presses: flexo and rotogravure used for sale

2016 Nilpeter MO4 8 Units 6 Flexo 1 Screen printing + 1 Flexo varnishing • 6 offset printing units • 1 unit flexo printing /varnishing unit • 1 Screen printing unit 8 Units for offset printing, screen printing, and flexo printing Units are interchangeable Manufacturer: Nilpeter – Denmark Type: MO4 Year of Production: 2016 Max web width: 430 mm Max. printing width: 420 mm • Interchangeable Offset / Interchangeable Flexo • Automatic Register Control • Unwinder • Rewinder • 6 offset printing units • 1 Screen printing units • 1 Flexo printing unit • Inspection Camera with detection of faulty labels Tooling: 15 Z175 plate and blanket cylinders 10 Z184 plate and blanket cylinders 15 Z194 plate and blanket cylinders 3 Magnetic cylinders (Z175 / Z 184 / Z194) 3 Flexo plate cylinders 2 continuous flexo varnish cylinders 2 Anilo ...

Size: Max: 1.700 x 1.150 mm min: 520 x 600 mmEquipments:Bottom PrintingMin. Sheet Size 520 x 600 mmN° 4 Flexo-Printing UnitsElectric Running RegisterMax. Speed 9.000 Sheets per HourAutomatic StackerVacuum Dust CleanerMax. Sheet Size 1.700 x 1.150 mmSide track printing UnitsWith Ceramic Rolls & Chamber Doctor BladeVacuum Feeder

Reference ID PP-39271 Category Flexo Printer Manufacturer Martin Model 1224 Year Built 1992 Color 2 Impression- Working Hours - Speed-- Max. Size 1200x2400 mm Min. Size 285x1240 mm Condition Good Location Europe Availability October 2024 Machine Description 2 colors flexo+slotter+folder mechanically retrofitted in August 2020. and emmepi strapping machine from 2018. Minimum width: 285mm Maxi width: 1240mm Minimum flow: 500mm Maximum flow: 2350mm

Number of color units: 8, max. material width: 900mm, max. printing width: 850mm, speed: 200m/min.

Reference ID PP-38367 Category Rotary Die Cutter (RDC) Manufacturer Martin Model DRO 1628 Year Built 1995 Color 4 Impression- Working Hours - Speed-- Max. Size Boy 2800 x 1600 mm Min. Size - Condition Good Location Europe Availability August 2024 Machine Description Alliance prefeeder 4 colors Rotary Slotter Martin palettizer

Compressed air connection: 6bar, connected load: 6.6kVA, weight: 450kg, with magnetic cylinder, chrome anilox roller, UV dryer, blower, suction unit and cliché bending device.

4 colors, Possible pressure variation = 4+0 Film width max : 1120 mm Print width max : 1040 mm Repeat : 300 - 800 mm Max. speed (mech.) : 200 m/min Unwinder diameter : 1000 mm, core 76 / 152 Rewinder diameter : 1000 mm , core 76 / 152 Dryer heating medium = GAS, Incl: 4 electric pumps Existing printing cylinders, anilox rollers and sleeves

Two single-color flexographic printing presses are available, without documentation, an on-site inspection is possible.

SKM-PD1222 technical parameters Feeding : Automatic Vacuum Feeder antistatic system for corrugated board 6 printing units / 5 with squeegee beams 1 with rubber roller Each printing unit has a ceramic anilox roller Dryer: Infrared Details: Bosch Rexroth controllers with servo drives . 11 pieces of servo drives Each printing unit has a vacuum arc transport. Maximum mechanical speed: 130 pieces /min Ideal speed: 120 pieces /min Printing speed: 70-90 pieces /min Max sheet size: 1200mmx2400mmx12mm Min. sheet size: 320x650x1,5mm Max pressure dimension: 1150mmx2200mm Control system: Siemes Weight: 50 t Dimensions: 22m x 4.85m x 2.8m

The gravure printing machine was used for wallpaper and other substrates. Number of printing units: 7, track width: 59mm, max. printing width: 53mm, max. roll diameter: 1000mm. King shaft drive / DW 1 + 7, single drive possible. Unwinding with lifting platform aid. Intermediate dryer operated with thermal oil. Paper and non-woven printing substrate, register control.

