magazine used for sale

4-side squaring and edge banding line Machine 1: Fixed side right, moving side left Rolling chain, feed 10 - 40 m/min Controlls NC 21 Panel thickness 8 - 60 mm Max. panel width 1500 mm Edges: coil 0,3 - 3 mm, strips 0,4 - 20 mm Entry fence for veneered panels Equipment: 1+1 Compact-twin hogger, 2 motors 6,6 kW 1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application 1+1 Free space for solid wood edges up to 2,54 m length 1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm) 1+1 Universal shaper 8,1 kW 1+1 Universal shaper 8,1 kW 1+1 Edge sander KS 10 1+1 Disc sander DS 40 1+1 Disc sander DS 40 Angular transfer to the right, TWR 24/30/12/S Panel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mm Machine 2 Machine II + infeed magazine TW ...

5-axis machining center with 2-fold pallet changer Travel x/ y/ z = 600/ 770/ 675 mm Swivel/rotary table (A/B axis) Pallet changer 2-fold Pallet size 400x400 mm Spindle speed up to 16,000 1/min Spindle power 160/ 223 Nm Tool magazine 34-fold + additional magazine 99 tool positions Tool holder HSK 63 - Control Siemens 840D sl - Additional magazine TM99 - Automatic opening/closing for manual loading and unloading - Pallets with fluid connections (coupling connections) - Electromechanical tool length device - Infrared probe Renishaw - Internal coolant supply, infinitely variable up to 38 bar - Handheld control unit - Workspace extraction - Remote machine diagnostics - Brankamp machine protection system - Hydraulic clamping of the workpieces on the pallet

aschinella details Warehouse number 1105-03380 Machine Type Machining Center - Vertical Sigma brand Type MISSION 2 Year of construction 2002 Control type CNC Control FANUC 18 M Storage location FRANCE Country of origin Italy Delivery time by arrangement Freight base from location Technical details x-path 750 mm y-way 400 mm z-displacement 450 mm Table clamping surface 900 X 400 mm table load 600 kg Tool holder SK-40 ( DIN 69871-A) Speed range 6000 rpm Spindle pitch 15 kW torque 191 Nm Spindle cooling with cooling agregat Tool magazine with TELLER MAGAZINE Places in the tool magazine 16 pieces( RANDOM) Suit bolts DIN 69872-A Control FANUC 18 M Information Accessories: NC STEUREUNG FANUC 18 M

Double-spindle machining center with swivel axis One side 5.axes with swivel bridge and rotary tables. One side 4th axis, without swing bridge, 5th axis prepared. Workspace x-axis 400 mm y-axis (tool change position) 450 (700) mm z-axis 400 mm Swivel beam/counter bearing with face toothing ----- Number of spindles 2 Spindle spacing 400 mm Spindle speeds up to 17,500 rpm Power 40/ 100% ED 25/ 18 KW ----- Feed/rapid traverse 50,000 mm/min Tool magazine 2 x 60 tool slots Tool holder HSK 63 Equipment: - Expansion of the tool magazine to 2 x 60 tool positions per spindle - Oil distributor for NC rotary table - 5.Axis for one side - Extension of machine hydraulics - Increased clamping pressure to 250 bar - Connection to central coolant system - IKZ 70 bar - Automatic loading door - Pneumatic support control - Flushing package - Tool life monitoring -Probe - Art ...

Manufacturer ARPAC Line date: 2018 new, original packed Product description: Plastic Jar, 35 jars (bottles) / Minute (per line) Packaging description: RSC Cases (regular slotted case) , tape sealed System description: PART ARPACK ARPAC developed an integrated solution for this end line packaging system. Product is received single lane, diameter-to-diameter, into an automatic cartoning machine. Cartons are pushed into the required case pack configuration by a pneumatic row pusher. Product is collated, packed into a case, and manually palletized. Labellers: Jars (bottles) arrive filled, sealed, and are already labelled One Jars are placed inside a carton, the flaps are sealed with glue and a printed label with date/lot code is applied. Once cartons are placed in case, the flaps are sealed with tape and a printed label with date/lot code is applied. Features: - (3) Print an ...

Line date: 2018 new, original packed Product description: Plastic Jar, 35 jars (bottles) / Minute (per line) Packaging description: RSC Cases (regular slotted case) , tape sealed System description: ARPAC ARPAC developed an integrated solution for this end line packaging system. Product is received single lane, diameter-to-diameter, into an automatic cartoning machine. Cartons are pushed into the required case pack configuration by a pneumatic row pusher. Product is collated, packed into a case, and manually palletized. Labellers: Jars (bottles) arrive filled, sealed, and are already labelled One Jars are placed inside a carton, the flaps are sealed with glue and a printed label with date/lot code is applied. Once cartons are placed in case, the flaps are sealed with tape and a printed label with date/lot code is applied. Features: - (3) Print and Apply Bar Co ...

