longitudinal used for sale

Manufacturer: Winfos Model: YC 180 Year of Manufacture: 2010 Type of Machine : Longitudinal Slitting Line In operation since: 2017 Condition: Operational Technical Specifications: - Line length: 24.5 m - Line width: 7.8 m - Material thickness: 1.5 ~ 5.0 mm - Maximum coil diameter: 1.8 m - Coil inner diameter: 640 – 800 mm - Maximum coil width: 1500 mm - Maximum coil weight: 16 MT - Installed power: 253 kW Line Speed: - At 1.5 mm thickness: 110 m/min - At 4.0 mm thickness: 95 m/min Tooling & Accessories: - Knives – 186 pcs total: - Set 1 – 10 mm, Ø307: 26 pcs - Set 2 – 14 mm, Ø315: 66 pcs - Set 3 – 14 mm, Ø315: 50 pcs - New Ø320: 44 pcs - Rubber rings – 93 pcs total: - Set 1 – 25 mm: 31 pcs - 15 mm: 12 pcs - Set 2 – 25 mm: 31 pcs - 15 mm: 18 pcs - Set 3 – 25 mm: 31 pcs - 15 mm: 18 pcs - Slitter knife spacers: 480 pcs - Separator spacers: - Metal: 252 pcs - ...

We are offering for sale a complete used longitudinal beam welding line, comprising the following equipment: MACHINE 1 - TACK WELDING DEVICE - Manufacturer: Wehling - Type: Heftvorrichtung Langsträger - Year of Construction: 2015 - Power: 0.25 kW + 28 x 0.06 kW - CE Marked: Yes Technical Specifications: - Maximum beam length: 13,700 mm - Beam height range: 70 to 500 mm - Flange width: 150 mm and 120 mm (after conversion) - Flange thickness: 5 to 20 mm - Web plate thickness: 5 mm (to DIN 2768-1 tolerances) - Tack position: trough position, 45 degrees - Changeover time per beam pair: max. 10 minutes - Total unit length: 14,300 mm - 28 servo motors for individual height adjustment of beam supports - Rotatable base frame: 0 to 45 degrees - Permanent magnet clamping of the top flange - Siemens S7 control system - Touch screen operator interface - NC axis with programmable software switch ...

Longitudinal slitting machine for paper. NEW. Cutting to length (columns) paper or foil to approx. 70 cm width-Perforieren paper, labels, cards, forms -6 Circular blades (blades), or alternatively 6 perforating knife holder -Maximum paper width 70 cm Shipping is possible with extra charge.

2 Coilhaken 1 x 9 t 1 x 1 t

approx. 2,700 longitudinal bracing, for longitudinal bracing as an alternative to cross bracing, LV 3134 for span length 1,282mm – used - : Price per piece ex site: only 4.- € (net)! 4 pieces are needed per field! Manufacturer: SSI Schaefer Type: LV 3134 Year of construction: 2021 Field length 1,282mm Shelf height 40mm Original price per piece: approx. 12.-€ (net) Longitudinal braces Sheet steel, painted light silver. For longitudinal bracing as an alternative to cross bracing, if cross braces in the double rack interfere with storage or if both sides are to be operated in the single rack. In order to ensure subsequent height adjustability, the frame distance for double racks must be at least 30 mm. In each shelf space of a rack row, the lower and upper shelves are to be provided with 2 longitudinal supports (for shelf heights up to 2967 mm). The form-fittin ...

Unwinding reel / decoiler â?¢ Bandwidth / strip width max. 1,500 mm â?¢ Tape thickness / strip thickness (430 N/mm2) 0.5-2.0 mm â?¢ Coil outer diameter / coil outer - 1,300 mm â?¢ Coil inner diameter / coil inside - 470-520 mm â?¢ Coil weight / coil weight 10,000 kg â?¢ Side shift / side shift . . . . . . . . . . . . . . . . .

