ARBURG used machine for sale

Key data: 2000 kN, 291 g/PS, 45 mm

1.0 St. gebr. Injection Molding Machine with 6 - AXIS ROBOT Manufacturer: ARBURG Type: 5700C2000-675 GOLDEN EDITIO Year of Make: 2007 Clamping force: 200 tons Handlebar spacing 570 x 570 mm Screws DN: 45 mm Displacement: 318 ccm³ Moulded part weight 291 g/hp Control: SELGOCIA Equipment: -6 - ACHS robot Stäubli -1 x Core Pull -Bimetal cylinder -Temperature release up to 450° C -3 electric heating control circuits for tool heating

Arburg 570 C 2200-900 (only 24.000 working hours) + robot Apex Clamping force: 220 tons Opening stroke: 650 mm Mould height: 300 mm Clamping platen daylight: 950 mm Tie bar daylight: 570 x 570 mm Mould clamping plattens (b x h) : 795 x 795 mm Ejector stroke: 225 mm Screw diameter: 50 mm Screw stroke: 200 mm Injection volume: 392 cm3 Shot weight: 359 g Injection pressure: 2000 bar Working hours: 24.191 Core pullers: 2x

Clamping force: 100 tons Opening stroke: 500 mm Mould height: 250 mm Clamping platen daylight: 750 mm Mould clamping plattens (b x h) : 580 x 580 mm Ejector stroke: 125 mm Screw diameter: 40 mm Shot weight: 172 g Working hours: 22.206

Key data: 200000 kN, 127 g/PS, 35 mm

Clamping force: 200 t Year of construction: 2007 Injection weight in PS: 127 g Injection unit: .../350 Screw diameter: 35 mm Spec. Injection pressure: 2500 bar Spray volume: 139 ccm Injection weight in PS: 127 g L/D screw ratio: 23 Clamping unit: 2000/... Clamping force: 200 t Size of clamping plates: 728 x 728 mm Lights spar spacing: 520 x 520 mm Ejector force: 66 kN Aperture travel: 650 mm Max. plate spacing: 900 mm Ejector travel: 225 mm Fuel tank capacity OIL: 290 l

Key data: 130000 kN, 194 g/PS, 45 mm

Clamping force: 130 t Year of construction: 1999 Injection weight in hp: 194 (hp) g Control type: Selogica Injection unit: .../350 Screw diameter: 45 mm Spec. Injection pressure: 1670 bar Spraying volume: 230 ccm Injection weight in hp: 194 (hp) g Hydr. Drive power: 22 kW L/D Screw Ratio: 18 Clamping unit: 1300/... Clamping force:: 130 t Size of clamping plates: 615 x 615 mm Lights spar spacing: 420 x 420 mm Ejector force: 40 kN Tool installation height: 250 mm Aperture travel: 500 mm Max. plate spacing: 750 mm Ejector travel: 175 mm General information: Fuel tank capacity OIL: 240 l Weight: 4100 kg Dimensions(m) LxWxH: 4.4 x 1.4 x 2.1 m

Year of construction: 1987 Injection weight in PS: 24 g Control type: Dialogica Injection unit: .../45 Screw diameter: 22 mm Injection weight in PS: 24 g Clamping unit: 150/... Lights spar spacing: 170 x 170 mm Aperture travel: 200 mm Max. plate spacing: 350 mm Ejector travel: 75 mm

Key data: 320000 kN, 131 g/PS, 35 mm

Clamping force: 320 t Year of construction: 2007 Injection weight in PS: 131 / 131 g Injection unit: .../800 / 350 Screw diameter: 35 / 35 mm Spray volume: 139 / 139 ccm Injection weight in PS: 131 / 131 g Clamping unit: 320/... Clamping force:: 320 t Lights spar spacing: 720 x 720 mm Tool installation height: 300...1400 mm Ejector travel: 250 mm General information: Delivery Time: Natychmiast Weight: 17,000 kg Dimensions(m) LxWxH: 6.83 x 2.25 x 2.50 m Instrumentation: 1 x 8-speed water battery 1 x 12-speed water battery 1 x 4-way water battery 3 x hydraulic core pull control 4 x Air Valve Robot interface according to EUROMAP 67

