Description Seiger lathe SLZ 800E x 4000 Details Machine no. 4443 Year of construction 2008 Siemens Cycle Control Spindle holder according to DIN 55027 size 11 Spindle bore Ø 130 mm Spindle diameter in the front bearing 170 mm Spindle taper 1:20 Drive power 20/28 kW Main spindle speed switching stage "I" 9-1,800 min-1 Main spindle speed switching stage "II" 9-400 min-1 Maximum torque: 3,200 Nm Center width 4,000 mm Circulation Ø above the bed 810 mm Circulation Ø above the face slide 540 mm Bed width 480 mm Machine dimensions 2,000+center width x 2,750 x 2,000 mm Permissible workpiece masses between points without setting stick 2,000 kg Permissible workpiece masses between points with a setting stick 2,200 kg Permissible workpiece masses between tips with two setting sticks 2,500 kg Permissible workpiece masses flying i ...
Key data: 1010 mm, 3000 mm
Cycle lathe Seiger SLZ 1000 Year of construction 2009 Cycle lathe Seiger SLZ 1000 Year of construction 2009 Center width 3000mm Circulation over bed 1010 Circulation via face slide 650 Drive at 100% ED 37KW at 60/ ED 52KW Max. torque approx. 9000NM Speed 5-900rpm X Feed force max 240000N Z Feed force max 16000N Control Heidenhain Manual Turn with face plate and steady rest The offer is aimed exclusively at tradespeople within the meaning of §14 BGB
Key data: 800 mm, 4000 mm
Description Seiger SLZ 800E cycle lathe incl. milling unit Details Machine no. 4443 Year of construction 2008 Control Siemens Sinumerik Turning diameter 800 mm Turning length 4,000 mm Face plate 800 mm, 4 jaws Face plate 500 mm, 4 jaws 3-jaw chuck 400 mm Lynette up to 450 mm (2 different) Accessories various jaw sets powered tool Permissible workpiece dimensions: between tips without setting stick 2,000 kg with a setting stick 2,200 kg with two sets 2,500 kg flying in the face plate 750 kg Machine dimensions incl. cladding 2,000 mm + Tip Wide x 2,750 mm x 2,000 mm incl. documentation
turning diameter:500 mm turning length:1500 mm spindle motor:16 kW Spindle RPM:1 - 2500 1/min taper in tailstock MT:5 tailstock quill stroke:160 mm tailstock quill diameter:70 mm total power requirement:22 kW weight of the machine ca.:3,2 t dimensions of the machine ca.:3,2 x 1,8 x 1,4 m Machine with Heidenhain Manual plus control - Multifix quick tool change device - 3-jaw chuck - sliding splash door - various accessories.
turning diameter:1250 mm turning length:6000 mm spindle bore:130 mm Turning rate:5 - 710 U/min. turning diameter over bed slide:850 total power requirement:37/52 kW weight of the machine ca.:16 t dimensions of the machine ca.:12 x 4 x 2 m Teach In Controll HEIDENHAIN 1 fixed steady
turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden
turning diameter:490 mm turning length:2000 mm total power requirement:15/20 kW weight of the machine ca.:3,6 t dimensions of the machine ca.:2,8 x1,85 x 1,9 m In like new condition Heidenhain cycle control Torsion-resistant bed, made of high-quality cast iron with hardened, precision-ground guideways and a glass scale on the X-axis Safety clutch on the Z and X axes Sealing air with carbon filter in direct position measuring system High accuracy and rigidity of the lathe spindle thanks to precision spindle bearings, spindle bore Ø 93 mm standard, optional Ø up to 130 mm Solid tailstock, quill Ø 90 mm with internal taper MK5 Large overhang above the facing slide for easy accessibility during shaft machining. The machine has Teach-in CNC Programms. Control: MC420. Tool holder: SAUTER. Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. U ...
