121,949 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
BTO 236 spring coiling machine + AB1 decoiler cap wire diameter: 1 gt; 3 mm winding diameter: max 70 mm max spring length: 180 mm max length of leg: 80 mm speed: 80 m/min power: min 9 kW / max 13,4 kW length: 1500 mm width: 1100 mm height: 1500 mm weight: 1300 kg
used
BX 400 spring coiling machine + AB2 decoiler cap wire diameter: 0,8 gt; 4 mm winding diameter: max 70 mm speed: 180 m/min (max 90 pieces/min) power: 6 kW length: 1400 mm width: 1350 mm height: 1900 mm weight: 2200 kg nbsp; extension springs - compression springs - conical springs - biconicalsprings with winding on the right or on the left
used
BTO 215 spring coiling machine + AB1 decoiler cap wire diameter: 0,2 gt; 1,5 mm winding diameter: max 45 mm max spring length: 100 mm max length of leg: 60 mm speed: 80 m/min power: min 3 kW / max 5,2 kW length: 1300 mm width: 900 mm height: 1300 mm weight: 620 kg
used
Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) is perfect solution for longitudinal cutting of coil metal into strips. This line can work with very big coils up to 74,000 Lb weight and 0.25 inches maximum metal thickness. Line is strong enough to make cutting speed 200 – 600 fpm depends on metal thickness and width you work with Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) Manufacturer: PRO ECO Material: CRS, HRS, HPP & O Material Width: 12″ – 72″ Material Thickness: .060″ – .250″ Coil Weight: 74,000Lb Coil ID: 20″ – 30″ / 20″ – 24″ Coil OD: 72″ Line Speed: 200 – 600 fpm Direction: L-R Three (3) Coil Storage Ramp Coil Car Powered Lift & Traverse Double Cone Uncoiler Sliding Base Dual Water Cooled Brake Feed-Up Motor Powered ...
Qty. 1 Second-hand slitting line – still on foundation! Mfc.: SUNDWIG Built: 1990 Materials: Cold rolled steel coil, Hot rolled steel coil, galvanised steel coil Strip width: 400 – 1,700 mm Thickness: 0.4 – 3.0 mm Coil weight: 32,000 kgs Tensile strength: max. 600 N/mm² Final strip width after slitting: 50 – 1,600 mm Coil ID (uncoiler): 508 / 610 mm Coil OD (uncoiler): 550 – 2,100 mm Coil ID (recoiler): 508 / 610 mm Coil OD (recoiler): max. 2,100 mm Hydraulic pressure: 120 bar Feeding speed at straightener: 15 m/min. Feeding speed: 30 m/min. Operation speeds: 30-150 m/min & 30-300 m/min.
used
sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...
used
Press type: PME 315 T Drive system: Eccentric Type of used tools Progressive Nominal force: 3150 kN Rating above BDC mm Material flow L->R - Maximum SPM: 75 1/min Minimum SPM: 20 1/min Maximum shut height: 525 mm Minimal shut heigh:t 325 mm Slide adjustment: 130 mm Maximum slide stroke: 210 mm Minimum slide stroke: 40 mm Bolster specification Bolster dimension: 2220 x 1225 mm T-slots in bolster: T28 H8 DIN650 - Draw cushion N/A - Draw cushion stroke: N/A mm Draw cushion force: N/A kN Draw cushon dimension: N/A mm Maximum weight: kg Ram specification Ram dimension: 2220 x 1225 mm T-slots in ram: T28 H8 DIN650 - Max. upper die weight: 3600 kg Tool manipulation Tool is manipulated by forklift - Max. tool weight: 5500 kg Forks size/pitch: 150x60/940 mm Lower die clamp height: 50 mm Upper die clamp height: 50 mm Tool locating (centering) stůl/bolster ...
used
60″ x .187″ x 50,000Lb Stamco Loop Slitting Line Make: Stamco Material Width: 12″ – 60″ (Recoiler Mandrel is 56″) Material Thickness: .020″ – .187″ (.135″ Stainless) Coil ID: 20″ Coil OD: 26″ – 72″ Coil Weight: 50,000Lb Direction: Left to Right Entry 4-Arm Coil Turnstile Powered Rotation Entry L-Type Coil Floor Standing Design Powered Lift & Traverse Mandrel Uncoiler Powered Hold-Down Roll Hydraulic Expansion Sliding Base Water Cooled Brake Feed-Up Motor Hydraulic Peeling Table Driven Entry Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Air Clutch & Brake Two (2) Slitting Heads Arbor Diameter: 9″ Slitter Face Width: 56″ & 60″ Powered Arbor Adjustment Motor: 100HP DC Tooling with Tooling Rack One Scrap Winder Hydraulic Motor Powered Open / Closed Herr-Voss 6-Hi Strand Extensioner Number ...
