press forging used for sale

General SKU209W119 MakeHaagen & Rinau No.301015/4 Year of construction1998 LocationBarneveld Specified Features - Pressure vessel Material finishPolished inside Pressure Working pressure3 Bar Vacuum possiblecheck Number of vertical pressure tanks1 Main Features MaterialStainless steel Volume300 Ltr. Pressure3 Bar Vacuumcheck Pressure vessels MaterialStainless steel 1.4435 (316L) Notified bodyTÜV Capacity300 Ltr. ( bruto 380 ltr) Vessel sizesDia. 740x997 mm Dished topcheck Dished bottomcheck With covercheck Manholecheck DN400 Top connectionscheck OutletDN40 Max. temperature143°C Information Mounted on consolesOn wheels Floorspace0,95x1,15 m Total height2,0 m Weight360 kg Extra Specificationswith spray ball. inspection window in mannhole. SolventsDetergent & surf.CosmeticsDyes & pigmentsAPIMinerals & inorganicPlastic & polymersAgrochemicalsBiotechnology ...

General SKU039E129 MakeRichard Stihler No.5057 Year of construction1963 Mounted on legscheck Pressure Working pressure2 Bar Vacuum possiblecheck Number of vertical pressure tanks1 Main Features MaterialStainless steel Volume4480 Ltr. Pressure2 Bar Vacuumcheck Specified Features - Pressure vessel MaterialStainless steel 1.4571 (316Ti) Capacity4480 Ltr Vessel sizesdia. 1800x1200mm Dished topcheck Dished bottomcheck Manholedia. 500mm Top connections(6x) Outletdia. 100mm Max. temperature50 Degr. C. Information LocationBarneveld Floorspace1,8x1,8 M Total height2,8 MDiscountPressure vesselsRichard StihlerDiscountTanks > Pressure vesselsBrand > Richard Stihler What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barnevel ...

General SKU011U240 MakeHanag AG Oberwil No.111094 Year of construction1995 LocationBarneveld Pressure Working pressure16 Bar Vacuum possiblecheck Working pressure jacket16 Bar Vacuum possible jacketcheck Number of vertical pressure tanks1 Main Features MaterialStainless steel Volume3560 Ltr. Pressure16 Bar Vacuumcheck Specified Features - Pressure vessel MaterialStainless steel 1.4435 (316L) Capacity3560 Ltr Vessel sizesdia. 1200x2600mm Dished topcheck Top connections4x dia. 80mm Outlet2x dia. 80mm + dia. 100mm + dia. 200mm Max. temperature-30/+120 Degr. C. Half coil jacketed(80 Ltr) Information Weight1900 KGDiscountPressure vesselsHanag OberwilDiscountTanks > Pressure vesselsBrand > Hanag Oberwil What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You ar ...

General SKU011U177 MakePaul Schwingel No.8183-3 Year of construction1986 LocationBarneveld Pressure Working pressure3.2 Bar Vacuum possiblecheck Number of vertical pressure tanks1 Main Features MaterialStainless steel Volume23120 Ltr. Pressure3.2 Bar Vacuumcheck Specified Features - Pressure vessel MaterialStainless steel 1.4571 (316Ti) Capacity23.120 l Vessel sizesdia. 2400 x 4000mm Dished topcheck Dished bottomcheck Manholedia. 600mm Top connections6x dia. 100mm + 2x dia. 150mm Outletdia. 150mm + dia. 100mm Max. temperature65 °C Information Floorspace2,8 x 2,8 m Total height5,5 m Weight4800 kgDiscountPressure vesselsPaul SchwingelDiscountTanks > Pressure vesselsBrand > Paul Schwingel What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome  ...

