used TRUMPF trulaser

Description: Serial nº: A0216L0095 Laser Type: Trudisk 2001 Laser power: 2000 W Power: 400V/50Hz Maximum sheet dimensions: 3000x1500 mm Automatic loading with 2 tables , Working Hours: 17.071 laser capacity: 2 kW, weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 7,974 x 8,972 x 3,004 mm

TRUMPF TruLaser 3030 FIBER laser cutting machine was manufactured in 2014 in Germany. The machine uses state-of-the-art fibre cutting technology for the precise machining of structural steel, stainless steel, aluminium and copper sheets, which guarantees smooth and even edges without any splintering. Thanks to the DetectLine package, which automatically measures the cut crest of the focal point and precisely determines the position of the focal point and the position of the sheet, it is also possible to perform very accurate additional processing of previously cut parts. The TruLaser 3030 FIBER (L49) laser cutting machine is equipped with the reliable TRUMPF TruDisk 3001 disk laser with a power of 3000 W. The energy-saving pulse function and intelligent power management generate a high-quality beam with simultaneously low operating costs and reduced power requirements. Cutting of work ...

TRUMPF TruLaser Cell 7040 3D laser built in 2015 in Germany is the ideal solution for versatile cutting, welding and laser metal deposition (LMD). For all these tasks, the TRUMPF 3D laser cutting machine uses the TruDisk 4001 semiconductor laser and a specially designed 3D head with 5 axes, which can machine not only flat workpieces, but also tubes, closed profiles and very complex shapes. All of this makes this extremely technically advanced machine capable of tackling any challenge in the broad field of automotive engineering. The workpiece placed on one of two work tables is machined by an extremely stable laser beam with a power of up to 4 kW. During machining, the head moves in the three-dimensional cartesian coordinate system and rotates in two axes in the polar coordinate system. This is what gives the universal 3D laser its extraordinary quality and precision, impossible to ac ...

TRUMPF TruLaser 3030 fiber laser built in Germany in 2013, is used for precision machining of workpieces made of structural steel, stainless steel, as well as brass and copper, thanks to special technology data packages equipped in the machine. The extremely efficient and reliable fibre-cutting technology expands the machining possibilities and allows to achieve very smooth and even edges. The laser cutting machine features a robust, durable design that prevents any vibrations from occurring during changes in direction. The enclosed laser body with lift-up roof and fixed guards effectively protect the operator during work. The axes are driven by a direct Torque drive (X-axis) and direct linear drives (Y-axis and Z-axis), which, combined with hardened guideways of the highest manufacture precision, ensure that high accelerations and working speeds are achieved. Generated by the reli ...

TRUMPF TruLaser 3030 laser cutting machine was manufactured in 2011. The machine is equipped with modern components to provide precise cutting of workpieces made of mild steel, stainless steel and aluminium. High stability during processing is ensured by the steel body on which a state-of-the-art SIEMENS SINUMERIK 840D CNC controller is mounted for programming operating modes and control of the cutting process. The TruLaser 3030 Basic Edition laser cutting machine cuts metal sheets with a maximum weight of 900 kg and a thickness of 20 mm (mild steel), 12 mm (stainless steel) and 8 mm (aluminium) using a 3.2 kW laser beam, guaranteeing high precision and smooth and even workpiece edges. The laser is also equipped with an automatic pallet changing system. The total weight of the machine is 11500 kg. Technical data of the TRUMPF TruLaser 3030 laser cutting machine - CNC control: SIEM ...

TRUMPF TruLaser 3030 laser cutting machine was built in 2009 in Germany. The machine designed for cutting workpieces made of steel or aluminium, is ideal for any production facility where precision and the quality of the manufactured parts are the highest priority. The workpieces are machined by an extremely powerful laser beam which, in combination with extensive equipment, allows for rapid cutting of thin sheets with a thickness of up to 1.5 mm. This ensures that the finished workpieces have perfectly smooth and even edges, regardless of the machined material. The offered equipment includes an easy-to-use SIEMENS SINUMERIK 840D CNC controller with 500 MB memory for NC programmes, a table with hydraulic pallet changer and three cutting heads. The TRUMPF TruLaser 3030 Basic Edition laser cutting machine weighs 10500 kg. Technical specifications of the TRUMPF TruLaser 3030 laser - max ...