Machine type Machining center universal BAZ Manufacturer Heller Model MCS-H / U 300 Year of construction 2002 Condition good (used) Specifications Bright MCS-H/U 300 Year of construction: 2002 Control: Siemens 840 D Workspace: Longitudinal stroke X-axis 1000 mm Vertical stroke Y-axis 800 mm Transverse stroke Z-axis 1100 mm Lifting position longitudinally to the center of the table MCS-H X-axis +500 to -500 mm Lifting position vertically over. Palettes. MCS-H Y-axis +120 to +920 mm Lifting position transverse to the center of the table MCS-H Z-axis +200 to +1300 mm Guidance system: Linear compact roller guide version Size 55 Transfer elements: Accuracy Ball Screws Diameter x Slope Diameter 50 x 20 mm Feed drive system: Three-phase servo motors Closed design Feed forces: X-axis at ED S3-40% 15000 N Y-axis at ED S3-40% 15000 N Z-axis at ED S3-40% 20000 N Positio ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² //  ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² // 16.4/ ...

I. Working capacity -Faceplate diameter 2000 mm -Workpiece max. diameter 2200 mm -Workpiece max. height: -under the cross rail 1850 mm -Workpiece max. weight 20 tons II. Movable cross rail : - Stroke on the column 1600 mm - Rapid moving speed 400 mm/min - Slow moving speed 10 mm/min III. Faceplate main drive in the turning mode. -Main drive motor power 60 kW -Faceplate speed range 250 rev/min IV. Working support: -Ram stroke (Z axis) 1500mm -Ram section 250x250 mm -Ram/taper ISO 50 -Tool magazine, tool number 16 (left tool magazine with milling tools and right tool magazine with turning tools or mixed) -Milling shaft drive motor power 37 kW -One tool holder max. Weight 30-70 Kg -Milling spindle speed 1 - 2000 rev/min V. Feeds -X, Z axes working feeds 1 – 6.000 mm -C – axis feeds (faceplate-milling mode) 0,001 + 2, 7 rev /min -Rapid feeds 10.000 mm/min  ...

Automatic hobbing machine make MORAT type B 9for milling gears with spur toothinggr. workpiece diameter Magazine guide: 20 mmGr. workpiece diameter without magazine guide: 70 mmkl. Workpiece diameter: 1.5 mmgr. milling length: 40 mmgr. number of teeth to be milled: up to 360kl. number of teeth to be milled: 5Gr. Division: Module 1kl. Division: Module 0.1Pliers tension: 0.5 - 12 mmMain engine power: 0.5 hpPower return motor: 1/6 hpPower magazine engine: 1/6 hpWeight approx: 400 kgWith- compl. Change gear kit- 1 slider insert each- 1 additional gearbox for mehrgg. snails- 1 spindle insertdespite year of construction in very good, well-kept conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your querie ...

GeneralTurn- mill machining centre; Control: Siemens sl Operate3G without ShopTurn appr 2 channel Tool magazineNumber of tools38 Max. tool length250 mmMax. tool diameter70 mmMax. tool weight3 KgB-axis Turning-milling spindleSwivelling range+/- 120 degreeSpeed range B3100 rpmAngular value, min.1 degreeTurning-milling spindleSpindle taperCapto C5 Drive power (100% DC)5,5 kWSpindle speed-20000 rpmDrive power (40% DC)7,5 kWTorque (100% DC)22 NmTorque (40% DC)30 Nmangular value, min.5 degreelocking moment700 NmB-axis counter spindlePositioning angle B3-axis, in 5 degree steps0 - 225 degreeSpeed range B340 rpmSlide 3Longitudinal stroke665 mmRapid traverse Z36 m/minSlide 1Longitudinal stroke454 mmTransverse stroke380 mmRapid traverse in X40 m/minY axis, vertical+/- 105 mmRapid traverse in Z50 m/minRapid traverse in Y40 m/minHeadstock, rightClamping chuck Ø140 mmSpindle bore38 mmSpindle diametr ...

GeneralUniversal Milling Machine; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal650 mmCross520 mmVertical475 mmFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgTechnical DataType of main driveAC Drive power (100% DC)30 kWDrive power (40% DC)46 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minSpindle speed 15,000 rpm, 200NmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring sy ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens Sinumerik ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minIntegrated motor spindle speedMASTER®Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTorque (40% DC) 130 NmSpeed range - 20000 rpmSpindle taper HSK-A 63 DIN 69893Clamping System HSK-A 63NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationClamping pneumatic, two circuitsClamping pneumatics, 2 clamping circuits for standard machineTool clamping for HSK-A63Tool clamping HSK-A63 accordi ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperSK40 Tool holder DIN ISO 7388-1-A Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 ...

