agie cut used for sale

Agie Charmilles Form E 600 EDM Wire Cutting Machine C axis X, Y, Z axis: 600 x 400 x 400 mm Working table.: 800 x 600 mm Maximum workpiece weight:: 1000 Kg Machine is in like new condition

Machine is in very good condition X : 600 mm Y : 400 mm Z : 350 mm

Agie Charmilles CUT30P EDM Wire Cutting Machine Axis movement: X, Y, Z : 600 x 400 x 350 mm Maximum workpiece size : X, Y, Z 1050 x 800 x 350 mm

X axis (longitudinal) 400 mm Y axis (transverse) 250 mm Z axis (vertical) 256 mm Max length of the piece 860 mm Max workpiece width 580 mm Maximum workpiece weight 850 kg Type of the CN Agiematic Length of the tank 810 mm Width of the tank 580 mm Height of the tank 250 mm Max height of the piece 250 mm Automatic threading Yes Weight approx. in kg. 2350

Agie Agietron Integral 3 EDM Wire Cutting Machine X/Y/Z : 500/350/500 Work tank dimensions (mm) X/Y/Z- 860/620//350 Work table dimensions (mm) 800 x 600 Max work piece weight 800 kg Max. electrode weight 200 kg 28 Head Tool Change Generator power 90 A

AGIE AGIECUT EXCELLENCE 2F Wire cutting edm machine ACCESSORIES INCLUDED • Wire Press 214MM GTAI214300 • Rectified side grip press • GTV40 Precision Ground Press – Vertex • Grip bar for part support • Magnetic 20MM Kit 6 Units • Chiller for water temperature control – ICS Cool Energy GENERAL CONDITION • New equipment in 1999 • Completely refurbished and overhauled in 2019 • After revision it had only 152 hours of use • The Machine is in perfect working order, complying with the demanding factory specifications (Annex 1) • Can be proven in operation

Technical details x-way 350 mm y-way 250 mm z-way 256 mm Max. Workpiece dimensions 750 x 550 x 250 mm U-axis +/- 70 mm V-axis +/- 70 mm Rapid traverse X / Y / Z axis 1.5 / 1.5 / 0.6 m / min Rapid traverse U / V-axis 0.6 m / min Max. Taper 30 ° / 100 mm control AGIEVISION Wire diameter 0.1 - 0.33 mm Wire speed 60-300 mm / sec Wire feeder semi-automatic Total power requirement 9.1 kVA Machine weight approx. 3.6 t Dimensions L x W x H 2.21 x 2.21 x 2.22 m

AGIECUT CLASSIC 2S wire cutter 2004 AGIECUT CLASSIC 2S

max. workpiece dimensions length x width x height 750 x 550 x 250 mm X / Y / Z axes 350 / 250 / 256 mm

AGIE CHARMILLES wire cut AC2 VERTEX year `2010

X-Axis travel 350 mm Y-Axis travel 250 mm Z-Axis travel 300 mm X-Y-Z axes speed 6 - 6 - 15 m/min Table length 500 mm Table width 400 mm Work tank size 790 x 530 x 350 mm Workpiece weight 500 kg Linear tool changer 4 (Std. tooling) / 5 (Combi tooling) Rotary tool changer 16-80 pos. (Std. tooling) / 32-160 pos. (Combi tooling) Dimensions L 1900 x W 1690 x H 2398 mm Weight 2800 kg

This AGIE CHARMILLES CUT 20 Erosion machine was manufactured in the year 2008. It is equipped with a Charmilles CNC control unit.

Wire EDM AGIE CHARMILLES CUT 30P Used machine in excellent condition Year 2010 dimension table 950 x 630 mm working tank 1260 x 945 x 675 mm max size piece 1050 x 850 x 350 mm max size weight 1000 Kg. Axis X 600 mm Y 400 mm Z 350 mm U 100 mm V 100 mm Operating System Windows XP Overall dimension 3100 x 2800 x 2325 mm

There are three AGIE CUT CNC 100 available, year of construction 1/2/3: 1980/1979/1979, with accessories, machine 1 and 2 are functional, machine 3 serves as a source for spare parts.

