Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...
Control Siemens Bar passage 32 mm 2 x 12-speed revolver with attached revolver Competition. Main / sub-spindle Y-axis turret top Parts pick-up device Conveyor IRCO Bar Loading Magazine
Specifications: Main spindle: Max. turning diameter: 33 mm Max. speed: 8000 1/min Drive power: 5.5 kW Drive power at 60% ED: 7.5 kW Slide 1: Carriage path Z1: 320 mm Slide path X1: 50 mm Carriage path Y1: 255 mm Rapid traverse speed: 30 m/min Ball screw diameter: 25 mm Tool holder slide 1: Number of tools fixed with tool shank 16 x 16: 5 pieces Slide 2: Slide path X2: 165 mm Carriage path Z2: 200 mm Rapid traverse speed: 30 m/min Ball screw diameter: 30 mm Tool holder slide 2: Number of stations for turret with integrated spindle: 8 pieces Number of axially driven tools (integrated): 8 pieces Coolant pan, approx.: 400l Coolant pump, max. capacity: 80 l/min Dimensions (LxWxH), approx.: 2460 x 1510 x 1750 mm Equipment: - CNC control Fanuc iT - Workpiece unloading system - IEMCA bar loading magazine - 5-item tool carrier plate for carriage 1 - Elec ...
Number of axes : 6 - Number of spindles : 2 MAIN COPDLE - Max. rod diameter : 25 [mm] - Travel : 160 [mm] - Spindle speed : 8000 [rpm] - Minimum C-axis resolution : 0.0001 [degrees] SUB-SPINDLE - Max. rod diameter : 25 [mm] - Number of turrets : 1 UPPER TURRET HEAD - Number of positions : 7 - Number of motorized positions : 7 - Travel X : 100 [mm] - Travel Z : 270 [mm] - Driven tools speed : 6000 [rpm] BUSHING HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Driven tools speed : 6000 [rpm] - Travel X/Y : 220/30 [mm] COUNTER MACHINING - Number of positions : 3 ELECTRICAL SUPPLY - Supply voltage : 400 [V] Accessories - Control : Fanuc 18 iT - Interface : RS232 / PCMCIA - Driven guide bush - Parts removal - Coolant tank - Hydraulic Bar Loading Magazine Brand/Type : - FMB Turbo 3-26
Key data: 500 mm, 450 mm, 6000 1/min
1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...
General: Year of construction 2006 Management Heidenhain plus IT Travel X 150 mm Z 650 mm Y 80 mm Program duration 10,600 h Spindle: Spindle speed 5,000 rpm Spindle bore 65 mm Turning diameter over face slide 375 mm Turning length 635 mm Revolver: Tool holder VDI30 Number of stations 12-fold with AGW Dimensions and weight: Dimensions 5,000 mm x 2,500 mm x 2,800 mm Weight approx. 5,800 kg
GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...
Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.
Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.
Control Siemens ... Sinumerik 840 D Turning diameter ... 365mm Rotation length ... 450mm Inclined bed Spindle bore ... 52mm Tool turret ... 12/6 Spindle speed ... 0-6000/min. Main engine power ... 12/16kW Axis C ... 360° Max. rod diameter ... 60mm L x W x H ... 4000 x 1640 x 1730mm Machine weight ... 3500kg The machine is in good condition, possible to test under electricity.
used
Turning diameter 80 mm Bar diameter 20 mm Spindle speed 10000 rpm X1, Y1, Z1, X2,Z2 axes Controller Fanuc FANUC 160iB LNS barfeeder
Key data: 320 mm, 750 mm
Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 5 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation
CNC lathe GILDEMEISTER CTX ALPHA 300 with bar feeder and parts pick-up device Built in 2010 in good condition. Duty Cycle: 22930 Hours: 7326 Control Heidenhain CNC-Pilot 640 Circulation over bed: 380 mm Circulation via face slide: 290 mm Spindle bore: 73 mm Flat travel ( X ) : 190 mm Longitudinal travel ( Z ) : 335 mm Speed max. 6000 rpm C-axis 360° Number of driven tool stations 12 pos. Tool holder VDI 30 Accessories: 3 jaw chuck hydraulic 170 mm Conveyor Coolant system Hydraulic hollow clamping device Tool drive C-axis Parts pick-up device Bar Feeder Irco RBK10012 Tailstock
Key data: 205 mm, 650 mm
For sale: Gildemeister CNC lathe type Sprint 65 Linear equipped with a Fanuc 310I control. This CNC lathe is equipped with 2 equal spindles with a bar passage of 65 mm. The machine also has three turrets with 12 positions where you can place driven holders in any position! The upper turret is equipped with a Y-axis with a displacement of 80 mm ( (+50, - 30 mm). The turning diameter is 205 mm. The maximum turning length is 650 mm. The movement X1, X2, X3 is 165mm, the Z1 axis movement is 220mm, the Z2 axis movement is 150mm, and the Z3 axis movement is 768mm. The W2 axis movement is 690 mm and the maximum rapid traverses are 30 meters/min. The maximum speed of both spindles is a speed of 5,000 rpm and both spindles have a full C-axis. The tool holder holder on all turrets is VDI-30. The machine is also equipped with a hinged belt chip conveyor with right ejection and the machine has an Ir ...