CNC Universal Bed Type Milling Machine Condition very good –11000 operating hours only Inspect under power IS POSSIBLLE Manufacturer Soraluce Model TA-A 25 Year 2018 Control Heidenhain TNC 640 Table size 2700 x 1000 mm Table load max. 6700 kg T-Slots 6 x 22 H12 Reference slot 1 x 22 H8 Distance between T-Slots 140 mm Travels Longitudinal travel X 2500 mm Vertical travel Z 1250 mm Cross travel Y 1200 mm Through the two horizontal positions forward of the automatically swiveling milling head the vertical machining can be extended by 500 mm (up to 1750 mm). Feed thrust X/Y/Z 10000 N Rapids X/Y/Z 25000 mm/min. Average Acceleration 2 m/s2 Automatic indexing milling head Number of swivelling positions 0.001° x 0.001° Positions in ...

Can filling line capacity: approx. 24,000 cph Filling Product: Soft drinks Can size: 330 ml and 500 ml standard cans Can Type: 211/202 consisting of: 1. Can depalletizer King with automatic can infeed system with Siemens S7 PLC including can table, pallet magazine, sheet removal system the depalletizer is fixed for the following pallet dimensions: 1.180 x 1.250 mm 2. Can rinser Transtech Hysek to rins new cans with filtered water infeed height: approx. 2,500 mm Outfeed Height: approx. 1,200 mm 3. Can filler and seamer KHS / Ferrum - Filler Innofill EMD 76 with 76 filling valves blocked with - Can seamer Ferrum type: F708G with 8 seaming stations the filler and seamer will be complete reconditioned in our workshop including new electric control panel with PLC Siemens S7 including Danfoss frequency inverter including beer pressure regulating valve including CIP  ...

GeneralHorizontal Machining Centre in travelling column construction; Control: 3D Control Siemens 840D solutionline operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minRapid traverse longitudinal/transverse/vertical60/60/70 m/minWorking area 1Longitudinal630 mmCross800 mmVertical850 mmPackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axis)Main driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range -12000 rpmSpindle taper HSK-A 63CabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet changerTable surface 500 x 500 mmCentre bore 50 mmTool magazine, wheel, 63 pockets HSK-A63Tool magazine wheel magazine (1 wheel) with 63 tool pockets HSK-A ...

CNC-controlled erosion machine for the processing (erosion, grinding, polishing) of PCD tipped tools up to 400 mm diameter and 400 mm length, according to disc-electrical-erosion processes for use in service and in production., Accessories:, Total enclosure,, Software path management,, Software end mill (207/208),, Software disc-shaped workpieces on the front side (221/222/223/224),, Software profiled workpieces (233/234/239/240),, Software hogger, hogger profiled (255/256/257/258/260/261/262/263), Software for disc-shaped workpieces (264/265),, Software for end and joint milling cutters (267/268/277/278),, Software step tools (271),, Software scoring saws (299),, Software saws flat tooth (301), Software saws one sided with bevel (302/303),, Software saws alternating teeth (304),, Software saws trapezoid trapezoid tooth (309),, Software saws flat roof tooth (310),, Software saws flat-tra ...

Automatic 3D wire bending machine was manufactured in Poland in 2022. The machine is used to automatically bend cut wire with a diameter of 4 to 8 mm. The structure made of thick-walled steel profiles, together with high-quality components, guarantee high bending precision and reliable operation. The automatic wire bending machine is equipped with a bending head with carriage and grippers and a wire feeding module consisting of a cut wire magazine and a selector mechanism. The workpiece taken from the magazine with a capacity of 150 kg, is fed via the wire selector mechanism into the feed channel, where it is pushed into the bending head and processed. At the end of the process, the bent wire falls into a receiving hopper or support table. All the capabilities of the wire bending machine are controlled by an installed PLC with an intuitive interface, taking care of the performance  ...

Manufacturer: Homag mit Doppelenprofilerformatteil, Type: KFL 23/03/27/PU/30+ZHR 05, Year: 2000, Program: NC 21, Control: Homatig, Min-max edge material mm: 0,5-3,0, Work piece width min-max mm: 250-2600, Min.-max. workpiece length in mm: 150-1300, Min.-max. workpiece height in mm: 10-55, Edgeband height max mm: 60, Min-max feed m/min: 30, Finished product: Fronten Küche, Axis control: yes, Infeed table: yes, Einlauflineal gesteuert: yes, Premilling: Schutzfräsen/zerspanen/zerspanen, IR zone: yes, Coil magazine: 2 X 24 fach, Strip magazin: no, Min.-max. batten magazine mm: no, Mitre stations: yes, Pre-milling: yes, Bevel milling: yes, Radius milling axis adjustment: yes, 2 motors: FK 13/6 fach, Grooves, slewable-controlled: 2, Radius scraper: yes, Type of scraper: yes, Scraper with axis adjustment: yes, Cleaning nozzles: yes, Bonding part EVA: PU Verleimteil, Number of tools per tool-m ...