Key data: 200 kN, 72 g/PS, 30 mm

Clamping force: 200 t Year of construction: 2002 Injection weight in PS: 72 / 45 g Control type: Selogica Injection unit: .../150 / 150 Screw diameter: 30 / 25 mm Spray volume: 77 / 54 ccm Injection weight in PS: 72 / 45 g Clamping unit: 200/... Clamping force: 200 t Lights spar spacing: 570 x 570 mm Ejector travel: 225 mm General information: Weight: 8000 kg Dimensions(m) LxWxH: 5.1 x 1.8 x 2.2 m • 2 x Hydraulic Core Pull • 1 x Air Valve Snail: Top/Vertical: 30mm Bottom/Horizontal: 25mm

Key data: 1000 kN

Manufacturer: Arburg Type: Allrounder 420 S 1000-350 Year of construction: 2000 Clamping force: 1000 KN Minimum tool installation height: 225 mm Maximum opening distance: 575 mm Screw diameter: 35 mm Maximum dosing volume: 139 cc Accessories: Helios granulate dryer, type Jetboxx E economy Flowbox Fa. Alpha ionstatex Protective enclosure with door (Bosch profile) for robot assembly Handle extension 200 mm Location: Seelbach We will be happy to send you further information on request.

Key data: 250 kN, 20 g/PS, 18 mm

Arburg 270U-250-70 (221) Description General information SKU: (221) Availability: In stock Year of construction: 2005 Brand: Arburg Specifications Injection weight: 20 g Clamping force: 250 kN Stand: Used Screw diameter: 18 mm Injection pressure: 2500 bar Tie bar spacing: 270 x 270 mm Clamping plate size: 380 x 380 mm Tool installation height min.: 200 mm Control: Selogica Language: German Power: 35 kW Operating hours: 82,985 h Curmtbe2w8 Weight: 2100 kg Dimensions: 3m x 1.1 m Funnel: No Core Train: Yes Euromap: Yes

Key data: 1600 kN, 359 g/PS, 50 mm

Machine in good condition, dry, clean, ready for production. The pump is quiet and the injection molding is precise. Everything works perfectly. With 2 core pullers and robot connector, with quality control program. Please see my other ads.

1996 Arburg Allrounder 320 M 500 - 90, 50 t Clamping force 50 t Screw 30 mm Mold height min 250 mm Distance between tie bars 320 mm Mould weight max 0,6 t Shot capacity 71 cmm Control Multronica Core pullers - no Hotrunner zones - no Weight 2360 kg, L x W: 4100 mm x 1200 mm year of made 1996 stock number 00660 accessories - no (in price of machine is not hopper loader on photo, but is possible to buy it)

2001 Arburg Allrounder Selecta 320 S 500 - 150, 50 t Clamping force 50 t Screw 30 mm Mold height min 225 mm Distance between tie bars 320 mm Mould weight max 0,6 t Shot capacity 78 ccm Control Selogica Core pullers - 1 Hotrunner zones - 9 Weight 2250 kg, L x W: 3700 mm x 1100 mm year of made 2001 stock num 00659 accessories - no (in price of machine is not hopper loader on photo, but is possible to buy it)

1998 Arburg Allrounder 320 M 500 - 210, 50 t Clamping force 50 t Screw 30 mm Mold height min 250 mm Distance between tie bars 320 mm Mould weight max 0,6 t Shot capacity 101 ccm Control Multronica Core pullers - no Hotrunner zones - no Weight 2610 kg, L x W: 4100 mm x 1200 mm year of made 1998 accessories - no (in price of machine is not hopper loader on photo, but is possible to buy it)

Key data: 3200 kN

Arburg 1500T 3200-1300 e² / Hybrid machine with one turntable Year of construction: 2011 Injection unit: Screw diameter: 60 mm Injection weight: 607 g Spray pressure: 2000 bar Dosing volume: 664 ccm Clamping unit: Clamping force: 320 t Tie bar spacing: 0x0 mm Size of clamping plates: 1510 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Operating hours: approx. 30,000 in automatic mode Euromap 67 Robot Interface Control with air valve Hydraulic core pull x 3 Hot runner control x 13 Injection unit hardened - Bimetal Main motor of the machine - servo motor driven by inverter Very precise turntable, driven by a servo motor, controlled by an inverter Turntable diameter: 1500 mm Horizontal injection unit with automatic injection height adjustment Sel ...