used
Fagor cut-to-length high speed line 72'' x 0.135'' x 60,000Lb is machine for cut to length coil metal cutting into metal sheets of required sizes. This machine can be used by coil metal working companies to make preparatory works before main operation. Machine is equipped with feeding unit and acceptance table to make all the process maximum automatic. It allows to make high speed cutting about 200-250 meters per minute. Cutting speed depends on metal thickness you work with, kind of metal, maximum metal cutting width. This machine helps to make preparatory works maximum fast and automatic, saving your time and labor, reduce expenses costs. Machine is equipped with flying shear so help you to save factory space avoiding loop system installation. 72″ x .135″ x 60,000Lb Fagor CTL Line Make: Fagor Year: 2003 Material Width: 12″ – 72″ Material Thickness: .020″ – .13 ...
used
Paxson loop slitting line 72”x0.187”x 50,000Lb Make: Paxson Material Width: 12″ – 72″ (Uncoiler 60″) Material Width: .010″ – .187″ Coil Weight: 50,000Lb Coil ID: 20″ – 24″ Coil OD: 72″ Speed: 500 /1000 fpm Direction: Right to Left Material Strength: 40,000 yield / 50,000 psi shear Material: CR, HR, Galvanized Entry Transfer Cart Mechanical Traverse Entry Coil Car Floor Standing L-Type Design Hydraulic Lift & Traverse Self – Contained Hydraulics Mandrel Uncoiler Powered Hold-Down Roll Powered Expansion Sliding Base Air Cooled Brake Feed-Up Motor Hydraulic Peeling Table Driven Pinch Rolls Mechanical Entry Crop Shear Two (2) Slitting Heads Arbor Diameter: 7.5″ Adjustable Arbors Sliding Outboard Housing 175HP DC Motor Drive with Gear Box Two (2) Scrap Winders Mechanical Drive Powered Open / Close Exit Mechanical Crop Shear R ...
used
96” x .500” x 100,000# CAUFFIEL/BRADBURY FLYING SHEAR CUT TO LENGTH LINE MANUFACTURER – CAUFFIEL/BRADBURY YEAR – 2013 LINE DIRECTION –LEFT to RIGHT MATERIALS – CARBON STEEL THICKNESS – .075” MIN., .500” MAX. COIL WIDTH – 96” MAX. THRU LINE (84” MAX. THRU BRADBURY LEVELER) COIL WEIGHT – 100,000# MAX. COIL OUTSIDE DIAMETER – 39” MIN., 84” MAX. COIL INSIDE DIAMETER – 20” MIN., 32” MAX. SHEET WIDTH – 36” MIN., 96” MAX. (84” MAX. THRU BRADBURY LEVELER) SHEET LENGTH – 144” MAX., 492” MAX. w/ SPECIAL HANDLING PACK HEIGHT – 20” MAX. PACK WEIGHT – 20,000# FLATTENER TYPE – COMBINATION 3 ROLL & 7 ROLL FLATTENER LEVELER TYPE – 11 ROLL, 4 HIGH, HYDRAULIC LINE SPEED – 150 FPM MAX. UNCOILER DRIVE – HYDRAULIC FEED-UP FLATTENER DRIVE LEVELER DRIVE – 300 HP LINE COMPONENTS: COIL PUSHER TWO (2) ROLL COIL LIFT DUAL CONE ...
used
Cut-to-length line Bronx 2050x8mm x35t (A3781) Cut-to-length line Bronx 2050x8mm x35t (A3781) for coil metal cross cutting into sheets of required sizes with different length and width. Thickness Range: 2 – 8 mm Coil Capacity: 35t Coil OD: 2100mm Coil ID: 508mm , 610mm , 762mm Strip Width: 2000mm – 600mm Sheet Length: 8000mm – 600mm Pack Weight: 10 t Max Line Speed: 60 meters/min Cuts Per Minute: 35 Complete Line With 4 Coil Storage Storage Ramp Coil Loading Car Double Stub Mandrel Uncoiler Sliding Base Hydraulic Expansion Drag Brake Tension Control Peeler / Hold Down Roll 3 Roll Coil Breaker Feed Up Table 7 Roll Backed Up Leveler with Pinch Roll Breaker (9 Rolls Total) Entry Power Pinch Rolls 3 Flights Top & Bottom Back-Up Rolls Entry & Exit Pinch Rolls Marking Unit Measuring Roll Pinch Rolls Bronx Flying Shear AC Die Accelerator ...