Machine is in very good condition X movement (mm) : 350 Y movement (mm) : 255 Z movement (mm) : 255

This AgieCharmilles CUT 20 P Erosion machine was made in 2015 in China.

table-size: 800 x 500 mm workpiece height: +-30º/510 mm travel x / y / z: 800 x 550 x 510 mm workpiece sizes: 1300 x 1000 x 510 mm workpiece weight: 3.000 kg wire dia.: 0,10-0,33 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 350 mm y-axis: 250 mm z-axis: 256 mm U-axis: +/-70 mm V-axis: +/-70 mm dimension of workpiece: 750x550x256 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 950 mm table width: 630 mm ampere: 35 A max. size of workpiece LxWxH: 450 x 300 x 100 mm x-axis: 600 mm y-axis: 400 mm z-axis: 350 mm Control: Windows XP SP2 range L-W-H: 310 x 280 x 232 cm workpiece weight: 1000 kg total power requirement: 11 kVA weight of the machine ca.: 4,44 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 550 mm y-travel: 350 mm z-travel: 400 mm U-travel: 550 mm V- travel: 350 mm volume: 1200 L material diameter: round: 1200x700x400 mm workpiece weight: 1500 kg inclination: +/-30°/400 mm ° thread dia.: 0,10-0,33 Bobbin Weight max.: 25 kg total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

voltage: 3 x 400 V weight: 3600 kg output: 9 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC EDM machine Fabr. AGIE type Agietron 200 CSeries 03, device 04, list of devices 356804.5 built in 1987Travel X: 500 mmTravel Y: 350 mmTravel distance Z: 500 mmSupport surface: 800 x 630 mmMax. Workpiece dimensions: 1000 x 700 x 320 mmInner container dimensions: 1070 x 740 x 420 mmWorkpiece weight approx. 1200 kgMax. Weight of the electrode: 400 kgDistance table - quill: 180/680 mmPosition deviation (PA): 0.005 mmaverage position spread (PS): 0.003 mmmean inverse span (u): 0.002 mmResolution: 0.001 mmNumber of flushing connections: 10manual flushing: 1/20 l / minautomatic dosing spray: 8 / 3-800 ml / minControl mode: Multi-taskingSimultaneously controllable axis: 4Simultaneously controllable rotative and linear axes: C with X, Y, ZStorage Capacity: 3.5 , MS-DOS, 720KBScreen: color 14 Interface: RS 232 / CV 24Rated current: 60 ARemoval rate: 450/590 mm3 / minNumber of channels: 1Agiepu ...

CNC spark erosion machine make AGIE type AGIETRON 100Device list 357914.1, series 015, device 005Technical specifications:Table size: 580 x 450 mmwith 3 T-slots 10 mmX axis: 350 mmY axis: 250 mmWeight of the erosion machine: 2275 kgWith- Agiematic T control, device list 813834.9, series 008, device 008, 290 kg 1.25 kVA- FSK, device list 813864.6, series 008, device 009, 65 kg- ATK 35, device list 144170.8, series 016, device 009, 220 kg- Generator Agiepuls 60M, device list 814104.6, series 008, device 008, 305 kg 3.4 kVA- Dielectric unit DA 100, device list 369964.2, series 020, device 009, 460 kg, 4.2 kVA + PD + GEN- tool changer- Cooling unit make HIROSS ICE 005, 230/1/50 serial no. 3293540001, 110 kgused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We  ...

x-travel: 350 mm y-travel: 250 mm z-travel: 256 mm max. size of workpiece: 750 x 550 x 250 mm U-axis: +/- 70 mm V-axis: +/- 70 mm rapid traverse X/Y/Z axis: 1,5 / 1,5 / 0,6 m/min rapid traverse U/V-axis: 0,6 m/min max. concentricity: 30° / 100 mm control: AGIEVISION wire dia.: 0,1 - 0,33 mm speed of wire: 60 - 300 mm/sec wire retraction: halbautomatisch total power requirement: 9,1 kVA weight of the machine ca.: 3,6 t dimensions: 2,21 x 2,21 x 2,22 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

