Code 71145 Description Horizontal table borer Make UNION Model BFT 80 / 3-1 Serial number 18301 / 34 Year 1986 Spindle 80 mm Spindle taper ISO 40 Spindle out (W) 710 mm Table 1120 x 1000 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 2500 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Size L x W x H 5500 x 3200 x 2800 mm Weigth 9 ton Accessoiries Facing head Ø 460 mm with 180 mm stroke 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead Condition Machine is in good condition

Code 61080 Description Horizontal table borer Make UNION Model BFT 90/3 at Serial number 25 742 Year 1979 ( 1980 in use ) Control Heidenhain TNC 121 Spindle 102 mm Spindle taper ISO 50 Spindle out (W) 710 mm Table 1400 x 1250 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm Weight on table 3000 kg 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 3000 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Accessoiries 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead with 600 mm gap

spindle diameter: 90 mm x-travel: 1000 mm y-travel: 1200 mm z-travel: 1200 mm feed movement: 710 mm spindle taper ISO: 40 turning speed range: 8 - 1600 U/min table-size: 1120 x 1000 mm table rotating: 360 ° table load: 2,5 t total power requirement: 11 kW weight of the machine ca.: 10 t dimensions of the machine ca.: 4,5 x 3,3 x 3 m separate switchboard, rapid feed, some tool holders, without face plate The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 90 mm x-travel: 2000 mm y-travel: 1250 mm z-travel: 1250 mm spindle turning speed range: 8-1600 U/min spindle stroke: 720 mm Feed: 1-2500 mm/U weight of the machine ca.: 9,1 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications: X-axis 2,750 mm Y-axis 2,500 mm Z-axis 2,320 mm W-axis 700 mm Spindle power 50 kW Spindle diameter 130 mm Spindle speed 1.6 – 1,600 rpm. Tool holder SK 50 Control: CNC HEIDENHAIN TNC426 Table dimensions 2,000 x 1,800 mm max. table load 8 tons B-axis 360 A° Weight approx. 37,000 kg

Ref. -No.: 10354 Manufacturer: UNION Year of construction: 1998 Retrofit: 2000 Type of control: Digitale Steuerung 2D Control: HAIDENHAIN TNC 135 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 1600 mm Y-Travel: 1250 mm Z-Travel: 1475 mm Spindle stroke: 710 mm Table Dimensions (Lengthxwidth): 1250x1400 mm Spindle Speed: 1600 RPM Drive Capacity - Spindle Motor: 30 kW Total Power Requirement: 35 kW

Ref. -No.: 10353 Manufacturer: UNION Year of construction: 1986 Type of control: Konventionell Storage location: Halberstadt Country of origin: Deutschland X-Travel: 1600 mm Y-Travel: 1000 mm Z-Travel: 1200 mm W-Axis: 710 mm Spindle Taper: SK 40 Table Load: 2500 kg Max. Size Of Workpiece Lxwxh: Höhe 1400 mm Spindle Speed: 1600 RPM Rapid Traverse: 3,15 m / min Total Power Requirement: 23 kW Weight Of The Machine Ca.: 10,3 t

Ref. -No.: 10022 Manufacturer: UNION Year of construction: 2001 Type of control: CNC Control: Heidenhain-Steuerung TNC 310 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 1600 mm Z-Travel: 2000 mm Machine length: 6950 mm Machine width: 4685 mm Machine Height: 3885 mm Table Height: 1050 mm Spindle Diameter: 110 mm Spindle Taper: ISO 50 Table Dimensions (Lengthxwidth): 1400 x 1600 mm Faceplate speed: 5,6 - 224 RPM Spindle Speed: 5,6 - 1120 RPM Metric thread feeds: 1,25 - 56 mm Drive Capacity - Spindle Motor: 40 kW Weight Of The Machine Ca.: 25 t Bore Depth: W 800 mm Further information: with facing slide 13 inch thread feeds 1 1/8 - 28 Gg / 1 “ YOM: 1990/ Retrofit: 2001

BFT 90/3 SPINDEL 102 , ISO

spindle diameter 130 mm - ISO 50 tool - rated power of the spindle rotation motor 18.5 kW - installed power 4 0kW - spindle drive motor speed range 722-1455 rpm - spindle rotation range 2.25-900 rpm, 27 degrees - disc rotation range 2.25-180 rpm, 18 degrees - X axis feed speed range 0-5000 mm/min, stepless - Y axis feed speed range 0-5000 mm/min, stepless - Z axis feed speed range 0-3150 mm/min, stepless - B axis feed speed range 0-4000 mm/min, for Ø1m, steplessly Bg2Ltmk8Gq - machine weight 30 t

Key data: 102 mm, 1530 mm, 900 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,530 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: Digital readout

Key data: 102 mm, 1600 mm, 900 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,520 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: 3-axis Digital readout with point to point control Heidenhain 310

