7 STUDER cylindrical grinding machines used machines

STUDER S30-1 CE – Universal Cylindrical Grinding Machine – Integral Retrofit STUDER S30-1 CE high-precision universal cylindrical grinding machine, designed for external and internal grinding work. - Manufacturer: STUDER - Model: S30-1 - Distance between points: 1,000 mm - Height between dots: 175 mm - CE marking - Application: External and internal cylindrical grinding The machine has undergone a complete reconstruction and retrofit process in our facilities, intervening in the main mechanical and electrical assemblies. The work carried out includes: - Reconditioning of the guides. - Replacement of bearings. - Renovation of the electrical installation. - Renovation of the electrical cabinet. - Review and adjustment of the main mechanical assemblies. - Complete painting of the machine. - Adjustment and verification of geometry. - Fine-tuning and f ...

CNC cylindrical grinding machine, STUDER S31 CNC LeanPro, with Pictogramming, Distance between centers: 1000mm, Center heigh 175mm, Grinding Wheel head rotation (B) 360° (1°), 2 ext Grinding Wheels, 1 int Grinding Wheel > 20000 RPM spindle + 60000 RPM spindle, Ext Grinding wheel, 400 mm x 40 mm x 127 mm, Workhead, CM 4, 0-1000 RPM, CNC Fanuc, Programming: Pictogramming, Heidenhain linear encoders, This machine can be inspected under power in our warehouse in Gussago BS Italy

MAX DIAM 450 . MAX LENGHT 1600

Distance between centers: 1000 mm, Distance between points: 1000 mm, Height of points: 175 mm, Main engine power: 7.5 Kw, Working wheel dimensions (od x id x width): Ø500 x Ø203.2 x 80 mm, Ø max to be rectified: 350 mm, Max. diameter to be rectified: 350 mm, tailstock cone: MORSE 3, Workpiece head cone: MORSE 4, Workpiece holder head cone: MORSE 4, Max travel Z axis: 1150 mm, Max. X axis travel: 275 mm, Max travel X axis: 275 mm, Approximate dimensions (length x width x height): 5,200 x 2,300 x 2084, Approx. dimensions (length x width x height): 5,200 x 2,300 x 2084, Weight approx.: 7000 Kg

Distance between points: 1000 mm, Height of the points: 175 mm, Point height: 175 mm, Grinding length: 500 mm, grinding length: 500 mm, Max. diameter to be rectified: 300 mm, Working wheel dimensions (od x id x width): Ø500 x Ø203 x 80/100 mm, Ø max to be rectified: 300 mm, Inner cone: Morse 5, inner cone: Morse 5, Working wheel motor power: 7.5 Kw, Total power: 17 Kw, Longitudinal travel of the carriage (X axis): 267 mm, Transverse travel of the carriage (Z axis): 650 mm, CNC brand: FANUC, cnc brand: FANUC, CNC model: 16-T, cnc model: 16-T, Grinding wheel speed: 0-1670 rpm, Turning range: +/- 8.5º, Dimensions: 2600 mm x 2300 mm x 2100 mm, Weight approx.: 4200 Kg

Year of retrofitting: 2025, Maximum distance between points: 1000 mm, Max distance between points: 1000 mm, Max travel Z axis: 650 mm, Max. Z-axis travel: 650 mm, Max. travel X axis: 254 mm, Max travel X axis: 254 mm, Height of points: 175 mm, Ø max to rectify: 350 mm, Main engine power: 7.5 Kw, Max. diameter to be rectified: 350 mm, Max. piece weight: 130 Kg, Control type (CNC/manual): CNC, CNC brand: FANUC, CNC model: Oi-TF PLUS, Dimensions of the grinding wheel: Ø500 x Ø203 x 80 mm, Angle of tilt of the work spindle head: + / -8,5°, Long: 2500 mm, Grinding wheel dimensions: Ø500 x Ø203 x 80 mm, Width: 2300 mm, Height: 2000 mm, Weight approx.: 3500 Kg, Angle of inclination of the work wheel head: + / -8.5°

