122,049 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
x-travel: 10500 mm y-travel: 2750 mm y-travel: (3350) mm z-travel: 1500 mm turning speeds: 3500 U/min Tool changer: 80 Control: Heidenhain TNC 430 M positioning accuracy: 1 ° milling-head swivable +/-: CNC Plate area: 12000x2500 mm chip conveyor: spindle taper ISO: 50 Spindle capacity: 37 KW Feed: 6000 mm/min Rapid movement: 15000 mm/min total power requirement: kW weight of the machine ca.: 65 t dimensions of the machine ca.: 18,1x6,7 m CNC angle head 360 ° with 1 ° Hirtverzahnung spindle hours 13500 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Spindle diameter: 150 mm Longitudinal X: 8400 mm Vertical Y: 3000 mm Cross Z: 700 mm Positions ATC: 0 Table length: 0 mm Table width: 0 mm Number of tables: 0 CNC Brand: Heidenhain CNC Model: iTNC 530 WOTAN Rapid 4 FLOORBORER iTNC530 Make : Wotan Werke Dusseldorf Typ &nbs p; : RAPID 4 A Mach.No : 67 . 003 Age &nbs p; : New iTNC 530 in 2010 / 82” X – travel : 8.400 Y – travel & ...
used
Spindle diameter: 0 mm Longitudinal X: 18500 mm Vertical Y: 4500 mm Cross Z: 950 mm Positions ATC: 60 Table length: 20000 mm Table width: 4200 mm Number of tables: 0 CNC Brand: Heidenhain CNC Model: iTNC 530 Hydrostatic guideways Hydrostatic spindle bearing Pick place head change station 1 = Facing head with U-Axis 2 = Universal milling head 3 = Boring Spindel support 4 = Vertical milling head X – Travel: 18.500mm Y – Travel: 4.500mm Z – Travel: 950mm W – Travel: 900mm Table Length: 20.000mm Table Width: 4.200mm Table load: ...
used
Spindle diameter: 0 mm Longitudinal X: 9000 mm Vertical Y: 4000 mm Cross Z: 1000 mm Positions ATC: 80 Table length: 2500 mm Table width: 2500 mm Number of tables: 1 CNC Brand: Heidenhain CNC Model: TNC 430 WMW - BP 160 CNC Floor type Horizontal borer Ø 160 with Y 4000 mm MACH - ID 6368 Make: WMW Type: BP 160 Control: HeidenHain TNC 430 YOP: 2001 X – Travel 9.000 mm Y – Travel 4.000 mm Z – Travel 1.000 mm W – Travel 800 mm Table Length 2.500 mm Table Width 2.500 mm Table load 30.000 kg Speeds / ranges 2000 Rpm Power 52 kW Ram size 500 x 620 mm Spindle Taper Iso 50 IS ...
used
Spindle diameter: 0 mm Longitudinal X: 14500 mm Vertical Y: 3750 mm Cross Z: 1600 mm Positions ATC: 0 Table length: 0 mm Table width: 0 mm Number of tables: 0 CNC Brand: Heidenhain CNC Model: TNC 430 MACH-id 402 MAKE Skoda TYPE W 200 HB YEAR 1999 SPECIFICATIONS Controll HeidenHain TNC 430 Floor or table type borer Floor X - Travel 14.500 mm Y - Travel 3750 mm Z - Travel 1600 mm W - Travel 2000 mm Spindle Diameter Ø 200 mm Spindle Taper Sk 50 Ram size 520 x 520 mm kW power on spindle 78 kW Spindle speeds / ranges 0,9 - 930 Rpm Number off controlled axi ...
used
Spindle diameter: 200 mm Longitudinal X: 12800 mm Vertical Y: 4000 mm Cross Z: 1100 mm Positions ATC: 0 Table length: 0 mm Table width: 0 mm Number of tables: 0 CNC Brand: Fanuc CNC Model: 31 i MAKE PAMA TITAN License TYPE AFP 200 YEAR 2006 Retrofitted SPECIFICATIONS Controll FANUC 31i Floor or table type borer Floor borer X - Travel 12.800 mm Y - Travel 4.000 mm Z - Travel 1100 mm W - Travel 900 mm Spindle Diameter Ø 200 mm Spindle Taper ISO 50 Ram size 600 x 530 mm kW power on spindle 100 kW Spindle speeds / ranges 1500 Rpm Number off controlled axis 4 DIMENSIONS Length 18000 mm Width 10000 mm Height ...
