longitudinal used for sale

Slitting line Fimi 1500×2.5mm x15t (A3783) Manufacture FIMI ITALY Year 1990 Strip width Min. 200 mm Max. 1500 mm Strip thickness 0.3 – 2.5 mm Coil weight Max. 15 t Coil- Max. 1500 mm Speed Max. 80 m/min Working direction Right  Left The line consists of:  Decoiler Mandrel Cone-Ø 480 – 610 mm Drive / braking Hydraulic motor Lifting table Hydraulic  Coil opener / pinch roll unit Telescopic table Hydraulic No. of pinch rolls 2 Pinch roll-Ø 400 mm Driving motor 25 kw  Slitting head No. of heads 2 Shafts diameter 120 mm Main drive D.C. motor Driving power 92 kW  Scrap baller  Minimum scrap width 5 mm  Maximum number of slits 17 Slits up to 1.0 mm 5 Slits at 2.5 mm  Brakes Pneumatic Press up and dow  Re coiler Capacity 15 t Diameter 508 mm Driving power 120 kw  Term style 4 arms x 15 ton

STEP-MET NCW 1250 X 1.5 slitting line built in Poland in 2011, is used in the process of slitting thin steel sheets with a maximum thickness of 1.5 mm into equal-sized stripes. The material is slit longitudinally by high-quality cutting rollers, which guarantee the highest product quality while making optimum use of the raw material. The NCW 1250 X 1.5 slitting line consists of several modules, including, among others, an easy-to-operate control cabinet that allows adjustment of the operating speed and cutting width. The STEP-MET slitting line consists of the following components: – sheet metal decoiler – sheet metal winder – control cabinet Technical data of the STEP-MET NCW 1250 X 1.5 slitting line - maximum sheet metal thickness: 1.5 mm - maximum sheet metal width: 1250 mm - minimum sheet metal width: 25 mm - maximum sheet metal coil weight: 6 t - cutting speed ran ...

72”x 0.5” x 60,000Lb Braner Turret Type Loop Slitting Liney Braner Turret Type Loop Slitting Line is used for coil metal cross cutting with maximum width 72”, maximum 0,5” metal thcikness and 60,000Lb coil capacity Make: Braner Year New: 1996 Material Thickness: .060″ – .500″ Material Width: 12″ – 72″ Coil Weight: 60,000Lb Line Speed: 120 – 250 feet per minute Coil ID: 20″ – 24″ Coil OD: 75″ Slitting Cap: .500″ / 4 cuts – .125″ / 40 cuts Entry L-Type Coil Car Hydraulic Lift & Traverse Self Contained Hydraulics Control Panel Mandrel Uncoiler Powered Hold – Down Roll Outboard Bearing Support Hydraulic Feed-Up Drive Water Cooled Brake Hydraulic Peeling Table Driven Entry Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Two Turret Type Slitting Heads Arbor Diameter: 12″ Powered Arbor Adjustment Powered Head Rotation Motor: 100HP DC Driv ...

Tornos Multiswiss 8x26, Year of construction 2018, Control Tornos, 1 x counter spindle, 4 x reverse machining, Parts tape, 2 x 80 bar high-pressure pumps, fire extinguishing system, Bkhjrdnfq8o hinged belt conveyors, Bar feeders, paper tape filters,

Gebr. CNC Long Short Turning/Milling Center with B-Axis Hours: 7200 Control: Fanuc 31i-A Machining length: max. 250 mm Number of controlled axes: 7 axes and max. 5 axes simultaneously B-axis: 0°-130° freely programmable Rod passage: Ø 3 mm to max. Ø 20 mm Drive power main spindle: 3.7 kW Drive power counter spindle: 2.2 kW Main spindle speed: 10,000 rpm Counter spindle speed: 10,000 rpm C-axis: main and counter spindle Number of linear beams: 2 pieces Total number of tools: 35 pieces Dimensions (LxWxH) in mm: 2.110x1.200x1.885 Weight: 3,300 kg Conversion from long to short turning Deep Hole Drilling Stations NAKANISHI high-speed spindle Rear slide with Y-axis Cross Drilling Rear Conveyor Fire extinguishing system FMB bar feeder Minimag 20, YOC 2012 The machine can be viewed under power by arrangement. Subject to changes and errors in the technical data and  ...