General SKU082C465 MakeEisen- und Hüttenwerke Thale AG No.60 6731 Year of construction1996 LocationBarneveld Material Lining materialGlass - Enamel Pressure Working pressure6 Bar Vacuum possiblecheck Working pressure jacket6 Bar Vacuum possible jacketcheck Number of vertical pressure tanks1 Main Features MaterialGlass Volume2350 Ltr. Pressure6 Bar Vacuumcheck Specified Features - Pressure vessel Capacity2350 Ltr Vessel sizesdia. 1400x1200mm Dished topcheck Dished bottomcheck Manholedia. 500mm Top connections(5x) Outletdia. 80mm Max. temperature200 Degr. C. With jacket(300 Ltr) Information Floorspace1,6x1,6 M Total height2,5 M -- VESSEL HAS NEVER BEEN USED -- Weight2150 KGDiscountPressure vesselsThaleDiscountTanks > Pressure vesselsBrand > Thale What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Rea ...

General SKU065Y550 MakeFIB Leeuwarden No.1326-05 Year of construction1982 LocationBarneveld Pressure Working pressure5 Bar Number of vertical pressure tanks1 Main Features MaterialStainless steel Volume1200 Ltr. Pressure5 Bar Specified Features - Pressure vessel MaterialStainless steel 1.4401 (316) Capacity1200 Ltr Vessel sizesdia. 1000x1100mm Dished topcheck Dished bottomcheck Manhole/hand hole dia. 200mm Top connections4x dia. 25mm + dia. 65mm Outletdia. 80mm Max. temperature100 Degr. C. With paddle stirrermake Veenstra, type FR-200 Motor2,0 KW, 220/380 Volt (Ex) With variable speed drivecheck Information Floorspace1,5x1,5 M Total height3,3 M ATEX compatiblecheckDiscountPressure vesselsFib LeeuwardenDiscountTanks > Pressure vesselsBrand > Fib Leeuwarden What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new ...

-Max pressure at the end of stroke – 4000 ton -Press stroke – 400 mm -Number of stroke – 50 per minute -Max distance of stroke from the table – 1400 mm -Dimensions of slider: 1320 x 1320 mm -Bed dimensions: 1120 x 1600 mm -Bed movement by height – 20 mm -Max pressure of upper ejector – 20 t -Max stroke of upper ejector – 65 mm -Max pressure of lower ejector – 40t -Max stroke of lower ejector – 80 mm -Main motor power – 225 kW -Main motor speed – 730 rpm -Total width — 6280 mm -Total depth – 4885 mm -Total height – 8870 mm -Height over the bed – 7315 mm -Total net weight – 280 092 kg

Qty. 1 Second-hand crank hot forging press – dismantled & in storage Mfc.: Hyunjin Industry, Korea Built: 2008 Status: dismantled and in storage Force: 2500 T Total weight of the machinery: approx. 250 T

2000 Ton Sumitomo Hot Forging Press line Year 2006 Stroke 350 mm (13.78") Strokes per min 75 Shut height 850 mm (33.47") SlideAdj. 7 mm (.27") Ram size 1200 mm LR X 1300 mm FB Bed size 1320 mm LR X 1300 mm FB 4 stage transfer system Slide knockout Bottom knockout Scrap System Dual Die Changer Extra Die Shoes Billet Heater and Billet Saw Also Available This line was used by HONDA to make transmission gears, It takes a billet, cuts it to size, heats it to 1300 C then the press hits it 4 times. It can determine good from bad parts, the bad parts get sent to a quench tank, the good parts get sent into a cool down conveyor that you can pick the parts up by hand at the end. The entire system was ran by one operator.

no. of strokes:150 /min impact energy:420 kJ distance lower die block / ram gudeway:435 mm Throat:425 mm steel forging - rectangular up to:110 mm steel forging - diameter up to:125 mm power requirement:22,0 kW weight of hammer:3,9 t weight of anvil:3,0 t ram hammer weight:200 kg weight:6,9 t dimensions (WxDxH):1,1 x 2,3 x 2,4 m

