hidro precis used for sale

Very high-quality CNC – controlled precision sheet metal round bending machine with automatic bending sequence calculation – automatic CNC – controlled double-sided pre-bending – conical bending device, three hydraulically driven rollers (one hydraulic motor per roll), hydraulic linear sub-roll adjustment – hard chrome-plated piston rods – hardened and ground rollers - PILZ® laser protection - BECKHOFF® CNC – control with Ethernet technology and large touch screen - DANFOSS® precision hydraulics – central lubrication system Maximum bending length 2,000 mm Roll diameter 170 mm Smallest weft diameter = 1.1 x the roll diameter The rollers run in bronze plain bearings. Nominal pre-bending performance over the entire bending length at 5 x D = 5 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 7 mm sheet steel/ST40 Drive  ...

air bearing high precision bearings Brand: Drevetti Regman Dimensions: 120 x 60 x 18 mm For more data, please see also photos.

air bearing high precision bearings Brand: Drevetti Regman Dimensions: 95 x 45 x 15 mm

x-travel: 400 mm y-travel: 250 mm workpiece height: 485 mm Control: ELESTA CNC 314 total power requirement: 10 kW weight of the machine ca.: 4000 kg dimensions of the machine ca.: m H A U S E R CNC - Controlled Vertical Precision Coordinate Grinding Machine Model S 3 – CNC 314 Year 1987 / 1998 partially reconditioned by Swiss-HTT # 0463 ____________________________________________________________ Table size, approx. 600 x 380 mm Max. load on table, approx. 300 kg Table travel, longitudinal, max. (X Axis) 400 mm Table travel, cross, max. (Y Axis) 250 mm Vertical adjustment of grinding head max. (W Axis) 450 mm Stroke of grinding spindle, max. (Z Axis) 120 mm Table Longitudinal and cross feeds (X/Y-Axis) 0 – 1.500 mm/min Speed of grinding head stroke 15 – 7.500 mm/mi ...

grinding diameter: 350 mm grinding length: 400 mm centre height: 175 mm Control: FANUC 16i-T max. workpiece weight between centers: 80 kg x-axis: 300 mm z-axis: 485 mm b-axis: 0-30 ° turning speeds: 3200 U/min total power requirement: 38 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 4,5x2,0x2,2 m with charging system Seckler Modulo 5 The machine has produced parts with a precision of 5-6µ. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 750 mm y-travel: 560 mm z-travel: 600 mm Control: HEIDENHAIN iTNC 530 total power requirement: 70 kW weight of the machine ca.: 11.000 kg dimensions of the machine ca.: m D E C K E L M A H O (Germany) Vertical CNC Machining Centre with high speed linear drives in 3 Axis and in double column design for high precision work Model DMC 75 V LINEAR Year 2005 _______________________________________________________ Working range: Longitudinal stroke X Axis 750 mm Vertical stroke Z Axis 600 mm Cross stroke Y Axis 560 mm Table clamping size 950 x 650 mm Max. Table load 1.000 kg Max. height of workpiece 600 mm Tool holder Cone HSK 63 Spindle (KESSLER) speeds 18,000 rpm Torque, max. 86/1 ...

Gold – Inserts System Tools Box window set Product Name: Inserts Manufacturer: Gold Werkzeuge GmbH Condition: used For the production of profiled single or box windows Slotting tools - Indexable insert version HW(HM) - Z-2 - Zero diameter 300 mm - BG test - screwed to precision threaded bushings 50/40 mm Longitudinal tools - with zero – diameter 111.5 mm Tool set consisting of: 1x slot set for frame 1x pin set for frame pins on top 1x cone set for frame frames at the bottom 1x inner profile set for glare frames inside side and top 1x inner profile set for frame inside bottom 1x inner profile set for wings inside all around 1x slot set for grand pianos 1x cone set for wings 1x outer profile set for wings all around 1x outer profile set for wings - middle seam Price: 3.750,00 € plus VAT from location Grunow (Brandenburg) Shipping is of  ...

bore capacity in steel (diameter): 30 mm x-travel: 850 mm y-travel: 435 mm Control: HEIDENHAIN TNC 150 total power requirement: 16 kW weight of the machine ca.: 3500 kg dimensions of the machine ca.: m F E H L M A N N (Switzerland) CNC-Controlled High Precision Drilling and Milling Machine with HEIDENHAIN CNC-Control Model TNC 150 Model PICOMAX 100 CNC – 2 + A Year 1985 Serial No. 16 085 109 _______________________________________________________________ Table travel: Longitudinal ( X-Axis) 850 mm Cross (Y-Axis) 435 mm Milling/Boring head travel vertical ( Z-Axis) 210 mm Table size /Clamping area 500 x 1.570 resp. 390 x 1.280 mm Mounting height below spindle, approx. 140 / 690 mm Height adjustment of Milling head max. 540 mm Distance between spindle and column 450 mm Spindle tape ...