Inv. Num. : 7432 Type: SW 32 Producer: Goodway Created: 2017 Parameters: Side length: 315 mm Max. turning diameter: 32 mm Weight: 3200 kg

Description: Working width: 125 - 1500 mm System consisting of, -Height-adjustable coil trolley -Decoiler type HYD DEC-5-1500 -Stretching / Feed through unit -Length cutting unit -Length measuring device -Cutting shears type BKR 1600-2-S -Positioning device -Punching unit with 20 punches -Profiling unit -Double mini press brake -Outfeed roller conveyors -Sheet vacuum lifter with stacking station plate cut-off length: 6,300 mm, strip width: 125 - 1500 mm, coil internal diameter: 500 mm, coil external diameter: 1,000 mm, coil weight: max 5000 kg, weight approx.: 30,000 kg, Approx. Onsite Dimension. (l x w x h): 50,000 x 3,000 x 3,000 mm

bar material dia.:38 mm turning length:350 mm turning speeds:7.000 / 7.000 U/min number of tools:30 (3 x 10) driven tools:ja / yes control:FANUC 31i-B5 rapid traverse:30 m/min total power requirement:10,5 kVA weight of the machine ca.:6,5 t dimensions of the machine ca.:2,50 x 1,45 x 1,75 plus Lademagazin m work piece power:4 kW toolpiece turning speed range:5.700 1/min main spindle power:11 kW sub spindle power:7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining"

bar material dia.:10 mm turning length:105 mm turning speeds:15.000 / 10.000 U/min number of tools:30 (3 x 10) driven tools:ja / yes control:FANUC 18i-TB total power requirement:3,5 kVA weight of the machine ca.:1,5 t dimensions of the machine ca.:1,9 x 0,8 x 1,7 m toolpiece turning speed range:8.000 1/min main spindle power:3,7 kW sub spindle power:1,1 kW CNC sliding headstock machine, subspindle, 7 axis (X1, Z1, Y1, C1, X2, Z2, C2), barloader LNS TRYTON 112 A-B, Fireextinguisher KRAFT und BAUER, parts-ejector, coolant tank, machining with oil as coolant, reading hours: approx. 38.000 hours "machine on", approx. 27.000 hours "machining"

:HBM-130XL spindle diameter:130 mm x-travel:2000 mm y-travel:1800 mm z-travel:(ohne Gegenhalter) 2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3136 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:10 t table-size:1800 x 1600 mm T-slots:11 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:29300 kg main drive:15 kW Machine size (LxWxH):7030x4665x3800 mm 2-Axis DRO :von NEWALL f. X- und Y-Achse Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower maintenance and 80% failure rate reduced ? High rigidity spindle could insure the strong machining ? Worktable 4x90° position  ...

:HBM-130 | HBM-130L | HBM-130XL spindle diameter:130|130|130 mm x-travel:1600|2000|2000 mm y-travel:1400|1800|1800 mm z-travel:2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3200 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:8|10|10 t table-size:1600 x 1400|1800 x 1600|2200 x 2000 mm T-slots:9/11/12 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:22,5|24,5|25,5 t main drive:22 kW Machine size (LxWxH):6995/3647/342|7030/4665/3800|7030/4665/3800 mm PLC control:Siemens S7 servo motors:von Siemens/Fanuc/Fagor Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower mainten ...

Used cutting machine Hundegger K2 machining width 1250mm Manufacturer: Hundegger, DE Type: K2i - 5 1250mm Built: 2009 Condition: used, in operation, very good Consisting of: 1. Fully automatic wood conveying with feed roller conveyor and feed and feeding cross conveyor Consisting of a roller conveyor with cross-over from the cross conveyor with 5 strands equipped with hinge tape chains, which ensure injury-free transport Length: 9.2 m, Width: 2.2 m 2. Lower table swivel crosscut saw with 4-axis control With a carbide saw blade of 900 mm (11.0 KW) max. saw cutting depth: 300mm at 90° infinitely adjustable machining stroke with positioning drive pivotable 0- 360°, inclination 0-65°, drive servo-hydraulic, With this aggregate, all saw cuts, such as angles and shitging sections, longitudinal sections for burring and lruning, hewing or stash sections) are executed.  ...

Used cutting machine Hundegger K2 -5 machining width 625mm Manufacturer: Hundegger, DE Type: K2 - 5, 625mm Built: 2006 Condition: used, in operation, very good Consisting of: 1. Fully automatic wood conveying with feed roller conveyor and feed and feeding cross conveyor Consisting of a roller conveyor with cross-over from the cross conveyor with 5 strands equipped with hinge tape chains, which ensure injury-free transport Length: 9.2 m, Width: 2.2 m 2. Lower table swivel crosscut saw with 4-axis control With a carbide saw blade of 900 mm (11.0 KW) max. saw cutting depth: 300mm at 90° infinitely adjustable machining stroke with positioning drive pivotable 0- 360°, inclination 0-65°, drive servo-hydraulic, With this aggregate, all saw cuts, such as angles and shitging sections, longitudinal sections for burring and lruning, hewing or stash sections) are executed ...

