Complete vertical packaging system for dosing coffee beans AND ground coffee and packaging in coffee stand-up pouches with aroma valve. The system is equipped with two separate dosing systems (auger filler for powder, volumetric cup dosing unit for granules) and also has a Z-conveyor, screw conveyor, outfeed conveyor and an AMTEC PRO P60L as VFFS packaging machine. A hot stamping printer for date, batch number (optional: thermal transfer printer on request), an anti-static module, stand-up pouch module (gusset device) and flat-bottom module (bottom seam is applied tightly to bottom, depending on the film material) are also part of the equipment. - Specifications VFFS: Stable film pulling by vacuum | MITSUBISHI/SIEMENS PLC, WEINVIEW touch screen operator interface | mark sensor registration control | quick change former assembly, pneumatic sealing unit | servo motor film pulling | bag siz ...
Rotary tablet press for tableting single-layer tablets. Easy punch tool change, quick to clean, low noise operation. Including dust collector, tablet deduster and vacuum feeder. - Specifications: press tool: D | number of punch stations: 15 | max. speed of the machine in neutral: 77 cycles/minute (corresponds to approx. 69,000 tablets/hour) | max. tablet diameter: 25 mm | max. filling depth: 20 mm | max. precompression force: 12 kN | max. main compression force: 100 kN | product contact parts are made of stainless steel SUS 316L, chassis is made of stainless steel 304 | power consumption: 5.5 kW | machine dimensions: 660?690?1620 mm | weight: 675kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short de ...
Horizontal single-shaft mixer for blending dry, moist and pasty products. - Specifications: agitator type: S-shaped mixing paddle | volume tank: 300 liters | processing volume: max. 210 liters per run | stirring speed: max. 24/min | stirring motor power: 5.5kW | discharge motor power: 1.1kW | machine dimensions approx.: L2160?W700?H1200mm | weight: 750kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
Industriemischer f?r trockene Pulver, feuchte oder past?se, klebrige Produkte. Mit dem Einwellen-Spiralmischer lassen sich die Produkte in wenigen Minuten zu einer gleichmigen Masse mischen.- Spezifikationen: R?hrwerkstyp: Einwellen-Spiralr?hrwerk | Kapazit?t: max. 120 Liter | maximale Drehzahl der Maschine im Leerlauf: 53r/min | Maschinenabmessungen: L2030xB630xH980mm | Gewicht: 450kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
Industrial mixing machine for blending dry, moist or pasty products, specifically designed for products with large net weight. The horizontal single shaft with the double ribbon mixers is blending the materials into high uniformity in a few minutes. ? Specifications: agitator type: single-shaft double ribbon agitator | capacity: max. 9000 liters | max. speed of the machine in neutral: 20 rpm | power: 90kW | machine dimensions: L6500xW2100xH2800mm | weight: 9800kg.That machine/system is available in different versions for different packaging sizes and with different packaging speeds.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviation ...
3-D mixer for fast mixing of powdery materials. The innovative three-dimensional mixing principle of oscillating, parallel and rolling motion generates a strong impulse movement to cause a continuous forward pushing of the materials. With an excellent mixing effect in the result, the technology also allows short mixing times and so a higher output compared to conventional mixers. - Specifications: Tank volume: 300 liters | processing volume: max. 240 liters per batch | max. processing weight: 150kg | power 4kW | machine dimensions approx.: L1800?W1950?H1700mm | weight: 1000kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations fro ...
Horizontal single-shaft mixer for dry, moist and pasty products. - Specifications: S-shaped mixing paddle | volume tank: 200 liters | processing volume: max. 140 liters per run | stirring speed: max. 24/min | stirring motor power: 4kW | discharge motor power: 0.75kW | machine dimensions approx.: L1850xW600xH1000mm | weight: 720kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
High-speed tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for pre-made tubes (with closed cap) made of plastic, aluminum or laminated composite material. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. External tube feed lift, water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lif ...
Fully automatic tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for premade aluminum tubes with closed cap. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. Water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lift. - Specifications: max. speed of the machine in neutral: 65 cycles/min ...
Fully automatic tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for pre-made tubes (with closed cap) made of plastic, aluminum or laminated composite material. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. Water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lift. - Specifications: ...
