119,555 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
As good as new machine with very few operating hours (built in 2020). This like-new, very powerful, fully automatic shrink wrapping machine works with a permanently heated longitudinal and a cycled transverse welding, which offers at least 3 undeniable advantages: • No length limit of the product to be packaged • Significant increase in production capacity • Cost savings due to less film waste • Machine dimensions: 2180 x 1545 x 1525-1655 mm • Dimensions welded frame: 500 mm/length unlimited • Max. product height: 200 mm • Max. film roll width: 600 mm • Max. ø film roll: 350 mm • Production capacity: 600-4200 per hour (depending on product size and material) • Belt speed: 10-30 m/min • Power rating: 380-415V /3ph/ 50/60Hz • Consumption: 2300W • Continuous longitudinal seam with permanently heated transverse welding • Welding beam for longit ...
used
grinding diameter: 250 mm grinding length: 1000 mm centre height: 125 mm total power requirement: 16 kW weight of the machine ca.: 3,0 t dimensions of the machine ca.: 2,0 X 1,2 X 1,8 m A Studer RHU 1000 circular grinding machine built in 1979 is for sale. The machine is expected to be released in February 2024 and can be under power be visited. This is the variant with a grinding wheel on the right side External and longitudinal grinding with straight and angled grooves. The machine was carried out in accordance with the manufacturers maintenance specifications maintenance serviced. Manufacturer: Fritz Studer AG Type: RHU 1000 / 125-DR Machine number: 61.41 Year of construction: 1979 Mains voltage: 380V 50Hz System weight: 2600 kg Max. workpiece weight: 80 kg Main dimensions: Tip height: 125 mm Center width: 1025 mm Largest longitudinal slide path: 1020 mm Longitudinal slide: Table spee ...
used
Second-hand wide belt sanding machine Make Heesemann Type MFA Impression not rebuilt - without guarantee Year of construction 2010 Technical specifications: Sanding width 1,350 mm - cross sanding unit with pressure lamellar belt system - combined longitudinal sanding unit with calibration roll - longitudinal sanding unit - structuring brushing unit - dust removal brushing unit - 3 pressure beams with computer-controlled selective pressure control system CSD Distance of the control rollers 21 mm Feed speed: 3 - 15 m/min. Working height constant 880 mm motorized adjustment to the workpiece thickness 3 - 150 mm 1 pressure roller Ø 50 mm swinging, in the infeed of the machine including workpiece oversize control Roller table in the infeed of the machine 1 industrial PC 10.4 with program memory for 100 programs 1 cross sanding unit Abrasive belt ...
used
Technical data: Capacities: Height of centres over the flat way: 625 mm Height of centres over the flat floor: 1225 mm Swing over bed: 1250 mm Swing over carriage: 940 mm Diameter of four-jaw chuck: 1250 mm Only range of the chuck min/max: 230/1050 mm Distance between centres: 5000 mm Headstock: Spindle bore: 105 mm Spindle seat: cyl. 105 Diameter of the spindle in the front bearing: 320 mm Number of spindle speeds: 24 Overall range of spindle speeds: 1.6-315 rpm Spindle drive motor rating: 75 kW Maximum torque of the spindle: 63000 NM Carriage: Of the bed width: 1100 mm Length of the saddle: 1320 mm Of the cross slide width: 550 mm Travel of cross slide: 800 mm Travel of tool slide: 600 mm Number of feed Council for each range: 20 Overall range of longitudinal feed Council: 0.18-160 mm / rev Range of longitudinal feed Council at: -high range of spindle speeds: ...
new
Machine according to DIN 8605: lathe with increased accuracy. Top width: 700 mm Tip height: 170 mm Swing over bed: Ã? 340 mm Swing over cross slide: Ã? 190 mm Bed width: 260 mm Longitudinal slide displacement: 600 mm Cross slide displacement: 220 mm Upper carriage displacement: 110 mm Plan carriage length: 410 mm Plan slide width: 150 mm Bed slide length: 380 mm Turning tool cross section: 20 x 20 mm Distance turning Center - upper carriage: 34 mm Range of the upper carriage (support): 60 / 120 ° Main spindle: Spindle connection DIN 55029 (camlock): S 5 spindle bore: Ã? 50 mm Internal cone according to DIN 7178: 1:22 spindle diameter in front bearing: Ã? 70 mm Maximum Chuck diameter: Ã? 200 mm Faceplate diameter: Ã? 200 mm Spindle speeds: 40-3000 rpm Speed: Stepless mechanical speeds: 4 Main drive: Power at 40% ED: 5,3 kW Maximum nominal torq ...
