Hydraulic Shear ATLANTIC ATS 3000

Hydr. Guillotine shears ATLANTIC, ATS 3000, year 03, 25448
Technical data:

- max. working width 3050 mm - max. cutting capacity St 40 0.5 - 6 mm
- Cutting angle adjustable mot. 0,5 - 3 °
- Cutting gap adjustment by hand
- Number of hydraulic hold-downs 18 pcs
- Motorized backgauge with positioning control SP8 10 - 750 mm
- Stroke rate depending on cutting angle and cutting length 9 - 17 rpm
- Hydraulic drive 400 V / 7.5 kW
- Table height 770 mm
- Space required including back gauge, without front support arm
- approx. W 3750 x H 1600 x D 2450 mm
- Weight approx. 4500 kg
- with: - E-foot switch
- Cut line illumination
- Angle stop
- 2 support arms
- Rear area protection with side grille + light barrier
seller offer No. resale 170310250