Fully automatic tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for premade aluminum tubes with closed cap. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. Water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lift. - Specifications: max. speed of the machine in neutral: 50 cycles/min ...
Fully automatic tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for premade aluminum tubes with closed cap. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. Water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lift. - Specifications: max. speed of the machine in neutral: 80 cycles/min ...
Sample system for liquid filling of large containers. Fully automatic line. - Specifications: capacity: 1-10 liter | max. speed of the machine in neutral: 720 containers/hour | accuracy: +/-0.5%. - System includes: Optional storage container, 5m conveyor, 4 sensor weighing systems, 4 electronic filling heads, pipelines, control system and anti-drip mechanism (4 pcs.). Final Specifications will depend on customers needs. - Please give us your details to prepare a full quotation.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
Sample filling system for motor oils in 20 litre canisters. Generally suitable for different liquids (high or low viscosity) into large containers, canisters. The filling quantity is controlled by a weighing sensor. High accuracy due to slow filling speed with still relatively high output compensated by two filling heads. Can be equipped with a steam sterilizer. Mitsubishi PLC, WIENVIEW Touch-Monitor, sensors from Sick. -Specifications: Filling range: 5-25kg | speed: up to 250 containers/hour | accuracy: = +/-0.3%. Number of filling heads: 4 | required compressed air: 4-6 bar. Filling volume and filling range can be customized, whereby performance and price can vary. The final specifications depend on customer requirements. Please provide us with your details so that we can prepare a complete quotation.Please note that our new prices are often below the usual used prices. Please feel fre ...
Sample system for capsule and tablet counting and filling. The system includes a vibration and multi channel feeder, PLC control system, dynamic scan counting, bottle/can transfer unit. - Specifications: Range of counting 20-999 pcs | counting and filling speed: max. 4000 tablets/min | final output: 50-100 bottles/cans per minute | max. product diameter: 13mm | max. product length/thickness: 6mm | typical bottles sizes: diameter 45-60mm, height 50-100mm | 380V, 1.2kW. Please note: This is a sample system only. The final specifications will vary. - Please let us know your product datails (product size and shape, required speed , working stations, etc.) to prepare a suitable quotation for you.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately fro ...
Fully automatic capsule filling machine for powder or pellets in capsules of size 000 - 5. Along with the main machine, various additional modules and machine enable a fully automatic filling process. Included: material hopper, capsule hopper, vacuum feeder, capsule feeder, industrial dust collector, capsule polisher, metal detector, collecting hopper (final product). ? Specifications: suitable for capsule size: 000 - 5 | segment bores: 25 | max. speed of the machine in neutral: 140 cycles/minute (corresponding up to 3500 capsules/minute) | main machine dimensions: L1555xW1165xH2040 mm | main machine weight: 2200kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks ...
Fully automatic tube filler for pastes and liquids. Typically for cosmetics such as make-up, creams, general care products such as shower gel, hair shampoo, hair gel, toothpaste, sun blocker etc. Suitable for premade plastic tubes with closed cap. Fully automatic feeding, alignment of the tubes (rotation in the mould) based on print markings as well as filling and sealing of the tubes. Before filling, the tube is air-flushed to prevent contamination. No-tube-no-filling is also a standard function. Water chiller, batch/date printer and dosing unit, consisting of pneumatic piston pump and storage hopper with level sensor, are included. PLC controlled, operation via touchscreen. Optional at surcharge: heated stirrer for storage hopper, additional format sets (moulds) for different tube diameters, external tube feed lift. - Specifications: max. speed of the machine in neutral: 50 cycles/minu ...
Sample system for volumetric filling and capping in one monobloc. Stainless steel SS316, 4 or 8 filling nozzles, volumetric injection pump, automatic cap orientation and capping. - Specifications: filling range: 20-1000ml (ideal filling ranges: 20-100ml, 50-250ml, 100-500ml, 200-1000ml) | max. speed of the machine in neutral: 5000 bottles/hour | filling precision < +/- 1%, yield of capping > 99% | power: 220V, 1.2-2.2kW | 0.6m?, 6bar | weight: 800-1000kg. - Please note these are sample specifications only. - Please ask for an inquiry and let us know your product details (size, shape, required speed , product, etc.) to prepare an individual quotation for you.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have ver ...
