edge trim used for sale

Linck 700 x 100 edger - German production - hydraulic disc shifting TECHNICAL PARAMETERS: - cutting width max 550 mm - cutting height max 100 mm - element width max 700 mm - engine power 22 kW - feed smoothly adjustable from 10 - 60 m/min - working length of the fixed sleeve 120 mm - working length of the movable sleeve 120 mm - minimum element length 600 mm - disc diameter max 350 mm - spindle diameter 55 mm - sleeve diameter 85 mm - spindle with steady rest - two upper pulling rollers - two lower pulling rollers - two auxiliary rollers in the tabletop - feeder length 3700 mm - feeder width 700 mm - four rollers in the table - adjustment of the disc spacing from the feeder - a row of anti-kickback pawls Transport dimensions 380x220x150 cm weight ~ 2000 kg

Condition: like new, never used MatrixCompactor 140 All-in-one Units are designed to capture, convey, cut, collect and compact adhesive matrix and edge trim waste from all process machines. They can handle matrix and edge trim from 1 process machine and if edge trim only up to 4 process machines. Configuration of Granulator(s) is customised to the material and number of process machines. Maximum width of matrix Up to 550mm (22") Maximum air capacity 1,600 m³ / hour (940 CFM) Maximum speed 150 m / min (490 FPM) Maximum pipe size Dia. 160 mm (6") transfer Maximum suction distance Up to 10 m (32 feet) Size (LxWxH) 2.212x820x2.110 mm (6'-11" x 3'-3" x 7'-0") Weight 680 kg (1,500 lbs.) Motor fan 2,2kW (3 HP) Motor compactor 2,2kW (3 HP) Power 3 Phase, 230-460V, 50-60 Hz Sound 68-72 dB (A)

– German production –DTR – optimization of cutting width – dripping cross saw – automatic blade spacing – year of production 1989 TECHNICAL PARAMETERS: .max. element width 920 mm .max. element height 90 mm .max. element length 6000 mm main engine power 37 kW disc diameter max. 300 mm spindle diameter 60 mm sleeve diameter 70 mm fixed sleeve with a length of 60 mm floating sleeve for 1 disc floating sleeve with spindle length of 100 mm number of measuring heads 15 measuring head spacing 350 mm distance between measuring heads total input power 10 kW cross-cut saw for cutting material for a length of 2630 mm saw leveling the material cascade for transporting the board hydraulic feed in smooth speed control hydraulic material pressure hydraulic material height adjustment

Walter WDPP-410 edger – Polish production – DTR, CE TECHNICAL PARAMETERS: min. length of the cut prism 1100 mm max. thickness of the cut prism 120 mm max. input material width 500 mm max. width of the finished board 140 mm min. width of the finished board 70 mm circular saw diameter 425 mm capacity 20 m3 right vertical spindle motor power 5.5 kW left vertical spindle motor power 5.5 kW engine speed (vertical saw drive) 2850 rpm horizontal saw engine power 18 kW engine speed (horizontal saw drive) 2850 rpm feed motor rotational speed 1450 rpm feed speed (smooth regulation) 0/20 m/min mains voltage (50 Hz) 3×400 V machine dimensions (length/width/height) 6900 / 1400 / 1380 mm machine weight 1300 kg

Storti RM 500 edger - Italian production - Year of production 1993 - electric spacing of discs TECHNICAL PARAMETERS: - cutting width max 435 mm - cutting height max 170 mm - engine power 2 x 22kW - max element width 600 mm - minimum material length 800 mm - max disc diameter 600 mm - spindle diameter 40 mm - two upper pulling rollers - one upper pressure roller - roller motor power 2 x 1.1 kW - roller pressure with automatic jump - seven bottom pulling toothed rollers - electric disc adjustment - two lasers - feed speed 25 and 50 m/min - feeding table 2950 mm - receiving table 3000 mm - drive rollers D100 mm - power of the roller feed motor 2 x 1.5 kW Transport dimensions 500x240x180 cm weight 3500 kg