AGIE AGIECUT EXCELLENCE 2 wire EDM machine built in 1999 in Switzerland, is used in the production of e.g. precision dies, tools and punches. For the machining of workpieces, the machine uses advanced electrical erosion technology which makes it possible to achieve difficult shapes in even the hardest materials. The use of this method further minimises or completely eliminates the need for other secondary processes, such as polishing. The AGIE EDM machine is equipped with a state-of-the-art AGIEVISION CNC controller and brushless axis servo motors to guarantee the highest machining accuracy and precision in the shortest possible time, with low energy consumption at the same time. The machine also comes with among others an integrated generator, a semi-automatic wire threading system and the AGIESETUP 3D measuring probe for automatic detection of the plane and position of the workpiece ...

table length: 500 mm table width: 350 mm ampere: 65 A Control: AGIEVISION 5 CNC total power requirement: 20 kW weight of the machine ca.: 4000 kg dimensions of the machine ca.: m A G I E (Switzerland) CNC - Controlled Wire Cutting EDM Machine Model AGIECUT PROGRESS V 3, Year 2007 Working range, X Y Z (=height) 500 x 350 x 426 mm Wire head, U-V axis (helical/taper cuts) + / - 30 °/ +/- 70 mm Resolution of axes 0.0001 mm Speed for positioning the axes up to 3 m/Min. Tolerances (If machine is new) 4 µ Workpiece dimensions, L x W x H max. 1.050 x 650 x 420 mm Max.weight of workpiece with/w.o. Dieelektricum 400/800 kg Clamping System Universal Beams with fixing holes Cutting wire Ø 0.2 – 0.33 mm Size of wire roll up to 25 kg Cutting speed of wire  ...

Defected Power cable for down head

This AGIE AGIEMATIC + AGIEPULS 60 HSF erosion machine was made in the year 2000. It is equipped with an Agie control unit. The machine has a table of 600 x 450 mm.

This AGIE AGIETRON INTEGRAL 3 EDM Wire Cutting Machine was built in the year 1998. The machine has a table of 800 x 600 mm.

This Agie Agietron Integral 2 Erosion machine was manufactured in Switzerland in 1994. It operates for a max. workpiece weight of 400 kg and max. electrode weight of 100 kg.

Spark Erosion Machine AGIE AGIETRON 250C used machine in excellent condition tool change 24 positions

Axes X/Y/Z: 350mm/250mm/350mm, workpiece dimensions X/Y/Z: 650mm/580mm/250mm, max. workpiece weight: 100kg. Inner dimensions of work bowl: 860mm/620mm/360mm, rotation: 60rpm, capacity: 415l, filter quality: 3μm-5μm. Dimensions X/Y/Z: 2689mm/1855mm/2593mm, empty weight: approx. 3200kg, filling weight: approx. 4200kg, control: AgieVision. Documentation available.

X-travel: 250mm, y-travel: 160mm, table dimensions: 420x250mm, max. workpiece height: 160mm, max. workpiece weight: 120kg, length: 1545mm, width: 1240mm, height: 1065mm, weight: 540kg, with documentation, the machine should be overhauled, an inspection is possible.

Wire erosion machine make AGIE type Agiecut AC 100Machine -No: 117 built in 1988Working area X: 300 mmWorking area Y: 200 mmWorking area Z: 250 mmTable length: 510 mmTable width: 580 mmWorkpiece dimensions: 810 x 580 x 250 mmWorkpiece weight max.: 200 kgWire diameter: 0.03 - 0.3 mmTotal power requirement: 10 kWWeight approx: 3.0 tonsWith- Agiepuls MM- Operating hours 33976 hrs.used, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Inv. Num. : 6319 Type: AGIETRON HYPERSPARK Producer: AGIE Created: 2006 Parameters: Control system: AGIEVISION Operating hours: 69006 h Switch-on hours: 31080 h Table dimensions: 600 x 450 mm Travel length of the X-axis: 350 mm Travel length of the Y-axis: 250 mm Travel length of the Z-axis: 350 mm Maximum table load: 400 kg Container size: 860 x 620 mm Equipment: Clamping solenoid 3x electrode holder Cooler Dielectric 8x dielectric filter Erowa clamping head

travel -x axis: 800 mm travel -y axis: 500 mm workpiece sizes: 1.300 x 1000 U/min ampere: 60 A workpiece weight: 3.000 kg Control: CNC VISION 5 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

