6 ELB surface grinding machines used machines

Code 0776 Description Surface grinding machine Make ELB Type SWBD 030 MCNC82 Machine No. 18.346.0383 Manufacturing date 1983 Control MCNC / 82-PC Tablesize 3520 x 600 mm Table grinding size L x B x H 3000 x 600 x 600 mm Magnetical plate size L x B 3000 x 400 mm Speed table movement 0,2 – 6 m/min. Max. distance table – centre grinding wheel 850 mm Speeds vertical 3 – 375 mm/min. Speeds cross 1,2 m/min. Speeds grindingwheel stepless 750 – 1400 omw/min Grindingstone: Ø 600 x Wide:100 x Bore: 200 mm Weight 18.000 kg Motor power 37 kW – 380 Volt Accessoiries Electro table 3000 x 400 mm Grinding unit with water cooling Filtering unit with paperfilter Profile grinding unit Condition Machine is in very good condition

ELB Perfect BD 15 PLC surface grinding machine, grinding area 1500 x 550 mm, grinding wheel 400 x 100 mm, electric perm magnetic clamping plate 1500 x 550 mm, automatic dresser with compensation, paper belt filter, the machine is overhauled, grinding spindle rebeared, guideways are scraped, meets the tolerance of a new machine. We are happy to take over the installation / training on site, as well as the subsequent service

Magnetic table 455 x 170 mm Digital Water tank Pulling device Wet grinding device

ELB Perfect BD 10 750 PLC, Year of construction 2008 Control Siemens STC Grinding area 1000 x 750 mm Grinding wheel 400 x 100 mm Grinding spindle 10 KW Electro Perm Magnetic Clamping Plate 1000 x 750 mm Automatic straight-dressing device with compensation Coolant system with paper belt filter Machine is immediately ready for use CE compliant Installation / on-site training included

Favretto MD 300 Universal Surface Grinding Machine CNC Manufacturer [manufacturer]: Favretto Type [ type]: MD 300 Control unit: DTG Plus / Siemens 840D Baujahr[construction year]: 10/2006 Table size: 3,220 mm Grinding travel length: 3,200 x 900 x 725 mm Magnetic table/plate size [magnetic table/plate size ]: 3,000 x 600 mm Longitudinal table speed: 1–40 m/min Cross table speed: 5 m/min Cross locking mechanism speed: 1–50 m/min Maximum load: 4,000 kg (without magnetic plate) Grinding wheel size: 508 x 203.2 x 100 mm Grinding wheel speed: 1,400 rpm Motor power of grinding mandrel: 22 kW Weight of the machine approx.: 17,500 kg Dimensions[machine size]: 9,400 x 3,550 x 3,000 mm Accessories: Magnetic tabletop [magnetic tabletop] coolant press with paper filter various grinding wheels [various grinding wheels] Documentation We will be happy to answer any furt ...

Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition

ELB Perfect BD 10 750, grinding area 1000 x 750 mm, year of construction 2004, grinding spindle 10 KW, grinding wheel 400 x 100 mm, automatic dresser with compensation, electric perm magnetic clamping plate 1000 x 750 mm, partial enclosure with suction, water tank with paper belt filter, the machine is partially overhauled, geometry according to the standard of new machine, we are happy to take over the installation / training on site, as well as the subsequent service.

ELB SURFACE GRINDER 460x2440mm CNC Dresser

1 used ELB SURFACE GRINDER Model: SWBE 010 NPC-K Grinding area: 1000 X 550 X 400 mm Year of Make: 1988 Grinding wheel:  400 X100 X 127 mm ACCESSORIES Electric straight-line dresser with compensation Electro-Permian Magnetic Clamping Plate 1000 X 400 mm (SAV) Magnetic adhesive force control Universal Paper Belt Filter Grinding wheel with holder

Surface grinding machine, used, Grinding area: 450x200x250mm, with magnetic plate, puller, holders, coolant device, ...

ELB PERFEKT BD10 SPS surface grinding machine was built in 2004 in Germany by ELB-Schliff Werkzeugmaschinen GmbH. The machine is used for precision grinding of workpieces with a maximum weight of 1000 kg. The machining process is carried out fully automatically on a large magnetic plate or directly on the work table. The grinding head, consisting of a spindle and grinding wheel, moves along guide rails to ensure an even and accurate surface finish. The ELB SCHLIFF PERFEKT BD10 SPS magnetic surface grinding machine is also equipped with, among others, a cooling system with a belt paper filter, which cleans the coolant after machining and allows it to be reused in the next process. The total weight of the machine is 6300 kg. Technical specifications of the ELB PERFEKT BD10 SPS grinding machine - magnetic plate dimensions (L x W): 1000 x 750 mm - maximum grinding dimensions (L x W x H) ...

dayligth: 420 mm Magnetic field: 420x200 mm grinding length: . mm weight of the machine ca.: t dimensions of the machine ca.: m Stepless automatic feed for table 3-40 m/min Return feed for table Filter attachment Hydraulic unit Coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Surface grinding machine ELB type SW 3 HA JuwelMasch. No. 51810465 year of construction 1965Grinding area 300 x 150 mmClamping surface 300 x 150 mmElectromagnet 300 x 150 mmDistance spindle center - magnet approx. 350 mmGrinding wheel diameter 175 mmGrinding wheel width max. 25 mmGrinding wheel speed 2800 rpm. Grinding spindle drive 0.75 kWNetz connection 380 volts, 50 Hz.- manual and automatic table - transverse adjustment (0.02 mm per graduation) - manual transverse adjustment via handwheel, travel distance per handwheel revolution, Y -

workpiece diameter: 600 mm workpiece weight: 400 kg workpiece height: 300 mm total power requirement: 35 kW weight of the machine ca.: 4500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

