turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5 Documents:vorhanden
turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5
swing diameter:320 mm control:840 D SIEMENS turning speeds:5000 1/min spindle drive:20 / 27 kW chucking diameter:250 mm travel -x axis:650 mm travel -z axis:300 mm turret head:12 Pos. tool holder:VDI 40 toolpiece turning speed range:4000 1/min work piece power:max. 11,7 kW weight of the machine ca.:8 t CNC vertical lathe, live tools, C-axis, high pressure pump 20 bar, 500l, filter, flush gun, 3-jaw chuc, EWAB loading station right, chipconveyor, approx. 23.500h "machine on", approx. 8.000h "spindle on" (in total) MACHINE WILL GET NEW (OVERHAULED) SPINDLE (0 hours)
turning diameter:325 mm turning length:600 mm total power requirement:35 kW spindle drive:25 kW spindle turning speed range:5000 U/min speeds of tool:4500 U/min rapid traverse X-axis:60 m/min diverse toolholders:VDI 40 rapid traverse Z-axis:45 m/min weight of the machine ca.:6,5 t dimensions of the machine ca.:3,5 x 2,5 x 2,1 m Machine with SIEMENS 840 D control power line with shopturn - C and Y-axis, driven tools - bar loader IRCO ILS-RBK - coolant device with coolant throough revolving head - Revolver - counter spindle - chip conveyor - collet clamping - part catcher
used
-X-Way-700mm -Y-way-700mm -Z-way-700mm -Control-ITNC 530 -Spindle holder HSK A63 -Spindle speed-12000rpm -Plate changer with 7 pallets -Tool magasin with 120 -Internal cooling feeder-40bar -Spindle motor-20kW -Pallet size 500x500mm -Machine weight approx.16t -Top condition,to be visited under electricity
Key data: 500 , 520 , 380
Bearing number 1105-02750 Machine Type Machining Center - Universal Make DMG DECKEL-MAHO Type DMU 50 eV / 5 axes Built in 2001 Control type CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight base EX WORK Technical details x-way 500 mm y-way 420 mm z-way 380 mm Control HEIDENHAIN TNC 430 Spindle cone SK 40 Speeds 18,000 rpm Spindle motor 15 kW Rapid speed 50 m/min Table clamping area 500 per m. x 380 mm Feed range up to 20 000 mm/min Tool change device 32 fold Total power requirement 38 kVA Machine weight approx. 5.9 t Information - CNC - CONTROL of the display of HEIDENHAIN TNC 430 - 5-axis machine with B + C axis - Spindle on: 22 800 h - Current on: 38 000 h - Machine documents spaenefoerderer
used
Machine details Location 1105-02917 Machine type Machining Center - Vertical Make DECKEL-MAHO DMG Type DMC 63 V Built 2001 Control type Cnc Location France Origin Germany Delivery JULY 2020 Freight base from stock, freely loaded Price On request Technical details x-Way 630 mm y-way 500 mm z-way 500 mm Table size 800 x 500 mm Spindle mount ISO 40 Range 0 - 8000 rpm Feeds - longitudinal/transverse/vertical 1 - 30000 mm/min Rapids - longitudinal/transverse/vertical 30 m/min Number of tool magazine slots 24 Tool diameter at full assembly 80 mm Tool diameter at 2 free spaces 140 mm Tool length max. 300 mm Tool weight max. 7 kg Table load 500 kg Spindle motor 9 / 13 kW Control Siemens 810 D Total performance requirements 30 kVA Machine weight approx. 4.2 t Information Tested machine ready for demonstration under current YEAR OF ...
Machine details 1105-02953 Machine type Machining Center - Vertical Make DECKEL-MAHO (DMG) Type DMC 64V Built 2002 Control type Cnc Location Haguenau Origin Germany Delivery Right away Freight base from stock Price On request Technical details x-Way 640 mm y-way 600 mm z-way 500 mm Control HEIDENHAIN TNC 530 Machine weight approx. 8 t Information 1 gebr. CNC vertical BAZ Fabr. DECKEL-MAHO Type DMC 64V linear, Y.O.M. 2002 1 used CNC Vertical Milling Center DECKEL-MAHO type DMC 64V linear, built 2002 WITH 2 AXIS PART APPARAT INCLU CNC Control HEIDENHAIN TNC 530 30-fah tool changer Conveyor 30-fold ATC chip conveyor Technical data / technical details: X-Way / X-travel 640 mm Y-way / Y-travel 600 mm Z-way / Z-travel 500 mm Spindle holder / spindle taper SK40 Speed range / spindle speed 0-12000 rpm Feed range X , Y , Z / feed range X , ...