Eccentric shaft for hot forging press K8548 6300T Weight, kg 27 800

Drive gear for hot forging press K8548 6300T Weight, kg 15 700

Driven gear for hot forging press 6300T Weight, kg 1300

Clutch hub for hot forging press K8548 6300T Weight, kg 7100

6500ton Open Die Forging Press HJ / Seonam (Korea) Design: Eastern European Corporation Installation: 2006/2008 Press Type: Four column push down Oil hydraulic system Nominal force (static working pressure of 320 bar): 5,000 Tons Up-setting force (static working pressure of 420 bar): 6500 Tons Daylight: 5,200 mm Stroke of Movable cross head: 2,700 mm Main Ram dia. (Center cylinder): 1 set - ￠950 mm Side Ram dia. (Side cylinder): 2 sets - ￠750 mm Return cylinder Ram dia: 2 sets - ￠300 mm Moving Table Width: 2,600×Length 6,600 mm Moving Table stroke (center to both side 2,750mm): 5,500 mm Approaching speed: 300 mm/sec Main cylinder Forging speed (2,200 tons/ 320 bar): 163 mm/sec All cylinder Forging speed (5,000 tons/ 320 bar): 73 mm/sec Up-setting Forging speed (6,500 tons/ 420 bar): 10 mm/sec Return speed: 270 mm/sec Hydraulic Main pump: 12 sets  ...

pressure: 1645 t stroke: 1000 mm dayligth: 3000 mm Control: down speed: 280 mm/sec return speed: 275/346 mm/sec distance between columns: 2520 mm total power requirement: kW weight of the machine ca.: t the machine is in very good condition optional you can buy a shifting table as well The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Nominal force 1250 ton - first stage : 260 tons, - second stage : 800 tons, - third stage : 1250 tons, Slide stroke 1250 mm Distance between table and slide 2650 mm Main cylinder dia Ø 500mm Return cylinder dia. ( two) 2xØ400mm Distance between column 1800mm Table size width / length 1250 / 3150 mm Main motor power 150 kW Machine dimensions L x W x H 16950 x 12100 x 11410 mm Weight 265000 kg Forging manipulator FS2ЕТС -2T also available 1T and 700t

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between tableand slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 E5931468 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

400 Ton Hydromec HF4000 Non-Ferrous Hot Forging Press Line MANUFACTURER – HYDROMEC YEAR – 2000 SERIAL NUMBER – 660 MODEL – HF4000 C/D MATERIAL – NON-FERROUS TONNAGE – 400 TON (4000 KN) STROKE – 380MM STROKE PER MINUTE (CONTINUOUS) – 22-35 STROKE PER MINUTE (SINGLE STROKE) – 22-45 RAM ADJUSTMENT RANGE – 100MM CLEARANCE (STROKE TO BOTTOM, ADJUSTMENT TO TOP) – 865MM SIZE OF TOOL MOUNTING PLATE – 1000MM X 1000MM MAIN PRESS MOTOR – 59 KW MAIN MOTOR RAM ADJUSTMENT – 2.2 KW CUSHION FORCE – 70 TON (700 KN) CUSHION STROKE – 40 – 110MM INCLUDES: AUTOMATED PICK AND PLACE ROBOT FULLY AUTOMATED SLUG LOADING STATION WITH FURNACE/CONVEYANCE MAESTRI C.T. 3500 4 TRACKS SLUG FURNACE (NEW 2000) , 420 KW POWER. NATURAL GAS, 950 DEGREES CELCIUS ELECTRICS PRESS CONTROLS VIRTUAL WALK Combination Lot of the following: Lot No. O233 MAESTRI Gas  ...

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between table and slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

LASCO FP 222 S hydraulic press was built in Germany by Lasco Umformtechnik GmbH. The machine has been continuously maintained and upgraded throughout its service life. In 2022, a major upgrade was carried out, which included replacing the electrical cabinet, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The LASCO FP 222 S is an extremely versatile hydraulic press designed for the production of extremely precise, repeatable and yet complex components used in the broadly defined automotive or machinery industry. Its main application is hot and cold forging. The use of a die cushio in the lower work table and the large slider stroke means that the machine can also be used as a deep drawing press. All machining processes are performed with a high press force of up to 200 tonnes, which, combined with the highly dynamic slider, guarantees the b ...

