VECOPLAN vaz used machines

Vecoplan VAZ 2500 M NF-T, Compact high torque motor with motor pump unit and electric motor, Including:, Generous bolted hopper about 16 m3 capacity, Special Vecoplan system to stop the machine with hard contamination, horizontal hydraulic ram + vertical hydraulic ram (excellent for light voluminous or round shaped scraps), hydraulic power station with 1x15 kw + 1x7,5 kw motors, 250 lt hydraulic oil tank, Max. operating pressure up to 150 bar, Hi Torque drive with silent running sysyem, Rotor Ø 640, Rotor width 2.500 mm., rotor rpm 0-220, n.76 cutting crowns 60x60 x30 mm, n.6 still knives, 5-pieces screen size : 20 mm - different size on request, electro-pneumatic pistons for screen opening, Motor power : choose among 134 kW, 203 kw or 247 kw Hi Torque., 315 kw inverter, 415 A nominal 0-220 rpm 400 V 50 Hz - IP 54, temperature probes on the 2 bearings, constructed in 2006 but seldom use ...

VECOPLAN VAZ 1300, multi-purpose single shaft shredder, 45 Kw drive, in its electrical, mechanical and hydraulic parts, Knives : 40 x 40 mm, Rotor lenght : 1.300 mm, horizontal hydraulic ram, hydraulic power station, control panel, constructed in 2007, the machine is offered totally reconditioned, installed power - used power in work: about 60-65% : 45 kW, availability: immediate, working width: 1.300 mm, conditions: reconditioned, type: single shaft, multi-purpose shredder

VECOPLAN VAZ M-K-T- 1600, 1.600 mm long rotor, rotor diameter 370, rotor rpm 200, HI-TORQUE a.c.motor 110 kW, n.42 cutting pieces 60x60 mm, screen size 60 mm (or different), horizontal ram, hydraulic pack, Electric cabinet, Total dimensions : LxWxH mt.4,315 x 2,885 x 1,600, Total weight kg.7.200 ca, Machine offered totally reconditioned, Our offer includes a MTA chilling unit, installed power - used power in work: about 60-65% : 110 kW, working width: 1.600 mm, conditions: reconditioned, type: Single shaft

Vecoplan Type: VAZ 300/250 UNF, Shredder Built: 1996 Dimensions and weights Machine weight Kg: 24000 Other Drive power 200 KW Rotor diameter 620mm Rotor width 2491 mm Speed 150 1/min Throughput line about 4000kg/h

VECOPLAN VAZ 120/105 U, single shaft shredder for wood, cardboard and paper, transport size : LxWxH 2,49 x 1,88 x 1,35 mt., Infeed size 1,2 x 1,05 m., 235 mm rotor Ø, rotor width 1.070 mm, Weight: approx. 2300kg, Rotor speed: 120 rpm, 18,5 kw 34.5A Electric motor with turbo clutch, V-belt drive, 2-stage, spur gearbox, motor speed 1.455 rpm 400V 50 Hz IP54 des.B3, Cobstructed in 1999, few hours worked, offered reconditioned., installed power - used power in work: about 60-65% : 20, availability: 2 weeks

Manufacturer: Vecoplan Model: VAZ 1300 Year of Manufacture: 2011 Type of Machine : Shredder System Technical Details: - Year of Manufacture: 2011 - Operating Hours: 4,718 - Throughput (depending on material): - Shredding stage P-3: approx. 1,300 kg/h - Shredding stage P-4: approx. 1,000 kg/h Performance Data: - Permissible load lifting device: 600 kg - Max. lifting speed: approx. 6 m/min Shredding performance (depending on screen hole size): - With 15 mm screen: approx. 700–800 kg/h - With 20 mm screen: approx. 1,000 kg/h - With 30 mm screen: approx. 1,300 kg/h Conveyor capacity: - Scraper chain conveyor: approx. 25 m³/h - Scraper chain conveyor speed: approx. 18.8 m/min - Screw conveyor speed: approx. 4.5 m/min Condition: - Shredder is disassembled. - In photos, hopper is rotated 90° and placed loosely. - No discharge conveying system (scraper chain conveyor) included.  ...

