HAISHU CNC550T 4-axis CNC Lathe Producer- Taian HAISHU Machinery Co. Ltd YOM 2015 Condition- Never used Equipped with two spindle and an additional lower turret with 12 tools, providing automatic two-way processing of the workpiece in the achievement of maximum processing speed. Control CNC GSK988TD Additional Y axis Max. working length 750 mm Maximum turning diameter over bed 550 mm Maximum turning diameter pallet 500 mm Spindle type А12 Hydraulic Jaws: 2x 300 mm Front spindle bore taper 1:20 Spindle pass 75 mm Speed of Servo spindled 0-4000 mm/min Axis X/Z/B Quick moves 40 000 mm/min CS1, CS2 power of main motors: 15 kW Engine motor on axle C- 5.5 kW Moment by Axis X/Z: 15 Nm Movement on Y axis: + 55/-55 mm; Moment on axis B: 20 N. m; Time to change tool 1.6 sec Positioning accuracy 0.005 mm Moves on axes X1/X2- 350 mm Moves on axes Z1/Z2- 1100/1350/1850 mm ...
CNC centerless grinding machine Monzesi mod Monza 510 CNC 6 axes complete with piece loading and unloading system CNC Fanuc 160i-T Under power in our warehouse in Gussago BS. Mimu machine tools Italy
(3) Mikrosa SASL 5 CNC (size similar to Kronos M, MX, L) CNC overhaul and retrofit in progress full overhaul and CNC retrofit (pending) komplett Ueberholung + CNC retrofit Grinding wheel 500mm wide x 610mm dia. CNC 5 axis / 5 axis Mikrosa SASL 5 CNC complete overhaul and retrofit Grinding wheel 500 x 610 mm Regulating wheel 400 x 650mm Fixed center Complete mechanical overhaul Complete electrical overhaul Elimination of hydraulic movements Application CNC Siemens 840D 5 axes controlled in position with digital brushless motors: - Operating wheel axis motor with optical scale - 4 dressing axes: 2 on the grinding wheel, 2 on the regulating wheel - rotating axis with adjustable speed motor on regulating wheel - rotating axis with 55kW AC motor with inverter on grinding wheel to adjust RPM / peripheral speed (m/sec) Set-up for through-feed grinding and still customizable according to custome ...
Matsuura MC600VF Vertical Machining Centre in great working condition ready to use. COOLING TROUGH SPINDLE YEAR: 1997 with Yasnaz i80M Control, Table size 870 x 400mm, 20 Position ATC, BT40 Taper, Spindle Chiller, Coolant Tank, X = 600 Y = 410 Z = 470mm, Spindle Speeds 30 – 8000rpm. S/No. 970112285 including Large Qty of BT40 Tooling (33 TOOLS, Universal 3D Tester. Country of Origin: Japan. INCLUDED AS WELL BACK UP PARAMETERS.
KENYO VS80160 5-axis Machining center with CE Producer: Nanjing Kenyo Precision Machine Manufacture Co., Ltd YOM 2015 Simultaneously 5 axes Total Installed Capacity 22.4 kW 5-Axis vertical Milling machine for blanks up to 1000-1500kg Stroke X/Y/Z- 1600/800/800 mm Working table size 800x1800 mm Diameter of NC swivel table axle C 630 mm Rotating mass clamping force 4000 Nm Spindle clamping force: ≥ 2000 Nm Maximum mass load 2000 kg Spindle diameter 170 mm Spindle rotation angle- ± 110 Degree Tool Store Type BT40 ISO Tool magazine 24 pcs Maximum spindle rotation speed 10.000 rpm Spindle power 15 kW Ball-Screw pair HIWIN Spindle Hesheng Ball Bearings NSK Positioning accuracy ≤ X/Y/Z: 0.015 mm, C: 0.002 degree, B: 0.002 degree Repeat accuracy ≤ X/Y/Z- 0.01 mm, C:0.0015 Degree, B:0.0015 Degree Quick move: ≥ 10000 mm/min Milling speed: ≥ 1 to 8000 mm/min OC ...
5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...
5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...
Naxos CNC Multi-Axis Cylindrical Grinder Year: 1987/2013 Max. swing: 630mm Max. distance workhead face to tailstock face: 4850mm Max. travel for Z axis: 5000mm Max. grinding distance for main wheel: 4520mm X axis infeed travel for both headstocks: 720mm Approx. weight between centers: 4000kg Power requirements: 460/3/60 This machine was completely remanufactured to new specifications in 2013 and installed in 2014. It was stripped down to the bare casting, table/base/wheel heads/work head and tailstock and the second z axis ways were fit and rescrapped. New electrical cabinet with all new wiring to the machine and new all components, hydraulic lines, air lines and new cable carriers were added. New Marathon 60HP motors for both grinding wheel heads. (The drives in the cabinet are set for 40 Hp) The spindle drives in the cabinet are Yakawa built in the USA along with the workh ...