Fully automatic filling and closing machine for filling pharmaceutical liquids into vials. Suitable for aseptic filling and for vaccines. The main machine doses with peristaltic pump system safely, precisely and caps the vials with a freeze dryer stopper. The 8-head capping machine also works very quickly, precisely and is suitable for aluminum twist-off caps. The vials are guided individually, which enables safe and fast filling and capping. The included collecting table for the final product, the main machine and the capping machine can be flexibly combined to a complete line. All machines are equipped with dust cover and laminar flow hood. - Specifications of filling and capping system: number of filling stations: 4 | number of capping heads for freeze dryer stopper: 1 | number of capping heads for aluminum twist-off caps: 8 | filling volume: max. 30ml per vial | speed of the machine ...
Fully automatic filling and closing machine for filling pharmaceutical liquids into vials. Suitable for aseptic filling and for vaccines. The main machine doses with peristaltic pump system safely, precisely and caps the vials with a freeze dryer stopper. The 1-head capping machine also works quickly, precisely and is suitable for aluminum twist-off caps. The included collecting table for the final product, the main machine and the capping machine can be flexibly combined to a complete line. All machines are equipped with dust cover and laminar flow hood. - Specifications of filling and capping system: number of filling stations: 4 | number of capping heads for freeze dryer stopper: 1 | number of capping heads for aluminum twist-off caps: 1 | filling volume: max. 30ml per vial | speed of the machine in neutral: max. 120 bottles/min (at 4 filling stations and 5ml per vial) | accuracy: = ...
Samples System to fill small bottles with small volume of liquid: Typical use is filling of eye drops, nail polish and other. Infeed by infeed line | possibly from an sorting system upstream (which is not included in this system). The system includes a container unscrambler, which sets the small bottles after the filling into an outfeed line. The system is PLC controlled. - Specifications: max. speed of the machine in neutral: 50 bottles/Minute | filling capacity: 20-60ml | 1.75kW | 6-8bar. All theses specifications are just examples. The final system will be custom-built. - Please give us your detailed inquiry (container shape and size, speed , product to fill, working steps) to give you a full quotation.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available ...
Filling and capping system for aseptic and precise filling and capping of small bottles with small liquid volumes as used for eye drops, nasal sprays, nail polishes, esoteric oils etc. Dosing by piston pump. - Specifications filling and capping system: number of filling nozzles: 4 | number of capping heads: 2 | filling volume: max. 10ml/bottle | speed in neutral: max. 60 bottles/min | accuracy: = ? 1% | suitable bottles: glass, PP, PE, PVC | product contact parts from stainless steel 316L.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
Samples System to fill small bottles with small volume of liquid: Typical use is filling of eye drops. The system includes an container unscrambler, which sets the small bottles into an infeed line. Module to clean the bottles (water/gas) and inside/outside tucks (cap parts), filling and labelling the bottles. The system is PLC controlled. The total 3 cleaning processes with water plus the 3 cleaning processes with gas assures a very high cleaning standard without any water remaining. All liquid touching parts are made of stainless steel SS316 completely. - Specifications: Filling precision: < +/- 0.5% | max. speed of the machine in neutral: 120 bottles/minute | filling capacity: 5-30ml | 380V, 3.8kW | 6bar. All these specifications only are sample specifications. Depending on the final working process they will vary. - Please give us your detailed inquiry (container shape and size, spee ...
Sample filling system for low viscosity products (ketchup, jam, sauces, etc.) into bottles, glasses, cans. Including container unscrambler, rolling bottle/container rinser, viscosity filler (hot filling, steam filling), vacuumize jar capper. - Specifications: filling volume 20-1000ml | bottle size range: diameter 20-150mm, cap diameter: 20-70mm | 4-12 filling nozzles allowing speed s of up to 6000 bottles/containers per hour | tolerance of filling quantity: +/- 1% | yield of capping: < 99% | 380V, 3.5kW, 0.6m?, 6bar. - Please note: These are specifications for a sample system only. The final specifications will vary. Please give us your packaging details (container size, shape, filling product, required speed , etc.) to prepare a full quotation for you.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usu ...
