Single Column Presses ZEULENRODA PYE 25 N

Offer 24591

Specifications:

- Max. pressing force 25 t
- Max. ram stroke 500 mm
- Lifting speed 0 - 40 mm/s
- Return 0 - 200 m/min
- Installation height 800 mm
- Projection to the middle of the ram 360 mm
- Pusher clamping surface 440 x 360 mm
- Plunger clamping pin 40 mm
- Table size 630 x 500 mm
- Table height above floor 710 mm
- Thermoforming force 10 t
- Largest deep-drawing depth 160 mm
- Drive 400 V / 4 kW
- Space requirement approx. W 800 x H 2720 x D 1150 mm
- Weight approx. 2500 kg


seller offer No. resale Lg.-Nr. 24591
