used
CNC Milling Machine Fabr. TOS CELAKOVICE Type FNG 32 NCMash. -No: 7200075Table longitudinal path X: 600 mmUpper arm lateral travel Y: 400 mmTable perpendicular path Z: 400 mmSpindle mount: ISA 40stepless speeds: 10 - 3150 rpm.stepless feed rates in 3 axes: 1 - 9000 mm / min.Weight approx: 2.6 tDrive power: 10 kVAWith- CNC control Heidenhain TNC 155- rigid angle tablelittle usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Code 1810 DESCRIPTION CNC Universal milling machine Make TOS Model FNG 63 CNC S/N 16663 Year 1991 Control Heidenhain TNC 355 Table 1120 x 630 mm Longitude ( X – axis ) table 800 mm Vertical ( Y – axis ) table 500 mm Cross ( Z – axis ) spindle 630 mm Spindle movement ( H/V ) 100 mm Spindle taper 40 ISO Speeds 20 - 4000 rpm Feeds X-Y-Z 1 – 7500 mm/min Rapides 7,5 m/min Spindle motor 11 kW – 380 Volts Accessories Table 1120 x 630 mm Coolant Condition Machine is in normal condition
used
TOS-OSO FNK 2R - Tool milling machine Description- Heidenhain PT 855 position indicator - Infinitely variable speed adjustment - pneumatic tool clamp - Coolant device - Task lighting -Vice - incl. instruction manual & documents - Year of construction 2006 Specification - Table dimensions: 250 x 1100 mm - T-slots number x spacing: 4x 50 mm - Middle groove width: 14 mm H8 - Width of additional grooves: 14 mm - Max. permissible table load: 200 kg - Manual table work stroke lengthwise/crosswise/vertically: 840 / 376 / 460 mm - Motorized table work stroke longitudinal/transverse/vertical: 820 / 355 / 440 mm - Number of feed stages: infinitely variable - Feed range long/cross: 28 - 630 mm/min - Feed range vertical (reduction 1:3.3): 8.5 - 196 mm/min - Rapid feed longitudinal/transverse: 1500 mm/min - Rapid feed vertical (reduction 1:3.3): 450 mm/min - Distance from sp ...
used
Machine Type: Tool Milling Machine Manufacturer: TOS Model: FNGJ 32 Machine No.: 0101896 Year of construction: 1990 Condition: very good Offer Type: Used Machine Specifications: Table: 795 x 400 mm Speed range: 40 – 2000 rpm. Spindle mount: SK40 Travel range: x = 600 mm y = 400 mm z = 400 mm Propulsion: 3.0 kW Remark: Heidenhain VRZ 650 3-axis digital display, coolant device, 5 tool holders SK 40 Weight: 2100 kg The machine is in a very good condition and ready for immediate use and can be viewed and demonstrated by us. We would be pleased if you are interested in our offer. Errors, modifications and prior sale excepted.
used
CNC tool milling machine TOS Žebrák Manufacturer: Intos Žebrák Type: FNG 50 CNC E Year of construction 2001 Control system: Heidenhain TNC 426 Spindle taper: ISO40 (SK40) Spindle speed: 0-3150 rpm Axle travel: X-700mm Y-500mm Z-500mm Machine weight:2550 kg Rotatable head: -90° ~ +90° Accessories: Documentation Riding bike Cooling Tool holder see photo
used
Table clamping area: 290 x 1250 mm Table movement x: 800 mm Table movement y: 360 mm Table movement z: 450 mm Milling head pivotable: 90/45 ° Spindle holder: ISA 40 Spindle speeds: 56 - 4500 rpm Pinolene stroke: 125 mm Pinolene feeds: 0.035; 0,14; 0.7 mm/min Spindle drive: 1.8/2.4 kW Space requirement: 2000 x 1900 x 2300 mm Weight: 1700 kg
used
The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Year 1993 Heidenhain 415F Parameters: ISO 40 spindle Table dimensions 800x400 mm X-axis travel 500 mm Travel of the Y axis 400 mm Z axis travel 400 mm Spindle clamping cone ISO 40. Spindle speed 10 - 3150 /min. Max. workpiece weight 300 kg Dimensions LxWxH 2800x2700x1980 mm Machine weight 2600 kg Power of the main electric motor 4.5 kW
used
Heidenhain TNC 124 Universal table 630x400 mm Spindle speed 63-3150 1/min, SK 40 Travel X/Y/Z 600/400/400mm Vertical milling head with manual quill Counter bearing arm with counter bearing Partial enclosure hinged Need for repair in Y-axis
used