used
Horizontal Lathe POREBA TCA 160 x 12 m Condition: very good, complete Technical details: Max. swing over bed 1600 mm Max. swing over carriage 1280 mm Max. swing over gap 1600 mm Turning length (between centers) 12000 mm spindle turning speed (min) 0.85 rpm spindle turning speed (max) 170 rpm The width of guide way 1100 mm Dia. of spindle bore 105 mm Taper of center sleeve 120/80 Feeds: bed slide/longitudinal 0,19-5, 0 mm/1 spindle rotation Feeds cross slide 0,095-2, 5 mm/1 spindle rotation Rapid travel-longitudinal/face 4000 mm/min Max work piece weight centre this centre 30000kg Max work piece weight with 2 steady rest 40000kg Faceplate diameter 1600 mm Metric thread 35 strokes-1-50 mm Whitworth thread 35 strokes-24-1/2 " Module thread Diametrical pitch thread Section of tool shank 70x70mm Travel of the top slide 0,095-2, 5 mm/1 spindle rotation Max.travel o ...
Qty. 1 Second-hand wire cage welding machine – very good condition Mfc.: Züblin Type: ASMS 30 200 Built: 1985 Machine for production of wire cages within the range of diameters between 300-2250 mm. Wire cage dia.: 300 – 2250 mm Dia. of longitudinal wire: 5 – 7 mm Number of longitudinal wires: 12 Diameter of ring wire: 5 – 9 mm Grade of ring wires: 35 – 165 mm Longitudinal wire – speed:0.3-3.0 m/min.
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Positions APC: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 426/430 Technical data Number of axis total: 3 Table length: 900 mm Table width: 600 mm Longitudinal travel (X-axis): 710 mm Transversal travel (y-axis): 550 mm Vertical travel (z axis): 500 mm Table load max.: 1600 kg Tool changer: Number of tools: 30 Tool diameter: 90 mm Diameter with free adjacent pockets: 140 mm Tool lenght: 300 mm Max. tool-weight: 8 kg Time of tool changing: 5 sec Spindle nose: ISO: B40 Spindle speeds: from: 100 rpm up to: 12000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 15000 mm/min transversal from: 1 mm/min up to: 15000 mm/min vertical from: 1 mm/min up to: 1 mm/min Feed range: 10000 mm/min Rapid traverse: long.: 30 m/min Rapid traverse: transversal: 30 m/min Rapid traver ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: MAHO 432 Operating hours: 7002 Technical data Table length: 900 mm Table width: 600 mm Longitudinal travel (X-axis): 800 mm cross travel (Z-axis): 550 mm vertical travel (Y-axis): 500 mm Table load max.: 450 kg Taper in spindle: 40 ISO Spindle speeds: stepless horizontal from: 20 rpm up to: 5000 rpm vertical from: 20 rpm up to: 5000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 4000 mm/min transversal from: 1 mm/min up to: 4000 mm/min vertical from: 1 mm/min up to: 4000 mm/min Rapid traverse:: 6 m/min Voltage 50 Hz 3x: 380 Volt Milling spindle motor: 10 kW Machine´s weight about: 5000 kg Overall dimensions machine: Length: 3000 mm Width: 2200 mm Height: 2100 mm Various accessories: Vice: width: 125 mm In ...
