cross used for sale

RA1156 Flow rack for storage according to the FIFO principle (First In - First Out) for short ways and fast access times when picking! Basic field with 5 levels consisting of: 2 x upright frame 5 x throughfeed frame kink design 12 x roller strips per level (4 per channel) 2 x stiffening cross beams 20 x adjustment hooks (suspension angle) width: 2040mm depth: 1450mm height: 2500mm Maximum shelf load: 420kg Maximum field load: 1800kg Cultivation field with 5 levels consisting of: 1 x stand frame 5 x throughfeed frame kink design 12 x roller strips per level (4 per channel) 2 x stiffening cross beams 20 x adjustment hooks (suspension angle) Price per cultivation field 650,00€ plus VAT Prices net plus VAT, ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Width in mm: 2040 Depth in mm: 1450 Height in mm: 2500 Maximum compartment load: 420 kg Maximum field load: 1 ...

Esterer HKS/U under-table cross-cut saw for cutting, cutting or sawing boards and other wood with large Cross-section., engine: 4 kW, cutting width: max. approx. 600 mm, cutting height: max. approx. 150 mm, saw blade ø: about 500 mm

Complete sawmill plant (capacity approx. 80 000 m²) consists of: Round timber feeder 5 strands with separation Debarking Nicholson A2 approx. 90cm Reducer TC Remote-controlled EWD clamping carriage with cab, Swing frame gate EWD GDZ-GE 600, Splitting wedge, Conveyor systems with L/R discharge, Cross conveyor for resawing saw EWD FR 12, EWD Twin Shaft Recut Circular Saw FR12 Heavy sawmill machine with fixed hook-up. Both saw shafts are hydraulically height-adjustable. Technical data FR12 Cutting height max. 300 mm Clamping length max. 500 mm Passage width max. 900 mm Feed rate max. 50 m/min Weight approx. 15 tons Cross conveyor to sergeant, EWD OPTIMES BKO TL2 (3 movable flanges, new OPTIDRIVE BKO control) Price separator, Assortment of boards, Hacker RUDNICK&ENNERS RE-TH 250/700 75 kW with disposal

Contact insert, 35 pcs PHOENIX CONTACT VC-TFS 2 article family: VARIOCON 1852846 rated voltage: 400 V rated current: 20 A number of poles: 2 wire cross-section ( min. ): 0,25 mm², core cross-section ( max. ): 4 mm² Material ( housing ): Polyamide, colour: light grey, Connection type: Screw connection Contact type: Socket - Connector Other quantities on request ! New ! Dimensions ( one contact insert ): 31 x 15 x 27 mm Dimensions (packaging): 110 x 90 x 40 mm

pressure: 30.0 t punching cross-cut in cmm: 30 in 9.0 mm stroke: 0 - 28.0 mm column arm: 610 mm work height max.: 1010 mm no. of strokes: ca. 35 Hub/min oil volume: 35.0 l punching cross-cut in cmm: 270 mm² total power requirement: 4.0 kW weight of the machine ca.: 1200 kg. range L-W-H: 1400 x 700 x 1600 mm good condition () with a lot of application tools (stamps/dies) Furnishing: - electro-hydraulic hole punch, with large throat - Material/sheet metal scrapers including scraper plates - Large material support table, with adjustable depth stops - continuous stroke adjustment - freely movable foot switch including protective cover - Forklift pockets for easy transport - side storage area - lots of accessories + tools - including tool cabinet - Matrix base (for special size matrices) - Stamp holders (for special size stamps) - original user manuel Machine link: https://mhp.logotech.de ...

ID3011 Presto Presses CC40V 4.2 t Channel baling press, transportable in a hook lift container, pressing force 400 kN, channel cross-section 750×1100 mm, 15 KW drive power, with mobile extraction system Höcker Polytechnik Vacumobil V 180 Channel baler, transportable in a hook lift container, pressing force 400 kN, channel cross-section 750×1100 mm, 15 KW drive power, with mobile extraction system Höcker Polytechnik Vacumobil V 180

cross-section width:: Schläuche max. 11 mm cross-section heigth:: 11 mm feed:: 0,5 - 100.000 mm Condition: used, very good condition Specification: universal cutting machine with roller drive for hoses - small cutting machine for hoses - feed unit: roller drive - microcontroller control: 80537 - cutting unit: pneumatic - Type of cut: Blade cut - Industrial blade: for PVC hoses - Max. hose diameter: 11 mm - Maintenance unit: yes - Max. feed speed: 1 - 50 m/min - Cutting capacity max.: 450 cuts/min depending on the cutting length - Cutting force approx.: 500 N at 6 bar - Cutting length: 0.5 - 100,000 mm - Resolution/step change: 0.5 mm - Operating voltage: 230V, 50-60 Hz - Compressed air: 5 - 6 bar - Air consumption per stroke approx.: 0.2 l/stroke at 6 bar - Paint finish: RAL 7035 light grey - No docum ...

