automatic punching machine used for sale

This AMADA EMZ 3610 NT was manufactured in 2008. It features a press force of 300 kN, can handle material up to 4.5 mm thick, and supports a maximum table load of 160 kg. The machine includes 45 turret stations with auto-index and achieves a stroke rate of 1000 strokes/min. If you are looking to get high-quality punching capabilities consider the AMADA EMZ 3610 NT machine we have for sale. Contact us for more information.

This TRUMPF TRUMATIC 500 was manufactured in 1998. It features a maximum punching force of 220 kN and can handle sheet thicknesses up to 6 mm. The machine accommodates workpieces up to 150 kg, with a working range of 2500 mm on the X-axis and 1250 mm on the Y-axis. It requires a 400 V power supply and 6 bar of compressed air. Contact us for more information about this machine.

This 3s Finn-Power C5 + Compact Express CNC punching machine was manufactured in 2007. It features a working area of 2500 × 1250 mm and a punching force of 30 tonnes. With 20 tool stations and a maximum tool diameter of ~89 mm, it offers efficient operation. Consider the opportunity to buy this Finn-Power C5 + Compact Express CNC punching machine. Contact us for further details.

Cart beam punching machine / travelling head die cutting press 25 ton, 1600 x 500 mm, punching head 500 x 500 mm with 2-hand touch triggering, with light curtain approx. 1500 kg

Plate punching machine 70x100 Brand: Grapho Metronic

new EcoCut V8 perforated sheet punch consisting of: - Eccentric punch with drive - Infinitely adjustable feed speed - Machine body: RAL 5003 / coarse structure / semi-gloss - Control cabinet: RAL 7035 / coarse structure / semi-gloss - Front panel: RAL 5003 / structure / semi-gloss - EcoOil Lubrication System for EcoCut Punching Machines - Integrated compressed air supply unit for EcoOil lubrication system - Machine table EcoCut for setting up automatic punching machine - Punching oil - standard 1 liter special cutting oil for optimal lubrication of all EcoCut tools - Round hole punching tool 7xd5 Sheet thickness steel :0.7 mm Sheet thickness aluminium :1,0 Sheet thickness front: 0.5 mm Colour: light grey/blue Total power requirement: 16 A Weight: 500 kg Dimensions: 910 x 1120 mm Projection: 280 mm Punching capacity 150 stroke/min Compressed air :2 - 5 bar Steples ...

Reference ID: PP-56668 Category: Flatbed Die Cutter Manufacturer: Bobst Model: SPO 1600 Year: 1986 Speed: 6000 sheets/h Max. size: 160 × 110 cm Min. Size: 60 × 52 cm Condition: Good Location: Europe Availability: Immediately

CNC punching machine manufactured in 1995. This TRUMPF TRUMATIC 500 features a maximum punching force of 220 kN and a working area of 2,500 mm. It is multitool capable and comes with 2 tools in a cassette for commissioning. If you are looking to get high-quality punching capabilities, consider the TRUMPF TRUMATIC 500 machine we have for sale. Contact us for further details.

This 3-axis TRUMPF Trumatic 120R was manufactured in 1991. It features a maximum punching force of 150 kN and a machine weight of 4,300 kg. With an estimated operational lifespan of 40,000–60,000 hours, this machine is designed for durability. If you are looking to get high-quality punching capabilities, consider the TRUMPF Trumatic 120R CNC punching machine we have for sale. Contact us for further details.

CNC punching machine manufactured in 1999. This TRUMPF TRUMATIC 500 features a maximum punching force of 220 kN and a working area of 3,000 mm by 1,600 mm. It is equipped with a Bosch control system and is multitool capable. If you are looking to get high-quality punching capabilities, consider the TRUMPF TRUMATIC 500 machine we have for sale. Contact us for further details.

CNC punching machine manufactured in 1991. This TRUMPF TRUMATIC 120R features a punching force of 15 tons and a maximum punching diameter of 38 mm. It offers a working area of 1000 x 2000 mm with repositioning and includes a complete set of tools. If you are looking to get high-quality punching capabilities, consider the TRUMPF TRUMATIC 120R machine we have for sale. Contact us for further details regarding this machine.