Technical data: Bandwidth / strip width min. 150mm Bandwidth / strip width max. 1,650 mm Strip thickness min. 0.4 mm Strip thickness max. 400 N/mm² 2.5 mm 300 N/mm² 3.0 mm Coil weight decoiler/ coil weight decoiler 12,000 kg Coil outer Ø / coil outer-Ø 1,600 mm

Cutting height: 205 mm Motor output: 11 kW cutting width: 450 mm Cutting length: 5200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine for the processing of large-area composite panel materials With this machine you are able to process portrait panel semi-finished products that are otherwise difficult to process We offer you a technology that has already proven itself in practice and works. With this technique you can process semi-finished products up to a maximum height of 220 mm precisely and accurately The technical parameters are queried and measured as required.

Stock number: 3778 CUTTING LINE Manufacturer: MORGAN , Type: 1330 x 0.7 - 3.2 mm Specifications: Size scissors length 1330 mm Size sheet thickness 0.7 - 3.2 mm - Roller feed 2 pc dia. 100 rools Composed of: - Straightening machine 5 pc. dia 100 Reels - Drain reel 5 ton dia. 530-610 mm tone - Scissors Morgan 1500 x 3.2 mm Accessories: Coil trolley 5 ton Length: 6500 mm, Height: , Width: 33.00 mm, Weight:

Bandwidth. 500 mm Strip thickness.. 0.3-2.5mm Coil weight. 5,000 kg Velocity. 70 - 120 m/min. Coil I Diameter.. 508 mm Coil A diameter. 1,500 mm

Compact slitting line, with uncoiler, loading prism, pressure arm AH 1500/5000 kg, clamping range 480 - 550 mm, with 3 arched tables, with 4 overflow tables, with 2 bases, with 2 stairs, with guillotine shears for cutting to length, foil holder with brake, with 5 pairs of knives Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 1500 mm Sheet thickness steel: 1.5 mm Sheet thickness aluminium: 2.5 mm Sheet thickness front: 1.0 mm Color: Blue Total power requirement: 3 x 400 V Machine weight: 9100 kg Dimensions: 11541 x 5300 x 1770 mm Coil weight: 5000 kg Straightening rollers: 7 Number of blades: 5 pairs Straightening rollers at the top: 3 Straightening rollers at the bottom: 4 Speed: 35 m/min Machine Number: K08258

An indestructible machine for the toughest conditions. The machine is suitable for processing raw wood. The machine has no inclination. The saw blade is located directly on the motor. Technical parameters: Maximum saw blade diameter: ø 500/mm Power of the main motor: 5.5 kW Main speed of the saw blade: 2850 rpm Maximum cutting height: 85 mm (with 350 mm saw blade) Inclination of the saw unit: NO Dimensions of the iron table: 1050 × 600 mm Aluminium formatting table: 2000 × 360 mm / OPTION 3200 x 360 mm Formatting table for hardened rods (Altendorf principle) Cutting length: 2000 mm Weight of the machine: 450 kg Given the prices of new Chinese machines that cannot withstand the harsh conditions, this machine is the solution. Made in Slovakia in Europe

CINCINNATI ACW6 slitting line is used in the processing of thin steel sheets with a maximum thickness of 4 mm. The process consists in gradually unrolling the sheet coils towards cutting rollers with special roller knives with a thickness of 5 to 30 mm, and then passing the sheet between the rollers for precise slitting. After the slitting process, the sheet is wound onto coils ready for further processing. The ACW6 slitting line guarantees the highest product quality while making optimum use of the raw material. The CINCINNATI coil slitting line consists of: – sheet decoiler – sheet metal winder – roller knives (thickness 5 mm, 10 mm, 12 mm, 20 mm, 25 mm, 30 mm) – ejector spacers (width 10 mm, 12 mm, 20 mm, 25 mm, 30 mm) – slitting aggregate unit – brake Technical specifications of the CINCINNATI ACW6 slitting line - maximum sheet thickness: 4 mm - minimum shee ...

