Used SMG HZPUX 350/200 - 1500/1300 moulding press in good condition! Main technical data: - Power: 510 ton - Maximum span with castle: 1460 mm - Minimum light with castle: 520 mm - Maximum span without castle: 2160 mm - Minimum light without castle: 1220 mm
SMG DS 315-1500/1300 CNC hydraulic press was manufactured in 1984 in Germany. The machine, consisting of two interconnected stations, is used for pressing metal workpieces in manual, semi-automatic and automatic mode with a pressing force of up to 315 tonnes. All the machine’s machining parameters are set using a CNC control with a full-colour, touchscreen display. The press is equipped with a hydraulic and pneumatic sheet metal feeder, servo drives for feed rollers to set a very precise stroke of up to 0.1 mm, safety cages and workpiece feed and drop control sensors. The SMG 315 T machine underwent a complete overhaul in 2007, during which components such as pumps and safety installations were replaced. Technical data of the SMG DS 315-1500/1300 press - maximum press force: 315 t - working table dimensions (L x W): 1500 x 1300 mm - upper machine point (from the table): 750 mm ...
pressure:160 t throat:450 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:580 mm table surface area:1000 x 1000 mm die cushion capacity:20 t die cushion stroke:300 mm ram surface:700 x 750 mm feed down:400 mm/s feed up:400 mm/s table height over floor:1350 mm die cushion area:Ø 350 mm power capacity:55 + 11 kW weight:19,5 t Dimensions (WxDxH):1,5 x 3,5 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch depth stop:mechanisch
pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:51,0 kW weight:33,0 t dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary
pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:52,0 kW weight:33,0 t Dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary
pressure:250 t distance between columns:930 mm stroke:200 mm Distance table/ram, stroke up:600 mm table surface area:900 x 860 mm die cushion capacity:100 t die cushion stroke:50 mm die cushion area:350 x 400 mm table height over floor:950 mm side window:380 x 380 mm ram surface:850 x 700 mm feed down:400 mm/s feed up:400 mm/s working feed:30 mm/s oil volume:350 l power capacity:45,0 kW weight:11,5 t Dimensions (WxDxH):2,0 x 1,2 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary
Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable
pressure:800 t distance between columns:3010 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:1350 mm table surface area:3000 x 1800 mm table height over floor:500 mm side window:1500 x 1400 mm ram surface:3000 x 1800 mm speed down:300 mm/s oil volume:900 l height over floor:5,4 m height beneath floor:2,1 m power requirement:200,0 kW weight:80,0 t Dimensions (WxDxH):5,2 x 2,6 x 7,5 m ram interlocking:in TDC depth stop:mechanical
pressure:63 t throat:320 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:750 x 600 mm pressure of drawing cushion in table:6,5 t stroke of drawing cushion in table:80 mm die cushion area:240 mm table height over floor:800 mm ram surface:500 x 450 mm capacity of ejector in ram:0,5 t ejector stroke in ram:70 mm speed down:300 mm/s speed up:300 mm/s working speed:50 mm/s oil volume:380 l power requirement:12,0 kW weight:6,5 t dimensions (WxDxH):1,3 x 2,0 x 2,75 m drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical cutting impact cushioning:hydraulic
Pressure:200 t distance between columns:1910 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1900 x 1150 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:300 mm die cushion area:1500 x 950 mm table height over floor:800 mm side window:1000 mm ram surface:1900 x 1100 mm return capacity:36 t speed down:400 mm/s speed up:170 mm/s working speed:30,5 mm/s oil volume:1500 l height over floor:4,85 m height beneath floor:2,6 m power requirement:45,0 kW weight:38,0 t dimensions (WxDxH):3,05 x 2,8 x 5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
pressure: 63 t distance between columns: 680 mm stroke: 150 mm total power requirement: 15 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 3 x 3 x 3 m No. 0214 ydraulic high-speed double-column press SMG DS 63 Clearance between the uprights 680 mm, max. distance between table top and ram 385 mm, Ejector force 15kN, largest ram stroke 150 mm. Working area: Table surface 660 x 460 Drive: 15 kW pressing force 630 kN, retraction force 51 kN The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Pressure total: 1400 ton Stroke: 950 mm Daylight: 2000 mm Table surface area : 3600 x 2500 mm Slide area: 3600 x 2500 mm Die cushion capacity in table: 400 ton Die cushion stroke: 500 mm Die cushion pad area: 3060 x 1860 mm Approach speed: 400 mm / sec Working speed: 40 / 80 mm / sec Return speed: 400 mm / sec Oil volume: 5000 l Required power: 450 kW Weight of machine approx.: 240 ton
pressure: 40 t distance between columns: 600 mm stroke: 150 mm table surface area: 600x410 mm ram surface: 220x130 mm table height: 850 mm weight of the machine ca.: 2,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
SMG 320 cold forming press for sale. Year of build 1981 Model HPU 315-1300/1150 The machine has a crack in the head piece. Drive power: 2 x 55 KW Oil volume of one tank filling 3800 liters Maximum ram force: 3200 KN Drive cylinder: 3 pieces Cylinder 1: 2000 KN Cylinders 2+3: 600 KN each maximum adjustment: 310 mm Find more here - / Contact us at -
pressure: 25 t distance between columns: 580 mm stroke: 150 mm dayligth: 370 mm table surface area: 560x400 mm ram surface: 400x350 mm hole in the table: 80 mm weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1500x500x2500 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