Key data: 2200 kN

Arburg 570S 2200-290/100/100 / Production line with the Wittmann W823 robot / Operating hours: 20,499 h in automatic mode Year of construction: 2016 Injection unit: Screw diameter: 35 mm Injection weight: 132 g Spray pressure: 2000 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 220 t Tie bar spacing: 570x570 mm Size of clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 3-component injection moulding machine, high-speed Very good technical condition Operating hours: 20,499 h in automatic mode Euromap 67 Robot Interface Air valve x 6 Hydraulic, needle core pull, controlled by a proportional valve x 4 Control with hot runners Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Machine with two cylinders / battery with compressed  ...

Key data: 2200 kN

Arburg 570S 2200-290/100/100 / Production line with the Wittmann W843 robot / Operating hours: 23,897 h in automatic mode Year of construction: 2014 Injection unit: Screw diameter: 35 mm Injection weight: 132 g Spray pressure: 2000 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 220 t Tie bar spacing: 570x570 mm Size of clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 3-component injection moulding machine, high-speed Very good technical condition Operating hours: 23,897 h in automatic mode Euromap 67 Robot Interface Air valve x 6 Hydraulic, needle core pull, controlled by a proportional valve x 4 Control with hot runners Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Machine with two cylinders / battery with compressed  ...

Key data: 2000 kN

Arburg 520C 2000-350/150 / Production line with the Wittmann W731 robot Year of construction: 2008 Injection unit: Screw diameter: 40 mm Spray weight: 166 g Spray pressure: 2120 bar Dosing volume: 182 ccm Clamping unit: Clamping force: 200 t Tie bar spacing: 520x520 mm Size of clamping plates: 728x728 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 2-Component Injection Molding Machine Very good technical condition Euromap 67 Robot Interface Air Valve x 4 Hydraulic, needle core pull, controlled by a proportional valve x 3 Control with hot runners Injection unit hardened - Bimetal Proportional valve on the vertical injection unit – precise injection Parallel Movements Screw diameter in vertical injection unit: ⌀25 mm - 49 g/hp Robot Wittmann W731 Year of construction: 2008 5-axis robots: 3 axes ar ...

Key data: 2000 kN

Arburg 570E 2000-800 with the Sepro Industrial Robot 65 sprue picker / Electric machine / Operating hours: approx. 3,500 h in automatic mode Year of construction: 2021 Injection unit: Screw diameter: 50 mm Spray weight: 359 g Spray pressure: 2000 bar Dosing volume: 392 ccm Clamping unit: Clamping force: 200 t Tie bar spacing: 570x570 mm Size of clamping plates: 795x795 mm Ejector: electric Clamping unit: toggle lever Control: SELOGICA - Touchscreen Additional equipment: Perfect technical condition, machine like new Electric machine: high-speed, energy-saving and very quiet Operating hours: approx. 3,500 h in automatic mode Euromap 67 Robot Interface Control with air valve Hydraulic core pull x 2 Air core on solid plate side x 2 Pneumatic nozzle closing valve x 2 Injection unit hardened - Bimetal Central lubrication Parallel Movements Sprue Picker Sepr ...

Key data: 2000 kN

Arburg 570C 2000-150/60 / 2K machine Year of construction: 2003 Injection unit: Screw diameter: 35 mm Injection weight: 97 g Spray pressure: 1620 bar Dosing volume: 106 ccm Clamping unit : Clamping force: 200 t Tie bar spacing: 570x570 mm Size of clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 67 Robot Interface Hydraulic Core Pull x 2 Hot runner control x 12 Injection unit hardened - Bimetal Screw diameter in vertical injection unit: fi 18 mm Machine with 1 cylinder/battery with compressed nitrogen (extra charge for fast working) It is possible to install a turntable in the machine - at an additional cost Metrics: Weight: 8000 kg Length/width/height: 0x0x0 m Drive: Pumps/motor: 30 kW Heating capacity: 9.4 + 3.2 kW Total power: 42.6 kW All offered machines are started by ou ...