The NEW CNC grinding VERECO RG 700/8500 is designed for the batch production of bench pins and connecting rod pins of crankshafts in a fully automatic cycle, or, for the production of individual parts in manual. It operates by means of a mobile grinding wheel unit both on the X axis and on the Z axis: this allows the grinding of different diameters in a single positioning of the piece. MAIN TECHNICAL FEATURES: Distance between tips: 8500 mm Drill height: 800 mm Maximum rotating Ø: 1600 mm Maximum weight of the balance piece: 10,000 kg Maximum grinding wheel dimensions (with recesses): 1600x900x160 mm Approximate machine weight: 98.000 kg NB: The aforementioned technical data, collected from the technical data sheet of the manufacturer, are to be considered non-binding and subject to change without notice. NUMERICAL CONTROL The Siemens 840 D electronic numerical contro ...

Capacity: 1,500 K/h Types of boxes: Boxes of 6, 0.7 VdF, 200 x 300 x 320 mm, transverse Boxes of 6, 1.0 VdF, 200 x 300 x 320 mm, transverse Boxes of 12, 0.7 VdF, 355 x 270 x 310 mm, longitudinal running Boxes of 24, 0.2 goiter neck KK, 300 x 400 x 210 mm, longitudinal run Boxes of 24, 0.2 goiter neck SV, 300 x 400 x 210 mm, longitudinal run The following evaluations are integrated: crate geometry, foreign bodies, crate color, bottle height, bottle color + Box pusher VT-1201 Year of construction: 2016 Capacity: 1,500 K/h Box types: Boxes of 6, 0.7 VdF, 200 x 300 x 320 mm, cross run 6-boxes, 1.0 VdF, 200 x 300 x 320 mm, cross run Boxes of 12, 0.7 VdF, 355 x 270 x 310 mm, lengthwise run 24-boxes, 0.2 Kropfhals KK, 300 x 400 x 210 mm, longitudinal barrel 24-boxes, 0.2 goitre neck SV, 300 x 400 x 210 mm, longitudinal run The following evaluations are integrated: crate geo ...

Specifications: Clamping surface: 1100 x 250 mm Number of T-slots: 3 Travel: Longitudinal movement, automatic: 680 mm Longitudinal movement, manual: 700 mm Transverse movement, automatic: 260 mm Transverse movement, manual: 280 mm Vertical movement, automatic: 390 mm Vertical movement, manual: 400 mm Displacement of the upper arm, manual: 540 mm Vertical milling head: Speed range: (18) 38 - 1800 1/min Tool holder: SK 40 Distance spindle nose/table: 150 - 480 mm Distance spindle center/stand: 220 - 760 mm Horizontal spindle: Speed range: (18) 32 - 1600 1/min Tool holder: SK 40 Distance spindle center/table: 60 - 400 mm Auto. Feeds & Rapid Traverse: Number of feeds: 18 Feed range, longitudinal and transverse: 15 - 1200 mm/min Feed range, vertical: 5 - 400 mm/min Rapid traverse, longitudinal and transverse: 2450 mm/min Rapid traverse, vertical: 810 mm/min Drive:  ...

Hersteller : Costa, Type: Optima 2000 CNC, Year: 1993, Control: CNI, Positioning of CNC axis: yes, Double edge bander: yes, Hand-over: yes, Longitudinal edge banding: yes, Sanding machine: no, Tool exchange places: yes, Working width min-max mm: 320-4000, Arbeitshöhe min-max mm: 30-100, Saw Units: 1, Double edge bander - milling units/side total: 1, Spindle length of double edge bander mm: 620, Double edge bander with stoppers: yes, Longitudinal milling units total: 5, Längsprofiler Fräsaggregate linke Seite: 2, Längsprofiler Fräsaggregate rechte Seite: 2, Längsprofiler Fräsaggregate linke Seite: 2, Longitudinal milling units horizontally: 1, Spindle length - longitudinal milling mm: 320, Spindle diameter - longitudinal milling mm: 50, Feeding speed min-max m/min: 2,5-23, Vorschub stufenlos: yes, inkl Werkzeuge, Year :1993

