Manufacturer:
(Category: 101-51)
Key data: 2300 mm, 1200 mm, 800 mm
Control Heidenhain ... TNC 530 Clamping table surface ... 2300 x 1600mm Axis X ... 2300mm Axis Y ... 1200mm Axis Z ... 800mm Spindle speed ... 30-12000 rpm. controlled axes ... 5 IKZ ... 20bar HSK 100 Max. spindle torque ... 200Nm Magazine spaces ... 10 Axis C ... ±185° Axis B ... + 60/-90° Rapid traverse ... 30m/min Machine weight... 23000kg L x W x H ... 4800 x 4750 x 4660mm Workpiece probe, spindle IMT 8kW/30 000rpm. In 2024 new spindle.
Incl. tool changer and the tool holders located inside, with chip conveyor and coolant system.Attention: The machine can be transported on a standard truck!Additional technical specifications: • Nominal current: 80 A • Table: with 9 slots • attached clamping plate, dimensions: 1200 x 810 mm • with three ALLMATIC machine vices, jaw widths: 160 mm
Key data: 635 mm, 510 mm, 460 mm
Vertical machining center Manufacturer: DMG Gildemeister Type: DMC 635 v eco Engine No.: 1537000170A Year of Make: 2009 Control: Siemens 810D Shopmill Axles: 3 Travels X: 635 mm Y: 510 mm Z: 460 mm Tool changer: 20 places SK 40 Speed: 20-8,000 rpm Drive power: 13/9 kW (40/100%ED) - Direct displacement measurement system X,Y,Z - Sealing air for measuring systems - Coolant blowing air switching - Table size 560x790 mm - Electronic handwheel Errors and prior sale excepted.
Incl. chip conveyor, incl. 3-D touch probe and incl. the tool holders located in the tool changer!Attention: without the machine vises seen in the photos!Attention: the machine can be transported on a standard truck!
Manufacturer: MAZAK Model No.: Variaxis i-800 NEO Year 2023 Condition Used Stock number 9210 Mazatrol Smooth Ai control system Work table length 800 mm Work table width 630 mm Maximum table load (uniform) 1000 kg Maximum vertical spindle speed 18000 1/min X-axis travel 750 mm Y-axis travels 890 mm Travel Z axis 600 mm Taper HSK A100 Number of axles 5 pieces Number of Stacking Positions 80 Pieces Machine height 3497 mm Machine length 2695 mm Machine width 4890 mm Machine weight 18080 kg Equipment: Chip conveyor Handwheel Blowing air on the workpiece Air cooling through the spindle Workpiece rinsing Oil Mist Separator (Gx1000) Smooth Cam AI M Renishaw RMP600 Workpiece Probe High pressure unit (70 bar) Camera in the machine working room Coolant coolers Renishaw PRIMO LTS Tool Probe
Attention: The machine can be transported on a truck up to 3000 mm wide!Additional technical specifications:• table with 5 slots• with mounted plate, plate dimensions: 900 x 550 mm• incl. vise, jaw width: 125 mm
Manufacturer KONDIA Model A-6 Year 2015 CNC HEIDENHAIN TNC 530 HSCI Table Table surface 800 x 400 mm. Number of T-Slots 3 T-slots (width, distance) 18.125 mm. Table-floor distance 885 mm. Table distance – spindle nose (min/max) 140 / 650 mm. Maximum weight allowed on table 450 kg. Routes and advances Longitudinal travel (X) 600 mm. Cross travel (Y) 410 mm. Vertical travel (Z) 500 mm. Fast forward X/Y/Z axes 30,000 mm./min. Head Spindle taper ISO 40 DIN 69871 Maximum spindle speed 12,000 rpm Spindle power 10 / 17 kW Autoloader Tools Chain Type Random Change Warehouse Positions 20 Maximum tool width with adjacent free positionsq 135 mm. Maximum tool width without adjacent free positionsq 85 mm. Maximum tool length 250 mm. Maximum tool weight 6 kg Equipment Internal cooling 20 BAR INCLUDED Chip evacuator INCLUDED Water gun cleaning parts INC ...