Dimensions:, Filling box:, Width: 1000mm, Height: 1000mm, Length: 2400 mm, Average filling length: 1950 mm, Press chamber, Width: 1000mm, Height: 1000mm, Length: 2700 mm, Cylinder forces, Filling pressure cylinder: 980 KN, Intermediate pressure cylinder: 1950 KN, Final pressure cylinder: 1950 KN, Hydraulic drive: 2 x 90 KW, Main drive motors: 2 pieces, Power by motor: 90 KW, Production data, Package cross-section Width: 300 mm, Height: 300mm, Number of parcels per hour approx: 100 to 140, Operating voltage: 400V/50Hz, Hydraulic tank: 3,600 l, Construction year: 1994, Width: 1000 mm, Average filling length: 1950 mm, Length: 2700 mm, Filling pressure cylinder: 980 KN, Length: 2700 mm, Intermediate pressure cylinder: 1950 KN, Final pressure cylinder: 1950 KN, Hydraulic drive: 2 x 90 KW, Main drive motors: 2 pieces, Power by motor: 90 KW, Package cross-section Width: 300 mm, Height: 300 mm,  ...

Klebebinder mit Vorsatzanleger / Perfect Binder Kolbus Ratiobinder KM 470 with endsheet feeder Baujahr 1988/1995 Kolbus Ratiobinder KM470 23 Zagne Format / Size min 125 x 100 x 3mm / max 460 x 310 x 60mm Buchblockdicke min. 3mm - max. 60mm Aussattung / Consist of: Zusammentragmschine / Gatherer ZU 803 32 Stations Links- und Rechtslauf / Left and right side Criss-Cross Auslage / Criss-Cross delivery Anleger Vor- & Nachsatz fuer Hardcoverproduktion / Feeder for endsheet hard cover production Handanleger / Hand fed station Ratiobinder KM 470 mit 25 Zangen / Ratiobinder KM 470 with 25 Clamps PUR Rueckenleimwerk / PUR spine gluing unit Hotmelt spine gluing unit PUR-, Hotmelt- und Dispersionsklebebindung / PUR, Hotmelt and dispersion glue binding Seitenbeleimung Heissleim / Hotmelt side gluing unit Faelzelstation / Back Lining station Buchblock- und Ganzpresse FM 405 fuer fadengeheftete Bu ...

FRORIEP CNC Vertical Boring Mill Double Column REBUILT & CNC RETROFIT IN 1999 FEATURES: SIEMENS 840D CNC CONTROL 2-VERTICAL RAM HEADS CAPACITY: TABLE DIAMETER: 10,000mm TURNING DIAMETER WITH VERTICAL RAMS: 15,000mm MAXIMUM TURNING HEIGHT: 5000mm RAM VERTICAL TRAVEL: 2000mm RAM SWIVEL +/- 30/15 DEG MAXIMUM CUTTING FORCE RIGHT RAIL HD: 25t TABLE LOAD CAPACITY: 200t TABLE SPEED RANGES, INF VARIABLE: 4 TABLE SPEEDS: 0.13 TO 13 RPM CROSS RAIL ELEVATION MOTOR: 40.23 HP NUMBER OF FEEDS, VERTICAL & HORIZ: 30 CROSS RAIL ADJUSTMENT MOTOR 86 HP RAPID TRAVERSE MOTORS: 15.5 HP MAIN MOTOR: 250 HP EQUIPPED WITH: SIEMENS 840D CNC CONTROL NEW 1999 DUAL PENDANT OPERATED CONTROLS 2-VERTICAL CNC CONTROLLED RAMS 10,000mm DIAMETER T-SLOTTED TABLE 4-HEAVY DUTY FACE PLATE TYPE JAWS HYDROSTATIC BEARING SYSTEM FOR TABLE DUAL OPERATORS PLATFORMS DUAL JORGANSEN CHIP CONV ...

Wood Her UNO 1304 FÜ + PU Edge thickness 0.4 - 6 mm Control panel with selector switches for adjusting the units Pre-milling unit for attachment in front of the gluing part Fully automatic edge magazine for rolls and strips Glue Application Station: Cartridges + PU Gluing Workpiece height 6-55 mm Printing unit pneumatic Cross-cut unit 1918 for rolls and strips up to 8 mm edge thickness with pneumatic changeover of 0-10° incline of the cross-cut saws Milling unit flush milling 6 mm, radius milling - bevel milling - 15° Scraper unit for chamfers and radii with 2 scraper blade carriers pneumatic indentation and disengagement Surface Scraper Unit - Finish Machine is WORKSHOP OVERHAULED in TOP CONDITION from a craftsman's workshop

table diameter: 4520 mm table load: 12000 t swivelling range: 110 Grad total power requirement: 44 kW weight of the machine ca.: / t required space: / m Type: ROMAT 350 / LVEB-120000N-4m / VVEs-D-18000N-5m-S / QVEB-2m travelling beam / CR-200000N / Hydraulic scissor lift table In the scope of delivery: Item Designation 1 Welding power source GLC 603 Quinto SD 2 Wire drum 3 Service door 2.1 4 Robot control cabinet 5 Service door 1.2 6 Scissor lift table (shown in parking position) 7 Cross-travelling unit QVEB 8 ROMAT 350 robot 9 Service door 1.1 10 Safety fence 11 Platform 12 Positioner 13 Sliding door 1 14 Linear traversing unit LVEB 15 Vertical traversing unit VVEs 16 Sliding door 2 ---------------------------------------------------------------------- ---- Technical data - Mechanical dimensions (without control unit and superstructures): approx.6440(57 7 0)x4520(2700)x5460(3320) LxWxH  ...

