Model
(Manufacturer: HURCO)
Key data: 1020 mm, 510 mm, 610 mm
Inv. Num. : 6222 Type: BMC 4020 Producer: HURCO Created: 2000 Parameters: Control system: UNIMAX Operating hours: 59,600 h Work table length: 1220 mm Work table width: 510 mm Minimum vertical spindle speed: 80 1/min Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Spindle power: 15 kW Maximum tool weight: 682 kg Max. tool weight: 7 kg Machine height: 2670 mm Machine length: 3350 mm Machine width: 2320 mm Machine weight: 5600 kg Equipment: Tool clamping 2015: Spindle change
Inv. Num. : 6594 Type: VMX 42 SR Producer: Hurco Generated: 2008 Parameters: Control system: Winmax Work table length: 1270 mm Work table width: 610 mm Maximum table load (even): 500 kg Speed: 12000 1/min Travel X-axis: 1066 mm Travel Y-axis: 610 mm Travel Z-axis: 610 mm Cone: SK40 Machine weight: 7550 kg Equipment: C-axis: CNC rotary table B-axis 2016: new spindle
Inv. Num. : 5552 Type: BMC 24 SSM Producer: HURCO Created: 2004 Parameters: Control system: ULTIMAX Work table length: 760 mm Work table width: 400 mm Spindle drive power: 7.5 kW Tool magazine: 24 pieces Speed: 80-8000 1/min Travel X-axis: 610 mm Travel Y-axis: 405 mm Travel Z-axis: 505 mm Cone: SK40 Machine height: 2650 mm Machine length: 2140 mm Machine width: 2100 mm Machine weight: 4200 kg
HURCO VM10 Vertical Machining Centre. Hurco WINMax Control Year of construction: 2010 Manufacturer: Hurco Model: VM10 Control: Hurco WINMAX Spindle Speed: 10000rpm Table size: 762 x 356 mm Tool change capacity: 20 Tool size: DIN40 Traverses XYZ: 560 x 356 x 457mm
turning diameter:336 mm turning length:216 mm weight of the machine ca.:8,3 t Article: CNC multi-axis lathe Manufacturer: Hurco Model: TMX 8MYSi Year of manufacture: 2022 CNC multi-axis lathe Excerpt from manufacturer?s specifications: Working area: Max. turning diameter: 336 mm Max. swing diameter: 560 mm Main spindle specifications: Max. speed: 4,500 rpm Chuck diameter: 210 mm Tie-bar diameter: 64.5 mm Counter-spindle specifications: Max. speed: 6,000 rpm Tool turret with driven tools Bar-Loading Magazine: SAMSYS M3000 (2022 model) HYDAC Cooler The machine can be visited under power. The tool configuration included in the scope of delivery may differ from the images Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
This 3-axis Hurco VMX42t was manufactured in 2007. It features an X-axis travel of 1067 mm, Y-axis travel of 610 mm, and Z-axis travel of 610 mm. The machine includes a table size of 1270 x 610 mm and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the Hurco VMX42t vertical machining centre we have for sale. Contact us for further details.
Travel X/Y/Z: 610mm/406mm/508mm, max. spindle speed: 8000rpm, spindle power: approx. 7.5kW, rapid traverse X/Y: 24m/min, rapid traverse Z: 15m/min, spindle taper: SK40, tool capacity: 24, table dimensions X/Y: 750mm/400mm, max. table load: approx. 350kg, control: Hurco Ultimax 4 Dual Screen. Weight: approx. 4000kg. An on-site inspection is possible.
5-axis machining center, year 2013, CNC WinMax. Used machine in good condition. More info & price on IndustrialBuyer.
This 3-axis Hurco VMX 24 vertical machining centre was manufactured in 2001. It features X, Y, and Z travels of 610 mm each and a tool holder sk40. If you are looking to get high quality milling capabilities consider the Hurco VMX 24 machine we have for sale. Contact us for more information.
This 3-axis Hurco VMX 64 was manufactured in 2006. It features a travel range of 1,625 mm on the X-axis, 860 mm on the Y-axis, and 760 mm on the Z-axis. The machine includes a robust table clamping area of 1,675 x 890 mm and a load capacity of 2,500 kg. If you are looking to get high-quality machining capabilities, consider the Hurco VMX 64 vertical machining centre we have for sale. Contact us for further details.