An ELB cycle-controlled surface grinding machine is available. Grinding length: 600mm, grinding width: 375mm, max. workpiece height: 375mm, magnetic clamping plate dimensions X/Y: 1000mm/375mm, table travel: 525mm, table speed: 30m/min, max. table load: 300kg. Machine dimensions X/Y/Z: approx. 2550mm/2050mm/2500mm, weight: approx. 4000kg. Including a coolant unit. st möglich.

Grinding dimensions X/Y/Z: 500mm/300mm/350mm, grinding wheel dimensions X/Y/Z: 300mm/50mm/76.2mm, magnetic table dimensions X/Y: 500mm/200mm, pole pitch: 5mm, machine dimensions X/Y/Z: approx. 3050mm/1600mm/2400mm, weight: approx. 3000kg. Including coolant system, paper band filter, sine table, digital display, and grinding wheel flange. Documentation available. An on-site inspection is possible.

grinding length: 400 / 500 / 600 mm grinding width: 200 / 300 mm workpiece height: 300 / 350 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A surface grinding machine ELB-Schliff with position display is available. Magnetic chuck dimensions X/Y: 900mm/450mm, grinding length: 900mm, grinding width: 450mm. Documentation available. An on-site inspection is possible.

Color: RAL 7035 light grey, RAL 7012 basalt grey, RAL 5012 blue grey, the machine’s inverter is defective. Accessories: electromagnetic clamping plate 400x250mm, with pole pitch 5mm and holding force control, automatic vertical infeed with infeed program and digital display for vertical and cross movement, automatic central lubrication system, wet grinding unit with paper belt filter system for filter paper 460x200mm with filter fineness 0.016–0.025mm, electric wheel dresser with dimensional compensation and operating manual. An on-site inspection is possible.

Table dimensions X/Y: 900mm/350mm, magnet dimensions X/Y: 600mm/350mm, max. workpiece height: 375mm, max. table load: 300kg. Machine dimensions X/Y/Z: 3200mm/2600mm/2400mm, weight: approx. 400kg. Documentation available. An on-site inspection is possible.

grinding length:450 mm grinding width:250 mm workpiece height:280 mm Table area:760 x 250 mm grinding spindle drive:2,5 kW grinding wheel dia. x width:250x 25 mm grinding spindle speed:1430/2900 U/min way of grinding spindle saddle, vertical:400 mm total power requirement:4,5 kW weight of the machine ca.:1,8 t dimensions of the machine ca.:1,8 x 1,4 x 2,0 m Machine equiped with magnetic plate - dresser

grinding length:450 mm grinding width:250 mm workpiece height:280 mm Table area:760 x 250 mm grinding spindle drive:2,5 kW grinding wheel dia. x width:250x 25 mm grinding spindle speed:1430/2900 U/min way of grinding spindle saddle, vertical:400 mm total power requirement:4,5 kW weight of the machine ca.:1,8 t dimensions of the machine ca.:1,8 x 1,4 x 2,0 m Machine equiped with magnetic plate - dresser

Elb 6375 ND Grindingwidth: 375 mm Longitudinal travel X-axis (autom.): 600 mm Cross-travel Y-axis (autom.): 375 mm Travel Z-axis (autom.): 350 mm Dimensions magnetic table : 600 x 350 mm Max dia grindingstone: 300 x 50 x 76.2 mm Spindlespeeds: 2900 rpm Motorpower: 9 kW Tension needed: 400V Weight: 3300 kg ACCESSORIES: Diamant tools Cooling system: yes

Elb SWE 6 VA II Worklenth without magnetic table: 600 mm Grindingwidth: 400 mm Longitudinal travel X-axis (autom.): 600 mm Cross-travel Y-axis (autom.): 400 mm Travel Z-axis (autom.): 450 mm Dimensions of the table: 1100 x 450 mm Dimensions magnetic table : 700 x 200 mm Max dia grindingstone: 300x50x76 mm Spindlespeeds: 1400 x 1800 rpm Motorpower: 5.5 kW, total 13 kW Tension needed: 400V

CONTROLS   CNC controls SIEMENS 840 D WORKING RANGE SURFACE GRINDING   grinding length: 1000 mm   grinding width: 600 mm   vertical travel: 350 mm TABLE (SURFACE GRINDING)   table surface (left-right): 1360 mm   table surface (front-back): 550 mm   workpiece load (max): 1000 kg SPINDLESTOCK GRINDING SPINDLE   spindle revolutions (min): 1000 /min   spindle revolutions (max): 6500 /min GRINDING TOOL   type of grinding tool: wheel   diameter (min): 500 mm   borehole: diameter: 203 mm   width: 100 mm ELECTRICAL SPECIFICATIONS   total power consumption: 91 kW   mains voltage: 400 V   mains frequency: 50 Hz