Attention: the machine can be transported on a truck up to 3000 mm width!Additional technical specifications:• Feed rate in X/Y/Z: 20 - 15,000 mm/min• Setup mode X/Y/Z: 20 - 2000 mm/min• with in total 32-station tool changer (2 x 16 places)• max. tool diameter when all slots in magazine 1 are occupied: 130 mm• max. tool diameter when all slots in magazine 2 are occupied: 80 mm• max. tool length from spindle nose: 315 mm• max. tool weight at automatic tool changing: 8 kg• max. total tool weight in magazine: 160 kg• T-slot spacing: 63 mm
Year of construction: 2010 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 500 Y-axis travel mm: 450 Z-axis travel mm: 400 C-axis degrees: 360º (0,001) B-axis degrees: 0º/108º (0,001) Rapid traverse m/min: 80/50/50 Milling/turning table nc: Table dimensions mm: Ø390 Maximum workpiece size (D x H) mm: Ø630x500 Max. workpiece weight kg: 200 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/87 Tool system Tool holder: HSK-A 63 Tool magazine slots: 30 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5 Equipment Chip conveyor Infrared probe Rinsing gun blowing air through spindle center selectable via M-function Signal lamp Laser tool measurement for measuring tool length and diameter Programmable coolant n ...
CHIRON MODEL FZ18W MAGNUM 4 axis Vertical machining center with rotopallet and double 4th axis 20 TOOLS ISO 40 Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kW X = 625 Y = 400 Z = 400 Rapids 40m/min Table area: 2 x 900 x 470 - TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos. - original HAWE hydraulic unit - FANUC 0M 1995 Can be inspected under power in our warehouse Mimu machine tools (Italy), X: 625, Y: 400, Z: 600, 4th axis: Yes, (2x) Tsudakoma 360 000 pos.
Year of construction: 2011 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 500 Y-axis travel mm: 450 Z-axis travel mm: 400 C-axis degrees: 360º (0,001) B-axis degrees: 0º/108º (0,001) Rapid traverse m/min: 80/50/50 Milling/turning table nc: Table dimensions mm: Ø390 Maximum workpiece size (D x H) mm: Ø630x500 Max. workpiece weight kg: 200 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/87 Tool system Tool holder: HSK-A 63 Tool magazine slots: 30 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5 Equipment Chip conveyor Infrared probe Rinsing gun blowing air through spindle center selectable via M-function Signal lamp Laser tool measurement for measuring tool length and diameter Programmable coolant no ...
x-travel: 762 mmy-travel: 460 mmz-travel: 460 mmtable surface area: 1.000 x 460 mmcontrol: Okuma OSP 20 M rapid traverse: 40/40/32 m/mintable load: 0,7 tturning speed range: 12000 U/minpower capacity - milling spindle: 22/18,5 kWmax. torque on the spindle: 198 Nmno. of tools in the magazine: 32 Stückinternal coolant system feed: 20/43 bartool taper: BT 40 weight of the machine ca.: 6,8 tdimensions: 2.22 x 2,9 x 2,75 mCNC- vertical machining centre with internal coolantFirst installation 2014- coolant through the spindel 15 bar, 20 ltr/min- air throug the spindle- chip conveyor- signal lamp- Dual tool change arm- external electric hand weel- tool lenght measuring and toolbreak detection- filter system- X- axis in gantry style- spindle oil cooler- thermal compensation spindel and bed- USB and Ethernet port- Hi-Cut Pro high speed control- 100 Zero offsets- thread millingThe data for this a ...