x-travel: 2000 mm y-travel: 1120 mm z-travel: 1000 mm control: FANUC 18 I MB numbers of pallets: 2 pallet size:: 1000 x 1000 mm max. workpiece weight: 2000 kg Spindle RPM: 6000 1/min spindle drive: 22/26 kW max. torque on the spindle: toolpiece magazine: chain magazine: 60 Stück rapid travel x/y/z: 12 m/min distance spindle /table: 75 - 1195 mm total power requirement: 68,46 kVA weight of the machine ca.: 27 t dimensions of the machine ca.: m Horizontal machining centre with: - CNC control FANUC 18iMB - 2 x 1000x1000mm pallets - B-axis with 1° indexing - IKZ - high cooling through the working spindle & external 30-70bar - 60-fold tool magazine ISO 50 - Chip conveyor - CE The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 4500 mm swing diameter: 5000 mm turning height: 2645 mm Control: Siemens 840 D total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Equipment: CNC control Siemens Sinumerik 840 D Direct measuring system C-axis with extension of the workpiece measurement Hydrostatic guidance of the linear axes Workpiece measurement Tool measurement Tool and process monitoring ARTIS CTM system Workroom surveillance with video camera (at the support) Processing heads with automatic tool clamping UWFK 500 Nm, +/- 90° manually pivotable Various tool holders, type 300.2 Tool magazine 24 to 72 Platu magazine pick-up plate Loading crane for the tool magazine, load capacity 500 kg Loading device with HSK, capto-, KM tool holder Machine protection device Automatic cover of the chip chute Working area protection completely closed Preparation for installing a ...

SAMAG MFZ 2-2 CNC milling machine was built in 2005 in Germany. This specially designed machine for the automatic machining of workpieces made of metallic materials has been equipped with two high-performance spindles and two work tables with a rotary axis, allowing for simultaneous machining of a part and loading/unloading of another. This solution maximises production efficiency and shortens production times, making the machine significantly distinguishable from other milling machines on the market. The machining, characterised by high quality and precision, is performed in automatic mode or in the setting up mode, using rotary tools taken from a capacious magazine. During its service life, the SAMAG twin-spindle milling machine has worked around 40000 hours and has been continuously serviced. The total weight of the machine is approximately 22 tonnes. Technical specifications of ...

TORNOS MICRO-8 CNC turning centre built in 2008 in Switzerland is distinguished by its extensive machining capabilities, sturdy design made of the highest quality cast iron and compact size. The machine designed for ultra-precise machining of workpieces with a maximum diameter of 10 mm is equipped with two reliable spindles to maximise production efficiency in any production facility, even during the most demanding challenges. The main spindle and counter spindle with integrated thermal control, retractable collet and ceramic ball bearing run on guides with increased rigidity. Both spindles are powered by reliable FANUC motors, ensuring that the necessary power is supplied for the versatile use of all the cutting tools located in the 20-position linear magazine. The arrangement of the tools in the magazine has been made in such a way as to allow simultaneous machining on the main spin ...

GeneralVertical Machining Centre; Control: 3D control Heidenhain iTNC 530 Technical DataFeed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal885 mmCross600 mmVertical600 mmMiscellaneousClamping SystemHSK-A 63 Colour Floor space/WeightDimensions (L x W x H)4,9 x 4,3 x 3,2 mWeight approx.12000 KgCabineFull protection cabinDMC 75 V linear in 5-axes-versionAdditional price DMC 75V linear in 5-axes-version - motion in X=885mm und Z=600mm - spindle speed up to 18.000rpm, - tool-taper HSK-A 63, - swiveling range B-axis +10° to -110°, - swiveling speed B-axis 50rpm, - max. torque 750Nm / 553ft/lbs - clampiTool magazine 150 pocketsTool magazine 150 pockets Tower type magazine Only available for HSK Tool holders. (differently from standard)Number of tools 150Preparation measuring probe TS640 ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmCross600 mmVertical600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMiscellaneousClamping SystemDIN ISO 7388 CabineFull protection cabinCoolant supplyMulti-jet unit at horizontal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pump output: 40 l/min / 10.4 gallon/min at 2 bar / 29 psi for horizontal head (theoretical pump performance) coolant tank capacity: approx.NC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Table surface 400 x 400 mmTool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets SK 40 or ...