LASCO TSP 160 S forging press was built in Germany by Langenstein & Schemann A.G. (Lasco Umformtechnik GmbH). The machine has been continuously maintained and upgraded throughout its service life. In 2019, a major upgrade was carried out, which included replacing the seals, upgrading the control system, installing light curtains and adding a SIEMENS SIMATIC HMI TOUCH touchscreen operator panel. The LASCO TSP 160 S is an extremely versatile hydraulic press designed for the production of extremely precise, repeatable and yet complex parts. It is ideal for forges and industrial plants that require high press forces and high repeatability of the manufactured parts. Its main purpose is die forging, metal stamping and metal forming, especially hot forming of steel or aluminium workpieces. It also enables punching, calibration of forgings, trimming and blanking of workpieces after the forgin ...

nominal force:2500 t stroke:600 mm cycle time:13 - 18 s distance between columns:1720 mm Distance table/ram, max. stroke up, adjustment up:2600 mm table surface area:1720 x 1800 mm allowed max. force:4000 t blow die to die:5000 t ram surface:2100 x 1320 mm capacity of ejector in table:40 t ejector stroke in table:250 mm ejector surface area in table:900 x 820 mm capacity of ejector in ram:6 t ejector stroke in ram:40 mm spindle diameter:425 mm power requirement:900,0 kW weight:335,0 t Dimensions (WxDxH):3,4 x 4,6 x 9,7 m height over floor:8,3 m fully-automated forging line:to produce axle shaft

impact energy:207951 mkg ram hammer stroke:660 mm no. of strokes:100 /min impact energy:2040 kJ distance lower die block / ram gudeway:660 mm Throat:750 mm steel forging - rectangular up to:240 mm steel forging - diameter up to:270 mm power requirement:75,0 kW weight of hammer:16,5 t weight of anvil:15,5 t ram hammer weight:750 kg weight:32,0 t dimensions (WxDxH):3,2 x 1,45 x 3,45 m Mode of operation:pneumatisch

Cold Radial Forging Machine GFM SX-10 YOM: 1971/2024 CNC: Siemens SINUMERIK ONE with PLC 1500 Forging Box Number of forging hammers 4 Max. forging force per hammer 1250 kN Number of strokes 1200 1/min Hammer lenght 135 mm Diameter setting range 60 mm Forge eccentric 3,5 mm Chuck head Clamping force max. 50 kN Advance speed max. 20000 mm/min Stroke 1290 mm Workpiece rotation 35-71 1/min Workpiece lenght max. 900 mm Counter holder Clamping force max. 50 kN Advance speed max. 20000 mm/min Stroke 1290 mm Mandrel Clamping force max. 20 kN Advance speed max. 18000 mm/min Stroke 800 mm Dimensions Lenght approx. 9100 mm Width (with electrical cabinets an ...

CNC Hot Radial Forging GFM SX-13 New in 1974 / 2022 New CNC Control SIEMENS SIMATIC Machine number: 1276 No. of Hammers: 4 Forging force each hummer: 160 Ton Hammer stroke / min: 700/min Hammer lenght: 240 mm Diameter setting range: 80 mm Maximum forging diameter: Structural steel, round-cross section: Ø 130 mm square cross section: Ø 115 mm Smallest dimensions forged: Ø 25 mm Manipulator A max. displacement: 6820 mm Manipulator B max. displacement: 7150 mm Maximum workpiece length: 6000 mm Rapid speed manipulator: 400mm/sec Total connected power: 300 kW 380 V, 50 Hz Machine dimensions: Forging height over floor: 615 mm Total height pf the machinr over floor: 16 ...