used
72”x 0.5” x 60,000Lb Braner Turret Type Loop Slitting Liney Braner Turret Type Loop Slitting Line is used for coil metal cross cutting with maximum width 72”, maximum 0,5” metal thcikness and 60,000Lb coil capacity Make: Braner Year New: 1996 Material Thickness: .060″ – .500″ Material Width: 12″ – 72″ Coil Weight: 60,000Lb Line Speed: 120 – 250 feet per minute Coil ID: 20″ – 24″ Coil OD: 75″ Slitting Cap: .500″ / 4 cuts – .125″ / 40 cuts Entry L-Type Coil Car Hydraulic Lift & Traverse Self Contained Hydraulics Control Panel Mandrel Uncoiler Powered Hold – Down Roll Outboard Bearing Support Hydraulic Feed-Up Drive Water Cooled Brake Hydraulic Peeling Table Driven Entry Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Two Turret Type Slitting Heads Arbor Diameter: 12″ Powered Arbor Adjustment Powered Head Rotation Motor: 100HP DC Driv ...
used
Qty. 1 Second-hand skin pass mill Mfc.: Mannesmann Demag Sack Built: 1980’s Modernised in 1986 & 1993 Type: Duo Cold Rolling Mill – Non-Rev. Dia. 330 x 500 mm Material: Carbon steel, cold rolled and annealed Strip width: 80 - 470 mm Thickness entry: 4.0 mm Exit: 0.2 mm Decoiler Modernised in 1986 ID: 400 with segments 500 & 600 mm Spreading range: 370 – 420 mm Strip tension: 1300 – 65 daN Braking system: Generator Braking torque: max. 1300 daNm De-coiling speed: 2.5 m/sec. Coil cross section: 20 – 1880 mm² Coil weight per mm strip width max.: 10 kg Coil weight: 5.0 T Coil ID: 400 & 500 mm Coil OD: 600 – 1400 mm Roll dia.: 300 – 330 mm Roll length: 500 mm Roll force: 1850 – 2400 kN Min. roll force: 150 kN Hydraulic roll adjustment Adjustment stroke: 80 mm Adjustment speed: 1 – 3 mm/sec. Rolling speed: 2.5 m/sec. (150 m/min.) PLC system: ...
used
Unwinding reel / decoiler â?¢ Bandwidth / strip width max. 1,500 mm â?¢ Tape thickness / strip thickness (430 N/mm2) 0.5-2.0 mm â?¢ Coil outer diameter / coil outer - 1,300 mm â?¢ Coil inner diameter / coil inside - 470-520 mm â?¢ Coil weight / coil weight 10,000 kg â?¢ Side shift / side shift . . . . . . . . . . . . . . . . .
used
MRI Esaote S-scan with HF cabin Magnetic resonance imaging Magnetic resonance imaging Magnetic resonance imaging MSK-MRI System Esaote S-scan Musculoskeletal MRI Magnetic Resonance Imaging Manufacturer: Esaote SpA Type: S-scan Date of acquisition: 06/2012 with standard patient table, magn. Probe unit + box, accessory cabinet incl. soundproofing cabin Manufacturer: Langenberg GmbH Custom-made with closed sheets, thus stronger attenuation 90 -110 dB (otherwise approx. 70 dB) Dimensions: approx. 442 x 327 x 240 cm (LWH) with lighting and 4 connections for air conditioning, with honeycomb filters Properties: - Maintenance-free, open permanent magnet, field strength 0.25 Tesla - stand-alone system with low space requirements (recommended room size 20 m²) - low power consumption - less than 3 kW (normal 230 V connection is sufficient) - ergonomic, swivel patient table ...
used
Octagon Loop Slitting Line 60″ x .250″ x 60,000Lb Thickness Range: .015″ – .250″ Line Speed: 1000 FPM Entry Coil ID: 20″ – 24″ Exit Coil ID: 20″ Coil OD: 72″ Weight Capacity: 60,000Lb Shear Strength: 60,000 PSI Material: Steel, Aluminum, stainless Line Direction: Left to Right Complete Line With: Entry L-Type Coil Car Floor Standing / Self Contained Hydraulics Mandrel Uncoiler 4 Leaf Hydraulic Expansion Hydraulic Sliding Base Water Cooled Brake and Cooler Feed-Up Drive Air Clutch Powered Hold Down Roll North American Edge Control Peeler Table Pinch Rolls 2 Sets of Edge Guides Crop Shear 2 Injector Style Slitter Heads 8″ Diameter Arbors Sliding Outboard Support Hydraulic Slitter Head Clamping Hydraulic Arbor Adjustment 150 HP DC Slitter Drive Shim-less Tooling 2 Scrap Winders Oscillating Wind Hydraulic Eject Looping Pit C ...
used
Material width 250 â 1.510 mm Material thickness 0,6 - 3 mm Coil inner diameter 508 / 610 / 750 / 810 Coil max. Outer diameter 1.800 mm Coil max. weight 28 Tn Re 280 Mpa Rm 450 Mpa Length 280 â 6.000 mm Nr. of rolls 17 rolls Diameter of leveller rolls 69 mm Nr. of back up rolls 54 Diameter of back up rolls 130 mm Shear Flying shear Total installed power 150 Kw Line speed according to thickness Speed 40 m/min with thickness 0,6 mm Speed 40 m/min with thickness 3 mm includes: 1 Buffer coil car 2 Entry coil car 3 Double de-coiler with hold down arm and pneumatic brake 4 17 rolls leveller (diameter 69 mm) and backup rolls manually adjusted 5 Flying saw with scrap output car 6 Out conveyor 7 Stacker 8 Roller output tables 9 Electrical cabinets Revamping: Year 2008: Flying saw New stacker New electrics and automation New gearbox leveller Ye ...