Vecoplan injection moulding machine Type: VAZ 160/200 SLF Control: PLC Control built year: 2004 Dimensions and weights Dimensions LxBxH m: 3.5 x 3.75 x 2.34 Machine Weight kg: 19,000 Other Inlet length: 1600 mm inlet width: 2000 mm rotor diameter: 640 mm Double number cutting crowns 48 pieces (80 x 80 mm) rotor speed: 148 UpM screen diameter: 120 mm drive power: 250 kW operating voltage: 400 V frequency: 50 Hz throughput: When face, Precrushed and FE-free material for replacement fuel preparation > 12 t/h at heavy goods with a density of 120 kg/m ³ > 5 t/h at lightweight with a density of 80 kg/m ³ with product grain size < 150 mm more than 98% < 30 mm less than 5%.

Vecoplan S Type: VAZ 300/250 UNF, Shredder Built: 1996 Dimensions and weights Machine weight Kg: 24000 Other Drive power 200 KW Rotor diameter 620mm Rotor width 2491 mm Speed 150 1/min Throughput line about 4000kg/h

Vecoplan injection moulding machine Type: VAZ 200 / 200 SLF control:-year of production: 2003 Dimensions and weights Machine weight kg: 18,000 Other Drive power 132 KW rotor diameter 640mm rotor width 2000 mm speed 120-340 1 / min throughput line about 3000kg / h

Motor power 11 kW hydraulic dock drawer shaft width 800mm Dimensions of the hopper 80x100 cm 15 mm sieve Square knife shaft with rotating drawer motor power 1.8 KW

SPECIFICATIONS: Hopper opening: 1300 x 600 mm Installed power: 15 kW Rotor: Ø 250 mm Rotor width: 600 mm 014 Knife Screen: 16 mm EQUIPMENT: Replacement Knife

A large-format single-shaft shredder Vecoplan is available. Rotor diameter: 370mm, effective rotor length: 1300mm, speed: 120rpm, knife rows: 37, knife dimensions X/Y: 40mm/40mm, feed opening X/Y: 1400mm/1300mm, hopper volume: approx. 3m³. Machine dimensions X/Y/Z: 3200mm/2400mm/1500mm, weight: approx. 5500kg. An on-site inspection is possible.

Single-shaft shredder, waste shredder, cutting mill, auxiliary mill, granulator, shredder, plastic shredder, granulate mill, granulator, rotor mill, recycling technology -Condition: Single-shaft shredder is equipped with a good set of blades. -Manufacturer: Vecoplan, Side-mounted mill cutting mill -Type: VAZ120/105 -Processing capacity: 200-3000 kg/h -Number of sieves: 2 pieces Ø20 mm, Ø30 mm -Drive motor: 18.5 kW -Number of cutting blades: 27 pieces -Number of counter blades: 1 piece -Inlet cross-section: 1240 x 1075 mm -Rotor width: 1075 mm -Rotor diameter: 230 mm -Dimensions: 2000/2700/H2370 mm -Weight: 2800 kg

1 piece scratch chain foerderer 650/500 mm (W/D) length 38 m; good

1 piece of scratch chain foerderer 900/500 mm (W/T) length = 34 m; Very good

4 shaft shredder for crushing of thick-walled pipes. Supply via feeding shaft (not in scope of delivery, can be manufactured alternatively) Manufacturer Vecoplan Drive: Rotorshaft 1: 37 kW Rotorshaft 2-4: 30 kW (each)

ORDER NO. 7026 TECHNICAL SPECIFICATIONS - inlet width 740mm - inlet height 300mm - shaft width 780mm - shaft diameter 1000mm - knife length 780mm - number of knives 2pcs - sieve dimensions 55x55mm - 4 toothed pulling shafts from the bottom - lower shaft motor 5,5kW - 3 toothed pulling shafts from above - upper shaft motor 5,5kW - belt feeder - feed belt length 4300mm - feed belt width 600mm - belt feed motor 2,2kW - main engine 90kW - reverse gear, - autorewers - overall dimensions of the machine length / width / height 4600x2350x1700mm - overall dimensions of the feeder length / width / height 4550x980x970mm - total weight about 11000kg – German production, – used chipper, very good condition Net price: 295900 PLN Net price: 66494 EUR depending on the price 4.45 EUR (Prices may fluctuate with higher fluctuations)

Ripper 1 shaft with hydraulic pusher, brand: Vecoplan, rotor measures: 1600x350 mm, dice: 40x40, motor: 75 Kw (100 hp), hopper measures: 1600x2200 mm. No electrical panel.