Year of construction: 2019 CNC controller: FS-31iB (MAPPS IVB) Axes X-axis travel mm: 1540 Y-axis travel mm: 760 Z-axis travel mm: 660 Rapid traverse m/min: 20 Worktable Table dimensions mm: 1700x760 Max. workpiece weight kg: 2000 Spindle Spindle speed rpm: 20000 Spindle drive power kW: 18,5/15/11 (10 min./30 min./cont) Spindle torque Nm: 81 (10%ED) Cooling Cooling through the Spindle Center bar: 70 Tool system Tool holder: BT 40 Tool magazine slots: 60 With free neighboring places mm: 125 With occupied neighboring places mm: 95 Max. Tool Length mm: 450 Max tool weight kg: 12 Tool-to-tool time s: 2.1 Equipment Electronic Handwheel Internal cooling lubricant supply Rinsing gun Signal lamp Tool measuring arm Mist collector Heat compensator Program restart Paper band filter Machine running times Under power: 35557 Spindle Working: 27278 Rat ...
Manufacturer DMG-MORI Model DMF 260 Year 2011 CNC SIEMENS SINUMERIC 840D Table Table surface 2,900 x 700 mm. Maximum weight on table 2,150 kg. Routes and advances Longitudinal (X-axis) 2,600 mm Transverse (Y-axis) 700 mm Vertical (Z-axis) 700 mm Fast forward of the axes (X,Y,Z) 40 m/min Working progress of the axes (X,Y,Z) 40 m/min Axle acceleration 4 m/s2 Head Revolutions 14,000 mm/min SK 40 Head Cone DIN 69872 Main engine power 18.4 / 14 kW Automatic tool loader No. of Charger Tools 30 Maximum tool length 300 mm Maximum tool weight 6 kg. Maximum tool diameter with adjacent free positions 130 mm Maximum tool diameter without adjacent free positions 80 mm Equipment Refrigeration 40 Bar / 600 l. INCLUDED Longitudinal chip evacuator INCLUDED Coolant cleaning gun INCLUDED Portable steering wheel INCLUDED Direct Measurement System INCLUDED Machine hours ...
x-travel: 500 mmy-travel: 450 mmz-travel: 400 mmcontrol: iTNC 530 HeidenhainMain spindle:: turning speed range - main spindle: 20 - 14.000 min/-1power capacity - main spindel: 18,9 / 14 kWmax. Torque: 100 Nmtool taper: HSK A-63 NC-Rotary table:: table surface area: 630 x 500 mmmax. table load: 300 kgSwivel range: -5 / +110 °rotation range: 360 °T-slots: 7x 14 x 63 mmtool magazin:: number of toolpositions: 30 pos.max. tool weight: 6 kgmax. tool diameter: 80 mmmax. tool-dia with free toolbox: 130 mmmax. workpiece length: 300 mmfeeds:: rapid traverse: 24 m/minFeed force: 4,8 kNfeed speeds: 1 - 24.000 mm/mintotal power requirement: 25 kVAweight of the machine ca.: 5,0 tdimensions of the machine ca.: 4,5 x 3,5 x 2,3 mDocuments: Chip conveyor: Coolantsystem: elektr. hand wheel: hydraulic system: elektr. hand wheel: exhaust fan: 3D quickSET: test probe: DMG Power Probe 60 CNC - Mi ...
Year of construction: 2015 CNC controller: Heidenhain TNC 640 Axes X-axis travel mm: 850 Y-axis travel mm: 520 Z-axis travel mm: 475 Feed rates m/min: 42 Rapid traverse m/min: 42 Acceleration in the axes m/s2: 5 Worktable Table dimensions mm: 1100x570 Maximum workpiece size (D x H) mm: H=800mm Max. workpiece weight kg: 1000 Spindle Spindle speed rpm: 14000 Spindle drive power kW: 20,3/14,5 (40/100%ED) Cooling Cooling through the Spindle Center bar: 20 Tank capacity: 600 Tool system Tool holder: SK 40 Tool magazine slots: 20 With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Chip-to-chip time s: 5.7 Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Direct m ...