used
Technical data: - Load capacity E. chain hoist 250 kg - Lifting speed approx. m/min - Operation of the chain hoist via hand remote scanner - Man. Process hoist / transverse path + longitudinal path - Track gauge variable to approx. 3000 mm - Hook height approx. 2200 mm - Crane track length approx. 4000 mm - Height approx. 3500 mm - UK crane carrier approx. 2700 mm - UK - longitudinal rail approx. 3000 mm - 4 pieces of steel supports made of recheck tube 150 x 100 mm H 3500 mm - 2 longitudinal suspension carriers approx. 4250 mm - Cross suspension carriers approx. 3000 mm - Weight of the plant approx. 1000 kg
used
Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0 Positions ATC: 0 CNC Brand: 0 CNC Model: 0 Control: GE FANUC Technical data Longitudinal travel (X-axis): 700 mm Transversal travel (y-axis): 500 mm Vertical travel (z axis): 700 mm Table divisions (B): 360´000x0.001 ° Table speeds: up to: 15 rpm Pallets: number: 9 Length: 500 mm Width: 400 mm Time of changing palets: 14 sec Transport weight: 500 kg Tool changer: Number of tools: 144 (2x72) Max. tool-weight: 12 kg Time of tool changing: 6 - 8 sec Spindle nose: ISO: 45 Horizontal spindle speeds: stepless from: 40 rpm up to: 10000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 10000 mm/min transversal from: 1 mm/min up to: 10000 mm/min vertical from: 1 mm/min up to: 10000 mm/min Rapid traverse:: 15 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 15 kW Total ...
used
Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0 Number controlled axis: 0 CNC Brand: 0 CNC Model: 0 Control: FANUC Operating hours: 2330 Technical data Number of spindles: 2 Number of revolvers: 2 Distance spindle nose: 250 - 870 mm Maximum turning length: 160 mm Max. turning diameter: 130 mm Turret carriage: Carriage 1: Longitudinal travel (Z-axis): 200 mm Longitudinal travel (X-axis): 180 mm Transversal travel (y-axis): +/-30 mm Carriage 2: Longitudinal travel (X-axis): 180 mm Cross travel (z-axis): 620 mm Y axis: +/-30 mm Number of positions turret 1: 12 Number of positions turret 2: 12 Driven tools turret 1: 6 Driven tools turret 2: 6 Spindle speeds: 3600 rpm Power of driven tools: 3.7 / 2.2 kW Main spindle: Internal spindle diameter: 42 mm Spindle speeds: stepless up to: 5500 rpm Spindle power: 7.5 kW Back spindle: Spindle hole: 40 mm max. sp ...
used
Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0 Positions ATC: 0 CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 D Operating hours: 7176 Technical data Number of axis total: 4 Table length: 6400 mm Table width: 1000 mm Table load max.: 1500 kg Longitudinal travel (X-axis): 6000 mm Transversal travel (y-axis): 1000 mm Vertical travel (z axis): 1140 / 1200 mm B axis swivelling range: +/-90 ° Milling head divisions (B): 0.001 ° Tool magazine number of tools: 80 Tool diameter max.: 100 mm Diameter with free adjacent pockets: 180 mm Tool lenght: 400 mm Max. tool-weight: 15 kg Time of tool changing: 6 sec Spindle nose: HSK-A: 100 Spindle speeds: stepless from: 45 rpm up to: 9000 rpm Feeds: longitudinal from: 1 mm/min up to: 9999 mm/min transversal from: 1 mm/min up to: 9999 mm/min vertical from: 1 mm/min up to: ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 10 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse:: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm Various accessories: Digital readout number of axis:: 3 Coolant system Tool storage
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Positions APC: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN MillPlus /3R-WorkMaster +3R-WorkShopManager Operating hours: 30452 Technical data Number of axis simultaneous: 5 Number of tables: 1 Number of spindles: 1 Circulary table diameter: 630 mm Number of T-channels: 9 Distance of the T-slots: 63 mm T-channel width: 14H7 mm Centering bore diameter: 50H6 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 700 mm Vertical travel (z axis): 600 mm Dimension of the workpice: Height: 1000 mm Diameter: 920 mm Table load max.: 500 kg Table divisions (B): 360 ° A axis Swivel angle (a-axis): +45/-30 ° Holding torque A-axis: 3866 Nm Clamping torque C-axis: 6008 Nm Torque max.: 2650 Nm Tool changer: Number of tools: 180 Tool diameter: 80 mm Diameter with free adja ...