: neu : 12 - 14 Wochen ab Auftrag : Deutschland : 4010 mm : 2 mm : 1.5 mm : 4 ELECTROCINEMATIC DRIVE OF THE BENDING JOINTS millmeter precise adjustment of the clamping beam BMS MULTI-Touchcontrol electric powered rotary shear electronic depth stop flexible material supports inclined bending beam optimized geometry of the clamping beam safety equipment accoring to the control rules BG Germany 3 year warranty on stands and tension arms. Quality Made in Germany. FURTHER MODELS FROM3 UP TO12 M LENGTH AND FROM 1,25 MM UP TO 2,00 MM BENDING CAPACITY ON REQUEST. OPTIONS: Extended depth 1.250 mm price on request Conical depth stop to bend conical profiles and narrow/wide bendings for easy intermateing price on request clamping beam made out of hardox price on request Prices ex works Germany. Transport and commissioningat customers place on request. The data for this ad was created with Modul ...

internal diameter: 2 - 40 mm grinding depth: - mm swing diameter: 285 mm total power requirement: 5,5 kW weight of the machine ca.: 1,5 t dimensions of the machine ca.: m Max. Distance chuck flange - wheelhead 390 mm Accessories: Grinding spindle, make PRECISE 20.000 - 66.000 rpm, power 1.3 kW Grinding spindle, make PRECISE 60.000 - 120.000 rpm, power 0.23 kW magazine The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 400 mm gear width: 0 mm module: pinion diameter - max.: 254 mm axial cross angle: 90 ° total power requirement: 15 kW weight of the machine ca.: t dimensions of the machine ca.: m This machine is very suitable for precision production testing of spiral and hypoid bevel gears with shaft angle 90°. The gear spindle is vertical and the pinion spindle is horizontal. The pinion cone distance can be adjusted while the machine is working in order to find the optimal mounting position whereby the gear is loaded with a preset torque. The axial pinion position can be adjusted until the quietest meshing position of the traction flank is found. Likewise, the thrust flank can be tested during the return run. Marking compound is sprayed on both sides of the teeth so the flank contact pattern can be seen. Working cycles, as well as the positioning in the tooth gap, are automat ...

rolling capacity max.: NA t workpiece diameter: 38 mm workpiece length: 500 mm total power requirement: 24 kW weight of the machine ca.: 10 t dimensions of the machine ca.: m Max.Ø tool slide stroke 760 mm Max.Ø rack length 610 mm Length of workpiece between centres, approx. 500 mm Max. tooth width / profile width 92 mm Max. workpiece Ø 38 mm Tailstock stroke on outboard support, hydraulic, approx. 500 mm Module range 0.3 - 1.3 Total electrical load, approx. 24 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features KBH Workpiece Feed Device, standing parallel to the machine, at present set-up for feed-in and feed-out of shaft-formed workpieces, approx. Ø 16 x 200 mm long, with prism conveyor belt and lifting station for 2 shafts (blank and finished part), as well as workpiece positioning control. Originally, external gears were formed on the machine using  ...

: 15-150 m/min capacity 90 degrees: round: 325 mm capacity 90 degrees: flat: 500 x 300 mm capacity 45 degrees: round: 300 mm capacity 45 degrees: flat: 300 x 300 mm : 200 mm : 200 x 200 mm dimensions of saw-band: 4200 x 34 x 1,1 mm : 60 mm : 165 mm min. dia.: 5 mm work height max.: 750 mm total power requirement: 3 kW dimensions: 1300 x 2050 x 1400 mm weight: 910 kg Standard equipment: - Fast miter adjustment from 90° to 30° stepless to 0.5° accuracy according to scale. The miter turning point is the point of intersection between saw band and Material system, thereby no change in the length dimension - At each angular position of the saw frame, the material is parallel in 90° tightened - Complete coolant device with electric submersible pump - Machine stand with chip collecting tray - Precise saw band carbide roller guide, saw blade brush - 1 saw blade on machine 4-6 ZpZ - MEBA high  ...

x-travel: 700 mm y-travel: 715 mm z-travel: 850 mm Control: FANUC 16i-MB table-size: 500 x 500 mm table weight: 500 Kg a-axis: +45 / -135 ° c-axis: 360 ° distance table / middle of spindle: - mm number of spindle speeds: 10000 U/min/rpm tool taper: ISO 40 spindle drive: 18,5 / 22 kW rapid travel x/y/z: 70 m/min Tools changer: - pos. dimension of workpiece: dia 725 mm total power requirement: - kVA weight of the machine ca.: 21 t dimensions of the machine ca.: m The machines of the Clock series can also be used as 5-axis multitasking machines. The Clock series is characterized by high speed and precision. paired with a very stable machine concept. Thanks to the fast tool change and pallet exchange, the machines achieve a very high productivity. As 5-axis version the Clock 700 is equipped with a very stable Swivel table equipped. The swivel table is double on the axes and thus guarantees ...