Key data: 1270 mm, 610 mm, 720 mm
Inv. Num. : 9302 Type: MCV 1270 POWER Producer: MAS Created: 2002 Parameters: Control system: Heidenhain iTNC 530 Operating hours: 1000 h Tool magazine: 24 pieces Maximum vertical spindle speed: 10000 1/min X-axis travel: 1270 mm Y-axis travel: 610 mm Travel distances Z-axis: 720 mm Cone: ISO 50 Machine height: 3300 mm Machine length: 5000 mm Machine width: 3600 mm Machine weight: 11000 kg Equipment: Technical documentation Workpiece probes Tool probe IKZ (15 bar) 10/2020: Machine completely cleaned and repaired Air hoses of the machine replaced Tool/workpiece cooling hoses replaced Piston rod of tool magazine sealed Air/oil clamping distributor sealed Piston seal of tool clamping sealed at the top of the spindle Automatic lubrication of the machine tested 8/2022: Main power module from SIEMENS completely repaired AC/DC converte ...
Key data: 1600 mm, 1250 mm, 1000 mm
Vertical machining center Manufacturer: DMG Type: DMU 160 P duoBLOCK Year of Make: 2007 Control: Heidenhain ITNC 530 Axes: 5-axis simultaneous Travels X: 1600 mm Y: 1250 mm Z: 1000 mm Tool changer: 60 tool positions Speed: 18,000 rpm - HSK 63 - Probes - Tool measurement Blum Laser - Coolant tank 980 litres - IKZ 40 Bar - Chip conveyors - Electronic handwheel - Operating mode 4 - Preparation of 3-D Quickset (software) - Universal milling head with controlled A-axis Machine from Space Institute. Excellent condition. Errors and prior sale excepted.
x-travel: 1016 mmy-travel: 610 mmz-travel: 760 mmtotal power requirement: ? kWweight of the machine ca.: 7,5 tdimensions of the machine ca.: 3 x 2,5 x 3,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CNC controller: 3D-Control Siemens 840D Axes X-axis travel mm: 600 Y-axis travel mm: 500 Z-axis travel mm: 500 C-axis degrees: 360º (0.001) B-axis degrees: -5 / +110º Spindle nose distance - table surface mm: 600 Feed rates m/min: 80 Rapid traverse m/min: 80 Acceleration in the axes m/s2: 10 Worktable Number of pallets: 2 Table dimensions mm: 500x500 Maximum workpiece size (D x H) mm: 500x525 Max. workpiece weight kg: 240 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40%ED/cont) Spindle torque Nm: 130/87 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 980 Tool system Tool holder: HSK-A 63 Tool magazine slots: 60 Tool changer: Double gripper With free neighboring places mm: 130 With occupied neighboring places mm: 80 Max. Tool Length mm: 300 Max tool weight kg: 6 Chip-to-chip time: 4.5 Equipment ...
x-travel: 1016 mmy-travel: 610 mmz-travel: 760 mmtotal power requirement: ? kWweight of the machine ca.: 7,5 tdimensions of the machine ca.: 4 x 3 x 3,2 mTable clamping surface 1,270 x 590 mmmax. table load 1,350 kgfeed rate 15,000 mm/minrapid traverse 20 m/minTool holder ISO 4024-position tool changerChip conveyorIKZPreparation for IR - measuring probe ( Renishaw )SELCA controlThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 6000 Y-axis travel mm: 1200/1400 Z-axis travel mm: 1800 (H) / 1790 (V) C-axis degrees: 360º (0,001) A-axis degrees: ±180° B-axis degrees: ±180° Rapid traverse m/min: 30 Worktable Table dimensions mm: 6000x1235 Milling/turning table nc: Table dimensions mm: Ø2200 Max. workpiece weight kg: 3000 Table rotation speed rpm: 200 max. torque Nm: 4600 Spindle Spindle speed rpm: 8000 Spindle drive power kW: 33/24 (40%ED/cont) Spindle torque Nm: 382/278 (40/100%ED) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 900 Tool system Tool holder: HSK-A 100 Tool magazine slots: 60 With free neighboring places mm: 200 With occupied neighboring places mm: 104 Max. Tool Length mm: 460 Max tool weight kg: 25 Chip-to-chip time s: 9.8 Equipment Electronic Handwheel ...