used
GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC Machi ...
used
GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC Machi ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 185 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Distance from horizontal spindle to table: 310 mm Spindle speeds: number (steps): 8 from: 95 rpm up to: 1500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 116 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Total power required: 2.5 HP Machine´s weight about: 450 kg Overall dimensions machine: Length: 1000 mm Width: 900 mm Height: 1500 mm Various accessories: Universal table Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Distance from vertical spindle to table: 260 mm Spindle speeds: number (steps): 8 from: 95 rpm up to: 2000 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 500 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Universal table Vertical milling head
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 180 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 95 rpm up to: 1500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 116 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 450 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1400 mm Various accessories: Rotary table:diameter Steady
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: PHILIPS 132 Technical data Table length: 740 mm Table width: 440 mm Longitudinal travel (X-axis): 500 mm Cross travel (z-axis): 300 mm vertical travel (Y-axis): 400 mm Taper in spindle: 40 ISO Spindle speeds: stepless horizontal from: 63 rpm up to: 4000 rpm vertical from: 63 rpm up to: 4000 rpm Feeds: stepless longitudinal from: 1.0 mm/min up to: 3000 mm/min transversal from: 1.0 mm/min up to: 3000 mm/min vertical from: 1.0 mm/min up to: 3000 mm/min Rapid traverse: long.: 5 m/min Rapid traverse: transversal: 5 m/min Rapid traverse: vertical: 5 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 5 HP Machine´s weight about: 1700 kg Overall dimensions machine: Length: 1800 mm Width: 2200 mm Height: 1900 mm Various acc ...
used
Key data: 600 , 200 , 300
Table length: 600 mm Table width: 200 mm Longitudinal X: 300 mm Cross Y: 135 mm Vertical Z: 300 mm Technical data Table length: 600 mm Table width: 200 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 1500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Steady Universal table Vertical milling head
used
Key data: 600 , 200 , 300
Table length: 600 mm Table width: 200 mm Longitudinal X: 300 mm Cross Y: 135 mm Vertical Z: 300 mm Technical data Table length: 600 mm Table width: 200 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 2500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 500 kg Various accessories: Coolant system Steady Universal table Vertical milling head
used
Control: SIEMENS SINUMERIK 840 D Operating hours: 29500 Technical data Number of axis total: 4 Number of spindles: 2 Distance spindle nose: 580 mm Swing over cross-slide: 100 mm Swing over bed: 145 mm Spindle hole: 50 mm Turning diameter: 100 mm Bar diameter with collet: 36 mm Clamping chuck diameter: 140 mm Carriage 1: Longitudinal travel (Z-axis): 320 mm Transversal strocke (X axis): 220 mm Carriage 2: Longitudinal travel (X-axis): 345 mm Cross travel (z-axis): 120 mm Turret slide: number: 2 Number of positions turret 1: 12 Number of positions turret 2: 12 Driven tools turret 1: 12 Driven tools turret 2: 12 Spindle speeds: 30/6000 rpm Spindle speeds: 30/6000 rpm Power of driven tools: 2.1 kW Plage vitesse de rotation rad./axial: 30/6000 rpm Collet bore: 36 mm Spindle speeds: stepless from: 40 rpm up to: 8000 rpm Back spindle: max. speed: 40/8000 rpm Power of back spindle: 26/21 kW st ...