turning diameter: 1800 mm turning length: 600 mm control: Siemens 6 - Jaw Chuck: ? spindle bore: 130 mm spindle nose: DIN 55027 Größe 11 turning speed range: 1 - 400 U/min max. torque on the spindle: 9000 total power requirement: 38 / 52 kW weight of the machine ca.: 25 t dimensions of the machine ca.: 6x3x2,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bed width: 350 mm turning length: 1.000 mm control: Manual plus 620 Heidenhain greates pass round over bed: 430 mm Swing dia. over traverse guideway: 220 mm Main spindle:: turning speed range - main spindle: 1 - 3.600 min/-1 power capacity - main spindel: 9 / 11 kW max. Torque: ca. 200 Nm spindle head: DIN 55027 / 6 spindle diameter in front bearing: 110 mm spindle bore: 80 mm usable bar diameter: max. 80 mm Tool Mount:: System: MultiFix Shank diameter: 20 x 20 mm axis stroke:: x-axis: 230 mm z-axis: ca. 1.000 mm Tailstock:: diameter of quill: 70 mm quill stroke: 150 mm taper of center: MK 5 steady: hollow: fix: 12 -150 mm hollow: var: 12 -125 mm feeds:: rapid traverse: X: 10 / Z: 7 m/min feed power: X: 4 / Z: 5 kN total power requirement: - kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 2,8 x 2,1 x 1,9 m Documents: Tailstock: steady rest: 1x Coolantsystem: M ...
turning diameter: 1010 mm turning length: 6000 mm control: Siemens type: Sinumerik 840D turning diameter over slide rest: 650 mm 3-jaw chuck: Schunk Rota Plus 3-jaw-chuck diameter: 500 mm bed width: 750 mm steady: 820 mm Rotating speeds: 1100 U/min length of gap: 500 mm steady: 450 mm spindle passage: 104 mm workpiece weight: 7000 kg main drive: 52 kW turning speeds: 5-900 U/min total power requirement: . kW weight of the machine ca.: . t dimensions of the machine ca.: . m Serial number: 262/01 Machine number: 08122394 Quick-change tool post Coolant system Monitor Chip conveyor The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessorie ...
turning diameter: 1010 mm turning length: 6000 mm control: Siemens type: Sinumerik 840D turning diameter over slide rest: 650 mm 3-jaw chuck: Schunk Rota Plus 3-jaw-chuck diameter: 500 mm bed width: 750 mm steady: 450 mm Rotating speeds: 1100 U/min length of gap: 500 mm steady: 450 mm spindle passage: 104 mm workpiece weight: 7000 kg main drive: 52 kW turning speeds: 5-900 U/min live tooling: total power requirement: . kW weight of the machine ca.: . t dimensions of the machine ca.: . m Serial number: 262/01 Machine number: 08122394 Quick-change tool post Coolant system Monitor Chip conveyor The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items ...
turning diameter: 1600 mm turning length: 6200 mm control: Siemens type: Sinumerik turning diameter over slide rest: 1300 mm transmission ratio: . 3-jaw chuck: Schunk Rota Plus 3-jaw-chuck diameter: 630 mm bed width: 750 mm live tooling: steady: 1200 mm steady: 670 mm steady: 408 mm total power requirement: . kW weight of the machine ca.: . t dimensions of the machine ca.: . m Serial number: 262/01 Machine number: 08122394 Quick-change tool post Coolant system Monitor Chip conveyor The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your busines ...
turning diameter: 570 mm turning length: 2000 mm control: ja weight of the machine ca.: 3,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning length: 2000 mm : 980507 x-axis: 7000 mm z-axis: 10000 mm : 65 mm total power requirement: 15 kW weight of the machine ca.: 3,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Seiger SLZ1000 (2009) – Short Details - Type: Heavy-duty cycle lathe (Zyklen-Drehmaschine) See picutres for specs The SLZ1000 is known for its stability, precision, and suitability for heavy-duty turning tasks, especially with large or long workpieces Find more here - / Contact us at -
turning diameter: 570 mm turning length: 2000 mm control: total power requirement: 15 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