x-travel: 640 mmy-travel: 600 mmz-travel: 500 mmcontrol: Siemens 840 D total power requirement: 19 kWweight of the machine ca.: 8 tdimensions of the machine ca.: 5 x 4 x 3 mNo. 5312:Vertical machining center DECKEL MAHO type DMC 64 V linearyear of construction 2007Working area: 640 x 600 x 500 mmDrive power: 13/19 kWEquipment:Table 850 x 600 mm ( WITHOUT the clamping devices shown )Preparation 4th axisProduction package / IKZ 40 bar:BFA 600 cooling lubricant cleaning systemIntegrated spiral chip conveyorSeparate scraper belt chip conveyordocumentationMiscellaneous:Spindle ISO 40Speed range 1-12,000 min-1Space requirement see sketchTransport dimensions approx. 6.5 loading metersWeight approx. 8.8 tonsThe machine is ready for operation with wear and tear due to age and use.Short video: https://www.youtube.com/watch?v=sDkgx4BYXeYSpecial price ex works EXW - free loaded on suitable truck - 1 ...
CNC-controlled vertical machining center AXA VSC-3-3000-M Year of Make: 1995 Control: Heidenhain TNC 407 Technical data: X-travel: 3000 mm Y-travel: 420 mm Z-travel: 480 mm Table size: approx. 3000 x 500 mm Spindle holder: SK40 Speed range: up to 6000 rpm 22-fold tool changer Coolant system Heavy-duty travelling column construction Special features: Additional angle/universal milling head 4-/5-axis machining possible Noc Eey U Hy Tjg S Rrgswg Flexible machining of complex workpieces Ideal for toolmaking, mechanical engineering and single part production Machine is in neat condition. Viewing under power possible by arrangement.
x-travel: 1350 mmy-travel: 560 mmz-travel: 510 mmControl: Heidenhain iTNC 530 total power requirement: 13 kWweight of the machine ca.: 5 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
For sale is a vertical CNC machining center STAMA MC015 based on FANUC ROBODRILL α-T14iA with FANUC 16i-M control. Equipment: 14-fold tool changer High-speed spindle BT30 / SK30 Tool Holder Coolant system Compact design FANUC CNC Control with additional swivel/dividing head 5-axis machining possible Technical data: Travel distances approx. X500 / Y380 / Z300 mm up to 24,000 rpm Year of construction 2000 Weight approx. 1800 kg
x-travel: 760 mmy-travel: 550 mmz-travel: 300 mmControl: RMS6V3.15 tool change unit: 25-fach tool taper: HSK E40 turning speeds: 42.000 U/mintable-size: 860 x 550 mmtable load: 800 kgtotal power requirement: 14 kWweight of the machine ca.: 5200 kgdimensions of the machine ca.: 2,5 x 2,1 x 2,55 m3-axis high-speed machining centre, Roeders RFM760, year of manufacture 2000, installation in 2001Key specifications:Roeders RFM760 high-speed machining centre with accessories (tool holders, tool shrink-fitter, etc.).The machine is fully operational, well-maintained, serviced and powered up (battery maintenance).• Spindle: Newly fitted in December 2022, in use until March 2023 – Estimated running time approx. 75 hours (de-registered by the company in March 2023)• Control system: Röders, software: RMS6V3.15 (211)• Operating system: Windows NT• Complete s ...