Working area 1Longitudinal500 mmCross450 mmVertical400 mmGeneralUniversal milling machine, with compound Guideway construction New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataType of main driveAC Drive power (40% DC)20,3 kWDrive power (100% DC)14,5 kWSpeed range20 - 14000 rpmSpindle taperSK 40 DIN 69871 Feed rate longitudinal/transverse/vertical-30000/-30000/-30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minMiscellaneousClamping SystemDIN 69872 Floor space/WeightDimensions (L x W x H)4,15 x 3,98 x 2,75 mWeight approx.4500 KgSwivel Rotary Table, simultaneousSwivel Rotary Table for simultaneous machining swivel range -5 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformation Not available with NC-Divider EA 410!Table surface 630 x 500 mmCentre bore 30H6 mmMaximum load (table cen ...

HAAS VF-1 CNC vertical machining center built in 2014 in the United States is distinguished by its excellent milling precision and accuracy, making it able to stand up to even the most intensive production requirements. This highly efficient and reliable machine features a robust, steel design with compact dimensions that effectively dampens any vibrations and ensures maximum stability of the machining process. Behind the sliding door, there is a large work area with a T-slot table, a 20-position tool magazine and a powerful spindle. All tools taken from the magazine are continuously measured by a measuring probe to prevent damage or tool breakage. The HAAS VF1 vertical milling center is also equipped with an intuitive HAAS CNC control that allows the creation of machining programmes in just a few steps. The VF-1 CNC machining center weighs 3539 kg. Technical specifications of the  ...

RAFAMET KCI 320/400N CNC vertical turret lathe manufactured in 2011 in Poland, can perform complex production programmes on large-size workpieces, thanks to one turning head and three milling heads set at different angles. The machine, with its compact frame structure made of high-quality grey cast iron, is distinguished by its high geometric stability, high rigidity and excellent vibration damping. The CNC vertical turret lathe KCI 320/400N performs precision turning, milling, drilling and boring of cylindrical, conical and curved surfaces with the aid of the applied heads. One of them is a special milling head (offset), used to perform drilling and milling operations with the position of the tool axis offset from the spindle axis in a direction parallel to the slide travel plane. On the other hand, the turning head allows to mount CAPTO turning tools in horizontal and vertical socke ...

Suitable for automatic cutting and surface grinding of carbide and HSS rods with high precision for standard and Special solutions Accessories: Total enclosure,, Loading magazine for tools up to 350 mm long,, automatic feed (hydro-pneumatic),, Rapid traverse adjustable via touch panel,, Automatic fire extinguishing system Kraft & Bauer FB 703,, Length positioning freely programmable,, Control Siemens SPS-S7 300,, Preparation for connection to central coolant system., Workpiece diameter with loading magazine: 3 - 20 mm, Workpiece length without loading magazine: 3-32mm, Workpiece length: 3-150mm, Spindle speed grinding spindle: 2000 rpm,, weight: approx. 1,700 kg, Dimensions L x W x H: 1900 x 1500 x 2400 mm, colour: Grey

Dn Solution Nhp 5100 - Continuously controlled 4-axis horizontal CNC machining center Fanuc 31i-model B -apc 2 Stations - racing X730 -60 Random Tool Places - Iso 50 electrospindle with double contact flange, oil cooled, 15000 rpm - Pallet capacity: 500 kg -External air blow Adjustable m” function -Internal refrigerant supply at 70 Bar - preparation of measuring probe for zeroing of piece with Renishaw Rmp60 cycles (radio transmission) -data Server 2gb, Fanuc Aicc 2 Software (High Speed ​​For 3D Molds And Figures, 1ooo Blocks Ahead) -communication with ports and USB + Ethernet - Carpet Chip Conveyor Belt Steering Unit: FANUC 31I-MODEL B X Axis Runs: 730 Y Axis Strokes: 730 Z Axis Strokes: 880 Board length: 500 Board width: 500 Max Piece Dimensions Length x Width x Height Table: D.800x10900 Spindle Table Surface: Tapped Holes Max Piece Spindle Weight: 500 kg  ...

Key data: 800 mm, 800 mm, 550 mm

CNC Vertical 5-Axis Machining Center with 6-Fold Pallet Station Hermle C 42 U Year of construction 2014 Heidenhain iTNC 530 CNC 2-Axis NC Swivel Rotary Table: Table rotation axis C-axis 360° Tabletop swivel axis A-axis +130°/-130° Number of pallets in the system: 6 Pallet clamping surface 400 x 400 mm Pallet load max. 450 kg Longitudinal travel: X 800 mm Transverse travel: Y 800 mm Vertical travel Z 550 mm Rapid traverses up to: X/Y/Z 45,000 mm/min. C 65 rpm. A 25 rpm. Spindle drive power: 10/20 kW AC Spindle speeds: 20 - 18,000 rpm. Spindle torque max. 180 Nm Tool magazine positions: max. 85 (42 ATC + 43 additional magazine) Tool holder: HSK-A63 Tool Ø with/without adjacent tools: max. 90/125 mm Tool length: max.300 mm Tool weight: max. 8 kg Chip-to-chip time: 4.5 sec Accessories: 5-axis machining with 2-axis NC swivel rotary table. Pallet ...

