four column press used for sale

Key data: 100 t

Durendus DCD-100 – Hydraulic single-column press 10–100 t – 800 × 600 mm For sale is a hydraulic single-column press (C-frame) from the manufacturer Durendus with an adjustable press force from 10 to 100 t. The machine is designed for demanding forming, deep-drawing and assembly processes and has an integrated thermoforming pad and a modern Siemens control system. Thanks to high travel speeds and precise control, it is suitable for both series production and flexible individual applications. Technical data + information: Hydraulic Single Column Press – DCD-100 General information - Manufacturer: Durendus - Model: DCD-100 - Type: C-frame / single-column press - Press force: 10–100 t (adjustable) - Total weight: approx. 6,500 kg - Overall dimensions: approx. 1,850 × 1,845 × 3,520 mm - Table height above floor: 1,000 mm Workspace - Max. distance table ...

A hydraulic transfer molding press Lauffer is available. Press force: 125t, power: 15kW, hydraulic oil volume: 300l, machine dimensions X/Y/Z: approx. 2200mm/1400mm/3000mm, weight: approx. 6500kg. An on-site inspection is possible.

: neu : ca. 4 Monate ab Auftragse : Italien : 138000 € : 2608.2 € : 170 to : 500 mm : 870x500 mm : 1000x600 mm : 600 mm : 300 mm : 110 mm/s : 42 mm/s : 7 mm/s : 70 mm/s : 19 kW : 1500 mm : 1950 mm : 2650 mm 4 guides for the slide T-slots in the table Rexroth hydraulic unit Monitored electrovalves Air/oil heat exchanger Pressure switch Double pushbuttons control Stroke adjustment by limit switch microns Siemens CPU Lateral fixed protrection grates CE certification following ",IV enclosure", OPTIONS(prices on request): Blank holder Prismatic guides Frontal light curtain CNC control Siemens with touchscreen Hydraulic pump with variable flow Proportional valves Lateral sliding guides with security microns The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Number of pistons 3 Table dimensions ( x-y/mm) 2210 x 1830 Slide Dimensions X-Y (mm) 2210 x 1830 Stroke (mm) 915 Cushion number 1 Cushion type hydraulic Cushion stroke (mm) 406 Cushion power (ton) 250 Weight ( ton) 100 Machine Conditions ce marked

Key data: 300 t, 2 mm, 600 mm

Pressure: 300 tons Distance between the uprights 1800mm Side passages: Yes Installation height: 1000mm Table: 1800x1000mm Plunger: 1800x1000mm Stroke: 600mm Weight: 43 tons Height: 4700mm Siemes S7 Controller Ground-level installation Sick Light Barrier Cushion: Stroke 200mm

Jessinegg + Urban, Stroke 300, Lift: 300, table 450x370, 1300kg

Offer 25272 Technical data: - Max. pressing force 25 t - Max. ram stroke 500 mm - Lifting speed 0 - 2.4 m/min - Return 0 - 12 m/min - Installation height 800 mm - Projection to the middle of the ram 360 mm - Pusher clamping surface 440 x 360 mm - Plunger clamping pin 40 mm - Table size 630 x 500 mm - Table bore / breakthrough 180 mm - E. footswitch - 2 hand control panel - Drive 400 V / 8.75 kW - Space requirement approx. W 800 x H 2750 x D 1150 mm - Weight approx. 2000 kg

Offer 25274 Hydraulic – single-column press with drawing cushion Technical data: - Max. pressing force 25 t - Max. ram stroke 500 mm - Lifting speed 200 mm/sec - Return 450 mm/sec - Installation height 800 mm - Projection to the middle of the ram 380 mm - Pusher clamping surface 440 x 360 mm - Plunger clamping pin 40 mm - Table size 630 x 500 mm - Table bore / breakthrough 180 mm - Drawing cushion 10 t - E. footswitch - 2 hand control panel - Drive 400 V / 12.5 kW - Space requirement approx. W 800 x H 2750 x D 1150 mm - Weight approx. 2400 kg

Offer 25275 Technical data: - Max. pressing force 25 t - Max. ram stroke 500 mm - Lifting speed 200 mm/sec - Return 450 mm/sec - Installation height 800 mm - Projection to the middle of the ram 380 mm - Pusher clamping surface 440 x 360 mm - Plunger clamping pin 40 mm - Table size 630 x 500 mm - Table bore / breakthrough 180 mm - E. footswitch - 2 hand control panel - Drive 400 V / 12.5 kW - Space requirement approx. W 800 x H 2750 x D 1150 mm - Weight approx. 2200 kg