BERNARDO BSG 4080 TDC surface grinding machine was built in Austria in 2018. Designed for fully professional production applications, the machine machines workpieces placed on a magnetic plate or directly on the work table with the utmost precision and accuracy. The hydraulically driven work table with a large magnetic platen moves on hardened and ground guideways, which have been additionally coated with a special Turcite-B coating to increase abrasion resistance. The hydraulic drive, in the form of a separate hydraulic unit with heat exchanger, prevents vibration and overheating, and also ensures safe table feed even under heavy loads. Radial and axial forces are evenly distributed on special bearings without play in the grinding wheel spindle. The BERNARDO magnetic grinding machine weighs 3400 kg. Technical specifications of the magnetic surface grinding machine BERNARDO BSG 4080 T ...

72”x 0.5” x 60,000Lb Braner Turret Type Loop Slitting Liney Braner Turret Type Loop Slitting Line is used for coil metal cross cutting with maximum width 72”, maximum 0,5” metal thcikness and 60,000Lb coil capacity Make: Braner Year New: 1996 Material Thickness: .060″ – .500″ Material Width: 12″ – 72″ Coil Weight: 60,000Lb Line Speed: 120 – 250 feet per minute Coil ID: 20″ – 24″ Coil OD: 75″ Slitting Cap: .500″ / 4 cuts – .125″ / 40 cuts Entry L-Type Coil Car Hydraulic Lift & Traverse Self Contained Hydraulics Control Panel Mandrel Uncoiler Powered Hold – Down Roll Outboard Bearing Support Hydraulic Feed-Up Drive Water Cooled Brake Hydraulic Peeling Table Driven Entry Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Two Turret Type Slitting Heads Arbor Diameter: 12″ Powered Arbor Adjustment Powered Head Rotation Motor: 100HP DC Driv ...

T MAST ROTATING TABLE Table surface 3200 X 740 Table longitudinal stroke 3000 mm Ram cross section 1000 mm Head vertical 1000 mm Column cross section 1200 mm Main spindle ISO 50 power 22 kw N 2 speed ranges from 250 to 958 rpm and from 958 at 2500 rpm Total machine weight 18500 kg

The machine is equipped with a Bytrans Cross automatic loading and unloading system. Operating hours: Cutting approx. 16,000h The laser source, the cutting head and the cooling unit have been completely renewed, and have been equipped with the current technology of 2021! These elements have been in operation for approx. 8,000 hours. The machine is currently working in two shifts. BASE MACHINE The basic machine is the basis for the modular BySprint system and consists of the following parts: - a laser source with corresponding laser control, as well as a closed cooling system. - a closed machine frame with controlled sector extraction system - a shuttle table system with exchangeable, pluggable and serrated steel grids - a CNC cabinet with ByVision CNC control system - 2KW fibre laser source YLS, laser power possibly extendable - Small parts and cutting residues that fal ...

number of spindles: 6 spindle passage: 27 mm turning length: 59 mm hexagon material: 24 mm square material: 18 mm cross slide travel: 36 mm longitudinal slide travel: 85 mm spindle turning speed range: 366 - 5020 U/min max. torque: 95 Nm control: INDEX total power requirement: 20 kW - 6 cross slides - 6 longitudinal slides - polygon device - thread cutting device - hydr. tapping device - workpiece removal belt - bar loading magazine PIETRO CUCCHI, model AN-BN Accessories: various tool holders, various collets, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Used Filling Monoblock Galdi Up to 6000 BPH Introduction to Advanced Bottling Technology Initially the Galdi RG260A a high performance filling monoblock from 2010 stands as a cornerstone of modern bottling operations Having been recently overhauled it showcases unmatched efficiency and reliability Consequently achieving speeds of up to 6 000 bottles per hour this machine sets a benchmark in the industry Specifically it is engineered for Pure Pak Daimond Standard Curve B style T Bottom containers Moreover it utilizes 36mm Elocap caps demonstrating its versatility and adaptability to various packaging needs Ensuring Uncompromised Product Safety of the Filling monoblock Galdi Importantly one of the critical aspects of the Galdi RG260A is its disinfection killing rate With up to LOG5 it guarantees the highest levels of product safety This capability is especially crucial in today s market wh ...