Flame cutting system, flame cutting machine, longitudinal carriage, chassis, welding carriage, longitudinal carriage, welding machine, welding carriage, inert gas welding device, longitudinal seam welding system, longitudinal seam welding machine, longitudinal seam welding device, Rail Runner, welding tractor -Burning cutting head of a: Burning system copying system -Feed: adjustable -Dimensions: 460/210/230mm -Weight: 7.6kg

Torch cutting system, torch cutting machine, longitudinal carriage, chassis, welding carriage, longitudinal carriage, welding machine, welding carriage, inert gas welding device, longitudinal seam welding system, longitudinal seam welding machine, longitudinal seam welding device, rail runner, welding tractor -Cutting machine of a: Burning plant -Motor: 180 V/30 W. -Dimensions: 580/370/H280 mm -Weight: 17.5 kg

Submerged arc welding device, welding accessories, forming gas welding device, longitudinal carriage, chassis, welding carriage, longitudinal carriage, welding machine, welding carriage, inert gas welding device, longitudinal seam welding system, longitudinal seam welding machine, longitudinal seam welding device, rail runner -Submerged arc welding machine without: power source -Submerged arc welding machine type: Minisaf 02 -Control box SUBARC 3 -Intermediate hose package -Equipment -Dimensions: 1200/800/H500 mm -Weight: 215 kg

Manufacturer: CUGIR / Romania Tip: FV 36 CF Table size: 360 x 1600 mm Curse: - longitudinal: 1100 mm - vertical: 450 mm - transversal: 300 mm Main shaft taper: ISO 50 Spindle speed range: 32 - 1600 rpm. Work advances: - longitudinal and transverse: 19 - 950 mm/min. - vertical: 1/3 of the longitudinal advance Fast forward: - longitudinal and transverse: 2300 mm/min. - vertical: 1/3 of the longitudinal advance Main electric motor power: 7.5 kW Net weight of the car: 3450 kg

number of spindles:6 spindle passage:51 mm Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: S51 PC Yob: 2008 Six-spindle automatic lathe with 6 main spindles max. nominal diameter D=51mm hirth-coupled spindle drum, Control: Software SICS 2000 / Windows 2000 / Beckhoff Twincat Position I: cross slide X-I; longitudinal slide Z-I Position II: compound slide cross XZ-II; longitudinal slide Z-II Position III: compound slide cross XZ-III; longitudinal slide Z-III Position IV: compound slide cross XZ-IV; compound slide longitudinal ZX-IV Position V: cross slide X-V; compound slide longitudinal ZX-V Position VI: cross slide X-VI; pick up for rear machining; second cross slide XX-VI Coolant tank with hinged belt chip conveyor; Coolant pump with two pressure connections: q= 180 l/min, p1 bar; q=70 l/min, p=7 bar; Workpiece collecting device with belt conveyor (low ...

CNC Horizontal Lathe POREBA Manufacturer: POREBA Model TCF 200 Technical datails: Swing over bed: 2000 mm Swing over carriage: 1680 mm Max.distance between centres: 10000 mm Centers’ height: 1000 mm Max. weight of workpiece in centers: 30000 kg Spindle drive motor power: 75 kW Headstock: spindle clearance: 105mm Chuck wheel diameter: 1600 mm Max. diameter of clamping in jaws: 1400 mm Min. diameter of clamping in jaws: 250 mm Bed: Bed width on the guides height: 1500 mm Bed height: 600 mm Carriage: Guides length of longitudinal carriage: 1400 mm Transversal carriage travelling: 500 mm Longitudinal feed range regulated stepless: 0,1 – 400mm / min Travelling feed range regulated stepless: 0,1 – 200 mm / min Longitudinal carriage skip travelling: 4000 mm / min Transversal carriage skip travelling: 2000 mm / min Lon ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 135 Operating hours: 1012 Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2 m/min transversal: 2 m/min vertical: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm Various accessories: Digital readout number of ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2 m/min transversal: 2 m/min vertical: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm Various accessories: Vice Coolant system Lamp

table length: 2000 mm table width: 1800 mm table load: 12,5 t total power requirement: 10 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: m Table size approx. 2,000 x 1,800 mm Max. weight of workpiece, approx. 12,500 kg Table travel, longitudinal 1,250 mm Table height above floor 920 mm Longitudinal feed 0.63 - 2,000 mm/min Turning feed, with Ø 1,000 mm 1 - 3,150 mm/min Longitudinal quick feed 2,000 mm/min Turning quick feed, with Ø 1,000 mm 3,150 mm/min Weight of machine 7,500 kg External dimensions of machine 3,700 x 2,100 x 920 mm Total electrical load 10 KW - 180 V - 50 Hz Accessories / Special Features Telescopic covers for the guides. Infinitely variable table feed. Optical display for setting and reading the longitudinal adjustment. Optical display for setting and reading the angle. Condition : Satisfactory to good. Machine can be inspected under power ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 650 mm Table width: 250 mm Longitudinal travel (X-axis): 330 mm Transversal travel (y axis): 400 mm Vertical travel (z axis): 475 mm Spindle speeds: number (steps): 12 from: 63 rpm up to: 2800 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 4 mm/min up to: 500 mm/min vertical from: 2 mm/min up to: 200 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2.5 m/min vertical: 1.0 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.2 HP Machine´s weight about: 950 kg Overall dimensions machine: Length: 1600 mm Width: 1100 mm Height: 1650 mm