Aluminium saw with a cutting length of up to 600 mm with hydro-pneumatic feed Pneumatically adjustable angle between 45° and 90° Pneumatic material tensioners Suction Max. saw blade diameter: 500 mm

7 axes Max. spindle passage: Ø 16 mm Max. headstock stroke: 205 mm MAIN SPINDLE Spindle speed: 10000 1/min Spindle drive power: 3.7 kW Minimum C-axis resolution : 0.001 [degrees] SUB-SPINDLE - Max. rod end Ø: 16 mm - Spindle speed : 9000 1/min - Minimum resolution C-axis : 0.001 [degrees] TOOLS 5x Turning tool holder on linear slide 4x drilling unit incl. drilling holders (front/rear) 3x driven tools for transverse machining on linear slides 4x tools incl. drill holders for reverse side machining Driven Tools Speed : 7500 1/min Conveyor Bar Feeder FMB minimag 18/3200

Pulse laser cleaning device with 200 watt laser power much more effective in cleaning/rust removal applications than continuous lasers, such as those used in welding lasers. Take a look and test it now Top device at a top price from our showroom for paint stripping, rust removal, VA weld seam cleaning, etc. 200 Watt Pulse Laser / Air-Cooled German menu navigation at call Machine dimensions approx.: Width: 60cm Height: 120cm Depth: 110cm Weight: approx. 100kg

Tsugami BU20 Swiss-type lathe :::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 16i - TB Main spindle power: 3.7Kw Main spindle bar passage: 20mm Headstock Stroke (Z1): 170mm Number of main spindle speeds: 8000 Number of linear axes: 7 Number of fixed tool slots for tool plate: 4 Number of live tool slots for tool plate: 3 Sub-spindle: yes Number of counter-spindle revolutions: 8000 Bar Passage: 20mm Number of fixed rear tools: 6 + 6 Refrigerant used: neat oil Chip conveyor: belt Machine equipment: the machine is supplied without bar loader :::D DIMENSIONS AND WEIGHT::: Length: 2712mm Width: 1401mm Height: 1728mm Weight: 3500Kg

Centauro Slitting Saw Type SLG 8000 Year of construction: 2011 Cutting length max. 8000 mm Cutting width max. 1900 mm Cutting height max. 160 mm Motor 11 kW with laser light with pressure beam

Ref. No. 00891 Name of the Tube Laser Cutting System Manufacturer: BLM Adige Model LT 652/B Year of construction 2002 Laser power 2000 watts Loading length Unloading length Loading length 6500mm and unloading length 3500mm. In 2024, 40,000 euros were invested Operating hours 3 shifts Computer 127,653h Heating HF tube 62.850 h High voltage 119,453 h From order confirmation at the time of purchase Lasertube LT652 Automatic feeder for pipes between 3200 and 6500mm Fully automatic pipe support and unloading device for pipes up to 4500mm Siemens Sinumerik 840D control system Teleservice incl. modem CO2-Slab-Laser Model DC020 Kompakt, Fabr. Rofin Sinar Hamburg Integration RF DC020 Compact Laser Cooling Unit Fine dust filter, Fabr. Donaldson Torit Universal AK-HP Cutting Head, Fabr. Precitec Gaggenau Precitec Interchangeable Cassettes AK-HP 5" HP ZNSE 5"  ...

Coil turner, usable as a stand-alone machine for dressing coils of all kinds, or at the end of a slitting line for setting up sliced coils as a transfer for a coil packaging system.