max. wheel diameter: 400 mm max. number of teeth: 150 max. module: 5 total power requirement: 16 kW weight of the machine ca.: 10 t Workpiece Ø, min./max. 30 - 400 mm Number of teeth 6 - 150 Module range, max. 5 Tool holder shaft Ø SK 30 / 20 Tool speeds 4,000 rpm Spindle drive max. infinitely variable 1.8 kW Feeds, longitudinal and cross 0.001 - 12 m/min Workpiece speed, max. (1.5 kW) C Axis 2,000 rpm Workspindle slide 400 mm Tool speed, max. 3,000 rpm Tool holder SK 30 Total electrical load, approx. 16 kW - 380 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features BWO (HECKLER & KOCH) CNC Control model 785 H for altogether 7 axes. Input via monitor. The control has all the supervision and fault diagnosis features necessary for fully automatic working process. 2 workspindle units, left and right, which can be set at any angle. CNC controlled: Z and W Axes for tool cr ...

cutting diameter: 320 mm saw band length: 4160x 34 x 1,1 mm cutting width: 450 mm : 320 mm : 320 x 320 mm capacity 90 degrees: flat: 450 x 320 mm capacity 45 degrees: round: 320 mm : 180 mm Capacity 45° rectangular: 330 x 320 mm : 160 mm : 150 mm : 150 x 150 mm capacity 60 degrees: round: 240 mm capacity 60 degrees: square: 320 x 320 mm capacity 60 degrees: flat: 230 x 220 mm speed: 20 - 100 m/min total power requirement: 2,69 kW weight of the machine ca.: 1,03 t dimensions of the machine ca.: 2,23 x 0,88 x 1,89 m 280G,320G and 320GL are durable and stably laid out for universal separetion from full materials,pipes and profiles.A fast and precise mitre adjustment is characteristic within the range of 90 deg to 30 deg.The sawing property is situated in-line and becomes manuel strained in the angle of 90 deg. The machines are fitted with a removable coolant tank incorporating a submerged  ...

sheet width: 4000 mm plate thickness: 10 mm distance between columns: 4100 mm no. of strokes: 8 Hub/min table height: 805 mm back stop - adjustable: 1000 mm/mn column arm: 50 mm down holder: 19 Stück oil volume: 300 l cutting angle: 1,8 ° total power requirement: 22,75 kW weight of the machine ca.: 12 t dimensions of the machine ca.: 4,94 x 3,58 x 2,22 m Robust design & powerful body for perfect cutting Hardened and ground blades for long life and precise Proved and rigid design with swing beam top table Minimum deformation and optimum cutting quality with best cutting angle CE standards security The combination of economic and perfect cutting performance CNC controlled gap adjustment User friendly CNC touch screen control unit Sheet support arms Ball transfer tables and T-slot The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

cutting diameter: 320 mm saw band length: 4160 mm cutting width: 610 mm : 320 x 320 mm Capacity 90° rectangular: 610 x 320 mm dimensions of saw-band: 4160 x 34 x 1,1 mm : 320 mm : 320 x 320 mm Capacity 45° rectangular: 355 x 320 mm : 280 mm : 280 mm : 280 x 280 mm capacity 60 degrees: round: 320 mm capacity 60 degrees: square: 320 x 320 mm capacity 60 degrees: flat: 510 x 320 mm speed: 20 -100 m/min total power requirement: 2,7 kW weight of the machine ca.: 1,2 t dimensions of the machine ca.: 2,1 x 1,2 x 1,35 m Beka-Mak Lineer Sledge horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pum ...

sheet width: 3000 mm plate thickness: 16 mm distance between columns: 3100 mm no. of strokes: 8 Hub/min table height: 880 mm back stop - adjustable: 1000 mm/mn column arm: 50 mm down holder: 15 Stück oil volume: 400 l cutting angle: 2,5 ° total power requirement: 37,75 kW weight of the machine ca.: 15,0 t dimensions of the machine ca.: 4,04 x 3,75 x 2,37 m Robust design & powerful body for perfect cutting Hardened and ground blades for long life and precise Proved and rigid design with swing beam top table Minimum deformation and optimum cutting quality with best cutting angle CE standards security The combination of economic and perfect cutting performance CNC controlled gap adjustment User friendly CNC touch screen control unit Sheet support arms Ball transfer tables and T-slot The data for this ad was created with ModulMWS - the software solution of LogoTech o ...

cutting diameter: 90° / 810 mm saw band length: 8200 mm cutting width: 850 mm : 810 x 810 mm : 850 x 810 mm : 480 mm : 480 x 480 mm Capacity 45° rectangular: 480 x 810 mm table height: 585 mm cutting speed: 20 - 100 m/min dimensions of saw-band: 8200 x 41 x 1,3 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 5,5 kW weight of the machine ca.: 3,8 t dimensions of the machine ca.: 3,9 x 1,2 x 2,35 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. ?inverter ?hydromechan ...

sheet width: 4000 mm plate thickness: 6 mm distance between columns: 4100 mm no. of strokes: 12 Hub/min table height: 790 mm back stop - adjustable: 1000 mm/mn column arm: 50 mm down holder: 19 Stück oil volume: 200 l cutting angle: 1,5 ° total power requirement: 11,75 kW weight of the machine ca.: 10.2 t dimensions of the machine ca.: 5,12 x 3,5 x 1,77 m Robust design & powerful body for perfect cutting Hardened and ground blades for long life and precise Proved and rigid design with swing beam top table Minimum deformation and optimum cutting quality with best cutting angle CE standards security The combination of economic and perfect cutting performance CNC controlled gap adjustment User friendly CNC touch screen control unit Sheet support arms Ball transfer tables and T-slot The data for this ad was created with ModulMWS - the software solution of LogoTech oH ...