used
Description: serial number: 11308/4 max. sheet thickness: 2 mm max. strip width: 250 mm max. coil diameter: 1200 mm Inner coil diameter: 450 - 550 mm max. coil mass: 1600 kg plate width: 250 mm, coil weight: 1,600 kg, coil internal diameter: 450 - 550 mm, coil external diameter: 1,200 mm, weight approx.: 920 kg, Approx. Onsite Dimension. (l x w x h): 1,800 x 2,100 x 1,900 mm
used
Description: serial number: 11307/7 max. sheet thickness: 2 mm max. strip width: 250 mm max. coil diameter: 1200 mm Inner coil diameter: 450 - 550 mm max. coil mass: 1600 kg plate width: 250 mm, coil weight: 1,600 kg, coil internal diameter: 450 - 550 mm, coil external diameter: 1,200 mm, weight approx.: 920 kg, Approx. Onsite Dimension. (l x w x h): 1,800 x 2,100 x 1,900 mm
used
Description: serial number: 11313/18 max. sheet thickness: 2 mm max. strip width: 250 mm max. coil diameter: 1200 mm Inner coil diameter: 450 - 550 mm max. coil mass: 1600 kg plate width: 250 mm, coil weight: 1,600 kg, coil internal diameter: 450 - 550 mm, coil external diameter: 1,200 mm, weight approx.: 920 kg, Approx. Onsite Dimension. (l x w x h): 1,700 x 1,300 x 1,700 mm
used
CONTROLS PLC SIEMENS FEEDSTOCK STEEL STRIP sheet width max.: 221 mm sheet width min.: 58 mm sheet thickness max.: 8 mm sheet thickness min.: 1 mm exterior coil diameter max.: 2100 mm exterior coil diameter min.: 1600 mm internal coil diameter max.: 610 mm internal coil diameter min.: 508 mm coil weight max.: 6000 kg PRODUCT (PROFILE, TUBE) external diameter min.: 22 mm external diameter max.: 65 mm length min.: 4500 mm lenght max.: 10000 mm LINE CHARACTERISTICS Forming Process: rollforming welding process: HF inductive sawing process: travelling speed max.: 100 m/min feedstock transport direction: left to right Line consists of: - Band Preparation VAI-SEUTHE BV ...
used
Qty. 1 Second-hand steel strip slitter Mfc.: Dai Hyun Built: 1994 Still in operation until end of July 2023 Material to Slit: Hot & cold rolled steel coil, Hot deep galvanized steel, Carbon steel Line Direction: Left to right Strip Width: 1400 mm Thickness: 0.8 - 6.0 mm Max. Coil weight: 24 MT Un-coiler ID with Liner: Ø 480 mm, Ø 600 mm Coil Dia.: Ø 1000 & Ø 2000 mm Re-coiler Inside Dia.: Ø 500 mm, Ø 760 mm Slitting Speed: 50-100 m/min Edging width: 3 mm to 10 mm Electric Power: Input voltage: 400 V, 50 Hz - 220 VAC, 50 Hz,3 Ph. ± l 0% for drive Control Voltage: 110 VAC, 50 Hz, 1 Ph. Slitting capacity Working speed and No. of cuts Min. slit width is 40 mm at thickness 1.0 – 2.5 mm. Strip thickness No. of cuts No. of strips Line speed mm m/min 1.0 - 1.9 16 15 70-90 2.0 - 2.9 14 13 70-80 3.0 – 4.0 12 11 60-70 4.1 – 5.0 7 6 60-70 ...
Qty. 1 Second-hand cold rolling mill Mfc.: MCC, ABB, IMS Type: 6-Hi Cold Rolling Mill Built: 2009 Stopped: 2017 Annual capacity: 220,000 Ton/Year Annual running time (Hour): 6480 Strip Width: 800~1250 mm Thickness Entry: 1.5~3.5 mm Exit: 0.2 – 1.2 mm De-Coiler OD: 1000~2000 mm De-Coil ID: 610 mm De-Coil Weight: Max. 25 T Coil OD: 1000~2000 mm Coil ID: 610 mm Coil Weight: Max. 25 T Mill Max Speed: 1300 m/min Threading Speed: 30 m/min Main Drive Controller (3300 VAC) Mfc.: ABB ACS6000 Variable Speed Variable Voltage Xray Gauge Mfc.: IMS Germany Automation Siemens PLC/Wincc
used
Strip thickness / strip thickness: 3 - 4 mm Coil weight max.: 10,000 kg Coil inner diameter/coil inner-dia.: 508 mm Coil outer diameter / coil outer-dia.: .700 mm Thorn width / mandrel width: 1,650 mm Low-return / pressure arm Separierarm / separating arm Hydr. Spread / hydr. Spreading Working dircetion: right/left; Right/left On board hydraulic pipes 24 VGS or 110 V, 50 Hz. On board hydraulic piping 24 V DC or 110 V, 50 Hz.