General Manufacturer: Citizen Type: Cincom R 07 VI Year of Make: 2012 Control: Citizen Cincom Number of axles: 6 Turning diameter: 7 mm Turning length: 40 mm Thread diameter: 4 m Spindle passage: 12 mm Spindle Speed: 0 – 16,000 rpm Spindle power: 1.1 kW Sub-spindle Speed: 0 – 10,000 rpm Pick-up length: 40 mm C-axis: 1° Tapping diameter: 3 m Tool Carrier Quantity: 2 Number of stations: 13 Turning tools: 5 Drilling tools: 4 Tool shank cross-section: 8 mm Counter-processing Number of tools: 4 Drive Connection 50 Hz 3x: 400 Volts Sub-spindle power: 0.5 kW Total power requirement: 4 kVA Dimensions and weight Dimensions: 1,465 mm x 560 mm x 1,410 mm Weight: approx. 950 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Pneumatic workpiece extraction LNS Tryton 112 Rother mini ...

Slitting line 500 x 0.3-2.5 mm Coil weight . 7 to. Coil I diam 508 mm Coil A Dia. 1,300 mm Coil I Dia. Expenditure. 400 mm Strip number 2-25 Speed 1-150 m/min. Working Guidelines right/left

Strip width 1,500 mm, strip thickness 0.5-1.5 mm, coil weight 10 tons. Longitudinal sections 4, straightening rollers 7, coil inside diameter. 508 mm Coil Outside Diam. 1,600 mm

Slitting line 2,100 x 14 mm Bandwidth... 2,100 mm Strip thickness 4-14 mm Coil weight.. 35 tons. Coil Diam. I 508-810 mm Coil Diam. Rewinder 750 mm Coil A Dia. 2,000 mm Knife shafts diameter 380 mm Connected load 660 KW

Belt width 1,500 mm, strip thickness 0.5, - 2.0 mm, coil weight 7 tons, straightening rollers 7 pcs. , Longitudinal sliced 4 x , Coil inside diam. 508 mm, coil outer diam.1,600 mm

CNC Swiss Automatic Lathe TRAUB TNL 32 9P With control TX 8 i - p Year of Make: 2016 Spindle bore: 32 mm MAIN SPINDLE Speed range: Max. 6400 rpm C Axis SUB-SPINDLE Speed range: Max. 6000 rpm C Axis TOOL TURRET TOP: Speed range: Max. 12000 rpm 10 speed turret ( All driven ) TOOL TURRET ABOVE: Speed range: Max. 12000 rpm 9 speed turret ( All driven ) REAR UNIT Number of stations: 8 Of which powered: 3 ( T 12 , 13 and 14 ) Speed T12 + T 14 ( 12000 rpm ) Speed T 13 : ( 4000 rpm ) With the following accessories: Full protection cab with interior lighting Various powered tools Various tool holders IEMCA Boss 338 Bar Feeder - HD KSS Pump 20 bar Chip conveyor Operating Instructions

Belt width 1,500 mm. Strip thickness 0.5 -3.0 mm, coil weight 7 to. Longitudinal cuts 4 pcs., straightening rollers 7 pcs., coil inside dia. 508 mm, coil outside diam. 1,600 mm Facility consists of: Decoiler Pallet truck Pressing arm Overflow table Straightener Longitudinal shears Cross shears Scrap Wrapper Side table

Longitudinal cut-to-length line for the sheet metal industry 1,500 x 1.5 mm Belt width 1,500 mm Band thickness 0.4 -1.5 mm Longitudinal sections 3 Coil weight 3,000 kg# Speed 15 m/min. 3 unwinders Machine very well maintained, immediately ready for use, ex site

Jrion & Denz longitudinal saw Edging saw longitudinal circular saw Type HMS 15 Cutting length 3400 mm Cutting width 650 mm Cutting height maximum 120 mm Width stop can be adjusted motorically at the touch of a button Saw motor 11 kW Hydraulic pump feed 1.5 kW Saw blade feed speed infinitely variable 1 – 60 m/min. Saw blade return 60 m/min. At full capacity of the maximum cutting height of 120 mm, the maximum cutting length is 3200 mm. Saw blade diameter maximum 450 mm Cutting height for saw blade diameter 400 mm, 105 mm Saw blade bore 30 mm Extraction connection diameter 200 mm was mainly used to cut 80 mm thick planks Saw is activated via footswitch Rated current 23 A, frequency 50 Hz Instruction manual included Saw blades included 2 pieces diameter 400 mm, 4 pieces 450 mm Good, ready-to-use condition Machine Dimensions: 5750 mm x 1700 mm x H 1200 mm