Machine-Details Stock-No. 1105-04006 Type of machine Machining Center - Vertical Make DMG MORI Type M 1 Year of manufacture 2022 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time IMMEDIATELY Freight basis EX WORK Price Technical details X-Travel 550 mm Y-Travel 550 mm Z-Travel 510 mm table-size 790 x 560 mm spindle taper ISO SK 40 turning speed range 10000 1/min Feeds longditudinal/cross/vertical 1 - 30000 mm/min Rapid Motion -Longitudinal/Cross/Vertical 30 m/min No. of tools in magazin 20 Workpiece diameter at full load 80 mm Wotkpiece diameter with 2 vacant positions 140 mm Workpiece length 300 mm Weight of tools max. 7 kg Table Load 600 kg spindle drive 9 / 11 kW control SIEMENS 828D total power requirement 30 kVA Additional information cnc SIEMENS 828 D ONLY 1400 SPINDEL HOURS VERY NICE El. handwheel, CH ...
Control: Siemens 840D Country of origin: Germany Spindle speed n-1: 12,000 Spindle motor kW: 9 Z - Path mm: 510 Y - Path mm: 510 X - Path mm: 835 Speed m/min: 30 Tool holder: HSK 40 Table load: 800 kg Clamping area mm: 1,000 x 560 Machine footprint mm: 2,100 x 2,700 Machine weight approx. kg: 4,200
Machine details Bearing number 1105-03199 Machine type Milling machine - Universal Make DECKEL MAHO DMG Type DMU 70eVolution Built in 2001 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time by arrangement Freight base from location Price Technical details x-path 750 mm y-path 600 mm z-way 520 mm Control HEIDENHAIN iTNC 530 Information Milling machine - Universal DECKEL MAHO DMG DMU 70eVolution NC Swivel Round Table (700X500) Spindle -------------------- Spindle speed: 18,000rpm Tool holder: SK40 Tool changer -------------------- Magazine places: 32 Pick up Facilities -------------------- Measuring probe Conveyor 2. Processor card electronic handwheel HR410 Blowing air M25 Rinsing gun
Machine details Bearing number 1105-02750 Machine type Machining center - Universal Made DMG DECKEL-MAHO Type DMU 50 eV / 5 axes Built in 1998 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time immediately Freight base EX WORK Technical details x-path 500 mm y-path 420 mm z-way 380 mm Control HEIDENHAIN TNC 430 Spindle cone HSK 63 Speeds 18,000 rpm Spindle motor 15 kW Rapid response 50 m/min Table clamping area 500 throughs. x 380 mm Feed range up to 20 000 mm/min Tool change device 32 fold Total power requirement 38 kVA Machine weight approx. 5.9 t Information - CNC - Screen web control HEIDENHAIN TNC 430 5-axis machine with B +C axis SIMULTAN - Machine documents spaenefoerderer
Machine Details Stock-No. 1105-03325 Type of machine Machining Center - Universal Make DMG Type DMU 70 V Year of manufacture (2000) Type of control CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight basis EX WORK Technical details x-travel 750 mm y-travel 600 mm z-travel 520 mm table-size ø 700 x 500 mm spindle taper SK 40 spindle turning speed - stepless 20 - 12,000 rpm feeds longditudinal/cross/vertical 20,000 mm/min rapid traverse 50 m/min ATC 24x workpiece length 315 mm weight of tools max. 6 kg table load max. 0.35 t weight of the machine approx. 7 t Additional information , chip conveyor CNC CONTROL HEIDENHAIN I TNC 430 12000 RPM SK 40
Machine details Stock number 1105-03328 Machine type tool milling machine - Universal Make MAHO Type MH 800 E Year of construction 2000 Control type CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from stock price Technical details x-path 700 mm y-way 550 mm z-path 500 mm Speed 20 - 5000 rpm Tool holder SK 40 Quibola stroke vertical 80 mm Feed 1 - 5000 mm/min Rapid speed 6000 mm/min Table size 900 x 550 mm Total power requirement 16 KVA Weight of the machine ca. 7 t Space requirement approx. 2.4 x 2.85 x 2.1 m Information - with web control CNC 532 - with FIXED ANGLE TABLE WITH TOOL CHANGER - Enclosure Machine under power Ready for demonstration.