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 210 mm Longitudinal travel (X-axis): 450 mm Transversal travel (y axis): 175 mm Vertical travel (z axis): 400 mm Distance from vertical spindle to table: 320 mm Spindle speeds: number (steps): 9 from: 60 rpm up to: 1200 rpm Taper in spindle: 30 ISO Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 216 mm/min vertical from: 12.0 mm/min up to: 216 mm/min Rapid traverse: longitudinal: 1.0 m/min vertical: 0.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 1.5 HP Total power required: 2.0 HP Machine´s weight about: 880 kg Overall dimensions machine: Length: 1100 mm Width: 1100 mm Height: 1600 mm

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 800 mm Table width: 300 mm Longitudinal travel (X-axis): 495 mm Transversal travel (y axis): 292 mm Vertical travel (z axis): 399 mm Distance from horizontal spindle to table: 480 mm Spindle speeds: stepless from: 50 rpm up to: 3400 rpm Taper in spindle: 40 ISO Feeds stepless: longitudinal from: 10.0 mm/min up to: 600 mm/min transversal from: 10.0 mm/min up to: 600 mm/min vertical from: 10.0 mm/min up to: 600 mm/min Vertical quill travel: 45 mm Rapid traverse: longitudinal: 1.5 m/min transversal: 1.5 m/min vertical: 1.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 4.0 HP Total power required: 5.0 HP Machine´s weight about: 1300 kg Overall dimensions machine: Length: 1700 mm Width: 1500 mm Height: 1800 mm Various accessories: Coolant syst ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 300 mm Longitudinal travel (X-axis): 450 mm Transversal travel (y axis): 170 mm Vertical travel (z axis): 410 mm Distance from vertical spindle to table: 320 mm Spindle speeds: number (steps): 18 from: 60 rpm up to: 2400 rpm Taper in spindle: 40 ISO Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 216 mm/min vertical from: 6.0 mm/min up to: 108 mm/min Rapid traverse: longitudinal: 1.0 m/min vertical: 0.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 1.5 HP Total power required: 2.0 HP Machine´s weight about: 800 kg Overall dimensions machine: Length: 1200 mm Width: 1100 mm Height: 1600 mm Various accessories: Coolant system Rigide table Quick drill and milling head Lamp

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 300 mm Longitudinal travel (X-axis): 450 mm Transversal travel (y axis): 170 mm Vertical travel (z axis): 410 mm Distance from vertical spindle to table: 320 mm Spindle speeds: number (steps): 18 from: 60 rpm up to: 2400 rpm Taper in spindle: 30 ISO Feeds steps:: 8 longitudinal from: 12.0 mm/min up to: 216 mm/min vertical from: 6.0 mm/min up to: 108 mm/min Rapid traverse: longitudinal: 1.0 m/min vertical: 0.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 1.5 HP Total power required: 2.0 HP Machine´s weight about: 800 kg Various accessories: Coolant system Steady Rigide table

The FU 251 universal milling machine was built in 1983. The machine is equipped with a table with dimensions (L x W) 1120 x 250 mm. The mechanical feeds of the working table in the X / Y / Z axis are respectively 765/230/390 mm, and manual feeds are 785/250/410 mm. The milling machine has three T-slots with a spacing of 14 mm and a steady rest. The total weight of the machine is 2 tons. Technical data of the universal milling machine FU 251 - working dimensions of the table (length x width): 1120x250 mm - mechanical table feeds in the X / Y / Z axis: 765/230/390 mm - manual table feeds in the X / Y / Z axis: 785/250/410 mm - accelerated longitudinal and transverse feed: 2500 mm / min - accelerated vertical feed: 1040 mm / min - longitudinal and transverse feed speed range: 12.5-630 mm / min, - vertical feed speed range: 5.2-262 mm / min - speed range of the longitudinal and  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 900 mm Table width: 300 mm Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 370 mm Travel of the upper slide: 400 mm Spindle speeds: number (steps): 12 from: 45 rpm up to: 2000 rpm Taper in spindle: 40 ISO Feeds steps:: 12 longitudinal from: 18 mm/min up to: 800 mm/min transversal from: 18 mm/min up to: 800 mm/min vertical from: 7.2 mm/min up to: 320 mm/min Rapid traverse: longitudinal: 2.5 m/min transversal: 2.5 m/min vertical: 1.0 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 6 HP Machine´s weight about: 1900 kg Overall dimensions machine: Length: 2000 mm Width: 1600 mm Height: 1700 mm Various accessories: Digital readout number of axis:: 3