sheet width: 300 mm plate thickness: 6 mm distance between columns: 3100 mm no. of strokes: 14 Hub/min table height: 790 mm back stop - adjustable: 1000 mm/mn cutting angle: 1,5 ° column arm: 50 mm lower gears: 15 Stück oil volume: 200 l total power requirement: 11,75 kW weight of the machine ca.: 7,0 t dimensions of the machine ca.: 4,11 x 3,48 x 1,77 m Robust design & powerful body for perfect cutting Hardened and ground blades for long life and precise Proved and rigid design with swing beam top table Minimum deformation and optimum cutting quality with best cutting angle CE standards security The combination of economic and perfect cutting performance CNC controlled gap adjustment User friendly CNC touch screen control unit Sheet support arms Ball transfer tables and T-slot The data for this ad was created with ModulMWS - the software solution of LogoTech oHG ...

Capacity: 12 t Table length: 2000 mm Table width: 0 mm Stroke: 2000 mm CNC Brand: _Unknown / Other CNC Model: Leonard en Bauer MAKE   ARKU Germany TYPE    VRM 200/7/2000 + AH 1200/2000/MSG-4Q YEAR   1990 SPECIFICATIONS Controll   Leonard + Bauer Throat     2000 mm Maximum sheet thickness Steel   6,3 mm DIMENSIONS Length   6000 mm Width     4500 mm Height    3000 mm ARKU De-Coil & Straightener 2000 x 6,3 mm   Make           : ARKU Germany Typ              : VRM 200 / 7 / 2000 Serial No    : WO 1576 Age              : 1989 in Work 1990  ARKU Precision s ...

STRATASYS OBJET30 PRIME V3 3D PRINTING (year 2015) 3D printing of medical implements that require prolonged contact with the skin, such as headsets or surgical guides. Prototypes of joints, connections and sealants. The Objet30 Prime printer offers 12 different materials so you can create accurate prototypes of consumer products with smooth surfaces and flexible components from your desktop. Printing time: 1102 Specifications: layer thickness 28 microns for Tango materials; 16 microns for all other materials Precision 0.1 mm could vary depending on part geometry, size, orientation, material, and post-processing method model materials Biocompatible (MED610) Material for high temperature (RGD525) Rigid and opaque white material (VeroWhitePlus) Rigid and opaque blue material (VeroBlue) Rigid and opaque black material (VeroBlack) Rigid and opaque gray material (VeroGray) ...

Bore diameter: variabel mm Number of heads horizontal: 3 St. Number of heads vertical: 4 St. Götzinger Power Drill in special version with dübelleim and press-in station With the Götzinger PowerDrill, you can choose: - Drill the front and long sides - Doweling of doors, seatings, fighters - The drilling patterns are freely programmable - You can: Grip handle and corner bearing, with quick-change Multi-spindle drilling heads - You can: lock casings, pusher and PZ as well as 3D tapes and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, Save and recall POWER DRILL - drilling and milling machine Universal drilling machine for drilling olives, corner bearings, dowel work On the front and the front, milling, lock boxes, tapes, etc. Base in stable design, covered with sheet metal Table top 1800 x 200 mm  ...

• Xeikon Service Contract from 2012 - December 2017 and from June 2018 until today • Year of manufacture: 2012 • Approximate 8,000 operating hours • Print Technology: QA-I Dry toner electrophotography • Imaging Head: 5 x High-Precision LED Print Heads • Printing Engine: Simplex, 5 colours (White + CMYK) • Media Input: Hunkeler Unwinder • Media Output: Hunkeler Rewinder with cutter • Imaging Quality: 1200 x 3600 dpi, variable dot density • Media Width: 250 - 516 mm Print Width: 508 mm • Toner: QA-I dry toner | Compliant with FDA and ISEGA • Printing Speed: Up to 594 sqm/hour • Media Weight: 40-350 g/sqm, 550 microns • Substrates: SA or PS label (Paper, PP, PET, Vinyl, co-extruded film) Paper, Paperboard, Transfer substrate • Digital Front End: Xeikon X-800 Version 3.71.x • Machine is still under production for small runs

grinding range: 8 - 32 mm sharp cornered angle min./max.: 90 - 140 Grad connected load: 230 V weight of the machine ca.: 16 Kg dimensions of the machine ca.: 0,43 x 0,24 x 0,24 m Drill grinding machine: Additional station for grinding back the drilling cutting surface (clearance angle) 25tk. Collets ER 40 are included in the scope of delivery, these are also suitable for clamping intermediate sizes. For grinding twist drills made of HSS and Hard metals with a TiN layer of 8 - 32 mm. Rotor with precision ball bearings guarantees smooth running. Vibration-free running thanks to its heavy weight and rubber feet. Sharpening angle adjustable for all common twist drills. Package dimensions: 430 x 240 x 240mm. Weight 16kg. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