Key data: 102 mm, 1600 mm, 1250 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 1,250 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm Table load 5 ton R.P.M. 4 – 1,250 (18x) kW 23 Volts 380 Cycles 50

spindle diameter: 130 mm x-travel: 2750 mm y-travel: 2500 mm z-travel: 1050 mm w-axis: 1000 mm Radial face slide diameter: 800 mm radial face slide travel: 240 mm table surface area: 1800x2000 mm turning speeds: 4,8-900 U/min workpiece weight: 8000 kg faceplate speeds from - to: 4,5-180 U/min Feed: 5-2000 mm/min threading: total power requirement: 40 kW weight of the machine ca.: 37 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 102 mm x-travel: 1600 mm y-travel: 1000 mm z-travel: 1600 mm Control: Heidenhain type: TNC 410 table surface area: 1000x1120 mm Table load: 3000 kg spindle stroke: 710 mm spindle turning speed range: 4-1600 U/min main drive motor: 13 kW total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 102 mm x-travel: 1600 mm y-travel: 1210 mm z-axis: 1475 mm spindle travel: 710 mm B-axis (table): 360 ° Table dimensions: 1250x1400 mm Table load: 3500 kg T-slots: 22H7 T-slot - distance: 125 mm spindle turning speed range: 4-1600 U/min spindle drive: 16,5 kW Control: total power requirement: 47 kW weight of the machine ca.: 9,25 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 110 mm x-travel: 1950 mm y-travel: 1600 mm w-axis: 1000 mm spindle turning speed range: 5,6 - 1120 (27x) U/min table load: max. 5-8 t voltage: 380 V total power requirement: 25 kW weight of the machine ca.: . t dimensions of the machine ca.: 1400 x 1600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 102 mm x-travel: 1600 mm y-travel: 1250 mm z-travel: 1600 mm spindle taper ISO: 50 bore spindle stroke: 710 mm main drive motor: 11 kW turning speeds: 1600 U/min Feed: 4000 mm/min Control: Heidenhain type: TNC 135 T-slot - width: 22 mm T-slot - distance: 140 mm table surface area: 1250x1400 mm Table load: 2500 kg total power requirement: 23 kW weight of the machine ca.: 9,3 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 2750 mm y-travel: 2000 mm z-travel: 2330 mm spindle taper ISO: 50 bore spindle stroke: 1000 mm turning speeds: 900 U/min Feed: 2500 mm/min Control: Heidenhain type: TNC 131 T-slot - width: 28 mm table surface area: mm Table load: 8000 kg total power requirement: kW weight of the machine ca.: 37,8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 6500 mm y-travel: 2000 mm z-travel: 900 mm W-axis (spindle longitudinal): 800 mm spindle motor: kW spindle turning speed range: 5 - 1000 U/min total power requirement: 30 kW weight of the machine ca.: 35,5 t dimensions of the machine ca.: - m - Spindle mount: SK 50 - Table size: 1800 x 2000 mm,10t - Angle head - Faceplate with faceplate slide U: 320 mm, - Heidenhain digital Readout, - Counterholder - 2 plate fields The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: - mm x-travel: 1600 mm y-travel: - mm total power requirement: - kW weight of the machine ca.: 13,7 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 90 mm, 1000 mm, 1000 mm

Retrofit built in 2009 Spindle running time - control: 3093 h Switch-on hours: 10585 h - Control HdT TNC 320 - Displacement measurement system in all axes - New drives in all axles - New table, new clamping - New media aggregates Equipment: - Manual control unit - Coolant device - Hydraulic power unit Accessories: - 3D touch probe - Security fence

spindle diameter:130 mm spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-travel:1000 mm w-axis:1075 mm table surface area:2000 x 1800 mm workpiece weight max.:8000 kg spindle turning speed range:4,5 x 900 U/min spindle taper: ISO:50 faceplate turning speed range:4,5 x 180 U/min faceplate diameter:785 mm rapid traverse::5000 mm/min total power requirement:40 kW weight of the machine ca.:35 t dimensions of the machine ca.:5,5 x 6,9 x 5,2 m Machine retrofit and overhould with TNC 360 Heidenhain in 2023 and stepless spindle speeds - table indexing 4 x 90° - facing head 785 mm - exhauster - various arbors and tooling

spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-axis:1520 mm w-axis:1000 mm table surface area:2000 x 1800 mm workpiece weight:8 t spindle motor:18 kW spindle taper ISO:50 spindle turning speed range:4,5 - 900 U/min faceplate diameter:785 mm rapid traverse:5 m/min total power requirement:40 kW dimensions of the machine ca.:5,5 x 6,9 x 5,2 m weight of the machine ca.:35 t Machine was retrofitted in 2023 with HEIDENHAIN TNC 360 CNC control - inf. variable spindle spped - 4 x 90° table positioning - diverse toolholders - dDust exhauster