Multi-spindle lathe (8 spindles) max. rod diameter 16 mm Guide tubes 4,000 mm Conveyor
4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5 threading device 1x threading spindle pick-up spindle broaching device set of cams set of collets bar-loader Cucchi Giovanni (YOM 2004)
Note: We have 6 pieces of this machine in stock! Manufacturer: Gildemeister Type: GS 36 – 6 A/C Machine no.: 7.0176 Year of construction: 1987 Weight: 11t General / technical data: Portal-6spindle automatic lathe with measuring device and automatic feeding Spindle dividing circuit: 300mm Number of longitudinal slides: 6 Number of cross slides: 2 gr. cross slide stroke: 60mm gr. longitudinal slide stroke: 125mm Spindle speeds: Infinitely variable 562 – 3373 rpm Main time range: Stepless 1.95 – 78 sec. Low time range: 0.79 – 2.13 sec. Drive power: DC motor spindles 20kW; Feed rates 8kW Installation area: approx. 1720 x 4700mm Remark: The machine cannot be converted for bar work. Equipment: – 1 creep gear drive for set-up operation – 1 automatic central lubrication device – 1 coolant device with lines and pu ...
Year built 2004 OTHER TECHNICAL DATA POWER OF ROTATING TOOLS 4 Kw MACHINE EQUIPMENT Tool holder set supplied DIMENSIONS AND WEIGHT Length 3000 mm Width 2500 mm Height 2010 mm Weight 6700 Kg
Turning diameter 320 mm Turning length 450 mm Control HEIDENHAIN Circulation diameter over slide 260 mm Travel - x 160 mm Travel - z 450 mm Speed range - main spindle 5,000 rpm Drive power - main spindle 11 / 7.5 kW Max Torque 76 / 112 Nm Turret head (x-fold) 12 pos
Guildmaster CTX 210 2005 Turning diameter: 290mm Turning length: 300mm Orbital diameter over bed: 380mm Main spindle Speed range: 20-6000 min/-1 Max Torque: 79/72Nm max. feed diameter: 165mm Spindle diameter in front bearing: 90mm Rod diameter: max. 45mm C-axis: 0.04° Holding moment: C:112Nm Tool turret: Number of powered tools: 12 pos. Shank diameter: 30mm Speed range: max. 5000 rpm Clamping diameter driven tools: max. 16mm Travel X-axis: 160mm Z-axis: 305mm Riding pole travel: 370mm Feeds: Rapid response: X 20 m/min Rapid response: Z 30 m/min Rapid response: C 100 m/min
CNC Lathe Gildemeister CTX 200 Series 2 Immediately free from location: CNC Lathe Gildemeister Type CTX 200 Series 2 Built in 2001 Operating hours 39,000 CNC Control Heidenhain 4290 TP Turning diameter 210 mm Turning length 305 mm Reiststock revolver 12 driven tools Conveyor Bar loading magazine Max travel plan 160 mm Max travel length 350 mm Spindle speeds up to 5000 rpm 2 simultaneous axes with C axis 1 controlled spindle 12 driven tools Collet pliers with hydr. Hollow clamping device up to 43 mm Workpiece pick-up device up to 56 mm very many tools
CNC slot machine Gildemeister GLD 25 with counter spindle Technical data: Manufacturer: Gildemeister Type: GLD 25 Built: 1999 Control: FANUC Series O-T Main spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (Z-axis): 160 mm Counter spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (C-axis): 265 mm - Rapid speed C-axis 15 m/min Sled: - Slide: X= 30 mm, Y= 220 mm - Rapid x-axis 10 m/min - Rapid y-axis 15 m/min - Number of WZ on the sled: 5 + 3 (driven) - Speed WZ (driven) : 6,000 rpm Accessories: - Chip conveyor -Bar loader: IEMCA MINI BOSS 325/32 Dimensions LxWxH: - Machine with chip conveyor 3150 x 1100 x 1700 mm - Bar loader 3900 x 800 x 1400 mm Weight: - Machine: approx.2000 Kg - Bar loader: approx. 1000 kg. - Total weight: approx. 3,000 kg