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 300 mm Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 470 mm Travel of the upper slide: 400 mm Spindle speeds: number (steps): 12 from: 45 rpm up to: 2000 rpm Taper in spindle: 40 ISO Feeds steps:: 12 longitudinal from: 18.0 mm/min up to: 800 mm/min transversal from: 18.0 mm/min up to: 800 mm/min vertical from: 7.2 mm/min up to: 320 mm/min Rapid traverse: longitudinal: 2.5 m/min transversal: 2.5 m/min vertical: 1.0 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 6.0 HP Machine´s weight about: 1900 kg Overall dimensions machine: Length: 2000 mm Width: 1600 mm Height: 1700 mm Various accessories: Digital readout number of axis:: 3 Manufacturer: Mitutoyo Coolant system La ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Operating hours: 3811 Technical data Table length: 700 mm Table width: 250 mm Longitudinal travel (X-axis): 320 mm Transversal travel (y axis): 220 mm Vertical travel (z axis): 410 mm Spindle speeds: stepless from: 56 rpm up to: 3150 rpm Taper in spindle: 40 ISO Feeds stepless: longitudinal from: 8 mm/min up to: 1000 mm/min transversal from: 8 mm/min up to: 1000 mm/min vertical from: 8 mm/min up to: 1000 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2 m/min transversal: 2 m/min vertical: 2 m/min Voltage 50 Hz 3x: 380 Volt Motor power: 1.8 kW Total power required: 2.6 kW Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 1500 mm Various accessories: Vice: width: 120 mm Digital readout number of axis::  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 210 mm Longitudinal travel (X-axis): 260 mm Transversal travel (y axis): 150 mm Vertical travel (z axis): 310 mm Travel of the upper slide Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 410 mm Spindle speeds: stepless from: 58 rpm up to: 2000 rpm Taper in spindle: 30 ISO Feeds steps:: 10 Feeds stepless: longitudinal from: 12.0 mm/min up to: 400 mm/min vertical from: 12.0 mm/min up to: 400 mm/min Rapid traverse: longitudinal: 1.2 m/min vertical: 1.2 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Total power required: 3.0 HP Total power required Machine´s weight about: 700 kg Overall dimensions machine: Length: 1500 mm Width: 1100 mm Height: 1600 mm Various accessories: D ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 350 mm Longitudinal travel (X-axis): 500 mm Transversal travel (y axis): 300 mm Vertical travel (z axis): 380 mm Distance from vertical spindle to table: 470 mm Spindle speeds: number (steps): 18 from: 40 rpm up to: 2000 rpm Taper in spindle CN: 40 Feeds steps:: 18 longitudinal from: 10.0 mm/min up to: 500 mm/min transversal from: 10.0 mm/min up to: 500 mm/min vertical from: 10.0 mm/min up to: 500 mm/min Vertical quill travel: 100 mm Rapid traverse: longitudinal: 1.5 m/min transversal: 1.5 m/min vertical: 1.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 4.0 HP Machine´s weight about: 1100 kg Overall dimensions machine: Length: 2200 mm Width: 1800 mm Height: 2000 mm Various accessories: Digital readout number of axis:: ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 305 mm Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 490 mm Spindle speeds: number (steps): 18 from: 38 rpm up to: 1510 rpm Taper in spindle: 40 ISO Feeds steps:: 18 longitudinal from: 12.0 mm/min up to: 1050 mm/min transversal from: 12.0 mm/min up to: 1050 mm/min vertical from: 6.0 mm/min up to: 525 mm/min Rapid traverse: longitudinal: 3.5 m/min transversal: 3.5 m/min vertical: 1.7 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 5.5 HP Total power required: 7.5 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1800 mm Width: 1600 mm Height: 1800 mm