Distance between points: 650 mm, Max external diameter to be rectified: 320 mm, Working wheel dimensions (od x id x width): Ø400 x Ø127 x 80 mm, Ø interior max to be rectified: 140 mm, Height of points: 175 mm, Control type (CNC/manual): CNC, CNC brand: SIEMENS, CNC model: SINUMERIC 3G7, Maximum length to be rectified: 650 mm, Max. piece weight: 130 Kg, Main engine power: 5.5 Kw, Total power: 22 KVA, Max. revolutions of the workhead: 30 - 750 rpm, Strain: 380 V / 50 Hz, X-axis feed: 0.01 – 5,000 mm/min, Z-axis feed: 0.06 – 10,000 mm/min, Air pressure: 5 bar, Max travel X axis: 275 mm, Max travel Z axis: 700, Max. rotation of workpiece table: 8.5º, Inner cone of workpiece head: M 5, tailstock cone: M 3, Counterpoint reed route: 35 mm, Dimensions (length x width x height): 2,815mm x 1,875mm x 2,090mm, Weight: 3.600 Kg

grinding diameter: 250 mm grinding length: 1000 mm centre height: 125 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Complete disassembly Cylindrical grinding machine STUDER RHU 500 – MIRA Retrofit We have a complete exploded view from a STUDER RHU 500 cylindrical grinding machine, ideal for spare parts, repair or maintenance. The machine has been dismantled by MIRA Retrofit, specialists in the reconstruction and modernization of grinding machines, preserving its main assemblies and components for sale as spare parts. Available, among others: - Workpiece holder head and its components. - Tailstock headstock. - Grinding head and grinding assemblies. - Motors and drives. - Spindles and mechanical elements. - Trolleys, guides and moving elements. - Steering wheels, controls and mechanisms. - Hydraulic and pneumatic components. - Electrical elements. - Protections, supports and accessories. - Different original STUDER parts. Sale by individual components or possibil ...

STUDER S30 Favorit – High-precision universal cylindrical grinding machine Completely refurbished and modernized machine (complete retrofit), intended for cylindrical grinding of exterior and interior surfaces. Technical data: - Distance between points: 650 mm - Height between dots: 175 mm - External and internal grinding - Fagor digital measurement system Complete Refurbishment / Retrofit: - The machine has been completely disassembled and rebuilt piece by piece. Work carried out: - Complete mechanics overhaul - Revision and refurbishment of the guides - Refurbishment/overhaul of bearings and wear elements - Completely new electrical cabinet - New electrical installation and wiring - Complete modernization of the electrical system - Installation of Fagor digital visualizer - Review and adjustment of all sets - Full geometric adjustment and precisio ...

centre height: 175 mm grinding length: 650 mm grinding diameter: 350 mm control: Fanuc 0i-TD Resolution: 0,0001 mm grinding spindle head:: grinding wheel turining speeds: 1-2810 U/min grinding spindle - swivable: 0-15 -30 ° grinding wheel size: 500 x 63 x 203 mm peripheral speed: max. 50 m/sec power capacity: 11,5 kW workpiece spindle head:: Number of revolutions: 1-1500 U/min power capacity: 1,8 kW spindle passage: 26 mm Fitting taper: MK 4 Tailstock:: taper of center: MK 3/4 quill stroke: 35 mm diameter of quill: 50 mm fine adjustment: +/- 0,04 mm axis stroke:: x-axis: 370 mm z-axis: 800 mm b-axis: ? ° feeds:: feed speeds: X: 0,001 - 15.000 mm/min feed speeds: Z: 0,001 - 20.000 mm/min workpiece weight: 80 kg workpiece length - max.: 650 mm max. workpiece diameter: 349 mm table swivelabel +/-: 10 ° total power requirement: 20 kVA weight of the machine ca.: 9 t dimensions of the  ...