CNC Radial Forging Machine GFM mod. SXL-16 Manufacture: GFM (Austria) YOM: 1974 / 2022 Machine number: 1293 PLC: Siemens S7 - Technology V4.2 with CNC Bosch Rexroth XM Numbers of Hammers: 4 Forging force: 800 Ton (200 t per Hammer) Strokes per minute: 580 Hammer length: 320 mm Maximum hammer setting scope - calculated by diameter: 100 mm Maximum diameter of forging regarding: - structural steel: circular cross section – Ø 160 mm square cross section – 130 mm - high alloy steel: circular cross section – Ø 120 mm square cross section – 100 mm Extreme quadrangle: 12 x 120 mm Maximum length of forging: 6000 mm Min and Max diameter of mounting in manipulator: 30 - 160 mm Feed of manipulator A: 6800 mm Feed of manipu ...

ZIEGLER C41-20A - air forging hammer Hammer weight: 20 kg Strokes: 270/min Lifting height: 200 mm Projection: 180 mm Cylinder diameter: 115 mm Hammermasse: 90 x 50 mm Engine power: 2,2 kW Voltage: 400 V Dimensions WxHxD: 460 x 1110 x 820 mm Weight: 380 kg Equipment: Hand - and foot operation, integrated Ambos Base optional

Radial Forging Machine GFM SXL-32 The main equipment includes: - Manipulator A - Manipulator B - GFM 32 forging machine - N° 2 loading and unloading clamps - Transport roller track Technical data: - No. of forging hammers: 4 - Forging pressure of each hammer: 500 Mp = 5,000 bar - N° of strokes for each hammer: 310 strokes/min - Rated power each forging motor: 2 x 250 kW - Hydraulic pump motor power: 100 kW - Loading - unloading pincers motor power: N° 2 x 37 kW - Hammer length: 480 mm - Maximum raw piece diameter: 320 mm - Max hammer adjustment area: 210 mm - Largest forging diameter: Non-alloyed and low-alloy construction steel: 320 mm/Ø ….. 290 mm/Ø Biggest clamping diameter in clamping head: 320 mm High and special-alloyed steels: smaller dimensions - Max workpiece length: 3000 mm - Rapid traverse spee ...

Max. diameter of initial blank: 30 mm Blank length: -Min.: 120 mm -Max.: 300 mm Max. diameter of upset flange: 60 mm Upset slide nominal force: 2500 kN Max. force on clamping slide with dies closed: 2500 kN Stroke: -Movable die: 100 mm -Upset slide (full): 220 mm -Die closing: 140 mm Slide strokes per minute: 45 Machine overall dimensions: -Length: 6050 mm -Width: 4600 mm -Height: 2260 mm Machine weight: 24680 kg

Key data: 50 kg

Say-Mak SPH 50 - Pneumatic Forging Hammer - Welded steel structure - Regular beating with valve adjustment - Pneumatic working system with 2 pistons -Hour meter - All dies and Sal-Block replaceable, Sal-Block adjustable in 8 directions - Adjustable sal block for the operator's working angle - Simple and functional automatic lubrication system for front and rear pistons - Adjustable foot pedal depending on working height and foot protection cover - 360° adjustable flanged plunger and plexiglass cover - Incl. steel foundation Specifications - Operating mode: pneumatic - Drop weight: 50 kg - Lifting height: 185 mm - Motor power: 4 kW - Weight: 1000 kg - Dimensions WxHxD: 730 x 1450 x 1750 mm

Capacity, ton 800 Movable die stroke, mm 180 Max. upsetting ram stroke, mm 380 Upsetting ram workstore, mm 250 Upsetting ram return stroke with closed dies, mm 130 Distance bentween upsetting ram and dies stroke forward, mm 140 Number of ram strokes per minute 35 Die dimensions, mm 590 x 220 x 660 Electric motor power, kW 40 Dimensions: mm 6300 x 3900 x 2850 Weight: kg app. 80800

Max. diameter of initial blank: 30 mm Blank length: -Min.: 120 mm -Max.: 300 mm Max. diameter of upset flange: 60 mm Upset slide nominal force: 2500 kN Max. force on clamping slide with dies closed: 2500 kN Stroke: -Movable die: 100 mm -Upset slide (full): 220 mm -Die closing: 140 mm Slide strokes per minute: 45 Machine overall dimensions: -Length: 6050 mm -Width: 4600 mm -Height: 2260 mm Machine weight: 24680 kg