AGIE AGIECUT 150 HSS CE Wire EDM machine YOM 1997 Control AGIEMATIC CF 50 SE AGIEPULS HSS Electric Control cabinet DA-19 Table dimensions: 560x445 mm Maximum travel length X-axis: 300 mm Maximum travel length Y-axis: 200 mm Maximum travel length Z-axis: 251 mm Travel length U-axis ( -): 30 mm Travel length V-axis ( -): 30 mm Maximum workpieces length: 810 mm Maximum workpieces height: 250 mm Maximum workpieces width: 580 mm Largest workpiece weight: 450 kg Minimum starting hole: 2,0 diameter Max. Threadable workpiece height: 220 mm Wire diameter: 0,1 - 0,33 mm Max. Wire spool weight: 16 kg Dimensions 2325x1620x2130 mm Machine weight: 2900 kg In production at the moment.

AGIE AGIECUT 150 Wire EDM machine YOM-not written, about 1995 Control AGIEMATIC CF 50 AGIEPULS MMD Electric Control cabinet DA-15/PF AGIE RC 123 Table dimensions: 560x445 mm Maximum travel length X-axis: 300 mm Maximum travel length Y-axis: 200 mm Maximum travel length Z-axis: 251 mm Travel length U-axis ( -): 30 mm Travel length V-axis ( -): 30 mm Maximum workpieces length: 810 mm Maximum workpieces height: 250 mm Maximum workpieces width: 580 mm Largest workpiece weight: 450 kg Minimum starting hole: 2,0 diameter Max. Threadable workpiece height: 220 mm Wire diameter: 0,1 - 0,33 mm Max. Wire spool weight: 16 kg Dimensions 2325x1620x2130 mm Machine weight: 2900 kg In production at the moment.

AGIE AGIECUT 100 D Wire EDM machine YOM-not written, about 1990 Serial No. 144 Control AGIEMATIC CD AGIEPULS MM Electric Control cabinet DA-15/AF AGIE RC 123 Table dimensions: 560x445 mm Working travel: X: 300 mm Y: 200 mm Z: 256 mm Wire diameter: 0.1 - 0.3 mm Axis U, V: ±30° Working detail dimensions: length:810 mm width:580 mm height:250 mm Working detail weight: 200 kg Machine weight: 2 910 kg Dimensions 1700x1550x2130 mm In production at the moment.

In addition to the highlighted features, it is worth mentioning the controlled C axis with EROWA connection. Electrode change with 14 positions. Monitor overhauled with new LCD screen.

This 3-axis AGIE AGIECUT CLASSIC S erosion machine was manufactured in 2000. It has impressive axis movements with x=350mm, y=250mm, and z=256mm, providing ample flexibility for handling erosion tasks. The machine accommodates a maximum piece size of 750mm in length, 550mm in width, and 250mm in height, and it can manage weights up to 200kg. The dimensions and capabilities make it suitable for a wide range of erosion processes, ensuring detailed and precise outcomes. The AGIE AGIECUT CLASSIC S machine we have for sale is designed for robust performance and precision. Contact us for more information about this erosion machine.