4 col gearless flexoprinting machine to print foil and paper with waterbased color or UV color. The Machine can be further used to coat foil or paper. Working width 1.4 m Diameter Mono un - and rewinder = 1000 mm Speed = 350 m/min.

A Briem 6-color gravure printing system is available. Number of colors: 6, max. web width: 1500mm, max. printing width: 1420mm, drying zones: 2, max. printing length: 940mm, max. printing speed: 50m/min, format precision: +/-0.25mm, max. drying temperature: 120°C, materials: PVC-P/PVC/PET/PE/CPP/OPP/BOPP/paper. Dimensions X/Y/Z: approx. 8500mm/2500mm/2500mm, weight: approx. 22000kg. Including turret winder and intermediate drying.

Nilpeter Flexo Rotolabel F-200 year 1978 water inks - 1 UV on the last unit printing width: film 210 mm, paper 225 mm 5 printing units 3 rotary cutting units 16 Anilox 29 sets printing cylinders 3 magnetic cylinders

Number of colors: 6, film passage width: 1250mm, print width: 1200mm, print length min./max.: 300mm/900mm, max. print speed: 200m/min, dimensions X/Y: approx. 9000mm/3600mm. Including anilox rollers and Rossini impression cylinder sleeves with the required gears. Documentation available. An on-site inspection is possible.

Width 52 cm Year of construction 2000 Web width 520 mm max. roll diameter 1270 mm Web edge control Erhardt + Leimer 2 wet offset printing units 630 mm circumference Technotrans cooling unit Turning cross air-flushed turning rods Sheeter Q 74 Trimming edges on both sides Sheet delivery Uniplus 520 Strip Insertor Price on request. We deliver and install worldwide!

A Bosgraaf three-color flexographic printing machine is available. Number of colors: 3, web width: 1300mm, printing width: 1150mm, printing speed: 150m-250m/min, processable materials: OPP/PE/CPP/PET, material thickness range: 12µm-100µm, drying system: UV and IR drying, max. roll weight: approx. 2000kg. On-site inspection is possible.

Print stations: 4 Stations: 2 Air Dryers Lamps Turn Bar Waste Rewind

CUIR1700 MK1, • Model: Rotaflexo 1700 MK1, • Year : 1994, • Max. sheet width: 1700mm, • Max sheet length : 1275mm, • Number of printing units: 4, • Dryer: 1 infrared dryer after last printing unit, • Max speed: 8000 sheets/hour, • Prefeeder: Serco FM 604 from 2002

ROTOFLEX VLI 500 Slitter and Rewinder Age: 2003 Web width: 500 mm Cutting by razor blades Foot switch Counter 2x Rewinding shafts Core Diameter: 76 and 152 mm / 3 and 6 inch

range L-W-H: 390 x 270 x 760 mmcorner cutter: 1 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Terminal / Monitor for CNC Printing Machines F&K , Mint condition because never used

web widht: 310 mmprinting lenght: 300 mmprinting widht: 310 mmconnection value: 230 VoltEnables precise imprinting in prefabricated roll labels.- Flexo printing unit- Electronic infeed control- Longitudinal cutter (razor blade cut)- Job storageWeb widht max.: 315 mmPrinting lenght max. 300 mmPrinting widht max.: 310 mmunwind and rewindRoll diameter max.: 400 mmShafts diameter: 76 mmLongitudinal cutter, cutting width min.: 16 mmOutput/Speed: 30 m / min.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

flexographic printing machine For paper and foil SMB type FD10-4 / UV Year of construction 2014 4 – COLORS / UV UV drying system IST Video system Super Handy SCAN 400 BST Bridge width max 600mm Material width max 650 mm

web widht: 310 mmprinting lenght: 300 mmprinting widht: 310 mmconnection value: 230 VoltEnables precise imprinting in prefabricated roll labels.- Flexo printing unit- UV-Drying- Electronic infeed control- Longitudinal cutter (razor blade cut)- Job storageWeb widht max.: 315 mmPrinting lenght max. 300 mmPrinting widht max.: 310 mmunwind and rewindRoll diameter max.: 400 mmShafts diameter: 76 mmLongitudinal cutter, cutting width min.: 16 mmOutput/Speed: 30 m / min.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Gallus EM 280 6 colors UV Flekso Year 2009 BST camera With rewinder GAP punch In production Immediately available