Sample filling system of a disinfection liquid bottle filling line for smaller bottles with a filling volume of up to 100ml. The fully automatic filling process includes: Aligning and feeding of the bottles | filling with 2 to 8 filling heads and with high accuracy by anti-drip device | automatic alignment, feeding and capping of the lids / spray caps, single or double sided labeling of the bottles | outfeed and collection of the bottles to a collection table or to the next production station. -Specifications: number of filling nozzles: 4 (can be customized for a surcharge) | number of heads for lid positioning and capping: 1, each (can be customized for a surcharge) | filling range: 30-100ml | dosing method: by piston pump | accuracy: +/- 1% | speed: max. 2000 bottles/hour, at 100ml max. 500 bottles/hour | label size: L10-350mm, W10-200mm | product contact parts are made from corrosion- ...
Sample system for volumetric filling into bottles or jars. That system is equipped with 12 filling heads and piston pumps, which enables high production speed . The filling heads are drip proof and avoid foaming of filling material. Filling volume and filling speed can be easily adjusted. Further features: Precise filling, no bottle no filling, bottle fix position, system runs stably. - Specifications: production capacity: max. 6.000 bottles/hour (with 370ml) | Bottle height: 150-280mm (glass bottle) | Bottle diameter: 50-90mm | Power consumption: 1.5kW | Power 380V/50HZ | Stainless steel SS304 | Machine dimensions: L1850xW1350xH1900mm. Stepless speed conveyor includingPlease note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition ...
Sample system for filling liquids into bottles, closing them with a twist-off cap and then bottles labelling. Complete system consisting of: Bottle unscrambler | Filling machine with 4 filling heads for liquids with high or low viscosity | Lid closing machine for different sizes and shapes of lids including lid unscrambler | Labelling machine for bottles/cans/containers made of glass or plastic | Collecting table. The individual machines of the packaging line are connected to each other via conveyor belts, which gives the installation of the line high flexibility. -Specifications: Number of filling nozzles: 4 | filling range: 100-1000ml | dosing method: by piston pump | accuracy: +/- 1% | bottle height: 15-400mm | bottle diameter: 25-200mm | speed: max. 1000 bottles/hour | label size: L25-300mm, W20-180mm, product contact parts are made from 304 stainless steel. Dimensions and total weig ...
Complete sample system for a water production plant to do 3.000 cycles per hour. Including Blow Molding Machine (with 4-cavity blow molding machine, air compressor, air dryer group, chiller, blow mould), Bottle Feeding Table, Automatic Rinsing/Filling/Capping Machine, Cap Feeding Machine, Lamp Inspection Box, Drying Device, Automatic Label Shrinker Machine, Code Spraying Machine, Automatic Wrapping Machine, Conveyor System. Way of production: Bottle blowing > bottle rinsing > bottle filling > bottle capping > lamp inspection > labelling > thermo shrinking > code spraying > wrapping. - Specifications: 3000 cycles/h (at 500ml) | bottle volume: 350-1500ml | PET bottles | standard 28/30mm PET caps | 1500 liter of water filling /hour | 500 liter of water for rinsing per hour, gravity filliing, 24 bottles in a multipack. - Specification depending on final layout and customized combination of ...
Automatic water filling system for up to 18.000 bottles per hour. - Including feeding system for empty bottles to the 40-head rotary rinser. - Rotary filling station (40 heads) with gravity filling principle. The capping unit is working with 12 capping heads and is suitable for 28 and 30mm PE standard caps. - All product contacting parts are made of SS304 or standard food package plastic. - The frame is made of high quality carbon steel Q235 (optional SS304). - MITSUBISHI PLC, WEINVIEW Touchscreen, Specifications: productivity 6.000-18.000 bottles per hour, number of rinsing heads: 40, number of filling heads: 40, 12 capping heads, bottle volume: 350-2000ml, bottle diameter: 50-90mm, bottle height: 150-310mm, filling tolerance: +/- 2%, compressed air: 0.5m?/6bar, filling water: 9m?/h, rinsing water: 3m?/h, power: 380V, 7.5kW, machine dimensions: L4300xW3400xH3050mm, 12.000kg.Please note ...
Automatic collection system for cans, glasses, bottles. Collection of single containers on rotating table so that jams can be avoided. - Specifications: up to 80 containers/min | diameter of table: 1.200mm | 380V, 0.18kW | machine weight: 50kg | dimensions: L1300xW1200xH1000mm.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.