used
Technical data Table length: 600 mm Table width: 210 mm Longitudinal travel (X-axis): 260 mm Transversal travel (y axis): 150 mm Vertical travel (z axis): 310 mm Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 410 mm Spindle speeds: stepless from: 58 rpm up to: 2000 rpm Taper in spindle: 30 ISO Feeds steps:: 10 longitudinal from: 12.0 mm/min up to: 400 mm/min vertical from: 12.0 mm/min up to: 400 mm/min Rapid traverse: longitudinal: 1.2 m/min vertical: 1.2 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Total power required: 3.0 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1500 mm Width: 1100 mm Height: 1600 mm
used
Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2 m/min transversal: 2 m/min vertical: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm Various accessories: Coolant system Lamp
used
Control: HEIDENHAIN TNC 135 Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2 m/min transversal: 2 m/min vertical: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 200 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 230 mm Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 330 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 2000 rpm Taper in spindle: Vertical: ISO 30 Horizontal: W 20 Feeds steps:: 8 longitudinal from: 12 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2 HP Machine´s weight about: 500 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1800 mm Various accessories: Motorized table adjustment vertically Tilting table
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 842 mm Longitudinal travel (X-axis): 1000 mm Transversal travel (y-axis): 795 mm Vertical travel (z axis): 800 mm Table load max.: 800 kg Drill capacity in steel: 55 mm Taper in spindle: MT: 4 Stroke of drilling spindle (Z-axis): 250 mm Bore diameter max.: 300 mm Spindle speeds: number (steps): 18 from: 40 rpm up to: 2000 rpm Feeds: Table: stepless up to: 300 mm/min Drill spindle slide: number (steps): 6 from: 0.04 mm/r up to: 0.35 mm/r Rapid traverse: Table:longitudinal: 2500 mm/min transversal from: 2500 mm/min Distance between columns: 1100 mm Distance between spindle and table: 900 mm Voltage 50 Hz 3x: 380 Volt Spindle motor: 4.00 HP Total power required: 8.0 HP Machine´s weight about: 7500 kg Overall dimensions ma ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 425 Technical data Number of axis total: 3 Table length: 900 mm Table width: 530 mm Number of T-channels: 8 T-channel width: 14H7 mm Distance of the T-slots: 63 mm Table load max.: 400 kg Longitudinal travel (X-axis): 600 mm Transversal travel (y axis): 600 mm Vertical travel (z axis): 450 mm Spindle speeds: stepless from: 10 rpm up to: 6300 rpm Tool changer: number of tools: 22 with double gripper Spindle nose SK: 40 DIN 69871 Pull-Studs: DIN 69872 B Tool diameter: 80 mm Diameter with free adjacent pockets: 130 mm Tool lenght: 300 mm Max. tool-weight: 8 kg Time of tool changing: 5-15 sec Feeds: stepless longitudinal from: 2 mm/min up to: 10000 mm/min transversal from: 2 mm/min up to: 10000 mm/min verti ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 125 rpm up to: 2000 rpm Taper in spindle CN: 40 Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 2000 rpm Taper in spindle: Vertical: W20 Horizontal: W20 Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Motorized table adjustment vertically Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 2000 rpm Taper in spindle: Vertical: ISO 30 Horizontal: ISO 30 Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Dividing attachment 3-jaw chuck diameter: 110 mm Steady Set of supports Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 124 Technical data Number of axis total: 3 Table length: 800 mm Table width: 425 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y axis): 400 mm Vertical travel (z axis): 400 mm Table load max.: 250 kg Distance from vertical spindle to table: 560 mm Taper in spindle:: 40 SK Spindle speeds: stepless horizontal from: 5 rpm up to: 5000 rpm vertical from from: 5 rpm up to: 5000 rpm Swivel range Vertical milling head: +/- 90 ° Feeds: stepless longitudinal from: 0 mm/min up to: 2000 mm/min transversal from: 0 mm/min up to: 2000 mm/min vertical from: 0 mm/min up to: 2000 mm/min Rapid traverse: long.: 10 m/min Rapid traverse: transversal: 10 m/min Rapid traverse: vertical: 7.5 m/min Vertical quill ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 124 Technical data Number of axis total: 3 Table length: 800 mm Table width: 425 mm Longitudinal travel (X-axis): 600 mm Transversal travel (y axis): 400 mm Vertical travel (z axis): 400 mm Table load max.: 250 kg Distance from vertical spindle to table: 560 mm Taper in spindle:: 40 SK Spindle speeds: stepless horizontal from: 5 rpm up to: 5000 rpm vertical from from: 5 rpm up to: 5000 rpm Swivel range Vertical milling head: +/- 90 ° Feeds: stepless longitudinal from: 0 mm/min up to: 2000 mm/min transversal from: 0 mm/min up to: 2000 mm/min vertical from: 0 mm/min up to: 2000 mm/min Rapid traverse: long.: 10 m/min Rapid traverse: transversal: 10 m/min Rapid traverse: vertical: 7.5 m/min Vertical quill ...