x-travel: 600 mm y-travel: 525 mm z-travel: 500 mm weight of the machine ca.: 6,5 t CNC Steuerung Heidenhain TNC 426 Kühlmitteleinrichtung Spänewanne CNC control Heidenhain TNC 426 coolant device chip tank Technische Daten / technical details: X-Weg / X-travel 600 mm Y-Weg / Y-travel 525 mm Z-Weg / Z-travel 500 mm Spindeldrehzahlen / spindle speed 6300 UpM /rpm Werkzeugaufnahme / spindle taper SK40 Vorschubbereich X/Y/Z / feed range 10000 mm/min. Universaltisch / clamping area of universal table 750x530 mm Gewicht der Maschine ca. / weight 6500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 560 mm z-travel: 560 mm table surface area: 500x400 mm control: Siemens type: 840 D spindle taper ISO: 40 spindle turning speed range: 8000 U/min : type of pallet-changer: 2 Rotary table: 360 ° Cooling through the spindle: bar Tool changer: 40 chip conveyor: total power requirement: kW weight of the machine ca.: 11,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 600 mm y-travel: 560 mm z-travel: 560 mm Control: Siemens type: type of pallet-changer: size of pallet: 400x500 mm Table load: 300 kg feed: 40.000 m/min spindle speed:: 20-8000 U/min spindle taper ISO: 40 Spindle capacity: 13/20 KW Torque: 191 Nm Tool changer: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Machine Details Warehouse number 1105-03636 Machine Type Machining Center - Vertical Make DECKEL MAHO Type DMC 63 V Year of construction 2000 Control type CNC Control heidenhain tnc 426 Storage location FRANCE Country of origin Germany Delivery time IMMEDIATELY Freight base EX WORK Technical details x-travel 630 mm y-travel 500 mm z-travel 500 mm Table size 800 x 500 mm Spindle holder ISO SK 40 Speed range 0 - 8,000 1/min Feeds - longitudinal/transverse/vertical 1 - 30000 mm/min Rapid traverses - longitudinal/transverse/vertical 30 m/min Number of tool magazine slots 24 Tool diameter with full assembly 80 mm Tool diameter with 2 free spaces 140 mm Tool length max. 300 mm Tool weight max. 7 kg Table load 500 kg Spindle motor 9 / 11 kW Control heidenhain tnc 426 Total power requirement 30 kVA Machine weight approx. 4.5 t Information heidenhain tnc 426 El. ...
Machine Details Warehouse number 1105-03531 Machine Type Machining Center - Vertical Make DMG DECKEL-MAHO Type DMC 64 V linear Year of construction 2002 Control type CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from stock Technical details x-travel 640 mm y-travel 600 mm z-travel 500 mm Table size 850 x 600 mm Spindle holder ISO 40 Speed range 0 - 12000 rpm Rapid traverses - longitudinal/transverse/vertical 30 m/min Number of tool magazine slots 30 Information CNC control heidenhain tnc 530 30X SK 40 MAGAZINE ELECTRONIC HANDWHEEL MACHINE IN GOOD CONDITION WITH SPAENEFOERDERER
Control: Siemens 840D Shopmill Country of origin: Germany Spindle speed n-1: 12,000 Spindle motor kW: 14 Z - Travel mm: 510 Y - Travel mm: 510 X - Travel mm: 835 Rapid traverse m/min: 30 Tool holder: SK 40 Table load: 800 kg Clamping surface mm: 1,000 x 560 Base area of the machine mm: 2,100 x 2,700 Machine weight approx. kg: 4,200 Linear scales Axis A Electronic handwheel IKM – 25 bar / 30 l/min Conveyor Canopy SPINDLE BEARINGS NEW!