used
Spindle diameter: 200 mm Longitudinal X: 16000 mm Vertical Y: 1128 mm Cross Z: 4785 mm Positions ATC: 0 Table length: 4250 mm Table width: 4250 mm Number of tables: 1 CNC Brand: Heidenhain CNC Model: iTNC 530 5 Axis MACH-id 341 MAKE Innocenti italia TYPE CWB FAF 200 CNC YEAR 2015 Reconditioned to iTNC 530 / New electric SPECIFICATIONS ControllHeidenhain iTNC 530 5 Axis Floor or table type borer Floortype X - Travel 16000 mm Y - Travel 1128 ( table - column) mm Z - Travel 4785 mm W - Travel 1600 mm Spindle Diameter Ø 200 mm Spindle Taper SA60 kW power on spindle 74 kW Spindle speeds / ranges0 - 500 Rpm Table Length x Width 4.250 x 4.250 mm Table load in kG 60000 Kg Movement V Axis 2590 mmNumber off controlled axis5 Retrofitted 1990 - 1993 & 2013 Innocenti CWM FAW 20 ...
used
Spindle diameter: 130 mm Longitudinal X: 10000 mm Vertical Y: 3500 mm Cross Z: 1000 mm Positions ATC: 0 Table length: 3000 mm Table width: 3000 mm Number of tables: 1 CNC Brand: _Unknown / Other CNC Model: Bosch CC 200 Universal milling head Angular indexing vertical milling head V Axis table 1600 mm X - Travel: 10000mm Y - Travel: 3500mm Z - Travel: 1000mm W - Travel: 900mm Table Length: 3000mm Table Width: 3000mm Table load: 25000 Speeds / ranges:800/2500Rpm Power: 63kW Ram size: 400 x 400mm Spindle Taper: 50ISO/Bt/Mk Feed rate X-Axis:5000mm/min. Feed rate Y-Axis:5000mm/min. Feed rate Z-Axis:5000mm/min. Feed rate W-Axis:5000mm/min. Length:   ...
used
Ref. -No.: 10350 Manufacturer: FPT Year of construction: 2012 Type of control: CNC Control: Heidenhain 530 Storage location: Halberstadt Country of origin: Italien X-Travel: 14000 mm Y-Travel: 5000 mm Z-Travel: 1500 mm W-Axis: 1000 mm Numbers Of Tools In Magazin: 24 Drive Capacity - Spindle Motor: 60 kW Rotary table diameter: 3000x3000 mm Rotary table travel V: 2500 mm Rotary table max. Load: 80000 kg swivel angle: 180 ° Further information: +3D M Sensor +CNC controlled angle head: micro
used
x-travel: 2.600 mm y-travel: 700 mm z-travel: 700 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 35 / 25 kW tool taper: SK 40 work table:: table surface area: 2.900 x 700 mm max. table load: 2.150 kg tool magazin:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 40 m/min feed speeds: max. 40.000 mm/min feed power: max. 8 kN total power requirement: 54 kVA weight of the machine ca.: 14,4 t dimensions of the machine ca.: 8,0 x 5,6 x 2,8 m Chip conveyor: Coolantsystem: high pressure coolant: 40 bar through spindle coolant: Rotary screen: 2x Signal-Light: paper band filter: interface 4. axis: indexing attachment: Hofmann - RWNC-220L tool setti ...