Type: VSP 50 CNC Parameters: 11750 mm, 2000 mm Manufacturer: Tos Description: The machine is in good technical condition, after agreement the possibility of testing. Main dimensions maximum and smallest distance of the spindle axis from the stand guide: -version without tool magazine 2500/500 mm -version with tool magazine 2500/600 mm maximum and smallest spindle end distance: -from bed guide 1480/380 mm -from the base of the machine 1860/760 mm headstock adjustment 2000 mm adjustment of the headstock on a machine with a tool magazine 1900 mm arm adjustment 800 mm Sleigh adjustment: -version with one bed 1000 mm -version with two beds 4500 mm -version with three beds 8000 mm -version with four beds 11500 mm Maximum drilling diameters: diameter of drilling fully into steel with a strength of 600 MPa 50 mm diameter of drilling completely into cast iron with a strength o ...

Pressing force 300 kN (30 t) Tools A, B, C, D Number of stations in the turret 6 (size D) Number of rotary stations 3 Max. number of tools 60 of which rotary - continuously 360° 30 Maximum punch diameter (size D )– separate 81 mm Maximum punch diameter in XMTE4M magazine 4 x 31.7 mm Maximum punch diameter in XMTE6M magazine 6 x 24.0 mm Maximum punch diameter in XMTE10M magazine 2 x 24.8 x 12.7 mm Working range in Y axis (with Multitool) 1300 mm Working range in the Y axis (single tool) 1250 mm Working range in the X axis (with Multitool) 2550 mm Numerically controlled stroke depth 0.1 – 31 mm Automatic repositioning of clamps in the X axis up to 10,000 mm Max. positioning speed in axis Y+X 80 m/min. Axis acceleration 10 m/sec² Number of strokes – ( step 1.0mm ) 1000/min USB port 6 Weight 7800 kg Max. jaw opening 11 mm Max. stroke 31 mm Power supply 3 x 400 V/50 Hz Machine power 8 ...

Cartoner, make Mohrbach, type MB PCT, year 2015, Possible folding box formats:, 92 82 95mm and 92 82 75mm, Function description, Machine for erecting and gluing boxes of flat blanks, as well as filling the boxes, lid molds and lid closing., The magazine supply for the cardboard blanks is monitored by 2 photocells. One is used to warn, at minimum cutting and the second, the machine switches to malfunction when only a few are left, There are blanks in the magazine., A cardboard blank is removed from the inclined magazine by means of a vacuum feeder, into which, Transport guide rails stored and with feed bars horizontally over the folding tool, transported. Here, the blank passes the glue station, where hot glue is applied to the cardboard blank, is applied., After the blank has been transported over the folding tool, it becomes vertical from the, working push-in ram pushed through the  ...

Description: SW BA 40 Vertical moving column machining center with swivel bridge, YOM 2000 CNC control SIEMENS 840D retrofit in 2014 WORKSPACE X-axis travel: 3300 mm Y-axis travel: 620 mm Z-axis travel: 800 mm (only with the swivel bridge dismantled) TABLE Clamping surface: 3500 mm x 650mm Clamping surface with dismantled swivel bridge 1600x650mm SPINDLE Speed ​​range up to: 10,000 rpm Tool holder: ISO SK 40 FINAL DRIVES Rapid traverse: 25000 mm/min TOOL MAGAZINE Magazine type: chain magazine Number of tool positions: 60 ELECTRICAL CONNECTIONS Connection voltage: 400 V Mains frequency: 50 Hz z-motion: 800 mm, x-motion: 3,300 mm, y-motion: 620 mm, control: Siemens 840 D, retrofit 2014, table surface area l x w : 3500x650 mm, taper: ISO SK40, toolchanger positions: 60, turning speed range: 1,000 rpm, rapid motion: 2,500 m/min, weight approx.: 17,500 kg, Approx. Onsite Dimension. ...

Description: Machine information : Machine on: 18573 h Running time: 6735 h Cutting time: 6460 h CAPACITIES X axis travel: 1300 mm Y axis travel: 650 mm Z axis travel: 600 mm Table surface: 1450 x 650 mm Table load capacity: 1300 kg Distance spindle nose to table: 125-725 mm Distance table/floor: 900 mm SPINDLE Drive system: GEARBOX Spindle speed: 6000 rpm Spindle nose: BT 50 Motor power (continuous/30 min): 15/ 18.5 kW Motor torque: 381 Nm MOVEMENTS Rapid feeds for X / Y / Z axes: 30/30/24 m/min Working feed (cutting): 10 m/min Ball screw dimensions: diam. 45 x pitch 10 PRECISION (VI 3441) Positioning (P): 0.012 mm Repeatability (Ps): 0.006 mm TOOL MAGAZINE Tool changer: RANDOM Magazine capacity (standard): 40 tools Max. tool diameter (adjacent pocket empty): 80 (150) mm Maximum tool length: 300 mm Maximum tool weight: 15 kg OTHER Compressed air requir ...

