm) 2,000 Z-off (mm) 3,000 Speeds from (rpm) 20 - 1,800 Tool holder BT50 Feed longitudinal (mm/rev) 5 - 5000 mm/min Feed Transverse (mm/U) 5- 5000 mm/min. Vertical feed rate (mm/rev) 5- 5000 mm/min. Rapid traverse 10,000 mm/min. Total power(KW) 34 Length (mm) 11,000 Width (mm) 2,500 Height (mm) 7,000 Weight 31.000 kg Information 'Juaristi MG6' rotary table: 1500 x 1200 mm With coolant pump Cooling system: 2.5 bar Tool cooling: 15 bar
Inv. Num. : 7770 Type: KFU 3000 Producer: Zayer Created: 1990 Parameters: Operating system: HEIDENHAIN TNC 415 B Table length: 3000 mm Table width: 1000 mm Maximum table load: 10000 kg Max. Speed: 3000 1/min Axis X: 2700 mm Axis Y: 1000 mm Axis Z: 1000 mm Machine dimensions: 4000 x 2500 x 2800 mm Weight: 18600 kg Equipment: Staples (approx. 40 pieces) Vises (2 pieces) Angle (2 pieces) Clamping Blocks (2 pieces)
Code 8529 Description CNC Bed milling machine Make Zayer Type 2200 BF 3 Machine nmb 52248 Year 1986 Control Fagor 8020 Table size 2200 x 800 mm Movement table (X) 1830 mm Cross traverse ram (Y) 1016 mm Vertical traverse milling head (Z) 1016 mm Spindle taper ISO 50 Max. Weight on table 4000 kg No. of spindle speeds 18 steps Spindle speeds 28 – 1800 rpm Feeds dir. Progr. X-Y-Z 3 – 5000 mm/min Rapids Longitudinal 5 m/min Cross 5 m/min Vertical 5 m/min Total Weight 10.000 kg Mainmotor 11 kW Power connection 38 KVA Voltage 380 Volt Accessories Milling head Horiz./Vert. with ISO-50 Hydr. tool clamping device Condition Machine is in good condition
Fixed bed milling machine Zayer 2000BF. Table: 2500x700mm. Longitudinal travel: 2000mm. Cross travel: 1000mm. Vertical travel: 1000mm. ISO50. Speeds: 18. (28-1800rpm). Power: 15cv. Weight: 13000Kgs. Equipped with DRO Fagor.
Universal milling machine with automatic movement ram. Table: 1700x700. Longitudinal travel: 1320mm. Cross travel: 1016mm. Vertical travel: 560mm. ISO50. 18 speeds (28-1800rpm) 18,75 Hp. Weight: 6200Kg.
x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4.700 mm y-travel: 1.250 mm z-travel: 1.500 mm control: HEIDENHAIN iTNC 530 clamping table: - surface area: 5.000 x 1.000 mm max. workpiece weight: 10.000 kg T-slot number x size: 7 x 22 Abstand 140 mm Universal Milling Head: _ Swiveling area front/back level: automatisch Indexing: 0,001 x 0,001° stepless Constant Power at 100 % ED: 37 kW Speed range, stepless: 35 - 4.500 min-1 max. torque: 880 Nm tool taper: SK 50 – DIN 69871 internal coolant system feed: durch das Spindelzentrum automatic tool changer ATC: - Tool places: 60 Plätze diameter of tools max.: 125/240 mm workpiece length: 300 mm weight of tools max.: 25 kg feeds: - X-, Y- and Z-axis, stepless: 6 - 15.000 mm/min rapid in X/Y/Z: 25.000 m/min max. feed force X-Y-Z-axis: 10.000 N total power requirement: kW weight of the machine ca.: 35 t dimensions of the machine ca.: 12,7 x 5,6 x 4,2 m Equipment / Accessories:Hea ...
This 3-axis Zayer 30KF 3000 vertical machining center was manufactured in 1997. It offers robust construction and precision for complex machining tasks. Ideal for those seeking reliable performance in a used machine. Contact us for more information.