used
x-travel: 6200 mm y-travel: 1070 mm z-travel: 1000 mm Table dimensions: 1030 x 8000 mm control: Siemens Sinumerik 8 MC taper ISO: 50 spindle speeds: 15 - 1595 U/min voltage: 380 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 8000 mm y-travel: 1000 mm z-travel: 1250 mm dividing head: CNC chip conveyor: Universal angular milling head 2-axis adjustable: control: Fagor type: 8025 : CNC clamping plate: 1500x3000 mm clamping plate: 1500x4000 mm clamping plate: 1500x4000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 12000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 415 taper ISO: 50 P.D.B. spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 2750 mm y-travel: 400 mm z-travel: 325 mm spindle taper ISO: 50 throat: 450 mm turning speeds: 31,5-2000 U/min Feed: 0,4-200 mm/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 8000 mm y-travel: 2500 mm z-travel: 1000 mm control: Heidenhain TNC 355 taper ISO: 50 spindle speeds: 20 - 1800 mm voltage: 380 V total power requirement: 27,6 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 12000 mm y-travel: 2000 mm z-travel: 1000 mm control: E.C.S. 2351 taper ISO: 50 P.D.B. Table dimensions: 450 x 450 mm spindle speeds: 0 - 1500 mm total power requirement: 35 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 20000 mm y-travel: 2800 mm z-travel: 1050 mm control: Heidenhain 530i taper ISO: 50 P.D.B. spindle speeds: 0 - 2000 mm voltage: 380 V total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 1100 mm y-travel: 600 mm z-travel: 500 mm Control: Heidenhain TNC 335 B tool taper: SK40 table surface - upper: 1650 x 700 mm table face - lower: 1870 x 300 mm spindle speed:: 3000 Upm spindle motor: ca. 9 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Horizontal and vertical milling Position change of the head is done manually Vertical head with drilling quill, drilling depth 100 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 22.000 mm y-travel: 1.500 mm z-travel: 3.000 mm Control: SIEMENS 840 D milling head -swivable: 0,001/0,001 Grad milling head: Universalfräskopf 45° Internal cooling system: 20 bar Chip coveyor: ja Tools changer: 30 pos. coolant: 1.100 l Tool taper: DIN 69871A ISO 50 total power requirement: 45 kW weight of the machine ca.: 68 t The round table shown in the pictures as well as the plate field are not sold with ! urning Speeds 6.000 r.p.m. AutoIndex Head 45 º Head 360.000 Pos. Elbow 360.000 Pos. Main Motor Power 37 Kw. Nº Change Range 2 Ranges Automatic Tool Charger INCLUDED Tools at ATC 30 Coolant Through Tool 20 Bar INCLUDED Soluble Oil Tank with filter paper INCLUDED Head Coolant System + CF Box INCLUDED Longitudinal Chip Conveyor INCLUDED Operator?s Platformd with 2000 mm Vertical movement. INCLUDED Ready for Rotor Translating Table (Regulator + Wires) /IN ...
used
Spindle diameter: 500 mm Longitudinal X: 8500 mm Vertical Y: 1000 mm Cross Z: 2750 mm Positions ATC: 0 Table length: 3000 mm Table width: 2100 mm Number of tables: 1 CNC Brand: NUM CNC Model: 3 Axis MACH-id 3411 MAKE Innocenti TYPE FAF 140 - 95 YEAR 1964 SPECIFICATIONS Controll Num in 3 Axis Floor or table type borer Floortype X - Travel 8.500 mm Y - Travel 1.000 mm Z - Travel 2.750 mm Spindle Diameter Ø 500 mm Table Length x Width 3.000 x 2.100 mm Number off controlled axis 3 Innocenti FAF 140 - 95 cnc floor boring machine
used
X-travel: 2000mm, y-travel: 500mm, z-travel: 500mm, max. workpiece weight: 2.5t, connected load: 60kVA, length: 4000mm, width: 3100mm, height: 3200mm, weight: 16t, with documentation and tools, has been regularly maintained, an on-site inspection is possible, the machine is available from July 2024.
used
X-travel: 2500mm, y-travel: 970mm, z-travel: 1000mm, table dimensions: 2920x920mm, connected load: 52kVA, controls: HEIDENHAIN iTNC 530, weight: 15t.
used
x-travel: 2.940 (2x 1.220) mm y-travel: 500 mm z-travel: max. 800 mm Control: TNC 426/430 Heidenhain distance spindle nose and table: V: 0 - 770 mm distance spindle nose and table: H: 180 - 980 mm Main spindle:: turning speed range - main spindle: 80 - 8.000 min/-1 power capacity - main spindel: 40 kW max. Torque: 191 Nm spindle diameter in front bearing: 70 mm swivellable: +/- 90 ° tool taper: SK 40 work table:: table surface area: ca. 3.340 x 650 mm T-slots: 14 H9 mm max. table load: 600 kg Tool-Presetter:: number of toolpositions: 22 pos. tool taper: SK 40 change-time tool to tool: 5 sec change-time chip to chip: 9 sec max. tool diameter: 85 mm max. tool-dia with free toolbox: 135 mm max. tool length: 400 mm max. workpiece weight: 8 kg feeds:: rapid traverse ( X / Y / Z ): 25 / 25 / 20 m/min Feed x / y / z: 1 ... 9.999 mm/min feed power: 9 kN total power requirement: 69 KVA weigh ...