x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm table-size: 800x400 mm quill stroke: ca. 100 mm turning speed - milling spindle: 40-2000 U/min feed range: X, Y: 8-400 mm/min feed range: Z: 4-200 mm/min rapid travel - x-direction: 2000 mm/min rapid travel in y-direction: 2000 mm/min rapid traverse cross: 1000 mm/min vertical head swivelling: +/- 90 Grad weight of the machine ca.: 2 t dimensions of the machine ca.: 2,1x1,7x1,7 m Universal milling machine with DRO for 3 axis, sviweable vertical milling head and horizontal milling spindle. -incl. knee and milling 3 arbors for milling discs -incl. 9 tool holder ISO 40 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 600 mm y-travel: 400 mm z-travel: 400 mm spindle taper ISO: 40 quill stroke: 100 mm spindle turning speed range: 40 - 2000 U/min voltage: 380 V Table dimensions: 800 x 400 mm weight: 1,9 t total power requirement: 3,0 kW dimensions of the machine ca.: 1,90 x 1,80 x 1,90 m digital readout, 3-axis: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
The machine is in good technical condition, fully functional, possibility of testing, loading provided. Measuring Heidenhain Positip 855 including controlled axes. Machine weight: 1725 kg Table clamping area: 800x400 mm Table longitudinal movement - x-axis: 600 mm Transverse table movement - z-axis: 400 mm Vertical table movement - y-axis: 400 mm Machine dimensions d x w x h : 1830 x 1645 x 1735 mm
used
x-travel:800 mm y-travel:630 mm z-travel:500 mm feed stepless:1-7500 mm/min rapid traverse feeds:7500 mm/min tool cone:40 ISO spindle drive motor:10 kW turning speed range - spindle:20-4000 U/min Torque of spindles:630 Nm total connected load:25 kW weight of the machine ca.:5 t dimensions of the machine ca.:15 qm 100 % before loading warranty: none The machine is in very good condition (only one prior owner), only few operating hours. Machine was installed first time and equipped with CNC Heidenhain TNC 355 in 1996. Other optional accessories can be delivered. Price basis: ex stock, free on truck time of delivery: immediatly, prior sales reserved payment:100% before loading warranty: none techn. documentation: as available.
used
TOS SN 500S/1500 universal lathe was built by the Czechoslovakian factory TOS Trenčín. The conventional lathe is used for machining rotating parts such as a shaft or disc with a maximum length of 1500 mm, in single unit or small batch production. The machine’s rigid, stable design with a high-power main motor significantly increases production efficiency and allows full utilisation of the tools. The TOS SN500-S lathe for metal performs machining on workpieces with a maximum diameter of 500 mm (turning over bed), 270 mm (turning over support) or 700 mm (turning in bridge). Workpieces machined on the machine are characterised by excellent quality and precision. The total weight of the TOS SN 500 S 1500 lathe is 1895 kg. Technical parameters of the TOS SN 500S/1500 metal lathe - maximum turning length: 1500 mm - turning diameter in the bridge: 700 mm - turning diameter above th ...
used
Center height: 255 mm Center distance: 2000 mm Spindle bore: 78 mm TOS - SN 500 SA Universal turning lathe Ø 505 x 2000 mm MACH - ID 6328 Make: TOS Type: SN 500 SA YOP : 2003 Swing over bed Ø 505 mm Swing over cross slide Ø 270 mm Swing in the gap Ø 700 mm DBC Turning Length 2.000 mm Gap length 230 mm Spindle bore 78 mm Spindle power 7,5 kW Stroke pinole 180 mm Spindle taper 5 Mk Speeds / ranges 2000 Rpm Dimensions Length 3.800 mm Width 1.800 mm Height 1.600 mm Weight 2.000 kg
used
Turning diameter: 630 mm Turning length: 1000 mm Turret positions: 12 CNC Brand: _Unknown / Other TOS - SBL 500 CNC CNC Lathe Ø 630 x 1000 mm C-Axis MACH - ID 6291 Make: TOS Type: SBL 500 CNC YOP: 2001 Max. turning Ø 630 mm X-Axis 320 mm Z-Axis 500 mm Spindle bore 92 mm Speedrange 3000 Rpm Spindle power 17 kW ATC / revolver 12 Speed live tools 4000 Rpm Chip conveyor yes Dimensions Length 5.500 mm Width 2.200 mm Height 2.100 mm Weight 6.620 kg
used
