used ARBURG 470

Manufacturer: Arburg Type: 470 C 1500 - 350 Year of construction: 2005 Control: Selogica Closing type: Hydraulic Closing force: 1500 kN Tie bar spacing: 470 mm x 470 mm Plate size: 650 mm x 650 mm Tool height: min 250 mm Opening distance: 500 mm Plate spacing max.: 750 mm Screw: 45 mm Lifting volume: 230 ccm / 210 gram PS Injection pressure: 1670 bar general Engine: 30 kW Heating: 10,2 kW Dimensions: 4.9 m x 1.7 m x 2 m Weight: 4600 kg Screen text: German Optional extras Robot Arburg Multilift + 100mm column extension El. Dosing + LGS 6 heating control points Robot interface Core train x1

Producer ARBURG Type 470 S 1300-350 Year 2002 Clamping unit Clamping force 130 ton Opening stroke 575 mm Distance between tie bars 470 x 470 mm Mould height min. 275 mm Opening width 850 mm Platen size (h x v) 650 x 650 mm Injection unit Screw diameter 35 mm Injection volume 139 cm³ Shot weight 125 g Injection pressure 2500 bar Measurements and weight Dimensions 4,68 x 1,3 x 2,2 m Machine weight 5000 kg

Closing unit Clamping force t: 200 Opening path mm: 650 Holm size mm: 470 x 470 Installation height min/max mm: 300/950 Plate size: 715 x 715 Spraying unit Screw diameter mm: 45 Spray weight gr: 240 Spray volume cm3: 286 Dimensions and weights Dimensions LxWxH m: 5.8 x 2.1 x 2.1 Machine Weight Kg: 7800 Other - 1 core - robot Interface Euromap 12

Arburg 470C-2000-675 (No. 40) without picker Built: 1998 TECHNICAL DATA Screw diameter [mm]: 60 Spray weight [g]: 427 Spray pressure [bar]: 1440 Closing force [kN]: 2000 Tie bar distance [mm]: 470x470 Clamping plate size [mm]: 715x715 Tool installation height min. [mm]: 250 Control Control: Selogica Monitor: Yes Control cabinet: Yes Language: Polish, German Other Power [kW]: 45.8 Engine hours [h]: 94737 Weight [kg]: 6630 GR - EUROMAP

Arburg 470C-2000-675 (No. 40) without picker Built: 1998 TECHNICAL DATA Screw diameter [mm]: 60 Spray weight [g]: 427 Spray pressure [bar]: 1440 Closing force [kN]: 2000 Tie bar distance [mm]: 470x470 Clamping plate size [mm]: 715x715 Tool installation height min. [mm]: 250 Control Control: Selogica Monitor: Yes Control cabinet: Yes Language: Polish, German Other Power [kW]: 45.8 Engine hours [h]: 94737 Weight [kg]: 6630 GR - EUROMAP

Arburg 470C-2000-675 (No. 40) without picker Built: 1998 TECHNICAL DATA Screw diameter [mm]: 60 Spray weight [g]: 427 Spray pressure [bar]: 1440 Closing force [kN]: 2000 Tie bar distance [mm]: 470x470 Clamping plate size [mm]: 715x715 Tool installation height min. [mm]: 250 Control Control: Selogica Monitor: Yes Control cabinet: Yes Language: Polish, German Other Power [kW]: 45.8 Engine hours [h]: 94737 Weight [kg]: 6630 GR - EUROMAP

Description Press with electric extruder NO ROBOT

Description AVAILABLE LANGUAGES: GERMAN - ITALIAN - ENGLISH

Aburg 470C-2000-800 SKU: 49 Availability: In stock Built: 2006 Brand: Arburg specifications Spray weight: 510 g Closing force 2000 kN Screw diameter: 60 mm Spray pressure: 1380 bar Tie bar ratio: 470x470 mm Clamping plate size: 730 x 730 mm Tool installation height min.: 250 mm Control: Selogica Language: Polish Power: 44.9 kW Engine hours: 57310 h Weight: 6830 kg Air valve: Yes

Arburg 470C-1500-350(166) General information Item number: 166 Availability: In stock Year of construction: 2003 Brand: Arburg Specifications Spray weight: 210 g Clamping force: 1,500 kN Screw diameter: 45 mm Spray pressure: 1670 bar Spar spacing: 470x470 mm Clamping plate size: 650x650 mm Tool installation height min.: 250 mm Control: Selogica Language: German Power: 40.2 kW Operating hours: 83824 h Weight: 4410 kg Dimensions: 4.5 x 1.8 m Funnel: No Core train: Yes Euromap: Yes Air valve: Yes