used
Ref. -No.: 10347 Manufacturer: FPT Year of construction: 2006 Type of control: CNC Control: Heidenhain 530 Country of origin: Italien X-Travel: 12000 mm Y-Travel: 3500 mm Z-Travel: 1500 mm Tool Piece Magazine With: 80 Pcs./pcs. Spindle Speed: 3000 RPM Drive Capacity - Spindle Motor: 37 kW Round table 1 (lxw): 2500x2500 mm Round Table 1 - V: 2000 mm Rotary table 1 max. load: 30000 kg Round table 2 (lxw): 2500x2500 mm Round Table 2 - V: 1500 mm Rotary table 2 max. load: 30000 kg Further information:
used
Ref. -No.: 10201 Manufacturer: AXA Year of construction: 2007 Type of control: CNC Control: Siemens 840D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 5000 mm Y-Travel: 600 mm Z-Travel: 800 mm Machine length: 9400 mm Machine width: 3500 mm Machine Height: 3300 mm Table Dimensions (Lengthxwidth): 6325 x 1050 mm Swivelling: +/-90 ° Numbers Of Tools In Magazin: 120 Turning Speeds: 30-9000 RPM Tool changer: SK 50 Drive Capacity - Spindle Motor: 45 kW Weight Of The Machine Ca.: 23 t Tool change time: 6 s Vertical working height: 0-740 mm Working height horizontal: 250-1050 mm Space requirement (LxWxH): 11000 x 5090 x 3300 mm Feed rate: X/Y/Z: 40 m / min
used
Work platform, scissor lift, aerial work platform, cherry picker, lifting platform, scissor lift, scissor lift, travel drive axle lift work platform, travel drive, drive axle aerial -Manufacturer: GSL, travel drive axle for aerial work platform with solid rubber wheel -Solid rubber wheel: Continental CSE-Robust SC 15 5.00-8 -Dimension: 610/320/H400 mm -Weight: 57 kg
used
x-travel 3000 mm y-travel 650 mm z-travel 800 mm control Heidenhain 426/430 table dimensions 3.500 x 750 mm turning speed range 7300 U/min with transmission tool taper SK50 tool magacine with 48 Plätzen IKZ KNOLL slewability of milling head + / - 90 integrated rundtisch 750mm 2x made by FIBRO weight of the machine ca. 24 t dimensions of the machine ca. 8,4 x 4,4 x 3,6 m Table max. 2,500 kg load chip conveyor without vise prepared for delivery
used
OMZ Cobo 30 traveling column milling machine, equipped with chip conveyor CNC can be connected to PC or external device via RS 232 serial cable. The maximum electrical absorption of the milling machine is 30 KVA, and the machine has all three axes with linear guides and roller shoes. The Heidenhain optical scale is present only on the X axis while for the other two axes and spindle the encoders present on the motors are used as measuring systems. Two ways of purchasing the machine (both with the machine running): - ⬠18,000 + VAT per car seen and liked; - ⬠28,000 + VAT if also complete with CE certification, machine identification plate, user and maintenance manual. - X axis travel = 2000 mm - Y axis travel = 550 mm - Z axis travel = 500 mm - Table dimensions 2300 x 600 mm - Spindle motor power 11 Kw, 6,000 rpm - Internal spindle cooling - Mitsubishi dr ...
