travel used for sale

x-travel: 12000 mm y-travel: 2000 mm z-travel: 1000 mm control: E.C.S. 2351 taper ISO: 50 P.D.B. Table dimensions: 450 x 450 mm spindle speeds: 0 - 1500 mm total power requirement: 35 kW weight of the machine ca.: t dimensions of the machine ca.: m Mist extraction Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Travel path X/Y/Z: 1670mm/800mm/900mm, Speed: 4000rpm, Tool positions: 16, Tool holder: SK40, Table dimensions X/Y: 2000mm/900mm, Weight: approx. 4500kg, Operating hours: approx. 9680h. According to the error message, the standstill monitoring of the Z-axis is defective. Documentation available. An on-site inspection is possible.

Key data: 2200 mm, 600 mm, 600 mm

Travelling column milling machine Manufacturer Ibarmia Type ZV40 Year of construction 2000 Control Heidenhain TNC 410 Table size 2600 x 650 permissible. Load 2300kg Travel X/YZ 2200/600/600 Tool holder SK40 24 Way Tool Changer max speed 8,000rpm Partition wall for pendulum operation Electronic Handwheel HR410 Chip conveyor Glass scales in all axes Guide of the Y-axis would have to be redone In 2018, the machine got a new guide in Z and X axis, and a new main spindle. Machine is fully functional except for the linear guide of the Y-axis. Machine has the following dimensions: L x W x H 4200 x 3000 x 3050, weight 12000kg. Without the vices in the photos.

Machining length X: 5000mm, machine dimensions X/Y/Z: approx. 7500mm/3500mm/3500mm, weight: approx. 14000kg, control system: Heidenhain 426, operating hours: 91758h, running hours: 36086h. Including tool changer and tool holders. Without extraction system. Documentation available. An on-site inspection is possible.

Working platform, scissor lift, aerial work platform, cherry picker, lifting platform, scissor lift, scissor lift, drive axle aerial work platform, travel drive, drive axle -Manufacturer: GSL, travel drive axles left and right from aerial work platform -Type: KM 400 and HM 400 -Bolt circle: Ø 145 mm M14 -Dimensions: see photos -Delivery/price: complete -Dimensions: 630/370/H510 mm respectively -Weight: 52 kg/pc.

Travel wheel axle for crane undercarriage, friction wheel, travel wheel for bridge crane, indoor crane, assembly crane, workplace crane -Travel wheel axle: for crane trolley -Type: D=120x649.5 Part 3 Crane 1/2 -Art.No.: 1031 4148 -Dimensions: see photo technical drawing -Number: 3x axle available -Price: per piece -Dimensions: Ø 120 x 649.5 mm -Weight: 35 kg/piece

Travel wheel axle for crane undercarriage, friction wheel, travel wheel for bridge crane, indoor crane, assembly crane, workplace crane -Travel wheel axle: for crane trolley -Type: D=90x244 -Dimensions: see photo technical drawing -Number: 3x axle available -Price: per piece -Dimensions: Ø 90 x 244 mm -Weight: 10.4 kg/piece

Vacuümhefunit - Type: V01174 - Maximaal hefvermogen bij 60% werkvacuüm: 1650 kg - Gewicht: 700 kg - lengte: 10,3 meter - breedte: 500 mm - hoogte: 950 mm

Wingspan: approx. 18,000 mm, max. load capacity: 6,300 kg, with electric trolley and radio remote control

Wingspan: approx. 18,000 mm, max. load capacity: 3,200 kg, with electric trolley and radio remote control

Unaudited Good condition Auction-ID: A7-45427-148

Good condition Very light Auction-ID: A7-45427-211

A relatively new double-girder overhead crane Konecranes is available. Load capacity: 12t. Documentation available. An on-site inspection is possible.

With electric chain hoist, remote controlled, 10 steel columns, height approximately 9.500mm, travelling beam length approximately 27.500mm and power rail Auction-ID: A1-43459-26

x-travel:6000 mm y-travel:2100 mm z-travel:1500 mm Controls:HEIDENHAIN iTNC 530 BASIC DESIGN:. - basic design : travelling column :. WORKING RANGE -MILLING-:. - x-axis travel:6000 mm - y-axis travel:2100 mm - z-axis travel:1500 mm FLOOR PLATE:. - clamping surface (left-right):7000 mm - clamping surface (front-back):2000 mm WORKING SPINDLE / HEAD:. - spindle type : orthogonal head :. - tilting range:360 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - tilting range (2nd axis):270 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - spindle revolutions (min):20 /min - spindle revolutions (max):4000 /min - spindle diameter:90 mm - taper fixture : ISO SK 50 :. - spindle power (continuous):32 kW - torque (max.):910 Nm AXIS DRIVES:. - feed velocity (min):2 mm/min - feed velocity (max):20000 mm/min - rapid traverse:25000 mm/min ELE ...

x-travel:6.300 mm y-travel:2.000 mm z-travel:2.700 mm tool taper:ISO 50 surface area:7.000 x 3.000 mm turning speed range:60 - 4.000 U/min power capacity:22/30 kW feeds:0 - 10.000 mm/min rapid traverse:20.000 mm/min Tool changer:80 max. workpiece weight:8.000 kg Plate clamping area 7,000 x 3,000 mm CNC rotary table 1,500 mm Orthogonal milling head Deep drilling unit IKZ Paper belt filter Measuring probe

automatic:Werkzeugspannung Spannk.15000 N total power requirement:63 KVA weight of the machine ca.:56000 kg table-size:22000 x 800 mm Tool bore:ISO 50, DIN 69871 AD x-travel:20500 mm y-travel:1600 mm z-travel:1000 mm dimensions of the machine ca.:24 x 6 x 4 m tool piece magazine with:30 Plätze

x-travel:7000 mm y-travel:1200 mm z-travel:1300 mm rapid travel x/y/z:10 m/min table-size:7.200 x 1.000 mm table load:max. 4 t/qm universal head:5 Pos. plus manuell 1° tool taper:SK 50 milling head speed:20 - 2.000 1/min power capacity:30 kW max. torque on the spindle:Getriebe 2 stufig , 1.500 Nm control:HEIDENHAIN TNC 360 total power requirement:50 KW dimensions of the machine ca.:9,0 x 3,8 x 4,6 m weight of the machine ca.:25,0 t universal travelling column - universal milling machine orthogonal milling head with 5 controlled Pos. with M-code and additional 1° indexing, manually in spindle axis, prepared for HSC milling heads incl. torque support, moveable operator-cabin/panel, chipconveyor, incl. controlled security fence, miscellaneous accessories (angle milling heads, vices...) on request still under power in closed factory

x-travel:30000 mm y-travel:3600 mm z-travel:1900 mm milling head speed:1 - 4000 U/min spindle taper ISO:50 feed speeds:1 - 10000 mm/min rapid traverse:25 m/min milling spindle motor:46 kW total power requirement:85 kW dimensions of the machine ca.:45 x 8,7 x 5,5 ü.F. m with CNC HEIDENHAIN iTNC 530 autom. milling head indexing 2,5° floor plate field 31000 x 2500 mm ( 4 floor plates 6000 x 2500 mm + 1 floor plate 7000 x 2500 mm ) 2 chip conveyors, coolant attachment

x-travel:16300 mm y-travel:2600 mm z-travel:1600 mm spindle taper ISO:50 spindle turning speed range:22 - 4000 U/min rapid traverse:24 / 36 m/min main drive:37 kW total power requirement:50 kW with CNC HEIDENHAIN TNC 430 automatic Universal Milling Head automatic toolchanger 90-pockets coolant attchament and chip conveyor
