double column milling used for sale

Double head eyeletting machine Hang 87 D Serial-No. 31583

Double eyeletting machine Hang 87 D Serial-No. 17040 Projection 320mm Release via foot switch 300mm Release via 3-point switch 250mm Working height 900mm Cycle time/capacity 0,5 sec Width 1200mm Depth 900mm Height 1450mm Net weight 420kg Gross weight 480kg Cycle time 0,5sec

General SKU395X1066 MakeKemutec LocationBarneveld Main Features MaterialStainless steel Volume600 Ltr. Motor2.2 KW Specified Features - Tumbler mixer Double cone tumbler mixercheck Capacity400 Ltr. (max. 600 Ltr.) Diameter900 mm Length/Depth450 mm Cylindrical length450 mm Conical length2x 450 mm Inlet300 mm Outlet150 mm With motor2,2 kW 380V Speed mixer17 rpm MaterialStainless steel 1.4301 (304), Stainless steel 1.4404 (316L) Information No.001082 Year of construction1995 Floorspace1,8 x 1,5 m Total height2,5 m Weight1100 kgTumbler mixersKemutecMixers > Tumbler mixersBrand > Kemutec What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in Barneveld for many more machines!

Pallet circulation system for the production of Twin-Wall Panels and Filigree Floor Slabs comprising: 56 pallets; length = 10.00 m, width = 3.00 m Longitudinal and transverse transport systems for the pallets Stacker crane for storing and retrieving the pallets Curing chamber with 50 storage spaces 1 tilting station at the demoulding station Stacking areas with transfer trolleys Transfer trolleys for horizontal and vertical precast elements Automatic concrete distributor (built in 2018) Turning device for the production of double walls Beckhoff control system 2 laser plotters, from Z-Laser Steel processing PROGRESS: Straightening and cutting system, Progress MSR2/16 with positioning device for the steel of a complete pallet – plotter by Z-Laser Lattice girder cutting system for wall girders Spare parts for electrical/control systems, spare parts for mechanical c ...

General SKU235U235 MakeIlchmann TypeDTSF 2x200x6.525 Mach.No.CRO 0348 Year of construction2014 Main Features Motor3 KW Length6525 mm Inlet diameter350 mm Specified Features - Horizontal screw conveyor MaterialStainless steel 1.4571 (316Ti) Horizontal conveyor screwcheck Trough-typecheck Double shaftcheck Diameter200 mm (2x) Length6525 mm Between inlet and outlet5880 mm Shaft diameter108 mm (x) Pitch200 mm Inlet630x350 mm Outlet350x350 mm Max. temperature90 °C With adjustable packing glandscheck Motor3 kW, 220-230 volt / 380-400 volt, 1456 rpm Screw speed31 rpm With coverscheck Information LocationBarneveld Floorspace8,3x5,1 m Total height0,49 m Weight1250 kg CEcheck Extra SpecificationsCapacity: max. 5 m³/hOils & fatConsumer wastePaints & coatingsPowdered foodsGeneric medicinesOintmentsTea, herbs & coffeeFine chemicalsStarchOther chemicalAgrochemicalsR ...

General SKU204U042 LocationBarneveld MakeWerner &: pfleiderer Sizes Screw diameter70 mm Main Features Motor108 KW L/D23 Specified Features - Double screw extruder Double screw extrudercheck Screw diameter70 mm L/D23 Co-rotatingcheck Water coolingcheck AC-motor108kW, 330Volt, 1500rpm With variable speed drivefrequency controller Screw speed198 rpm Exchangeable segments( not included) MaterialNichrome 2.4869 With jacketcheck General TypeZSK 70F175E Mach.No.231783 Year of construction1996 ( gearbox 2017) With switchgearcheck Sizes switchgear1,25x0,7x2,15 m Floorspace4,6x2 m Total height1,7 m Weight6400 kg Extra Specificationsinlet: 142x130 mm- there are 2 screw shafts present- no screw segments present- no extruder head presentOils & fatConsumer wastePaints & coatingsPowdered foodsGeneric medicinesOintmentsTea, herbs & coffeeFine chemicalsStarchOther chemicalA ...