used
DESCRIPTION U.M. ORIGIN VALUES X axis - Longitudinal travel 5,000 mm Z axis - Vertical travel 2,200 mm Y axis - Transversal travel 1,000 mm Spindle motor power in S6 kW 42 Max. speed constant power spindle rpm 2,500 Supply voltage Vac 400 Power frequency Hz 50 ISO spindle taper ISO 50 SIEMENS Brushless Motors SIiemens Simodrive 611 drives CNC FIDIA C10 Supplied accessories: - X-axis bench with cable carrier and X-axis telescopic cover - Double upright complete with ram - Hanging arm with CNC - Z axis telescopic cover - Fixed operator platform with protections - Conical supports and gibs - Carter - N° 2 hydraulic power units - Oil cooler - Coolant tank - Cabinet - N° 2 horizontal nose cones Machine retrofitted in 2010. The machine is currently positioned on the ground in our workshops. Location: Northern Italy
used
Year of construction 2001 Hours of power up 16,400 hours Spindle rotation hours h 3,078 X axis - Longitudinal travel 7,000 mm Z axis - Vertical travel 2,500 mm Y axis - Transverse travel mm 1,250 (1050) Work progress speed mm/min 0 ÷ 4,000 Rapid feed speed mm/min 12,000 Maximum thrust on the X-Y-Z axes daN 2,200 Spindle motor power in S1 kW 30 Spindle motor power in S6 kW 37.5 Spindle speed at constant torque. rpm 0 ÷ 235 Spindle speed at constant power. rpm 235 ÷ 4,000 Maximum spindle torque in S6 Nm 1,500 Supply voltage Vac 400 Power frequency Hz 50 Total installed power kW 75.1 Spindle taper NOT INSTALLED Automatic head change Yes ISO 50 tool magazine no. pos. 60 Automatic tool changer installed HEIDENHAIN TNC430M CNC Positioning accuracy mm ±0.020 Repeatability accuracy mm ±0.010 Supplied accessories: - X axis bench with X axis telescopic cover - Up ...
used
Year of construction 2000 Hours of power up h 10205 X axis - Longitudinal travel 10,500 mm Z axis - Vertical travel 2,500 mm Y axis - Transversal travel 1,250 mm Work progress speed mm/min 0 ÷ 4,000 Rapid feed speed mm/min 12,000 Maximum thrust on the X-Y-Z axes daN 2,200 Spindle motor power in S1 kW 30 Spindle motor power in S6 kW 37.5 Spindle speed at constant torque. rpm 0 ÷ 235 Spindle speed at constant power. rpm 235 ÷ 4,000 Maximum spindle torque in S6 Nm 1,500 Supply voltage Vac 400 Power frequency Hz 50 Total installed power kW 75.1 ISO spindle taper ISO 50 Positioning accuracy mm ±0.020 Repeatability accuracy mm ±0.010 Supplied accessories: - X axis bench with X axis telescopic cover - Upright complete with ram - Z axis telescopic cover - Articulated presetting probe support - Pneumostatic support system - Carter - Hydraulic unit - Filtering tan ...
used
Year of construction 1985 X axis - Longitudinal travel 4,000 mm Z axis - Vertical travel 2,550 mm Y axis - Transversal travel 1,000 mm Hydrostatic support Yes Spindle motor power in S6 kW 42 Max. speed constant power spindle rpm 2,500 Supply voltage Vac 400 Power frequency Hz 50 ISO spindle taper ISO 50 Brushless motors CNC GBR SINUS - To be replaced Total weight 48,500 kg Supplied accessories: - X axis bench with X axis telescopic cover - Double upright complete with ram - Z axis telescopic cover - Conical supports and gibs - N° 2 hydraulic power units - Coolant tank - Cabinet - Mobile operator platform (Z and Y axes independent from the mast) - Hanging arm with CNC - Chip conveyor - Levelers The machine is currently positioned on the ground in our workshops. Location: Northern Italy
new
x-travel:2000 | 3000 | 4000 | 6000 | 8000 mm y-travel:600 mm z-travel:600 mm distance spindle nose and table:110-710 mm table load:2000/ 3000 / 4000 / 5000/ 5500 kg spindle taper:40 (50 opt.) BT/SK spindle speeds:60 - 8000 1/min spindle drive:11/15 kW rapid speed:16/24/24 m/min feed range:1 - 10000 mm/min tool piece magazine with:24 (30 opt.) Stk. diameter of tools max.:150 mm (24 Werkzeuge) 180 (30 Werkzeuge) mm workpiece length:300 mm weight of the machine ca.:22 t weight of tools max.:7 kg positioning accuracy:± 0.005 mm repeatability:± 0.005 mm tool changing time:2,5 sec coolant capacity:470/550/660/830/980 l machine weight:14000 / 16500 / 22000 / 24000 / 26000 kg ATC:24 pos fach CNC controller:Heidenhain 620 chip conveyor - auger:auf der Rückseite des Tisches Machine semi-cover:oben offen :20 bar ATC:30 fach tool measuring system:Renishaw TS-27R :sowie 2 Tage Schulung Traveling ...