Gildemeister Multispindle Slot machine 6- Spindler Type: AS 25-6 Pick-up device back-valued processing pneumatic stop Balluff cam switch IEMCA PRA Bar loader Oil mist separator (electrostat.) Conveyor Machine has been retrofitted in the past
Gildemeister 6-spindle rotary machine, curve controlled max. rod passage: 32.0 mm for rods up to 3.30 m - incl. rod guide, - Steel processing, run with cutting oel - easily equipped with tools Sowiabeb - 1 set of clamping and feed pliers - Alternating wheels (on machine) - 1 set of curves for cross slides - 1 set of curves for main slide
Gildemeister 6 Spindle Lathe AS 32-6 - Spindle stop set-up - Pneum pick-up device. - Zubehoer at an extra cost - Cross hole drilling - Thread cutting gears - Thread cutting device - wahlw. Fraeseinrichtung Querschl. - Spaenefoerderer
Gildemeister 6-spindle rotary machine, curve controlled max. rod passage: 32.0 mm for rods up to 3.30 m - incl. rod guide, - Steel processing, run with cutting oel - easily equipped with tools Cmvlgfoyc - 1 set of clamping and feed pliers - Alternating wheels (on machine) - 1 set of curves for cross slides - 1 set of curves for main slide
Gildemeister Twin 32 YYear of manuf. : 2007 Control : Siemens 840 D Turning diam. : 100 mmTurning length : 580 mm____________Description:In General:Year of manufacture:2007Control system:Siemens 840 DTurning diameter:100 mmTurning length:approx. 580 mmBar capacity:32 mmMain spindle:Technology:Motorised spindleSpeed:8,000 rpmTorque max.:100 NmPower max.:26 kWC-axis:0.001°Bar capacity:32 mmClamping cylinder:Hollow clamping cylinderChuck:Hainbuch SpanntopSub spindle:Technology:Motorised spindleSpeed:8,000 rpmMax. torque:100 Nm.Max. power:26 kWC-axis:0.001°X-axis:145 mmZ-axis:380 mmClamping cylinder:Partial hollow clamping cylinderChuck:Hainbuch SpanntopTool carrier I (X/Y/Z):Technology:Tool turretNumber of stations:12 unitsTool holder:VDI 25Tool drive:6,000 rpmX-axis:220 mmY-axis:60 (+/- 30) mmZ-axis:320 mmTool carrier II (X/Z):Technology:Tool turret:Number of stations. 12 units ...
Gildemeister Twin 65 Y - RG2Year of manuf. : 2007 Control : Siemens 840 D Turning diam. : 250 mmTurning length : 650 mm____________Description:In General:Year of construction:2007Control:Siemens 840 DBar capacity:65 mmTurning diameter:350 mmTurning length:650 mmMain spindle:Technology:Motor spindleSpeed:5,000 rpmPower max.:35 kWTorque max.:370 NmC-axis:0.001Bar capacity:65 mmChuck:Hainbuch Spanntop size 65Clamping cylinder:Hollow clamping cylinderSub spindle:Technology:Motor spindleSpeed:5,000 rpmPower:26 kWTorque:290 NmC-axis:0.001Chuck:Hainbuch Spanntop size 65Clamping cylinder:Partial hollow clamping cylinderZ-axis:670 mmX-axis:175 mmTool carrier i (X/Y/Z):Technology:Tool turret, 12 stationsTool holder:VDI 30Tool drive:4,000 rpm, 11 kW, 28 NmX-axis:300Y-axis:80 mm ( +/- 40 mm)Z-axis:650 mmTool carrier II (X/Z):Technology:Tool turret, 12 stationsTool holder:VDI 30Tool drive:4,000 ...