Key data: 2300 mm, 1400 mm, 1050 mm
Control Heidenhain ... TNC 530 Clamping table surface ... 1800 (1600x2500)mm Axis X ... 2300mm Axis Y ... 1400mm Axis Z ... 1050mm Spindle speed ... 10-10000rpm. Controlled axes... 5 IKZ ... 40bar HSK-A100 Max. workpiece weight ... 10000/5000kg Max. spindle torque ... 130/150Nm Axis C ... 360° Axis B ... ±110° Rapid traverse... 50m/min Magazine spaces ... 48 Machine weight ... 32000kg L x W x H ... 6640x6000x4800 mm Accessories: Workpiece probes, tool probes New spindle in 2024
x-travel: 600 mmy-travel: 700 mmz-travel: 600 mmControl: Heidenhain Millplus total power requirement: kWweight of the machine ca.: 9 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 800 mm, 500 mm, 610 mm
JOHNFORD VMC-850 Vertical machining center GENERAL Project No.: 906006 Quantity: 1 pcs. Manufacturer: JOHNFORD Type: VMC-850 Control: Fanuc 0 M Year of Make: 1999 Condition: Used machine Layers Machine Approx (Hrs): 1-2 Layers DESCRIPTION MILLING Travel in X 800 mm Travel in Y 500 mm Travel in Z 610 mm Max. rapid traverse speed in X/Y/Z 30/30/20 m/min Tool holder BT 40 Max. speed milling spindle 8000 1/min Spindle diameter in the front bearing 65 mm Disc tool magazine 24 stations Max. tool diameter 100 mm Max. tool length 200 mm Max. tool weight 10 kg Max. workpiece weight 400 kg Table size 1000x500 mm OTHER EQUIPMENT Splash protection cladding with fully encapsulated working area Lighting in the work area Chip conveyor Coolant Setup GENERAL TECHNICAL DATA Machine dimensions (LxWxH) approx. 2350x3200 mm Machine weight approx. 5500 k ...
x-travel: 3.600 mmy-travel: 920 mmz-travel: 820 mmcontrol: iTNC530 HeidenhainB - axis: +/- 90 x 1 °C-axis: 360 x 0,001 °feed X/Y/Z-axis: 1 - 20.000 mm/minrapid traverse X-axis: 100 m/minrapid traverse Y-axis: 60 m/minrapid traverse Z-axis: 60 m/minspindle turning speed - stepless: 20 - 10.000 U/mintool taper: SK50 power capacity at 100 % load: 32,00 kWpower capacity at 40 % load: 48,00 KWmax. torque at 40% / 100% load: 294 / 196 kWtable surface area: 4.200 x 900 mmnumber of T-slots: 9 T-slot - distance: 100 mmT-slots: 1x 18H7 / 8x 18H12 table load capacity - central/maximum: 4.200 kgtool magazin:: 80 tool diameter: 115 mmwotkpiece diameter with 2 vacant positions: 160 mmtool length - max.: 360 mmweight of tools max.: 12,00 kgtotal power requirement: 85,00 kWweight of the machine ca.: 32,00 tdimensions of the machine ca.: 11,50 x 6,60 x H3,30 mVertical machining center with HEIDENHAIN i ...
Key data: 1000 mm, 600 mm, 660 mm
Control Heidenhain ... TNC 620 Clamping table surface ... 1300 x 600mm Axis X ... 1000mm Axis Y ... 600mm Axis Z ... 660mm Spindle speed ... 0-10000 rpm controlled axes ... 3 cooling ... 20bar, Grundfos ISO 40 Max. table load ... 700 kg L x W x H ... 3000 x 2700 x 2940mmmm Machine weight... 5500kg Magazine spaces ... 24 Handwheel Heidenhain HR510FS Workpiece Probe Heidenhain TS460 Rinsing gun 10bar The machine has undergone a complete overhaul. More info on request. The machine is ready for the viewings.