Multi-saw edger by FOD Bydgoszcz DPPA-II-50-E with electronic blade setting – Polish production – DTR – fixed sleeve – movable dial with the possibility of programming 8 fixed dimensions TECHNICAL PARAMETERS: - cutting height 120 mm - cutting width 500 mm - engine power 30 kW - material width max 730 mm - four types of feed speeds - feed motor power 4 kW - spindle diameter 55 mm - sleeve diameter 90 mm - electronic adjustment of disc spacing with programmable fixed dimensions - fixed edging sleeve 60 mm - one movable disc - two rows of anti-kickback pawls - three lower pulling rollers - two upper pulling rollers - two lasers - shaft support Transport dimensions: 270x165x220 cm weight ~ 2000 kg

Multisaw ZLT 500 edger with 500/120 feeders – Czech production – a movable shield with the possibility of installing several shields TECHNICAL PARAMETERS: cutting width 500 mm cutting height 120 mm Min. material length 800 mm .max. disc diameter 450 mm one disc movable sleeve 70 mm fixed sleeve length 100 mm engine power 45 kW two upper pressing rollers four lower pulling ones feed smoothly adjustable on the inverter shaft support two rows of pawls max material width 700 mm length of feed rollers 3000 mm roll width 700 mm roll diameter 70 mm receiving table 6200 mm chain width 60mm seven pressure rollers two bottom pull rollers transport dimensions (length / width / height) 700 / 245 / 180 cm weight 3000 kg

Besaummer Wurster Dietz FR7 Schmithohe 160mm rollengang steigforder kapsaege

Working piece thickness (Radius) ca. 16 - 55 mm Working piece thickness (Chamfer) ca. 12 -55 mm Working piece width min. Ca. 30 mm Inner radius min. Ca. 35 mm (depending on edge-radius and workingpiece countours) Edge thickness max. ca. 3 mm Milling motor 2 x 0,4 kW, 10950 o/min. Dust extraction 1 x diam. 80 mm Working height 900 mm Radius 3 mm tooling

Welding edge former, edge former, edge chamfering machine TRUMPF chamfers of steel plates for weld seam preparation type TKF 103 Sheet thickness: 4 - 25 mm Bevel length max: 10mm Bevel angle: 30 Power: 2000 Watt Mains connection: 220 Volt, 50 Hz - equipped with guide bracket for 30 bevel angles - regrindable butt steel for high tool utilization - several impact steels - Support plates 6, 8, 10, 12, 14, 16, 18, 20, 22 mm for different material thicknesses For bevelling straight and curved edges with at least 40 mm radius. For bevelling edges on flat and curved workpieces as well as tubes with an inner diameter of at least 80 mm. Weight: 14 kg; used

<br>8 stations 7 investors P 15 Bulletin station Trimmer Trimmer HT 15 Stacker RS 10<br><br>Still in operation: No.<br>Available: immediately

; operational

<br>Collective chain &amp; investors 1 station hand feeding 6 Stehendbogenanleger Double and false sheet control Bulletin station 2 Heftk pfe Hohner Large of roller cleaning for 4 wire wheels 1 Three knife trimmer Media cutting device Band display<br><br>Still in operation: No.<br>Available: immediately

<br>7 stations chain 6 investors P 15 1 folding feeder FF 100 Bulletin station 2 Heftk pfe Hohner Three knife trimmer Band display<br><br>Still in operation: No.<br>Available: immediately

Gratpress

The nominal gain kN 4000 Slide stroke, mm 400 Frequency Slider strokes min-1, 25 The frequency of single strokes, min-1 19 Slider travel to its lowest position, where the press develops the rated force, mm 8 The distance between table and slider in its lower position at the upper adjustment position, mm 470 Size of adjustment of distance between table and slider, mm 160 The size of the table, mm 1000x1000 The size of the slide from front to back, mm 800 Width of windows in racks mm 600 Main electric motor power, kW 37.0 Air flow, m3 / stroke 0,017 Press overall dimensions, mm left to right 3470 front to back 3140 Height above floor level, mm 5940 Weight without hydro pillow kg 32600

Size max 220 x 297 mm Speed max 2.700 c/h Equipment o automatic feeder o 2 cutting stations o 3 edge corner cutting station o delivery ; working condition