new
x-travel:3000 mm y-travel:800 mm z-travel:600 mm :800 mm working area:800x1770 mm :970 mm distance spindle nose and table:110 mm table load:1200 kg spindle taper:40 BT/SK spindle speeds:15.000 1/min spindle drive:33 kW addendum angle max.:120 Grad rapid speed:12/24/24/24 m/min feed range:1 - 10000 mm/min tool piece magazine with:24 Stk. diameter of tools max.:150 mm mm workpiece length:300 mm weight of tools max.:7 kg positioning accuracy:± 0.001 mm repeatability:± 0.001 mm tool changing time:2,5 sec coolant capacity:550 l :Rollentyp, Linearführungen base area:7200x3900x3200 mm CNC controller:Heidenhain TNC- 620 :CNC gesteuert Automatically power off:M30 tool box:mit Hilfswerkzeugen ATC:24 pos fach chip conveyor - auger:auf der Rückseite des Tisches alarm stack light:3-farbig :20 bar ATC:30 fach CNC controls from:Siemens tool measuring system:Renishaw TS-27R :sowie 2 Tage Schulung ...
new
x-travel:4000/7000/9000 mm y-travel:700 mm z-travel:300 mm spindle cone: 30 SK turning speeds:0/24000 U/min spindle drive:18 kW Weight approx.: 3200 (bei 4m in X) kg machine dimensions:6800x3100x3000 (bei 4m in X) mm automatic tool changer:8 optional 16 oder 30 CNC controller:mit Zyklen von Italmac :6 Klemmvorrichtungen automatisch verfahrbar
used
x-travel:6000 mm y-travel:2100 mm z-travel:1500 mm Controls:HEIDENHAIN iTNC 530 BASIC DESIGN:. - basic design : travelling column :. WORKING RANGE -MILLING-:. - x-axis traverse:6000 mm - y-axis traverse:2100 mm - z-axis traverse:1500 mm FLOOR PLATE:. - clamping surface (left-right):7000 mm - clamping surface (front-back):2000 mm WORKING SPINDLE / HEAD:. - spindle type : orthogonal head :. - tilting range:360 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - tilting range (2nd axis):270 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - spindle revolutions (min):20 /min - spindle revolutions (max):4000 /min - spindle diameter:90 mm - taper fixture : ISO SK 50 :. - spindle power (continuous):32 kW - torque (max.):910 Nm AXIS DRIVES:. - feed velocity (min):2 mm/min - feed velocity (max):20000 mm/min - rapid traverse:25000 mm/m ...
used
automatic:Werkzeugspannung Spannk.15000 N total power requirement:63 KVA weight of the machine ca.:56000 kg table-size:22000 x 800 mm Tool bore:ISO 50, DIN 69871 AD x-travel:20500 mm y-travel:1600 mm z-travel:1000 mm dimensions of the machine ca.:24 x 6 x 4 m tool piece magazine with:30 Plätze
used
Spindle diameter: 240 mm Longitudinal X: 8000 mm Vertical Y: 400 mm Cross Z: 0 mm Positions ATC: 0 Table length: 0 mm Table width: 0 mm Number of tables: 0 SPECIFICATIONS Controll Conventionel Floor or table type borer Floor borer X - Trave l8000 mm Y - Travel 4000 mm W - Travel 1400 mm Spindle Diameter Ø240 mm Spindle Taper Iso 60 / 50 Ram size 560 mm kW power on spindle 110 kW Spindle speeds / ranges 1,25 - 600 Rpm
used
X-travel: 11,000mm, y-travel: 5000mm, connected load: 50kW, on-site inspection is possible, the drive motor of the spindle on one traveling column has been removed and is defective.