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Spindle speeds maximum: 0 rpm Feed maximum: 0 mm/min Positions ATC: 0 Positions APC: 0 CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Operating hours: 40317 Technical data Number of axis total: 5 Rotary table:diameter: 250 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 240 mm Vertical travel (z axis): 350 mm B axis swivelling range: +/-110 ° C axis: 360 ° Pallets:: EROWA ITS 148mm number: 20 Tool changer:: TCD Number of tools: 36 Spindle nose: HSK: 40E OptiCool Spindle speeds:: StepTec stepless from: 100 rpm up to: 42000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 40000 mm/min transversal from: 1 mm/min up to: 40000 mm/min vertical from: 1 mm/min up to: 40000 mm/min Rapid traverse:: 42 m/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 13 kW Machine´s weight about: 6500 kg Overall dim ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Technical data Table length: 1000 mm Table width: 500 mm Longitudinal travel (X-axis): 800 mm Transversal travel (y axis): 500 mm Vertical travel (z axis): 460 mm Table load max.: 500 kg Distance from vertical spindle to table: 559 mm Taper in spindle: 40/M16 ISO Spindle speeds: number (steps): 21 horizontal from: 31.5 rpm up to: 3150 rpm vertical from: 31.5 rpm up to: 3150 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 3000 mm/min transversal from: 1 mm/min up to: 3000 mm/min vertical from: 1 mm/min up to: 3000 mm/min Rapid traverse: long.: 6 m/min Rapid traverse: transversal: 6 m/min Rapid traverse: vertical: 4 m/min Vertical quill travel: 110 mm Voltage 50 Hz 3x: 380 Volt Spindle motor: 10.8 HP Machine´s weigh ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 125 rpm up to: 2500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Set of toolholders Tool cabinet
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 190 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 135 mm Vertical travel (z axis): 300 mm Spindle speeds: number (steps): 8 from: 100 rpm up to: 1500 rpm Taper in spindle:: 20 W Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 232 mm/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Machine´s weight about: 620 kg Overall dimensions machine: Length: 1100 mm Width: 900 mm Height: 1600 mm Various accessories: Dividing attachment Centre height: 85 mm Vice: width: 50 mm Tilting and swivel table Vertical milling head Lamp
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC 11 Operating hours: 10751 Technical data Table length: 1100 mm Table width: 842 mm Longitudinal travel (X-axis): 1000 mm Transversal travel (y-axis): 700 mm Vertical travel (z axis): 780 mm Table load max.: 1500 kg Drill capacity in steel: 60 mm Taper in spindle: ISO: 4 B Diameter of drilling spindle: 135 mm Stroke of drilling spindle (Z-axis): 300 mm Bore diameter min.: 60 mm Bore diameter max.: 300 mm Distance table to spindle: 1000 mm Spindle speeds: number (steps): 18 from: 20 rpm up to: 3000 rpm Feeds: Table: from: 0.1 mm/min up to: 6000 mm/min Drill spindle slide: number (steps): 6 from: 0.01 mm/r up to: 0.39 mm/r Rapid traverse: Table:longitudinal: 6000 mm/min transversal from: 6000 mm/min vertical: 6000 mm/min Distance between columns: 1100 mm Vol ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: REALMECA Technical data Table length: 500 mm Table width: 300 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 260 mm Vertical travel (z axis): 340 mm Spindle speeds: stepless vertical from: 100 rpm up to: 6000 rpm Tool changer: number of tools: 12 Spindle nose: ISO: 30 Tool diameter: 70 mm Tool lenght: 120 mm Feeds: stepless longitudinal from: 0 mm/min up to: 5000 mm/min transversal from: 0 mm/min up to: 5000 mm/min vertical from: 0 mm/min up to: 5000 mm/min Rapid traverse:: 5 m/min Voltage 50 Hz 3x: 400 Volt Total power required: 14 kVA Machine´s weight about: 2380 kg Overall dimensions machine: Length: 2270 mm Width: 1440 mm Height: 2380 mm Various accessories: Set of toolholders: ISO 30
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: 0 CNC Model: 0 Control: DECKEL DIALOG 3 Technical data Table length: 632 mm Table width: 277 mm Longitudinal travel (X-axis): 300 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 400 mm Table load max.: 400 kg Distance from vertical spindle to table: 93 - 525 mm Distance from spindle axis Spindle speeds: number (steps): 21 vertical from: 31.5 rpm up to: 3150 rpm Feeds: stepless longitudinal from: 2 mm/min up to: 2000 mm/min transversal from: 2 mm/min up to: 2000 mm/min vertical from: 2 mm/min up to: 2000 mm/min Rapid traverse:: 4 m/min Vertical quill travel: 60 mm Stroke of horizontal spindle: 65 mm Voltage 50 Hz 3x: 380 Volt Milling spindle motor: 1.6 / 2 kW Machine´s weight about: 1215 kg Overall dimensions machine: Len ...