Vertical machining center EUMACH SUMO 1100, CNC Selca X 1100 mm Y 610 mm Z 610 mm Rapid feeds linear axes X Y Z 30 m / min Table dimensions 1270 x 640 mm Max table load 1200 Kg Spindle 16 Kw / 10,000 rpm - ISO 40 Tools 24 Coolant through the spindle 2007 Under power in our warehouse in Gussago BS. Mimu Machine Tools Gussago BS Italy, The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations, with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several motion axles and one, automatic tool exchange system and sometimes multiple pallets
Key data: 500 mm, 1 mm, 500 mm
5-Axis CNC Vertical Machining Center with Pallet Pool Makino D500 Year of construction: 2011 Fanuc 310iS Professional 5 2-axis NC rotary and swivel table Erowa pallet handling system with 4 pallets Table size 400 x 400 mm C-axis 360° A-axis +30° ~ -120° X 500 mm Y 1,000 mm Z 500 mm Spindle speeds 300 – 3,000 rpm. 60-cavity tool magazine Offer number MV-6494
Hwacheon, mod Sirius III - 1250, Table 1400 700, X 1100 mm, Y 700, Z 650, Cambio utensili / Toolchanger 30 pos, ISO 50, 8000 RPM max 30kW, CNC Fanuc 18iMB, Still under power on the shop floor
Key data: 762 mm, 508 mm, 508 mm
5-Axis CNC Vertical Machining Center Haas UMC 750 Year of construction 2019 Haas CNC 2-axis NC swivel rotary table Table diameter Ø 500 mm Table load max. 300 kg. C-axis 360° B-axis +120°/-35° X 762 mm Y 508 mm Z 508 mm Spindle holder ISO 40 Spindle drive power 22.4 kW Spindle speed max. 12,000 rpm Tool holder ISO 40 31 tool magazine positions Offer number MV-6495
x-travel: 1660 mmy-travel: 760 mmz-travel: 660 mmcontrol: Mazatrol M Plus table surface area: 2000 x 760 mmtable load: 1,0 trapid traverse: 24 m/minturning speed range: 7000 U/minpower capacity - milling spindle: 11 kWtool taper: SK 40 | |no. of tools in the magazine: 2 x 24 Stückweight of the machine ca.: 8,1 tdimensions: 4,2 x 3,2 x 2,8 mVertical Machining Center traveling coloumn- internal coolant- chipconveyor- ext, hand wheelThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 750 mm, 600 mm, 520 mm
CNC 5-Axis HSC Vertical Machining Center DMG DMU 70 eVo Linear NEW DESIGN Year of construction: 2011 Heidenhain iTNC 530 2-axis NC swivel rotary table Table size Ø 700 x 500 mm Table load max. 350 kg C-axis rotation 360° x 0.001° Swivel axis B-axis 120° x 0.001° X 750 mm Y 600 mm Z 520 mm Spindle drive motor 25/35 kW Spindle speeds max. 18,000 rpm. 60-fold tool magazine positions Tool holder HSK-A63 Electrified tour of the factory Offer number MV-6513
x-travel: 650 mmy-travel: 500 mmz-travel: 500 mmcontrol: Siemens 840 D table surface area: 800 x 500 mmrapid traverse: 60 m/mintable load: 1,5 tturning speed range: 0 - 18.000 U/minmax. torque on the spindle: 130 Nmpower capacity - milling spindle: 15 kWno. of tools in the magazine: 30 Stücktool taper: HSK 63 A |internal coolant system feed: 40 barweight of the machine ca.: 10,5 tdimensions: 4,10 x 3,90 x 2,90 mHSC- vertical machining with 4th axisEquipment: - coolant system - 3,5 floppy disk - 4th axis - new spindle in 2019The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 600 mm, 500 mm, 500 mm
CNC 5-Axis Vertical Machining Center DMG Mori DMU 60 eVo Year of construction 2017 Heidenhain TNC 640 ERGOline 2-axis NC swivel rotary table Table size 600 × 500 mm Table load max. 400 kg Table NC Rotary Axis C-Axis 360° Table NC swivel axis B-axis -5° / +110° X 600 mm Y 500 mm Z 500 mm Spindle holder SK 40 BIG PLUS Spindle drive power 25 / 35 kW AC Spindle speeds up to 20,000 rpm. 120 tool magazine slots Operating hours 47,589 Spindle hours 28,638 Offer number MV-6512
x-travel: 650 mmy-travel: 500 mmz-travel: 500 mmcontrol: Siemens 840 D table surface area: 800 x 500 mmrapid traverse: 60 m/mintable load: 1,5 tturning speed range: 0 - 18.000 U/minmax. torque on the spindle: 130 Nmpower capacity - milling spindle: 15 kWno. of tools in the magazine: 30 Stücktool taper: HSK 63 A |weight of the machine ca.: 11 tdimensions: 4,10 x 3,90 x 2,90 mHSC- vertical machining with 4th axisEquipment: - coolant system - Lasersystem for tool measure - 3,5 floppy disk - 4th axis - new spindle in 2016The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 800 mm, 450 mm, 510 mm
Doosan DNM 4500 Vertical Machining Center (VMC) Year of construction: 2016 Condition: Used – in very good working condition Well-maintained Doosan DNM 4500 vertical machining center, ideal for precision milling and general machining. Technical specifications: X-axis travel: 800 mm Y-axis travel: 450 mm Z-axis travel: 510 mm Rapid traverse (X/Y/Z): 36 / 36 / 30 m/min Spindle speed: up to 8,000 rpm Spindle power: 18.5 kW Spindle torque: 117.8 Nm Tool changer: 30 positions Table size: 1,000 mm Max. workpiece weight: 600 kg Machine weight: approx. 5,000 kg The machine has been regularly maintained and is in good condition. Inspection under power is possible.