Power 550 W Auction-ID: A1-45866-77

Key data: 125 t

Single-column press – manufacturer Durendus – 125 t servo press – table 2200 × 750 mm For sale is a hydraulic C-frame servo press from the manufacturer Durendus with an adjustable press force of up to 125 t and an integrated 50 t ejector. Thanks to modern servo hydraulics, the machine offers significantly reduced energy consumption of up to 40% compared to conventional systems and is ideal for demanding assembly, forming and production processes. = Technical data + information: Hydraulic servo press – C-frame – 125 t General information - Manufacturer: Durendus - Model: Single column press / servo press - Type: C-frame press Laobqcjx Aqtqotxvoa - Press force: 20 – 125 t (adjustable) - Machine weight: approx. 8,700 kg - Dimensions (W × D × H): approx. 2,400 × 2,000 × 3,300 mm - Table height: 870 mm - Installation height: max. 1,000 mm Table &  ...

pressure:800 t distance between columns:2900 mm stroke:350 mm Controls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 to PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mm RAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):2560 mm ...

pressure:40 t throat:220 mm stroke:8 / 88 mm table pass:ø- abgesetzt 225/200 mm ram head dimension:400 x 250 mm distance table/ram:228 mm stroke adjustable from - to:30 - 140 mm ram adjustment:63 mm thickness of bolster:80 mm no. of strokes:70 Hub/min total power requirement:5,5 kW weight of the machine ca.:2600 kg dimensions of the machine ca.:1100 x 1300 x 2300 mm Documents:vorhanden

pressure:250 t passage width:1280 mm stroke:bis 500 mm total power requirement:47 kW weight of the machine ca.:23 t dimensions of the machine ca.:2200 x 1850 x 4600 mm table surface area:1250 x 1000 mm dayligth:800 mm daylight between the side columns:520 x 750 mm table height above floor:1000 mm Documents: vorhanden

pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:56 / 84 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:710 x 500 mm hole in the table:320 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,1 t dimensions (W x D x H):1,35 x 2,0 x 2,6 m overload protection in ram:mechanical

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:51,0 kW weight:33,0 t dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:52,0 kW weight:33,0 t Dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:400 t distance between columns:3250 mm distance table/ram, max. stroke up, adjustment up:1000 mm stroke:800 mm table surface area:3250 x 1400 mm table height over floor:1250 mm die cushion capacity:170 t die cushion stroke:200 mm die cushion area:1800 x 1000 mm distance between cutting impact cushioning:2610 mm side window:800 mm ram surface:3250 x 1400 mm return capacity:51 t speed down:300 mm/s speed up:300 mm/s working speed:16 - 33 mm/s quantity of oil:2900 l power requirement:100,0 kW weight:70,0 t Dimensions (WxDxH):4,9 x 3,1 x 7,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

pressure:400 t distance between columns:1250 mm stroke:250 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:825 mm table surface area:1000 x 900 mm column travel -side:400 x 700 mm ram surface:1000 x 900 mm ram adjustment:100 mm capacity of ejector in table:40 t ejector stroke:160 mm power capacity:270,0 kW weight:44,0 t Dimensions (WxDxH):2,4 x 3,6 x 7,2 m height over floor:6,4 m

pressure:125 t stroke:25 fix mm no. of strokes:70 - 700 /min distance between columns:1150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:1150 x 1000 mm hole in the table:900 x 220 mm side window:650 mm ram surface:990 x 850 mm ram adjustment:60 mm material width:250 mm material thickness:2,5 mm power requirement:46,5 kW weight:29,5 t roll feed:mechanical, Schuler, WK 8-250