Double Shield Tunnel Boring Machine for hard rock Typ of TBM Hardrock Double Shield TBM Manufacturer Robbins / Herrenknecht Year of manufacture 2015, 2020 Boring diameter DME = 7.100 m Length 14 m Main drive power 7 x 330 kW = 2.310 kW Main trust force 33.780 kN @ 350 bar Stroke length 1.760 mm Installed power 4.800 kVA Weight ca. 770 t Find more here - /

2021 Eillert WASH-20 Double Washer – Like New, Low Hours, Premium Vegetable Washing System – Ready for Immediate Production, Offered for sale is this 2021 Eillert WASH-20 Double Washer, a premium vegetable washing system in exceptional, like-new condition. The machine has very low operating hours, has been meticulously maintained, and is ready for immediate operation., Designed for professional fresh produce processors, the WASH-20 combines high washing performance with gentle product handling, making it suitable for delicate leafy vegetables as well as heavier products requiring intensive cleaning., ---------------------------------------------------------------, Key Features, - Manufacturer: Eillert, - Model: WASH-20 Double Washer, - Year: 2021, - Condition: Like new, - Operating hours: Very low, - Double washing section for superior cleaning performance, - Stainless steel hygienic ...

Double side corner cutter - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Double side corner cutter Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers Laminators Offset printing machinery Others Paper drills Perfect binders Pile turners Spare parts Stitching machines Double side corner cutter Price: 3750 EUR Download PDF Double side corner cutter Very good condition. This is a professional, production device for rounding corners. Solid construction ensures precision of operation. Two trimming heads. Interchangeable knives. Adjustable margins. Controlled by foot pedal. One set of 8mm knives included Stack height approx. 80mm Weight 100kg Efficiency 20 cycles/min Compressed air supply. Ask About The Product  ...

Hang 150 Double-Head Riveter for Binders - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Hang 150 Double-Head Riveter for Binders Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers Laminators Offset printing machinery Others Paper drills Perfect binders Pile turners Spare parts Stitching machines Hang 150 Double-Head Riveter for Binders Price: 5750 EUR Download PDF Hang 150 Double-Head Riveter for Binders Manufacturer: Hang Germany Machine has been overhauled and is ready to use. The machine is used for riveting all types of ring mechanisms. Two riveting heads with adjustable spacing. Cardboard thickness: 0.2-4mm Throat depth: 310mm Head spacing: adjustable from 35-440mm Cycle time: 0.5s Weight: 570kg Powe ...

Tranklein EK-D 100 Double Corner Trimmer - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Tranklein EK-D 100 Double Corner Trimmer Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers Laminators Offset printing machinery Others Paper drills Perfect binders Pile turners Spare parts Stitching machines Tranklein EK-D 100 Double Corner Trimmer Price: 7000 EUR Download PDF Tranklein EK-D 100 Double Corner Trimmer Made in Germany by Karl Tranklein. Very good condition. This is a professional, production-grade corner rounding tool. Sturdy cast iron construction ensures precise operation. Two trimming heads. Interchangeable knives. Adjustable margins. Includes one set of knives with an 8mm radius. Stack height: 100mm ...

HANG 136DK Double-head paper drill - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl HANG 136DK Double-head paper drill Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers Laminators Offset printing machinery Others Paper drills Perfect binders Pile turners Spare parts Stitching machines HANG 136DK Double-head paper drill Price: 1070 EUR Download PDF HANG 136DK Double-head paper drill The machine is in perfect condition, ready to work. Hang is the best brand among drills. Made in Germany. Technical data: Two drilling heads drill diameter 2-10mm Stack height 55mm 380V power supply Weight 150 kg The machine has an enlarged table, with a large range of adjustment in each plane. Cycle control with foot pedal. The ...