saw blade diameter: 370 mm capacity 90 degrees: round: 120 mm capacity 90 degrees: square: 100 mm : 180x100 mm Working height: 925 mm saw blade turning speeds: 15 - 70 U/min total power requirement: 1,8/2,2 kW weight of the machine ca.: 0,71 t dimensions of the machine ca.: 1,9 x 1,45 x 2,1 m ACTION PRICE ! High Performance Vertical Circular Saw Hydropneumatic Fully Automatic. (20192) · Miter left 60 ° + right 45 ° · Hydro-pneumatic control of the saw unit · Electro-pneumatic material feed unit · Quiet, powerful worm drive with large Gear ratio, integrated in a stable cast housing for Achieving optimal cutting results · Vice with double clamping arm for low-profile cuts.Additionally with lateral quick shift at miter change · Precision prism guide of the gearhead, laterally adjustable · Particularly stable undercarriage with built-in automatic cooling · Large chip drawe ...

bore capacity in steel (diameter): 50 mm throat: 360 mm bore stroke: 150 mm spindle turning speed range: 120 - 3000 U/min spindle taper: SK 40 : 650 mm : 320 mm vertical adjustment: 500 mm table surface area: 1000 x 300 mm connected load frequency: 400 V diameter of hob: max. 80 mm total power requirement: 2,2 kW weight of the machine ca.: 0,85 t dimensions of the machine ca.: 1,25 x 1.5 x 2,3 m New Model Industrial Drilling and Milling Machine with Manual Transmission and High Speed Range. The prism guide in the Z-axis ensures a high degree of precision even in the most difficult milling jobs. Domestic equipments: • automatic feed in X-axis • 3-axis digital display • motorized Z-axis • Feed in quill • Left-right-run high • tapping attachment • Gear head swiveling • Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Agitator REITZ RW012X244 Agitator 0.12 KW with gear motor ELVEM and 2-wing Inclined blade stirrer 244 mm With traverse made of aluminum profiles 45 45 mm. Gear motor: worm gear motor ELKEM, 3 x 230/400 volts, 0.12 kW, n1 = 1395 rpm, IP 55, weight approx. 8 kg. With motor protection plug. Available in 3 agitator speeds: n2 = 14 rpm (i = 100), n2 = 23 rpm (i= 60), n2 = 23 rpm (i= 56). Shaft: precision stainless steel shaft D20, length 1000 mm, diameter 20 mm, Material stainless steel 1.4571. With rigid coupling made of stainless steel 1.4571 Very slow-running, high-torque agitator for use in attachment tanks or cooking kettles.

bore capacity in steel (diameter): 15 / 18 mm throat: 180 mm bore stroke: 80 mm turning speeds: 200 - 4000 U/min : 250 x 220 mm distance drilling head - clamping area: max. 380 mm total power requirement: 1,1 / 400 kW / Volt column diameter: 65 mm tool taper: MK 2 weight of the machine ca.: 0,08 t dimensions: 0,4 x 0,5 x 0,9 m precise bench drill: - Large speed range - Programmable thread cutting - high accuracy and quality - Drill table adjustable via rack and swiveling around the column - Full engine protection - Star grip - 230 volt mains connection The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

saw blade diameter: 350 x 32 mm capacity 45 degrees: round: 110 mm capacity 60 degrees: round: 90,0 mm capacity 90 degrees: square: 95,0 mm capacity 45 degrees: square: 95,0 mm capacity 60 degrees: square: 90,0 mm capacity 90 degrees: flat: 180 x 95 mm capacity 45 degrees: flat: 125 x 95 mm capacity 90 degrees: round: 115 mm capacity 60 degrees: flat: 90 x 90 mm 0: 15 / 30 / 45 / 90 U/min weight of the machine ca.: 375 kg Equipment / description: - Manual high-performance vertical circular saw - for cuts from 45 ° right to 60 ° left - The saw head is on pretensioned linear guides - guided on a stable cast steel column - The powerful 2-stage gear was specially designed for cuts designed in solid material - The user has a total of 4 blade speeds - available for optimal adaptation to the material - The large turntable with internal table clamp & Precision stops at 0/45/60 ° ensure quic ...

bore capacity in steel (diameter): 40,0 mm throat: 320 mm bore stroke: 160 mm morse taper: 4 MK table:: 500 x 420 mm turning speeds: 90 - 1455 U/min total power requirement: 1,0 / 1,5 kW weight of the machine ca.: 450 kg. range L-W-H: 500 x 930 x 1870 mm characteristics - Vario drive for precise setting of the speed - Quill infeed either by hand or by mechanical feed - Easy tool change thanks to automatic tool ejector - Set speed can be read quickly and easily using the digital display - Solid, swiveling gray cast iron table with T-slots and coolant channel - The coolant system and lighting are included in the scope of delivery - Adjustable drilling depth stop, drilling depth can be read off using a scale - Right-left rotation device for thread cutting scope of delivery - Drill chuck arbor MK 4 / B 16 - coolant device - Digital speed display - Keyless chuck 1 - 16 mm / B 16 - Reducing sl ...