VARGA FLEXO 800 Type HK68,, C.I. flexo printing,geared, 6 colors, working width 800 mm., Printable materials:, - Pre-treated plastics (PET, PE, BOPP), - Multilayer films, - Paper, - Lenze servomotors installed in machine- main drive, unwinding, winding, - pressure cylinder: central impression, - CI pressure cylinder material: ST52–3, - number of printing stations: 6 pcs, - printing length: 30–55 cm, - print length scale: 1 cm, - printing accuracy at constant speed ± 0.2 mm, - length register setting: manual, - cross register setting: manual, - maximum print width: 800 mm, - Maximum roll width: 900 mm, - Unwinder: 1 pc, - core diameter : 76 mm, - Maximum diameter of reels: 1000 mm, - mechanical speed: 15–120 m / min, - Machine weight: 7 tons, Equipment:, - Automatic, two-way winding and rewinding system that maintains a constant tensile force after setting the material parameters.  ...

Machine: Bielomatik TAL 100 Year 2001 - Separation and dispensing of RFID material - All material handling with web tension control -Web guide control via ultrasound and 2x via camera module -4 inline RFID readers (checking/marking defective inlays) - Web monitoring: Leuze camera system (3 cameras) -Folding device (DistaFerr) - Transfer module -2 inkjet printers Imaje 9020 (labeling and marking) - 2 controlled hole punches (devaluation, passepartout punching) - 2 longitudinal cutting modules with 2 knives each -3 hot melt heads for tickets - Ticket display after punch - Adjustable counter pressure cylinder -Only solid cylinder used - Rotary punch Register control yes Longitudinal cutting web edge control Material width [mm] min 20 max 120 Punching width [mm] min 10 max 120 Feed [mm] min 5 max 609.6 Unwinding 0 [mm] 600 Grid winding 0 [mm] 600 Winding 0 [mm] 600 R ...

1 color flexo printing machine, Manufacturer: Altinisik Makina, Model: AA1290, Year of manufacture: 2021, Size: 1290x1800mm, With Skipfeed: 1550mm, minute 350x750mm, Cardboard thickness with special thickness up to 28mm, speed up to 7,000 Bg/h, Manufacturer: Altinisik Makina, model: AA1290, Construction year: 2021, format: 1290x1800 mm

Gidue / Bobst I-Combat 430 flexographic printing machine Year 2007 with the following equipment: 12 colors flexographic printing Corona enema Softal Corona multilayer printing (Arcotec) Web storage BST orbit monitoring 2 x additional unwinding / unwinding 2 x Web Edge Controls 2 x Reversible Keuz 2 x rotary punching boxes including 1x GapMaster Sensotec register control Cooler (for cooling rollers) Teknek web cleaning Uviterno UV system including 1x replacement lamp (the UV system received completely new electronics in 2018) 3x screen printing units Including the following printing accessories: 19 Anilox Rollers 2 magnetic cylinders (Z120 / Z124) 78 cliché cylinders of various sizes 50 pairs of sieve rings Technical specifications: Multilayer label printing possible Max speed 180 m/min Max web width 430mm Video and Pictures on request

Windmöller & Hölscher flexographic printing machine Olympia 1665 central cylinder, Endpapers: Olympia 1665, Type: Central cylinder, Year of construction: 1969, Lifting: hydraulic, Color continuation: with freewheel and separate motor, Width: 1,100mm, Print width: 1,070mm, Printing range: from 280 to 600mm, Inks / printing units / dipping and anilox rollers:, Can be equipped on the stand: 4 colours, Anilox rollers available: 4 x chrome, Dip rollers available: 4 x rubber, Counterpressure cylinder: Central cylinder, Drying: Hot and cold air electrically on the bridge Intermediate drying in the printing unit possible, Completion:, Unwinding 1 x electrically rotatable, Brake: pneumatic, Roll diameter: up to 1,200mm, Winding shafts: pneumatic 70 and 76mm, Roll cutting: Shear cutting (upper and lower blade) inline with spreader roller, Winding:, Winder: 2 holders for large rolls / star winder ...
