used TOS du

Bezel, stick, lynette -Max. Passage: Ø 107 mm -Tip height: 180 mm -Edition: gray cast iron -technical drawing with the photos -Dimensions: 370/340/H80 mm -Weight: 16 kg

Bezel, stick, lynette -max. passage: Ø 107 mm -Tip height: 180 mm -Edition: gray cast iron -Technical drawing in the photos -Dimensions: 370/340/H80 mm -Weight: 16 kg

Bezel, stick, lynette -Max. Passage: Ø 150 mm -Tip height: 320 mm -Dimensions: 650/500/H110 mm -Weight: 50 kg

Moving steady rest, moving steady rest, steady rest, lynette -Max. Passage: Ø 120 mm -Edition: gray cast iron -Hole spacing: 135 mm -Tip height: 145 mm -Drawing with the photos -Number: 3x bezels available -Price: per piece -Dimensions: 370/280/H90 mm -Weight: 10 kg

Moving steady rest, moving steady rest, steady rest, lynette -Max. Passage: Ø 120 mm -Edition: gray cast iron -Hole spacing: 135 mm -Tip height: 145 mm -Drawing with the photos -Dimensions: 370/280/H90 mm -Weight: 10 kg

Dividing head, dividing head, rotary table, rotary table -with translation: 1:40 -Admission inside: MK4 -Tip height: mm -Passage: Ø 32 mm -Part head: swiveling -Dimensions: 430/430/H280 mm -Weight: 83 kg

Tailstock, counter bearing for dividing head, dividing attachment -Tip height: 135 mm -Recording: MK2 -Drawing with the photos -Price: per piece -Number: 2 pieces -Dimensions: 200/75/H145 mm -Weight: 5 kg

Moving steady rest, moving steady rest, steady rest, lynette -Max. Passage: Ø 200 mm -Plating: brass -Tip height: 230 mm -Drawings with the photos -Price: per piece -Number: 1x available -Dimensions: 530/200/H740 mm -Weight: 100 kg

Dividing head, dividing head, rotary table, rotary table -with translation: 1:40 -Admission inside: MK4 -Tip height: 100 mm -Part head: swiveling -Dimensions: 320/320/H230 mm -Weight: 37 kg

Max. working diameter: 630mm Distance between tines: 3500mm 5 lunettes fixed and movable.

The machine is in good technical condition. Circulating diameter above the bed: 630mm Distance between points: 4000mm Accessories: chucks, lunettes weight: 3,500 kg Upon prior arrangement, the possibility of inspection while in operation. Year of manufacture/SO/GO: 1979/-/1993

Point lathe SN 55 / 4000 in good technical condition, including lunette. Total machine input:: 7.5 kW Circulating diameter above the bed: 550 mm Revolving diameter above support: 310 mm Distance between spikes: 4000 mm Spindle drilling: 71 mm Spindle speed - range: 90-1000 Working feed - number of steps: 16 Working feed - range: 38 mm/min

The machine is in good technical condition, after prior agreement it is possible to test it. Circulating diameter above bed 800 mm Distance between spikes 4000 mm Circulating diameter above support 520 mm Machine weight 6400 kg

TOS SN 500S/1500 universal lathe was built by the Czechoslovakian factory TOS Trenčín. The conventional lathe is used for machining rotating parts such as a shaft or disc with a maximum length of 1500 mm, in single unit or small batch production. The machine’s rigid, stable design with a high-power main motor significantly increases production efficiency and allows full utilisation of the tools. The TOS SN500-S lathe for metal performs machining on workpieces with a maximum diameter of 500 mm (turning over bed), 270 mm (turning over support) or 700 mm (turning in bridge). Workpieces machined on the machine are characterised by excellent quality and precision. The total weight of the TOS SN 500 S 1500 lathe is 1895 kg. Technical parameters of the TOS SN 500S/1500 metal lathe - maximum turning length: 1500 mm - turning diameter in the bridge: 700 mm - turning diameter above th ...

Center height: 255 mm Center distance: 2000 mm Spindle bore: 78 mm TOS - SN 500 SA Universal turning lathe Ø 505 x 2000 mm MACH - ID 6328 Make: TOS Type: SN 500 SA YOP : 2003 Swing over bed Ø   505 mm Swing over cross slide Ø    270 mm Swing in the gap Ø     700 mm DBC Turning Length    2.000 mm Gap length    230 mm Spindle bore     78 mm Spindle power     7,5 kW Stroke pinole      180 mm Spindle taper      5 Mk Speeds / ranges     2000 Rpm Dimensions Length       3.800 mm Width         1.800 mm Height       1.600 mm Weight      2.000 kg

Turning diameter: 630 mm Turning length: 1000 mm Turret positions: 12 CNC Brand: _Unknown / Other TOS - SBL 500 CNC CNC Lathe Ø 630 x 1000 mm C-Axis MACH - ID 6291 Make: TOS Type: SBL 500 CNC YOP: 2001 Max. turning Ø    630 mm X-Axis     320 mm Z-Axis     500 mm Spindle bore      92 mm Speedrange       3000 Rpm Spindle power      17 kW ATC / revolver       12 Speed live tools       4000 Rpm Chip conveyor        yes Dimensions Length     5.500 mm Width       2.200 mm Height      2.100 mm Weight      6.620 kg