A HOSOKAWA ALPINE Originals machine Refurbished by the original manufacturer Use of original components only Original manufacturer warranty Guaranteed manufacturer spare parts supply Short lead time Before delivery, the machine is overhauled, all wear parts are revised and exchanged if needed and customized to your specific needs Possibility to provide all additionally required peripherals or adapt to existing production plant We are also interested in buying back disused HOSOKAWA ALPINE machinery Used Hosokawa Nobilta NOB 300. The Nobilta is the New - Generation of Powder Processor designed to perform fast powder mixing of Macro to Micro precision mixing, creating and treating composite materials such as surface-modification and sphericalizing particles in accordance with specific design conditions in one processor. The Nobilta is structured with a horizontally positioned c ...

ZOLLER SMILE / PILOT 3.0 presetting and measuring machine was manufactured in 2019 in Germany. The machine is a professional tool measuring and presetting device, whose easy operation and precision guarantee flawless results. A telecentric lens and a CCD camera with integrated LED ring for measurements in reflected light (blade inspection) are used to perform the measurements. ZOLLER SMILE 420 is equipped with the CNC controller ZOLLER »pilot 3.0« and functions such as automatic blade recognition, measurement of radial run-out and axial run-out, maximum contour function and cutting edge control. The tool to be measured can have a maximum length of 420 mm and a maximum diameter of 420 mm. Specifications of the ZOLLER SMILE / PILOT 3.0 presetting and measuring machine - maximum tool length Z: 420 mm - maximum tool diameter D: 420 mm - diameter measurement according to Abbe’s p ...

pressure: 30 t throat: 200 mm stroke: 0 - 60 mm table:: 400 x 600 mm table:: 150 mm - Bohrung no. of strokes: 140 Hub/min bore: 40,0 mm - Werkzeug compressed air: max. 6,0 bar dayligth: 300 mm total power requirement: 3,0 kW weight: 1.670 kg range L-W-H: 1150 x 1350 x 2050 mm Furnishing: - Welded steel structure body frame - AISI 4140 (42CrMo4) alloy steel crankshaft - CNC ground for maximum precision SnBz-12 quality - Bronze bearings, ground for minimal surface resistance - 4 sides pneumatic clutch-brake combination - PLC control for safety (PILZ Germany) - Photo cell light barriers around the work table (PILZ Germany) - Two-hand and foot pedal control - Adjustable stroke - Central lubrication system - CE safety approval by TÜV - electrical equipment SIEMENS, SCHNEIDER, PHOENIX, OMRON The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

saw blade diameter: 350 x 32 mm capacity 90 degrees: round: 120 mm capacity 90 degrees: square: 105 mm capacity 90 degrees: flat: 180 x 70 mm capacity 45 degrees: round: 120 mm links capacity 45 degrees: round: 110 mm rechts capacity 45 degrees: square: 100 mm links capacity 45 degrees: square: 95 mm rechts capacity 45 degrees: flat: 135 x 60 mm dimensions of saw-blade: 350 x 32 turning speeds: 1700 / 3400 U/min capacity 45 degrees: round: 120 mm total power requirement: 1,5 / 2,2 kW weight of the machine ca.: 210 kg dimensions of the machine ca.: 1170 x 860 x 1600 mm Description: manual high-performance circular saw for cuts from 45 ° right to 45 ° left in aluminum and lightweight metal alloys, with 2 speeds Furnishing: - with pneumatic vices - The saw head can be tilted by 45 ° on one side - Heavy cast iron construction - ensures vibration-free operation and maximum precision - The  ...

x-travel: 750 mm y-travel: 250 mm z-travel: 400 mm spindle taper ISO: 40 ISO table:: 1270 x 260 mm feed:: 24 - 402 mm/min. turning speeds: 45 - 1660 U/min distance spindle /table: 175 - 520 mm rapid traverse: Z Achse 660 mm/min throat: 0 - 550 mm total power requirement: 2,2 kW weight of the machine ca.: 1.400 kg range L-W-H: 1715 x 1470 x 1660 mm Furnishing : - Universal milling head, adjustable to all angular positions - Swiveling control panel with ergonomically mounted switches - Heavy machine stand made of gray cast iron for vibration-free work - Dovetail guide with adjustable V-ledges in all 3 axes - Very smooth running thanks to ground gear wheels running in an oil bath - Positioning motor for z-axis included in delivery - Standard with automatic table feed in x and y axes - Precise surface-machined cross table with T-slots - Digital position display for x, y and z axes included i ...