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:250 t distance between columns:930 mm stroke:200 mm Distance table/ram, stroke up:600 mm table surface area:900 x 860 mm die cushion capacity:100 t die cushion stroke:50 mm die cushion area:350 x 400 mm table height over floor:950 mm side window:380 x 380 mm ram surface:850 x 700 mm feed down:400 mm/s feed up:400 mm/s working feed:30 mm/s oil volume:350 l power capacity:45,0 kW weight:11,5 t Dimensions (WxDxH):2,0 x 1,2 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary

pressure:1000 t distance between columns:3030 mm stroke:350 mm Distance table/ram, max. stroke up, adjustment up:1400 mm table surface area:3000 x 2000 mm table height over floor:430 mm side window:1450 x 1400 mm ram surface:3000 x 2000 mm speed down:300 mm/s speed up:340 mm/s working speed:18 - 44 mm/s return capacity:120 t oil volume:4400 l width with platform:4950 mm power capacity:2 x 90,0 + 10,0 kW weight:87,0 t Dimensions (WxDxH):4,35 x 3,65 x 7,55 m height over floor:6,05 m height beneath floor:1,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:200 t distance between columns:1650 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1250 mm die cushion capacity:80 t die cushion stroke:300 mm die cushion area:1300 x 900 mm table height over floor:800 mm ram surface:1600 x 1250 mm oil volume:ca. 2000 l power capacity:43,0 kW weight:25,0 t Dimensions (WxDxH):2,9 x 2,3 x 5,8 m height beneath floor:0,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:350 t distance between columns:1350 mm stroke:900 mm distance table/ram, max. stroke up, adjustment up:1300 mm table surface area:1300 x 1000 mm pressure of drawing cushion in table:100 t stroke of drawing cushion in table:380 mm die cushion area:350 x 285 mm capacity of ejector in ram:25 t ejector stroke in ram:200 mm table height over floor:750 mm ram surface:1300 x 1000 mm speed down:500 mm/s speed up:160 - 470 mm/s working speed:16 - 44 mm/s drawing speed:57 - 160 mm/s return capacity:32 t oil volume:1700 l power requirement:91,0 kW Dimensions (WxDxH):3,75 x 2,8 x 7,2 m height over floor:5,28 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary

Pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:700 x 500 mm hole in the table:250 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,5 t Dimensions (WxDxH):1,6 x 2,0 x 2,8 m overload protection in ram:mechanical

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

Pressure:315 t distance between columns:1350 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1200 x 1300 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:680 mm/s working speed:180 mm/s oil volume:2000 l power requirement:150,0 kW weight:35,0 t Dimensions (WxDxH):3,3 x 3,3 x 5,5 m height over floor:5,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:063 t stroke:70 fix mm no. of strokes:15 - 60 /min distance between columns:1340 mm width between oil collecting pans:1180 mm distance table/ram, max. stroke up, adjustment up:328 mm table surface area:1260 x 700 mm hole in the table:1000 x 100 mm table height over floor:1000 mm column travel -side:470 mm ram surface:1300 x 650 mm ram adjustment:100 mm power requirement:27,5 kW weight:13,7 t Dimensions (WxDxH):3,4 x 2,1 x 3,4 m clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

Pressure:063 t throat:250 mm stroke:10 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:380 mm table surface area:700 x 500 mm hole in the table:180 x 140 mm table height over floor:700 mm ram surface:360 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,8 t Dimensions (WxDxH):1,9 x 1,7 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical

pressure:150 t throat:400 mm stroke:30 - 150 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1000 x 750 mm hole in the table:320 x 200 mm table height over floor:800 mm ram surface:800 x 600 mm ram adjustment:85 mm weight:10,0 t Dimensions (WxDxH):1,4 x 2,2 x 3,1 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic

pressure:250 t distance between columns:1125 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1100 x 900 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:100 mm die cushion area:700 x 400 mm table height over floor:960 mm side window:700 mm ram surface:1080 x 900 mm oil volume:1000 l power requirement:35,0 kW weight:23,0 t Dimensions (WxDxH):2,5 x 2,3 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary

pressure:250 t throat:450 mm stroke:36 - 126 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:525 mm table surface area:1000 x 750 mm hole in the table:400 x 360 mm table height over floor:1000 mm ram surface:600 x 500 mm ram adjustment:111 mm power requirement:19,0 kW weight:13,5 t Dimensions (WxDxH):1,3 x 3,2 x 3,35 m clutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric

pressure:100 t distance between columns:1230 mm stroke:20 - 200 mm no. of strokes:20 - 60 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1050 x 750 mm table height over floor:760 mm side window:540 mm ram surface:1000 x 750 mm ram adjustment:100 mm power requirement:18,0 kW weight:20,5 t Dimensions (WxDxH):2,8 x 1,9 x 4,3 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary

Pressure:250 t throat:450 mm stroke:8 - 135 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:635 mm table surface area:1250 x 850 mm hole in the table:355 mm table height over floor:950 mm passage to the back:660 mm ram surface:790 x 610 mm ram adjustment:120 mm power requirement:18,5 kW weight:14,0 t Dimensions (WxDxH):1,5 x 2,8 x 3,65 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:300 t distance between columns:2500 mm stroke:350 mm distance table/ram, max. stroke up, adjustment up:1280 mm table surface area:2500 x 1500 mm table height over floor:850 mm side window:900 mm ram surface:2500 x 1500 mm speed down:300 mm/s speed up:240 - 450 mm/s working speed:23 - 44 mm/s oil volume:3000 l power requirement:132,0 kW weight:54,0 t Dimensions (WxDxH):3,25 x 3,2 x 4,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA

pressure:150 t throat:450 mm stroke:115 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:2250 x 1090 mm table height over floor:900 mm passage to the back:1900 mm ram surface:1900 x 900 mm ram adjustment:100 mm power requirement:16,0 kW weight:19,5 t Dimensions (WxDxH):3,0 x 2,3 x 3,9 m

pressure:200 t distance between columns:1800 mm stroke:710 mm Distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1600 x 1300 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:250 mm die cushion area:1400 x 1080 mm table height over floor:800 mm side window:1300 mm ram surface:1660 x 1300 mm speed down:400 mm/s speed up:410 mm/s working speed:14,3 - 49,7 mm/s power requirement:46,0 kW weight:25,0 t Dimensions (WxDxH):3,65 x 3,3 x 5,4 m height over floor:5,05 m height beneath floor:0,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical

pressure:50 t distance between columns:1750 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1700 x 750 mm table height over floor:800 mm side window:650 x 750 mm ram surface:1700 x 750 mm power requirement:11,0 kW weight:11,0 t Dimensions (WxDxH):2,1 x 1,15 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:015 t throat:200 mm stroke:4 - 70 mm no. of strokes:140 /min distance table/ram, max. stroke up, adjustment up:310 mm table surface area:430 x 395 mm hole in the table:165 x 160 mm table height over floor:560 - 735 mm table adjustable:175 mm ram surface:160 x 130 mm ram adjustment:80 mm power requirement:1,2 kW weight:0,9 t Dimensions (WxDxH):1,0 x 1,25 x 1,8 m clutch:Drehkeil overload protection in ram:mechanical

pressure:030 t stroke:8 - 40 mm no. of strokes:100 - 600 /min distance between columns:325 mm distance table/ram, max. stroke up, adjustment up:250 mm table surface area:540 x 300 / 325 x 395 mm hole in the table:315 x 110 mm table height over floor:1000 mm column travel -side:290 mm ram surface:250 mm material width of feeder:120 mm material thickness of feeder:3,0 mm feed length:60 mm power requirement:5,5 kW weight:2,6 t Dimensions (WxDxH):1,5 x 1,2 x 2,2 m clutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60

pressure:100 t throat:350 mm stroke:6 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:850 x 700 mm hole in the table:470 x 150 mm table height over floor:855 mm ram surface:450 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,0 t dimensions (WxDxH):1,5 x 2,3 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:800 t distance between columns:3010 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:1350 mm table surface area:3000 x 1800 mm table height over floor:500 mm side window:1500 x 1400 mm ram surface:3000 x 1800 mm speed down:300 mm/s oil volume:900 l height over floor:5,4 m height beneath floor:2,1 m power requirement:200,0 kW weight:80,0 t Dimensions (WxDxH):5,2 x 2,6 x 7,5 m ram interlocking:in TDC depth stop:mechanical

pressure:100 t distance between columns:1060 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1250 mm table surface area:1000 x 700 mm pressure of drawing cushion in table:40 t stroke of drawing cushion in table:200 mm die cushion area:Ø 250 mm table height over floor:950 mm side window:580 x 750 mm ram surface:1000 x 700 mm oil volume:700 l power requirement:47,0 kW weight:13,0 t Dimensions (WxDxH):2,2 x 1,8 x 5,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA

pressure:160 t distance between columns:2050/1900 mm stroke:15 - 170 mm no. of strokes:15 - 40 /min distance table/ram, max. stroke up, adjustment up:690 mm table surface area:1600 x 800 mm side window:800 mm ram surface:1620 x 700 mm ram adjustment:140 mm power requirement:15,0 kW weight:24,0 t Dimensions (WxDxH):3,3 x 2,3 x 5,3 m height over floor:4,8 m height beneath floor:0,5 m clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
