ENGEL es used machines

Four Engel injection molding machines are available. 1) Engel ES 750/150 HL, year of manufacture: 2006, core pulls: 2, screw diameter: 55mm, shot volume: 511cm³, injection pressure: 1616bar/2052bar, nozzle stroke: 350mm, nozzle contact force: 67kN, clamping force: 1500kN, opening stroke: 606mm, ejector force: 60kN, ejector stroke: 150mm, min. mold installation height: 294mm, platen dimensions X/Y: 750mm/520mm, weight: approx. 9500kg, control system: CC100, operating hours: approx. 79000h. Including Engel HLi automation robot. 2) Engel ES 80/30 HL, year of manufacture: 1995, core pulls: 2, screw diameter: 22mm, shot volume: 38cm³, injection pressure: 1500bar/2050bar, nozzle stroke: 200mm, nozzle contact force: 28kN, clamping force: 300kN, opening stroke: 330mm, ejector force: 24kN, ejector stroke: 70mm, min. mold installation height: 110mm, platen dimensions X/Y: 550mm/380mm, weight: ap ...

A total of six old injection molding machines with various accessories from Arburg and Engel are available. 1) Engel ES80/35, year of manufacture: 1992, clamping force: 350kN, injection pressure: 1500bar, injection weight: 35g/hp, screw diameter: 22mm, centering bore: 110mm, mold opening stroke: 330mm, control: defective. 2) Arburg 305 ECO 700-230, year of manufacture: 1989, clamping force: 700kN, screw diameter: 40mm, centering bore: 125mm, mold height min./max.: 190mm/420mm, tie bar distance X/Y: 305mm/135mm, mold opening stroke: 250mm, control: defective. 3) Arburg 305-210-700, year of manufacture: 1982, clamping force: 700kN, injection pressure: 1500bar, injection weight: 117g/hp, screw diameter: 35mm, centering bore: 125mm, mould height min./max.: 200mm/400mm, tie bar distance: 305mm. 4) Arburg 221-75-350, year of construction: 1992, clamping force: 350kN, injection pressure: 1500ba ...

Key data: 2000 kN, 352 g/PS, 50 mm

1.0 St. gebr. Two-component injection molding machine with robot Manufacturer: ENGEL Type: ES650H/200W-200HL-2F Year of Make: 2000 Clamping force: 200 tons Tiebar spacing sparless Min. installation height: 450 mm Opening travel: 700 mm Screws DN 1: 50 mm Max. displacement: 392 cm³ Moulded part weight in hp: 352 g Screw DN 2: 25 mm Max. displacement: 69 cm³ Moulded part weight in hp: 60 g Control: CC200 Technical equipment: -Engel robot, type: ERC23/1-E -4 core slides -Turntable control

Key data: 2000 kN, 216 g/PS, 40 mm

1.0 St. gebr. Two-component injection molding machine with robot Manufacturer: ENGEL Type: ES650H/200W-200HL-2F Year of Make: 2001 Clamping force: 200 tons Tiebar spacing sparless Min. installation height: 550 mm Opening travel: 700 mm Screws DN 1: 40 mm Max. displacement: 251 cm³ Moulded part weight in hp: 216 g Screw DN 2: 25 mm Max. displacement: 69 cm³ Moulded part weight in hp: 60 g Control: CC200 Technical equipment: -Engel robot, type: ERC23/1-E -4 core slides -Turntable control

Key data: 2000 kN, 216 g/PS, 40 mm

1.0 St. gebr. Two-component injection molding machine with robot Manufacturer: ENGEL Type: ES650H/200W-200HL-2F Year of Make: 2004 Clamping force: 200 tons Tiebar spacing sparless Min. installation height: 500 mm Opening travel: 750 mm Screws DN 1: 40 mm Max. displacement: 251 cm³ Moulded part weight in hp: 216 g Screw DN 2: 25 mm Max. displacement: 69 cm³ Moulded part weight in hp: 60 g Control: CC200 Technical equipment: -Engel robot, type: ERC23/1-E -4 core slides -Turntable control

This 3-axis Engel ES650H/200W-200HL-2F was manufactured in 2001. It features a clamping force of 2000 kN, a mold opening stroke of 700 mm, and a tie-bar distance of 920 x 750 mm. Equipped with dual injection units, screw diameters of 40 mm and 25 mm, and a rotary table control. Consider the opportunity to buy this Engel ES650H/200W-200HL-2F hydraulic injection moulding machine. Contact us for more information about this machine.