This 3-axis STUDER S33 CNC cylindrical grinding machine was manufactured in 2005 and completely overhauled in 2026, with 0 operating hours post-overhaul. It features a center height of 175 mm and a center distance of 1000 mm. The machine is equipped with a powerful 7.5 kW motor spindle and a control system with a 10.4 color touch screen. If you are looking to get high-quality grinding capabilities, consider the STUDER S33 CNC machine we have for sale. Contact us for further details.

A Studer CNC universal cylindrical grinding machine in need of repair is offered. Mains voltage/frequency: 380V/50Hz, control: Siemens SINUMERIK System 3, drive system: Siemens SIMODRIVE, measuring system: Marposs E5. Including various accessories. Documentation available. An on-site inspection is possible.

grinding diameter: 0,2 - 190 mm grinding length:400 mm centre height:100 mm weight of the machine ca.:1,6 t dimensions of the machine ca.:2 x 1,5 x 1,8 m

CONTROLS   CNC controls FANUC 0I-TFP WORKING RANGE CYLINDRICAL GRINDING   swing diameter (max): 350 mm   workpiece weight between centers (max): 80 kg WORKING RANGE EXTERNAL GRINDING   grinding diameter (max): 350 mm   grinding length: 400 mm WORKPIECE SPINDLESTOCK   spindle revolutions (max): 1500 /min   drive power: 3 kW   spindle bore diameter: 30 mm   tool fixture: MK 5   c-axis: yes   - positioning/indexing: 0.5 ° TAILSTOCK   distance betw. centers (max): 400 mm   sleeve stroke: 60 mm   taper: MK 4 SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 370 mm   Z-axis travel: 500 mm   tilting range (B-direction) min: 60 °   drive power: 9 kW GRINDING TOOL   diameter (max): 500 mm   borehole: diameter: 203.2 mm   width: 63 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx ...

grinding length: 1000 mm centre height: 175 mm b-axis: 1 ° max. dia. of grinding wheel: 500 mm internal grinding spindles: 60000 U/Min c-axis: 0.001 ° weight of the machine ca.: 5.7 t dimensions of the machine ca.: 4.25 x 2.2 x 2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Various flanges

grinding diameter: 250 mm grinding length: 400 mm centre height: 125 mm Control: Fanuc 21i-T total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Maschine gewartet und teilüberholt. -Neue Schleifspindellagerung -Neue x-Achs Spindel -Obertisch überschliffen -Neue Geometrie Tischgeometrie -Neue Geometrie WSS zu Schleifspindeln B-Achse mit 1° Hirth Verzahnung Längspositionierung HF-Innenschleifspindel GAP Papierbandfilter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Studer S20 cylindrical grinding machine

internal diameter: 99999 mm grinding depth: 99999 mm swing diameter: 99999 mm grinding diameter: 99999 mm grinding length: 200 mm centre height: 175 mm control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC internal grinding machine B-axis 4 x 90° Q-axis for adjusting tapers Used with minor maintenance 2 HF internal grinding spindles: -Fischer MFM 1090 90,000 rpm -Fischer MFM 1242/60 42,000-60,000 rpm 1 external grinding motor spindle Fischer MFVS1407 7,000 rpm -Pneumatic power clamping device with 20mm stroke -Dressing device with 2 swivelling arms, hydraulically foldable back -Grinding detection ring sensor Dittel on the workpiece headstock -Passive grinding detection with magnetic base -Paper belt filter 375 l The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: - mm grinding length: - mm centre height: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 250 mm grinding length: 650 mm centre height: 125 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Maschine wird mit Wartung und neuer Geometrie verkauft Betriebsstunden bisher 12260 Reitstock mit Feinverstellung Schleifspindelstock schwenkbar mit 5° Hirtverzahnung Papierbandfilter Marposs Messeinrichtung Innenschleifeinrichtung The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 155 mm grinding length: 400 mm centre height: 80 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 155 mm grinding length: 400 mm centre height: 80 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 155 mm grinding length: 400 mm centre height: 80 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