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 305 mm Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 490 mm Spindle speeds: number (steps): 18 from: 38 rpm up to: 1510 rpm Taper in spindle: 40 ISO Feeds steps:: 18 longitudinal from: 12.0 mm/min up to: 1050 mm/min transversal from: 12.0 mm/min up to: 1050 mm/min vertical from: 6.0 mm/min up to: 525 mm/min Rapid traverse: longitudinal: 3.5 m/min transversal: 3.5 m/min vertical: 1.7 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 5.5 HP Total power required: 7.5 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1800 mm Width: 1600 mm Height: 1700 mm Various accessories: Universal milling head Set of toolholders

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 155P Operating hours: 3100 Technical data Table length: 1000 mm Table width: 560 mm Table load max.: 1000 kg Longitudinal travel (X-axis): 1000 mm Transversal travel (y axis): 500 mm Vertical travel (z axis): 550 mm Distance from spindle to table: 100 - 650 mm Taper in spindle: 40 ISO Spindle speeds: stepless from: 20 rpm up to: 3100 rpm Feeds: longitudinal from: 2 mm/min up to: 2000 mm/min transversal from: 2 mm/min up to: 2000 mm/min vertical from: 2 mm/min up to: 2000 mm/min Rapid traverse: longitudinal: 10 m/min transversal: 10 m/min vertical: 10 m/min Vertical quill travel: 80 mm Voltage 50 Hz 3x: 380 Volt Milling spindle motor: 11 kW Feed motor: 2.9 kW Machine´s weight about: 5500 kg Overall dimensions machine: Length: ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1700 mm Table width: 350 mm Longitudinal travel (X-axis): 1200 mm Transversal travel (y axis): 400 mm Vertical travel (z axis): 530 mm Spindle speeds: number (steps): 12 from: 32 rpm up to: 1600 rpm Feeds steps:: 18 longitudinal from: 10 mm/min up to: 700 mm/min transversal from: 10 mm/min up to: 700 mm/min vertical from: 5 mm/min up to: 530 mm/min Rapid traverse: longitudinal: 3 m/min transversal: 3 m/min vertical: 1.5 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 10 HP Machine´s weight about: 3300 kg Overall dimensions machine: Length: 2490 mm Width: 2535 mm Height: 2010 mm Various accessories: Set of toolholders

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1250 mm Table width: 350 mm Longitudinal travel (X-axis): 850 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 470 mm Table load max.: 400 kg Spindle speeds: number (steps): 12 from: 45 rpm up to: 2000 rpm Taper in spindle: 40 ISO Feeds steps:: 12 longitudinal from: 18 mm/min up to: 800 mm/min transversal from: 18 mm/min up to: 800 mm/min vertical from: 7.2 mm/min up to: 320 mm/min Rapid traverse: longitudinal: 2.70 m/min transversal: 2.75 m/min vertical: 1.10 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 10 HP Total power required: 7 HP Machine´s weight about: 1950 kg Overall dimensions machine: Length: 2000 mm Width: 1700 mm Height: 2000 mm Various accessories: Set of toolholders Lamp

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 650 mm Table width: 250 mm Longitudinal travel (X-axis): 330 mm Transversal travel (y axis): 400 mm Vertical travel (z axis): 475 mm Spindle speeds: number (steps): 12 from: 63 rpm up to: 2800 rpm Taper in spindle: 30 ISO Feeds stepless: longitudinal from: 4 mm/min up to: 500 mm/min vertical from: 2 mm/min up to: 200 mm/min Vertical quill travel: 60 mm Rapid traverse: longitudinal: 2.5 m/min vertical: 1.0 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.2 HP Machine´s weight about: 950 kg Overall dimensions machine: Length: 1600 mm Width: 1100 mm Height: 1650 mm Various accessories: Positionier- und Streckensteuerung Digital readout number of axis:: 3 Manufacturer: ELESTA Coolant system Lamp Chip tray

