used TOS sn

Stock number: 3760 LATHE Manufacturer: TRENS - TOS, Type: SN 50C - 2000 Machine NO.: 08005020060214, Year of construction: 2006 Specifications: Turning length 2000 mm Center height 250 mm Turning over bed 500 mm Ø Turning in recess 700 mm Ø Spindle bore 52 mm Ø Spindle speeds 22-2000 rpm Spindle motor power 5.5 kW Accessories: Tailstock Digital display Jenix - Ikke monteret - not mounted dkk 10.000.- Multi-tool holder Centering chuck mm Ø Universal lining mm Ø Fixed bezel mm Ø Length: 3640 mm, Height: 1540 mm, Width: 1100 mm, Weight: 1890 kg

turning diameter over bed: 590 mm centre distance: 4000 mm turning diameter over slide rest: / mm total power requirement: / kW weight of the machine ca.: / t required space: / m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Universal milling machine SN55/2000 with steady rest.

turning diameter: 0 mm turning length: 3000 mm swing diameter over bed slide: 710 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

TOS SN 500S/1500 universal lathe was built by the Czechoslovakian factory TOS Trenčín. The conventional lathe is used for machining rotating parts such as a shaft or disc with a maximum length of 1500 mm, in single unit or small batch production. The machine’s rigid, stable design with a high-power main motor significantly increases production efficiency and allows full utilisation of the tools. The TOS SN500-S lathe for metal performs machining on workpieces with a maximum diameter of 500 mm (turning over bed), 270 mm (turning over support) or 700 mm (turning in bridge). Workpieces machined on the machine are characterised by excellent quality and precision. The total weight of the TOS SN 500 S 1500 lathe is 1895 kg. Technical parameters of the TOS SN 500S/1500 metal lathe - maximum turning length: 1500 mm - turning diameter in the bridge: 700 mm - turning diameter above th ...

Center height: 255 mm Center distance: 2000 mm Spindle bore: 78 mm TOS - SN 500 SA Universal turning lathe Ø 505 x 2000 mm MACH - ID 6328 Make: TOS Type: SN 500 SA YOP : 2003 Swing over bed Ø   505 mm Swing over cross slide Ø    270 mm Swing in the gap Ø     700 mm DBC Turning Length    2.000 mm Gap length    230 mm Spindle bore     78 mm Spindle power     7,5 kW Stroke pinole      180 mm Spindle taper      5 Mk Speeds / ranges     2000 Rpm Dimensions Length       3.800 mm Width         1.800 mm Height       1.600 mm Weight      2.000 kg

Turning diameter: 630 mm Turning length: 1000 mm Turret positions: 12 CNC Brand: _Unknown / Other TOS - SBL 500 CNC CNC Lathe Ø 630 x 1000 mm C-Axis MACH - ID 6291 Make: TOS Type: SBL 500 CNC YOP: 2001 Max. turning Ø    630 mm X-Axis     320 mm Z-Axis     500 mm Spindle bore      92 mm Speedrange       3000 Rpm Spindle power      17 kW ATC / revolver       12 Speed live tools       4000 Rpm Chip conveyor        yes Dimensions Length     5.500 mm Width       2.200 mm Height      2.100 mm Weight      6.620 kg

Spindle diameter: 100 mm Cross X: 1120 mm Vertical Y: 1250 mm Table length: 1250 mm Table width: 1250 mm Positions ATC: 0   Number of pallets: 0   MAKE   TOS Varnsdorf TYPE     H 100 A YEAR SPECIFICATIONS Controll   Conventionel Floor or table type borer      Table borer X - Travel   1120 mm Y - Travel    1250 mm Z - Travel    1250 mm W - Travel    900 mm Spindle Diameter Ø  100 mm Spindle Taper   MK 6 Spindle speeds / ranges   900 Rpm Table Length x Width    1250 x 1250 mm Table load in kG    3000 Kg DIMENSIONS Length    6000 mm Width     3700 mm Height    3000 mm TOS Varnsdorf H100A Horizontal borer

Table diameter: 1000 mm Turning diameter: 0 mm Turning height: 630 mm Motor power: 40 HP/kW Positions ATC: 0   Positions APC: 0   Make TOS SKJ 8F Type SKJ 8 F Year 1984 Singel column vertical borer TOS SKJ 8 F Centre height (mm)Swing = 1.000 Center distance (mm) Height = 630 Spindle boreLoad = 2.500 Kg Speeds = 500 Rpm5 pos. revolver 2 axis digital read out

