Internal grinding machines used for sale (9)

1 Internal and surface grinding machine Make: WEMA Glauchau Model No.: SI 6/1 AS-Nx500 Year of Make: 1989 Grinding depth: 500 mm Workpiece spindle speed range: 40 – 400 mm Distance from workpiece spindle flange up to the grinding spindle carrier: 1450 mm Adjustment range of the internal grinding device: 530 mm Max. workpiece diameter: 500 mm Distance from workpiece spindle flange to steady rest seat: 280 – 650 mm Grinding diameter inner grinding: 40 – 400 mm Grinding diameter external grinding: 400 mm Rapid traverse: 10m/min. Grinding infeed: 0.1 – 8 m/min. Weight of the machine: 6.5 tons.

internal diameter: - mmgrinding depth: - mmswing diameter: - mm: 220 mm: ja total power requirement: - kWweight of the machine ca.: 1,4 tdimensions of the machine ca.: - mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MAX DIAM 200

internal diameter: 5-200 mmgrinding depth: 250 mmspindle stock travel: 180 mmspindle bore: 50 mmturning speed range - spindle: 120-1000 U/minweight of the machine ca.: 3 tdimensions of the machine ca.: 2.4 x 1.25 x 1.75 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inner diameter: 150 mm Grinding depth: 200 mm Table lift: 425 mm large oscillating circuit diameter: 250 / 420 mm Bore: 80 mm Table speed -infinitely-0.5 - 10 m/min Workpiece speeds: 125/176/246/350 rpm Spindle speed: 17000 rpm Total power requirement: 2.2 / 0.5 / 0.9 kW Machine weight ca. 2 t Space requirement approx. 2.40 x 1.20 x 1.45 m Control: conventional

internal diameter: 800 mmgrinding depth: 500 mmswing diameter: 850 mmtotal power requirement: kWweight of the machine ca.: 6,4 tdimensions of the machine ca.: mUsed internal cylindrical grinding machine with face grinding devicein special design with enlarged swing diameterand extended, hydraulic transverse movementReconstructed and modernized 1995 in the Glauchau manufacturer’s plant,put into operation 19961. TECHNICAL DATA1.1 Working areaGrinding diameter in the workpiece guardinternal grinding, min./max. mm 30/630(800)External grinding, max. mm 800Grinding depth, up to approx. mm 500Table stroke mm 800Workpiece diameter, max. mm 800Swing diameterin workpiece protection, max. mm 800Without workpiece protection, approx. mm 850Distance from workpiece spindle headto grinding spindle carrier, max. mm 1225Adjustment of the internal grinding deviceon the table, max. mm 5451.2 Workpiece h ...

Stock number: 3732 INTERNAL CYLINDRICAL GRINDING MACHINE Manufacturer: TRIPET HAUSER HTT CNC , Type: TST 100 CNC-4R Machine NO.: T1000256, Year of construction: 2002 Specifications: Grinding length 300 mm Size internal grinding diameter 0.5-75 mm Center height B axis- 130 mm C-ash main spindle 3" - 100 rpm degree Z ash 340 - 0.0005 mm mm B- Ashes Manuel -30/+60 degree X ash cross slide 50 mm Grinding spindle speeds 4 spindles - 25,000 - 45,000 2x 75000 rpm Resolution 0.0005 mm Tool spindle dock speeds B- axis 10-1500 rpm CNC control. Control Brüsch TPS 3000 Fabr. Accessories: Centering chuck PHM Heyn Pneumatic. 250 mm Ø Papir Filter Knoll Length: 2500 mm, Height: 2300 mm, Width: 2500 mm, Weight: 3500 kg

min./max. hole to grind: 8 / 10 mmmax. grinding depth by internal grinding: 150 mmswing dia.: 450 mmworkpiece spindle bore: 35 mmmax. swivability: 30 °min/max. table longitudinal travel: 5 / 150 mm/minInternal Grinding Machine | D14 - 1973The machine is in a well-maintained condition.Bitte entnehmen Sie weitere technische Details im Angebot.- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -#Tags: D-14 | D 14The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Spindle speed min: 9,000 Umd.min Max: 15.000 Umd.min Tip height min: 230 mm Max: 510 mm Spindle stroke: 210 mm Horiz. Table large: 700 x 1000 mm Table stroke: 1,800 mm Equipped with: - feed table - feed Hor. Grinding movement - coolant equipment - protection doors table
