Manufacturer : Pester Model: Pewo-pack 200 SN-K Type: Electronically/pneumatically controlled bundling / shrink-wrapping machine Application: Production of single or grouped packs. Year : 1995 Power: 1.6 kW Stacking device Film type: PE Max. film width 200 mm Min. film width 30 mm Max. film thickness 0.1 mm Min. film thickness 0.02 mm Max. reel ? 300 mm Core diameter: 70/76 mm Operating video: https://www.youtube.com/watch?v=cZdCP2Gy0hI This equipment can be part of a : Domino / Keyence / Cermac - Inkjet printing with detection -> https://www.osertech.eu/en/product/domino-keyence-cermac-inkjet-printi ng-with-detection/ Natel NM25 - Accumulation t ...

Three-jaw chuck, three-jaw lathe chuck -screwable interchangeable jaws -Chuck size: Ø 200 mm -Weight: 12 kg ...

• more information

Combined automatic pharmaceutical machine : case packer (case packing unit) + palletizer Brand : PESTER Model : SLP 2K Year : 2010 Capacity: up to 8 cartons/min Case packing: shaping, filling, taping on the case Palletizing: Kuka robot arm - Positioning, case control on pallets. Pallets 1200 x 800 and 1200 ? 1000 Sizes Case Size Mini / Maxi: 230 x 230 x 170 mm / 450 x 320 x 320 mm Max. pallet height: 1400 mm Carton size at machine input min/max : 30 x 12 x 66 mm/ 440 x 150 x 250 mm

• For single and multiple packs • 90° infeed conveyor with stacking device, max. product width 200 mm • Format range insertion max. (w x d x h) 450 x 250 x 250 mm • For PE film, film width 30 - 450 mm, film thickness 20 - 100 µm • Roll diam. max. 300 mm, core diam. 79/76 mm • Seal width max. 450 mm • Output max. 24 cycles/min, depending on the format • Shrink tunnel passage width max. 450 mm, height max. 250 mm • Control panel Lauer PCS 095 • PLC Siemens S5-95U • Enclosure with safety switches • Connection 400V/50Hz/8,5kW

The basic unit includes following modules (standard equipment): ï?  Compact and stable design in modular design ï?  All feeding systems that ensure an optimal product handling, are adaptable ï?  Control Panel with 4-zeiliger plain text display for the following: piece counter. Speedometer, hour meter, temperature monitoring, General Fault indicator ï?  Wear-free, infinitely adjustable, patented tension system ï?  Wear arm seal system by steel seal bars with more accurate Temperature monitoring ï?  Mechanical locking of the clamping bar, this precise slide clamp and sealing ï?  Product protection by security monitoring via light barriers in the Clamping range  ...

Pester Straff-banding machine type Pewo mat 450SN Bundle Packers pester PEWO-Pack 450 SN Stretchwrapper -Modified in 2016. -Memorized (max. mm): - Insert length 300, - rack width 540, - rack 250, - seal width 450, - power: 24 cycles/min. -With shrink tunnel PEWO-therm II, passage height 130 mm, machine is with new hardware and software Mitsubishi operation via touch panel and new paint in silver offers. Infeed conveyor with Stacker in the direction of the production flow with 90 ° high thrust

• For banding bottles or folding boxes • 90° infeed • Grouping by translator • Bottle infeed with 2 screws (adjustable to each other) for shaped bottles, grouped from single infeed lengthwise to 6x crosswise • With 2 format screws for shaped bottles 63.5 x 32.5 x 108 mm and 67 x 38.5 x 114 mm • Folding box infeed conveyor • Translator with one gripper each for bottle and one suction plate for folding boxes • for PE film • film width 30 - 450 mm • film thickness 0,025 - 0,1 mm • Roll diam. max. 320 mm • Output max. 50 cycles/min (packs/min), format/product-dependent • Format range product 30-100 x 30-100 x 60-250 mm [L x W x H] / pack 30-300 x 60-380 x 6 ...

Thermotunnel with semi-automatic sealing device. The machines is made in Germany with very good working condition.  ...

• more information

Pester PEWO-therm III 250 K PEWO-therm includes following modules (standard equipment): -Maintenance-free mesh conveyor belt -With frequency-controlled three-phase motor -Rotary switch for the band -Temperature controllers -Pre and post shrink zone -Geräuschoptimiererter fan and adjustable air ducts -Page radiators -Size range: 250 x 180/250 mm Technical data: -Machine execution of degree of protection IP54 -Voltage 3x400V + N + PE, 50 Hz / 60 Hz -Pluggable proximity switches IFM (standard) -Packaging material PE flat foil -Infeed height of pester machine 900-950 mm -Spout height of pester machine 900-950 mm

Pester PEWO-pack 450 stretchwrapper for folding cartons, etc., including PEWO-therm shrink tunnel and PEWO-collect packing table, carton infeed with turning device and stacker, film splicing unit, format range cartons min. 30 x 30 x 60 mm (LxWxH), max. 100 x 100 x 250 mm (LxWxH), format range collation/bundle min. 30 x 30 x 60 mm (LxWxH), max. 300 x 380 x 250 mm (LxWxH), capacity up to 50 bundles per minute, electrics 3x400V+N+PE/50Hz, power consumption 13.1 kW, operating pressure 5 bar, infeed height 840 +/-10 mm, outfeed height approx. 800-950 mm, machine floor space approx. 4000 x 2513 mm (LxW), machine height approx. 2100 mm