Spindle diameter: 100 mm Cross X: 1120 mm Vertical Y: 1250 mm Table length: 1250 mm Table width: 1250 mm Positions ATC: 0 Number of pallets: 0 MAKE TOS Varnsdorf TYPE H 100 A YEAR SPECIFICATIONS Controll Conventionel Floor or table type borer Table borer X - Travel 1120 mm Y - Travel 1250 mm Z - Travel 1250 mm W - Travel 900 mm Spindle Diameter Ø 100 mm Spindle Taper MK 6 Spindle speeds / ranges 900 Rpm Table Length x Width 1250 x 1250 mm Table load in kG 3000 Kg DIMENSIONS Length 6000 mm Width 3700 mm Height 3000 mm TOS Varnsdorf H100A Horizontal borer
used
Table diameter: 1000 mm Turning diameter: 0 mm Turning height: 630 mm Motor power: 40 HP/kW Positions ATC: 0 Positions APC: 0 Make TOS SKJ 8F Type SKJ 8 F Year 1984 Singel column vertical borer TOS SKJ 8 F Centre height (mm)Swing = 1.000 Center distance (mm) Height = 630 Spindle boreLoad = 2.500 Kg Speeds = 500 Rpm5 pos. revolver 2 axis digital read out
used
Center height: 840 mm Center distance: 2000 mm Spindle bore: 128 mm Make TOS SUA 8 Type Celakovice SUA 80 Numeric Year 2001 TOS Celakovice SUA 80 Numerisch gesteuerte Centre height (mm) Swing bed = 840 Center distance (mm) DBC = 2.000 Spindle bore Bore = 128 HeidenHain Manuel Plus Steady rest fixed 3 chuck 500 mm
used
Spindle diameter: 130 mm Cross X: 3500 mm Vertical Y: 2000 mm Table length: 1800 mm Table width: 1600 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: Heidenhain CNC Model: TNC 415 Make TOS WH13 CNC Type 1996 Year Heidenhain TNC 415 - 5 Axis tos wh13 cnc cnc table borer tisch bohrwerk kotter Spindle diameter (mm)130/iso50/37kw Table length (mm)1800 Table width (mm)1600 Longitudinal X (mm)3500 Cross Y (mm) 2000 Pos ATC 1250 Number APC.w = 800 1500 rpm
used
Spindle diameter: 105 mm Cross X: 1800 mm Vertical Y: 1250 mm Table length: 1400 mm Table width: 1250 mm Positions ATC: 0 Number of pallets: 0 CNC Brand: Heidenhain CNC Model: TNC 426 Make TOS WH105 CNC Type WH 105 CNC Year 1998 Tos WH 105 CNC with TNC 426 - 5 Axis Spindle diameter (mm)105 / iso50 / 28 kW Table length (mm) L = 1.400 Table width (mm) W = 1.250 Longitudinal X (mm)X = 1.800 Cross Y (mm)Y = 1.250 Z = 1.250 W = 630 CNC TNC 426 - 5 AxisSpeeds 2800 Rpm
used
Turning diameter: 1050 mm Turning length: 4000 mm Turret positions: 0 CNC Brand: Heidenhain CNC Model: Manuel Plus Make TOS Variant Type SUA 100 CNC Variant Year 11 / 2001 tos variant HeidenHain MANUEL PLUS draaibank Centre height (mm)Swing bed = 1.050 Center distance (mm)Swing sup = 730 Spindle bore DBC = 4.000 Bore = 1154 Chuck 800 mm 3 x Steady rest* Mot. tailstock * Feed top slide * Work load 8 T
used
Universal milling head, milling adapter, milling extension, angled milling head, universal milling angled head, milling angled head -Manufacturer: TOS, universal milling angle head from milling machine TOS FB25-V -Recording output: SK50 -Recording: input gear -Milling head: completely swiveling -Stroke: 55 mm -Rezes recording: mm -Pitch circle: mm -Transport dimensions: 780/490 / H430 mm -Weight: 224 kg
used
swing diameter: 220 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m for TOS CIRCULAR GRINDING MACHINES of the BUC series 1x steady rest 1x 3-jaw chuck TOS The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
MCFHD 80 CNC - TOS KUŘIM Machining center Medium correction made: 2021 System: TNC 407 Warranty: 6 months Availability: 1 month from order IN GEOMETRIC ACCURACY BY MANUFACTURER MCFHD 80 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 4,490 mm Overall width: 5,700 mm Overall height: 3,885 mm Gross weight: 20,500 kg Total power consumption: 75 kVA Working range: X-axis longitudinal stroke 1,000 mm Transverse stroke of the Y axis 750 mm Vertical stroke Z axis 750 mm Positioning the pallet clamping base ° 360 x 1 Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 9 - 2,000 n. min-1 Ex. engine spindle. at 60/100% ED 23.5 / 27.5 (AC) kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 3,000 ...