new
Technical data : Bandwidth / strip width 1,350 mm Strip thickness / strip thickness 0.4 - 4.0 mm Coil weight 10,000 kg Speed / speed 15 m/min. Coil inners / coil inside 508 mm Coil outer / coil outer- x 1,800 mm Distance ground & reel mpine center / Distance bottom and center of reel mandrel 1,200 mm Imposition ratio / reduction ratio 1:2 Low-return / press arm Deportation sign / push-off sign
used
Technical data : Bandwidth / strip width: 1,800 mm Strip thickness / strip thickness: 0.5 - 1.5/2.0 mm Coil weight: 30,000 kg Coil inner/ coil inner-a: 508 mm Coil outer / coil outer-a: 2,000 mm
used
48″ x .076″ x 20,000Lb Rowe – Voss Cut to length line Cut to length line 48″ x .076″ x 20,000Lb Rowe – Voss Make: Rowe – Voss Material Width: 12″ – 48″ Material Thickness: .017″ – .076″ Coil Weight: 20,000Lb Coil ID: 20″ Coil OD: 72″ Entry V-Type Coil Car Mandrel Uncoiler with Hold-Down Roll 9-Roll Coil Straightener with DC Motor Voss 4-Hi Precision Leveler with 19 Work Rolls 1.156″ Work Roll Diameter 40HP Moto High Speed Shear Drop Type Stacker with Driven Conveyors
used
60″ x .625″ x 100,000Lb McKay Slitting Line Make: McKay Material Thickness: .065″ – .625″ Maximum Material Width: 66″ Weight Capacity: 100,000Lb Coil ID: 24″ – 30″ Exit ID: 30″ Coil OD: 90″ Maximum Speed: 450 fpm Direction: L-R Pit Type Entry Coil Car Double Mandrel Uncoiler with Hold-Down Roll Hydraulic Peeler Driven Pinch Rolls Coil Flattener with 200HP Drive Slitting Head with 16″ Arbor Diameter 250HP Drive Knives & Tooling Two (2) Scrap Choppers Recoiler with Over-Arm Separator 250HP DC Drive Exit Pit Type Coil Car Electrics, Hydraulics Controls, Tooling
used
377mm x 12mm HF Pipe Mill Round Size: 165mm – 327mm, Square: 100mm – 300mm, Wall Thickness: 4mm – 12.7mm, Pipe Length: 6m – 12m, Coil ID: 610mm – 760mm, Coil OD: 1100mm – 2000mm, Coil Weight: 25ton, Strip Width: 400mm – 1200mm, Speed: 10 – 35 mpm. Entry Coil Car, Mandrel Uncoiler, Pinch Rolls, Coil Straightener, Horizontal Accumulator, Guiding. Rolls, Forming Mill with DC Drive, Welding Section, 800Kw High Frequency Welder, Water Cooling Section, Sizing Mill, Driven Turk-Heads, Flying Cut-Off, Run-Out Table. Electrics, Hydraulics, Controls
used
60″ x .080″ x 30,000Lb Iowa Precision / Herr Voss Multi Blanking Line Make: Iowa Precision Material Width: 12″ – 60″ Material Thickness: .010″ – .080″ Coil Weight: 30,000Lb Coil ID: 20″ Coil OD: 72″ Direction: Left to Right Entry Coil Car V-shape Floor Standing Design Powered Lift & Traverse Mandrel Uncoiler 3-Leaf Mandrel Design Powered Expansion Powered Hold – Down Roll Electrical Drive Panel Hydraulic Peeling Table Adjustable Edge Guides Driven Pinch Rolls Adjustable Coil Braking Rolls Herr – Voss 4-Hi Precision Leveler Work Roll Diameter: 1.50″ Work Roll Width: 74″ Number of Work Rolls: 19 Adjustable Work Rolls Up & Down Back Up Flights Variable Speed Motor and Gear Box Electrical Drive / Control Panel Slitter / Shear Make: Iowa Precision Model: Slear 3 Entry and Exit Pinch Rolls Slitting Head with Knives Hydraulic Flying ...
