BAYKAL HGL 2100 x 6.0

sheet width: 2050 mm
plate thickness: 6.0 mm
thickness at Niro-steel: 4.0 mm
distance between columns: 2100 mm
down holder: 12 Stück
no. of strokes: max. 26 Hub/min
cutting angle: 1.6 °
back stop - adjustable: 750 mm
Control: ELGO
oil volume: 120 ltr.
total power requirement: 11.0 kW
weight: 3900 kg
range L-W-H: 2860 x 2100 x 1560 mm
with only approx. 400 operating hours ()
Original price approx. 30.000 euros
Special price upon request

Features:
- Robust electro-hydraulic oscillating shear
- ELGO digital display, Model P9521,
for electric backgauge
- NC-controlled electric motor-driven material/backgauge
Travel range continuously adjustable backgauge X = 750 mm
Backgauge with backlash-free ball screw
Travel speed: 100 mm/sec
- 1x sturdy side stop
with T-slot and millimeter scale
- 1x sturdy support arm
- Electric cut length limiter
Cut length limiter to increase the number of strokes per minute
- Manual kerf adjustment
Operated centrally from the right-hand side stand
- Front support plates with ball bearings
- Front finger/interference guard
- Jog mode with push buttons on the left control panel
- Protective guard = safety device behind the machine
- Operating instructions (PDF)