Description: Type of work Drilling Routing X axis working area 4250 mm Y axis working area 1500 mm Working Table Pod and Rail Main Electrospindle power 11 KW Number of controlled axes 4 axes Total number of drilling spindles 25 Total number of tool changer positions 26 X axis work area 4250 mm X axis travel 5050 mm Y axis work area 1500 mm Y axis travel 2150 mm X axis movement speed 80 m/min Y axis movement speed 60 m/min Z axis movement speed 20 m/min No. working fields 2 Working table yes Working table Pod and Rail No. of Rails 10 Pod Position Indicators yes Vacuum pump yes No. pumps 2 Single capacity 100 m3/h Boring units 1 BORING UNITS 1 Unit : top Vertical Boring Spindles : 25 Router Spindles 1 ROUTER SPINDLES 1 Unit : top No. controlled axes : 4 Motor power : 11 kw r.p.m. : 24000 RPM Grooving unit 1 GROOVING UNIT 1 Unit : top Grooving unit : yes Unit : Fixed for Grooving in X Max.  ...

For sale a Homag cnc wood center from 1996. The machine is mechanically functional, the software has been damaged, if someone has access to the software, it will be easy to handle. Lots of spare parts for the machine. More information by phone. CONTROL SYSTEM • NC Homatic, NC 81 PLC based system • No. 4th steering axis (x, y, z, c) - 360 ° rotation • Maximum speed of movement: - Axes X-Y 80 m / min - Z axis 30 m / min TECHNICAL DETAILS • Piece length: - max 3.700 mm for single processing - max 1.250 mm for alternative processing • Max workpiece width 1,200 mm • Element thickness: - with edge banding max. 40 mm - without gluing max 60 mm FLAT WORK TABLE with a retractable block and the possibility of mounting lockable lowering devices on parts • No. 8 front stops (4 + 4) • No. 4 return stops (2 + 2) • No. 4 side stops (2 + 2) • No. 12 Locking t ...

x-travel:730 mm y-travel:850 mm z-travel:1100 mm control:MSX 711 MAPPS IV Spindle power:22 / 18,5 kW Spindle RPM:12000 1/min Tool magazine:120 HSK-A 63 max. tool diameter:70 mm Max. Tool dia with free space next in magazine:140 mm max. tool length:480 mm max. tool weight:12 kg rapid travel x/y/z:50.000 mm/min A-axis (5th axis) pivoting table:+30° -120° ° Rapid Rpm B-axis (rotary table):50 1/min Rapid feed A-axis (tilt axis):20 1/min Pallet changer 2x:500 x 500 mm max. workpiece weight:500 kg workpiece - installed height:700 mm max. workpiece diameter on pallets:700 mm total power requirement:63 kVA weight of the machine ca.:21 t dimensions of the machine ca.:6,0 x 6,1 x 3,3 m Number of coordinate systems:300 Memory:1 MB Registered Programs:1000 Coolant through spindle 50 bar with filter:Frascara Fast state of the art 5-axis machining center with twin 500mm pallet changer, full A- an ...

We offer the labeler after comprehensive overhaul and modernization (including cabinet). The machine is designed for bonding three paper labels on glass bottle. Implementation of fully stainless steel. Labeller is equipped with two stations: - adhesive label front, neck and back label. Scanning system and label transfer is based on the pallets, which select a label from a magazine, transfer it onto the gripper drum and then onto bottle. The machine is extremely stable and reliable. Support comes down to refill glue and charge labels into magazine. Capacity: max. 24 000 b/h. We provide 1 set of equipment designed for a customer bottle. Machine has full 12-month warranty.

