optic used for sale

Resolution X/Y (3D and 2D): 21μm/10.5μm, illumination: multispectral, multidirectional, component clearance above/below PCB: 40mm/100mm, max. inspection speed: 50cm²/s, inspection range X/Y: 450mm/350mm. Dimensions X/Y/Z: approx. 1150mm/1150mm/1450mm, weight: approx. 500kg, software: OptiCon Pilot 5.3. Including calibration tool, instructions, camera, lighting and repair software for error visualization. Computer was replaced in 2012. Documentation available.

Brand Name: GOPEL Model: OPTICON THT 600 LINE Year: 2015 Serial Number: TH-603 Notes: - The machine is in excellent condition and in working order. - No CE manuals and declaration of conformity have been provided. - The goods being sold are declared out of service and with the obligation to restore safety in the devices relating to Legislative Decree 81/08 on machine safety. - PROPERTY INTENDED FOR VAT HOLDERS.

Software: OptiCon Pilot 5.1, with documentation, camera and lighting module, 3x repair work place software for defect visualisation and 4GB RAM computer, was last maintained in 2013.

Pumping station for external system cooling, specifically for LEYBOLD sputtering systems H 3200 the sputtering is one other offer on ebay offered and is not included in this offer the facility had not made it to production, is as good as new

Automatic optimization crosscut saw: Technical data: Follow later!

Key data: 500 mm, 160 mm

Optimisation cross-cut saw OptiCut S 90 Speed - Left-hand version Max. wood entrance length 7.2 m Wood dimensions to be processed Sawing unit for large wood cross-sections with saw blade diameter Ø 500 mm Saw blade made of tungsten carbide, Z=144, WZ 20° Saw Blade Drilling 30 mm Saw blade speed max. 3600 rpm. Input lengths min./max. Widths min./max. Thicknesses/thicknesses min./max. Nominal cross-sections (without board curvature) Min. 500 - 7200 mm 23 - 160 mm 12 - 100 mm 23 x 12 mm .max. 160 x 100 mm Package size at max.9 strips per package Packet Ratio Width and Length to Thickness 160x100 mm 2:1 Fixed length min. 60 mm Performance / Positioning Moving speed of the positioning slide infinitely variable max. approx. 240 m/min. Cutting time / cutting height Adjustable The practical daily output depends to a large extent on the production  ...

Machine Details Warehouse number 1105-03634 Machine type lathe - cycle controlled Make CAZENEUVE Type OPTICA 360 Year of construction 2000 Control type CNC Control CNC NUM Storage location FRANCE HAGUENAU Country of origin France Delivery time immediately Freight base EX WAREHOUSE Technical details Turning diameter 380 mm Turning length 750 mm Control CNC NUM Turning diameter above the face sled 200 mm Turning diameter via transverse guide 280 mm Main drive motor 11 kW Spindle speeds 2 - 3000 rpm Spindle passage 54 mm Chuck diameter 160 mm Tailstock cone MK 4 Total power requirement 14 kW Machine weight approx. 2 t Information TAECH IN CNC MACHINE CAZENEUVE OPTICA 360 FROM 2000 3 BAKING FEED TAILSTOCK

DIMTER optimizing cross cut saw, type OptiCut 150

Leybold Optics H3200 it is a horizontal inline sputtering system H3200 for the separation of Cu - In-Ga layers, glass substrates, which are coated from above, run continuously in this, it is a universal system for glass coating / architectural glass coating with 3 large process chambers and 8 infeed and discharge modules 3 modules of 650 mm run side by side in the process   the plant is as good as unused, (it did not come to production, only sporadic attempts), is already dismantled and stored in the north of Brandenburg Year of construction 2009 , plant number 070817 Type H3200 Original price of the inline sputtering system (2009): 5.600.000,- € the sales price is net plus VAT incl. loading and transport for Germany Dimensions : 24,335 m x 4,30 m Weight: approx. 120 t the three process chambers are special transports incl. all parts and document ...