Milling machine 4-axis (15995740874) DMG Milltap 700 (2015) Spindle 24,000 1/min NC parts apparatus Lehmann EA-510. L Tool magazine 25 places Renishaw Measurement Kit Rinsing gun Milling machine 5-axis (15995747284) DMG Milltap 700 (2015) Spindle 24,000 1/min Swivel rotary tables 5-axis simultaneous operation Clamping pneumatics 1-circuit Tool magazine 25 places 40 bar IKZ Conveyor Rinsing gun Renishaw Measurement Kit Milling machine 5-axis (15995765944) DMG Milltap 700 (2018) Spindle 10,000 1/min Swivel rotary tables 5-axis simultaneous operation Clamping pneumatics 1-circuit Tool magazine 25 places 40 bar IKZ Conveyor Renishaw Measurement Kit Automatic front door Automation interface including automation door on the right Milling machine 5-axis (15995734744) + WH3 (770200062R) DMG Milltap 700 (2014) Spindle 10,000 1/min Swivel rotary ...
Machine Details Warehouse number 1105-03678 Machine type machining center - Universal Make DECKEL MAHO DMG Type DMU 50 5-axis 3+2 Year of construction 2005 Control type CNC Control HEIDENHAIN ITNC 530 530 Storage location FRANCE Country of origin Germany Delivery time immediately Freight base EX WORK Price Technical details x-travel 500 mm y-travel 420 mm z-travel 380 mm Control HEIDENHAIN ITNC 530 530 Recording SK 40 Speed 10000 1/min Table top 500 X 380 MM mm Information HEINDENHAIN ITNC 530 Controlled NC round swivel table, 2 axes coolant device, Full cabin, 10000 RPM MAGaZIN 30 TRAY SK 40 LINEAR MASSTAEBE PARTS MEASURING SYSTEMS HEIDENHAIN SPAENEFOEDERER
Machine Details Stock number 1105-03737 Machine type machining center - Universal Brand DMG DECKEL MAHO Type DMU 80 MONOBLOCK Year of construction 2006 Control type CNC Control MILLPLUS HEIDENHAIN Storage location FRANCE Country of origin Germany Delivery time immediately Freight Base EX WORK Technical details x-travel 980 mm y-travel 630 mm z-travel 610 mm Speed 12000 1/min Control MILLPLUS HEIDENHAIN Tool holder SK 40 Tool changing device 32 items. Spindle 28 / 19 kW Table load 650 kg Total power requirement 44 kVA Machine weight ca. 9 t Information 5-axis, simultaneous universal machining centre HEIDENHAIN MILL PLUS Table 1250 x 700 mm, integrated rotary table 700mm, controlled NC swivel milling head (B-axis) -30° / +91°, Electr. Handwheel Conveyor IKZ 20 BARS WITH NEW SPINDLE TIME MAERTZ 2022
Deckel Maho DMF 300 Linear, built in 2002 TECHNICAL INFO: CONTROLS: CNC SIEMENS Sinumerik 840 D power line, TRAVELS: X: 3,000 mm Y: 560 mm Z: 720 mm Spindle mount SK40 Spindle speed: max 12,000 rpm (limited to 6,000 by gearbox) Tool magazine for 40 tools Operating hours: 21,865 Spindle hours: only 9,320 Very reliable, stable and good machine! No maintenance backlog! - In recent years, small items such as belt pulleys, hydraulic accumulators, scrapers, linkages have been added, regardless of the maintenance positions - In 2018 a new Z-axis ball screw came in. The engine gearbox was also overhauled - Rotary table 560mm (4th axis) for assembly also available and part of the sale The orientation of the Hirth toothing when swiveling would have to be readjusted. However, we only use the machine as ...
Machine Details Stock number 1105-02917 Machine type machining center - vertical Brand DECKEL-MAHO DMG Type DMC 63 V Year of construction 2003 Control type CNC Control SIEMENS 840 D Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight base from stock, freely loaded Technical details x-travel 630 mm y-travel 500 mm z-travel 500 mm Table size 800 x 500 mm Spindle holder ISO 40 Speed range 0 - 8000 rpm Feeds - longitudinal/transverse/vertical 1 - 30000 mm/min Rapid traverse - longitudinal/transverse/vertical 30 m/min Number of tool magazine positions 24 Tool diameter with full assembly 80 mm Tool diameter with 2 free spaces 140 mm Tool length max. 300 mm Tool weight max. 7 kg Table load 500 kg Spindle motor 9 / 13 kW Control SIEMENS 840 D Total power requirement 30 kVA Machine weight ca. 4,2 t Information Tested machine read ...
