Material: steel Engine: 37 kW Weight: 900 kg Length x Width x Height: 1300 mm x 1000 mm x 900 mm Applicable for production of finest plastic-powder: - finest powder without use of nitrogen - best powder characteristic: best flow behaviour, high apparent density and narrow particle distribution - low grinding temperature, in terms of optimal ducting of the air - fully automatic continous operation - simple regluation of particle size. Throughput rate : 50 - 200 kg / h. Very good condition. Are you looking for something else? Write us below! WE PROJECT AND BUILD YOUR ENTIRE PLANT EXACTLY FOR YOUR NEEDS FROM USED AND NEW MACHINES.
Stock# U2293-1 Used stainless steel contact parts horizontal hammer mill by Pallmann (Germany) type PHM 600-350. Mill has internal dimensions of milling chamber L 600 mm x W 350 mm. Top of milling chamber is manually rised. At the bottom mill has a discharge outlet through the screen. At the top of milling chamber there is installed static knife for grinding of product. Rotor has diameter 500 mm x width 345 mm. On the rotor there are 24 rows with hammers, each row consist of 4 hammers. Total number of hammers is 96. Rotor and hammers are designed in non-corrosive steel. Rotor is belt driven by el. motor 75 kW, 2975 rpm, 380/660 V, 50 hz. Mill has side feeding inlet with dimensions 350 mm x 265 mm. Product is moved into milling chamber through three screws. Screws are driven by el. motor 0.55 kW, 2800 rpm, 220/380V, 50 hz and varispeed gearbox with manual adjustment of outgoing rotatio ...
Working width_ 600 mm Working height_ 300 mm N of knives_ 3 OTHERS AVAILABLE FROM STOCK
Drives: 45 KW + 15 KW Weight: 2100 kg Dimensions: L 3.50 m x W 1.36 m x H 1.52 m;
GRANULATOR TYPE PALLMANN PS-H 1000 x 1400, 132 kW very good condition incl. 3 sets of rotor knives and stator knives incl. 2 sets of screens, 5 and 8 mm IMMEDIATELY AVAILABLE AND READY FOR USE
Stock number: U2293-2 Used carbon steel grinding/refining mill by Pallmann (Germany) model PR8. Mill has bolted rotor with diameter 795 mm and stator with diameter 800 mm. Belt driven by el. motor 100 kW, 1480 rpm, 380 V, 50 hz. Manual adjustment of gap between milling plates. Mill has mounted 5 nozzles for feeding gas or liquid inside the milling chamber. Front door bolted with central feeding inlet through feeding chute. Bottom discharge.
we sell a Pallmann granulator IPS 50x1000. Year of construction :2001. The machine is fully operational. The regrind discharge is equipped with an extraction chute. Optionally, we can also offer you other system components, e.g. Cyclone, etc. Control cabinet with input load switching is included.
Drive : 75 KW Dimensions : L 3800 mm x W 1600 mm x H 2200 mm Weight : 3900 kg.
Drive : 110 KW Dimensions : L 2500 mm x W 1300 mm x H 1800 mm Weight : 2800 kg
ID2850 Pallmann year/Bauahr 2001 70 t Impact hammer mill, electric motor 500 KW 400V, output: up to 100 tons/hour, infeed width 2000 mm, rotor diameter 1600 mm, 6 upper feed rollers Impact hammer mill, electric motor 500 KW 400V, output: up to 100 tons/hour, infeed width 2000 mm, rotor diameter 1600 mm, 6 upper feed rollers
Used mill / granulator made by Pallmann, type PS4 - 7.5. New 1972. Speed: Rotor 640
Granulator with rotor width 1000 mm, motor 37 kW, with hopper attachment and hydraulic feed slide. Knives resharpened and whole machine repainted. Very good condition. Optionally with total separator and fan for the regrind.
PALLMANN AGGLOMERATOR PFV 250/20, Average thrpughput rate depending on materials - see pdf below, Including :, AGGLOMERATOR PFV250, n.2 disks Ø250 mm., It has been working with with PET and PS -possible different die on request, HOT MELT GRANULATOR, PS-HG 400x500, constructed in Stainless steel,, granulatiojn chamber mm.500 x 400, Screen size 10 mm, water cooled, Rotary air lock (PZSL 2.0 G), pneumatic system ro separate fines, Fan conveyor system, Storage bin PFST, Control cabinet, Voltage 415 -3Ph-50Hz, Constructed in 2001, this line is offered reconditioned., Possible addition of first granulator, on separate request, capacity: around 300 kg/h with PET and PS
Refurbished plast agglomerator for sale. Trial run possible for a fee of 1500€. The fee will be charged at the time of purchase.