used
Technical data Table length: 900 mm Table width: 200 mm Longitudinal travel (X-axis): 500 mm Transversal travel (y axis): 200 mm Vertical travel (z axis): 350 mm Spindle speeds: number (steps): 8 from: 45 rpm up to: 1500 rpm Feeds steps:: 8 longitudinal from: 16 mm/min up to: 384 mm/min transversal from: 16 mm/min up to: 384 mm/min vertical from: 8 mm/min up to: 192 mm/min Rapid traverse: longitudinal: 1.5 m/min transversal: 1.5 m/min vertical: 0.750 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2 HP
used
Technical data Table length: 600 mm Table width: 210 mm Longitudinal travel (X-axis): 260 mm Transversal travel (y axis): 150 mm Vertical travel (z axis): 310 mm Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 410 mm Spindle speeds: stepless from: 58 rpm up to: 2000 rpm Taper in spindle: 30 ISO Feeds steps:: 10 longitudinal from: 12.0 mm/min up to: 400 mm/min vertical from: 12.0 mm/min up to: 400 mm/min Rapid traverse: longitudinal: 1.2 m/min vertical: 1.2 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Total power required: 3.0 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1500 mm Width: 1100 mm Height: 1600 mm Various accessories: Universal table
used
Technical data Table length: 1000 mm Table width: 700 mm Longitudinal travel (X-axis): 800 mm Transversal travel (y axis): 300 mm Vertical travel (z axis): 400 mm Travel of the upper slide: 100 mm Spindle speeds: number (steps): 18 from: 40 rpm up to: 2000 rpm Taper in spindle: 40 ISO Feeds steps:: 18 longitudinal from: 10.0 mm/min up to: 500 mm/min transversal from: 10.0 mm/min up to: 500 mm/min vertical from: 10.0 mm/min up to: 500 mm/min Vertical quill travel: 50 mm Rapid traverse: longitudinal: 1.5 m/min transversal: 1.5 m/min vertical: 1.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 4.0 HP Machine´s weight about: 2400 kg Overall dimensions machine: Length: 1500 mm Width: 1200 mm Height: 1800 mm Various accessories: Vice: width Digital readout number of axis:: 3 Manufacturer: HEIDENHAIN Coolant system Rigide table Vertical milling head Quick drill and milling head Angular m ...
used
Technical data Table length: 590 mm Table width: 270 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 737 mm Distance from vertical spindle to table: 400 mm Distance from horizontal spindle to table: 470 mm Table load max.: 60 kg Spindle speeds: stepless from: 50 rpm up to: 3450 rpm Taper in spindle: 40 ISO Feeds stepless: longitudinal from: 5 mm/min up to: 1000 mm/min transversal from: 5 mm/min up to: 5000 mm/min Rapid traverse: longitudinal: 0.67 m/min transversal: 2.4 m/min vertical: 1.6 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 2.2 kW Total power required: 5.1 kVA Machine´s weight about: 900 kg Overall dimensions machine: Length: 1500 mm Width: 1300 mm Height: 2000 mm Various accessories: Dividing attachment Rotary table:diameter: 340 mm Digital readout number of axis:: 3 Coolant system Steady Rigide table Universal ta ...