Control: Siemens Travel X/Y/Z: 350 x 240 x 340 mm Spindle speed 6300 min-1 Tool holder SK 40 Manual swivel rotary table Tool holder Vice Accessories
Machine Details Stock number 1105-03861 Machine type: Machining center - Universal Make DECKEL-MAHO (DMG) Type DMU 80 T Year of construction: 1998 Control type: CNC Location: FRANCE Country of origin: Germany Delivery time: immediately Freight base EX WORK Technical details x-travel 800 mm y-travel 650 mm z-travel 550 mm CNC control TNC 426 HEIDENHAIN Table size 1100 x 650 mm max. table load 600 kg Spindle mount SK 40 Spindle speeds 20 - 12,000 rpm Feed range 20 - 10,000 mm/min Rapid traverse Z-axis 15 m/min Rapid traverses X- and Y-axis 18 m/min Tool changing device 25 pos. Drive power 15 kW Operating voltage 400 V Total power requirement 26 kVA Machine weight approx. 6.0 t Space requirement approx. 2.40 x 3.30 x 2.40 m Chip conveyor 2.90 x 0.70 x 1.50 m Information CNC HEIDENHAIN TNC 426 TOOL MAGAZINE SK 40 - Spindle hours: 11920 h - Coolant setup
Tool pressetter Needs new computer and software Estimated price 2022 from producer € 4500,--
x-travel: 700 mm y-travel: 700 mm z-travel: 700 mm total power requirement: 68 kW weight of the machine ca.: 10500 kg dimensions of the machine ca.: 4300x2400x2600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 400 mm, 400 mm, 375 mm
Machine Details Stock-No. 1105-03922 Type of machine Machining Center - Universal Make DMG DECKEL MAHO Type DMU 40 EVO Year of manufacture 2013 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time to be agreed Freight basis ex site Price Technical details X-Travel 400 mm Y-Travel 400 mm Z-Travel 375 mm control iTNC 530 Heidenhain Turning speed range - Main spindle max. 20,000 min/-1 power capacity - main spindle 19 kW max. torque 130 Nm tool taper SK 40 swivellable -105+ 40 ° table surface area Ø 450 mm T-slots 7x 14 x 63 mm max. table load approx. 275 kg rotatable C: 360° Max. workpiece diameter 500 mm max. workpiece height 400 mm number of toolpositions 60 pos. tool taper SK 40 max. tool diameter 80 mm max. tool-dia with free toolbox 160 mm max. tool length 315 mm max. tool weight 8.0 kg Change-time chip to chip a ...
Deckel Maho Universal Machining Center CNC DMU 70 VL Deckel Maho Manufacturer [manufacturer]: Deckel Maho (DMG) Typ [ type]: DMU 70 VL [control unit]: Heidenhain TNC 430C Jahr [construction year]: 2002 Travel range [travel path]: X= 710mm Y=520mm Z=520mm spindle rotation speed: 20-18,000 rpm Main spindle power: 36 kW IKZ internal coolant supply Tool changer: 2 x 32 places Tool holder: SK 40 to DIN2080 Cooling system: Knoll Chip conveyor: 2 units/units Weight [weight]: 12.800kg Dimensions [needed space]approx. (L x W x H): 5.3m x 2.75m x 2.75m Technical documentation/documents available in detail
WE OFFER AN NICE CONDITION DMU 70 EVO MACHINE IS ON POWER WORKING DAILY ORDERS IN SHORT WE PROVIDE VIDEO OF WORKING
Technical details x-travel 600 mm y-travel 560 mm z-travel 510 mm Steuerung Siemens Slim Line Multi Touch Control Main spindle: Max. speed 15,000 rpm/-1 Drive power - main spindle 20 / 14.5 kW Max. torque 121 / 84 Nm Tool holder SK 40 Distance between spindle nose and table 120 - 630 mm Workbench: Table clamping area 900 x 560 mm max. table load 600 kg T-slots 5 Working height 850 mm Tool magazine: Number of tool positions 60 pos. Tool holder SK 40 max. tool diameter 80 mm max. tool diameter. with a free neighboring box. 130 mm max. tool length 300 mm max. tool weight 8.0 kg Tool-tool changeover time 2.4 sec Changeover time chip - chip 6.7 sec Feeds: Rapid traverse 30 m/min Feed force 5 kN Feed speed max. 30,000 mm/min Total power requirement 32 kVA Machine weight approx. 5.0 t Space requirements approx. 4.0 x 5.0 x 3.0 m
Control: iTNC 530 Max.travel range: X 500 mm Y 450 mm Z 400 mm A +5 / - 110? - manual C nx 360? - manual Spindle speed ? 10000 rpm Taper ? SK 40 Tool changer ? 16 positon measuring probe for parts set up 3 axis + 2 axis (dividing head) Tool pr