Description: serial number: 034-006 travels: X-axis: 350 mm Y-axis: 250 mm Z-axis: 350 mm C-axis: 0 - 60 rpm max. workpiece dimensions: 650 x 580 x 250 mm max. workpiece weight: 400 kg distance table - quill: 170 - 520 mm  , please also have a look at the video of this machine x-motion: 350 mm, y-motion: 250 mm, z-motion: 350 mm, control: Agiematic T, weight approx.: 2,600 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 2,500 x 2,600 mm

CONTROLS   CNC controls AGIE WORKING RANGE -WIRE CUTTING-   worpiece length max.: 750 mm   worpiece width (max): 550 mm   X-axis travel: 350 mm   Y-axis travel: 250 mm   U-axis travel: 70 mm   V-axis travel: 70 mm TABLE   workpiece load (max): 450 kg WIRE SYSTEM   wire diameter (min): 0.2 mm   wire diameter (max): 0.33 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2000 mm   space requirements -front/back-: 1700 mm   total height: 2200 mm   total weight approx.: 2500 kg

CONTROLS   CNC controls WORKING RANGE -CUBIC-   X-axis travel: 250 mm   Y-axis travel: 160 mm   Z-axis travel: 250 mm TECHNICAL SPECIFICATION   Table-size          : 480 mm   Table-size          : 330 mm   Adjustment of  x-axis: 250 mm   Adjustment of  y-axis: 160 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 1200 mm   space requirements -front/back-: 1200 mm   total height: 2500 mm   total weight approx.: 1000 kg

Filter cartridges for AGIE sinkers Electrolyte filter cartridge Filter cartridges NEW and org. Packed Technical data please clarify briefly Tel. . Electrolyte filter cartridge Price pcs. 85 € net Complete. Sentence 6 pcs. New and Org. Packed 480 € Net plus 19% tax, freight and packaging Pradler Machine Service Tel. 05242 / 43186

Die sinking machine make AGIETRON type EMS 3.30Year of construction 1979Table size: 630 x 500 mmgr. workpiece height: 340 mmAdjustment = X: 420 mmAdjustment = Y: 320 mmgr. workpiece weight: 8000 NReading option: 0.01 mmgr. distance of table quill: 700 mmWork container: 945 x 650 x 465 mmFeed travel = Z: 400 mmRapid traverse and servo speed: 600 mm / minOutreach: 500 mmAgiepuls generator: Type 60 L / DDLRated current: 60 APulse voltage: 100/150/270 V.Dielectric aggregate: Type DA 220Capacity: 450 mmWeight: 1540 kgvery little used, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

AGIETRON HYPERSPARK 2 HS Sinker 2008 Design with lowerable working container Work table with 50 mm hole grid travel X/Y/Z 350x250x350 mm -Workpiece size: LxWxH=650x580x250 mm or 820x420x250 mm Integrated C axis, for rotation, indexing and erosion Electronic laser measurement of all axes Detection of the electrode and workpiece position 1 set of documentation (CD + manuals) AGIEVISION 5 Control with multitasking DNC interface with transmission protocolXon/Xoff and LSV2 2 serial interfaces RS 232C for DNC and master computer LAN connection for data exchange via in-house network RJ45 3 drives: hard drive, 3 1/2" floppy disks, CD-ROM Without tool changer

AGIETRON IMPACT 2, built in 2002 AGIEVISION Control Travel: X = 350 mm, Y = 250 mm, Z = 350 mm Max workpiece dimensions (L x W x H): 650 x 580 x 250 mm x 820 x 420 x 250 mm Max workpiece weight: 400 kg Distance table to pinole: 170-520 mm Pinole with automatic chuck Mecatool Including Astrol electrode and pallet changer Working container can be reslid for optimum accessibility; Incl. C-axis for rotation, indexing and erosion (U=0-60 rpm); AGIE IPG high-performance generator with 72 A Removal rate copper/steel: 450 mm3/min Removal rate graphite/steel: 530 mm3/min Best achievable surface Ra 0.2 microns 10.4" LCD color screen, lifting keyboard and mouse, JOGBOX for the axis process 2r90di Machine weight (net): 3200 kg Machine dimensions (L x W x H): 2689 x 1855 x 2593 mm

Machine in perfect condition, currently in operation. Machine price with Erowa charger and magnetic plates

Agie KOPF 30 in good condition Make: Agie Modle: Kopf 30 Year: 1983
