used Dowel drilling machines for sale

Dowel drilling rig Schleicher Type: Dowel-Quick Clamping width 950 mm 6 drill shafts Clamping height 80 mm Drill hole depth for drill shafts 35 mm Drill hole depth for drill guide cone 100 mm Drill hole diameter for drill shafts 6 – 35 mm Drill hole diameter for drill guide cone 6 – 16 mm Smallest drill hole spacing 30 mm Swivel drill beam lockable at 0 – 45 – 90 degrees Fast drilling sequence via roller-bearing drill shafts Drive by means of cone chew coupling through each hand drill Dowel-Quick is known for its wide range of applications in furniture production, Fitting recess work, frame and flat frame dowel work – for small medium-sized and large companies are interesting. Shortest set-up and changeover times. Corner joints blunt or on Mitres, frame connections of all kinds as well as fitting recess work can be produced quickly and precisely.

Dowel drill Scheer Dowel Hole Drill Type DB 5 Machine No. 508310 Year of manufacture 1983 Drilling of carcasses, frame joints, drawers, Door coverings, rows of holes or groups of holes Drill beam length 640 mm Spindle spacing min. 32 mm, max. 640 mm 21 pieces of spindles Drilling depth 80 mm With drills Drill beams can be swivelled pneumatically Motor power 2.2 kW Portal passage maximum width with one side stop 915 mm, with 2 side stops 770 mm 2 pneumatic hold-down devices on machine table Weight 460 kg with pallet Dimensions 1350 mm x 820 mm x H 1400 mm

New exhibition machine! List price: 13.610,- 400V, 3Ph, 50Hz / 1.5 kW complete in standard version with: Fully automatic electronic control with pulse operation via foot valve clamping-drilling-relaxing, electric intermittent operation. Automatic return of the drilling unit after the set drilling depth has been reached. Automatic borehole depth extension for frontal drilling. This eliminates the need to change the borehole depth from flat-side to front-side drilling (+ 10 mm, e.g. for dowel length 35 mm, drilling depth flat side 14 mm and drilling depth front side 24 mm). 1 drill beam with 21 spindles, pitch 32 mm, motor 1.5 kW (drill feed 0-70 mm). incl. 21 quick-change chuck (Ganner system) for easy changing of the drills. Easy swivelling of the drilling unit from 0° to 90°, supported by gas cylinders. 1 clamp carrier can be moved in Y-axis with 3 pneumatic clamping cyl ...

Voltage: 380V 50Hz Control voltage: 220V Current Consumption: 4.7A Foot switch for clamping cylinders (pneumatic) Height and depth limitation pneumatic Manual feed lever with on/off switch Stops for long-hole drilling Grid Wave Main switch with motor protection and CCE plug Chassis Drilling in 2 planes with one clamping

Motor 2.8 kW/380 V/50 Hz, work table 1250x350 mm, 2 pneumatic hold-down holders, 2 drilling levels pneumatically switchable, limitation adjustable at the bottom/top, stop to the left of the table 1450 mm, locking ruler 16 left/16 right, 16 mm spacing, feed drill with foot pedal, suction nozzle D=80 mm, incl. 3 pieces of multi-spindle drill heads

Zangheri & Boschetti B23 K dowel drill with swivel head Masch. Ref. K 74590 21 spindles Weight 506 kg The machine is in good condition, ready for operation. Subject to changes, errors and prior sale ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system+technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Phone: 0041 62 966 18 32 Fax 0041 62 966 21 12

SPECIFICATIONS: Number of drill bits: 35 (1/2 right - 1/2 left) Drilling distance mm: 32 Table width mm: 1250 03 Clamping jacks Installed capacity KW: 3.0 Electrical/pneumatic operation

Stegher FD Dowel Drill Brand: Stegher Type: FD Year of construction: 1995 M-No.: 35/12951 Control: Alfa-numeric, with pre-programmed drill cartridges Longitudinal and strin-side bores Length stops: Left and right digital stops for longitudinal drilling Lugs for left and right side holes with turret positioning Dowel dimensions: 6-16 mm Drilling depth: 80 mm Motor: 2.2 KW Compressed air: 6 bar Suction: ø80 mm

SPECIFICATIONS: Number of drill bits: 35 Drilling distance mm: 32 Vertical/horizontal swivel Installed capacity KW: 2,8 Quick release Pneumatic operation

SPECIFICATIONS: Number of drill bits: 29 - Quick release Drilling distance mm: 32 Pneumatic operation Vertical/horizontal tilt: 0°-90° Installed capacity: KW 2.2 04 Workpiece clamping hounds With angle drill

Dowel drilling machine DORNBURG Type: DDBP incl. 5-fold gear drill chuck Rotatable drilling unit Support table height adjustable and swivel from -20° to +30°. Motor power 1.5 KW Pneumatic workpiece holder automatic pneumatic drill feed incl. several drill bits. Condition see pictures, or please refer to the item description. Parts can also be picked up by yourself. All measurements are approximate. All information to the best of our knowledge but without warranty. Subject to prior sale. The items can be picked up by yourself or shipped at the expense of the buyer. Shipping costs are a guideline, depending on the distance and unloading option, they may vary.

Duebel hole drilling machine BORING SYSTEM 21 PRESTIGE QUICK CONNECTIONS 21 DRILLING SPINDLES AXLE DISTANCE 32 MM CENTER DISTANCE FROM THE FIRST TO THE LAST DRILL CHUCK 640 mm DRILLING DEPTH 65 mm Engine power 2 hp Aluminium stop with 2 folding straps equipped with 1 left stop 1500 mm and 1 right stop 1500 mm 5 drilling spindle droplets 2 Pneumatic hold-downs in a safe and secure manner incl. packaging Quick Connection Drilling Spindles Drill head in cast iron Cast iron work table Drilling depth adjustment via patented spiral system Pneumatic scraping of the drilling group from 00 to 90 ° adjustable in any position. Stop infinitely adjustable via millimeter scale with magnifying glass High drills over num. digital display adjustable Back-side stop max. travel 300 mm Fixed stop on 37 mm for doorband Machine built according to Ce standards

Specifications: Uniform spindle spacing: 32 mm Number of spindles: 23 Distance between the first and last spindle on the drill head: 672 mm drilling depth: 80 mm Table size: approx. 900 x 545 mm size of the workpiece: 800 x 2500 x 100 Working pressure: 0.6 MPa Air consumption: 10 NL/cycle Voltage, frequency: 400 V/50 Hz Spindle speed / min.l: 2800 rpm. Motor power: 1.5 kW Weight ca: 400 kg Dimensions: 1220 x 1065 x 1400 mm Patented spiral system Programming and adjustment devices of horizontal and vertical Drilling depth. Pneumatic drill head shears Drill head frame of 0-90 degrees with blocking in any position and reference switching angle with each angle Head with quick-connect spindles (the quick-release buckets are a Zubehoer). 5 quick-release buckets are standard. 2 patented pneumatic pressure devices accident-protected. 2 side connectors on the table ...

NUMBER OF SPINDLES 21 SPINDLE DISTANCE 32 MM DISTANCE BETWEEN FIRST AND LAST SPINDLE 640 MM DOWEL DRILL HEAD BY MAGGI MADE IN ITALY

Dowel drill Schleicher Type Partner 27/2 Specifications: • Year of construction: 1991 • Working width (mm): 900 • Number of drilling spindles: 27 • Pitch (mm): 32 • Drilling unit: swivelling • Motor power (kW): 1.9 • Space requirement L x W x H (mm): 1120 x 900 x 1150 • Weight (kg): 550
