cnc turning lathes used for sale

Additional technical specifications: • swing diameter over bed: 320 mm • swing diameter over slide: 150 mm • face slide: 185 mm • turning spindle bore diameter: 50,8 mm • spindle diameter at front bearing: 85 mm • tailstock quill diameter: 70 mm • quill taper: MK 5

turning diameter over bed: 2300 mm turning diameter over slide rest: 1100 mm turning length: - mm faceplate: 2000 mm centre height: 1180 mm max. workpiece weight -without tailstock: 4 t spindle diameter in front bearing: - mm spindle turning speed range: 1- 99,9 U/min feed: 0,06 - 19,98 mm/U rapid traverse: 2,3 m/min total power requirement: 37 kW weight of the machine ca.: - t dimensions of the machine ca.: 5,2 x 5,8 x 2,63 m equipped with: - face plate - Bed support with 4-point Tool Holder - Coolant system - Feed/chip guard The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SCHAUBLIN 102N-80 ist eine Mechanikerdrehbank, ausgelegt für Präzisionsbearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Spitzenhöhe 102 mm; Spitzenweite 450 mm; Drehdurchmesser über Planschlitten 120 mm, über Bett 200 mm; Spindelbohrung 25 mm; Spannzangenaufnahme W25. Spindel 24 Stufen 45–3100 t/min; Steigung Leitspindel 4 mm, Durchmesser 40 mm; Reitstockkegel 2 CM; Vorschübe 8 Stufen, längs ab 0,020 mm/U; Anschluss 3x380 V 50 Hz; Spindelmotor 1,50 CV; Gewicht ~550 kg; Abmessungen L1375×B670×H1210 mm. Zubehör: Schnellwechselhalter TRIPAN, Bohrreibstock, 2 Schubladen. Erreicht enge Toleranzen; Einsatz in Automotive, Uhrenbau, Werkzeugbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

SCHAUBLIN 102-80 ist eine Werkzeugmacherdrehbank, ausgelegt für präzise Bearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Bearbeitungsfähigkeiten: Spitzenhöhe 102 mm, Spitzenweite 300 mm, Drehdurchmesser über Planschlitten 120 mm, über dem Bett 200 mm, Spindelbohrung 25 mm. Technische Hauptdaten: stufenloser Drehzahlbereich von 55 bis 3000 t/min, Reitstockaufnahme 2 CM, Anschluss 3x 380 V 50 Hz, Spindelmotor 1.5 CV, Maschinengewicht ca. 450 kg; Abmessungen L 1200 mm x B 600 mm x H 1400 mm. Zubehör: Bremse, Lampe, Schnellspanneinrichtung, Bohrreitstock, Bohrfutter, Schnellwechselstahlhalter. Erreicht enge Toleranzen; typischer Einsatz in Automotive, Uhrenindustrie, Werkzeugbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr

turning diameter over bed: 4000 mm turning diameter over slide rest: 3500 mm turning length: 30000 mm centre height: 2000 mm workpiece weight: 160 t bed width: - mm bed height over floor: - spindle turning speed range: 0,5 - 80 U/min main drive motor: - kW faceplate diameter: - mm Control: Siemens 840D total power requirement: - kVA weight of the machine ca.: 160 t 2006 modernized/Overhauled and equipped with: - 4-guides bedway - CNC Control Siemens 840D - Face Plate - Counter Stay The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The lathe has only ever been used for hobby purposes. The guideways are in very good condition. Hardened bed. Everything operates smoothly and is fully functional. The motor requires a 400-volt connection; consequently, it offers more power and runs more smoothly than a 230V version. For additional equipment, please see the photos.