X-axis: 660mm, y-axis: 350mm, z-axis: 450mm, table clamping surface dimensions: 762x356mm, speed: 10-10,000/min, tool holder: SK 40 DIN 69871, number of tool changer stations: 20, rapid traverse: 28m/min, control: ULTIMAX 4, length: 2000mm, width: 1800mm, height: 2660mm, weight: 2.9t, with documentation, documents, hydraulic diagram and electrical circuit diagram. An on-site inspection is possible.
x-travel: 760 mm y-travel: 510 mm z-travel: 610 mm table surface area: 1.020 x 510 mm control: WINMAX spindle turning speed range: 12.000 U/min spindle drive: 13,5 kW : 24 St. tool adaptor: SK 40 | | internal coolant system feed: 20 bar feed: m/min rapid traverse: 35/35/30 m/min total power requirement: kW weight of the machine ca.: 5,0 t dimensions of the machine ca.: m used vertical machinig centre with 4th axis - 4th axis - Dual toolchanger - internal coolant with filter - spindle oil cooling - electric hand wheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
A Hurco CNC vertical machining center is available. Tool holder: SK50, travel X/Y/Z: 1270mm/660mm/610mm, max. table load: 1500kg, spindle speed: 8000rpm, tool stations: 30, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 4600mm/4600mm/3000mm, weight: approx. 9250kg. Documentation available. An on-site inspection is possible.
Offered is a Hurco CNC vertical machining center including spare parts. Travel X/Y/Z: 1270mm/660mm/610mm, table dimensions X/Y: 1500mm/660mm, max. table load: approx. 1360kg, spindle speed: 10000rpm, spindle taper: SK40, main drive power: approx. 18.5kW, tool pockets: 24, feed X/Y: 30m/min, feed Z: 20m/min, rapid traverse X/Y: 30m/min, rapid traverse Z: 20m/min, spindle operating hours counter: approx. 7676h, control: Hurco Ultimax. Machine dimensions X/Y/Z: approx. 3300mm/2800mm/3000mm, machine weight: approx. 9000kg. Inspection possible by arrangement.
A CNC machining center by Hurco requiring repair is offered, including spindle through-coolant and a chip conveyor. Travels X/Y/Z: 1625mm/860mm/760mm, operating hours: approx. 39025h, max. spindle speed: 8000rpm, tool stations: 40, tool holder: HSK40, cover of the Z-axis is defective. Inspection possible by appointment.
A repair-required Hurco vertical 3-axis machining center is offered, including spindle through-coolant, 3D tool and a chip conveyor. Travels X/Y/Z: 1270mm/660mm/610mm, rapid traverse: 30m/min, feed rate: 15m/min, operating hours: approx. 47646h, max. spindle speed: 12000rpm, tool positions: 40, tool holder: HSK40, control system: Winmax. Bearing damage in the X-axis. A new spindle was installed in 2018. Inspection possible by appointment.
A Hurco CNC vertical machining center is available. Spindle power: 15kW, torque: 238Nm, travel X/Y/Z: 1060mm/510mm/610mm, table dimensions X/Y: 1020mm/610mm, tool holder: SK40, tool stations: 24, spindle speed: 10000rpm. Machine dimensions X/Y/Z: approx. 2800mm/3050mm/2800mm, weight: approx. 5900kg, control system: Ultimax. An on-site inspection is possible.
This 3-axis Hurco VM10i was manufactured in 2016. It features an X-axis travel of 661 mm, Y-axis travel of 407 mm, and Z-axis travel of 508 mm. The machine includes a robust table size of 762 x 406 mm and a maximum table load of 1,500 kg. If you are looking to get high-quality machining capabilities, consider the Hurco VM10i vertical machining centre we have for sale. Contact us for further details.
A vertical CNC machining center is offered. Table diameter: 320mm, travels X/Y/Z: 1270mm/660mm/610mm, spindle speed: 16000rpm, tool holder: SK40, number of axes: 4, rapid traverse: 30000mm/min, max. feed rate: 15240mm/min, rotary table spindle bore: 105mm, rotary table center height: 225mm, control system: WINMAX MIL, overall dimensions X/Y/Z: approx. 4750mm/3200mm/3000mm, weight: approx. 9000kg, operating hours: approx. 61762h. Including a Yaskawa spindle motor and Hurco transport equipment. Documentation available. Inspection possible by appointment. Expected to be available from December 2026.
This 3-axis Hurco VM20i was manufactured in 2014. It features an X-axis travel of 1,016 mm, Y-axis travel of 508 mm, and Z-axis travel of 400 mm. The machine includes a table size of 1,170 x 507 mm and a spindle speed of 12,000 rpm. If you are looking to get high-quality machining capabilities, consider the Hurco VM20i vertical machining centre we have for sale. Contact us for further details.