Double-sided grinding and polishing bench MEYER type SMPMasch. No. 848 Year of construction 1963Shaft diameter 50 mmGrinding wheel holder 305 mmDisc spacing 1470 mmGrinding-polishing wheel diameter max. 800 mmWorking height 550 mmSpeed 710 / 800 / 950 rpm. Drive power 2x 3 kWNet connection 380 volts, 50 Hz.- two drive motors for each working side separately- star-delta switch for each drive motor separately- speed change by folding the drive belt- dust extraction flange 100 mm-

Profile Machining Center Machining length approx. 8,500 mm, max. profile size 300 x 200 mm, Travel XYZ = 9,300 x 1,000 x 800 mm, Sawing unit (mitre cuts), 4-axis drilling/milling unit (16 kW, 18,000 rpm), tool changer 24-fold option pendulum operation, option Clamping element displacement, preparation Flowdrill, , safety enclosure, BECKHOFF control panel (programming software CamQuix), refrigeration unit IDEA 16CCM-50-A-F-3 (No. C2019010009, year of construction 2019), Control cabinet, machine under power in production use Original price 176.500 EUR

x-travel:14000 mm y-travel:3100 mm z-travel:1.200 mm (220 - 1.420) mm distance between columns:4.417 mm table-size:14.000 x 2.500 mm workpiece weight:15.000 kg/m drive capacity - spindle motor:25 kW spindle cone:63 HSK spindle turning speed range:18000 rpm milling feeds:30000 mm/min dimensions of the machine ca.:15.000 x 8.418 x 6.033 mm weight of the machine ca.:135 t CNC controller: SIEMENS 840 D universal milling head:5 Achsen mit ?C5C? Elektrospindel automatic tool changer:24 fach

x-travel:6500/13150 mm y-travel:4000 mm z-travel:1250 mm w-axis:2250 mm table surface area:5500/12150 x 3000 mm max. workpiece weight:70.000/105.000 kg ram head dimension:480 x 510 mm milling spindle motor:63 kW max. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/min feed speeds:1 - 24000 mm/min w-axis:1 - 6000 mm/min distance between columns:3500 mm passage:3000 mm total power requirement:120 kW weight of the machine ca.:245 t dimensions of the machine ca.:29,0 x 7,7 x 8,1 m Machine is in nearly new condition and was completely modernized in 2020! With CNC SIEMENS 840 D Automatic tool magazine for 153 tool positions Automatic milling head magazine for 6 milling heads Machining module ? straight ? straight long ? Machining module ? angle standard ? 4000 rpm, 144 x 2.5°, ISO 50 Machining module ? narrow angle extended ? 40 kW, 4000 rpm, 1800  ...

x-travel:6500/13150 mm y-travel:4000 mm z-travel:1250 mm w-axis:2250 mm table surface area:5500/12150 x 3000 mm max. workpiece weight:70.000/105.000 kg ram head dimension:480 x 510 mm milling spindle motor:63 kW max. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/min feed speeds:1 - 24000 mm/min w-axis:1 - 6000 mm/min. distance between columns:3500 mm passage:3000 mm total power requirement:120 kW weight of the machine ca.:245 t dimensions of the machine ca.:29,0 x 7,7 x 8,1 m The machine is in mint condition and was generally overhauled in 2020! with CNC SIEMENS 840 D autom. tool magazine for 153 tool stations autom. milling head magazine for 6 heads milling heads - straight - straight extended length - milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50 milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm,  ...

CNC Double column Coordinate Boring Machine with Deep Hole Drilling Support Kolb KBN G 120 Year of manufacture 1984 / Retrofitted with Heidenhain TNC 426 in 2006 Table size 4250 x 2200 mm Table load max. 14 t Table longitudinal travel X 3000 mm Main spindle cross travel Y 2180 mm Deep hole drilling support cross travel A - 2000 mm Spindle vertical travel Z 500 mm Distance between the columns 2640 mm; Spindle to table 100 - 1300 mm; Spindle diameter 224 mm Spindle drive motor rating 46 KW Spindle speeds 14 - 1400 rpm Spindle taper ISO 50 Drilling in steel ST60 : 100 mm diameter; Boring to 300 mm; Threading to M 125 x 3; Milling capacity 730 cm³/min.; Second support for Deep Hole Drilling Spindle speeds for BTA and ELB boring 315 - 3150 rpm High pressure cutting oil delivery to spindle Chip- and oil collection and separation via Centrifuge. Very good condition P ...