Edge banding Holz-Her Type: 1417 Sprint Year of construction: 1999 Banding thickness max. 8 mm Workpiece thickness = banding height 6 – 45 mm Workpiece width min. 60 mm Workpiece length min. 180 mm Workpiece protrusion via the transport chain on the assembly side 30 mm Feed speed 11 m/min. Feed motor 1.5 kW Swivel control panel Machinery: Pre-milling unit 1961 Edge feeding 1901 - fully automatic edge feeding of roll goods and stiff goods Glue application station 1906 or 1910 cartridge system Printed in 1913 Cross-cut unit 1918 – 2 cross-cut saw motors guided diagonally on round bars Milling unit 1942 – flush/radius/chamfering station Milling unit 1942 M – flush/radius/chamfering station Scraper unit 1929 - for radii up to 3 mm Form milling unit 1983 – 1 motor 0.6 kW 18000 rpm, copy corners up to 3 mm edge thickness Surface scraper unit 1964 – for  ...

Webster & Bennett 36” Fixed Rail vertical borer Table Diameter 36 ” with a set of standard jaws Max swing 46 ” gripped on the inside Max height under cross rail 23” Travel of ram 22” Cross travel 23” from centre and will travel 2” past centre Table speeds 185 to 400 RPM ( 12 ) Feeds 0.005” to 0.250” per rev ( 12 ) 25 HP main motor Volt 440

Control: Fanuc 0-iTD + Manual Guide I Specification: Swing over bed: 805 mm Swing over support: 720 mm Swing over cross slide: 515 mm Center height: 400 mm Turning length: 3000 mm Spindle motor power: 17 kW Spindle speed: 0-450, 450-1700 U / min (stepless) axes Z, X: 0-7000 mm / min Rapid advance along the Z axis, X: 10 m / min Spindle taper: MT5 Spindle bore: 105MM Tool number: 12 pieces Cooling: External Hydraulic tailstock Inner cone tailstock: Morse 6 Machine weight about 6.46 t 5530 x 1800 x 2230 mm this extra information is standard for this model. Please always double-check the details during a visit The Metosa Pinachio ST 400 CNC lathe is a precision-engineered machine designed for high-performance metal turning operations. Equipped with a Fanuc 0-iTD control system along with Manual Guide I, this lathe offers intuitive operation and advanced programmi ...

x-travel: 850 mm y-travel: 630 mm z-travel: 550 mm table surface area: 1200 x 550 mm spindle taper: SK 40 spindle turning speed range: 20 - 4200 U/min spindle drive: 11,5 kW quill stroke: 95 mm feeds longditudinal/cross/vertical: 1 - 10.000 mm/min rapid traverse longitudinal and cross: 10 m/min rapid traverse vertical: 10 m/min control: HEIDENHAIN, TNC 426 total power requirement: 21 kW weight of the machine ca.: 6 t dimensions of machine L x W x H: 4,95 x 2,30 x 2,30 m Accessories: NC-dividing unit (= 4th axis) with tailstock, make HOFMANN, model RWNC-160, vertical head with hydr. tool clamping and quill retraction, solid table, electron. handwheel, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: FANUC Number of axles: 7 Complete with IEMCA GENIUS 118 bar loader Main spindle: - Max. diameter bar: 12 (15) mm - Maximum speed rpm: 12,000 - Driving performance (S2: 30 min/ S1) kW 3.7 / 2.2 Spindle counter: - Maximum turning diameter: 12 (15) mm - Maximum speed rpm: 12,000 - Driving performance (S2: 30 min/ S1) kW 3.7 / 2.2 Aces: - Maximum rapid translation of the axes m / min 40 - Maximum acceleration of the axes m / s2 10 - Translation path X1 (linear) / Y1/ Z1 mm 30/ 195/ 120 - Translation path X2 / Y2 / Z2 mm 180/-/ 180 Tool holder trolley 1: - Tool holder system: linear - Number of fixed/driven tools: 5 / 4 - Cross section of the joint for fixed tools: 10 x10 mm - Drive power for driven tools (S3 40% / S1): kW 1.1 / 0.55 Tool holder sliding carriage 2: - Tool holder system: linear - Number of fixed/driven tools: 8/ 5 - Cross se ...

Interplast GRAMEGNA brand that for over half a century has been operating on the heat-shrinking machinery market and is well known for the high quality and reliability of its machines. We sell our R-700 type shrink wrapping packaging machine. The equipment is in excellent condition. The machine has only been stored since the end of 2004. In 2004, we stopped producing soft drinks. We did not sell the machine because we planned to restart the activity. There are electrical drawings for it. Production capacity: nominal 20-25 packages actual 21-23 packets/min For 2 liter bottles, from the 4×2 format, according to a preliminary estimate, approx. 21 packages/minute. The machine consists of the following main units: 1 intro conveyor belt with bottle sorter for arranging bottles arriving in one row into several rows for bottles with round and square cross-sections 1 x Champion 4 HS- ...