used
Multi Blanking Line Iowa Precision 72″ x 14g x 20,000Lb Make: Iowa – Precision Model: Slear – 2 Condition: Very Good Material Width: 12″ – 72″ Material Thickness: .008″ – .080″ Coil Weight: 20,000Lb Coil ID: 20″ Coil OD: 72″ Speed: 150 feet per minute Entry V-Type Coil Car Mandrel Uncoiler Powered Over-Arm Separator Entry Table Driven Pinch Rolls Adjustable Edge Guides Slitting Head with Tooling Blade Position Indicator 6-Roll Coil Straightener Adjustable Work Rolls Flying Shear Controls with Operator Panel Electrics, Hydraulics, Controls, No Stacker
used
Paxson Loop Slitting Line 72″ x 0.375″ x 50,000Lb (A3754) Make: Paxson Material Width: 12″ – 72″ Weight Capacity: 50,000Lb Thickness: .050″ – .375″ Coil ID: 20″ – 30″ Coil OD: 72″ Line Speed: 850 feet per minute Direction: Right to Left Entry L-Type Coil Car Floor Standing Design Hydraulic Lift & Traverse Self Contained Hydraulics Mandrel Uncoiler Powered Hold-Down Roll Hydraulic Expansion Water Cooled Brake Feed-Up Motor Sliding Base Hydraulic Peeling Table Driven Pinch Rolls Adjustable Edge Guides 4-Roll Coil Breaker Mechanical Entry Crop Shear Two (2) Slitting Heads Arbor Diameter: 9″ and 12″ Crane Removable Type Adjustable Arbors 150HP DC Motor Drive Multi Speed Gear Lots of Knives and Tooling Two Pro-Eco Scrap Winders Max Thickness: .500″ 25HP Motor for Each Unit Powered Open / Close Pit Cross Over Table Drag Bo ...
used
Chicago Loop Slitting Line 48″ x .040″ x 40,000Lb (A3756) 48″ x .040″ x 40,000Lb Chicago Loop Slitting Line Stock#: 19650C Make; Chicago Material Width: 12″ – 48″ Material Thickness: .005″ – .040″ Coil Weight: 40,000lb Coil ID: 20″ Coil OD: 72″ Speed: 1500 feet per minute Entry 4-Arm Turnstile Powered Rotation ID Protective Arms Entry L-Type Coil Car Hydraulic Lift & Traverse Self – Contained Hydraulics Mandrel Uncoiler Powered Hold-Down Roll Powered Expansion AC Feed-Up Motor Drive Water Cooled Brake Hydraulic Peeling Table Driven Pinch Rolls Adjustable Edge Guides Entry Mechanical Crop Shear Three (3) Slitting Heads Ejection Type Head Change Arbor Diameter: 4″ Lots of Knives & Tooling 50HP DC Motor Drive Scrap Baller AC Motor Drive Automatic Dumping Pit Cross Over Table Cascade Entry & Exit Rolls Rotary & Drag Board Tensi ...
used
406mm x 14mm API Pipe Mill Year New: 2006 Material Grade: X70 / X52 Pipe Diameter: 4.5" - 16" Wall Thickness: 4mm - 14mm Pipe Length: 6m - 14m Coil Width: 1350mm Coil OD: 2200mm Coil Weight: 25 ton Four (4) Entry Storage Area Floor Standing V-Type Coil Car Mandrel Uncoiler (5.5Kw Drive) Automatic Shear & End Welder Coil Straightener Horizontal Accumulator Forming Mill Six (6) Forming Stands Three (3) Side Clusters Four (4) Finn Passes 280Kw & 355Kw Forming Drives Welding Section Mechanical 4 - Roll Squeeze Box 800Kw EFD High Frequency Welder Two (2) Mid Frequency Annealing Heads Sizing Mill Four (4) Sizing Stands Two (2) Straightening Turk Heads 200Kw & 400Kw Sizing Drives Milling Flying Cut Off Rotary Double Saw Blades Diameter: 355mm Speed Accelerating System Digital Length Control Hydraulic Cut-Off Drive Mechanical Traverse Powered Run-Out ...
used
Key data: 2000 mm, 25 mm
Cut-to-length line CMM 2000 x 25mm x 30t is perfect solution for heavy gauge coil metal cutting. Line is equipped with necessary machines to proceed high quality metal cutting. To get more information please contact our sales department Maker: CMM Cut-to-length line CMM 2000 x 25mm x 30t Material Width: 500mm – 2000mm Material Thickness: 8mm – 25mm Coil Weight: 60,000Lb (30 ton) Coil ID: 400mm – 700mm Coil OD: 1800mm Direction: Left to Right Entry Staging Area Entry Pit Type Coil Car Double Mandrel Uncoiler Feed Up Motor: 11Kw x 2 Powered Hold Down Roll Hydraulic Peeling Table Rough Leveler Five (5) Work Rolls Work Rolls Diameter: 225mm Motorized Rolls Adjustment Motor: 160Kw x 2 Work Adjustment Motor: 11Kw Corrective Leveler Nine (9) Work Rolls Up & Down Back Up Flights Work Rolls Diameter: 225mm Motorized Rolls Adjustment Motor: 250Kw Rolls Ad ...