Single cylinder punching machine equipped with three separate working stations for different tasks: punching, shearing flat bars, and cutting angles. Punching capacity: 36t. Diameter 28 mm in 10 mm thickness. Flat bar shearing: 350 x 6 mm. 200 x 13 mm. Angle cutting at 90: 80 x 80 x 8 mm. Angle cutting at 45: 50x50x6mm.

A die-cutting and embossing machine Woschnik + Partner is available. Stroke rate: 9000/h, max. sheet dimensions X/Y: 820mm/1130mm, min. sheet dimensions X/Y: 360mm/400mm, gripper margin adjustment: 10mm-17mm, closing frame dimensions X/Y: 820mm/1134mm, max. die-cutting dimensions X/Y: 800mm/1120mm, cutting rule height: 23.8mm, max. punching force: 4000kN. Machine dimensions X/Y/Z: approx. 8000mm/2650mm/2950mm, weight: approx. 30000kg. Documentation available. An on-site inspection is possible.

Non-stop sheet feeder with pre-stacking device Non-stop roller towel display Mechanical double-sheet inspection Side marks on the operating and drive side Strip insertion device in the delivery Standard stripping frame Punching Frame Stripping station Touch screen control Without compressor

A hydraulic sheet punching machine Indumasch without sheet manipulation axes, but with CNC backgauges for manual sheet positioning, is available. Punching force: 40t, max. sheet thickness: 10mm, stroke rate: 150/min, max. punching diameter: 105mm, working dimensions X/Y: 1000mm/750mm, positioning accuracy: 0.1mm, weight: approx. 3500kg. Without tools. The controls were overhauled in 2014. Documentation available. An on-site inspection is possible.

• Manufacturer: Peddinghaus • Model: Peddimax 601 • Year of construction: 1993 • Machine type: Hydraulic punching and shearing machine (Ironworker) • Condition: Used, functional, signs of wear and tear • Punching force: approx. 60 t • Punching speed: approx. 16 strokes/min • Motor power: 5.5 kW • Operating pressure: approx. 250 bar • Electrical connection: 400 V / 3-phase • Capacities: • Flat steel up to approx. 400 x 16 mm • Angle steel machining possible • Hole punching up to approx. Ø30 mm (depending on material) • Notching and profile editing integrated • Equipment: • Extensive tool package (punches & dies in various sizes) • Foot control • Robust industrial design • Machine weight: approx. 1,780 kg • Dimensions (L x W x H): approx. 1540 x 900 x 1900 mm • Areas of application: • Metal constructi ...

TMZ 6000 E-106 - the cutter year 1991 Size max. 76 x 106 cm pressure 300 t max speed 5,500 sh/h Min. thickness 250 g max. board 3 mm max corrugated board 6 mm no stripping Weight 11.000 kg good condition

Reference ID PP-57800 Category Flatbed Die Cutter Manufacturer Bobst Model SP 130-E Year Built 1985 Color - Impression - Working Hours - Speed 7000 sheets/h Max. size 130x92 cm Min. size 58x45 cm Condition Good Location Europe Availability Immediately

Key data: 165 kN, 6 mm, 1250 mm

The machine was purchased directly from Trumpf in 2015. It was a demonstration machine from 2012, which had previously been used in the Trumpf training workshop (there only a few operating hours). Later, it was used in single-shift operation in the housing production of welding machines. Therefore, only 15700 operating hours. Exclusively in the sheet metal sector, especially sheet steel 1.25 and 2.0mm, occasionally 3mm. No stronger material. No known defects, machine is currently still in use, available from May 26. Reason for sale: Discontinuation of production. The "Compact Edition" of the TP1000 is optimized for a part size of 1250x1250. Larger formats can be done with the "Reset" function, additional tables are necessary. The outstanding advantage of the "Compact" machine is the small space requirement of only 4.13 x 5.84 m. The machine is equipped with almost all availab ...