CMT Ursus/Emco Ø 500 x 1500 mm CNC Swing over bed: 500 mm Swing over cross-slide: 265 mm Distance centre tot centre: 1500 mm Max longitudinal travel Z-axis: 1500 mm Max cross travel X-axis: 240 mm Dia of spindle bore: 58 mm Power on the spindle: 7,5 kW Number of speeds: 15 > 1500 rpm Command: CMT Weight: 2 ton

Number of spindles 6 Spindle passage 27 mm Turning length 59 mm Hex material 24 mm Square material 18 mm Cross slide travel 36 mm Longitudinal slide path 85 mm Spindle speeds 366 - 5020 rpm Torque 95 Nm Control INDEX Total power requirement 20 kW Machine weight approx. 5.5 t - 6 cross slides - 6 longitudinal slides - Polygonal device - Thread cutting device - hydraulic tapping device - Workpiece removal belt - Bar loading magazine make PIETRO CUCCHI, type AN-BN Accesories various tool holders, various collets, chip conveyors, coolant device

3 MONTHS WARRANTY Offer consists of: Horizon AFC-746 AKT 6-pocket folding machine - Folding machine AFC-746 AKT - Pallet feeder PFU-74 - Parallel breaking rollers condition: 70% - Cross-fold rollers I condition: 50% - Cross-fold rollers II condition: 0% - Technology: Touch & Work - Fold roller adjustment: automatic - Memory fold types: 20 standard fold types pre-programmed - Job memory: 200 memory locations for repeat jobs - Number of pockets / swords: 6 pockets 1 sword + 1 pocket 1 sword - Operation swords: fully automatic - Format: max. 738x1,100 mm; min.210x297 mm - Paper weight: 40-250g/sqm - Output: max. 40,000 cycles/h - Pile height: max. 1.200mm - Pile weight: max. 1000kg - Power: 400V / 50Hz - 3,4kW - Dimensions: 4.320x1.700x1.690mm - Weight: 1.920kg On request we can organise the following for you: Packing, loading ...

Round timber yard Springer (noisy. Layout) Consisting of log feed 4 strands Separation Depositor Bruks Reducer Crane Blochzug Surveying 3D Speaker Metal detector Mesutronic Debarking Nicholson A5 /27 inch AIRSEAL ! (Rotor new!) Cross conveyors 2 cross-cut saws 66 sorting boxes each 2 sorting lines of 33 boxes each

CNC Vertical Milling Machine Make: JAFO Model: FYN 50 NB X-axis: 800 mm Y-axis: 500 mm Z-axis: 500 mm Year of construction: 1988 Controls: Heidenhain Operating voltage 380 V Control voltage: 24 V Total power consumption: 10 KW Weight 4,000 kg The track-controlled JAFO - FYN 50 NB NC vertical milling machine is designed for milling work on parts weighing up to 700 kg, including the clamping device. Consoles with table are equipped with a hydraulic counterweight. The well-sized guideways for the console on the stand chest and the guideways of the table are hardened. All counter guides are covered with "TURCITE" plastic and always remain in contact with the corresponding guides along their entire length. (no overflow). The vertical milling spindle, which can be swivelled in one plane, is attached to the transversely adjustable crossbeam. The milling spindle is driven by a t ...

Aluminum cross-cut saw, aluminum circular saw, aluminum semi-automatic circular saw, cross-cut saw, aluminum metal circular saw, light metal circular saw, metal cutting machine -Manufacturer: KASTO, semi-automatic under-table miter saw machine with roller conveyor -Type: KASTOalu U 14 -Saw blade: Ø 400 mm, 2,800 rpm -Saw feed: Hydropneumatic, infinitely adjustable saw feed with rapid return -Swivel range: 180° infinitely adjustable miter device -Cutting area 90°: 200x80 mm / 125x125 mm / 140 mm -Cutting area 45°: 140x80 mm / 110x110 mm / 130 mm -Coolant device: minimum quantity lubrication system -Drive: 1.8 kW -Clamping device: Two vertical and two horizontal clamping elements -Roller conveyor: 3000/520/H950 mm / 2000/470/H950 mm -Dimension saw: 700/1100/H1370 mm -Total weight: 298 kg

A system for planing/splitting and optimizing wood for strips or other workpieces Consisting of: · Flat magazine Weinig EM 12 · Planer and splitting machine Weinig Unimat 23 SP · Cross conveyor belt · Optimization cross-cut saw Dimter OptiCut 150 with inlet and outlet, Technical specifications: tba

swing diameter: 1600 mm turning height: 1285 mm Control: Siemens 840 D turning speeds: 400 U/min x-travel: +- 950 mm z-travel: 1100 mm workpiece weight: 9000 kg power capacity: 80 kW Torque: 19900 Nm table diameter: 1400 mm weight of the machine ca.: 42 t dimensions of the machine ca.: 7600 x 5200 x 5400 mm Dörries 7, Machine number V-800294 Crossbeam: -Cross beam travel: 600 mm Ram: -Ram cross section: 250 x 250 mm (immersion diameter: 340 mm) -Ram travel 1100 mm Equipment/accessories: -Tool magazine -Own filter system -BRANKAMP monitoring -REXROTH hydraulic unit -Chip conveyor -Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Drilling and milling machine Skoda HCW2 Machine type: HCW 2-180 5/16m Year of construction: 2009 Manufacturer: Skoda Plzen, CZ Control: CNC840D-Powerline Country of manufacture: Czech Republic Freight basis: from storage location + VAT incl. Dismatling and loading Technical data Control Siemens 840 D Powerline Travel distances X-axis 15,000 mm cross-column Y-axis 5,000 mm headstock vertical Z-axis 1,300 mm support beam (RAM) - horizontal W-axis 1,000 mm quill stroke horizontal Machine table rotary table plate field: Length 3,500mm 3,780mm Width 3,000mm 8,000mm max. table load: 60 t Travel 2500mm (V-axis) Drilling/milling spindle Tool taper: ISO 50 Quill Ø 180 mm RAM cross section 450 x 450 mm Power 100KW max torque 11,000 Nm (up to 85 rpm) max. speed 2500 rpm Rapid traverses: X; Y axis: 15 m/min W; Z - axis: 10 m/min Attachment ...