used
Key data: 7000 mm, 1600 mm, 800 mm
Complete system with all the accessories necessary for installation and operation, Travel x = 7000 y = 1600 z = 800 / transverse stroke w = 600mm / General overhaul 2007, year of production 1991: New Siemens Sinumerik 840D control system, new drive motors, guide guides refurbished, new control cabinets. ECOCUT 1 was then operated for only a few months / Travel speed 12000 mm / min / w axis 6000 mm / min turntable TDV 2 max. workpiece weight 6t / clamping surface 1000x1000 turntable TDV 3 max. workpiece weight 12t / clamping surface 1250x1600 Accessories: 2 like new angle crank / chain tool change system / plate field / complete housing / Knoll hopper feed / suction / coolant system with belt filter All BWF fixators for the installation of machine bed and plate
used
Working platform, scissor lift, aerial work platform, cherry picker, lifting platform, scissor lift, scissor lift, drive axle aerial work platform, travel drive, drive axle -Manufacturer: GSL, travel drive axles left and right from aerial work platform -Type: KM 400 and HM 400 -Bolt circle: Ø 145 mm M14 -Dimensions: see photos -Delivery/price: complete -Dimensions: 630/370/H510 mm respectively -Weight: 52 kg/pc.
used
Portal crane with SWF hoist 70 ton (main hoist) amp; 5 ton (secundaire hoist) 30 meter lifting cable 4 driven wheel carriages with 8 wheels crane travel speed: 6m/min hoist travel speed: 6m/min lifting speed: 6m/min use class: A lifting class: A Total weight: 115 ton Kind of: portal crane Capacity: 70 + 5 ton Span: 25 meter Drop: 18 meter Tackle speed: 6 m/min Rotationspeed: 6 m/min Displacementspeed: 6 m/min Weight: 115 ton
used
SHW UF 6 Travel • X-axis (bed): 6,000 mm • Y-axis (vertical): 2,100 mm • Z-axis (headstock): 1,200 (1,500) mm Control • CNC control: Heidenhain TNC 430 Feed speed • X, Y and Z axes infinitely variable from: 2 – 12,000 mm/min Universal milling head in orthogonal design • Swivel range milling head holder: 340 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 22 – 3,200 rpm Year of construction 1998 • 2013 – Overhaul of the headstock • 2017 – Overhaul of the milling head • 2022 – Partial overhaul Clip • T-slots: 22 H12, DIN 650 • T-slot spacing: 250 mm, • Clamping area: 6,000 mm x 2,000 mm Conveyor • Task length: 6,000 mm • Task width: 350 mm • Ejection height over corridor: 1,250 mm Coolant device • Paper belt filter system o Container capacity: 500 ...
used
Spindle diameter: 0 mm Longitudinal X: 15000 mm Vertical Y: 3150 mm Cross Z: 1600 mm Positions ATC: 0 Table length: 0 mm Table width: 0 mm Number of tables: 0 CNC Brand: Siemens CNC Model: 810 M Make Skoda CNC Type W 200 H - CNC Year 1981 / 1999 CNC Skoda Floorborer with Siemens 810 M Spindle diameter (mm) 200 Longitudinal X (mm)15.000 Cross Y (mm)3.150 Pos ATCW = 2.000 Number APC.Z = 1.600 CNC Siemens 810 M Ram Size = 520 x 520 Power = 77 kW Speeds Vario = 0.8 - 630 Rpm Feed Rate = 0.63 - 1.250 / 2.000 / 3.500 Optional: Floorplates = 13.000 x 5.560 mm 6 x 6.390 x 1.885 x 350 - T 36 Optional: Skoda Rotary Table Size = 4.000 x 3.550 mm X - Travel = 2.100 mm Max. load = ca. 80.000 Kg Incl. Chip Conveyer CNC Skoda Floorborer CNC Skoda Plattenbohrwerk
used
SHW Uniforce 5 Travel • X-axis (bed): 4,000 mm • Y-axis (vertical): 1,600 mm • Z-axis (headstock): 1,300 mm Control • CNC control: Heidenhain iTNC 530 Feed speed • X, Y and Z axes infinitely variable from: 2 – 12,000 mm/min Universal milling head in orthogonal design • Swivel range milling head holder: 360 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 22 – 4,000 1/min Year of construction 1999 • 2016 – General overhaul incl. new control system • 2022 – Partial overhaul o Inspection of all components -> if necessary replacement o General overhaul of the milling head o Geometric acceptance takes place after New Machine Acceptance Protocol Clip • Clamping surface: 4,000 mm x 2,000 mm Conveyor • Task length: 4,000 mm Coolant device • Paper belt filte ...