Deckel Maho DMF 300 Linear, built in 2002 TECHNICAL INFO: CONTROLS: CNC SIEMENS Sinumerik 840 D power line, TRAVELS: X: 3,000 mm Y: 560 mm Z: 720 mm Spindle mount SK40 Spindle speed: max 12,000 rpm (limited to 6,000 by gearbox) Tool magazine for 40 tools Operating hours: 21,865 Spindle hours: only 9,320 Very reliable, stable and good machine! No maintenance backlog! - In recent years, small items such as belt pulleys, hydraulic accumulators, scrapers, linkages have been added, regardless of the maintenance positions - In 2018 a new Z-axis ball screw came in. The engine gearbox was also overhauled - Rotary table 560mm (4th axis) for assembly also available and part of the sale The orientation of the Hirth toothing when swiveling would have to be readjusted. However, we only use the machine as ...
CNC Lathe - twin turret - subspindle Y axis NAKAMURA WT 250 CNC Fanuc, Series 16i-T, Spindle - sub spindle 1 turret live tools + Y axis 1 turret live tools (lower), 2x C-Axis, Swarf conveyor, IEMCA TS560P Bar loader Under power in our in our warehouse in Gussago BS. Mimu machine tools Italy
CNC Lathe - twin turret - subspindle Y axis NAKAMURA WTS150, CNC Fanuc, Series 16i-T, Spindle - Subspindle, 3x turrets, live tools + 2 Y axis (milling), 2x C-axis, Conveyor, LNS bar loader (short bars) Mimu machine tools Italy
This 5-axis COSMEC CONQUEST 515/13 was manufactured in 2019. A robust CNC Wood Machining Centre, it features a working area of 6210 Ã 1650 mm, dual motorization on a closed gantry structure, and a spindle power up to 18 kW. It supports tool changes with multiple configurations and is compatible with ALPHACAM and ASPAN software. Consider the opportunity to buy this COSMEC CONQUEST 515/13 CNC Wood Machining Centre. Contact us for more information about this machine.
used
Max. X-axis stroke 200 mm Max. Y-axis stroke 220 mm Max. Z-axis stroke 280 mm Max. workpiece diameter 200 mm Max. workpiece height 200 mm Max. workpiece weight 100 kg
CHIRON MODEL FZ18W MAGNUM 4 axisVertical machining center with rotopallet and double 4th axis20 TOOLSISO 40Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kWX = 625Y = 400Z = 400Rapids 40m/minTable area: 2 x 900 x 470- TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos.- original HAWE hydraulic unit - FANUC 0m be inspected under power in our warehouse.Mimu Machine tools Italy
5 axis machininng center (milling/turning from bar) Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4)
FZ15KS HIGH SPEED 4 axis vertical machining center X: 550mm Y: 400mm Z: 360mm 4th axis original Peiseler CNC Siemens 840D Table surface 1050 x 450mm Toolchanger 48 posts ISO 40 Spindle speeds up to 12000 1/min with 4th axis Renishaw broken tool detector Coolant through spindle swarf conveyor Can be inspected under power in our warehouse. Mimu machine tools (Italy)
Biesse Italy, Rover 22 CNC Machining Center Built in 2001 SN 07498 Workspace 4 axes X-axis 3060 mm Y-axis 1080 mm Z-axis 155 mm 6 consoles with 18 vaccum suction holder 4 pneumatic bakelite rods for lifting the plate Vertical electric spindle 7.5 kW with automatic tool change, ISO 30 cone Automatic tool change 7 positions on the working head Drill head with 20 spindles arranged as follows: 7 vertical in X-axis 7 permeable to Y-axis 4 horizontal in X-axis 2 horizontal in Y-axis Groove saw 120mm Safety tread mats 110 m3 / h vacuum pump CE marked Weight 3500 Kg Technical information subject to reservation
InfoTEC 6205 PRO 5 AXIS profile machining center was built in 2019 in Poland by 4CNC Sp. z o.o. The machine, designed for precision milling, drilling and cutting of workpieces made from a wide range of materials, is an excellent choice for companies with a diverse production profile. Workpieces are machined using a moveable machining station, which moves over an extended work area. This solution significantly increases production efficiency, thanks to the possibility of machining more than one workpiece at the same time. The InfoTEC PRO-X 5 AXIS aluminium profile machining center is offered with a wide range of equipment, including e.g. an advanced CNC controller, programs that facilitate daily machine operation and PANASONIC light curtains. The total weight of the machine is approximately 5800 kg. Technical specifications of the InfoTEC 6205 PRO 5 AXIS beam drill line - number of ax ...
