3 SCHULER eccentric presses used machines

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

Specifications: Capacity 63 tons 2 strokes 105 rpm and 140 rpm large projection 450 mm ! Plunger stroke 8-100 mm Plunger adjustment approx. 70 mm Table , WxD approx. 700 x 780 mm Plunger, W x D approx. 450 x 280 mm

Specifications: Capacity 63 tons Stroke rate 140 h/min Projection 250 mm Plunger stroke 8-100 mm Table , WxD approx. 700 x 480 mm Installation height approx. 400 mm

pressure: 63 t throat: 315 mm stroke: 8-100 mm no. of strokes: 140 Hub/min ram - range of adjustment: 63 mm table surface area: 1200x630 mm ram surface: 800x315 mm hole in the table: Ø 110 mm table height: 820 mm tool hole in ram: Ø 50 mm dayligth: 335 mm total power requirement: 7,5 kW weight of the machine ca.: 5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Press force: 250kN, ram stroke: 8mm-80mm, stroke rate: 180/min, installation height: 310mm, table dimensions X/Y: 550mm/400mm, ram dimensions X/Y: 355mm/220mm, machine dimensions X/Y/Z: approx. 1100mm/1400mm/2300mm, weight: approx. 2500kg. An on-site inspection is possible.

pressure:40 t throat:220 mm stroke:8 / 88 mm table pass:ø- abgesetzt 225/200 mm ram head dimension:400 x 250 mm distance table/ram:228 mm stroke adjustable from - to:30 - 140 mm ram adjustment:63 mm thickness of bolster:80 mm no. of strokes:70 Hub/min total power requirement:5,5 kW weight of the machine ca.:2600 kg dimensions of the machine ca.:1100 x 1300 x 2300 mm Documents:vorhanden

pressure:063 t throat:450 mm stroke:8 - 100 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:720 x 800 mm hole in the table:280/250 mm table height over floor:800 mm passage to the back:290 mm ram surface:450 x 280 mm ram adjustment:63 mm power requirement:7,5 kW weight:4,7 t dimensions (WxDxH):1,3 x 2,0 x 2,65 m clutch:pneumatisch overload protection in ram:mechanisch

pressure:100 t throat:315 mm stroke:30 - 160 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:460 mm table surface area:910 x 680 mm Hole in the table:400 mm table height over floor:800 mm passage to the back:400 mm ram surface:630 x 400 mm ram adjustment:80 mm power requirement:7,5 kW weight:7,5 t dimensions (WxDxH):1,7 x 2,0 x 3,0 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical ram counterbalance:pneumatic

Pressure:080 t throat:280 mm stroke:20 - 120 mm no. of strokes:42 - 125 /min distance table/ram, max. stroke up, adjustment up:510 mm table surface area:700 x 560 mm hole in the table:280 mm table height over floor:800 mm passage to the back:320 mm ram surface:560 x 350 mm ram adjustment:72 mm Weight:5,2 t Dimensions (WxDxH):1,6 x 1,6 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:60 - 180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:560 x 400 mm hole in the table:150 mm table height over floor:800 mm passage to the back:240 mm ram surface:355 x 220 mm ram adjustment:50 mm weight:3,0 t dimensions (WxDxH):1,0 x 1,4 x 2,2 m infinitely variable drive:Stöber overload protection in ram:mechanical NEW electrical controls:Pilz

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:550 x 400 mm hole in the table:60 mm table height over floor:800 mm passage to the back:200 mm ram surface:355 x 220 mm ram adjustment:50 mm power requirement:2,7 kW weight:2,5 t dimensions (WxDxH):1,2 x 1,8 x 2,4 m overload protection in ram:mechanical

pressure:160 t throat:400 mm stroke:30 - 200 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:600 mm table surface area:1000 x 770 mm table height over floor:810 mm hole in the table:360 mm Passage to the back:450 mm ram surface:710 x 450 mm ram adjustment:110 mm power requirement:15,0 kW weight:10,5 t Dimensions (WxDxH):1,7 x 2,0 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:hydraulic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:60 - 160 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 500 mm Hole in the table:250 / 280 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,3 t Dimensions (WxDxH):1,5 x 1,7 x 2,7 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:47 - 140 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 480 mm Hole in the table:280 / 250 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,0 t Dimensions (WxDxH):1,5 x 1,6 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