This 3-axis Engel ES650H/200W-200HL-2F was manufactured in 2000. It features a clamping force of 2000 kN, a tie-bar distance of 920 × 750 mm, and a screw diameter of 50 mm. Equipped with dual injection units, hydraulic locking system, and a rotary table control, it ensures precise and efficient operation. If you are looking to get high-quality injection molding capabilities, consider the Engel ES650H/200W-200HL-2F machine we have for sale. Contact us for more information.

Make: Engel Type: Vertical Rubber Injection Model: ES 280V/40VT-ELAST Serial number: 41938, Year of manufacture: 2000 Clamping force 400kN Injection volume 280cm3 Platen size: 860x400mm In good condition.

Screw cylinder complete with screw, cylinder head and closure nozzle for ENGEL injection unit size ES3550

Engel ES200/45VTHL-PRO-ELAST (2002) Clamping force: 45 t Type: Vertical Drive: Hydraulic

Key data: 2500 , 60

ENGEL 250T injection molding machine Reference : ES1800/250HL Clamping force : 250T Year : 1999 Working hours : 73 655 h Screw diameter : 60 mm Injectable volume : 763 cm3 Injection pressure : 1969 bars Platen dimensions : 1150 x 900 mm Mold thickness (min/max) : 350 mm x 850 mm Dimensions : 6,92 m x 2,08 m x 2,14 m + with 1 SEPRO robot

This Engel ES650H/200W-200HL-2F was manufactured in 2004. It features a clamping force of 2000 kN and platen dimensions of 920 x 760 mm. The machine includes a two-component system with screw diameters of 40 mm and 25 mm, and a robot system ERC 23/1-E for enhanced automation. Ideal for precision in hydraulic injection moulding. Contact us for more information about this machine.

Chassis, electric motor, DC motor, traction motor, drive motor, steering motor -Manufacturer: Engel, steering motor from Jungheinrich ESE 320 G 20-240.54 electric stacker -Type: GNM 5460-G18.5-MIR1 Ser. H -Motor: 24V/240W -Dimensions: 135/130/H365 mm -Weight: 8 kg

Hydro motor for screw cylinders Injection unit size ES3550 Hägglunds Drives type CA50 20 2 0 0 N 004

Key data: 500 , 30

Screw diameter; 30 mm Injectable volume: 99 cm3 Injection pressure: 1450 bar Trays dimensions: 920 x 400 mm Minimum mould thickness: 190 mm max: 520 mm Opening stroke: 330 mm Cores: 3

Key data: 5500 , 80

Screw diameter; 30 mm Injectable volume: 99 cm3 Injection pressure: 1450 bar Trays dimensions: 920 x 400 mm Minimum mould thickness: 190 mm max: 520 mm Opening stroke: 330 mm Cores: 3

Key data: 450 kN, 80 g/PS, 30 mm

Year of Make: 2001 Clamping force: 45 tons. shot volume: 99 cm³ shot weight: 80 gr./PS Screw diameter: 30 mm good condition

screw size:60 mm closing pressure:3500 kN weight of the machine ca.:25,5 t

ENGEL INSERT 60H/30 SHUTTLE injection moulding machine was manufactured in 2016 in Austria. A specialised machine with a small footprint, is used for, among others, the overmoulding of inserts and the joining of various materials such as glass, metal and electronics. Thanks to the electric control of the injection unit and the ‘pressure locking’ system for the injection cylinders, the injection moulding machine guarantees high repeatability and excellent quality of inserts. The ENGEL INSERT 30 injection moulding machine allows you to set the speed and clamping force to prevent damage to the mould. Once both mould halves are closed and a high closing force is generated, the injection unit pushes the nozzle against the injection sleeve of the mould and produces an adjustable clamping force. At the end of the cycle, a very powerful screw with a diameter of 18 mm injects the melt unde ...