Cross-cut line Opticut 150 -4 4 ejections built in 2004

Newport Optical table Bravo, very good condition Find more here - / Contact us at -

Göpel Electronics Opticon Smartline The software dongle would have to be renewed at Göpel, which we can arrange Find more here - / Contact us at -

c

Newtec CELOX optical sorting line, Machine has been upgraded to the newer type CELOX in 2016, The order is based on the following specifications, Ambient temperature ± 5 – 25 ºC., Product Clean, washed carrots, Capacity: 8 to 10 tons per hour, depending on the batch, (quality and sorting), Product foreign materials The Celox cannot detect foreign materials such as glass,, wood, stones etc., Functionality:, Length: +/- 3mm (less than 1% errors), Diameter: +/- 1mm (less than 1% errors), broken: 60-65% is removed (on normal broken carrots) there will be 5-6% good, carrots among the errors, C/S shape: 85-90% is removed. There will be 3-4% good carrots among the errors, Volume: +/- 5%, -Incl. conversion of complete camera unit to new version, -9 Cameras with 8 megapixel resolution (current 2 magapixel), Cameras look at the carrots from above and below at an angle, -Better detection of roo ...

Type: OptiCoater 600 Serial number: E022210405068 Year of construction: 2020 Belt width: 600 mm Power: 3 x 400V, 50Hz, 3kW Dimensions: 1800 x 1350 x 1450 mm Weight: 456 kg

spindle diameter: 125 mm x-travel: 2000 mm y-travel: 1100 mm z-travel: SK 50 mm spindle taper: Philips 2500 digital readout: Pfillips turning speeds: 925 U/min spindle stroke: 800 mm Table: 1000x1400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ...

Control card, controller, PLC controller, optical card, optical control card, optical interface -Manufacturer: Dr. Schenk Industriemesstechnik, Optical Control Card -Type: XVP2, Optical 4160631 -Box dimensions: 280/200/H50 mm -Weight: 0.8 kg

Manufacturer: Göpel Electronic Model: OptiCon BasicLine Year of Manufacture: 2011 Type of Machine : AOI System Voltage: 230V / 50Hz Current: 10A CE Marked: Yes --------------------------------------------------------------- Find more here - / Contact us at -

Inv. Num. : 8663 Type: Opticontrol Producer: Weinig Generated: Parameters: Max. tool diameter: 300 mm Max. tool length: 330 mm

I sell an automatic pneumatic Weinig Grecon Dimter Opticut 200 Elite Built in 2006. Motor power 7.5kW Entrance table automatic 4.10m (continuous system) Exit table automatic 6 ejectors on the right outlet table. Optimization with automatic defect detection and automatic cutting diagram programming. Available the same. CE equipment. Documents included.

A horizontal boring and milling machine Scharmann is available. Spindle sleeve diameter: 120mm, travel X/Y/W: 1600mm/1600mm/600mm, speed: 1000rpm, table dimensions X/Y/Z: approx. 1200mm/1400mm, max. table load: 6000kg, column diameter: 220mm, table rotation: 360°, rapid traverse: 380mm/min, feed: 2400mm/min. Machine dimensions X/Y/Z: approx. 4500mm/2600mm/3000mm, weight: approx. 17000kg. Dokumentation vorhanden. An on-site inspection is possible.

DIMTER automatic optimizing cross cut saw, type OptiCut S75

DIMTER automatic optimizing cross cut saw, type OptiCut S50

Grecon Dimter OptiCut 304R Optimizer Length of entrance timber min. 900 mm when loading on a cross chain conveyor Wood width min./max. 40-200mm Wood thickness min./max. 15-80mm Lowering, cutting and accelerating: 0.5 – 1 sec Cutting accuracy: min. 0.8 mm, max. 1.5 mm Wood cross-sections max. 200×25 mm, 170x50mm, 80x80mm, 140×60 mm Saw blade diameter 400 x 30 mm Saw blade speed 4200 rpm. Feed max. 170 m/min Material pick-up conveyor with 6 dodgehammers Cutting Modes: 1.Cut to fixed length 2. optimization of board length to maximize efficiency, 3. removal of wood defects with chalk marking of defects Length of the entire line 21m Year of manufacture 2000

This DIMTER S50 Opticut was manufactured in 2003. A robust optimizing cross-cut saw, it features a processing length of 5 m and a saw blade diameter of 500 mm. A new Movidrive converter was installed in 2018, enhancing its performance. If you are looking to get high-quality cutting capabilities, consider the DIMTER S50 Opticut machine we have for sale. Contact us for more information about this machine.