Lathe STANKO 1M63/2800

Assorted CNC lathe tooling and tool holders, including Sandvik Coromant Capto holders, SECO C4-SDUCR-27050-11JET holder, Wodex PSC40 SNR 16 tool heads (Art.-Nr. 19 323 450), and additional indexable turning/boring holders. Auction-ID: A7-50717-241

Thickness: 16 x 16 mm number: 4 Stähle weight: 3 kg dimensions: 300m x 200 x 50 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Including VCMT11/16, DCMT11T3; mainly shaft 16 and 20 mm; total 53 pieces; in 2 cardboard boxes Auction-ID: A1-49785-153

Control: SIEMENS 840D Max.turning length: 450 mm Max swing diametr over bed/Slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l M

Control: Heidenhain Max.turning length: 450 mm Max swing diameter over bed/slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l Ma

Technical details Type: CNC turning center Control system: ZIT Sistema 500T Configuration: - Horizontal CNC lathe - Semi-enclosed machining area - Hydraulic power chuck - 6-station hydraulic indexing turret - CNC-controlled longitudinal and cross axes - Electrical control cabinet - Hydraulic unit - Coolant enclosure Application: - CNC turning - Facing - Boring - Thread cutting - Precision machining of rotational components Construction: - Heavy-duty cast-iron machine bed - Early-generation CNC control system - Automatic turret indexing Dimensions: - Length: Approx. 3200 mm - Width: Approx. 1800 mm - Height: Approx. 2000 mm Weight: Approx. 3800 kg Condition: Used Observed condition: - Machine appears mechanically complete - Hydraulic chuck and 6-station turret installed - CNC electronics and electrical cabinet present - Hydraulic unit installed - Heavy du ...

Technical data: Double column vertical turret lathe CNC control Siemens 802 D Weight 66 to 63 kw Dimensions 13,600 x 9,800 x 6,750 mm Faceplate diameter 3,500 mm Maximum workpiece height 2000 mm Max support adjustment 30 ° Maximum workpiece diameter 4,000 mm Maximum workpiece diameter with page support 3,750 mm Number of support 2 Max turning height 1,400 mm Maximum workpiece weight 25 to Max speed 30/min Min. speed 1/min

Inv. Num. : 6238 Type: HIT-250 MS Producer: HYUNDAI Created: 2004 Parameters: Control system: Siemens Sinumerik 840D turning length: 650 mm turning diameter: 390 mm Maximum turning diameter over bed: 590 mm Maximum spindle speed: 3600 1/min Maximum main spindle power: 15 kW Spindle passage: 80 mm Number of all tools: 12 pieces Number of driven tools in the turret head: 12 pieces Chuck diameter: 250 mm Axis X: 265 mm Axis Z: 660 mm Clamping diameter (counter spindle): 160 mm Spindle passage (counter spindle): 50 mm speed (counter spindle): 4500 1/min Length: 3692 mm Width: 1850 mm Height: 1850 mm Weight: 6450 kg Equipment: C-axis Technical documentation Conveyor Driven tools 2x 3-jaw chuck Cooling Complete coverage of the work area Oil mist separators Housing for clamping rotary knives and cases (8 pcs.)

Swiss type CNC Manurhin KMX TWIN 207 is a double-spindle automatic machine with automatic feeding of bars. The CNC lathe was produced in 2000 in France. Technical data : - type of automatic lathe: Swiss Type - control: NUM - Swiss control - number of axles: 6 - turning diameter up to: 20 mm - diameter of passage Ø: 28 mm - number of turns: 150-8000 rpm - feed: 10/15 m / min - number of tools: 8 + 8 + 4 + 4 pcs - spindle power: 2.2 kW - tailstock: counter spindle - machine weight: 5000 kg Lathe equipment: - two main spindles / two opposite spindles - material feed with FMB Doppel-Turbo - counter spindle: 150-6000 rpm - chip conveyor - Manurhin / Schlichting-System clamps - coolant filtration

HORIZONTAL LATHE B1200 BIGLIA SWITCHABLE LENGTH 1200 MM TURNING DIAMETER 700 MM BAR STEP 80 MM SPINDLE POWER 30 KW NUMBER OF REVOLUTIONS/MIN 2800 Z-AXIS STROKE: 1200 MM Tailstock CHIP CONVEYOR HYDRAULIC BEZEL NUMBER OF TOOL POSTS 12 CONTROL: FANUC 21i-TB

Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...