Key data: 2000 kN

Arburg 570H 2000-2100 with the Sepro Industrial Robot SDR 22S robot / Hybrid machine / Operating hours: approx. 29,000 h in automatic mode Year of construction: 2010 Injection unit: Screw diameter: 70 mm Injection weight: 984 g Spray pressure: 2000 bar Dosing volume: 1078 ccm Clamping unit : Clamping force: 200 t Tie bar spacing: 570x570 mm Size of clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: toggle lever Control: SELOGICA - Touchscreen Additional equipment: Machine in very good technical condition Hybrid machine: high-speed, energy-saving and very quiet Operating hours: approx. 29,000 h in automatic mode Euromap 67 Robot Interface Air valve x 2 Hydraulic core pull x 1 Air Core Pull x 7 Hot runner control x 15 Injection unit hardened - Bimetal Main motor of the machine - servo motor driven by inverter - energy saving The injection unit  ...

Key data: 1500 kN

Arburg 470C 1500-800 with the Sepro Industrial Robot 65 sprue picker Year of construction: 2021 Injection unit: Screw diameter: 50 mm Spray weight: 359 g Spray pressure: 2000 bar Dosing volume: 392 ccm Clamping unit: Clamping force: 150 t Tie bar spacing: 470x470 mm Size of clamping plates: 650x650 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Perfect technical condition, machine like new Operating hours: 7,788 h in automatic mode Euromap 67 Robot Interface Air valve x 1 Hydraulic core pull x 1 Pneumatic Core Pull x 2 Pneumatic nozzle closing valve x 2 Injection unit hardened - Bimetal Sprue Picker Sepro Industrial Robot 65 Year of construction: 2021 Purchase of the sprue picker at an additional cost It is possible to buy the machine with another robot It is possible to buy a Moretto raw materi ...

Key data: 1500 kN

Arburg 470C 1500-400 with the Wittmann W721 robot Year of construction: 12.2006 Injection unit: Screw diameter: 40 mm Spray weight: 184 g Spray pressure: 2000 bar Dosing volume: 201 ccm Clamping unit: Clamping force: 150 t Tie bar spacing: 470x470 mm Size of clamping plates: 650x650 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot Interface Control with air valve Hydraulic core pull x 1 Injection unit hardened - Bimetal Built-in conveyor belt and sorting flap Robot Wittmann W721 Year of construction: 2006 4-axis robots: 3 axes are driven by servo motors (electric); Axis C - pneumatic Travels in axes: X-550, Y-1200, Z-3000 Touch control panel The safety package for robots Robot with adapter Purchase of the robot at an additional cost Metrics: Weight: 4900 kg Length/Width/Height: 4 ...

Key data: 1500 kN

Arburg 470C 1500-675 Year of construction: 2004 Injection unit: Screw diameter: 60 mm Injection weight: 427 g Spray pressure: 1440 bar Dosing volume: 508 ccm Clamping unit: Clamping force: 150 t Tie bar spacing: 470x470 mm Size of clamping plates: 685x685 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 12 Robot Interface Core Pull Control Injection unit hardened - Bimetal Parallel Movements Metrics: Weight: 4660 kg Length/Width/Height: 5.00x1.93x2.22 m Drive: Pumps/motor: 30 kW Heating capacity: 14.9 kW Total power: 44.9 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request

Key data: 1300 kN

Arburg 520S 1300-800 / Machine in very good technical condition Year of construction: 2008 Injection unit: Screw diameter: 50 mm Spray weight: 359 g Spray pressure: 2000 bar Dosing volume: 392 ccm Clamping unit: Clamping force: 130 t Tie bar spacing: 520x520 mm Size of clamping plates: 695x695 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Machine in very good technical condition Euromap 67 Euromap 12 Robot Interface Air valve x 2 Injection unit hardened - Bimetal The machine was regularly serviced by the authorised service company Arburg in the United States. Metrics: Weight: 6450 kg Length/Width/Height: 4.81x1.57x2.19 m Drive: Pumps/motor: 30 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the se ...