Optimizing Cross-Cut Saw manufactured in 2018. This WEINIG DIMTER Opticut S90 features a saw blade diameter of 500 mm and a maximum cutting height of 120 mm. It accommodates input lengths from 400 to 6,300 mm and widths from 20 to 300 mm. If you are looking to get high-quality cutting capabilities, consider the WEINIG DIMTER Opticut S90 machine we have for sale. Contact us for further details.

valve dimensional inspection

Manufacturer: Koh Young Year of Manufacture: 2022 Machine Type : Pre AOI - Automated Optical Inspection System Koh Young Pre AOI systems use high-resolution optical imaging and advanced inspection algorithms to verify component presence, placement accuracy and solder paste coverage on PCBs prior to reflow. Integrating a Pre AOI station into an SMT line significantly reduces defect rates, rework costs and scrap by catching errors at the earliest possible stage in the assembly process. Find more here - / Contact us at -

Manufacturer: Koh Young Year of Manufacture: 2022 Machine Type : Post AOI - Automated Optical Inspection System Koh Young Post AOI systems use high-resolution 3D optical imaging and intelligent inspection software to verify solder joint quality, component placement and board integrity after reflow soldering. A Post AOI station is an essential quality gate in any high-reliability SMT production line, preventing defective boards from advancing to final assembly, test or customer delivery. Find more here - / Contact us at -

Used GENIUS B-640 Compact optical sorter. Principle of operation: The product is evenly distributed on the conveyor belt and scanned by cameras and / or lasers on both sides of the different control zones. A few milliseconds later, the defects are rejected in 1 or 2 separate jets by powerful air guns located at the end of the feed belt. A good product continues its way through processing. Electrical requirements Voltage: 400V 3-phase (+ neutral and protective conductor) Power: 4kVA Frequency: 50Hz Compressed air requirements Minimum pressure: 6-7 bar (90-100 PSI) (At the entrance of the sorter) Normal consumption: 400/1500 L / min Maximum consumption: 10,000 L / min Water requirements Water pressure: between 1 and 3 bar Temperature: between 5 ° C and 12 ° C

Manufacturer: Scansonic Type: AL01 Condition: refurbished, since then unused and professionally stored in the manufacturer's suitcase Wavelengths: 900 ... 1030 nm; 1064 nm, 1080 nm to 4 kW Illustrations: 2.0:1 - 2.5:1 - 3.2:1 - 4.0:1 - 5.3:1 Fiber plug: Trumpf B or Type D (LLK Auto) Laser: CW laser up to 4 kW Working range height (Z): ± 5 mm Robot adaptation: any Repaired/replaced: - Lens - Compression spring - Protective spring - Cover - Beam aperture - Shaft spring - Fiber coupling firing In addition, the device was cleaned, adjusted and force-normalized.

Sea SELEKTA.3 optical sorter

Corning 048E88-611-31-29 MIC Unitized Tight-Buffered Cable, Plenum, 48fibres,OS2. The roll weighs just under 300kg. Specifications General Specifications Environment Indoor Application General Purpose Horizontal, Vertical Riser, Plenum Cable type Tight-Buffered Product type Distribution Flame rating Plenum (OFNP) Fibre Category single-mode (OS2) Temperature Range Storage -40°C to 70°C (-40°F to 158°F) Installation and assembly 0 °C to 60 °C (32 °F to 140 °F) Operation 0°C to 70°C (32°F to 158°F) Cable Design Central Element Jacketed GRP Fibre Count 48 Number of Active Tubes 8 Subunit Colour yellow Subunit Diameter 4.40 mm (0.17 in) Tight buffer colour subunit Blue, orange, green, brown, grey, white Tensile Strength Elements and/or Armouring - Layer 1 Dielectric strength members Number of ripcords 9 Outer jacket material Flame-retardant Ou ...

Programmable focusing optics Manufacturer: Trumpf Type: PFO 33-2 R1030-1070 HA Year of Make: 2017

Optical sorting machine with material feed (via 2 stainless steel infeed hoppers and 2 electronically controlled vibratory chutes), material chute (made of specially coated aluminium), optical unit (4 high-resolution monochrome cameras with 2,048 pixels each; integrated image processing with a resolution of 0.09 mm) and blow-out system (144 high-speed blow-out nozzles with 1,400 cycles per second). The machine can be used, for example, to remove particles of different colours or foreign bodies from a material stream. Throughput: 500 to 800 kg/h (for quartz sand 0.1 - 6.0 mm). IP6X protection class for dustproof operation; incl. connection for external dust removal. Dimensions: 1.4 m wide x 1.8 m deep x 1.90 m high.

