(1984) 100t Müller-Weingarten Eccentric Press High-Speed Single-Column Eccentric Press with Versatile Stroke Adjustment This Müller-Weingarten press is a highly adaptable industrial machine, featuring a 100-ton nominal force and an impressive stroke rate of 60 per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100 Year of Manufacture: 1984 Nominal Force: 100t Stroke Rate: 60 strokes/min Throat Depth (Projection): 375 mm Frame Passage (Front to Back): approx. 570 mm Max. Distance (Table to Ram): 384 mm Adjustable Ram Stroke: 8 mm – 137 mm Intermediate Strokes: 8, 23, 43, 63, 81, 97, 111, 122, 130, 135, 137 mm Ram Adjustment: 80 mm Ram Clamping Surface (W x D): 700 mm × 450 mm Ram Shank Hole (Ø x Depth): 50 mm × 85 mm Ejector Travel: 55 mm Table Clamping Surface (W x D): 920 mm × 660 mm Tabl ...

(1979) 100t Müller-Weingarten Eccentric Press High-Utility Eccentric Press for Flexible Stamping and Forming Operations This Müller-Weingarten model is a versatile single-column (C-frame) press designed for high-speed production with a stroke rate of 60 per minute. It features a comprehensive range of 11 adjustable stroke settings, making it highly adaptable for various industrial metalworking tasks from shallow blanking to deeper forming. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100‍ Year of Manufacture: 1984‍ Nominal Force: 100t‍ Stroke Rate: 60 strokes/min‍ Throat Depth (Projection): 375 mm‍ Body Passage (Front to Back): approx. 570 mm‍ Max. Distance (Table to Ram): 384 mm (at bottom of stroke, adjustment at top)‍ Adjustable Ram Stroke: 8 mm – 137 mm‍ Intermediate Strokes: 8, 23, 43 ...

1 eccentric press, manufacturer Weingarten, type AR125, built in 1970, serial number 120526, pressing force 125 t, ram stroke 20 - 120 mm, ram adjustment 100 mm, sheet thickness max. 13 mm, two-hand operation, swivel chair Find more here - / Contact us at -

Eccentric press vineyard type AR160 tons With protective shield. YOC 1971 2 rotational speeds via mechanical gearbox Switchable. Central lubrication. Low-wear steep-threaded coupling. Table dimensions : 800x1000 mm Visits : possible at any time. Total weight approx. 10.5 tons

pressure: 100 t throat: 410 mm stroke: 8-112 mm no. of strokes doubel-strokes per min.: 55 / 82 ram - range of adjustment: 80 mm table surface area: 950 x 700 mm ram surface: 700x450 mm hole in the table: Ø 280 mm table height: 850 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 7,0 t dimensions of the machine ca.: 1400x2200x2800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 410 mm stroke: 8-112 mm no. of strokes: 55/82 Hub/min ram - range of adjustment: 80 mm table surface area: 950x700 mm ram surface: 700x450 mm hole in the table: Ø 280 mm table height: 800 mm total power requirement: 11 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: BxTxH 1600x2200x3000 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 330 mm stroke: 8-100 mm no. of strokes: 56/84 Hub/min ram - range of adjustment: 63 mm table surface area: 850x600 mm ram surface: 550x360 mm hole in the table: Ø 240 mm table height: 800 mm tool hole in ram: Ø 40 mm weight of the machine ca.: 4,5 t dimensions of the machine ca.: 1300x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 415 mm stroke: 8-140 mm no. of strokes: 48 Hub/min ram - range of adjustment: 80 mm table surface area: 920x670 mm ram surface: 700x450 mm table height: 800 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 1500x2000x2800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 40 t throat: 240 mm stroke: 8-88 mm no. of strokes: 57/86 Hub/min ram - range of adjustment: 63 mm table surface area: 560x450 mm ram surface: 240x200 mm hole in the table: Ø100 mm table height: 840 mm tool hole in ram: Ø40 mm weight of the machine ca.: 3,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 40 t throat: 240 mm stroke: 8-88 mm no. of strokes: 57/86 Hub/min ram - range of adjustment: 63 mm table surface area: 560x450 mm ram surface: 240x200 mm hole in the table: Ø100 mm table height: 840 mm tool hole in ram: Ø40 mm weight of the machine ca.: 3,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 375 mm stroke: 20-125 mm no. of strokes: 60 Hub/min ram - range of adjustment: 80 mm table surface area: 920x660 mm ram surface: 700x450 mm hole in the table: Ø90 mm tool hole in ram: Ø50 mm weight of the machine ca.: 8 t dimensions of the machine ca.: 2100x1500x3300 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS   conventional PRESS DESIGN   drive system: eccentric / crank   frame design: C-frame, single sided PRESS FORCES   total force (nominal): 100 to SLIDE   slide force: 100 to   stroke rate (max.): 72 /min SLIDE (MECHAN. PRESS)   slide adjustment: 80 mm   stroke adjustment: yes   stroke min.: 8 mm   stroke max.: 112 mm TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 407 mm ATTACHMENTS (PRESSES)   2-hand engagement: yes for safe tools only

Press force: 100t, stroke rate: 60/min, ram stroke: 8mm-137mm, ram adjustment: 80mm, throat depth: 375mm, table dimensions X/Y/Z: 800mm/630mm, machine dimensions X/Y/Z: approx. 1500mm/2400mm/3500mm, weight: approx. 8800kg. An on-site inspection is possible.