used
band width:1050 mm plate thickness:8 mm number of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mm FEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mm LEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/min ELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 Hz Technical description : Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of: - LAWECO COIL LOA ...
used
material width coil line:600 mm coil weight in kg:2 x 3000 kg coil internal diameter:460 - 630 mm coil external diameter:1500 mm material thickness coil line:0,5 - 3,0 mm Number of Straightening rolls:9 roll diameter:30 mm material cross-cut:1200 mm² weight:9,5 t Dimensions (WxDxH):4,3 x 2,6 x 2,6 m straightening machine:30.600/9 double decoiler:Kohler, 3000.2 ausiliary drive:hydraulic lag brake:pneumatic expansion:hydraulic snubber roll:hydraulic; motoric driven
used
CONTROLS PLC SIEMENS S5 PRESS DESIGN drive system: eccentric / crank frame design: H-frame, monoblock openings in uprights: yes number of suspensions: 2 number of slide actions: 1 table cushion: yes quick die change system: yes feedstock transport direction: left to right PRESS FORCES total force (nominal): 400 to nominal work capacity: 32 kNm PRESS TABLE table surface (left-right): 2600 mm table surface (front-back): 990 mm thickness of bolster plate: 200 mm height above floor level: 800 mm opening in bed (left-right): 2250 mm opening in bed (front-back): 280 mm SLIDE slide force: 400 to table surface (left-right): 2600 mm table surface (front-bac ...
used
• Bandwidth / strip width: 1,600 mm • Strip thickness / strip thickness: 0.4 - 2.0 mm • Coil inner / coil inner-a:390-420 mm • Coil outer / coil outer-a: 1,500 mm • Spreading/ spreading: hydraulic/hydraulic • Motor drive AC servo cooling • For invertrers • Speed: 15 m/min. • Attachment segments for 500 mm • Reel shift: 200 mm • Working method: from top and bottom • Hydraulic valves on board
used
4-side squaring and edge banding line Machine 1: Fixed side right, moving side left Rolling chain, feed 10 - 40 m/min Controlls NC 21 Panel thickness 8 - 60 mm Max. panel width 1500 mm Edges: coil 0,3 - 3 mm, strips 0,4 - 20 mm Entry fence for veneered panels Equipment: 1+1 Compact-twin hogger, 2 motors 6,6 kW 1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application 1+1 Free space for solid wood edges up to 2,54 m length 1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm) 1+1 Universal shaper 8,1 kW 1+1 Universal shaper 8,1 kW 1+1 Edge sander KS 10 1+1 Disc sander DS 40 1+1 Disc sander DS 40 Angular transfer to the right, TWR 24/30/12/S Panel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mm Machine 2 Machine II + infeed magazine TW ...
used
Technical data: Bandwidth / strip width min. 150mm Bandwidth / strip width max. 1,650 mm Strip thickness min. 0.4 mm Strip thickness max. 400 N/mm² 2.5 mm 300 N/mm² 3.0 mm Coil weight decoiler/ coil weight decoiler 12,000 kg Coil outer Ø / coil outer-Ø 1,600 mm
used
USED STAINLESS STEEL 316 15.000 LITRES TM IBÉRICA REACTOR WITH HALF-COIL JACKET AND AGITATION REF.: C9500 Stainless steel reactor with agitation and half-coil manufactured by TM IBÉRICA. Klopper top bottom with central flange for stirring, manhole and connections. Bottom and body half-coil. Klopper lower bottom with bottom discharge. On 4 brackets General characteristics: Manufactured by TM IBÉRICA Material Stainless steel 316 Year built 1996 BODY HALF-COIL Design pressure -1 / 1 bar -1/+3 bar Working Temperature 90 ºC 140 ºC Volumee 15.000 L 570 L Technical characteristics: Capacity 15.000 litros totales Bottom type Klopper Half Reed + Type of agitation Impeller + anchor Stirring motor 27 kW On 4 brackets Vessel outside diameter 2400 mm Vessel thickness 8 mm Vessel height 2800 mm Vessel height + funds 3850 mm (TOTAL: 7.000 mm) Thickne ...