Auction-ID: A1-41275-2

AMADA Aries 222 – CNC Punching Machine General data: Manufacturer: AMADA Model: Aries 222 Machine type: Punching and perforating machine for sheet metal Weight: approx. 2000 kg Dimensions (L x W x H): approx. 3000 x 1500 x 2000 mm Technical details: Pressing force: 20 tons Maximum sheet size (without repositioning): not specified Control system: CNC Amadan 03P Turret configuration: typically equipped with a 10-station tool turret for fast tool changes Description: CNC punching machine AMADA Aries 222 designed for processing and perforating sheet metal. The machine is equipped with a turret system allowing quick tool changes and efficient production, making it suitable for industrial sheet metal fabrication. Auction-ID: A7-45351-6

Offered is a hydraulic punching machine: Punching force: 100tons (Tm), max. punching cross-section: 2350mm², punching capacity (standard): Ø50mm at 15mm material thickness, punching depth: 500-800mm, incl. special accessories: round punch: max. Ø80mm at 9mm, max. Ø100mm at 7.5mm, square punch: 50mm at 12mm, 60mm at 9.5mm, 70mm at 8mm, rectangular punch: max. 90 x 25mm at 10mm. Inspection possible by appointment.

Equipped with manual; about 400 operating hours, little used; approx. 2500 kg Auction-ID: A1-41991-73

c.a 2000kg Auction-ID: A1-41991-95

A Trumpf punching machine still in operation, including a Trumalift loading and unloading unit that has not been used for a longer period, is available. 1) CNC punching machine Trumpf TruMatic 500, year of manufacture: 1993, max. punching force: 220kN, max. sheet thickness: 6.4mm, max. workpiece weight: 150kg, max. punching diameter: 76.2mm, simultaneous motion: 108m/min, stroke rate: 900/min, machine dimensions X/Y/Z: approx. 6700mm/5800mm/2200mm, weight: approx. 11000kg. 2) Trumpf Trumalift SheetMaster 1250 loading and unloading system, year of manufacture: 1993, max. sheet dimensions X/Y: 2500mm/1250mm, max. sheet thickness: approx. 8mm. Documentation available. An on-site inspection is possible.

Finn-Power A5-25 FB Punching Machine Type: Punching machine Manufacturer: Finn-Power Model: A5-25 FB Year of manufacture: 1999 Punching capacity: 23 t Max. sheet thickness: 4 mm Approx. machine weight: 12,000 kg Approx total dimensions (L x W x H): 6000 x 6000 x 2000 mm X/Y-axis feed rates: 2500/1250 mm JETCAM software Tools: Included Brush table Max. hydraulic pressure: 300 bar Power supply: 3 x 400 V, 50 Hz Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-45225-6

Punching cylinder 1964 56 x 77 cm in production available: immediately located: Germany

Reference ID PP-58237 Category Flatbed Die Cutter Manufacturer Bobst Model SP 142-ER Year Built 1985 Color - Impression - Working Hours 75690 Speed 6000 sheets/h Max. size 142 x 102 cm Min. size 70 x 50 cm Condition Good Location Europe Availability Immediately Machine Description Double Stripping working hours 75690

with Fanuc 18P-C

Technical specifications of the accessories Accessories: Press protection grille Manufacturer: LEINHAAS – NILSON, 646 Gelnhausen Type: Nilson Press Guard SDF Factory No.: 1120 Year of manufacture: 03/1979 Configuration Execution: Mechanical press protection grille Auction-ID: A1-45711-112

Technical data Max. pressure: 30 tons Number of strokes: 100–600 Drive power: 0.96–5.5 kW Frequency: 50/60 cycles Control Current: 24 V AC Compressed air connection: R 1/2\" Operating pressure: 6–10 bar Adjustable stroke: 8-40 mm Adjustable ram height: 40 mm Belt running height from clamping plate: 50 + 100 mm Max. cutting thickness / drawing depth: 4 mm (according to table) Configuration Machine height: approx. 2150 mm Width: approx. 1200 mm Depth: approx. 1160 mm Weight: approx. 2500 kg Suitable for: Stamping and forming work up to 30 t press force Auction-ID: A1-45711-100