- The largest diameter of the workpiece, mm 90 - The maximum diameter of the planted flange, mm 120 - Rated force of the landing slide, kN 6300 - The force perceived by the clamping slide with closed dies, kN 6300 - stroke of the landing slider, mm 350 - The stroke of the landing slide after closing the dies, mm 230 - The frequency of continuous idle slider per minute, not less than 42 - Power of the electric motor 45 - Dimensions, mm length 4835 width 3450 height 2880

with vertical matrix connector Max. work-piece diameter: 140 mm Max. diameter of upset flange: 180 mm Nominal force of upset slide: 12500 kN Force on clamping slide with dies closed: 12500 kN Stroke of: -Upset slide: 460 mm -Upset slide after closing of dies: 310 mm Number of continuous slide strokes per minute: at least 32 Electric motor power: 75 kW Machine dimensions: -Length: 8035 mm -Width: 4800 mm -Height: 3575 mm Machine weight: 140 tons

furnace 1200 1x1x2m t max 1200 Celsius plc auto door various size possible Industrieöfen- Fertigung und Reparatur jeglicher Art Wartung und Einregulierung von Industriebrennern Industrieöfen für Öl, Gas oder elektrisch beheizt Umfangreichen Sortiments an Feuerfeststeinen, Feuerfestmassen, Isoliermaterialen und Gießereihilfsstoffe namhafter Hersteller. Renovierungen und Instandsetzungen von Ofenanlagen Brenner einstellungen von Ofenanlagen Modernisierungen von Ofensteuerungen Umrüstu ng von elektrischen Öfen auf gasbeheizte Öfen Umrüstung alter Heizsysteme auf Rekuperation Öfen Verzinkungsofen Ve rgüteofen Anlassofen Industrieöfen Glühofen Ovens laboratory ovens industrial furnaces industrial furnace plants Industrial Furnaces high-temperature chamber furnaces hardening furnace anlageHärteöfen Annealing furnaces Conveyor belt Abg aswäscher Abkühlungs ...

Key data: 6100 kg, 970 mm

Refurbished Beche KGH 8.0 forge hammer (built in 1980) The hammer was completely overhauled in Germany. The RAM (Schabotte) is from 2013. Control System: 2025 Description of the modernisation works: Hydraulic drive - Completely disassembled in 2024, cleaned, control valves replaced New control system - Siemens S7-1500F PLC control system with touch panel RAM (U-frame) - Contact surface ground - Insert adjusted - New wedge manufactured and hammered in Test run - Hammer was assembled in 2024 and tested in 2025 Technical description: Working capacity: 80 kJ The height max. 600 mm (without swallows) The height min. 200 mm (without dovetails) Bear depth: 810 mm Bear weight: 6100 kg Scabot weight: 105000 kg Total weight: 130700 kg Total height: 7.3 m above floor level Scope of delivery: •Hammer •Documentation The Modernisationword were well  ...

- Hand & foot control - integrated ambos - solid substructure Specifications: - Hammer weight: 40 kg - Lifting height: 230 mm - Projection: 240 mm - Cylinder Ø: 140 mm - Motor power: 4 kW - Voltage: 400 V - Dimensions WxHxD: 700 x 1900 x 1200 mm - Weight: approx. 900 kg

Air steam die forging hammer : Capacity : 16 tons, Nominal mass of drop parts : 16000 kg, Impact energy : 400 KJ, Ram stroke : 1500 mm, Ram stroke per minute : 20, Distance clear between guides : 1180 mm, Ram dimensions front to back : 1500 mm, Die holder dimensions front to back : 1600 mm, Bottom die impression to floor distance : 500 mm, Steam/air pressure : 0.7-0.9 MPa, Overal dimensions : - Floor space : 4500 x 2450 mm, - Height above floor level : 7920 mm, Mass of anvil block : 325 tons, Total weight of hammer : 425 tons.