TRUMPF TruLaser 3030 laser cutting machine built in Germany in 2007 provides excellent laser cutting quality while maintaining low operating costs. Designed for even the most demanding challenges, the machine machines workpieces with a maximum thickness of 12 mm with high precision and quality, making it suitable for any production facility. The stable 2 kW laser beam used during cutting produces very smooth and even edges along the entire length of the workpiece, regardless of the type of material. To further improve the workflow and reduce machine downtime to a minimum, the work table is equipped with an integrated automatic pallet changing system which allows workpieces to be loaded and unloaded simultaneously during the cutting process. The TRUMPF laser cutting machine weighs approximately 11500 kg. Technical specifications of the TRUMPF TruLaser 3030 laser - laser power: 2 kW (2 ...

TRUMPF TruLaser 3030 laser manufactured in 2007 in Germany, is the best choice for any production facility. This reliable and highly efficient machine provides excellent laser cutting quality while maintaining low operating costs, thanks to the use of a reliable laser source with the highest energy efficiency. The stable 2 kW laser beam makes the workpiece edges extremely smooth and even after machining. Machining is performed on a high-quality work table with an integrated automatic pallet changing system. This system allows simultaneous loading and unloading of workpieces during the cutting process, resulting in increased production efficiency and significantly reduced machine downtime. The TRUMPF laser cutting machine weighs approximately 11500 kg. Technical data of the TRUMPF TruLaser 3030 laser cutting machine - laser power: 2 kW (2000 W) - feed rate in the X/Y/Z axis: 3104/ ...

This TRUMPF TruLaser Tube 5000 laser cutting machine was manufactured in 2016. Its equipped with a Co2 Laser Truflow 2000 offering high frequency excitation and a maintenance-free turboradial blower, enhancing operational reliability and efficiency. The laser features precision capabilities, such as a lens cutting head with a 155mm focal length and advanced control features like SINUMERIK 840D SL. The machines versatility is evident in its clamping jaw sets for various diameters and molded shells for different shapes, including round and rectangular tubes. The TRUMPF TruLaser Tube 5000 machine we have for sale is adept at providing high-quality cuts for diverse applications. Contact us for further details regarding this laser cutting machine.

This TRUMPF trulaser 3030 laser cutting machine was manufactured in 2007. It offers a consistent laser power of 3200 W with the ability to handle cutting thicknesses up to 20 mm for steel, and includes efficient waste transportation. The working area spans dimensions of 3000 mm in the X-axis, 1500 mm in the Y-axis, and 115 mm in the Z-axis. The machine also features two interchangeable tables and an additional rotary head for tubes and profiles. For more information about this TRUMPF Trulaser 3030, please reach out to us.

PLANT WILL BE AVAILABLE FROM AUGUST 2023 AND WILL HAVE TO BE POSTPONED FROM PRODUCTION! - Filters for dust extraction were renewed in February 2023. - Hoses for the cooling circuit were replaced about 3 years ago. - Last after-sales service is scheduled for May 2023 Manafacture: Trumpf Type: TruLaser 3030 Year of construction: 2011 Laser: TruFlow 5000 (5 kW cutting power) Control: Trumpf based on Siemens 840D SL Laser switch-on hours: approx. 40,257 h Beam on: approx. 17,157 h Workspace: X-axis 3,000 mm Y-axis 1,500 mm Z-axis 115 mm Maximum sheet thickness: - Mild steel (Ø2) 20 mm - Stainless steel (N2) 15 mm - Aluminium (N2) 10 m Electrical connection: 400V/3Ph/50Hz 105 kVA / 160 A Dimensions & Weight: - Length: 9,300 mm for longitudinal installation, 6,500 mm for transverse installation - Width 4,600 mm for longitudinal installation 7,600 mm for transverse ...

Key data: 1500 mm

Trumpf TruLaser 5030 + Liftmaster LMZ3050 - CO2 Laser Cutting Machine + Loading & Unloading System Laser power:6000 W Working area:3000 x 1500 mm - Trumpf Liftmaster LMZ3050 automatic loading and unloading system - Siemens Sinumerik 840 control system - Trumpf TruFlow 6000 laser source - Laser power 6 kW - Table size 3000 x 1500 mm - Interchangeable table - Hinge belt conveyor - Operating hours beam: approx. 31000 h - Laser operating hours: approx. 57000 h - Year of construction 2013