This 3-axis Hurco VMX24 vertical machining centre was manufactured in 2004. It features an impressive X-axis travel of 610 mm and Y-axis travel of 508 mm, with a maximum spindle speed of 10,000 RPM. The machine includes advanced control options such as synchronous tapping and advanced velocity control. If you are looking to get high-quality machining capabilities, consider the Hurco VMX24 vertical machining centre we have for sale. Contact us for further details.
This 3-axis Hurco VMX 24i was manufactured in 2015. It features an X-axis travel of 610 mm, Y-axis travel of 508 mm, and Z-axis travel of 610 mm. The machine includes a robust table size of 760 x 508 mm and a maximum table load of 1,500 kg. If you are looking to get high-quality machining capabilities, consider the Hurco VMX 24i vertical machining centre we have for sale. Contact us for further details.
surface area: 1168 x 508 mm max. table load: 1800 kg travel -x axis: 1016 mm travel -y axis: 508 mm travel -z axis: 508 mm spindle taper: SK40 spindle speed: 10000 U/min spindle capacity: 15 kW spindle torque max.: 99 Nm rapid traverse y/x/z axis: 28 m/min control: HURCO MAX5 total power requirement: 20 kW weight of the machine ca.: 4,15 t dimensions of the machine ca.: 3,7 x 3,3 x 2,5 m The machine is like new !, only 61 spindle hours Tool changer: - Magazine capacity: 24 positions - Max. tool diameter: 80 mm - Max. tool length: 360 mm - Max. tool weight: 7 kg Accessories: documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
surface area: 1321 x 610 mm max. table load: 1800 kg travel -x axis: 1270 mm travel -y axis: 508 mm travel -z axis: 508 mm spindle cone: SK40 number of spindle speeds: 12000 U/min spindle capacity: 15 kW spindle torque max.: 82 Nm rapid traverse y/x/z axis: 28 m/min control: HURCO MAX5 total power requirement: 21 kW weight of the machine ca.: 4,25 t dimensions of the machine ca.: 4,1 x 3,35 x 2,6 m the machine is like new!, only 136 spindle hours Tool changer: - Magazine capacity: 24 positions - Max. tool diameter: 80 mm - Max. tool length: 250 mm - Max. tool weight: 7 kg Accessories: documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
X-axis: 1600mm, y-axis: 900mm, z-axis: 760mm, connected load: 38kVA, control: Ultimax, operating hours: approx. 50,000h, with CTS (coolant through spindle), Knoll AE 1058 coolant filtration and processing system. An on-site inspection is possible.
Offered is a vertical three-axis machining center. Travels X/Y/Z: 1524mm/660mm/610mm, table: 1675mm x 660mm, spindle speed: 12000rpm, tool holder: SK40, tool changer: 24 positions, spindle hours: 1937h (spindle replaced 10/2019), chip disposal: scraper conveyor, control system: WinMax. Equipped with 3D probe Renishaw, scraper chip conveyor, coolant system, spindle cooler, coolant spray gun, chip splash protection enclosure, flushing system for chip removal, electronic handwheel, rigid tapping, DXF software, cooling air through spindle switchable. Weight: approx. 8400kg, overall dimensions X/Y/Z: approx. 4650mm/3470mm/3030mm. Inspection possible by arrangement.
Number of axes: 3, connected load: 30kVA, control: Hurco Ultimax 4, weight: approx. 10.5t, equipment: chip conveyor, full enclosure cabin, electronic handwheel/control panel, coolant system, tool magazine. The machine should be overhauled, electronic components such as the mainboard and hard drive have been replaced repeatedly. An on-site inspection is possible.
This 3-axis Hurco VMX 42i was manufactured in 2018 and features X, Y, and Z travels of 1067 mm, 610 mm, and 610 mm respectively. It boasts a maximum spindle speed of 12000 rpm. If you are looking to get high-quality milling capabilities consider the Hurco VMX 42i machine we have for sale. Contact us for more information about this machine.
This 3-axis Hurco VMX 42i was manufactured in 2013 and features X-Travel of 1067 mm, Y-Travel of 610 mm, and Z-Travel of 610 mm, with a tool holder SK40. If you are looking to get high quality milling capabilities consider the Hurco VMX 42i machine we have for sale. Contact us for more information.
vertical machining center, year 2004, CNC Ultimax. Used machine in good condition. More info & price on IndustrialBuyer.