Technical data Manufacturer: Schroeder & Bauer Type: HB5 Year of Make: 1982 Machine No.: 5211 Operating voltage: 380 V Frequency: 50 Hz Power: 1.5 kW Rated current: 3.6 A Configuration Type: Industrial press (electric drive) Auction-ID: A1-45711-131

Technical data Manufacturer: Kaiser Pressen, Pforzheim-Kieselbronn Type: PV 50 Year of Make: 1975 Press force: 50 t Stroke rate: 95–400 rpm Stroke: 8–60 mm Plunger adjustment: 60 mm Configuration Execution: Eccentric Press Feed: Electronic roller feed Manufacturer feed: Zehnder & Sommer Automation Model: EV 12 – 22 AK-ZZ Max. strip cross-section: 150 mm² Auction-ID: A1-45711-107

Technical data Machine Type: Automatic punching machine Manufacturer: Bruderer AG, Switzerland Model: BSTA 40 Year of Make: 1978 Compressive force: 40 t Stroke rate: 50–1200 strokes/min Stroke adjustment: 13–57 mm (stepped) Tool installation height: 452 mm Tool installation height adjustment range: 60 mm Outlet columns (longitudinal): 210 mm Outlet columns (transverse): 680 mm Clamping surface at the bottom: 680 x 550 mm Clamping surface at the top: 680 x 400 mm Bed opening: 640 x 220 mm Strip running height: 60–140 mm Configuration Feeder: BBV 200/120 Max. belt width: 200 mm Max. strap thickness: 6 mm Feed length: 0–120 mm Soundproofing booth: DRIVER FKE 500/110BM (YOC 03/2001) Tool monitoring: SIEGFRIED Press-Processor SPP 450 Auction-ID: A1-45711-319

Technical data Max. pressure: 30 tons Number of strokes: 100–600 Drive power: 0.96–5.5 kW Frequency: 50/60 cycles Control Current: 24 V AC Compressed air connection: R 1/2" Operating pressure: 6–10 bar Adjustable stroke: 8-40 mm Adjustable ram height: 40 mm Belt running height from clamping plate: 50 + 100 mm Max. cutting thickness / drawing depth: 4 mm (according to table) Configuration Machine height: approx. 2150 mm Width: approx. 1200 mm Depth: approx. 1160 mm Weight: approx. 2500 kg Suitable for: Stamping and forming work up to 30 t press force

Motor power: 4 kW Maximum depth gauge range (Y): 500 mm Maximum Range Side Stop (X): 1000 mm Maximum cutting force: 280 kN (400 kN) Maximum punching diameter: 105 mm Maximum sheet thickness: 6 mm Working area: 500 x 1000 mm Maximum sheet metal size (with turn): 1000 x 2000 mm Stroke length (adjustable): 0 – 40 mm Auction-ID: A7-44864-8

Extension / distance slide center to frame: 320 mm Sheet thickness / sheet thickness: 3.2 mm Cutting surface / cutting capacity: 1600 mmx2 Distance table pestle/ distance table slide: 417 mm Stroke adjustment / adjustment of stroke: 16...125 mm Stroke number/ number of strokes: 45 / min Pestle adjustable/adjustment of slide: 80 mm Table size / surface of bed: 800 x 630 mm Bumper size / surface of ram: 500 x 400 mm Slope of the stand / inclination of coulmn: 25 Power of main motor power: 4 kW Weight: 2.5 Specification: C-frame punching press, used

<br><br><br>Still in operation: Yes<br>Available: immediately

Standard equipment; Ready

Eccentric C stand press, little used C frame - eccentric press, used Type: PED 63.3 S4 manufacturer: WMW Year of construction: 1994 Pressing power / rated pressure: 63 t Sheet thickness / material thickn. 3.2 mm Table size / surface of bed: 800 x 580 mm Hole in the table / hole in table: 300 mm diameter. Stroke / stroke of slide: 8... 120 mm Number / number of strokes: 56 / 90 / min Tappet adjustment / adjustment of slide: 70 mm The maximum distance between Table and plunger / max distance between table and slide: 560 m Projection / Cap: mm Power of main motor / power of main motor: 6 kW Weight / weight: 5.5 t