Three knife trimmer semi automatic Input height max 460 x 360 mm ; working condition

Built in 1989 Size max 320 x 400 mm Size trimmed max 305 x 380 mm Size trimmed 100 x 125 mm Product thickness max 80 mm min 6 mm Speed max 6.000 c/h Feeding height max 80 mm Equipment o infeed from the right side o automatic infeed with integrated pre stacker o cut counter o Equipment for sheet-fed o 1 set of clamping plates and holders o 3 sets of cutting sticks o 2 set of knives o external knife changing device o central lubrication o belt delivery

effort 250 ton stroke 315 mm slide adjustment 160 mm distance slide- table 800 mm die height 555 slide 620x950 mm table 800x1180 mm 28 kW Total weight 25t

Motor for trimmer BETTCHER type UN-84 Power: 440 Watt Power supply: 230 V without handle and circular blade We also offer: Blade - Knife 1000 - 183141 Blade - Knife 1400 - 183142 Blade - Knife 500 - 183142 Guide rail 1000 / 1400 - 183143 Toothed bushing 183154 Request a quote iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biala VAT id: PL547-17-47-669 tel. 0048/33 812 58 60 Fax. 0048/33 812 58 36

Capacity: 800 tons Stroke of slider: 500 mm Number of strokes per minute 12 Adjustment of slider: 185 mm Table area: 1250 x 1650 mm Slider dimensions 1000 x 1250 mm Main motor power: 55 kW Distance between columns 1250 mm Press dimensions, mm 3800 x 2800 x 6900 Weight: 57 tons

Capacity: 0 t Operating hours: 32165 Technical data Pressure: 25 to Max. Bending length: 1250 mm Passage between press bars: 320 mm Distance between the: 1020 Max. stroke: 100 mm Depth of throat: 200 mm Feed rate: 75 mm/s Working speed: 10 mm/s Return stroke speed: 80 m/min Table length: 1200 mm Table width: 60 mm Table height: 865 mm Number of spacers: 6 pce Height of the spacers: 120 mm Number of cylinder: 1 pce Oil capacity: 30 l Voltage 50 Hz 3x: 400 Volt Motor power: 4 kW Machine´s weight about: 1600 kg Overall dimensions machine: Length: 1800 mm Width: 1200 mm Height: 2000 mm

Capacity: 0 t Control: Cybelec S-DNC-8879-PS Technical data Pressure: 800 kN Total working length: 2050 mm Distance between the standards: 2050 mm Standard depth of throat: 255 mm Slide stroke, working stroke: from: 215 mm Mounting height max.: 390 mm Working speed: Press stroke: 8 mm/s up: 60 mm/s Voltage 50 Hz 3x: 380 Volt Motor power: 5.5 kW Machine´s weight about: 6700 kg Overall dimensions machine: Length: 3700 mm Width: 2000 mm Height: 3400 mm Various accessories: Set of bending tools Set of retaining clamps Motorized stop: 500 mm

Material thickness: 12 mm Throat: 0 mm Material length: 0 mm Material width: 0 mm MACH-id       6047 MAKE           OMERA TYPE              R4 / 12 YOP                1999 DIMENSIONS Length           2400 mm Width             2000 mm Height            1800 mm Weight            3800 kg

Material thickness: 5 mm Throat: 0 mm Material length: 0 mm Material width: 0 mm Make Lucas VBU 4 Type VBU 400 trimming & bearding Year 12 . 2001 Siemens SIMATIC Max. swing = 500 mm Thickness = 5 mm Stroke cylinder = 350 mm 2 x Support ZHSA 2 x Sick safety guids

Nominal effort: 630 tons Course stroke: 420 mm Number of strokes in a minute: 20 Bolster plate-to-ram adjustable stroke: 180 mm Max. distance plate-to-ram (in lower position of slider): 750 mm Slider dimensions 1000x1000 mm Table size: 1250x1250 mm Dimensions of the hole in the table 800x800mm Thickness of the sub-stamp plate 180 mm Height above floor level 600 mm Main motor power: 56 kW hydropneumatic pillow in the table Press overall dimensions: -Length: 3280 mm -Width: 3470 mm -Height: 6190 mm Press weight: 52650 kg