Belt grinding machine GRIT GI 150 2H, switchableSerial -No: 1121152 Year 2011with surface grinding module GIL and radius grinding module GIRTechnical specifications:BELT SANDERBelt dimensions approx.: 150 x 2000 mmSpeed: 3450 rpm.Voltage: 3 x 400/440V 50/60HzWeight approx. 80.6 kgwith- Machine foot GIB Serial-No: 1120014 year of manufacture 2011 Weight approx. 17 kgSURFACE GRINDING MODULE GILSerial-No: 1114072 built in 2011Tape dimensions approx.: 150 x 2000 mmDimensions of profiles/flat material max.: 100 x 100 mmVoltage: 3 x 400V 50/60HzApprox. weight: 69 kgfor longitudinal grinding of square tubes, profiles and flat materialsRADIAL GRINDING MODULE GIRSerial-No: 1124121 year of manufacture 2011Band dimensions approx.: 150 x 2250 mmDimensions of profiles/flat material max.: 120 x 150 mmTubes up to diameter: 20 - 150 mmWeight approx. 109 kgwith- integrated depth stop for series usefor  ...

Hydraulic Precision Cylindrical Grinding Machine make MARUS type HS 1/600Machine -No: 692 Year 1969Center height: 115 mmWorkpiece diameter max.:220 mmMaximum distance: 650 mmGrinding length: 620 mmWorkpiece weight max.:20 kgGrinding wheel size: 200 x 20 mmGrinding wheel speed: 2900 rpm.Clamping tool cone: MK 2Oil tank filling: 60 lDrive power: 1.1 / 2.2 kWWeight approx: 850 kgExternal dimensions approx: 1950 x 870 x 1450 mmWith- hydraulic slide feedxa0xa0infinitely variable 0 - 4 m / min.- Spindle drive hydraulically, stepless 100 - 500 rpm.- Hydraulically operated quick release devicexa0xa0with foot pedal operation- Grinding support height adjustable by 90 mm- Machine for the dry longitudinal grinding of rolls andxa0xa0Cylinders with covers made of rubber, synthetics, cork, glass,xa0xa0Ceramics and the like- Stepless control of spindle speed andxa0xa0carriage- suitable for grinding tens ...

: 3,0 mm ST 40 : 2,0 mm VA : 90° Grad blade length: 130 x 130 mm table:: 600 x 460 mm work height max.: 900 mm engine output: pneumatisch weight: 170 kg range L-W-H: 630 x 660 x 1270 mm Characteristics : - Notching with a burr-free cut, without deforming the cut edges - Machine body made of high-quality gray cast iron, base frame made of sheet steel - Cutting knife made of surface-hardened tool steel - Effort-saving work thanks to the pneumatic drive - Operation by means of a foot pedal, so both hands are free for the workpiece - Large work table with integrated scales - T-slots for precise guidance of the swiveling stops - Protective cover in front of the cutting knife for high security scope of delivery - 1 set of cutting knives - 2 swiveling material stops - Plexiglass protective cover - foot pedal - angle gauge - underframe The data for this ad was created with ModulMWS - the sof ...

lifting force: 5,0 t height: 585 mm width: 230 mm weight of the machine ca.: 25 kg Furnishing: - high precision according to the OIML R 76 standard - calibratable - Tare over the full range - works via direct display operation as well as via the remote control - Including remote control up to 10 m range and calibration function - bright and easy to read LED display with 30 mm high digits - Value can be held and frozen - The net weight can easily be determined using the tare function - Totalizing function for series weighings0 - automatic shutdown function - Overload warning on the display - Power supply via internal battery 6V / 10Ah, included in delivery, easy to swap and charge Model with 10 to. Lifting capacity also available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight max.: 1200 kg. table turning speeds: 80 - 1600 mm/min. roll diameter: 200 x 50 mm workpiece diameter: 20 - 800 mm range L-W-H: 520 x 470 x 390 mm Antrieb range L-W-H: dito mm Mitläufer volt: 230 V / 50 Hz weight: 56 kg Description: - Device for rotating and positioning Containers and cylindrical workpieces. - Unit in solid steel construction with polyurethane-coated metal rollers. - Precise speed adjustment by Frequency converter. - Foot switch for start / stop, 4-step operation. - Switch for right / left rotation. - Rotary knob for infinitely adjustable rotation speed. - Selector switch for rapid traverse / normal operation. - Switch with indicator light for operational readiness. - HF protected Scope of delivery: - 1 drive unit with control (integrated) - 1 follower The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Precision universal cylindrical grinding machine make OVERBECK type 250 RUMachine -No: 25211 built in 1971Technical specifications:Clamping length max .: 280 mmClamping length inside: 80 mmClamping diameter max .: 100 mmGrinding diameter: 100 mmGrinding length: 250 mmWorkpiece weight: 3.5 kgWorkpiece spindle speed continuously: 100 - 1000 rpm.Inner cone: MK 4Infinitely hydraulic longitudinal table movement: 0 - 6 m / minCross table movement on theDiameter related:Step by step: 0.001 - 0.01 mm / p.H.Continuous: 0 - 8 mm / minby hand: 0.001 mmhydraulic quick adjustment: 25 mmDrive power: 3.0 kWRequired space approx .: 1800 x 1500 x 1600 mmWeight approx: 800 kgwith- Internal grinding device- cooling deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We  ...