The turret press AMADA EUROPE 245 was produced in 2000 (machine installation: 2001). The price of the machine includes: installation and training in the use of the machine Punching machine technical data: - CNC control: FANUC 18 i-P - working time: 35,000 h - pressure: 20 t - work table: X = 600, Y = 400 - maximum punching format without intercept and with 31 stations head: 1020 x 1290 (Y-10; Y1010 T2XX; Y-50; Y970 T3XX) - maximum size of a punched sheet with an intercept: 1020 x 2540 mm - maximum size of the sheet to be punched with the intercept + 1 revolution (optional): 1500 x 2540 mm - maximum sheet thickness on the ball table: 6 mm - maximum sheet thickness on the brush table: 3 mm - maximum allowable weight on the table: 100 kg - punching accuracy: + -0.1 mm - positioning accuracy: + -0.07 mm - number of pneumatic clamps / grips: 2 - number of axes controlled s ...

With the universal hand punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work

pressure: 110 t : Ø 40x20 mm throat: 500 mm engine output: 9 kW no. of strokes: 28 Hub/min stroke max.: 80 mm weight: 3150 kg Accessories / equipment: - punching table The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

With the universal hole punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work.

Schuler PE4s 50/800 High Speed Press Manufacturer: Schuler Type: PE4s 50/800 High-speed press 61/21 600/3 Pressing force: 50 t Projection: 800 mm Stroke rate /min: 125-300 Plunger stroke: 40 mm Kohler unwinding reel 500.1 M We sell a large number of paternosters. The devices are in operation until 30.06.2021. After the purchase, there are also the documents for it From 01.07.21 the devices are ready for collection. Dismantling and transport by the buyer. Location is Hildesheim The dismantling, loading, as well as transport can alternatively be offered by us. In addition to about 50 paternosters, countless other machines are available. After purchase, the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying.

Printing capacity max. 300 t, table 1500 x 1000 mm, stroke max. 500 mm

Universal - NPR-55U Stanze Knee lever punch -Punching of paper, cardboard and plastics. -for simple stamping -The cutting blades can be recorded from the shaft -The cutting blades can be created also not attached just under the pressure plate. -The pictured tools are not part of the offer.

! KNIFE RETURNS! Directly from the manufacturer, the original from the patent holder of Apfel GmbH. Also available in other sizes! Dimensions: W=1040 mm, D=1050 mm, H=2140 mm two-tone powder-coated Housing : gentian blue structure (RAL 5010) Extracts : grey-white structure (RAL 9002) Payload per extension 900 Kg Weight: approx. 517 kg Fully assembled as a set included 6 Tool Holders WKH 210 6 Tool Holders WKH 211 5 Tool Holders WKH 212 5 Tool Holders WKH 213 4 Tool Holders WKH 214 4 Tool Holders WKH 215 Dimensions: 1,040 w x 2,140 h x 1,050 t Curb weight: 517 kg Structure powder-coated in Gentian blue RAL 5010 (body) and Off-white RAL 9002 (excerpts)

COLOMBO AGOSTINO 225.400 coil stamping and punching line was built in 2006 in Italy by Colombo Agostino S.p.A. Its extensive machining capabilities and high reliability make it an excellent choice for series production of components, such as washing machine parts or automotive parts. The production process is fully automatic, thanks to a high-speed feeding system. It unwinds the sheet metal from the coil towards the work station, which features precision tools operating at a maximum force of 400 tonnes. The monolithic design of the machine further ensures high durability and stress-free operation. The COLOMBO AGOSTINO coil-fed punching machine weighs 75000 kg. The coil punching line is complete and consists of the following machines: – 400 t eccentric press: COLOMBO AGOSTINO – sheet metal decoiler: DEF CT 3/128 – coil lift table – sheet metal straightener RA 3000/4-8/120 A ...

Alu window profiles Punching tool for end hole ventilation 4 stations