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 305 mm Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 250 mm Vertical travel (z axis): 490 mm Spindle speeds: number (steps): 18 from: 38 rpm up to: 1510 rpm Taper in spindle: 40 ISO Feeds steps:: 18 longitudinal from: 12.0 mm/min up to: 1050 mm/min transversal from: 12.0 mm/min up to: 1050 mm/min vertical from: 6.0 mm/min up to: 525 mm/min Rapid traverse: longitudinal: 3.5 m/min transversal: 3.5 m/min vertical: 1.7 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 5.5 HP Total power required: 7.5 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1800 mm Width: 1600 mm Height: 1800 mm Various accessories: Coolant system Cam control Steady Set of collets Set of short cutter arbors Se ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 600 mm Table width: 210 mm Number of T-channels: 4 T-channel width: 12 mm Distance of the T-slots: 40 mm Longitudinal travel (X-axis): 260 mm Transversal travel (y axis): 150 mm Vertical travel (z axis): 310 mm Travel of the upper slide Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 410 mm Spindle speeds: stepless from: 58 rpm up to: 2000 rpm Taper in spindle: 30 ISO Feeds steps:: 10 Feeds stepless: longitudinal from: 12.0 mm/min up to: 400 mm/min vertical from: 12.0 mm/min up to: 400 mm/min Rapid traverse: longitudinal: 1.2 m/min vertical: 1.2 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2.0 HP Total power required: 3.0 HP Total power required Machine´s weight about: 700 kg Overall dimensions  ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Number of axis total: 3 Table length: 600 mm Table width: 260 mm Number of T-channels: 5 T-channel width: 12H7 mm Distance of the T-slots: 40 mm Longitudinal travel (X-axis): 260 mm Transversal travel (y axis): 150 mm Vertical travel (z axis): 310 mm Travel of the upper slide Distance from vertical spindle to table: 310 mm Distance from horizontal spindle to table: 410 mm Spindle speeds: stepless from: 58 rpm up to: 2000 rpm Taper in spindle: 30 ISO Head inclining + -: 90 ° Feeds steps:: 10 Feeds stepless: longitudinal from: 12 mm/min up to: 400 mm/min vertical from: 12 mm/min up to: 400 mm/min Rapid traverse: longitudinal: 1.2 m/min vertical: 1.2 m/min Voltage 50 Hz 3x: 380 Volt Motor output: 2 HP Total power required: 3 HP Machine´s weight about: 700 ...

Note: We have 6 pieces of this machine in stock! Manufacturer: Gildemeister Type: GS 36 – 6 A/C Machine no.: 7.0176 Year of construction: 1987 Weight: 11t General / technical data: Portal-6spindle automatic lathe with measuring device and automatic feeding Spindle dividing circuit: 300mm Number of longitudinal slides: 6 Number of cross slides: 2 gr. cross slide stroke: 60mm gr. longitudinal slide stroke: 125mm Spindle speeds: Infinitely variable 562 – 3373 rpm Main time range: Stepless 1.95 – 78 sec. Low time range: 0.79 – 2.13 sec. Drive power: DC motor spindles 20kW; Feed rates 8kW Installation area: approx. 1720 x 4700mm Remark: The machine cannot be converted for bar work. Equipment: – 1 creep gear drive for set-up operation – 1 automatic central lubrication device – 1 coolant device with lines and pu ...

Suspended crane runway crane system DEMAG type KBK 1 Year of construction approx. 2000 Monorail overhead conveyor with monorail Crane bridge Light crane system made of KBK modular system profiles Load capacity: 125 kg Span: 5 meters Distance longitudinal rails: 4.1 meters Longitudinal member length complete: 12 meters Girder profile cross beam = KBK1 Carrier profile longitudinal track = KBK1 Consisting of: 29 meters system profile KBK-1 (4x 6000 mm + 1x 5000 mm) 1 piece carriage for the Crane suspension 2 pieces Double carriage for the longitudinal rails 10 pieces screw claws for crane suspension or ceiling mounting (without carrier clamps) 6 pieces End cover suitable for the track KBK1; used

SECOND-HAND CN SANDING LINE FOR STRAIGHT AND CURVED ELEMENTS OMEF MOD. FUTURE -Loader - 2 Top Transversal Horizontal Belts - 2 Bottom Transversal Horizontal Belts - 1 top horizontal longitudinal pneumatic roller - 1 bottom horizontal longitudinal pneumatic roller - 2 Right Vertical Transversal Belts - 2 Left Vertical Transversal Belts - 1 right longitudinal pneumatic roller - 1 left longitudinal pneumatic roller - 2 Orbital Sanders - CE rules - Year 2000

Machine: Boxmaker LCR Manufacturer: LCR Lorenzoni ( Bo. ) Model: Quark 2500 A Year of construction: 2007 Condition: very good (used) Carton machine type Quark 2500 A for processing continuous cardboard from the stack The following language changes are possible: German English Italian French Machine Description: The machine listed here belongs to the series of static machines, i.e. the operations transverse to the machine are carried out on the upright carton. The machine is designed for high productivity. The maximum working width of the cardboard box is 2,400 mm. All settings of the tools are carried out automatically. 1) Main Machine Body (Carton Cutting Machine): Linear cross-cutting group for head-to-foot cutting and Cross-cuts on the cardboard box. Linear transverse groove group for the transverse grooves on the carton. ( Supplied as trans ...