PRESS FOR PRODUCTION ALUMINIUM TRAYS FOR ALIMENTARY USE COMPLETE WITH DOUBLE IMPRESSION MOULD-1100 CC. COMPOSED OF: A LUBRICATION UNIT 4-COLUMN MOLDING UNIT TOW-SCRAP CONTROL PANEL. 55 STROKES/MINUTE DEPENDING ON THE MOULDS. PASS COLUMNS FOR MOULDS UP TO 800 MM

pressure: 100 t passage width: 1000 mm stroke: . mm width: 800 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Double column press with 200 T output, Idle speed 45 mm/sec Opening speed 60 mm/sec Starting press speed 9 mm/sec Table size 2000x600mm Plunger size 2000x600mm OIL temperature monitoring Manual lubrication Free positioning of the plunger ( adjustable via adjustable sensors ) PILZ photoelectric sensors 14.1 mm on front and back Circulatory oil cooling Pressure retaining valve 0 to 600 sec. Mechanical plunger protection at the upper breakpoint T-grooves according to DIN, and according to customer requirements Pressure adjustment from 40 T to 200 T (adjustable via rotary knob) Travel limitation optionally via pressure or position Set-up operation, single stroke ( adjustable via key switch ) Two-hand operation Construction, commissioning, instruction against separate calculation Design Press design double column press Therma ...

Passage width 2500 mm Stroke 900 mm Total power requirement 62 kW Machine weight ca. 27,5 t Dimensions L x W x H approx. 3950 x 2200 x 4850 mm Retraction force 40 t Master cylinder 2 pieces Column diameter 220 mm Installation height 1300 mm Table size 2500 x 1600 mm Ram size 3100 x 16000 mm Table height above floor approx. 900 mm Flow speed 200 mm/sec Return speed 200 mm/sec Working speed 5 - 15 mm/sec Oil tank 1500 l Oil quantity 1200 l Pressure control adjustable from up to 50 - 400 t Thermoforming cushion 1400 x 800 mm Deep-drawing unit capacity 30 - 60 t Deep-drawing cushion stroke 250 mm Deep-drawing cushion speed 5 - 80 mm/sec robust machine body with solid welded construction low-maintenance and reliable Piston rod with induction hardening and chrome cladding T-slots according to customer requirements, if not specified 22mm according to DIN CE Certific ...

Here are the technical data of the offered machine: Technical data + information: • No-load speed up to 40 mm/sec • Opening speed up to 40 mm/sec • Starting press speed 5–15 mm/sec • Table size/heating plate size 600 × 600 mm • Plunger size/heating plate size 600 × 600 mm • 2 heating plates, electrically heated, up to 250 degrees – as OPTION • Total size approx. 2000 × 1000 × 2800 mm height • OIL temperature monitoring • Automatic lubrication • Free positioning of the plunger • SICK/LEUTZE light barriers 14.1 mm on the front • Circulating oil cooling • Pressure holding valve 0 to 1800 sec. • Rear monitored door • Pressure adjustment from 30 T to 120 T • Travel limitation either by pressure or position • Programming set-up mode, single stroke (adjustable via rotary switch) • Control panel permanently installed in the wall  ...

pressure: 160 t distance between columns: 850 mm stroke: 150 mm table surface area: 850x650 mm total power requirement: kW weight of the machine ca.: 7 t dimensions of the machine ca.: 2,5 x 2,5 x 3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 6701 Type: 4000 kN Producer: Hydraulico Created: 1977 Parameters: Control system: SIEMENS SIMATIC OP Compressive force: 4000 kN Stroke: 800 mm Table height: 680 mm

Inv. Num. : 6700 Type: 3000 kN Producer: Loire Created: 1992 GO 2008 Parameters: Control system: SIEMENS SIMATIC OP17 Compressive force: 3000 kN Table length: 2495 mm Table width: 1505 mm Maximum distance between the table and the ram (when the ram is low): 1200 mm Stroke: 800 mm Working speed: 64 mm/s