This 3-axis Zayer KF 4000 was manufactured in 1989. It features a large table of 4,000 Ã 1,000 mm, capable of handling loads up to 10,000 kg. Equipped with a spindle speed of up to 3,000 rpm and a power range of 30â37 kW, it ensures robust machining capabilities. Consider the opportunity to buy this Zayer KF 4000 universal machining centre. Contact us for more information about this machine.
x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm Control: Heidenhain TNC 430 tool taper: ISO 50 spindle turning speed - stepless: 10 - 3000 U/min feed range: 10000 mm/min rapid traverse: 15 m/min main drive motor: 37 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC-control HEIDENHAIN TNC 430 40-station ATC NC-Universal Milling head, automatic positioning (A/B axis 0.001 / 0.001 deg) Chip conveyor Optional (price upon request): CNC rotary table Juaristi 3000 x 3000 mm - Table load 30 to - Longitudinal movement 2000mm - Separate CNC-control FAGOR The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 7000 mm y-travel: 2000 mm z-travel: 1250 mm control: Heidenhain iTNC 530 plate size: 7000 x 1500 mm tool change unit: 60 Pos turning speeds: 35 - 4500 U/min spindle motor: 37 kW rapid traverse: 20 / 10 m/min total power requirement: - kW weight of the machine ca.: - t required space: - m equipped with: - Heidenhain iTNC 530 CNC control - Tool changer for 60 tools (ISO 50) - autom. Milling head (0,001 °) - Spindle cooling 15bar with paper band filter - Chip conveyor - Renishaw RMP 60 - Extra Miling Head (Spare Part) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 10000 mm y-travel: 3000 mm z-travel: 1500 mm Control: Heidenhain TNC 430CA milling head -swivable: 360.000 pos spindle turning speed range: 10 - 3000 U/min Tools changer: 40 pos. feed: 5000 mm/min Rapid Travel X / Y / Z-Achse: 10 / 15 / 15 m/min spindle motor: 37 kW total power requirement: 80 kVA weight of the machine ca.: 40 t dimensions of the machine ca.: m Traveling column milling and boring machine - Control Heidenhain TNC 430CA & HR 410 - autom. Tool changer with 40 places (SK 50) - Huron Universal milling head, automatic Positioning (A-/B-Axis each 0,001°) - Chip conveyor - OPTIONAL: Rotary Table 3000x3000mm - 30t (W-Axes: 2000mm), with independent FAGOR CNC Control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 10000 mm y-travel: 1500 mm z-travel: 3000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m - CNC control Heidenhain TNC 415B - controlled 2-axes NC-milling head 2,5° - coolant device The machine will be sold without the plate field Accessories: ca. 20 pieces tool tapers DIN 2080 with bolts DIN 69872 some spare parts like bevel gears for the milling head and ball screw for X-axis. Technische Daten / technical details: Verfahrweg X längs / X-travel longitudinal 10000 mm Verfahrweg Y quer / Y-travel cross 1500 mm Verfahrweg Z vertikal / Z-travel vertical 3000 mm Werkzeugschaft / spindle taper SK50 Drehzahlbereich (2-stufig) / spindle speed (2-steps) 35-3000 UpM /rpm Vorschub / infeed 6-10000 mm/min Eilgang X,Y,Z / rapid feed X,Y,Z 10, 15, 10 m/min Antriebsleistung Hauptmotor 100%ED / drive capacity main motor 100%ED 37 ...