Hydraulic trolley for vertical sawmill Esterer Model VS Year of manufacture 1964 Dismantled from the sawmill

Remigia type trimmer for plywood. High working speed, low consumption, works perfectly and can be viewed at any time

End trimming unit IMA Type: 08.41 - pneumatic swivable

Capacity, ton 1000 Slider stroke, mm 400 Unattainable stroke, mm 12 Slider strokes, spm 20 Shut height, mm 730 Distance adjustment between table and slider, mm 200 Slider size, mm 1200 x 1200 Table size, mm 1250 x 1250 Table gap size, mm 800 x 800 Bolster plate thickness, mm 260 Pneumatic cushion capacity (eject), ton 40 Pneumatic cushion stroke, mm 160 Pneumatic cushion load, kg 4500 Main power drive, kW 75 Voltage, V 340 Machine dimensions, mm 4310 x 3820 x 6790 Machine weight, kg 77100

Maximum force ton-force 400 Slider stroke length mm 250 Slider stroke length to lower position mm 12 Slider strokes per minute 25 Number of single turn-on 19 Maximum distance between table and slider (in lower position of slider) mm 510 Adjustment mm 160 The sizes of a under-forginig plate mm 1000 Table overall dimensions: mm - from front to rear 1000 - from left to right 1000 The sizes of an aperture in a table mm 630 Slider overall dimensions mm 800 x 800 window dimensions in cheeks mm 600 Total power of electric motors kW 43,3 Press overall dimensions mm - length 3470 - width 3140 - height 5940 Press weight without hydropneumatic pillow kg 31 400

Nominal effort: 630 tons Course stroke: 420 mm Number of strokes in a minute: 20 Bolster plate-to-ram adjustable stroke: 180 mm Max. distance plate-to-ram (in lower position of slider): 750 mm Slider dimensions 1000x1000 mm Table size: 1250x1250 mm Dimensions of the hole in the table 800x800mm Thickness of the sub-stamp plate 180 mm Height above floor level 600 mm Main motor power: 56 kW hydropneumatic pillow in the table Press overall dimensions: -Length: 3280 mm -Width: 3470 mm -Height: 6190 mm Press weight: 52650 kg

Model: R3/7 With Two Heads Bench size: 1.050 x 1.300 mm Year 2008

Capacity, ton 630 Stroke path till its position where it develops nominal capacity, mm 16 Slider stroke, mm 320 Slider strokes, spm 20 Max. distance between table and slider, mm 800 Distance adjustment between table and slider, mm 180 Table size, mm 1250 x 1250 Slider dimensions, mm 1000 x 1000 Opening in the table, mm 800 x 800 Thickness of bolster, mm 180 Cushion stroke, mm 130 Main motor power, kW 58 Machine dimensions, mm 3280 x 3470 x 6190 Machine weight, kg 55500