Optical Parallel Gauge Measure, Gauge Dimensions, Reference Normal MITUTOYO Series 157 Code No.: 157-903 157 - 101, 102, 103, 104 4 parts in plastic box New ! Dimensions: 170 x 90 x 35 mm

Optical Laser color sorter BEST Helius C 1200D Optical Laser color sorter

Input lengths min/max. 3000 - 5000 mm average 4000 mm Input widths min/max. 80 - 200 mm Input strengths min/max. 38 - 80 mm Timber cross-sections max. 200 x 50 Generally rectangular max. 150 x 80 mm Wood end length min/max. 700 - 1000 mm, average 800 mm Number of cuts / board on average 5 Curvature of the timber in all directions max. 10 mm per metre length Thickness tolerance +/- 3 mm Cut/cut tolerance +/- 0.8 - 1.5 mm (for wood texture with minimal resin content and even surface. min. tolerance up to 1 m fixed length max. tolerance for longer parts up to 2.5 m). Wood types: Softwood or hardwood Capacity of the system: Feed speed, max. 180 m/min. Infinitely variable Time per cutting operation, incl. brakes, 0.7 - 1.2 sec. Capping, Accelerating In order to obtain the practical output per day, it is necessary to work with one of the production ratios o ...

Optical fiber, connection technology -Dimensions: 440/280/H170 mm -Weight: 1.5 kg

Two Keyence optical LED light-band micrometers are available. Repeatability: +/-0.03µm, sampling rate: 16000 measurements/s, light source: green InGaN LED. Documentation available. On-site inspection is possible.

Power cable, solar cable, fiber optic cable, fiber optic line, data cables, LAN cables, fiber optic cables -Manufacturer: Phoenix Contact, Fiber optic cable -Type: I-VH11Y 2K200/230 10A17 8B20 HCS Rugged -Length: 83 m -Price: complete -Dimensions roll: Ø 500 x 410 mm -Weight: 10 kg

Power cables, solar cables, fiber optic cables, fiber optic cables, data cables, LAN cables, fiber optic cables -Manufacturer: Leoni, fiber optic cable -Type: Gigaline AT-V/ZN) HH 4G50/125 -Length: 130 m -Price: complete -Dimensions roll: Ø 500 x 340 mm -Weight: 13 kg

Power cables, solar cables, fiber optic cables, fiber optic cables, data cables, LAN cables, fiber optic cables -Manufacturer: Phoenix Contact, fiber optic cable -Type: AT-VQHB2Y -Application area: outdoor use -Length: 72 m -Price: complete -Dimensions roll: Ø 500 x 370 mm -Weight: 14 kg

Components per hour: 480,000, field of view (FOV) dimensions: 61.1x44.9mm², PCB dimensions: 50-533x50-609mm, PCB thickness: 0.5-4mm, max. PCB weight: 3kg, clamping clearance for PCB clamping: 3mm, component clearance under the camera: 34mm, component clearance under the PCB: 60mm. Length: 1110mm, width: 1351mm, height: 1892mm, weight: 900kg. Without loader and unloader. On-site inspection is possible.

OPTICAL VIS+NIR SORTER, increase the quality of your product with a very economical, highly performant solution., Effective separation: Removes impurities, different colors, and other contaminating materials., Sample memory: Learns from samples to separate based on texture and color., Improved quality: Enhances product quality, ideal for the recycled plastics market., Quick assistance: Fast intervention from an Italian company. 24/7 response and quick intervention and assistance from this small, versatile Italian Company., Suitable for various materials: Can sort PET, HDPE, PP, PVC, PC, ABS, PMMA, and more., Customizable: Available with 1-6 channels., NIR technology: Detects stones, glass, soil, and other dense bodies., Polymer detection: Identifies different polymers using short-waved infrared cameras., A.I. software: Learns from previous selections to improve over time., Compact size:  ...

Clamping plate, measuring plate, measuring table, optical measuring device, altimeter, measuring table -Measuring table: with optical measuring device and altimeter -Width: 695 mm -Length: 1800 mm -Height: 1775 mm -Weight: 444 kg

Power cable, solar cable, fiber optic cable, fiber optic line, data cables, LAN cables, fiber optic cables -Manufacturer: Phoenix Contact, Fiber optic cable -Type: I-VH11Y 2K200/230 10A17 8B20 HCS Rugged -Length: 139 m -Price: complete -Dimensions roll: Ø 500 x 420 mm -Weight: 14 kg

optical rotary encoder -Shaft: Ø 15 x 30 mm -Type: TS1508N67 -Number: 3x available -Price: per piece -Dimensions: 68/68/131 mm -Weight: 620 g

Optical 3D coordinate measuring machine consisting of control unit VL-350, measuring head VL-370 and base VL-360. The meter was rarely used and is in very good condition., software: Version 1.3.0.235