ENGEL ES 1350/350 HL injection moulding machine was built in 1995 in Austria by ENGEL AUSTRIA GmbH. The machine, which is designed for the economical production of plastic parts, is distinguished by the use of many components with excellent technical parameters. These parts are produced using the reliable injection moulding method, which involves feeding plasticised plastic into a mould and then clamping it with high press force. A precision mould clamping system, operating at a maximum force of 350 tonnes, guarantees high repeatability and quality of the manufactured parts. Once the production process is complete, the robot automatically transfers the finished products from the workspace to a conveyor belt. The ES 1350/350 HL injection moulding machine weighs 5000 kg. Technical specifications of the ENGEL ES 1350/350 HL injection moulding machine - CNC controller: ENGEL - maximum m ...

ENGEL INSERT 200H/50 injection moulding machine was manufactured in 2007 in Austria. The machine with its small size and large capabilities is used for e.g. overmoulding of inserts and the joining of various materials such as glass, metal and electronics. Thanks to the combination of a clamping force of 50 tonnes and high-quality components, the injection moulding machine guarantees excellent quality of inserts and high repeatability. The machine’s sturdy, solidly built construction features a convenient and easy-to-use ENGEL CC 200 CNC controller for entering all possible process parameters, such as mould clamping force and speed. Once the parameters have been entered, the two halves of the mould are precisely closed, after which the vertical injection moulding machine ENGEL generates a high clamping force. The mould cavity is carefully filled with plastic under high pressure using ...

A total of four Engel injection molding machines are available. 1) Engel ES 80/25 HL-V, year of manufacture: 1999, the machine is a defective spare parts carrier. 2) Engel ES 80/25 HL-V, year of manufacture: 2001. 3) Engel VC 200/45 Tech, year of manufacture: 2004. 4) Engel e-Motion 200/55, year of manufacture: 2005. Documentation available. On-site inspection is possible. Individual sale possible.

Key data: 1100 kN

Engel Victory 330/110 Tech / Production line with the Engel ER-HLI 41 robot and conveyor belt / machine in very good technical condition Year of Make: 2004 Injection unit: Screw diameter: 40 mm Injection weight: 190 g Spray pressure: 1670 bar Dosing volume: 201 cc Clamping unit: Clamping force: 110 t Spar spacing: 0x0 mm Size of the clamping plates: 790x680 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 100 Additional equipment: Production line with integrated Engel ER-HLI 41 robot and conveyor belt Tie-bar-less machine Hydraulic core pull x 1 Hardened injection unit - Bimetal Machine has been serviced by the authorized service Engel Machine with original protective housing for robot and conveyor belt Dimensions: Weight: 7400 kg Length/Width/Height: 5.10x1.50x2.10 m Drive: Pumps/motor: 18.5 kW Heating capacity: 9.2 kW Total power: 27.7 k ...

Key data: 2200 kN

Engel Victory 1050/220 Tech Ecodrive with the Engel Viper 20 robot / hybrid machine Year of Make: 2011 Injection unit: Screw diameter: 55 mm Injection weight: approx. 480 g Spray pressure: 2053 bar Dosing volume: 511 ccm Clamping unit: Clamping force: 220 t Spar spacing: 0x0 mm Size of the clamping plates: 880x830 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - touch screen Additional equipment: Production line with the Engel Viper 20 robot Machine in very good technical condition Operating hours: 38,188 h in automatic mode Tie-bar-less, hybrid machine: energy-saving and very quiet Air valve x 4 on the side of the fixed clamping plate Hydraulic core pull x 2 on the side of the fixed clamping plate Hydraulic core pull x 2 on the side of the movable clamping plate Control with hot runners x 12 Injection unit is wear-resistant and resistant to ...

Engel Victory 1050/220 Tech Ecodrive with the Engel Viper 20 robot / hybrid machine Year of Make: 2011 Injection unit: Screw diameter: 50 mm Spraying weight: approx. 395 g Spray pressure: 2332 bar Dosing volume: 422 cc Clamping unit : Clamping force: 220 t Spar spacing: 0x0 mm Size of the clamping plates: 880x830 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - Touchscreen Additional equipment: Production line with the Engel Viper 20 robot Machine in very good technical condition Operating hours: 32,609 h in automatic mode Tie-bar-less, hybrid machine: energy-saving and very quiet Air valve x 4 on the side of the fixed clamping plate Hydraulic core pull x 2 on the side of the fixed clamping plate Hydraulic core pull x 2 on the side of the movable clamping plate Control with hot runners x 12 Injection unit is wear-resistant and resistant t ...