Arburg 470S-1300-350 (170) Hybrid with electric worm drive, without funnel General information Item number: 170 Availability: In stock Year of construction: 2005 Brand: Arburg Specifications Spray weight: 127 g Clamping force: 1,300 kN Screw diameter: 35 mm Spray pressure: 2500 bar Spar spacing: 470 x 470 mm Clamping plate size: 650 x 650 mm Tool installation height min.: 275 mm Control: Selogica Language: German Power: 33.9 kW Operating hours: 85,400 h Weight: 5,100 kg Dimensions: 5 x 1.8 m Funnel: No Core train: Yes Euromap: Yes Air valve: Yes

with - Screw diameter: 60 mm - Clamping force: 200 kN - Injection volume: 508 cm? - Mould opening stroke max: 650 mm - Mould height min: 250 mm - Platen size (h x v): 715 x 715 mm - Distance between tie-bars (h x v): 470 x 470 mm - Operating hours: 60.000 - Power: installed max: 15 + 30 kW - Weight: 6.630 kg - Dimensions (long x wide x high): 6.000 x 1.500 x 2.400 mm - Weight: 6.500 kg

Key data: 1300 , 177 , 40

Arburg 470C 1300-350 with 40mm plasticising unit. The ‘C’ variant of machines from Arburg is one of our most popular requests (once refurbished). These machines were market leaders for quite some time and proved reliable and good value for money over the years. With a little refurbished magic from the team to bring them back to ‘almost new’, these machines now have a new lease of life. They might not be the most energy efficient, but they are by no means power hungry and when the low upfront cost is considered with low maintenance costs, it’s a very good value option. Refurbished machines from STV Machinery undergo a comprehensive test procedure during which every function of the machine is tested and if necessary repaired. A production run of at least 5000 fault free cycles prior to sign off ensures trouble free operation once delivered. Machines are ultra clean and cos ...

warehouse no.: 503292 manufacturer: ARBURG type: Allrounder 470 C 1500-350 Selogica year of construction: 2003 operation hours: 48000 h clamping force: 1500 kN distance between tie bars h x v: 470 x 470 mm size of mould plates h x v: 650 x 650 mm min. mould height: 250 mm max. open daylight: 750 mm opening stroke: 500 mm screw diameter: 40 mm swept volume: 182 ccm injection pressure: 2050 bar measures of machine lxbxh: 4.68m x 1.3m x 2.18m total weight: 4410KG equipment included screen text german core pulling hydraulically 2x machine without material hopper Anti vibration mounts mould heating 6x

warehouse no.: 503294 manufacturer: ARBURG type: Allrounder 470 C 1500-350 Selogica year of construction: 2003 operation hours: 47000 h clamping force: 1500 kN distance between tie bars hxv: 470x470 mm size of mould plates hxv: 650x650 mm min. mould height: 250 mm max. open daylight: 750 mm opening stroke: 500 mm screw diameter: 40 mm swept volume: 182 ccm injection pressure: 2050 bar equipment included: screen text german machine without material hopper Anti vibration mounts measures of machine lxbxh: 4.68m x 1.3m x 2.18m total weight: 4410KG

warehouse no.: 503293 manufacturer: ARBURG type: Allrounder 470 C 1500-350 controller: Selogica year of construction: 2003 operation hours: 53000 h clamping force: 1500 kN distance between tie bars h x v: 470 x 470 mm size of mould plates h x v: 650 x 650 mm min. mould height: 250 mm max. open daylight: 750 mm opening stroke: 500 mm screw diameter: 40 mm swept volume: 182 ccm injection pressure: 2050 bar equipment included: screen text german core pulling hydraulically 2x machine without material hopper Anti vibration mounts mould heating 6x measures of machine lxbxh: 4.68m x 1.3m x 2.18m total weight: 4410KG

Arburg 470C-1500-400(194) Description with conveyor belt, bimetallic screw General Information SKU: 194 Availability: In stock Year of construction: 2006 Brand: Arburg Specifications Injection weight: 232 g Clamping force: 1,500 kN Screw diameter: 45 mm Spray pressure: 1580 bar Tie bar spacing: 470 x 470 mm Clamping plate size: 650 x 650 mm Tool installation height min.: 250 mm Control: Selogica Language: German Power: 28.7 kW Operating hours: 70,000 h Weight: 4900 kg Dimensions: 4.8 x 2 m Funnel: No Core train: Yes Euromap: Yes