•Compact design - edge thickness 0.4 - 6 mm •Control panel with selector switch for adjusting the units •Pre-milling unit for attachment in front of the gluing part •Fully automatic edge magazine for rolls and strips •Adhesive application station cartridges + PU gluing •Workpiece height 6-60 mm •Printing unit pneumatic •Cross-cut unit 1918 pneumatically for rolls and strips up to max. 6 mm edge thickness •with pneumatic changeover from 0-10° inclined of the cross-cut saws • Milling unit flush milling 6 mm, radius milling 3 mm, bevel milling - 15° •Scraper unit for chamfers and radii with 2 scraper blade carriers •pneumatic engagement and disengagement •Surface Scraper Unit - Finish •Machine WORKSHOP overhauled in TOP CONDITION from stock Lieboch

Holz Her Sprint 1321 FÜ + PU heavy-duty version - edge thickness 0.4 - 15 mm PLC Screen Control Edgecontrol Motorized, positioning-controlled bridge height adjustment Pre-milling unit for fastening upstream of the gluing station Fully automatic edge magazine for rolls and strips Glue application station cartridges + PU gluing Car. Glue height adjustment / tactile nozzle Printed plant 1913 pneum. Cross-cut unit for rolls and strips 1918 - 15 mm with pneumatic changeover of 0-10° incline of the cross-cut saws Multifunctional milling unit with mot. Adjustment: Flush milling - 15 mm, radii and bevel milling -15° Frommilling unit - corner rounds 1833 Scraper unit for chamfers and radii 1929 pneum. pneumatic indentation and disengagement Surface Scraper Unit - Finish pneum. Buffing unit for replastering and edge polishing with 2 textile discs HIGH-END spraying device Compl ...

Bread slicer, make WABAMA, Model ECONOMY Plus 450, year 2009, Cutting capacity: up to 200 cuts/min, cutting thickness: 4 - 26 mm,, for bread lengths up to max. 450 mm, cross-section: 200 x 150 mm (WxH), Sensor – technology for measuring the panes,, Product holder (multi-tooth gripper), dimensions: 1,130 x 740 x 1,200 mm, use: The machine is versatile and is usually used for the automatic cutting of all soft and hard breads such as: tea and toast breads, multigrain breads, hard-crust double baked breads as well as Christmas stollen and English fruit cake. A fresh bread - cut is usually already possible when warm. Due to the low-noise and vibration-free operation, the machine is ideal for installation in shop fittings., construction/ function: The WABÄMA bread slicer has an extremely stable and resilient construction completely in V2A Nirosta stainless steel. The machine is equipped wit ...

Description: Fabrication number: S4C141101 Operating voltage: 3 x 400 V Frequency: 50/60 Hz Rated current: 45 A Control system: SIEMENS SINUMERIK 840 D Rotation diameter over bed: 430 mm Rotation diameter over cross slide: 300 mm Max. turning diameter: 300 mm Max. part length: 480 mm Max. bar passage: 45 mm Center width (spindle nose to tailstock center point): 670 mm Distance main spindle to counter spindle: 720 mm Travel distance X: 160 mm Z travel: 510 mm Main spindle: Outer spindle diameter in the front bearing: 80 mm Main spindle clamping system: Wood clamping cylinder with tow bar with max. passage 45 mm Max. Chuck size: 160 mm diameter Speed range: 0 - 6300 rpm (infinitely variable) Counter spindle (spindle 2): Spindle connection: KK 4 Outer spindle diameter in the front bearing: 70 mm Travel distance Z2: 510 mm Travel speed: 30 m/min Holding force: 6000 N Counter spindle clamping ...

Description: Fabrication number: S4C132091 Operating voltage: 3 x 400 V Frequency: 50/60 Hz Rated current: 45 A Control system: SIEMENS SINUMERIK 840 D Rotation diameter over bed: 430 mm Rotation diameter over cross slide: 300 mm Max. turning diameter: 300 mm Max. Part length: 480 mm Max. Bar passage: 45 mm Center width (spindle nose to tailstock center point): 670 mm Distance main spindle to counter spindle: 720 mm Travel distance X: 160 mm Z travel: 510 mm Main spindle: Outer spindle diameter in the front bearing: 80 mm Main spindle clamping system: Wood clamping cylinder with tow bar with max. passage 45 mm Max. Chuck size: 160 mm diameter Speed range: 0 - 6300 rpm (infinitely variable) Counter spindle (spindle 2): Spindle connection: KK 4 Outer spindle diameter in the front bearing: 70 mm Travel distance Z2: 510 mm Travel speed: 30 m/min Holding force: 6000 N Counter spindle clamping ...