used
TECHNICAL DATA SHEET CNC – Travelling column milling machine Make PARPAS Type SHARK One Control HEIDENHAIN iTNC 530 HSCI Year of construction 2016 Travel Longitudinal movement (X-axis) 3,500 mm Transverse movement (Y-axis) 1,083 mm Vertical movement (Z-axis) 1,074 mm Clamping table Clamping surface 4,000 x 1,000 mm Threaded holes with fitting seat Feeds X-, Y- and Z-axis, infinitely variable 2 - 30,000 mm/min. Rapid traverses in X / Y / Z 30 m/min feed force of the axes 10,000 N 2-axis milling head 2-axis milling head TUB-E92 with drive viaTorque motors for 5-axis simultaneous machining Power at 100 % ED 29 kW Speed range, infinitely variable 0-18,000 min-1 torque 92 Nm Rotational speed axis A/C 60 min-1 Tool holder HSK 63A – DIN 69893 Clamping force A-, C-axis 2,300/4,000 Nm Automatic tool changer ATC Tool stations 30 places ...
used
SHW Uniforce 5 Travel • X-axis (bed): 5,000 mm • Z-axis (vertical): 1,000 mm • Y-axis (headstock): 1,300 mm Control • CNC control: Siemens SINUMERIK 840D Universal milling head in orthogonal design • Swivel range milling head holder: 360 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: HSK 100 • Speed range: 22 – 4,000 1/min Year of construction 1998 • 2022 – partial overhaul o Inspection of all components -> replacement if necessary o General overhaul milling head o Geometric acceptance takes place after New machine acceptance protocol Clip •Mounting table: Conveyor • Task length: Coolant device • Paper belt filter system • Container capacity: 800 l Automatic tool changer •Tool magazine with 90 magazine slots Reversible clamping device Rückle PKTW 2 About us: MBM Maschinenservice & G ...
used
SHW Powerspeed 5 Travel • X-axis (bed): 4,000 mm • Y-axis (headstock): 1,300 mm • Z-axis (vertical): 2,100 mm Control • CNC control: Heidenhain iTNC 530 Cjksdwxmut Feed speed • X, Y and Z axis: 30,000 mm/min Universal milling head in orthogonal design • Swivel range milling head holder: 360 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 236 - 4,000 1/min Clip • T-slots: 22 H12 • T-slot spacing: 250 mm, • Clamping surface: 5,000 mm x 1,500 mm Conveyor • Task length: 6,000 mm Automatic tool changer • Chain magazine for 48 tools • Toolrobot Splash & chip protection • Three-sided protection cover About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is a freelance specialist for SHW machine tools. Our main task is in the field of tool milling machines. Our s ...
used
This machine is currently undergoing an extensive overhaul in our company. Ask about the current status of the overhaul and convince yourself of the machine during a viewing appointment at MBM. SHW UF 6 Travel • X-axis (bed): 6,000 mm • Y-axis (vertical): 2,100 mm • Z-axis (headstock): 1,200 (1,500) mm Control • CNC control: Heidenhain TNC 430 Feed rate • X, Y and Z axes infinitely variable from: 2 – 12,000 mm/min Universal milling head in orthogonal design • Swivel range milling head mount: 340 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 22 – 3,200 rpm Year of construction: 1998 • 2013 – Headstock overhaul • 2017 – Overhaul of milling head • 2023 – Partial overhaul Clip • T-slots: 22 H12, DIN 650 • T-slot spacing: 250 mm, • Clamping area: 6,000 mm x 2,000 ...
used
Dressing device for abrasives WMW Travel: 50 mm ± 90° swivel Tool holder 1 : MK0, inclined approx. 5° Tool holder 2 : Ø 8 mm, length: 35 mm Base: 100 x 125 mm groove: 16 x 4 mm through bore: Ø 13 mm used, tested ! Dimensions: 190 x 180 x 130 mm