Center height: 840 mm Center distance: 2000 mm Spindle bore: 128 mm Make TOS SUA 8 Type Celakovice SUA 80 Numeric Year 2001 TOS Celakovice SUA 80 Numerisch gesteuerte Centre height (mm) Swing bed = 840 Center distance (mm) DBC = 2.000 Spindle bore Bore = 128 HeidenHain Manuel Plus Steady rest fixed 3 chuck 500 mm

Spindle diameter: 130 mm Cross X: 3500 mm Vertical Y: 2000 mm Table length: 1800 mm Table width: 1600 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: Heidenhain CNC Model: TNC 415 Make TOS WH13 CNC Type 1996 Year Heidenhain TNC 415 - 5 Axis tos wh13 cnc cnc table borer tisch bohrwerk kotter Spindle diameter (mm)130/iso50/37kw Table length (mm)1800 Table width (mm)1600 Longitudinal X (mm)3500 Cross Y (mm) 2000 Pos ATC 1250 Number APC.w = 800 1500 rpm

Spindle diameter: 105 mm Cross X: 1800 mm Vertical Y: 1250 mm Table length: 1400 mm Table width: 1250 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: Heidenhain CNC Model: TNC 426 Make TOS WH105 CNC Type WH 105 CNC Year 1998 Tos WH 105 CNC with TNC 426 - 5 Axis Spindle diameter (mm)105 / iso50 / 28 kW Table length (mm) L = 1.400 Table width (mm) W = 1.250 Longitudinal X (mm)X = 1.800 Cross Y (mm)Y = 1.250 Z = 1.250 W = 630 CNC TNC 426 - 5 AxisSpeeds 2800 Rpm

Turning diameter: 1050 mm Turning length: 4000 mm Turret positions: 0 CNC Brand: Heidenhain CNC Model: Manuel Plus Make TOS Variant  Type SUA 100 CNC Variant Year 11 / 2001 tos variant HeidenHain MANUEL PLUS draaibank Centre height (mm)Swing bed =  1.050 Center distance (mm)Swing sup = 730 Spindle bore DBC = 4.000 Bore = 1154 Chuck 800 mm 3 x Steady rest* Mot. tailstock * Feed top slide * Work load 8 T

Universal milling head, milling adapter, milling extension, angled milling head, universal milling angled head, milling angled head -Manufacturer: TOS, universal milling angle head from milling machine TOS FB25-V -Recording output: SK50 -Recording: input gear -Milling head: completely swiveling -Stroke: 55 mm -Rezes recording: mm -Pitch circle: mm -Transport dimensions: 780/490 / H430 mm -Weight: 224 kg

swing diameter: 220 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m for TOS CIRCULAR GRINDING MACHINES of the BUC series 1x steady rest 1x 3-jaw chuck TOS The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MCFHD 80 CNC - TOS KUŘIM Machining center Medium correction made: 2021 System: TNC 407 Warranty: 6 months Availability: 1 month from order IN GEOMETRIC ACCURACY BY MANUFACTURER MCFHD 80 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 4,490 mm Overall width: 5,700 mm Overall height: 3,885 mm Gross weight: 20,500 kg Total power consumption: 75 kVA Working range: X-axis longitudinal stroke 1,000 mm Transverse stroke of the Y axis 750 mm Vertical stroke Z axis 750 mm Positioning the pallet clamping base ° 360 x 1 Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 9 - 2,000 n. min-1 Ex. engine spindle. at 60/100% ED 23.5 / 27.5 (AC) kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 3,000  ...

FSQ 80 (100) O / A3 CNC - TOS KUŘIM Table milling machine, table length 3m System: Heidenhain / optional Availability: according to the selected repair Warranty: according to the selected repair FSQ 80 (100) O / A3 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 7,760 mm Overall width: 4,360 mm Overall height: 3,400 mm Total weight: 18,000 kg Total power consumption: 40 kVA Working range: X-axis longitudinal stroke 3,000 mm Transverse stroke of the Y axis 1,000 mm Vertical stroke Z axis 900 mm Spindle head (head O): Max. performance 22 kW Speed range 11 - 2,500 rpm Number of speed steps smoothly H-V machining, 2.5o rotation X - Y / Z feed range: Number of degrees / range continuously / 1 - 5,000 mm.min-1 Y - Z / X rapid traverse 10,000 / 15,000mm.min-1 Table : Table area 800 x 3,000 mm Max.  ...

FCQV 63 B CNC - TOS KUŘIM Table milling machine System: TNC 407 Warranty: 6 months Availability: 2 weeks from order We have the machine in stock FCQV 63 CNC B - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 5,900 mm Overall width: 3,600 mm Overall height: 3,400 mm Gross weight: 15,500 kg Number of places in the tool magazine: 40 pcs Total power consumption: 65 kVA Working range: X-axis longitudinal stroke 1,500 mm Transverse stroke of the Y axis 630 mm Vertical stroke Z axis 630 mm Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 20 - 3,500 n / min Ex. spindle motor 27.4 kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 2,000 mm / min Rapid traverse 15,000 -15,000 / 10,000 mm / min  ...