5-Axis Vertical Machining Center DMG DMC 75V LINEAR Linear Motors The machine can be viewed in working order in our warehouse in Gussago, Brescia. Mimu Machine Tools Gussago BS Italy Dmg DMC 75 Linear Heidenhain CNC iTNC 530 Tool holder HSK 63 Spindle power 35 kW Spindle speed 18,000 rpm Number of tools 60 X-axis travel 885 mm Y-axis travel 600 mm Z-axis travel 600 mm Rapid feeds X-Y-Z linear axes 90 m/min Roller guides Fourth-axis head yes Fourth-axis head type continuous Fourth-axis head degrees -10° + 110° Rotary table yes Rotary table type continuous Table size 750 mm MACHINE EQUIPMENT Precision package with optical scales on the axes New spindle line The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations with a single setup on Multiple surfaces of the same workpiece. It is generally equipped with multiple motio ...
CNC controller: Heidenhain iTCN530 Axes X-axis travel mm: 1.250 Y-axis travel mm: 620 Z-axis travel mm: 620 C-axis degrees: 360º (0,001º) B-axis degrees: ±115 (0,001º) Worktable Table dimensions mm: 1.350 x 620 Max. workpiece weight kg: 1.000 Spindle Spindle speed rpm: 15.000 Spindle drive power kW: 22 / 17 Spindle torque Nm: 387 / 466 Tool system Tool holder: SK 40 Tool magazine slots: 60 Max. Tool Diameter: 150 Max. Tool Length mm: 220 Max tool weight kg: 7 Tool-to-tool time s: 3 Equipment Electronic Handwheel Signal lamp Tool breakage probe Paper band filter Chip conveyor with built-in scraper RENISHAW OMP 40-2 4th and 5th axis Lehmann (ø400 x 40mm x 40kg) Cooling Tank capacity: 340 L High-pressure bar: 20 Machine running times Under power: 75.294 Operating Time: 33.525 Basic machine dimensions / weight Weight kg: 8.000
The machine is visible in our warehouse in Gussago BS. Mimu Machine Tools Gussago BS Italy The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several motion axles and one automatic tool exchange system and sometimes multiple pallets
Key data: 1016 mm, 610 mm, 710 mm
Control Heidenhain ... TNC 530 Clamping table surface ... 1300 x 600mm Axis X ... 1016mm Axis Y ... 610mm Axis Z ... 710mm Spindle speed ... 0-10000 rpm controlled axes ... 3 IKZ ISO 40 Magazine spaces ... 24 Machine weight ... 5500kg
Vertical machining center, CHIRON FZ08KW, 2 pallet, 15000 RPM, Tools: 24, HSK-A40, CNC Fanuc 21iM, The machine is visible in our warehouse in Gussago BS. M i m u Machine Tools Gussago BS Italy The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several motion axles and one automatic tool exchange system and sometimes multiple pallets