With Indumatik Automation x-travel 500mm Y travel 450mm z-travel 400mm Control Siemens 810 D Shopmill Main spindle: Speed Range - Main Spindle ((( 20 - 8,000 )))min/-1 Drive power - main spindle 13 / 9kW Tool holder SK 40 Max. torque 83Nm NC rotary table: Table clamping area 630 x 500mm Max. table load 200kg Swivel range -5 / +110° Rotation range 0.001° T-slots 7x 14 x 63mm Tool magazine: Number of tool locations 16pos. max. tool weight 6kg max. tool diameter 80mm max. tool diameter. with a free neighboring box. 130mm max. workpiece length 300mm Feeds: Rapid traverse 12m/min Feed force 4.5kN Feed speed 1 - 12,000mm/min Total power requirement 18kW Machine weight approx. 5.0t Space requirements approx. 4.5 x 3.5 x 2.3m
Control: SIEMENS 840D Max.turning length: 1185 mm Max swing diameter over bed/slide: 640 mm/550mm Workpiece diametr: 400/250 mm Material passage through the spindle: 65 mm Max.diameter of the material for barloader: 65 mm Rotation speed(max.) 5000 rpm Sp
Control: Heidenhain Mill plus Max.travel range: X 1250 mm Y 1000 mm Z 1000 mm B -30? / +180? C nx 360? Clamping table: 1000 x 800 mm Spindle speed ? 10000 rpm Taper ? HSK 100 Tool changer ? 120 positon Twin Pallets Coolant tank: 2000l machine
CONTROL .. CNC Control HEIDENHAIN TNC426 WORKSPACE -CUBIC- .. Number of machining axes (without parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 400 mm .. Travel Z-axis: 400 mm TABLE .. Clamping surface (left-right): 700 mm .. Clamping surface (front-rear): 500 mm SPINDLE / HEAD .. Speed range up to: 9000 rpm .. Tool holder: ISO SK 40 TOOL MAGAZINE .. Number of tool positions: 16 ELECTRICAL CONNECTION DATA .. Connection voltage: 400 V .. Mains frequency: 50 Hz DIMENSIONS / WEIGHTS Bsicvzmv7Vm .. Space requirement -left/right-: 5000 mm .. Space requirement -front/rear-: 3700 mm .. Total height: 2500 mm .. Total weight approx.: 4500 kg
Control: Mill plus Max.travel range: X 1250 mm Y 1000 mm Z 1000 mm B -30? / +180? C nx 360? Clamping table: 1000 x 800 mm Spindle speed ? 10000 rpm Taper ? HSK 100 Tool changer ? 120 positon Twin Pallets Coolant tank: 2000l machine has spindl
GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Cross650 mmLongitudinal735 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools90 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12400 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9Rotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRot ...
Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa
GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmMiscellaneousClamping SystemHSK-A 63 Floor space/WeightWeight approx.12300 KgNC swivel rotary tableTable surface 800 x 650 (Ø 650) mmCentre bore 50h6 mmMaximum load (table centre) 600 KgDirect measuring systemDir ...
GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Cross1000 mmLongitudinal1250 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring ...
Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa
Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 60 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for par
GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgDie and Mold Package linearDie and Mold Package linear Dynamic package V-type Eagle timing belt for Z axisPackage Mill / TurnPackage Mill / Turn (only available for Siemens 840D solutionline) NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C ...
GeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal650 mmCross700 mmVertical950 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...
Control: iTNC 530 Max.travel range: X 450 mm Y 650 mm Z 460 mm A -10 / + 110? C nx 360? Spindle speed ? 28000 rpm Taper ? HSK 63 Tool changer ? 120 positon machine has spindle cooling, Erowa clamping system is available, measuring probe for pa