Underframe for conveyor belt, belt conveyor, conveyor belt, belt conveyor, belt conveyor, flat belt conveyor, roller conveyor, roller conveyor stand -Subframe: longitudinal member -Type: Length 2000 mm -Number: 65 pieces of longitudinal beams available -Price: per piece -Roller conveyor: suitable in stock, see ID 35086 -Transport dimensions: 2000/120/H110 mm -Weight: 12.4 kg/piece

Underframe for conveyor belt, belt conveyor, conveyor belt, belt conveyor, belt conveyor, flat belt conveyor, roller conveyor, roller conveyor stand -Subframe: longitudinal member -Type: Length 2000 mm -Number: 50 pieces of longitudinal beams available -Price: per piece -Roller conveyor: suitable in stock, see ID 35086 -Transport dimensions: 2000/45/H140 mm -Weight: 7.3 kg/piece

Inv. Num. : 9078 Type: LC 3015 F1 NT Producer: AMADA Generated: Parameters: Work table length: 3000 mm Work table width: 1500 mm Feed length X-axis: 3070 mm Y-axis feed length: 1550 mm Feed length Z-axis: 100 mm

CNC Swiss lathe GILDEMEISTER SPRINT 20/8 linear With Fanuc 31i controller Year of Make: 2016 Spindle bore: 20 mm MAIN SPINDLE Turning diameter: max. 20 mm Speed range : max. 10000 rpm Stroke Z1: 80 mm SUB-SPINDLE Turning diameter: max. 20 mm Stroke Z 2 : 300 mm Speed: max. 10000 rpm SLIDE 1 Stroke X 1: 50 mm Stroke Y 1: 350 mm 6 Pos. Tool Holder 12 x 12 5 rotating tools including spindles with clamp holder ESX 16 SLIDE 2 Stroke x 2 : 240 mm 4 position tool holder for external machining with connection 12 x 12 4 position tool holder for internal machining diameter 20 mm 5 rotating tools including spindles with clamp holder ESX 16 6 + 2 axes, 2 Y axes as standard Linear actuator for maximum precision With the following accessories: Full protection cab with interior lighting Various tool holders C axis for main and counter spindle Bar Feeder L ...

CNC Swiss lathe GILDEMEISTER SPRINT 20/8 With Fanuc 32i control Year of manufacture: 11/2019 Spindle bore: 20 mm MAIN SPINDLE Turning diameter: max. 20 mm Speed range : max. 10000 rpm Stroke Z1: 60 mm SUB-SPINDLE Turning diameter: max. 20 mm Stroke x 2 : 220 mm Stroke Z 2 : 170 mm Speed: max. 10000 rpm SLIDE 1 Stroke X 1: 50 mm Stroke Y 1: 325 mm SLIDE Y 2 Stroke Y 2 : 85 mm With the following accessories: Full protection cab with interior lighting Various tool holders Tool holder for slides 1-3 4 driven tools with 4 spindles with ESX/ER 16 holder C axis for main and counter spindle Y axis on carriage 1 – 2 2 cross slides Workpiece unloading conveyor Signal light 4 colour Fire extinguishing system Coolant device 165 l ( Pumping capacity 90 l/min 1 bar) THE MACHINE IS IN MINT CONDITION THE MACHINE HAS ONLY 110 PROGRAM RUNNING HOURS