bore capacity in steel (diameter): 32,0 mm throat: 255 mm bore stroke: 120 mm morse taper: 4 MK table:: 385 x 335 mm turning speeds: 80 - 2130 U/min total power requirement: 1,1 / 2,2 kW weight: 125 kg range L-W-H: 460 x 900 x 1730 mm Furnishing: - Surface-machined work table - Height adjustable via rack and hand crank - Ground base plate with T-slots for clamping high workpieces - V-belt drive with balanced drive pulleys for smooth running - Adjustable drilling depth stop for precise infeed of the quill - Powerful 2-stage motor, speed range from 80 - 2130 rpm - Direction of rotation switch for clockwise and counterclockwise rotation included in the scope of delivery - Cross line laser device for comfortable work - Compact, stable cast iron construction in a modern design - Stable and polished steel column, designed for heavy use Scope of delivery: - Drill chuck arbor MK 4 / B 18 - Keyl ...

saw blade diameter: 400 mm cutting diameter: 130 mm capacity 90 degrees: flat: 220 x 90 mm turning speeds: 3200 U/min saw-blade dia.: 400 x 3,2 x 40 mm motor: 400 Volt total power requirement: 3,0 kW weight: 125 kg range L-W-H: 700 x 900 x 1500 mm Furnishing: - Precise and accident-free work thanks to cutting from below - Quick setting for miter cuts - Workpiece clamping with adjustable vice and pressure piece - pneumatic tool clamping The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

saw blade diameter: 350 mm cutting length: 430 mm cutting diameter: 135 mm turning speeds: 3.800 U/min Dust suction hood: 100 mm dimensions of saw-blade: 350 x 3,0/2,4 x 40 mm total power requirement: 3,0 kW weight of the machine ca.: 100 kg dimensions of the machine ca.: 1,6 x 1,0 x 2,0 m - Cross-cut and miter saws for cross-cut cuts - Miter adjustment on both sides (60 ° / 45 °), with fixed stop - Shift cut on one side up to 45 °, with fixed stop - Stable cast iron construction - Precise linear bushing guide on the tool slide hardened and ground steel shafts - manual saw feed - Saw blade infinitely adjustable in height - nozzle for opt. Suction Cutting data: - Cutting length at 90 ° = 430 mm - Cutting height at 90 ° = 135 mm - Cutting length at 45 ° = 310 mm - Cutting height at 45 ° = 92 mm Special accessories included: - 1x HM circular saw blade 350 x 3.0 / 2.4 x 40 mm Z = 1 ...

High precision turret lathe manufactured by SCHAUBLIN type TR 102 HPMasch. -No: 167073, year of construction 1966controlled hydropneumaticallyTechnical specifications:Tip height: 102 mmBed length: 900 mmDistance between headstock and turret: 300 mmCollets passage: 22 mmNumber of places in the revolver: 6Bore diameter: 20 mm6 spindle speeds: 840 - 3000 rpm.Feed rates: 0.02 - 2 mm / minFast delivery: 8 m / minrequired air pressure: 5 - 7 atmAir consumption: 5 - 10 m3 / hDrive power: 2.5 HPWeight approx: 670 kgExternal dimensions: 1930 x 590 x 1680 mmWith- Collet insert- bar feed- various accessoriesused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO ...

Draw spindle precision lathe Fabr. WMW Mikromat Dresden Type DZFG 200 x 500Fabr. -No: 7960, year of construction approx. 1986Technical specifications:Tip width 500 mmTop height 165 mmgr. circulation diameter over bed 315 mmGr. orbital diameter over cross slide 200 mmTurning length between the tips 560 mmgr. workpiece diameter for bar work 31 mmGr. chisel cross section 20 x 20 mmPassage of fixed set stick 100 mmPassage of the walking stick 70 mmgr. workpiece mass between the tips 50 kg9 spindle speeds 56 - 2800 rpmRotary feeds with increments of 1.25xa0xa0xa0longitudinal 0.02 - 0.8 mm / revxa0xa0xa0plan 0.02 - 0-4 mm / revThread feeds metric thread lengthwise 0.2 - 60 mm / revxa0xa0xa0plan 0.2 - 30 mm / revInch thread lengthwise 60 - 1/2 Gg / xa0xa0xa0plan 60 - 1 Gg / Module thread lengthwise 0.1 - 28 mm / revxa0xa0xa0plan 0.1 - 14 mm / revDiametrical pitch thread lengthwise 240-1 3/8 Gg  ...

bore capacity in steel (diameter): 32,0 mm throat: 230 mm bore stroke: 120 mm morse taper: 3 MK table:: 400x320 mm turning speeds: 105 - 1725 U/min total power requirement: 1,2 kW weight: 245 kg range L-W-H: 470x810x1710 mm Furnishing: - Compact, stable cast iron construction in a modern design - Infinitely variable speed control - is changed The speed is read on a digital display - Table height adjustment via rack and crank - Right and left rotation of the quill for thread cutting - Powerful 2-stage motor, speed range from 105 - 1725 rpm - Base plate with T-slots for clamping high workpieces - Safety switch with undervoltage release - The spindle runs in the precision ball bearing scope of delivery - Key chuck 1 - 13 mm / B 16 - Drill chuck arbor MK 3 / B 16 - Reducing sleeve MK 3/2 - Digital speed display - LED machine light - Height-adjustable protective cover The data for this ad w ...