Description: Fabrication number: S4AC0301 Operating voltage: 3 x 400 V Frequency: 50/60 Hz Rated current: 45 A Control system: SIEMENS SINUMERIK 840 D Rotation diameter over bed: 430 mm Rotation diameter over cross slide: 300 mm Max. turning diameter: 300 mm Max. part length: 480 mm Max. bar passage: 45 mm Center width (spindle nose to tailstock center point): 670 mm Distance main spindle to counter spindle: 720 mm Travel distance X: 160 mm Z travel: 510 mm Main spindle: Outer spindle diameter in the front bearing: 80 mm Main spindle clamping system: Wood clamping cylinder with tow bar with max. passage 45 mm Max. chuck size: 160 mm diameter Speed range: 0 - 6300 rpm (infinitely variable) Counter spindle (spindle 2): Spindle connection: KK 4 Outer spindle diameter in the front bearing: 70 mm Travel distance Z2: 510 mm Travel speed: 30 m/min Holding force: 6000 N Counter spindle clamping  ...

Description: Cabinet with sliding door 4 pieces cross beams with stations for Toolholder VDI 40 content consist of 40 pieces toolholder VDI 40 of misc. manufacturers like mimatic, WNT and Zürn 2 pieces driven tool holder (1x straight and 1x angled) suitable e.g. for Okuma lathes 38 pieces static tool holder with misc. Interfaces like boring bar, drill chuck and square cross Transportdimensions: 1.200 x 800 x 2.100 mm, ca. 240 kg Approx. Onsite Dimension. (l x w x h): 1,000 x 500 x 1,950 mm, weight approx.: 220 kg

Description: Cabinet with sliding door 4 pieces cross beams with stations for Toolholder VDI 40 content consist of 40 pieces toolholder VDI 40 of misc. manufacturers like Eppinger, Zürn, Garant 2 pieces driven tool holder (1x straight and 1x angled) suitable e.g. for Okuma lathes 38 pieces static tool holder with misc. Interfaces like boring bar, drill chuck and square cross Transportdimensions: 1.200 x 800 x 2.100 mm, ca. 240 kg Approx. Onsite Dimension. (l x w x h): 1,000 x 500 x 1,950 mm, weight approx.: 220 kg

Description: Cabinet with sliding door 4 pieces cross beams with stations for Toolholder VDI 40 content consist of 40 pieces toolholder VDI 40 of misc. manufacturers like mimatic, Eppinger, Zürn, Holex 2 pieces driven tool holder (1x straight and 1x angled) suitable e.g. for Okuma lathes 38 pieces static tool holder with misc. Interfaces like boring bar, drill chuck and square cross v Transportdimensions: 1.200 x 800 x 2.100 mm, ca. 240 kg Approx. Onsite Dimension. (l x w x h): 1,000 x 500 x 1,950 mm, weight approx.: 220 kg

grinding length: 1000 mm grinding width: 600 mm workpiece height: 400 mm table surface area: 1360 x 590 mm table speed -stepless-: 2 - 26 m/min table load: max. 1000 kg longitudinal stroke: max. 1100 mm grinding spindle speed: 1400 U/min grinding wheel motor: 10 kW grinding wheel size: 400 x 100 x 127 mm cross feed: max. 2000 mm/min cross adjustment: min. 0,001 mm vertical feed grinding spindle max.: 300 mm/min. vertical adjustment: min. 0,001 mm total power requirement: kW weight of the machine ca.: 6,3 t dimensions of machine L x W x H: 3,90 x 2,58 x 2,70 m Accessories: magnetic plate 1000 x 600 mm, grinding wheel with flange, wheel dressing attachment, wet grinding attachment with magnetic chip separator and paper band filter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Workpiece and edge parameters Workpiece width min: For workpiece thickness 8-22 mm | 70 mm For workpiece thickness 23-40mm | 120 mm For workpiece thickness 41-60mm , 150 mm depending on the workpiece length Workpiece protrusion | 38 mm Workpiece thickness | 8 - 60 mm Max. edge height = workpiece height, + 6 mm Edge material roll / 0.4 - 3 mm Edge cross-section max. For PVC | 135 mm For veneer | 100 mm Max. roll diameter , 830 mm Edge material strip , 0.4 - 15 mm (or 12 mm) (When using the VKNR 4845 exchange trimming unit, the max. edge thickness is 12 mm!) Max. edge cross-section For strips ' 600 mm If no radius is specified, R=2 mm is retracted and delivered serial number: 0-261-20-5413, workpiece thickness: 8 - 60 mm, feed: 8 - 18 m/min, joint trimming unit: 2 x 2,2 kW, gluing unit: A12, snipping unit: 2 x 0,35 kW, rough trimming unit: 2 x 0,55 kW, ...