Key data: 400 t, 800 mm

Oil-hydraulic double-column press 400 T with sliding table Press type: Double column press Thermally neutral 80 – 120 °C Number of operating pages 1 page Forces Pressing force max. 4000 kN Free tear-off force max. 400 kN Print build-up time Closed tool steel on steel Max. 4 sec. Dimensions: 3,800 mm long and 4,475 mm wide Max. opening width 800mm Stroke 800mm Table height above floor 1100mm Height above ground (height) approx. 4300 mm Hall height min. 5500 mm Parallel deviation at 20°C +/- 0.1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.2 mm/m Weight Total weight of the press without consumables and table top approx. 28 tons Press table Table size 1500x1500 mm Velocities Quick closing at 100 mm sec. Pressing speed 8 – 3 mm sec. Acoustic pressure Sound pressure level, measured at a height of 1.5m on the control pane ...

pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm hole in the table:110 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm power requirement:15,0 kW dimensions (WxDxH):1,9 x 1,3 x 2,7 m foundation pit:not necessary

pressure:250 t distance between columns:1110 mm stroke:250 mm Distance table/ram, max. stroke up, adjustment up:500 mm Table surface area:1100 x 900 mm Table height above floor:950 mm Side window:690 mm Ram surface:1100 x 900 mm Oil volume:730 l Power capacity:56,0 kW Dimensions (WxDxH):2,3 x 1,55 x 3,96 m

pressure:300 t distance between columns:1800 mm stroke:1000 mm Distance table/ram, max. stroke up, adjustment up:1300 mm Table surface area:1600 x 1200 mm Table height above floor:1080 mm Ram surface:1600 x 1200 mm Weight:24,0 t Dimensions (WxDxH):2,8 x 2,1 x 6,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

Key data: 30 t

Hydraulic press can be used in a variety of ways as an assembly press, small series press, manual insert press or heating press in double-column presses Design (H-press) A tour of the press is possible at the Ennepetal camp. It is a 2.5-year-old, unused press with no operating hours, which is sold with a full warranty. List price: 45,000 Technical details: Robust machine frame Capacity: 30 tons – at 300 bar Pump ASC: 28.5 liters/min. Engine: 11 kW – 15 hp Oil tank: 600 × 450 × 500 mm – with approx. 100 litres Cylinder piston: Ø 110 mm Cylinder inside: Ø 70 mm Stroke: 500 mm Fast forward: 45 mm/s Return: 55 mm/s Guides: Ø 50 mm Table top: 800 × 550 mm – with T-slots Plunger plate: 700 × 500 mm – with T-slots Total weight: 2000 kg Valves from BoschRexroth Control cabinet technology from renowned manufacturers Press table size 700 × 500 × 7 ...