5-Axis Horizontal Machining Centre MCM Tank 1300 5-AXIS New in 2017 Siemens 840D solution line Twin pallets 630 x 800 mm Work weight max. 1500 kg NC rotary table - 4th axis B-Axis 360° / 0.001° NC-Tilting head 5th axis A-Axis +80°/-95° / 0.001° X 1300 mm Y 1400 mm Z 1400 mm Feeds and rapids to 50000 mm/min. Spindle drive 40/52 KW Spindle speeds to 10000 rpm Tool taper ISO 50 199 tool ATC Linear scales for higher accuracies Renishaw sample Chip conveyor CTS 65 bar Beautiful machine – excellent condition Operating hours 11544 - 05/2020) Spindle Working hours 6784 (05/2021) Inspect under power Proposal Number MH-6155
General Manufacturer: Chiron Type: DZ 28 P five axis Year of manufacture: 2023 Control: Siemens Sinumerik 840D SL Travels: X 1,200 mm Y 1,100 mm Z 800 mm Rapid traverse: X 120 m/min Y 75 m/min Z 75 m/min Axle acceleration: X 1.0 g Y 0.8 g Z 1.5 g Main spindle drive Speed: up to 20,000 rpm 2-axis torque swivel device 2 x face plates diameter: 479 mm Swivel axis as A-axis Swivel angle: ± 120° Swivel radius: 700 mm Bridge dimension: max. 2,400 mm Repeatability: ± 5" Speed: 42 1/min NC rotary table as C-axis Clamping force: 25 kN +/- 15 % per clamping segment Repeatability: ± 5" Speed: 100 1/min Loading and unloading station for tools Tool Stations: 2 x 36 Tool shank: HSK-A 63 DIN 69893 Tool diameter: max. 78 mm Tool diameter with free adjacent spaces: max. 160 mm Tool length: max. 450 mm Tool weight: max. 10 kg Tool change time: approx. 0.9 s Ma ...
Dimensions (L/W/H): 3300x2100x2100 mm Weight: 2000 kg Total power requirement: 16 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 â 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...
Axes Strokes X = 3706mm Y = 2294mm Z1 = 515mm Z2 = 371mm Max rotation 24000 rpm C axis = 360 deg non-stop rotation B axis = 360 deg non-stop rotation 16 position revolver toolchanger
Key data: 630 mm, 560 mm, 560 mm
Machine Details Stock-No. 1105-04038 Type of machine Universal Milling Machine Make DECKEL-MAHO Type DMU 60 MONOBLOCK Year of manufacture 2008 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight basis EX WORK Technical details X-Travel 630 mm Y-Travel 560 mm Additional information CNC Univ. Tool Milling Machine DECKEL MAHO Model DMU 60 MONOBLOCK YEAR OF MANUFACTURE 2008 5 AXIS SIMULTAN CNC Universal Tool Room Milling Machine DECKEL MAHO type DMU 60 MONOBLOCK BUILT IN 2008 With CNC control Heidenhain TNC 530, 32-fold tool changer, ROUND TABLE 360000 ° , Cabin With CNC control Heidenhain TNC 530 , 33-fold automatic tool changer, , cabinl Technische Daten / technical details: Longitudinal travel X / X-travel longitudinal 730 mm Cross travel Y / Y-travel cross 560 mm Vertical travel Z / Z-travel vertica ...
MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 â 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...
CHIRON MODEL FZ18W MAGNUM 4 axis Vertical machining center with rotopallet and double 4th axis 20 TOOLS ISO 40 Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kW X = 625 Y = 400 Z = 400 Rapids 40m/min Table area: 2 x 900 x 470 - TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos. - original HAWE hydraulic unit - FANUC 0M 1995 Can be inspected under power in our warehouse Mimu machine tools (Italy), X: 625, Y: 400, Z: 600, 4th axis: Yes, (2x) Tsudakoma 360 000 pos.
3000w Year: 2018 5 Axis Fiber Laser 3000w Y Axis: 1500mm Twin Cell Machine
This 5s Okuma MU 6300 V L 5 AXIS was manufactured in 2016. It features a generous X-Axis travel of 1,450 mm and Y-Axis travel of 1,050 mm, providing ample workspace for various machining tasks. With a maximum workpiece diameter of 830 mm and a tool magazine capacity of 64 positions, consider the opportunity to buy this Okuma MU 6300 V L vertical machining centre. Contact us for further details.