Fully Automated Forging Hammer Line (2023) SCHULER KG H 6.3 B (63 KJ) Line Description The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step Conveyor, Stahlmann Cold conveyor belt Conductive Heating System, Stahlmann, E89, 2023 Transfer Gripper Hot Conveyor Belt with Lifting Device 2 Forging robot, Kuka, KR 30-3F, 2010 Safety Fence with Safety Doors Short-Stroke Die Forging Hammer, Schuler, KG H 6.3 B, 2023 Discharge / Extraction Robot, Kuka, KR 150/2, 2010 Output Station, Stahlmann, 2010 ‍ ‍ Technical Details ‍ (2023) Short-Stroke Die Forging Hammer SCHULER KGH 6.3B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 6.3B Machine number: 119820 Year of manufacture: 2023‍ Operational parameters Working capacity max. 63 kJ Max. impact frequency 98/min Max. usable impact rate  ...

Key data: 5600 kg, 810 mm

Fully Automated Forging Hammer Line (2009) LASCO HO-U 800 (80 KJ) The complete line consists of the following machines: ‍ Tilting device, Stahlmann Step conveyor, Stahlmann Induction heating unit, ABP, EBS 345-W, 2009 Quick-release conveyor Automation unit, Lasco, 2009 2 Forging robots, Kuka KR 30-3F, 2013 2 Bases, weight each: 336 kg Conveyor belt with lifting device, safety enclosure with doors Top pressure drop forging hammer, Lasco, HO-U 800, 2009 Picking robot, Kuka, KR 150/2, 1998 Dispensing station, consisting of: Discharge conveyor and blow-off control, Manufacturer Schramm ‍ ‍ Technical Details ‍ (2009) Short-Stroke Die Forging Hammer LASCO H-OU 800 ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: HO-U 800 Machine number: 00.08175 Year of manufacture: 2009 ‍ Operational parameters Working capacity max. 80  ...

Key data: 3700 kg, 775 mm

Fully Automated Forging Hammer Line (2004) BECHE KGH 5B (55 KJ) Line Description ‍ ‍ The complete line consists of the following machines: ‍ Tilting device, Stahlmann Conductive heating system, Stahlmann, D400G21/39000 XSH, 2004 Frako reactive power compensation Automation system, Lasco, 2009 2 Forging robots, Kuka, KR 30-3F Conveyor belt with lifting device Control cabinet with higher-level control system Short-stroke drop hammer, Beche, KG H 5.0B, 2004 Discharge robot for removal, Kuka, KR 30/2, with bucket, 1999 ‍ Technical Details (2004) Short-Stroke Die Forging Hammer BECHE KGH 5B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 5.0B Machine number: 155002 Year of manufacture: 2004 ‍ Operational parameters Working capacity max. 55 kJ Max. impact frequency 99/min Max. usable impact rate 55/min Maximum ...

Key data: 3700 kg, 775 mm

Fully Automated Forging Hammer Line (2002) BECHE KG H 5B (55 KJ) Line Description ‍ The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step conveyor, Stahlmann Cold Belt Conveyor with Lifting Device Conductive Heating System, Stahlmann, E89, 2019 Heated Conveyor Belt Forging Robot, Lasco / Kuka, KR 60-3F, 2019 Central Control Cabinet Safety Fence with Safety Doors Short-Stroke Die Forging Hammer, Müller Weingarten (Beche), KG H 5B, 2002 Extraction robot, Kuka, KR 60-3F, 2019 Discharge station, Stahlmann ‍ Technical Details ‍ (2002) Short-Stroke Die Forging Hammer BECHE KGH 5B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 5B Machine number: 127050 Year of manufacture: 2002 ‍ Operational parameters Working capacity max. 55 kJ Max. impact frequency 99/min Max. usable imp ...