x-travel: 10000 mm y-travel: 1500 mm z-travel: 2700 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 7.000 mm y-travel: 2.000 mm z-travel: 1.250 mm Control: Heidenhain iTNC 530 Internal cooling system: 15 bar milling head: Automatisch 0,001 spindle turning speed range: 4.500 U/min spindle drive: 37 kW taper ISO: 50 tool change unit: 60 Chip coveyor: Inkl. rapid traverse: 20/10 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m -CTS 15 bars -Controlled milling head (pos. Accuracy 0,001) -60 tools -37 kw spindle motor -rapid 20/10 m min -4500 rpm -iso50 -Renishaw RPM60 -chip conveyor -extra milling head (spare) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1700 mm y-travel: 800 mm z-travel: 890 mm table surface area: 2000 x 630 mm spindle taper: SK 50 spindle turning speed range: 35 - 3000 U/min spindle drive: 26 kW feeds longditudinal/cross/vertical: 6 - 5000 mm/min rapid traverse: 15 m/min table load: max. 6000 kg control: HEIDENHAIN control: TNC 360 total power requirement: 45 kVA weight of the machine ca.: 13 t dimensions of machine L x W x H: 5,2 x 2,78 x 2,95 m Accessories: vertical head swivelling in 2 planes with hydr. tool clamping, various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 12000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 415 taper ISO: 50 P.D.B. spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 10000 mm y-travel: 1100 mm z-travel: 1700 mm Control: Heidenhain type: TNC 155 Tool changer: 30 table surface area: 10000x1000 mm chip conveyor: universal head: table height over floor: 800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 3.400 mm y-travel: 1.250 mm z-travel: 2.000 mm Control: TNC-430PA table-size: 4.700 X 1.200 mm V- travel: 500 tool taper: ISO 50 milling head -swivable: 0.001º/0.001º Grad main drive: 37 kW Chip coveyor: inkl handwheel: HR-410 Tools changer: 60 pos. milling head: Automatic Head 45º weight of the machine ca.: 35 t - Automatic Head 45º INCLUDED - Automatic Head 45º 0.001º/0.001º - Head 45º Max. Speed 3.000 rpm - 45º Head Taper ISO-50 - Twist Head Contiuous INCLUDED - Twist Head Max Speed 3.000 rpm - Twist Head Taper ISO-50 - Ram with Quill - Quill Diameter 150 mm. - Quill Taper ISO-50 - Pick up station AITEK for 45º and Twist Heads - Rotary Table ZEATZ Ø 1200 INCLUDED - RENISHAW MP 16+SP2/1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 22.000 mm y-travel: 1.500 mm z-travel: 3.000 mm Control: SIEMENS 840 D milling head -swivable: 0,001/0,001 Grad milling head: Universalfräskopf 45° Internal cooling system: 20 bar Chip coveyor: ja Tools changer: 30 pos. coolant: 1.100 l Tool taper: DIN 69871A ISO 50 total power requirement: 45 kW weight of the machine ca.: 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /IN ...
x-travel: 6000 mm y-travel: 2000 mm z-travel: 3000 mm Control: heidenhain TNC 415 total power requirement: 34 kW weight of the machine ca.: 31 t dimensions of the machine ca.: 7000 mm m Stocknumber 1110055 Type of machine CNC Floortype milling machine Make ZAYER Type KCU6000 Build in 1992 Type of control Heidenhain TNC 415 X-stroke (mm) 6.000 Y-stroke (mm) 2.000 Z-stroke (mm) 3.000 Speeds (Rpm) 20 - 1.800 Admission in spindlehead BT50 Feeds X (mm/R) 5 - 5000 mm/min Feeds Y (mm/R) 5- 5000 mm/min. Feeds Z (mm/R) 5- 5000 mm/min. Rapid feeds 10.000 mm/min. Total Power (KW) 34 Lenght (mm) 11.000 Width (mm) 2.500 Height (mm) 7.000 Weight 31.000 Kg Additional information Juaristi MG6 turntable: 1500 x 1200 mm Cooling system: 2.5 Bar Tool cooling: 15 Bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 4700 mm y-travel: 1000 mm z-travel: 1000 mm control: HEIDENHAIN TNC355 table-size: 5000x1000 mm T-slots: 7x mm turning speed range: 2800 U/min feed: 6-5000 mm/min rapid traverse: 15000 mm/min spindle motor: 30,00 kW spindle taper: SK 50 Table load: 10.000 kg Main drive: 40 PS weight of the machine ca.: 27,00 t dimensions of the machine ca.: m With HEIDENHAIN TNC 355 control. Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