pressure: 500 t distance between columns: 1600 mm stroke: 60 mm max. ram stroke: 60 1 / min ram adjustment: 100 mm dayligth: 700 mm Table area: 1600x1400 mm ram surface: 1400x1150 mm total power requirement: kW weight of the machine ca.: 40 t dimensions of the machine ca.: m About usmore than 400 machines in the warehouse over 12000 m² storage area, crane capacity 70 tmore than 1000 items accessories for your workshopYou want to sell machines production lines or your company, then talk to us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t passage width: . mm stroke: . mm tracking travel: 45 mm safety distance: 208 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 3100 mm swing diameter: 3600 mm turning height: 3600 mm control: Fagor 8035 table load: 35 t turning speeds: 0,32 - 40 U/min max. ram stroke: 3000 mm table load: 35 t turning speeds: 0,32-40 U/min total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 630 KN distance between columns: 800 mm stroke: 150 mm table surface area: 720x550 mm ram surface: 720x520 mm dayligth: 420 mm rapid drop speed: 394 mm/sec working feed: 71/17 mm/sec return speed: 390 mm/sec adjustment movement of the stroke: 120 mm total power requirement: 15 kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore for us not binding. We reserve the right to prior sale, it apply only our business and conditions of sale. About Us more than 400 own machines in stock over 12000 m² storage area, crane capacity 70 t more than 10000 articles accessories for your workshop You want to sell machines, production lines or your company, Then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 630 t passage width: 1390 mm stroke: 400 mm table surface area: 1390x1250 mm total power requirement: 75 kW weight of the machine ca.: 36 t dimensions of the machine ca.: BxTxH 3200x2800x4000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t stroke: 150 mm table surface area: 850x650 mm ram surface: 730x560 mm weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 2000x2500x3600mm m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 40 t distance between columns: 600 mm stroke: 150 mm table surface area: 600x410 mm ram surface: 220x130 mm table height: 850 mm weight of the machine ca.: 2,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t distance between columns: 500 mm stroke: 150 mm ram surface: 320 mm table surface area: 470x400 mm weight of the machine ca.: 12 t dimensions of the machine ca.: 2000x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 300 t passage width: 1350 mm stroke: 500 mm column travel -side: 830 mm table surface area: 1350x1380 (1870x1380) mm table height: 1060 mm total power requirement: 45 kW weight of the machine ca.: 20 t dimensions of the machine ca.: BxTxH 2500x2000x3950 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t distance between columns: 850 mm stroke: 400 mm ram surface: 800x700 mm : 300 mm pressure of ejector: 20 t table surface area: 800x700 mm total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: 1800x1800x4200 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t distance between columns: 580 mm stroke: 150 mm dayligth: 370 mm table surface area: 560x400 mm ram surface: 400x350 mm hole in the table: 80 mm weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1500x500x2500 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 360 t stroke: 60 mm table surface area: 525x430 mm no. of strokes: 60 Hub/min : 40 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 8400 mm grinding width: 1450 mm workpiece height: 1250 mm surface area: 8000 x 1250 mm table height over floor: 920 mm distance between columns: 1470 mm workpiece weight max.: 59700 kg weight of the machine ca.: 59,7 t dimensions of the machine ca.: 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW The data for this ad was created with ModulMWS - the  ...

Pressure total: 140 ton Stroke: 800 mm Daylight: 1.004 mm Free frontal opening L-R: 2.060 mm Table surface area : 2.000 x 520 mm Slide area: 2.040 x 520 mm Working speed: 4 -20 mm / sec Rapid travel: 135 mm / sec Return speed: 120 mm / sec Weight of machine approx.: 14 ton Height over floor approx.: 4.810 mm Oil volume: 700 l

Pressure total: 80 - 800 ton Ram stroke: 1600 mm Free frontal opening L-R: 2850 mm Free lateral opening F-B: 1000 mm Daylight: 1900 mm Table surface area : 2800 x 2000 mm Slide area: 2800 x 2000 mm Die cushion capacity in table: 32 - 320 ton Die cushion stroke: 400 mm Die cushion pad area: 2500 x 1700 mm Approach speed: 400 mm / sec Working speed: 5 -42,7 mm / sec Return speed: 420 mm / sec Required power: 246 kW Height over floor approx.: 7785 mm Weight of machine approx.: 100 ton No. of moving bolster: 1 pcs.

Pressure total: 1400 ton Stroke: 950 mm Daylight: 2000 mm Table surface area : 3600 x 2500 mm Slide area: 3600 x 2500 mm Die cushion capacity in table: 400 ton Die cushion stroke: 500 mm Die cushion pad area: 3060 x 1860 mm Approach speed: 400 mm / sec Working speed: 40 / 80 mm / sec Return speed: 400 mm / sec Oil volume: 5000 l Required power: 450 kW Weight of machine approx.: 240 ton

Pressure total: 500 ton Stroke: 1100 mm Daylight: 1500 mm Table surface area : 2000 x 1250 mm Slide area: 2000 x 1250 mm Die cushion capacity in table: 160 ton Die cushion stroke: 300 mm Approach speed: 650 mm / sec Required power: 55 kW Weight of machine approx.: 50 ton