MAXIMUM SWITCHABLE LENGTH: 1520 MM MAXIMUM TROLLEY DIAMETER: 600 MM MAXIMUM SWITCHABLE DIAMETER: 540 MM AXLE STROKE X1:555 MM X2 AXIS STROKE: 185 MM Z-AXIS STROKE: 1595 MM STROKE Z2:1640 MM Y-AXIS STROKE: 160 (+-80) MM AXLE STROKE A: 1565 MM C1-C2 AXIS STROKE: 360 º (0.001) B-AXIS STROKE: 15-240 º (+-120) SPINDLE SPEED: 2800 RPM SPINDLE NOSE: ASA A2 # 8 CONTROL: FANUC 18I-TB COMPLETE WITH BEZEL SMW-AUTOBLOK

MAXIMUM SWITCHABLE LENGTH: 1520 MM MAXIMUM TROLLEY DIAMETER: 600 MM MAXIMUM SWITCHABLE DIAMETER: 540 MM AXLE STROKE X1:555 MM X2 AXIS STROKE: 185 MM Z-AXIS STROKE: 1595 MM STROKE Z2:1640 MM Y-AXIS STROKE: 160 (+-80) MM AXLE STROKE A: 1565 MM C1-C2 AXIS STROKE: 360 º (0.001) B-AXIS STROKE: 15-240 º (+-120) SPINDLE SPEED: 2800 RPM SPINDLE NOSE: ASA A2 # 8 CONTROL: FANUC 18I-TB COMPLETE WITH BEZEL SMW-AUTOBLOK

MAX DIAMETER OF ROTATION: 750 MM MAX DIAMETER SWITCHABLE: 680 MM SWITCHABLE LENGTH: 1195 MM CNC: FANUC 18i-TB MAIN SPINDLE: MAX SPEED. OF ROTATION: 2800 RPM DIN 55026 8 ' ' CHUCK NOSE BAR PASS: 95 MM MOTOR POWER: 30 KW SELF-CENTRING DIAMETER: 315 MM Tailstock: POSITIONING STROKE: 1310 MM RACEWAY: 150 MM TUBE DIAMETER: 115 MM TORRETA TOOLHOLDER: MOTOR POWER: 10-17.5 KW TOOL DIMENSIONS: 25X25 MM BARENI DIA DIMENSIONS: 32-40 MM

MAXIMUM ROTATING DIAMETER: 200 MM MAXIMUM TURNING LENGTH: 300 MM MAXIMUM TURNING DIAMETER: 160 MM BAR PASS: 41 MM COURSE ASSE X1: 175 MM COURSE ASSE X2: 132 MM COURSE ASSE Z1: 305 MM COURSE ASSE Z2: 155 MM QUICK X-Z AVANZAMENTS: 12 - 20 M/MIN MANDRINO: 100-5000 RPM; 11-15 KW; ASA 2-5 CONTROMANDRINO: 100-5000 RPM; 3.7-5.5 KW TOOL-HOLDER: 12 POSITIONS CONTROL: FANUC 18i-T WEIGHT: 4900 KG INGOMBRO: 3650 x 1940 x 1830 MM

Plate diameter 4200 mm Maximum turning diameter 4600 mm Max workpiece height under the cross member 4000 mm Max workpiece weight 100 t Travel RAM horizontal 2600 mm / min Travel RAM vertical 2000 mm / min Tool holder (powered tools) ISO 50 Table speed 40 rpm Main drive 120 kW Number of gear stages 4 Total connection value 180 kW Max torque on the flat disc 40000 kpm Max cutting force per support 10000 kp Crossbar support right and left Largest vertical path of the Chisel slider 2000 mm Cross-section of the chisel slider 285 x 310 mm Adjustment path of the crossbar 3500 mm Total weight of the machine 115,800 kg Accessories Automatic lubrication of the cross-bar guide on the stand Hydraulic weight compensation of the chisel sliders Milling spindle and C-axis c-axis 360,000 positions

CITIZEN CINCOM A20 VIPL CNC lathe built in 2006 ensures the highest precision and efficiency in the production process. During machining, the specially designed bed with its rigid structure and high thermal stability effectively reduces the heat impact, resulting in increased machine life and reliability. All of this, combined with a modular design with a reduced number of parts, makes the CINCOM A20 VIPL CNC lathe ideal for various types of production. Workpieces with a maximum diameter of 20 mm and a length of 135 mm are machined in 7 axes by a powerful main spindle which is synchronised with an AC motor, forming an electrospindle. A bushing driven by a separate AC motor is also synchronised with the machine’s main spindle. The operator’s panel consists of an intuitive FANUC 32i CNC controller, a memory card slot and an electronic wheel located next to the monitor designed to ch ...

Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

KNUTH PICO TURN CNC lathe built in 2015 in Germany is the ideal choice for small-scale industries focused on unit and small batch production. Due to its extensive machining capabilities, sturdy design and high productivity, this compact size machine performs excellently in, among others, precision arc turning, threading and longitudinal and transverse workpiece turning. All operations are performed by a powerful spindle with variable speed adjustment between 150 and 1750 rpm. The KNUTH PICO TURN CNC lathe is additionally equipped with, among others, an automatic 4-position tool changer, an intuitive SIEMENS SINUMERIK 808D CNC controller and a 3-jaw chuck with a diameter of 125 mm. The total weight of the machine is 400 kg. Technical specifications of the KNUTH PICO TURN mini metal lathe machine - feed rates in the X/Z axis: 500/250 mm - rapid traverse in the X/Z axis: 2000/1000 mm/m ...

CNC slot machine Gildemeister GLD 25 with counter spindle Technical data: Manufacturer: Gildemeister Type: GLD 25 Built: 1999 Control: FANUC Series O-T Main spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (Z-axis): 160 mm Counter spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (C-axis): 265 mm - Rapid speed C-axis 15 m/min Sled: - Slide: X= 30 mm, Y= 220 mm - Rapid x-axis 10 m/min - Rapid y-axis 15 m/min - Number of WZ on the sled: 5 + 3 (driven) - Speed WZ (driven) : 6,000 rpm Accessories: - Chip conveyor -Bar loader: IEMCA MINI BOSS 325/32 Dimensions LxWxH: - Machine with chip conveyor 3150 x 1100 x 1700 mm - Bar loader 3900 x 800 x 1400 mm Weight: - Machine: approx.2000 Kg - Bar loader: approx. 1000 kg. - Total weight: approx. 3,000 kg

CNC lathe GILDEMEISTER CTX ALPHA 300 with bar feeder and parts pick-up device Built in 2010 in good condition. Duty Cycle: 22930 Hours: 7326 Control Heidenhain CNC-Pilot 640 Circulation over bed: 380 mm Circulation via face slide: 290 mm Spindle bore: 73 mm Flat travel ( X ) : 190 mm Longitudinal travel ( Z ) : 335 mm Speed max. 6000 rpm C-axis 360° Number of driven tool stations 12 pos. Tool holder VDI 30 Accessories: 3 jaw chuck hydraulic 170 mm Conveyor Coolant system Hydraulic hollow clamping device Tool drive C-axis Parts pick-up device Bar Feeder Irco RBK10012 Tailstock

MAX DIAMETER OF ROD: 100 MM MAX CUTTING DIAMETER: 552 MM MAX TURNING LENGTH: 1.195 MM TURRET: 16 ROTATION SPEED: 2800 RPM CONTROL: FANUC 32 B INCLUDES: AUTOBLOK STEADY SLU-3.1 – ZS CAPACITY: 20-165 MM AUTOMATIC FEEDER FOR BARS BREUNING – MOD. MUK 10016-II

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

Table diameter 2.000 mm Working diameter 2.000 mm Machine under retrofit/rebuilding to install CNC Mechanical ready, totally rebuilt.