Qty. 1 Second-hand coil slitting line Mfc.: GUIDA IMPIANTI, Italy Built: 2003 Max. strip width: 2,000 mm Thickness: 1.5 – 5.0 mm Material: Carbon steel, inox, stainless steel Speed: 80 ~ 160 m/min Coil Weight: 26 TON Coil ID: 508 / 760 mm Coil OD: 2100 mm Knife diameter: 370 / 450 mm Traction resistance: 650 N/m² Installed power: 360 kW
used
Cut to length line 72″ x .075″ x 40000Lb Rowe / Herr Voss Make: Rowe / Herr Voss Material Width: 12″ – 72” Material Thickness: .020″ – .075” Weight Capacity: 40,000Lb Coil ID: 20″ Coil OD: 72” Speed: 160 feet per minute Sheet Max Length :12′ Direction: R-L Entry Coil Car Floor Standing V-Type Design Powered Lift & Traverse Control Panel Mandrel Uncoiler 4-Leaf Mandrel Powered Hold-Down Roll Motorized Expansion Feed-Up Motor Sliding Base Coil Straightener Driven Pinch Rolls Six (6) Adjustable Work Rolls DC Motor Drive Herr–Voss 6-Hi Precision Leveler Model: RH/84-1.500-19-9-6Hi Work Roll Width: 84″ Work Roll Diameter :1.500″ Number of Work Rolls: 19 Number of Back Up Flights: 9 Powered Work Rolls Adjustment 75HP DC Motor Drive Electrical Controls Rotary Edge Trimmers Mechanical Scrap Chopper Scrap Conveyor Fee ...
used
60″ x .135″ x 20,000Lb Dahlstrom CTL Line Coil Width: 12″ – 60″ Material Thickness: .015″-.135″ Coil ID: 20″-24″ Speed: 180 fpm Direction: Left to Right Entry Floor Standing Coil Car Mandrel Uncoiler with Powered Expansion Motorized Hold-Down Roll Feed-Up Drive Hydraulic Peeler 9-Roll Coil Straightener with 4″ Work Rolls Driven Entry Pinch Rolls 40HP Motor Adjustable Hump Table Mechanical Shear Belt Conveyor with Positive Stop Device Air Gate Sheet Stacker, with Two Section of Gravity Rolls
used
60″ x .135″ x 20,000Lb Cincinnati – Forte Loop Slitting Line Material Width: 12″ – 60″ , Thickness: .010″ – .135″, Weight: 20,000Lb, Coil ID: 16″ – 24″, Coil OD: 72″, Speed: 600 fpm, Direction: Left to Right. Entry Turnstile, Entry L-Type Coil Car, Mandrel Uncoiler with Hold-Down Roll, Powered Peeler, Driven Pinch Rolls, PVC Applicator, Entry Shear, Two Slitting Heads, Injection Design, 5″ & 7″ Arbor Diameter, 75HP DC Motor, Two (2) Hydraulic Scrap Winders, Pit Cross Over Table, Drag Board & Rotary Tension Stand, Recoiler with Over-Arm Separator & Push-Off, 150HP DC Motor, Exit L-Type Coil Car & Turnstile. Electrics, Hydraulics, Controls, Tooling, Spare Parts
used
72″ x .187″ x 50000Lb Paxson Loop Slitting Line Make: Paxson Material Width: 12″ – 72″ (Uncoiler 60″) Material Width: .010″ – .187″ Coil Weight: 50,000Lb Coil ID: 20″ – 24″ Coil OD: 72″ Speed: 500 /1000 fpm Direction: Right to Left Material Strength: 40,000 yield / 50,000 psi shear Material: CR, HR, Galvanized Entry Transfer Cart Entry Coil Car Mandrel Uncoiler Powered Hold-Down Roll Powered Expansion Sliding Base Hydraulic Peeling Table Driven Pinch Rolls
used
Cut to length line Redman 2000mm x 13mm x 20 ton Make: Redman (UK) Material Width: 600mm – 2000mm Material Thickness: 6mm – 13mm Coil Weight: 20 ton Coil ID: 460mm – 760mm Coil OD: 1800mm Max Speed: 20 meters per minute Production Mode: Stop / Start Direction: R-L Entry V-Type Coil Car Double Mandrel Uncoiler Hold-Down Roll Hydraulic Peeling Table Driven Pinch Rolls Pinch Rolls Diameter: 330mm Corrective 4-Hi Leveler Nine (9) Working Rolls Work Rolls Diameter: 140mm Hydraulic Work Rolls Adjustment Up and Down Back Up Flights 120HP DC Motor Drive Mechanical Shear with Motor Belt Conveyor with Measuring Head Drop Type Stacker with End Conveyors Electrics, Hydraulics, Controls
used
Universal Slitting Line 72″ x .187″ x 20,000Lb Material Width: 12″ – 72″ Material Thickness: .015″ – .187″ Coil Weight: 20,000Lb Coil ID: 20″ Coil OD: 72″ Direction: Left to Right Entry Floor Standing Coil Car L-Type Design Hydraulic Lift & Traverse Mandrel Uncoiler Powered Hold-Down Roll Hydraulic Expansion Air Cooling Brake Sliding Base Hydraulic Peeling Table Slitting Head Arbor Diameter: 7″ Powered Arbor Adjustment 100HP DC Motor Knives & Tooling Recoiler Powered Push-Off Hydraulic Over-Arm Separator Hydraulic Expansion 100HP DC Motor Exit 2-Arm Turnstile Arm Width: 72″ Powered Rotation Complete Slitter with Electrics, Hydraulics, Controls, Tooling
