ADLER BUZZI GRANULATOR 1200 mm 22 kw A120S Three-phase motor Supply voltage v 400 Voltage 50Hz Power kW 22+1.5+2.2 Revs 1450 rpm Hopper opening mm 1200×30 – 1000×200 Unloading device opening 160 mm Mobile blades 5×4 1200 mm Fixed blades 2×4 1240 mm Space between blade and counter blade 0.3 mm Rotor diameter 250mm Grid hole diameter 8mm Rotor revolutions 580 rpm Weight of granulator with aspirator 2500 kg Noise 85dB(A) Average production 250 kg/h Basic overall dimension 4000×1600 Loading hopper height 1400 mm Year 2009
AVIAN Engineering Model G46/ 60 Pinch Infeed Rollers Integral Blower Main Motor 20 kW Blower Motor 2 kW Rotary Blade 6pcs Stationary Blade 4pcs ThruPut 300 KG/H Cutting Chamber 620 x 460mm Hopper Opening 620 x 500mm
Including bottling line Rotor diameter: 320 mm Rotor width: 440 mm Drive motor 11 kW Weight approx. 800 kg
Rotor Ø: 340 mm Working width: 410mm Motor power: 11-18.5 kW Rotor cutting strips: 5 Stator cutting strips: 2 Insertion opening: approx. 410 x 340 mm Capacity depending on plastic and screen size: approx. 130-400 kg/h Granulate conveyor: 1.1 kW Net weight: approx. 1640 kg Gross weight: approx. 1865 kg Box dimensions: approx. 2.2 x 1.7 x 1.6 m Feed belts with silencer Centre distance: 3700 mm Belt width: 400mm Net weight: approx. 296 kg Gross weight: approx. 430 kg Box dimensions: approx. 0.8 x 0.8 x 4.4 m - Overhaul in 2022 - Real bevel cut - Integrated sound insulation - Conveniently designed grinding room - Safe material acceptance - Optimum granulate quality - Built-in granulate conveyor system - Easy maintenance and cleaning - Tested occupational safety Ø of rotor: 340 mm Useful width: 410mm Motor output: 11-18,5 kW Rotor blades: 5 Stator blades: ...
GUANGZHOU PC2660S plastic mill was manufactured by Chinese granulator manufacturer Guangzhou 3E Machinery Co. in 2018. The structure of the cascade knife granulator is made of high quality steel, ensuring rigidity, high efficiency and long service life of the machine. The machine is equipped with a rotor (cutting knife arrangement) with a cascade layout, consisting of 3 rows of 6 knives each. The rotor is 600mm long, 600mm wide and has a diameter of 260mm. The moving knives operate at a speed of 607 rpm. The drive system has a massive drive wheel, and the drive is transmitted via V-belts to the rotor pulley. The total weight of the machine is 1060 kg. Technical parameters of granulator GUANGZHOU PC2660S - layout of cutting knives: cascade - number of rotor knives: 3 rows x 6 pcs. - number of stationary knives: 2 rows x 2 pcs. - rotor length: 600 mm - rotor width: 600 mm - rot ...
Inv. Num. : 5847 Type: PRS-20 Producer: MAGUIRE Created: 2015 Parameters: Loader wagon: 508 x 762 x 406 mm Build volume: 150 l 1st degree : Shaft chipper with 8 blades on the rotor Chip: 13 (25) mm Motor power: 3.7 kW Belt Speed: 1750 1/min Pressure plate with pneumatic drive and hydraulic shock absorber Horizontal travel of the forklift with tire drive (against knife with pressure) 2nd degree : Radial knife mill with inclined rotor Motor power: 3.7 kW Direct drive Speed: 1750 1/min Sieve: 8 mm Crumb funnel Transport blower: 0.75 kW Mill capacity: 60-70 kg/hour Sequential control Timer for preset runtime with alarm Suitable materials : All thermoplastics including PVC 85 Shore and harder
PONAR ŻYWIEC SG-180FE-2B plastic mill built in 2011, is designed for crushing of plastic waste. Made of high quality steel, the plastic mill with dust exhaust ensures high rigidity of construction, high efficiency and long service life. The main advantages of the device are its comfortable operation and low noise level during machine’s work. SG 180FE 2B granulator is equipped with 9 rotary knives and 2 fixed knives with a length of 180 mm, capable of milling up to 30 kg of plastic elements per hour. The machine is offered with dust extraction. Total weight of the machine is 120 kg. Technical data of granulator PONAR ŻYWIEC SG-180FE-2B - length of blades: 180 mm - number of rotary blades: 9 - number of fixed blades: 2 - capacity: 30 kg/h - maximum rotation speed: 940 rpm - dust extraction - motor power: 1,5 kW - power supply: 380 V; 50 Hz - machine dimensions (L x W x H ...
Rotor: 1000mm Rotor width: 2500mm Rotor knives: 8 rows of 4 blades each Stator knives: 4 rows of 4 blades each Spare knives: 1 set rotor (32units) and 1 set stator (16units) Motor: 315kW soft start Included: Hydraulic unit for hopper opening 6,5 kW powered film feeding device 6,9kW, various blowers 4-45kW, Full control panel
Granulator Manufacturer: Rapid Type: 1514 Year of construction: 2000 - Device tested, cleaned and ready for use -
Propulsion: 22 kW With control cabinet and sound insulation
Ripper 2 axes of rotating shears. Brand: Sant Andrea, cutting chamber: 450x400 mm, motor: 7,5 hp.
TRIA GRANULATOR XT 100-80 Granulating chamber mm.1.040800 40,9431,50” 110 kw drive New rotor, diam 620 mm 24,41” N.5 Rotor knifes N.2 Fixed knifes Electrical hopper opening Blower and cyclone Included New impeller The machine is offered totally reconditioned