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch

pressure:100 t throat:375 mm stroke:20 - 125 mm no. of strokes:30 - 80 /min distance table/ram, max. stroke up, adjustment up:515 mm table surface area:900 x 635 mm hole in the table:280 mm table height over floor:800 mm passage to the back:570 mm ram surface:700 x 450 mm ram adjustment:80 mm power requirement:15,0 kW weight:8,0 t dimensions (WxDxH):1,5 x 2,4 x 3,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:160 t throat:480 mm stroke fix:fix 180 mm no. of strokes:25 - 70 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1100 x 900 mm Hole in the table:450 mm table height over floor:900 mm passage to the back:700 mm ram surface:900 x 600 mm ram adjustment:144 mm power requirement:30,75 kW weight:15,3 t dimensions (WxDxH):2,0 x 2,4 x 3,75 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:315 t throat:480 mm stroke:20 - 190 mm no. of strokes:36 + 45 /min distance table/ram, max. stroke up, adjustment up:615 mm table surface area:1400 x 880 mm hole in the table:250 mm table height over floor:800 mm passage to the back:950 mm ram surface:850 x 630 mm ram adjustment:125 mm power requirement:33,0 kW weight:30,0 t dimensions (WxDxH):2,0 x 3,0 x 4,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic

Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric

WEINGARTEN DE 200-20 press built in 1975 in Germany is used for precision workpiece machining. The rigid construction combined with a high press force of 200 tonnes make the machine the perfect solution for mass production of various types of parts. The process of precision sheet metal pressing can be fully automated when the WEINGARTEN press is retrofitted with a sheet metal feeder. Technical specifications of the WEINGARTEN DE200-20 200 t press - press force: 200 t - maximum slider stroke: 200 mm - minimum slider stroke: 15 mm - maximum number of slider strokes: 60/min - minimum number of slider strokes: 20/min - slider adjustment: 110 mm

Cylinder part for Multi for GDK3500 die casting machine, 931732, Frech/Müller Weingarten, new Special price !!! If you have a VAT number, we will gladly issue an invoice without VAT. Condition new The cylinder part for Multi comes from a spare parts warehouse at a production facility, has always been stored in a dry, sealed environment, is new and fully functional. The cylinder part for Multi item 931732 from Frech/Müller Weingarten. Suitable for Frech/Müller Weingarten GDK 3500 machines with 185-tonnes or 220-tonnes units.. Weight 720 kg. The goods can be viewed, inspected and collected from us at any time. We will also be happy to send you a sketch of the design or deliver the goods to your address. Attention: We offer various columns, adjusting nuts, tie bar expansion nuts and 2-piece nuts from: IDRA D330, D300, D260, D250, Oleopress/OP Die Casting: D285, D250, ...

(1961) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1961 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.174 Seconds Safety Distance: 278 mm Motor Power: 11 kW

(1963) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1963 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height Range (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.154 Seconds Safety Distance: 246 mm Motor Power: 11 kW

(1965) 125t Müller-Weingarten Eccentric Press Heavy-Duty Single-Column Press for Robust Metal Forming This Müller-Weingarten model is a reliable industrial workhorse capable of processing heavy-gauge sheet metal up to 13 mm in thickness. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model Type: ER 125 Year of Manufacture: 1965 Nominal Force: 125t Maximum Material Thickness: 13 mm Stroke Rate: 50 strokes/min Ram Stroke (Adjustable): 20 – 120 mm Ram Adjustment: 100 mm Overrun Time (Stopping Time): 0.34 seconds Safety Distance: 500 mm Motor Power: 11.0 kW

Single column - eccentric press WEINGARTEN type E 40 Masch. No. 643 / 62 Year of construction 1963 Pressure capacity 40 ton. Projection 250 mm Table opening 150 x 80 and Ø 200 mm Table area 560 x 460 mm Plunger area 250 x 200 mm Adjustable ram stroke 8-88 mm Plunger adjustment 63 mm Installation height 320 mm Clamping pin bore Ø 40 mm Stroke rate 100 / 130 strokes / min. Motor power 2.2 / 3 kW Mains connection 400 volts, 50 Hz Table height above floor 840 mm - Clutch-brake combination thanks to WEINGARTEN friction threaded clutch with OT flow protection - Electric stroke release via two-hand operation - Overload protection by crushing plate - Manual grease central lubrication - Front crankshaft support bearing - Control cabinet adjacent - UVV for manual insertion work Space requirements L x W x H 1800 x 1500 x 2200 mm Weight 3.1 ton.