CNC fine lathe Make: PetrolGer Type: TNL Control: Siemens 810T Built: 1991 Equipment and accessories: - Swivel loader system - Small conveyor belt - Charging-unloading gripper - Chip conveyors - Foot lever for clamping and relaxing the collet

Control Fanuc ... i Series Turning diameter ... 600mm Turning length ... 330mm Inclined bed Spindle bore ... 61mm Turret Circumferential diameter over bed ... 600mm Circumferential diameter via support ... 400mm Axis X ... 205mm Axis Z ... 340mm Rapid traverse of the X axis ... 30m/min Rapid traverse of the Z axis ... 36m/min Spin speed... 0-6000 rpm. Max. spindle torque ... 127Nm Main engine power ... 11/15kW Doosan Robot Cell Assembly: 2x LYNX 2100A + ROBOTEC APC7 (Fanuc AM-100 iC6L) - The machines are supplied with chucks and pliers - High pressure cooling 20bar - Arm for picking up workpieces (Ø65 x L130 mm, weight 3 kg) - Automatic door opening - Spindle bladders for cleaning the clamping jaws - Oil separator - OIL SKIMMER - Tool Load Monitor (works with X-, Z-axis and S-spindle) - Workpiece conveyor The machine is in good condition, possible to test un ...

BOEHRINGER VDF DUS 1000 CNC lathe was built in 1993 in Germany. The machine, designed for machining workpieces with a maximum diameter of 1000 mm, delivers excellent turning results during even the most intensive challenges, thanks to its extremely stable design and reliable components. The spindle is driven by an stepless AC motor, which allows efficient turning in two different, optimally adapted speed ranges. All axes, on the other hand, have powerful servo drives, guaranteeing excellent dynamics and positioning accuracy throughout the machine’s lifetime. This is rounded off by an intuitive SIEMENS CNC control with many functions for easy operation and programming. The BOEHRINGER VDF 1000 DUS lathe weighs approximately 10100 kg. Technical specifications of BOEHRINGER VDF DUS 1000 metal lathe - turning diameter above the bed: 1000 mm - turning diameter over transverse slide: 710 ...

Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...

Inv. Num: 5302 Type: DL 10G Producer: Profika Generated: 2011 Parameters: Control system: FANUC 0iMATE-TD Maximum rotation length: 185 mm Max turning diameter: 170 mm Maximum spindle speed: 3500 rpm Lathe length: 1980 mm Lathe width: 1420 mm Weight: 2750 kg

Key data: 85 mm, 255 mm, 6300 1/min

CNC lathe Emco E25 Powermill TCM Commissioning 03/2019 At call! Siemens 828D Shopturn Main spindle spindle passage 25mm PF - 6,300 1/min Turret 12-speed VDI16 driven tools 6,000 1/min PC Keyboard Machine set-up and fastening material Parts collection device Emco Standard Bar Feeder Interface Machine Status Lamp LED Multiflow Cleaning Gun 8-bar high-pressure coolant device Power Chuck 95/3 Röhm Pliers chuck KZF 20 for 148E Tool holder pact stationary/driven 9 pieces Radial Milling Holder VDI16 2 WStück Axial Milling Holder VDI16 2 WStück OPC UA / Siemens interface The options list is complete! No interest in dealer enquiries! No separate dealer price! WB mechanics GmbH is a precision mechanics workshop that markets its used machines on its own. We are not a machine dealer, but the machine user! The machine is in use in our company until it is sold a ...

Uterna company ovenn 650 inner dimensions 1x1x2m t max 650 C PLC Auto door Schachtofen Haubenofen Rollenherdöfen Durchstoßöfen Härten Glühen Normalisieren Weichglühen Vergüten Anlassen Entspannen Durchschuböfen Hubbalkenöfen Hubherdöfen Trockenöfen Rollenherdöfen Drehherdöfen Kammeröfen Mehrkammeröfen Verfahrbare zirlguss Haubenöfen Herdwagenöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haa ...

BIGLIA SMART TURN B1200 CNC automatic lathe was built in 2008 in Italy by OFFICINE E. BIGLIA & C. S.p.A. The machine, dedicated to the precise, multi-axis machining of workpieces with a maximum diameter of 580 mm, was created as an effective answer to the daily challenges of modern business. For this purpose, it features modern components with excellent technical characteristics inside a large work space, such as two spindles (main spindle and sub-spindle) and a 40-position tool magazine. The high-speed operation of the tool magazine further significantly speeds up production time and reduces machine downtime to a minimum. The SMART TURN B1200 S CNC turning center is offered with a wide range of equipment, including a bar feeder, Y-axis and FANUC intelligent CNC control. The total weight of the machine is 7000 kg. Technical specifications of the BIGLIA SMART TURN B1200 CNC lathe Gene ...