CATALOG NO. 7241 TECHNICAL DATA - inlet width 450mm - inlet height 230mm - shaft width 480mm - shaft diameter 380mm - number of knives 4 pcs - sieve size 50x40mm - toothed shaft pulling from above and below - shaft motor approximately 2×1.5kW - electric autoreverse - with conveyor belt - feed belt length 2190mm - feed belt width 440mm - front/backward belt feed - feed motor 1.5kW - main engine 30kW - dimensions length/width/height 3730x1670x1200mm - weight 1750kg – German production – used chipper, very good condition The prices given are net prices. Net price given for international transactions, EX, customers from the EU with an EU Tax Identification Number. Current offer on our website. Net price: 76900 PLN Net price: 17089 EUR depending on the price 4.50 EUR Net price: 20237 USD depending on the price of 3.80 USD (Prices may vary with higher fl ...

Ripper 1 axle, with hydraulic pusher, brand: Vecoplan, rotor measures: 1580x350 mm, die: 40x40, motor: 75 Kw (100 hp), hopper measures: 1580x2200 mm. With electrical panel.

Part Number 7685 SPECIFICATIONS - inlet width 440mm - inlet height 300mm - shaft width 480mm - shaft diameter 440mm - number of knives 2pcs - sieve size 50x50mm - toothed pulling shaft from above and below - shaft motor 0.78/1.1kW - electric autorewers (adjustable) - with conveyor belt - length of the infeed belt 4006mm - width of the feeding belt 380mm - Belt feed front/back - main motor 30kW - dimensions length/width/height 6100x1100x1100mm - weight about 2000kg ADVANTAGES – made in Germany – with a belt feeder – autorewers – used chipper, very good condition Net price: 76900 PLN Net price: 18094 EUR depending on the price of 4.25 EUR (Prices may change with higher fluctuations)

Part Number: 7686 SPECIFICATIONS - inlet width 340mm - inlet height 120mm - shaft width 345mm - number of knives 2pcs -sieve - toothed pulling shaft from above and below - shaft motor about 2×1.1kW - electric autorewers (adjustable) - with conveyor belt - length of the feeding belt 3850mm - width of the feeding belt 340mm - Belt feed front/back - main motor 22kW - extraction spigot diameter 220mm - dimensions length/width/height 5300x1500x1500mm - weight about 1500kg ADVANTAGES – made in Germany – with a belt feeder – autorewers – used chipper, very good condition Net price: 43900 PLN Net price: 10329 EUR depending on the price of 4.25 EUR (Prices may change with higher fluctuations)

Manufacturer: Vecoplan Model: 45/12/2 v Year of Manufacture: 1979 Rotor speed: 680 Gauge size: 98 Condition: Used, good condition Find more here - / Contact us at -

Two Vecoplan scraper chain conveyors are available. 1) VKU 800, year of construction: 2023, drive power: 5.5kW, belt speed: 24m/min, conveying capacity: approx. 120m³/h, belt width: 820mm, max. incline: 70°, section length: 10.2m. 2) VKU 1100, year of construction: 2023, drive power: 11kW, belt speed: 24m/min, conveying capacity: 180m³/h, belt width: 1150mm, max. incline: 70°, section length: 22mm. Documentation available. On-site inspection is possible.

Vecoplan hacker, type 65/22/5 Technical data: - max. infeed width 650 mm - max. infeed height 220 mm - 3 feed rollers at the bottom - 2 feed rollers at the bottom - with new through rollers - excl. drive motor