Modular unit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -HOMAG trimming unit for trimming the protruding edges on the front and rear edges -with heavy leadership -Milling unit: swiveling -2x motors -Motor type: -Power: 0.23 kW -Voltage: volts -Frequency: Hz -Speed: 18,000 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1000/420/H655 mm -Weight: 140 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -HOMAG trimming unit for trimming the protruding edges on the front and rear edges -with heavy leadership -Milling unit: swiveling -2x engines Perske -Motor type: -Power: 0.22 kW -Voltage: volts -Frequency: Hz -Speed: 18,000 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1240/600/H1100 mm -Weight: 296 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -HOMAG trimming unit for trimming the protruding edges on the front and rear edges -with heavy leadership -Milling unit: swiveling -1x engines Perske -Motor type: -Power: 0.75 kW -Voltage: volts -Frequency: 300 Hz -Speed: 8,600 rpm -Other engines with other services in stock for an additional charge -Dimensions: 990/620/H340 mm -Weight: 52 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -HOMAG trimming unit for trimming the protruding edges on the front and rear edges -with heavy leadership -Milling unit: swiveling -1x engines Perske -Motor type: -Power: 0.75 kW -Voltage: volts -Frequency: 300 Hz -Speed: 8,600 rpm -Other engines with other services in stock for an additional charge -Dimensions: 940/620/H350 mm -Weight: 54 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -HOMAG trimming unit for trimming the protruding edges on the front and rear edges -with heavy leadership -Milling unit: swiveling -2x motors -Motor type: -Power: 0.23 kW -Voltage: volts -Frequency: Hz -Speed: 18,000 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1020/400/H700 mm -Weight: 110 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -Manufacturer: Homag, trimming unit from edge banding machine BRANDT KM 35 -Motor: Homag type LF-40-L -Power: 0.27 kW / 12000 rpm -Voltage: 220V / 200 Hz -Saw blade: Ø 90 mm -Individual components: see photos -Dimensions: 590/280 / H750 mm -Weight: 27 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -Manufacturer: Homag, trimming unit from edge banding machine BRANDT KM 35 -Motor: Homag type LF-40-L -Power: 0.27 kW / 12000 rpm -Voltage: 220V / 200 Hz -Saw blade: Ø 90 mm -Pneumatic components: Bosch -Individual components: see photos -Dimensions: 500/370 / H680 mm -Weight: 26 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -Manufacturer: Hemag, saw unit can be swiveled by 30 ° -Saw blade: max. Ø 350 x 30 mm -Motor: Perske type DKNS 120/2 3.0 kW / 2830 rpm -Protection class: IP 54 -Dimensions: 950/780 / H630 mm -Weight: 115 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -Manufacturer: Homag, trimming units from the BRANDT KM 36 edge banding machine -Motors: Homag type LF-40-L / Perske KNS 22.08-2 -Power: 0.27 kW / 12000 rpm / 10800 rpm -Voltage: 220V / 200 Hz -Pneumatic components: Bosch -Individual components: see photos -Price / fee: complete -Dimensions: 500/560 / H670 mm -Weight: 51 kg

Unit construction kit, format processing unit, cutting unit, milling unit, profile milling unit, jointing milling unit, trimming unit, double-end profiler, edge processing machine, scoring motor, chipper motor, milling motor for edge processing machine -Sale: Handover in the current condition as seen -Case: slight damage, see photos -Trimming unit: for trimming the protruding edges on the front and rear edge -Adjustment range: 400 to 840 mm -Clamping: pneumatic -Motors: Holz-Her 750 W / 2600 rpm -Saw blade: Ø 160 mm -Dimensions: 1010/450 / H540 mm -Weight: 94 kg

Terminal and trim box, road cell -Terminal box: for up to 4 load cells -Inputs and outputs: via PG screw connections -Protection class: IP 65 -4 inputs, cable gland M12 for cable diameter: 2 to 6.5 mm -1 output, cable gland M20 for cable diameter: 7 to 12 mm -Number: 2x available -Price: per piece -Dimensions: 205/110/H70 mm -Weight: 0.8 kg

diameter range 5-12 mm shaft length under head 10-130 mm output - pieces/min 120

diameter range 2,2-8 mm shaft length under head 6-40 mm output pieces/min 250

Dreiseitenschneider - Halbautomatisch - Three-Knife-Trimmer - Semi-automatic Wohlenberg A43/30W Baujahr / Year 1959 - Serial-No. 4651 Semi-Automatic -Online-Video-Inspection by Skype-Video- -We would be very pleased with your visit - more machines on Stock- -Available Immediately - Can be inspect- -On Stock Emskirchen / Nuernberg - Can be test-

Dreimesserautomat / Three Knife Trimmer Hoerauf SN-140 Demand Baujahr / Year 2000 - Serial-No. 405060080 Formatbereich (unbeschnitten) / Paper size (before cutting) min. 80 x 60mm - max. 410 x 315mm Formatbereich (beschnitten) / Paper size (after cutting) min. 80 x 60mm - max. 380 x 300mm Stapelhoehe / Pile height max. 80mm Leistung bis zu 20 Takte/min. / Speed approx. 20 cycles per minute -Online-Video-Inspection by Skype-Video- -We would be very pleased with your visit - more machines on Stock- -Available Immediately - Can be inspect- -On Stock Emskirchen / Nuernberg - Can be test-