Description: Pillar jib crane Pillar height 3550mm, jib arm length 3120mm Lower edge of jib arm 2750mm, cross-section arm 120x65mm Cross-section pillar 120x120mm Untested / defects or incompleteness cannot be ruled out Approx. Onsite Dimension. (l x w x h): 3,550 x 200 x 200 mm, weight approx.: 100 kg

Description: Working area: X-axis (cross slide): 250 mm Z-axis (longitudinal slide): 350 mm Rotation diameter over cross slide: 204 mm Three-jaw chuck Outer diameter: 140 mm Turning diameter: 120 mm Working spindle: Spindle head: DIN55021 A5 Bar passage with hydraulic clamping: diameter 42 mm Feed drives: Feed force X-axis: 2600 N Z-axis: 3200 N Rapid traverse speed: 10 m/min Main drive, direct current Power: from 2350 rpm: 12.5 kW Speed range: 100 - 6000 rpm Tool carrier: Disk turret: 12 stations Turret: Manufacturer: SAUTER Type: 0.5.901.016 Turret can accommodate driven tools With bar loader Max. Bar length: approx. 1000 mm With spare parts machine Manufacturer: EBOSA Type: 143 (see pictures) With technical documentation as shown in the pictures Important note: Bar feeder is delivered without bar material. The bar material shown in the pictures is not included in the scope of delivery ...

Description: Machine number: 511516 Spindle diameter: Main spindle: 42 mm Counter spindle: 42 mm Cross slide 1 - X, Z, (top) Cross slide 2 - X, Z Control: C 200-4 (identical in construction: Siemens SINUMERIK 840 C) INDEX-WHU handling system - CNC programmable Pallet indexing system PST400 (system pallets 400 x 400 mm, see photos) 2 collet chucks - Hainbuch BZI 42 1 three-jaw chuck 1 chip hinge belt conveyor with 2 coolant pumps 8 bar and 18 bar Several pallets for the INDEX PST 400 pallet system Gripper jaws for handling system The scope of delivery includes 1 switch cabinet air conditioning unit Only run with oil Conditionally functional. The following repairs should be carried out: Counter spindle has misalignment. Guide rails and cylinder of the WHU in need of overhaul. Ball screw of the counter spindle was replaced in 2023. weight approx.: 6,500 kg, Approx. Onsit ...

Description: Center height 175 mm, center width 1000 mm, maximum longitudinal slide travel 1050 mm, longitudinal slide speed 0.0001 to 10000 mm per minute, maximum table inclination 8.5 degrees, maximum cross slide travel 275 mm, maximum cross slide speed 0,0001 to 10000 mm per minute, quill travel of tailstock 35 mm, maximum workpiece weight between centers 130 kg, speed range of workpiece spindle 30 to 750 rpm, including manual operation and existing documentation, machine number 011.0126.60.021 control: GE FANUC SERIES 16-GC, weight approx.: 6,000 kg, Approx. Onsite Dimension. (l x w x h): 4,400 x 2,300 x 2,600 mm

Description: clamping plate diameter: 8000 mm clamping plate diameter with extensions: 12500 mm max. workpiece weight: 200 tons clamping plate speed: 0.35 - 14 rpm smallest turning diameter: 5000 mm cross member without bases: 1040 mm transom with 3 pairs of bases: 5090 mm largest ,distance between the clamping plate and blase side bracket holder: 4200 mm vertical movement of the cross support: right: 3500 mm left: 2550 mm horizontal movement side carrier: 2000 mm vertical movement side carrier: 4000 mm area required: 20000 x 20000 x 12000 mm max. workpiece weight between centers: 200,000 kg, weight approx.: 550,000 kg, Approx. Onsite Dimension. (l x w x h): 20,000 x 12,500 x 11,750 mm

grinding diameter:1000 mm grinding length:6000 mm centre height:510 mm max. workpiece weight:1800 (zw. Spitzen) kg max. workpiece weight:7000 (m. Lünetten) kg grinding spindle speed:400-1200 1/min grinding wheel diameter:915 mm grinding wheel width:100 mm grinding wheel peripheral speeds::35 m/sec cross adjustment:autom. 0,001 mm cross adjustment:mit Handrad: 0,001/0,01/0,1 mm table travel:6200 mm table speed -stepless-:10~4500 mm/min Rotation speed of workhead :3~30 1/min tailstock quill stroke:150 mm taper in tailstock-quill:6 MK tailstock adjustment:über Pneumatik tailstock quill adjustment:manuell spindle drive:30 kW Weight approx.:26 t dimensions:17500x3700x1900 mm surface roughness: max. 0.3µm Ra cylindricity:0.002~0.005 mm/m roundness:0.002~0.005 mm CNC controller:Siemens 828D mit Schleifzyklen fully enclosed:Optional open steady:Optional live center:2 Stk./pc warranty: None pa ...