ARBURG 470H-1000-190 -Clamping force : 100 ton -Screw diameter : 30mm

Key data: 1500

warehouse no.: 503391 manufacturer: ARBURG type: Allrounder 470 C 1500-400 controller: Selogica year of construction: 2008 operation hours: 13847 h clamping force: 1500 kN distance between tie bars h x v: 470 x 470 mm size of mould plates h x v: 650 x 650 mm min. mould height: 250 mm max. open daylight: 750 mm opening stroke: 500 mm screw diameter: 40 mm swept volume: 201 ccm injection pressure: 2000 bar equipment included: screen text german CEE-socket 16A CEE-socket 16A core pulling hydraulically 2x air valve 1x machine incl. belt conveyor machine incl. hopper loader machine incl. Handling machine incl. safety fencing machine incl. water flow regulator Anti vibration mounts interface EUROMAP 67 Schuko-socket 10A Schuko-socket 10A technical data robot-system handling type: Linear manufacture: Wittmann controller: W ...

Key data: 1500 kN, 464 g/PS, 60 mm

1.0 pcs. Injection molding machine with robot Manufacturer: ARBURG Type: 470C1500-675 Year of construction: 2004 Clamping force: 150 tons Tie bar spacing: 470 x 470 mm Screw diameter: 60 mm Moulded part weight in PS: 464 g Control: SELGOCIA Equipment: -1.0 pcs. core pull -Robots, manufacturer: WITTMANN

Key data: 1000 kN, 35 mm

warehouse no.: 503181 manufacturer: ARBURG type: Allrounder 470 E 1000-290 controller: Selogica year of construction: 2012 operation hours: 47142 h clamping force: 1000 kN distance between tie bars h:: 470 mm distance between tie bars v:: 470 mm size of mould plates h: 637 mm size of mould plates v: 637 mm min. mould height: 250 mm max. mould height: 500 mm max. open daylight: 850 mm opening stroke: 350 mm screw diameter: 35 mm swept volume: 144 ccm injection pressure: 2000 bar measures of machine lxbxh: 4.4m x 1.62m x 2m total weight: 5280KG equipment included: screen text german CEE-socket 16A air valve 1x machine incl. water flow regulator machine incl. water flow regulator machine without material hopper Anti vibration mounts interface for ejector plates safety interface for dosing unit interface USB Schuko-socket 10A m ...

This ARBURG injection moulding machine is in machine storage at Plastima Used Machinery. The injection moulding machine is from 2001 and is in good condition. - Make: ARBURG GmbH + Co. KG - Model: Thermolift 100-2 - Year of construction: 2001 - Clamping force: 1,000 kN - Screw diameter: 45 mm - Injection pressure: 1,670 Bar - Shot volume: 230 cm³ - Working hours: 58,700

INJECTION UNIT Screw diameter: 35 mm Calculated injection volume: 106 cm³ Length / diameter ratio: 20 L / D Pressure on the material: 2120 bars CLOSING UNIT Closing force: 1300 kN Mold thickness Mini / Max: 225/275 mm Max distance between tray: 800 mm Passage between columns: 470 x 470 mm Tray size: 650 x 650 mm GENERAL Heat output: 22 kW Total installed power: 33.9 kW

INJECTION UNIT Screw diameter: 35 mm Calculated injection volume: 139 cm³ Length / diameter ratio: 23 L / D Max injection rate: cm³ / s Pressure on the material: 2500 bars Laminating capacity PS: Kg / h Screw Speed: 58 RPM Hydraulic motor torque: 560 Nm Hydraulic Motor Power: HP Nb Temperature Zones: N CLOSURE UNIT Closing force: 1300 kN Opening stroke: 650 mm Thickness Mold Mini / Max: mm Max distance between plate: mm Passage between columns: 470 x 470 mm Tray size: 715 x 715 mm GENERAL Heating power: 22 kW Total installed power: 38 kW Amount of oil: 260 l. Dimension: (WxHxD) m. Weight: 6380 Kg

Centering ring diameter on the plate is 160 mm (not the standard 125 mm) This machine was regularly maintained and has CE norms. Type of used material: PBT GF 30 *** ABS/PA *** PP Service history: 3.2015 – Replacing the CF card reader with a floppy disk drive 5.2013 – Machine calibration 5.2009 – Machine calibration