MARINUS endmatcher & defect saw, type Powermax 300, Manufacture year 2014
CNC Vertical Turret Lathe with C axis and live tool 3 Turning Plates Changer (translating pallet system) EQUIPPED WITH: Siemens Sinumerik 840C CNC Control (2015 Retrofit) Vertical Ram with Live Spindle Pallet Changer (3-Pallets) 16-Station Automatic Tool Changer C-Axis Table Year 2005 CNC Siemens 840 C Max. turning dia.: 2200 mm Max. turning height: 1800 mm Ram travel: 1500 mm Main drive: 75 kW Live spindle: 15 kW Spindle rotations: 45- 1350 1/min Max. workpiece weight: 12 000 kg Pallet changer with 3 pallets (turning plates) Tool magazine: Right: 8 turning tools Left: 8 boring/milling tools Feeds: 0,1-6000 mm/min Carriage feed: Vertical: 1500 mm Horizontal: 1320 mm Table rotation (2 ranges): 2,5 – 70 / 10-280 Max. table torque: 50 000 Nm Machine weight: 43 Ton Machine HxWxL: 6,8 m x 10 m x 9,7 m
x-travel:800 mm y-travel:950 mm z-travel:1020 mm control:Sinumerik 840D sl MDynamics Operate turning speeds:10.000 1/min Spindle power:26/20 kW max. torque on the spindle:340/262 Nm tool taper:HSK-A 100 tool change unit:120 (2x60) Pos. Pallet changer 2x:630 x 630 mm table load capacity:800 kg weight of the machine ca.:20 t dimensions of the machine ca.:3,3 x 6,15 x 3,2 m 6-axis simultaneous horizontal machining center with controlled swivel-rotary table (A/B-axis), Swivel table can swing overhead (180°), that means the part is hanging down overhead and chips don?t accumulate on pallet, they can fall free into the chip conveyor CNC controlled U-axis enables radial movement of tool for variable spindling diamenter. twin pallet changer 630 x 630 mm 6 hydraulic couplings for pallet fixture clamping with rotary joint in A and B-axis special hydraulic pump for fixture coolant through spindle ...
Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1215 Drive: 3 busiest brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse play maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 1860 x 1340 mm travel distances: X=1500mm; Y=1200mm; Z= 130 mm contact contactno-point sensors / reference switches / limit switches on all axes Double-secured emergency trigger energy chains for clean cable Total mass with motors : LxWxH approx. 2180 x 1800 x 1420 mm Fra- Sc ...
3D CNC Router T-Rex 1215 / Technical Data : Equipment / product data CNC-milling machine type High-Z/TRex series: Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all exis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 1860 x 1340 mm Travels: X=1500mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions wi ...
Equiptment / product data CNC-milling machine type High-Z/TRex series / 1224 Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all axis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 2800 x 1340 mm Travels: X=2400mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions with engines : LxBxH ca. 3070 x 1800 x ...
Cooling equipment - weight: 200kg L 1,700 x W 800 x H 900 cm, High: 2.100 mm, Long: 2.400 mm, Width: 2.400 mm, Weight: 2,500 Kg., Voltage: 380 V, Total power: 4 Kw, Wheel speed: 2,250 / 6,000 rpm, Grinding length: 400 mm, Ø max workpiece: 320 mm, Transversal stroke: 260, Longitudinal stroke: 400 mm, Distance between points: 700 mm, Race car rolling (x axis): 400 mm, Vertical travel of trolley wheel: 280 mm, Specification: Universal
Specifications / Technical Data S-400/T CNC portal fraesmachine / engraving machine, TUeV certified Already more than 4500 CNC machines of type High-Z sold worldwide ! With the T-variant of the High-Z CNC-Fraesmaschine you acquire old-fashioned technology with the certain I-T-Tpfelchen The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. The high-Z/T CNC fraes machine achieves fantastic accuracy and an almost unmeasurable reversal of about 0.01mm due to the ball-circuit spindles used. At the same time, high travel speeds of up to 108mm/second ( 6500mm/ minute) can be achieved. Thus, engraving and fraes speeds of up to approx. 4500mm/min can be realized and fast-moving speeds up to approx. 7000mm/min. This is just as applicable in the industrial sector for work such as engraving, frause, drilling, measuring, cutti ...
Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine with TÜV certification With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machine series is usable in the ...