5-axis controlled milling centre Control: E 160 CNC Work piece clamping: 2 axis cradle type with tool-taper clamping Indexing of work piece cradle (A/B) full rotary and tilting controlled Traverses: X 1050 mm Y 420 mm Z 420 mm Spindle motor rating: 9 kW Spindle speeds to: 4000 rpm Gear steps 2 Torque: 450 Nm Pick up magazine tool positions: 15 with 2 places for extra large tools Tool taper: ISO 40 Equipped with: 2 Axis clamping system for parts, taper ISO 50; Vertical milling head ISO 40; Full guarding; Pick up magazine for 15 tools; VERY LITTLE USAGE AND ONLY WITH CUTTING OILS; Excellent

For sale we offer an Amada EML 3610NT punch-laser combination machine. The offered machine is used and has 4657Bh. technical data: combined laser/turret punching press EML Z-3610 NT, Y.O.M. 11/2014, 45 tool stations, laser power 4 kW, operating hours: laser/resonator hours: 4657h, control type: AMNC-F, with resonator unit Amada/Fanuc AF 4000i-C, fabrication no. L14x40295, refrigeration & refrigeration unit, flue gas and laser dust filter system Herding MP2 -) right-sided automatic plate magazine LKI AS III MP, Y.O.M. 2015, machine weight approx. 12,000 kg -) left-sided vacuum acceptance & stacking device / single sorting PR 3 300 L 2P, Y.O.M. 2013, power consumption 8.5 kW, weight approx. 4,800 kg Basic installation approx. 20 x 10 m, total H (magazine) approx. 6 m The price is only valid for the machine, without dismantling, transport and commissioning. If you have any  ...

Ultrasonic banderolier ATS US 2000 AB; good condition; maintained and verified by ATS Customer Service; Bandwidth 30mm; Frame 360x260mm; extendable large roll magazine; Automatic or foot operation. Ultra sonic banding machine ATS US 2000 AB; good condition; cleaned and checked by the support of ATS; band width 30mm; Frame 360x260mm; big size magazine; automatic or foot switch.

The vertical milling center FADAL VMC 15XTL was manufactured in 2007 in the United States by the FADAL brand. The machining center is digitally controlled by Fadal. It has a table size of 870 x 400 mm. The milling machine is designed for processing materials weighing up to 340 kg. It is equipped with a magazine for 21 tools. The spindle speed of the machining center, on the other hand, reaches 7500 rpm. Technical parameters of the FADAL VMC 15XTL CNC milling machine - CNC control: Fadal - working table length: 400 mm - working table width: 870 mm - maximum table load (evenly distributed): 340 kg - number of tools in the magazine: 21 pcs. - spindle drive power: 5.6 kW - maximum rotary speed of the vertical spindle: 7500 1 / min. - minimum distance between the spindle and the table: 101.6 mm - maximum distance between the spindle and the table: 609.6 mm - travel length in th ...

MORI SEIKI SH-500/40 Horizontal Machining Center was built in Japan in 1999 by MORI SEIKI CO., LTD. The machine is equipped with a numerical control type MORI SEIKI MSC-502. The milling machine has a table size of 500 x 500 mm and processes workpieces weighing up to 500 kg. The travel range of its X, Y, Z axes is 630 x 600 x 650 mm, respectively. The machine spindle rotates at 12,000 revolutions per minute. The milling machine is equipped with a magazine for forty tools with a maximum tool diameter of 150 mm, length 360 mm and a weight of 12 kg. The milling center is offered at a price with different types of holders. Technical parameters of the MORI SEIKI SH-500/40 CNC milling machine - CNC control: MORI SEIKI MSC-502 Travel range: - X axis (table travel length): 630 mm - Y axis (vertical movement of the spindle head): 600 mm - Z axis (cross table movement): 650 mm - distan ...

Mesh Welding Machine Width: 1200 mm Length: 2000 mm Suitable for: Industrial products Consist of: -double magazine -line wire magazine of 2000 mm

Capacity: 4.000 crates / h (at palletizer / depalletizer) Presently equipped for: Bottles: 0,50l GdB Kropfhals 0,70l Zwiebelhalsflasche 0,75l Heilwasserflasche 1,00l GdB Leichtglasflasche 1,25l GdB Leichtglasflasche Crates: GdB crates with 12 bottles, short side leading GdB crates with 20 bottles, short side leading Pallet: EURO pallet 1200 x 800 mm consisting of: 1 Depalletizer make: Kettner type: Pressant Duplex 2NT 1136 year: 2000 1 Palletizer make: Kettner type: Pressant Duplex 2NT 1176 year: 2000 1 Pallet Pressure Control make: Kettner year: 2000 1 Empty Pallet Magazine make: Kettner type: ST year: 2000 1 Empty Pallet Magazine make: Kettner type: ST/EST EURO year: 2000 1 Pallet Destrapper make: Born type: PAE year: 1986 Crate Conveying System make: Krones type: Multico ...

Matchbook noteblock pasting machine / advernote Matchbook Model Advernote Year 1980´s Size of the noteblock 50 x 50 mm Size of the cover 50 x 110 mm Cover process The cover is being fed automatic from the magazine by air, gets the creasing lines, and gets folded Noteblock process The noteblock is being fed automatic from the magazine by air, gets a dot of glue and is inserted into the cover Finished process The cover is folded in the correct sequence and will be delivered onto the delivery tray, upright. Available direct