Equipped with feed table 300x55x100 cm, 2 conveyor chains with prism guide (length approx. 2400 mm), 2 pressure chains with drive motor and height adjustment, 2 machining motors with profiling cutter Ø 250 mm and height adjustment, 2 machining motors with facet cutter Ø 150 mm and height adjustment, width adjustment and safety screen; cap. width at least 90 mm, width at most 300 mm, thickness at least 12 mm, thickness at most 24 mm, length at least 450 mm, length maximum 3000 mm; total power approx. 25kW; including flexible hoses up to the ceiling and lift table Auction-ID: A1-44305-5

Information: - little used (as good as new) - Saw blade diameter 750 mm - Swivel height adjustment infinitely adjustable - Roller conveyor front 2,500 mm - With aluminium stop profile 3,000 mm - With rear support roller conveyor

bar material dia.:38 mm turning length:350 mm turning speeds:7.000 / 7.000 U/min number of tools:30 (3 x 10) driven tools:ja / yes control:FANUC 31i-B5 rapid traverse:30 m/min total power requirement:10,5 kVA weight of the machine ca.:6,5 t dimensions of the machine ca.:2,50 x 1,45 x 1,75 plus Lademagazin m work piece power:4 kW toolpiece turning speed range:5.700 1/min main spindle power:11 kW sub spindle power:7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining"

bar material dia.:13 mm turning length:205 mm turning speeds:12.000 / 12.000 U/min number of tools:29 driven tools:ja / yes 19 control:FANUC 16 iT total power requirement:9 kVA weight of the machine ca.:1,7 t dimensions of the machine ca.:2,7 x 1,4 x 1,7 m CNC sliding headstock machine, subspindle,Year 2003 (0450) FANUC 16i-T control with 9 axes, 9 axes (X / C1 / Y / E / B / A / X / c2), Main spindle, speed max. 12,000 rpm, C-axis, Counter spindle with collet, speed max. 12,000 rpm, C-axis, 4-fold tool holder 3 transverse drilling apparatuses Revolver with 8 stations various additional tool holders, quills, Extinguishing system Kraft and Bauer High pressure system SF-Systeme Büchele /SHD 150/ 150bar / 2 x 40 um /3 valves, Parts conveyor belt Manuals Operation/Programming/Electrical/Spare Parts Operating tool machine Up to 29 turning tools and up to 19 attachments possible 9.0KVA Tank ca ...

turning diameter over bed:20 mm spindle passage:3-20 mm turning length:250 mm control:FANUC 31 i-A main-spindle speed:10.000 1/min subspindle speed:10.000 1/min Main spindle capacity:3,7 kW subspindle power:2,2 kW number of tools:35 weight of the machine ca.:3,3 t dimensions of the machine ca.:2,11 x 1,2 x 1,89 m CNC sliding headstock turning/milling centre with B-axis Control system: Fanuc 31i-A Machining length: max. 250 mm Number of controlled axes: 7 axes and max. 5 axes simultaneously B-axis: 0°-130° freely programmable Rod passage: Ø 3 mm to max. Ø 20 mm Drive power main spindle: 3.7 kW Drive power counter spindle: 2.2 kW Main spindle speed: 10,000 rpm Counter spindle speed: 10,000 rpm C-axis: Main and counter spindle Number of linear supports: 2 pieces Total number of tools: 35 pieces Dimensions (LxWxH) in mm: 2,110×1,200×1,885 Weight: 3,300 kg Conversion from long to short  ...

spindle passage:25 mm Article: CNC sliding headstock automatic lathe Manufacturer: Tornos Type: Deco 2000/20 Year of construction: 2001 Control: Fanuc spindle diameter: D25 mm max. speed: 7000 rpm comb: 2 (X,Z,Y-axis) Front attachment: 1 (X,Z,S-axis) Loading magazine: Tornos Robobar SSF Chip conveyor: Hinged belt conveyor other: various accessories such as polygonal impact device, HF spindle Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com