Key data: 1500 kN

Arburg 470C 1500-150/150 / 2K machine / machine in very good technical condition Year of construction: 2005 Injection unit: Screw diameter: 25 mm Injection weight: 49 g Injection pressure: 2500 bar Dosing volume: 54 ccm Clamping unit : Clamping force: 150 t Tie bar spacing: 470x470 mm Size of clamping plates: 685x685 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: 2K Machine Euromap 67 Robot Interface Air valve x 1 Hydraulic core pull x 1 Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Type of injection unit: Vario - This offers the possibility to use the injection unit, e.g. for side spraying Parallel Movements The vertical injection unit - screw diameter fi 25 mm (49 g/PS) It is possible to change screw diameters in both injection units for the screw diameters recomm ...

Key data: 1300 kN

Arburg 420C 1300-675 with the Star sprue picker Year of construction: 2002 Injection unit: Screw diameter: 50 mm Spray weight: 297 g Spray pressure: 2080 bar Dosing volume: 353 ccm Clamping unit: Clamping force: 130 t Tie bar spacing: 420x420 mm Size of clamping plates: 605x605 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 12 Robot Interface Air valve x 2 Hydraulic core pull x 2 Injection unit hardened - Bimetal Type of injection unit: Vario - This offers the possibility to use the injection unit, e.g. for side spraying Covers from the operator's side open automatically Metrics: Weight: 4330 kg Length/Width/Height: 4.80x1.64x2.08 m Drive: Pumps/motor: 30 kW Heating capacity: 14.9 kW Total power: 44.9 kW All offered machines are started by our service technicians before they are sold. It is possib ...

Key data: 1300 kN

Arburg 470S 1300-350 Year of construction: 2001 Injection unit: Screw diameter: 35 mm Spray weight: 117 g Injection pressure: 2500 bar Dosing volume: 139 ccm Clamping unit : Clamping force: 130 t Tie bar spacing: 470x470 mm Size of clamping plates: 650x650 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 12 Robot Interface Hydraulic core pull x 1 Hot runner control x 6 Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Built-in print quality control system from Sensor Kistler - tool pressure measurement Type of injection unit: Vario - This offers the possibility to use the injection unit, e.g. for side spraying The new injection unit is installed in the machine Metrics: Weight: 5100 kg Length/Width/Height: 4.45x1.49x2.17 m Drive: Pumps/motor: 22 kW Heatin ...

Key data: 1300 kN

Arburg 470S 1300-350 Year of construction: 2001 Injection unit: Screw diameter: 35 mm Spray weight: 117 g Injection pressure: 2500 bar Dosing volume: 139 ccm Clamping unit: Clamping force: 130 t Tie bar spacing: 470x470 mm Size of clamping plates: 650x650 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Euromap 12 Robot Interface Hydraulic core pull x 1 Hot runner control x 6 Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Built-in print quality control system from Sensor Kistler - tool pressure measurement Type of injection unit: Vario - This offers the possibility to use the injection unit, e.g. for side spraying The new injection unit is installed in the machine Metrics: Weight: 5100 kg Length/Width/Height: 4.45x1.49x2.17 m Drive: Pumps/motor: 22 kW Heating c ...

Key data: 1000 kN

Arburg 470S 1000-290 / Production line with the Wittmann W821 robot / Operating hours: approx. 35,000 h in automatic mode Year of construction: 2012 Injection unit: Screw diameter: 30 mm Injection weight: 97 g Injection pressure: 2500 bar Dosing volume: 106 ccm Clamping unit: Clamping force: 100 t Tie bar spacing: 470x470 mm Size of clamping plates: 637x637 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Very good technical condition Operating hours: 35,000 h in automatic mode Euromap 67 Robot Interface Air valve x 2 Hydraulic, needle core pull, controlled by a proportional valve x 2 Control with hot runners Injection unit hardened - Bimetal Proportional valve on the injection unit – precise injection Cavity pressure sensor Priamus Robot Wittmann W821 Year of construction: 2012 5-axis robots: 4 axes ...