General SKU312X491 LocationBarneveld CEcheck MakePallmann Main Features Motor33 KW Inlet diameter120 mm Specified Features - Fine Impact Mill MaterialStainless steel 1.4552 Fine Impact Mills Turbo cone millcheck 2 Driven rotorscheck Rotor sizeInner roter ø 396 mm: outer roter 400 mm With grinding trackConidur 1,5: 2: 3 Housing dimensions ø 800 mm Inletø 120 mm Motor22 kW 400 V, 1470 rpm: 11 kW 400 V, 1475 rpm SpeedInner rotor 3000 rpm, outer rotor 1500 rpm Information TypePPS 4-120 No.139820170004 Year of construction2018 Mounted on framecheck Floor space0,9 x 2,8 m Total height1,5 m Weight1600 kgFine Impact MillsPallmannMills > Fine Impact MillsBrand > Pallmann What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine i ...
General SKU430X1346 LocationBarneveld CEcheck MakePallmann Main Features Motor150 KW Inlet diameter250 mm Width1000 mm Specified Features - Fine Impact Mill MaterialStainless steel 1.4541 (321) Fine Impact Mills Hammer millcheck 2 Driven rotorscheck Rotor size995 mm Grinding room sizeø 1000 mm Fixed hammerscheck (60) Hammer width250 mm With sieve cagecheck Housing dimensions ø 1400 mm Inletø 250 mm Motor110 kW, 380 V, 1500 rpm: 55 kW, 380 volt, 1500 rpm SpeedTurbo wheel drive speed 1590 rpm: sieve basket speed 660 rpm Information TypePPSR 10-300 No.0965.2007.0010 Year of construction2007 Mounted on framecheck Floor space4,00 x 1,545 m Total height2,85 m Weight7000 kgFine Impact MillsundefinedMills > Fine Impact MillsBrand > undefined What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for ship ...
General SKU160P705 LocationBarneveld MakePallmann TypePP 4 No.0668145 Main Features Motor22.5 KW Inlet diameter155 mm Width100 mm Specified Features - Fine Impact Mill MaterialMild steel Fine Impact Mills Turbo cone millcheck 2 Driven rotorsimpeller & co-rotating baffle plate Rotor sizeInner roter ø 396 mm: Outer roter 400 mm Grinding room sizeø 600 Inlet155 x 100 mm Motorcheck 15 kW + 7,5 kW, 380 V SpeedMax. 4100 rpm: Grinding disc 1450 rpm Information Year of construction1968 With switchgearcheck Floorspace2,1 x 1,1 m Total height0,8 mDiscountFine Impact MillsPallmannDiscountMills > Fine Impact MillsBrand > Pallmann What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in ...
- Dual-stream mill for fine wood chip production with segmented internal grinding elements. - Main motor power 315 KW. - Equipped with PALLMANN CLEANOMAT system (installed according to documentation in 2009). - Upper feed hopper with vibratory system and magnet for separation of metal elements. - Stripper. - Operating conditions of this machine: unchecked. - EX WORKS Sale. Dismantling, disconnection, loading and removal at the expense of the buyer, who must comply with current regulations on occupational risk prevention, health and safety in industrial work, providing the necessary documentation, insurance and accreditations. Auction-ID: A7-43986-14
- Knife ring virute mill for the manufacture of flat chips. - Percussion wheel motor power 250 KW. - Blade ring motor power 22 KW. - Percussion wheel rotation speed 850 rpm. - Cutting circle diameter 1200 mm. - Number of blades: 49. - Blade length 450 mm. - Maximum production up to approx. 10000 kg/h (depending on the type of wood, moisture and chip thickness). - Upper feed hopper with vibratory system and magnet for separation of metal elements. - Stripper. - Operating conditions of this machine: unchecked. - EX WORKS Sale. Dismantling, disconnection, loading and removal at the expense of the buyer, who must comply with current regulations on occupational risk prevention, health and safety in industrial work, providing the necessary documentation, insurance and accreditations. Auction-ID: A7-43986-6
- Knife ring virute mill for the manufacture of flat chips. - Percussion wheel motor power 250 KW. - Blade ring motor power 25 KW. - Percussion wheel rotation speed 850 rpm. - Cutting circle diameter 1200 mm. - Number of blades: 49. - Blade length 450 mm. - Maximum production up to approx. 10000 kg/h (depending on the type of wood, moisture and chip thickness). - Upper feed hopper with vibratory system and magnet for separation of metal elements. - Stripper. - Operating conditions of this machine: unchecked. - EX WORKS Sale. Dismantling, disconnection, loading and removal at the expense of the buyer, who must comply with current regulations on occupational risk prevention, health and safety in industrial work, providing the necessary documentation, insurance and accreditations. Auction-ID: A7-43986-7
- Knife ring virute mill for the manufacture of flat chips. - Percussion wheel motor power 250 KW. - Blade ring motor power 22 KW. - Percussion wheel rotation speed 850 rpm. - Cutting circle diameter 1200 mm. - Number of blades: 49. - Blade length 450 mm. - Maximum production up to approx. 10000 kg/h (depending on the type of wood, moisture and chip thickness). - Upper feed hopper with vibratory system and magnet for separation of metal elements. - Stripper. - Operating conditions of this machine: unchecked. - EX WORKS Sale. Dismantling, disconnection, loading and removal at the expense of the buyer, who must comply with current regulations on occupational risk prevention, health and safety in industrial work, providing the necessary documentation, insurance and accreditations. Auction-ID: A7-43986-8