Key data: 2700 kg, 790 mm

Semi-Automated Forging Hammer Line (2001) BECHE KG H 4B (40 KJ) Line Description ‍ ‍ The complete line consists of the following machines: Tilting device, Stahlmann Step conveyor, Stahlmann Cold conveyor belt Conductive heating unit with 3 modules, Schneider, KEA, 2002 Frako reactive power compensation unit; - Cooling system is required - Hot conveyor belt Impulse blower Short-stroke drop hammer (forging), Beche, KGH 4B, 2001 ‍ ‍ Technical Details ‍ (2001) Short-Stroke Die Forging Hammer BECHE KGH 4B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 4B Machine number: 127050 Year of manufacture: 2001 ‍ Operational parameters Working capacity max. 40 kJ Max. impact frequency 98/min Max. usable impact rate 41/min Max. ram stroke 790 mm ‍ Weights Total machine weight approx. 58,000 kg Anvil bed 46,000 kg  ...

Key data: 2700 kg, 855 mm

Line Description ‍ ‍ The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step Conveyor, Stahlmann Cold Belt Conveyor Conductive Heating System, Schneider, KEA 303, 2002 Transfer Conveyor Short-Stroke Die Forging Hammer, Beche, KGH 4B, 1994 Discharge Conveyor with Blow-Off Control, Stahlmann, 2001 Gas furnace, Stahlmann Eccentric Press for Hot Trimming, Ruhrmann, EVR 125 H ‍ ‍ Technical Details ‍ (1994) Short-Stroke Die Forging Hammer BECHE KGH 4B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 4.0B Machine number: 941 5435 Year of manufacture: 1994 ‍ Operational parameters Working capacity max. 40 kJ Max. impact frequency 98/min Max. usable impact rate 48/min Max. ram stroke 855 mm ‍ Weights Total machine weight approx. 58,000 kg Anvil bed 46,000 kg Drive head compl ...

Nominal mass of falling parts, taking into account the mass of the upper stamp (500 kg.), Kg. 5000 Actual mass of falling parts without top stamp, kg. 5030 Effective kinetic energy of falling parts at full successive impacts, kgc m 12500 The greatest working stroke of a woman, mm. 1300 The smallest height of dies without shanks, mm. 400 Distance between guides in the light, mm. 800 The length of the woman in the direction perpendicular to the front of the hammer, mm. 1180 Steam (air) pressure before entering the cylinder, atm. 7-9 Nominal mass of the upper die, kg 500 The largest mass of the upper die, kg. 1500 The highest permissible steam temperature, ⁰C 200 weight 145-148ton, weight of anvil block 75+22 ton.

Capacity :10 tons, Weight of falling part,nominal mass of drop parts without upper instr.:9 tons, Effective working kinetic energy after blow :25000 kg mtr., Max. working ram stroke :1400 mm, Max no of blows : 30/min , Distance between slides : 1000 mm, Shut height : 775 mm , Ram size front to back :1200 mm, Bolster size front to back :1200 mm, Air pressure : 7-9 MPA , Height of instruments : 450 min., Die-holder front to back dimensions: 1400 mm, Height above floor level: 7270 mm, Hammer dimensions : 4400x10420x2700 mm, Weight (less anvil block): 73.5 ton, Weight of anvil block : 203.8 tons.

Offer 04446 Specifications: - Total width approx. 950 mm - Working surface length / web length approx. 420 mm - Working surface depth / web depth approx. 150 mm - Compression foot approx. W 120 x D 125 x H 140 mm - Total depth approx. 280 mm - Round horn approx. 250 mm - Square horn approx. 260 mm - Round hole in the track approx. 22 mm - Through-square hole in the track approx. 25 mm - Anvil height approx. 345 mm - Weight approx. 190 kg - Base frame W 520 x D 520 x H 345 mm - Weight 30 kg

Nominal weight of the falling parts: 750 kg Max. number of blows per minute: 105 Kinetic energy: 1900 kg Distance from an axis of the slider up to bed: 750 mm Cylinder diameter: 600 mm Diameter of the plunger: 630 mm Max. headstock travel: 835 mm Dimensions: -Left-to-right: 3940 mm -Front-to-back: 1430 mm Height above floor level: 3260 mm Weight: -With an anvil-block: 25600 kg -Without an anvil-block: 16600 kg