GILDEMEISTER TWIN 65 CNC automatic lathe was built in 2005 in Germany by GILDEMEISTER Drehmaschinen GmbH. The machine is used for precise, multi-axis machining of workpieces with complex geometries. To increase overall production efficiency, a combination of two spindles and two 12-position turrets with excellent technical specifications are used inside the large working area. Both spindles feature a C-axis with a high indexing accuracy of ± 0.002 mm, which facilitates complex machining operations that require precise positioning of the workpiece. All this is complemented by an intelligent SIEMENS CNC control with an intuitive interface. The GILDEMEISTER CNC turning center weighs 10000 kg. Technical specifications of the GILDEMEISTER TWIN 65 CNC lathe General data - number of axes: 8 (X1, X2, X3, Y1, B, Z1, Z2, Z3) - feed in the X1/X2/X3 axis: 300/180/175 mm - feed in the Y1/B ax ...

The machine is in good technical condition, a test run is possible by prior arrangement. Hours: 8,981 Upper driven tool turrets with Y-axis, lower driven turret, double slide with two spindles. Control: FANUC 31i-B. Max. circumferential diameter above the bed: 300 mm Max. circumferential diameter over the support: 230 mm Max. turning diameter above the bed with upper turret: 230 mm Max. turning diameter above the bed with lower turret: 230 mm Max. turning length: 600 mm Max. distance between the ends of the right and left spindle: 980 mm Milling area outside the axis of rotation due to Y-axis: 100 mm (+/- 50 mm) Max. rod diameter (left spindle): 65 mm Max. rod diameter (right spindle): 65 mm Max. permissible workpiece weight without sub-spindle (incl. chuck weight = 23 kg): 12 kg Total weight: 7,800 kg Accessories: SS 2500 bar feeder, length 200–1 ...

The machine is in good technical condition, a test run is possible by prior arrangement. (spindle 32 mm) + Mitsubishi E60 control. Bar feeder included – for bars up to 3000 mm! Max. turning diameter: 60 mm Max. turning length: 120 mm Circulation diameter over cross slide: 120 mm X-axis: 170 mm Z-axis: 170 mm Spindle bore: 34 mm Max. bar diameter when using the loader: 32 mm Spindle holder: diameter 85 mm Spindle motor: 3.7 kW Spindle speed: 100–5,000 rpm Rapid traverse (X and Z axis): 15 m/min Min. program input: 0.001 mm Max. tool diameter: 16 mm Machine dimensions (L x W x H): 1200 x 1000 x 1500 mm

The machine is in good technical condition, an inspection by prior arrangement is possible. Max. turning diameter: 465 mm Max. circumferential diameter: 680 mm Max. rotation diameter via cross slide: 465 mm Max. width of the cross-section: 315 mm Travel in X/Z: 300/1050 mm 315mm 3-Jaw Hydraulic Chuck Max. spindle speed: 3250 rpm Spindle bore: 76 mm Spindle drive power (40%/100% ED): 33/22 kW Max. spindle torque (40%/100% ED): 630/420 Nm Max. speed driven tools: 4000 rpm Programmable tailstock, tool measurement, chip conveyor S/No. 8045000336E (2011) Installed power: 50 kVA Power supply: 400 V; 50/60 Hz Dimensions (L x W x H): 5250 x 2300 x 2000 mm Machine weight: 8000 kg

CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 520 C-axis: 360º (0.001°) Turning length mm: 515 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Counter spindle Counter spindle travel mm: 525 Equipment Chip conveyor Signal lamp Tool measuring arm Workarea light Working time hours Under power: 7.456 Cutting Time: 5.423 Basic machine dimensions / weight Length mm: 3.495 Width mm: 2.050 Height mm: 2.230 Weight kg: 5.800

Code 71139 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 1500 S/N 30 H / 87 Year 1996 Control Siemens Sinumerik 805 Distance between centers 1500 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 5500 kg Accessories 8 ATC Duplomatic toolholder R 10 Hydraulic 3 chuck Ø 315 mm 1 fixed steady with 320 mm bore 1 open steady cooling equipment Condition Machine is in good condition