FGS 50/63 - TOS KUŘIM Cantilever milling machine Horizontal / vertical axis milling New electrical switchboard + Print. panel Digital measuring of axes Overhaul 2021 Warranty: 12 months Availability: 3 weeks from order STATE OF THE MACHINE IN GEOMETRIC ACCURACY BY MANUFACTURER FGS 50/63 - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 3,060 mm Overall width: 3,350 mm Overall height: 2,500 mm Total weight: 6,500kg Total power consumption: 23 kVA Working range: X-axis longitudinal stroke 1,400 mm Transverse stroke of the Y axis 630 mm Vertical stroke Z axis 500 mm Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range 18 / 35.5 - 1,800 n / min Ex. spindle motor 15 kW Max. twisting mom. on the spindle. 2,500 Nm X - Y / Z feed range: Number of degrees / range 16/10 - 1 800 / 2.5  ...

There are one TOS WH10 TNC and one TOS WH10 CNC available, x-travel: 1250mm, y-travel: 1100mm, z-travel: 1000mm, W-travel: 600mm, table dimensions: 1100x1000mm, with accessories, various tools, holders, spindles, cutter heads, boring heads, tool cabinets and clamping screws.

Table length: 1250 mm Table width: 200 mm Longitudinal X: 600 mm Cross Y: 500 mm Vertical Z: 400 mm MACH-id      5556 MAKE          TOS OLOMOUC TYPE             FA 3 C YOP               2003 SPECIFICATIONS X-Axis       600 mm Y-Axis       500 mm Z-Axis        400 mm Table Length          1250 mm Table Width              200 mm Table load                 100 Kg Spindle speeds         2000 Rpm DIMENSIONS Length        2000 mm Width         1800 mm Height        1550 mm Weight    &nbs ...

Center height: 525 mm Center distance: 10000 mm Spindle bore: 122 mm MACH-id     5192 MAKE          TOS Celakovice CZ TYPE            SU 100 H YOP               2004 SPECIFICATIONS Swing over bed Ø     1050 mm Swing over cross slide        730 mm DBC Turning length      10.000 mm Spindle bore         122 mm Bed width         800 mm Quill Ø      150 mm Stroke pinole        200 mm Spindle taper       Mk        5 Mk Workpiece weight       8000 Kg Power     37 kW Feed rate  X-Axis      1000 mm/min. DIMENSIONS Length  ...

Center height: 250 mm Center distance: 1500 mm Spindle bore: 77 mm MACH-id   4177 MAKE       TOS Trencin TYPE         SN 500 SA YEAR        90 er SPECIFICATIONS Swing over bed Ø 505 mm Swing over cross slide    270 mm Swing in the gap Ø    700 mm Distance between centres    1500 mm Spindle bore    77 mm Spindle speeds / ranges      2000 Rpm Power     5.5 Kw DIMENSIONS Length    3500 mm Width     1400 mm Height      1600 mm

Spindle diameter: 100 mm Cross X: 1250 mm Vertical Y: 900 mm Table length: 1120 mm Table width: 1000 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: Siemens CNC Model: Sinumerik MAKE   TOS Varnsdorf TYPE    WH 10 CNC YEAR   80 er SPECIFICATIONS Controll    Siemens Sinumrik Floor or table type borer  Table borer X - Travel   1250 mm Y - Travel     900 mm Z - Travel     630 mm W - Travel   1000 mm Spindle Diameter Ø   100 mm Spindle Taper    ISO 50 kW power on spindle   30 kW Spindle speeds / ranges    1300 Rpm Table Length x Width    1120 x 1000 mm Table load in kG    3000 Kg Number off controlled axis    4 DIMENSIONS Length    4500 mm Width      3800  ...

Turning diameter: 1300 mm Turning height: 1150 mm Chuck diameter: 1000 mm Number of chucks: 1   CNC Brand: Siemens CNC Model: Sinumerik MAKE   TOS CZ TYPE    SKJ 10 B YEAR   1987 SPECIFICATIONS Controll    Siemens Sinumrik Max. turning diamter Ø   1300 mm Table / chuck size  Ø  1000 mm Workpiece height   1150 mm Work piece weight   2500 Kg Horizontal movement support / ram  750 mm Angle adjustment / ram swivable  Swivel    ATC tool changer   5 Power    40 Kw DIMENSIONS Length   4100 mm Width     3400 mm Height    3100 mm
