S. No.: 011001
Equipment / Additional information:
Untrimmed Book Size:
Max. Spine Length 350 x Fore-edge Length 320 mm
Limitation: The maximum length from the center to top or
bottom is 175 mm
Min. Spine Length 148 x Fore-edge Length 105 mm
Limitation: The minimum length from the center to top or
bottom is 74 mm
Finished Book Size:
Max. Spine Length 340 x Fore-edge Length 300 mm
Limitation: The maximum length from the center to top or
bottom is 170 mm
Min. Spine Length 145 x Fore-edge Length 101.6 mm
Limitation: The minimum length from the center to top or
bottom is 72.5 mm
Trim Width:
Fore-edge: Max. 110 mm / Min. 1 mm
Top and bottom: Max. 80 mm / Min. 1 mm
Trim Height:
1 to 65 mm
Book Weight:
Transport Speed Level 7: 2.8 kg or less
Transport Speed Level 6: 4.0 kg or less
Transport Speed Level 5: 5.2 kg or less
Height of Entrance Section Pusher:
56 mm
Clamp System and Pressure:
Servo Motor
2 kN to 8kN
Production Speed:
400 to 1,000 cycles per hour
Switzerland