Schuler PE4s 50/800 High Speed Press Manufacturer: Schuler Type: PE4s 50/800 High-speed press 61/21 600/3 Pressing force: 50 t Projection: 800 mm Stroke rate /min: 125-300 Plunger stroke: 40 mm Kohler unwinding reel 500.1 M We sell a large number of paternosters. The devices are in operation until 30.06.2021. After the purchase, there are also the documents for it From 01.07.21 the devices are ready for collection. Dismantling and transport by the buyer. Location is Hildesheim The dismantling, loading, as well as transport can alternatively be offered by us. In addition to about 50 paternosters, countless other machines are available. After purchase, the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying.

nominal force:100 t stroke:320 mm no. of strokes:35 /min distance between columns:360 / 250 mm Distance table/ram, max. stroke up, adjustment up:500 mm table surface area:320 x 450 mm table height over floor:660 mm ram surface:250 x 280 mm spindle diameter:125 mm power capacity:3,0 kW weight:4,5 t Dimensions (WxDxH):2,0 x 1,6 x 3,1 m

pressure: 63 t throat: 440 mm stroke: 8-100 mm no. of strokes: 65 Hub/min ram - range of adjustment: 63 mm table surface area: 720x750 mm ram surface: 440x280 mm hole in the table: Ø 240 mm table height: 830 mm tool hole in ram: Ø 40 mm weight of the machine ca.: ca. 5,0 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 600 ton Ram stroke: 762 mm Slide adjustment: 406 mm Shut height (stroke down, adjustment up): 1322 mm Free frontal opening L-R: 3700 mm Table surface area : 3350 x 2134 mm Slide area: 3350 x 2134 mm Die cushion capacity in table: 180 ton Die cushion stroke: 305 mm Ejector in ram: 60 ton Ejector stroke in ram: 230 mm Number of strokes: 16 s.p.m. Required power: 90 kW Weight of machine approx.: 185 ton

SCHULER HYDRAP SH 630 - 1.6 x 1.3 (2005) Total weight 74,000 kg Rated force 6,300 kN Max. stroke length 600 mm Mounting height 900 mm Closes quickly 500 mm/s Max. working speed 23 mm/s Min. working speed 51 mm/s Base and tool max. (xH) 2,280 x 1,200 mm Base and tool min. (xH) 1,250 x 600 mm Tool height min. 300 mm Total tool weight max. 2,500 kg Total tool weight max. 5,000 kg Permissible eccentric hydraulic press load left right Permissible eccentric load front rear 490 kNm 250 kNm Installed power 295 kW Rated current 565 A Voltage 400 V Frequency 50 Hz Operating hydraulic pressure 278 bar Total oil volume 5.185 l Oil type HLP 68 in accordance with DIN 51524

sheet width: 5 mm plate thickness: 1000 mm distance between columns: mm total power requirement: 4 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t nominal power: 2000 kN stroke length max.: 1700 mm working feed: 50 mm/sec weight of tools max.: 50000 kg voltage: 400 V table-size: 4.800 x 2.400 mm total power requirement: 99 kW weight of the machine ca.: 113 t dimensions of the machine ca.: m passage width: mm stroke: mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t throat: 200 mm stroke: 8 - 80 mm no. of strokes: 180 Hub/min distance table/ram: 330 mm table surface area: 550 x 400 mm hole in the table: 60 mm table height over floor: 800 mm table height over floor: 800 mm passage to the back: 200 mm ram surface: 355 x 220 mm ram adjustment: 50 mm power capacity: 2,5 kW total power requirement: kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1,2 x 1,8 x 2,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 600 t ram surface: 3600 x 2500 mm stroke: 350 mm Control: Siemens S 7 no. of strokes: 11 - 44 Hub/min table surface area: 3600 x 2500 mm ram adjustment: 400 mm material width: 500 - 1950 mm material thickness: 0,6 - 2,5 mm mm coil weight: 35 t coil external diameter: 900 - 1900 mm coil internal diameter: 610 mm no. of straightening rolls: 13 straightening roll diameter: 50 mm Stack height: 400 mm stations: 2 total power requirement: kW weight of the machine ca.: 390 t dimensions of the machine ca.: m with reel, Rstraight out Unit, (conveyor system Schleicher) and stacking unit(NSM) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sheet thickness iron: 0.75mm, sheet thickness steel: 0.5mm, working width: 780mm, stroke rate: 135/min. An on-site inspection is possible.

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 315 to   nominal work capacity: 38 kNm PRESS TABLE   table surface (left-right): 2000 mm   table surface (front-back): 1200 mm   thickness of bolster plate: 200 mm SLIDE   slide force: 315 to   table surface (left-right): 1995 mm   table surface (front-back): 1100 mm   stroke: 160 mm   stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS)   slide adjustment: 140 mm   stroke rate (min.): 20 /min   stroke rate (max.): 80 /min   main drive power: 90 kW TOO ...