table length: 3000 mm table width: 1500 mm burner heads: 1 Control: Trumpf total power requirement: 73 kW Laser cutting machine Trumpf TruLaser 3030 Lean Edition Laser power 3200W Type L 20 Year of construction 2012 Net 400V/50Hz Total power requirement 73 kVA Control voltage 24V Fuse 3 x 125 A Air connection 7-10 bar Nitrogen connection 30 bar Oxygen connection 20 bar Beam one hour 7755 Laser one hour 25263 Machine is in very good condition and optimized by Trumpf in 12/2022. Documentation: Completely available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SPECIFICATIONS: TRUMPF TruLaser 2525 - 4 kw (formerly Trumatic L 2530 plus) Working range: 2,500 x 1,250 x 115 mm Control: Siemens Sinumerik 840 D Laser power: 4,000 watts sheet thickness of mild steel: 20 mm sheet thickness stainless steel: 15 mm sheet thickness aluminium: 10 mm STANDARD: - Closed machine frame with integrated laser unit - TFT color screen - Position laser diode - Spraying device - Motion unit for high-precision machining - Additional highly dynamic axis Yp - Drives with maintenance-free three-phase servo motors - Closed beam guidance - Conveyors for small parts and waste - NitroLine - FlyLine - Penetration detection TRUMPF LASER: - CO2 laser TruFlow 3200 - High frequency excitation - Maintenance-friendly turbo radial blower - Gas mixer (integrated) - Laser power control - Logbook function laser CUTTING HEAD: - Laser cutting  ...

Key data: 1500 mm, 3000 mm

Trumpf Trulaser 5030 Classic 6 KW Co2 1500x3000 mm Year of construction 2007 ulpd9bqt 7000 hours open beam damper The system was serviced annually by Trumpf

Trumpf TruLaser 3030 Lase Cutting Machine Power : 5000 W Cutting area : 3000 mm x 1500 mm x 25 mm Automatic pallet changer Conveyor system 2 cutting heads Maintenance has been done by Trumpf BEAM ON:43281 LASER ON:68789

Trumpf Trulaser 3030 Basic Edition Laser Cutting Machine Power : 4000W Maximum cutting thickness: 25 mm BEAM ON: 27320 LASER ON: 44651 MODEL :BASİC EDITION Automatic pallet changer Conveyor system 2 cutting heads Cutting area: 3000X1500X25 Maintenance has been done by Trumpf

Trumpf Trulaser 8000 Laser Cutting Machine (6KW) Cutting area : 8000X2500X25 Maximum cutting thickness : 25 There are 3 pallet on the machine( 1 for 8000 x 2500 and 2 for 4000 x 2500) Automatic pallet changing system Conveyor system 3 cutting heads Maintenance has been done by Trumpf BEAM ON: 43281 LASER ON:68789

We have a Trumpf FIBER TruLaser 3030 (L49) laser cutter for sale. Basic parameters: - X / Y axis working area: 3000 x 1500 mm - Z axis work area, without RotoLas: 115 mm, with RotoLas: 205 mm Maximum sheet thickness: - O2 structural steel: --- 20 mm - N2 stainless steel: --15 mm - N2 aluminum: ---- 15 mm - copper: - 6 mm - brass: ---- 6 mm - titanium: ---- 4 mm ACCURACY: - maximum spread of Ps max position: + -0.03 mm - difference in Pa position: + -0.05 mm - the smallest programmable distance dimension: 0.001 mm Control system: - CNC control: TRUMPF CNC based on the SINUMERIK 840D sl - main memory: PC 2 GB - hard drive: 2 x 160 GB - color monitor: TFT 17 - screen resolution: 1280 x 1024 px - USB connector Connection: -L49 type -Year of production 04-2015 - 4000 watt laser power - network: 400 V / 50 Hz - connected load: 42.0 kVA - control voltage: 24 ...

This Trumpf Trulaser 3030 Laser Cutting machine was manufactured in the year 2007 in Switzerland and has 46150 production hours. It is equipped with a TRUMPF control unit and has 3 axis. The machine has a laser power of 3,0 kW.

This TRUMPF TruLaser 3030 laser cutting machine specializes in precise sheet metal cutting. Its equipped with a CO2 laser TruFlow 3200 and a refined laser control TASC system, complemented by the reliable SINUMERIK 840 D SL control. The cutting area extends to 3000 x 1500 mm, ensuring ample space for various cutting tasks. Noteworthy features include a lens cutting head with a 250 mm lens, a wide longitudinal conveyor belt for material handling, Liftmaster Compact for efficient loading, and an automatic pallet changer to enhance productivity. For further details regarding this TRUMPF laser cutter, please reach out to us.

Trumpf TruLaser 3530 Laser Cutting Machine power 4000 W capacity 1500x3000 in active use Maintenance done on time

Trumpf Trulaser 3530 laser cutting machine 3000 mm x 1500 mm Power : 4 KW Machine is in good condition

Trumpf TruLaser 5030 Laser Cutting Machine 3000 mm x 1500 mm Power : 5 KW

Trumpf TruLaser 3530 Laser Cutting Machine 3000 mm x 1500 mm 4 KW