Code 81176 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 3000 S/N 30 – S / 80 Year 1995 Control Heidenhain Manual Plus ( 1998 ) Distance between centers 3000 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 6000 kg Accessories 3 chuck of 315 mm 1 fixed steady 1 open steady cooling equipment Condition Machine is in good condition

Used lathe from Wagner Wagner WDE 500 Lathe, cycle-controlled Only approx. 1700 operating hours Turning diameter 500 mm Turning length 1500 mm Control Siemens 802 C Circumferential diameter over bed carriage 280 mm Spindle bore diameter 82 mm Number of Controlled Axes 2 Speed range 20- 3000 rpm Rapid traverse speed 5 m/min Number of receptacles in the turret 1 Multifix "C" Tailstock Yes MK 5 Drive power 7.5 kW Machine weight approx. 3.0 t Dimensions L x W x H 3.3 x 1.7 x 1.7 m Cycle-controlled CNC lathe in good condition. Accessories: - Coolant device - Basic holder - 3- Jaw chuck - various PARAT tool holders

DATASHEET – RAMO TN20 CNC LATHE Manufacturer: RAMO Industrie SA Model: TN20 Numerical control: NUM 1060 (Telemechanical) Type: Inclined Bench CNC Lathe Condition: Good general condition, visible machine under power ⚙️ TECHNICAL SPECIFICATIONS Power supply: 3 × 400 V – 50 Hz Current rating: 63 A Control voltage: 110 V ~ Signaling voltage: 110 V ~ Lighting voltage: 220 V ~ Clutch voltage: 24 V = MECHANICAL CAPACITIES (TN20 standard) Turning diameter above the bed: 420 mm Turning diameter above carriage: 250 mm Length between toes: 500 mm Z-axis travel: 500 mm X-axis travel: 200 mm Spindle passage: Ø 40 mm Spindle speed: 30 to 4000 rpm Spindle Cone: Camlock D1-4 Spindle motor power: 7.5 kW Fast feeds: 10 m/min (X and Z axis) Tool Turret: 8 automatic positions DIMENSIONS AND WEIGHT Dimensions (W × D × H): app ...

Key data: 420 mm, 650 mm

Machine Type: CNC Lathe Manufacturer: Okuma Type: LB400M-1SC Year of Make: 2000 Commissioning: 2001 Control: OSP-U100L Spindle hours: 14502 hrs Delivery time: in stock Machinery - Interior extraction from Hengst Filtration (built in 2023) - Touchsetter, tool measurement - C-axis (main spindle) - Tool breakage and wear monitoring - 3-jaw chuck, Kitagawa B210, Ø250 - Tailstock available - Coolant supply, also available through the tool - Dialogue programming IGF - Chip conveyor (scraper) Technical details - Max. turning length: 650 mm - Max. turning diameter: 420 mm - X-axis travel: 300 mm - Travel Z-axis: 675 mm - Travel C-axis: 360° - Chuck passage: 72 mm - Spindle passage: 95 mm - Clamping cylinder passage: 95 mm - Tool holder: VDI 40 - Tool stations: Stations 12 - Spindle speed: 2800 rpm - Main spindle power: 22/30 kW - M-spindle ...

Key data: 370 mm, 600 mm

Machine Type: CNC Lathe Manufacturer: Okuma Type: LU300-2ST Year of Make: 2005 Control: OSP-E100L Delivery time: in stock Machinery  Parts conveyor belt and parts collection tray – workpiece chute with removal conveyor belt incl. electrical kit  2 disc turret with VDI40 (12 + 8 stations)  Power clamping cylinder for hollow chips – Hole in the drawbar 52mm  Extension Kit "D" – Kit one touch IGF-D  Open/close chuck while the spindle is running via M-Code  Reinforced coolant pump 8 bar  Coolant on A and B turrets can be switched via M function  Interface for connecting rod feed  Chip conveyor Technical details  Swing diameter over bed: 530mm  Swing diameter over slide: 380mm  Distance between the tips: 600mm  Max. turning diameter: 370mm  Max. turning length: 600mm  Travel X-axis: upper 260mm  ...