Spindle diameter: 100 mm Cross X: 1120 mm Vertical Y: 1250 mm Table length: 1250 mm Table width: 1250 mm Positions ATC: 0   Number of pallets: 0   MAKE   TOS Varnsdorf TYPE     H 100 A YEAR SPECIFICATIONS Controll   Conventionel Floor or table type borer      Table borer X - Travel   1120 mm Y - Travel    1250 mm Z - Travel    1250 mm W - Travel    900 mm Spindle Diameter Ø  100 mm Spindle Taper   MK 6 Spindle speeds / ranges   900 Rpm Table Length x Width    1250 x 1250 mm Table load in kG    3000 Kg DIMENSIONS Length    6000 mm Width     3700 mm Height    3000 mm TOS Varnsdorf H100A Horizontal borer

Table diameter: 1000 mm Turning diameter: 0 mm Turning height: 630 mm Motor power: 40 HP/kW Positions ATC: 0   Positions APC: 0   Make TOS SKJ 8F Type SKJ 8 F Year 1984 Singel column vertical borer TOS SKJ 8 F Centre height (mm)Swing = 1.000 Center distance (mm) Height = 630 Spindle boreLoad = 2.500 Kg Speeds = 500 Rpm5 pos. revolver 2 axis digital read out

Center height: 840 mm Center distance: 2000 mm Spindle bore: 128 mm Make TOS SUA 8 Type Celakovice SUA 80 Numeric Year 2001 TOS Celakovice SUA 80 Numerisch gesteuerte Centre height (mm) Swing bed = 840 Center distance (mm) DBC = 2.000 Spindle bore Bore = 128 HeidenHain Manuel Plus Steady rest fixed 3 chuck 500 mm

Spindle diameter: 130 mm Cross X: 3500 mm Vertical Y: 2000 mm Table length: 1800 mm Table width: 1600 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: Heidenhain CNC Model: TNC 415 Make TOS WH13 CNC Type 1996 Year Heidenhain TNC 415 - 5 Axis tos wh13 cnc cnc table borer tisch bohrwerk kotter Spindle diameter (mm)130/iso50/37kw Table length (mm)1800 Table width (mm)1600 Longitudinal X (mm)3500 Cross Y (mm) 2000 Pos ATC 1250 Number APC.w = 800 1500 rpm

Spindle diameter: 105 mm Cross X: 1800 mm Vertical Y: 1250 mm Table length: 1400 mm Table width: 1250 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: Heidenhain CNC Model: TNC 426 Make TOS WH105 CNC Type WH 105 CNC Year 1998 Tos WH 105 CNC with TNC 426 - 5 Axis Spindle diameter (mm)105 / iso50 / 28 kW Table length (mm) L = 1.400 Table width (mm) W = 1.250 Longitudinal X (mm)X = 1.800 Cross Y (mm)Y = 1.250 Z = 1.250 W = 630 CNC TNC 426 - 5 AxisSpeeds 2800 Rpm

Turning diameter: 1050 mm Turning length: 4000 mm Turret positions: 0 CNC Brand: Heidenhain CNC Model: Manuel Plus Make TOS Variant  Type SUA 100 CNC Variant Year 11 / 2001 tos variant HeidenHain MANUEL PLUS draaibank Centre height (mm)Swing bed =  1.050 Center distance (mm)Swing sup = 730 Spindle bore DBC = 4.000 Bore = 1154 Chuck 800 mm 3 x Steady rest* Mot. tailstock * Feed top slide * Work load 8 T

Universal milling head, milling adapter, milling extension, angled milling head, universal milling angled head, milling angled head -Manufacturer: TOS, universal milling angle head from milling machine TOS FB25-V -Recording output: SK50 -Recording: input gear -Milling head: completely swiveling -Stroke: 55 mm -Rezes recording: mm -Pitch circle: mm -Transport dimensions: 780/490 / H430 mm -Weight: 224 kg

swing diameter: 220 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m for TOS CIRCULAR GRINDING MACHINES of the BUC series 1x steady rest 1x 3-jaw chuck TOS The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MCFHD 80 CNC - TOS KUŘIM Machining center Medium correction made: 2021 System: TNC 407 Warranty: 6 months Availability: 1 month from order IN GEOMETRIC ACCURACY BY MANUFACTURER MCFHD 80 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 4,490 mm Overall width: 5,700 mm Overall height: 3,885 mm Gross weight: 20,500 kg Total power consumption: 75 kVA Working range: X-axis longitudinal stroke 1,000 mm Transverse stroke of the Y axis 750 mm Vertical stroke Z axis 750 mm Positioning the pallet clamping base ° 360 x 1 Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 9 - 2,000 n. min-1 Ex. engine spindle. at 60/100% ED 23.5 / 27.5 (AC) kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 3,000  ...