Why produce the smallest parts on large, expensive CNC machining centers when it handles a small CNC machine for a fraction of the price just as quickly and massively ? On this machine, an unskilled worker can insert and unmount the factory quilts ! You can reduce your own costs from 250 Euros to 40 Euro Hourly Rate for Small Parts production and thus be much more competitive ! DIN ISO G-Code Programming or data output of the Fraesbahnen 2D or 3D directly from the software. You reduce your operating costs extremely. Also available with rotary axis ! Several companies produce extruder screws, 3D molded parts made of aluminium, small parts made of brass or stainless steel for injection moulding plants, etc. for your production. We would be happy to advise you on brass, copper, steel, stainless steel and many other materials can be processed. view informations and obtain non-bind ...
Specifications / Technical Data S-400 Fraes machine / engraving machine With the High-Z CNC-Fraes.- and engraving machine you acquire an all-round talent in TUeV-certified quality (EMC). Whether you want to clamp complex parts on a groove table or, or put factory tins in a high vice (the machine is on a frame construction, is driven in X via 2 motors and thus allows to be placed completely over a part to be machined). or simply want to do engraving or drilling then they simply work on a flat base, on which they then attach e.g. an MDF plate, which they once overfrave plan and are then able to work up to approx. +-0.02mm exactly in depth. All machines are supplied with coloured energy chains on all axes due to improved cable guidance. Furthermore, all machines are protected with a double-secured emergency exit button. Another is located directly at the controller. Basic equip ...
Specifications / Technical Data S-400 CNC Router / CNC milling machine / Engraver With the High-Z CNC-router / engraver you purchase an allround talent in TÜV-certified quality. If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc milling machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc-machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc milling / engraving machines are equipped with an emergency stop button. An additional emergency stop you fin ...
Specifications / Technical Data S-400 CNC Router / CNC milling machine / Engraver With the High-Z CNC-router / engraver you purchase an allround talent (optional WIN PCNC Economy, USB or professional). If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc milling machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc-machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc milling / engraving machines are equipped with an emergency stop button. An additional ...
Specifications / Technical data S-400/T CNC-Portalfraesmaschine / Engraving machine Granite, marble, slate, soapstone engraving, photoengraving, fraesen... With the T-variant of the High-Z CNC-Fraesmachine you acquire old-guarded technology with the certain i-Tuepfelchen in TUeV-Qualitat. The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circulation spindles used, the High-Z/T CNC-Fraes machine achieves a fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This means engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can see a video about empty journeys with the new High-Z/T. This makes t ...
Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine Grabite marble soapstione slate engraving photo engraving, milling .. With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machi ...
GranitoGrav photo-gravusystem for granite/tombstones and glass (also suitable for glazes and bottles) The CNC unit for photo engraving in stone and glass. The CNC-Fraesmaschine Series High-Z/S-400T with CNC module GranitoGrav incl. Software at a sensational price. Whether on gravestones, commemorative plaques, tiles, glass, mirror glass ... Load colour photos or photos in black and white into the CAD-CAM ConstruCAM 3D software via the specially developed module. You can then enter the output of the desired size and have milling paths calculated. This created file is opened in the machine's control software and therefore sent to the machine. - More is not necessary! It's really easy ! No programming skills are required ! The CAM software works out your data in a practical and short time and thus creates first-class photos in all the above-mentioned materials with the CNC machin ...
GranitoGrav photo-gravusystem for granite/tombstones and glass (also suitable for glazes and bottles) The CNC unit for photo engraving in stone and glass. The CNC-Fraesmaschine Series High-Z/S-400T with CNC module GranitoGrav incl. Software at a sensational price. Whether on gravestones, commemorative plaques, tiles, glass, mirror glass ... Load colour photos or photos in black and white into the CAD-CAM ConstruCAM 3D software via the specially developed module. You can then enter the output of the desired size and have milling paths calculated. This created file is opened in the machine's control software and therefore sent to the machine. - More is not necessary! It's really easy ! No programming skills are required ! The CAM software works out your data in a practical and short time and thus creates first-class photos in all the above-mentioned materials with the CNC machin ...
GranitoGrav photo-gravusystem for granite/tombstones and glass (also suitable for glazes and bottles) The CNC unit for photo engraving in stone and glass. The CNC-Fraesmaschine Series High-Z/S-400T with CNC module GranitoGrav incl. Software at a sensational price. Whether on gravestones, commemorative plaques, tiles, glass, mirror glass ... Load colour photos or photos in black and white into the CAD-CAM ConstruCAM 3D software via the specially developed module. You can then enter the output of the desired size and have milling paths calculated. This created file is opened in the machine's control software and therefore sent to the machine. - More is not necessary! It's really easy ! No programming skills are required ! The CAM software works out your data in a practical and short time and thus creates first-class photos in all the above-mentioned materials with the CNC machin ...
